1. General Description
Non-Contact Forehead IR Thermometer is specially designed to take
the body temperature of a person regardless of room temperature.
Depending on various skin types and thickness, there may be
temperature dierence.
2. Safety Information
• This device must only be used for the purposes described in this
instruction manual
• This device must only be used in an ambient temperature range
between 10 and 40°C
• Do not expose this thermometer to electic shocks.
• Do not expose this thermometer to extreme temperature conditions
of >50°C or <0°C
• Do not use the device in relative humidity higher than 85%.
• Do not use the device near large electromagnetic fields such as
found with cordless or cell phones.
• Keep the device away from water and heat, including direct sunlight.
• Do not drop or knock the device, and do not use if damaged.
• It may aect the accuracy of measurements when the forehead is
covered by hair, perspiration, cap or scarf. (See Part 10-4)
• Keep the Measuring distance as 1cm-10cm (0.39in-3.9in).
(See Part 10-4)
• When the body infrared thermometer should be left in that room
during 1 5 to 20 minutes before using.
• It may aect the accuracy of measurements when the forehead is
covered by perspiration or other factors, please take the temperature
behind the ear lobe.(See Part 10-5)
• Clean the glass with a cotton bud lightly moistened with 70% alcohol.

4English
Importance:
• Before taking of the temperature make sure to remove hair and
perspiration from the forehead.
• Selecting "Body" mode to measure the body temperature; Selecting
"Surface" mode to measure the surface temperature.
• Use of this thermometer is not intended as a substitute for
consultation with your physician.
• Should a problem occur with your device,please contact your retailer.
Do not attempt to repair the device yourself.
• According to EMC standard, the medical electronic products should
be maintained specially.
3. Features
• Precise non-contact measurements
• User selectable °C or °F
• Selectable Body and Surface temp
• Set Alarm value
• Memorization of the last 32 measurements
• Automatic Data Hold & Auto power o
• Display Resolution 0.1°C(0.1°F)
• Backlight LCD display
4. Intended Use
Non-Contact Forehead IR Thermometer is designed for body surface
and forehead temperature measurement for infants and adults without
contact to human body.
Non-Contact Forehead IR Thermometer can also be used to measure
the temperature of a baby-bottle or bath, or room temperature (by using
the Surface Temp function).

English 5
Normal Temperatures According To Measurement Method
Measurement Method Normal Temp °C Normal Temp °F
Rectal 36.6 to 38 97.8 to 100.4
Oral 35.5 to 37.5 95.9 to 99.5
Axillary 34.7 to 37.3 94.4 to 99.1
Ear 35.8 to 38 96.4 to 100.4
The temperature of the human body varies throughout the day. It can
also be influenced by numerous external factors: age, sex, type and
thickness of skin...
Normal Temperatures According To Age
Aqe Temp °C Temp °F
0-2 years 36.4 to 38.0 97.5 to 100.4
3-10 years 36.1 to 37.8 97.0 to 100.0
11-65 years 35.9 to 37.6 96.6 to 99.7
>65 years 35.8 to 37.5 96.4 to 99.5

6English
5. Configuration
1. LCD Display
2. Mode Selection
3. IR Sensor
4. Down Button
5. Up Button
6. Mode Button
7. Measurement Trigger
8. Battery Cover
2
3
4
7
5
6
8
1
6. Indicator
1. Surface mode Symbol
2. Body mode Symbol
3. Digital readout
4. Battery Symbol
5. The order number
6. Save data readout
7. Temperature °C(Celsius)/
°F(Fahrenheit) Scale
8. Buzzer symbol
Surface temp
Body
1
2
3
5
8
7
4
6

English 7
7. Technical Specifications
Normal Conditions of Use
Display Resolution 0.ГС (0.1 °F)
Operating Temperature 10 to 40°C (50 to 104°F)
Storage Temperature Oto 50°C (32 to 122°F)
Humidity Rate <85%
Power DC 3V (2 x "AAA" batteries)
Size 128x74x36 mm/5x2.9 x 1.4 in (LxWxH)
Weight Gross 125.4g/ Net 104.5g
Measuring Range
In Body Mode 32.0 to 42.5°C (90 to 108°F)
In Surface Temp Mod 0 to 60CC (32 to 140°F)
Accuracy ± 0.3°C (0.54°F)
Measuring Distance 1 cm - 10 cm (0.39 in - 3.9 in)
Automatic Stop 7 sec.
Non-contact Body Infrared Thermometer Precision
32 to 35.9^/93.2 to 96.6°F ± 0.3°C/ 0.5°F According to ASTM
Standard E1965-
1998 (2003)
36 to 39°C/ 96.8 to 102.2°F ± 0.2°C/0.4°F
39 to 42.5°C/102.2 to 108.5°F ± 0.3°C/0.5°F

8English
8. Description of Symbols
The device is in accordance with Medical Device Directive
93/42/EEC
The device is in accordance with FCC Part 15 Subpart
B:2007/Radio Frequency Devices IC Regulation ICEC-
003: 2004 Interference-causing Equipment Standard-
Digitial Apparatus
3V DC power supply
Type В equipment
In order to protect the environment, please recycle the
battery according to the local regulations
Body
Surface Indication of Mode
Attention,consult accompanying documents
9. Use
9-1. Install battery
9-2. For the first use or when inserting new batteries wait between 10 minutes
for the warm-up of the apparatus and when inserting the new batteries.
9-3. If the device is not used for a long time, once you turn it on again,
the device will test the room temperature first and will delay turning on
for one or two seconds.
9-4. Aim towards the forehead (see the diagram below for the
positioning), from a distance of 5cm(2in), press the measuring key,
thetemperature is displayed immediately. Making sure there is no hair,
perspiration, cosmetic or cap covered on the forehead.

English 9
1 to 10 cm
0.39 to 3.9in
9-5. When the room temperature is significant dierence, or there is
perspiration on the forehead, You can take the temperature behind the
ear lobe. Making sure there is no hair, perspiration, cosmetic or cap
covered.
1 to 10 cm
0.39 to 3.9in
10. Measuring Operation
10-1. Choosing The Temperature Unit - F1 Function
Press "MODE" button for 2 seconds, the screen displays: F1. Select
"DOWN" for degrees Celsius, "UP" for degrees Fahrenheit.
10-2. Alarme Setup - F2 Menu
Press "MODE" touch for 2 seconds, the screen displays: F1 .Press
twice "MODE" touch to get F2. Select "UP" to increase the threshold by
0.1 °C (0.1 °F), "DOWN" to reduce it by 0.1 °C (0.1 °F).
Note: The alarm threshold default value is 38°C (100.4°F).
10-3. Total Dierence - F3 Menu

10 English
To adjust the total variation of your the Non-contact Body Infrared
Thermometer.
Press "MODE" button for 2 seconds, the screen displays: F1. Press
"MODE" button two times to get F3. Select "UP" to increase the
dierence by 0.1°C (0.1°F), "DOWN" to reduce itby 0.1°C (0.1°F).
ln the cases of seasonal or environmental changes a verification and
adjustment should be carried out.
Note: This function is only eective Body
10-4. Buzzer ON/OFF - F4(F3) Menu
Press "MODE" button for 2 seconds, the screen displays: F1. Press
three(two) times "MODE" button to get F4(F3).
Select "UP" to open the buzzer (a sound icon " " is displayed on the
LCD screen), press "DOWN" to stop it (the icon disappear).
10-5. Exiting The Setting Mode
Press "MODE" button until the screen turns o.
10-6. The Non-contact Body Infrared Thermometer is specially designed
to take the body temperature of a human being. For this, use the Body
mode. Measurement range for Body mode: 32 to 42.5°C (86 to 108°F)
You can also use the Non-contact Body Infrared Thermometer to
measure the temperature of an area or an object, a food, a liquid or a
room temperature. For this, use the Surface mode. Measurement range
for Surface mode: 0 to 60°C (32 to 140°F)
Important: The area temperature diers from the internal body
temperature. To obtain the internal temperature always use the Body mode.
Please make sure to select the Body mode for an internal temperature reading
and the Surface mode for an external area reading (bottle, bath, room...).
10-7. Data Memory
Data memory automatically after temperature measurements, which will
display at the right corner of LCD. Press "UP" or "DOWN" button to
display the last temperature measurement.

English 11
Under the condition of power o, press "UP" and "DOWN" button
together for two seconds, to display the last temperature measurement.
At this mode if change the order number to 0 and press "MODE"
button, then delete all memory data.
10-8. Changing The Batteries
Display: when the LCD screen displays " ", the battery is used.
Operation: Open the lid and change the batteries, taking great care
with the correct positioning. A mistake with this could cause damage
to the apparatus and compromise the guarantee of your Non-contact
Body Infrared Thermometer. Never use rechargeable batteries. Use only
batteries for single usage.
Remove the battery from the instrument if it is not required for extended
periods of time in order to avoid damage to the thermometer resulting
from a leaking battery.
10-9. Longevity Use
The Non-contact Body Infrared Thermometer was conceived for an
intense and professional use, its longevity is guaranteed for 40000
takings.
11. Advice
• The protective glass over the lens is the most important and fragile
part of the thermometer, please take great care of it.
• Do not recharge non rechargeable batteries, do not throw in fire.
• Do not expose the thermometer to sunlight or water.
12. Maintenance and Cleaning
• The Infrared Sensor is the most precise part, must be protected
carefully.
• Clean the device with a cotton bud lightly moistened with 70%
alcohol.
• Do not clean the device with corrosive detergent.
• Keep the device away from water or other liquid.

12 English
• Store the device in a dry environment, and keep it away from dust
and direct sunlight.
13. Troubleshooting
If you happen to have one of the following problems while using your the
non-contact forehead IR thermometer please refer to this breakdown
service guide to help resolve the problem. If the problem persists please
contact our customer service.
The screen displays the body temperature inferior to 32°C (89.6°F)
If you're on Surface mode the 32°C(89.6°F) temperature displayed is
showing the external temperature that your body releases.
The screen displays the message "HI"
When using the Non-contact Body
Infrared Thermometer the message
"HI" can show on the screen.
The analysis is above the measurement
range selected, either superior to
42.5°C (108°F) in Body mode or
superior to 60°C (140°F) in Surface
mode.
Body
The screen displays the message "LO"
When using the Non-contact Body
Infrared Thermometer the message Lo
can show on the screen.
The temperature analyzed is under the
measuring range selected, either less
than 32°C (90°F) in Body mode or less
than 0°C (32°F) in Surface mode.
Body

English 13
This message displays in various cases - please find below a list
of the main cases.
Reasons for "LO" or "HI"
message display
Advice
Temperature reading hampered
by hair, perspiration...
Make sure that there is no
obstruction prior to taking
atemperature.
Temperature hampered by an
air flux.
Make sure there is no air flux
as this could interfere with the
infrared system.
The measuring distance is too far. Please respect the measuring
distance (between 1 to 10 cm -
0.39 to 3.9 in).
From high/low temperature
condition to room temperature
Waiting for 10 minutes before
taking the body temperature
14. This appliance conforms to the following standards:
• EN 980: Graphical symbols for use in the labeling of medical devices
EN1041 information supplied by the manufacturer with medical diveces
• EN 60601-1: Medical electrical equipment Part 1: General
requirements for safety (IEC60601 -1:1998)
• EN 60601-1-2: Medical electrical equipment Part 1-2: General
requirements for safety Collateral standard Electromagnetic
compatibility Requirements and test (IEC 60601-1-2:2001)
EMC Statement
This device has been tested and homologated in accordance with
EN60601 -1 -2:2007 for EMC. This does not guarantee in any way that
the device will not be aected by electromagnetic interference. Avoid
using the device in high electromagnetic environment.

14 English
The MEDICAL DELECTRICAL EQUIPMENT needs special precautions
regarding EMC and needs to be installed and put into service according
to the EMC information provided in the ACCOMPANYING DOCUMENTS.
The manufacturer reserves the right to alter the specifications of the
product without prior notification.
The manufacturer allows himself the right to modify without any
preliminary opinion the technical specifications of the product.
Table 201 -Declaration - electromagnetic emissions
Guidance and manufacturer's declaration - electromagnetic emissions
The Model Number or Type Number - by manufacturer is intended for
use in the electromagnetic environment specified below. The customer or
the user of the Model Number or Type Number - by manufacturer should
assure that it is used in such an environment.
Emissions test Compliance Electromagnetic environment
guidance
RF emissions
CISPR 11
Group 2 The Model Number or Type
Number - by manufacturer must
emit electromagnetic energy in
order to perform its Intended
function. Nearby electronic
equipment may be aected.
RF emissions
CISPR11
Class В The Model Number or Type
Number - by manufacturer
Is suitable for use in all
establishments other than
domestic and those directly
connected to the public low-
voltage power supply network
that supplies buildings used for
domestic purposes.
Harmonic
emissions
IEC61000-3-2
Not applicable
Voltage fluctuations
/ flicker emissions
IEC61000-3-3
Not applicable

English 15
Table 202 - Declaration - electromagnetic immunity
Guidance and manufacturer's declaration — electromagnetic immunity
The Model Number or Type Number - by manufacturer is intended for
use in the electromagnetic environment specified below. The customer or
the user of the Model Number or Type Number - by manufacturer should
assure that it is used in such an environment.
Immunity test IEC 60601 test
level
Compliance
level
Electromagnetic
environment -
guidance
Electrostatic
discharge
(ESD)
IEC61000-4-2
± 6 kV contact
± 8 kV air
± 6 kV contact
± 8 kVair
Floors should be
wood, concrete or
ceramic tile. If floors
are covered with
synthetic material,
the relative humidity
should be at least
30 %.
Table 204 - Declaration - electromagnetic immunity
Guidance and- manufacturer's declaration. Electromagnetic immunity
The Model Number or Type Number - by manufacturer is intended for use
in. the electromagnetic environment specified below. The customer or
the user of the Model Number or Type Number - bymanufacturer should
assure that it is used in such an environment.
Immunity test IEC 60501 test
level
Compliance
level
Electromagnetic environment - guidance
Portable and mobile RF communications equipment should be used no
closer to any part of the Model Number or Type Number - by manufacturer,
including cables, than the recommended separation distance calculated
from the equation applicable to the frequency of the transmitter.

16 English
Recommended
separation
distance
Conducted RF
IEC 61000-4-6
3 Vrms 150 kHz
to 80 Mhz
3 Vrms d = 1,2√p
Radiated RF
IEC61000-4-3
3 V/m
80 MHz to 2.5
GHz
3 V/m d = 1,2√p,
80MHz to
800MHz
d = 2,3√р,
800MHz to
2,5MHz
where P is the maximum output power rating of the transmitter In watts
(W) according to the. transmitter manufacturer and d is the recommended
separation distance in meters (m).
Field strengths from fixed RF transmitters, as determined by an
electromagnetic site survey, should be less than the compliance level in
each frequency range
Interference may occur In the vicinity of equipment marked with the
following symbol:
NOTE I At 80 MHz end 800 MHz. the higher frequency range applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic
propagation is aected by absorption and reflection from structures,
objects and people.

English 17
Field strengths from fixed transmitters, such as base stations for radio
(cellular/cordless) telephones and land mobile radios, amateur radio,
AM and FM radio broadcast and TV broadcast cannot be predicted
theoretically with accuracy. To assess the electromagnetic environment
due to fixed RF transmitters, an electromagnetic site survey should be
considered. If the measured field strength in the location in which the
Model Number or Type Number - by manufacturer is used exceeds
the applicable RF compliance level above, the Model Number or Type
Number - by manufacturer should be observed to verify normal operation.
If abnormal performance is observed, additional measures may be
necessary, such as reorienting or relocating the Model Number or Type
Number - by manufacturer.
Over the frequency range 150 kHz to 80 MHz, field strengths should be
less than [Vi] V/m.
Table 206 - Recommended separation distances between
portable and mobile
RF communications equipment and the Model Number or
Type Number - by manufacturer
Recommended separation distances between
portable and mobile RF communications equipment and the Model
Number or Type Number - by manufacturer
The Model Number or Type Number - by manufacturer is intended for
use in an electromagnetic environment in which radiated RF disturbances
are controlled. The customer or the user of the Model Number or Type
Number - by manufacturer can help prevent electromagnetic interference
by maintaining a minimum distance between portable and mobile RF
communications equipment (transmitters) and the Model Number or Type
Number - by manufacturer as recommended below, according to the
maximum output power of the communications equipment.

18 English
Rated maximum
output power of
transmitter W
Separation distance according to frequency of
transmitter m
150 kHz
to 80 MHz
d = 1,2√p
80 MHz
to 800 MHz
d = 1,2√p
800 MHz
to 2,5 GHz
d = 2,3√p
0,01 0.12 0.12 0.23
0,1 0.38 0.38 0.73
11.2 1.2 2.3
10 3.8 3.8 7.3
100 12 12 23
For transmitters rated at a maximum output power not listed above,
therecommended separation distance d in meters (m) can be estimated
using the equation applicable to the frequency of the transmitter, where
P is the maximum output power rating of the transmitter in watts (W)
accordable to the transmitter manufacturer.
NOTE I At 80 MHz and 800 MHz. the separation distance for the higher
frequency range applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic
propagation is aected by absorption and reflection from structures,
objects and people.

19Nederlands
Inhoudsopgave
1. Algemene beschrijving.................................................................... 20
2. Veiligheidsinformatie ...................................................................... 20
3. Kenmerken ..................................................................................... 21
4. Beoogd gebruik.............................................................................. 22
5. Onderdelen..................................................................................... 23
6. Display............................................................................................ 23
7. Technische specificaties.................................................................. 24
8. Betekenis van symbolen............................................................... 25
9. Gebruik........................................................................................... 25
10.Measuring Operation ..................................................................... 26
11. Belangrijk!...................................................................................... 28
12. Onderhoud en reiniging................................................................. 28
13. Problemen oplossen..................................................................... 29
14. Dit apparaat voldoet aan de volgende normen ............................. 30

20 Nederlands
1. Algemene beschrijving
De Contactloze Infrarood Voorhoofdthermometer is speciaal ontworpen
om de lichaamstemperatuur van personen te meten, ongeacht de
omgevingstemperatuur. Afhankelijk van verschillende huidtypes en
-diktes kan er een temperatuurverschil zijn.
2. Veiligheidsinformatie
• Dit apparaat mag alleen worden gebruikt voor de doeleinden die
worden beschreven in deze gebruikershandleiding.
• Dit apparaat mag alleen worden gebruikt bij een
omgevingstemperatuur tussen 10°C en 40°C.
• Stel deze thermometer niet bloot aan elektrische schokken.
• Stel deze thermometer niet bloot aan extreme temperaturen van
>50° C of <0°C.
• Gebruik het apparaat niet bij een relatieve luchtvochtigheid van meer
dan 85%.
• Gebruik het apparaat niet in de buurt van grote elektromagnetische
velden, zoals bij draadloze apparaten of mobiele telefoons.
• Houd het apparaat uit de buurt van water en hitte, inclusief direct
zonlicht.
• Laat het apparaat niet vallen, stoot het niet en gebruik het niet als het
beschadigd is.
• De nauwkeurigheid van metingen kan beïnvloed worden wanneer
het voorhoofd bedekt is met haar, een muts of sjaal of bij transpiratie.
(Zie 10-4)
• Zorg ervoor dat de meetafstand tussen de 1 en 10 cm ligt. (Zie 10-4)
• De thermometer dient zich ten minste 15 tot 20 minuten vóór gebruik
te bevinden in de ruimte waar de meting zal plaatsvinden.
• Wanneer er zich transpiratie op het voorhoofd bevindt of het voorhoofd
bedekt is, kan dit de nauwkeurigheid van metingen beïnvloeden. Neem
in dat geval de temperatuur achter de oorlel op. (Zie 10-5)
