SenTech STC-SCS231POE Installation instructions

No.15S085-04
1/44
STC-SCS231POE,STC-SBS231POE
Product Specifications and User’s Guide
GigE Vision Camera
2.3Meg CMOS Color / Monochrome
STC-SCS231POE (2.3M Color)
STC-SBS231POE (2.3M Monochrome)
Product Specifications and User’s Guide
Sentech Co., Ltd

No.15S085-04
2/44
STC-SCS231POE,STC-SBS231POE
Product Specifications and User’s Guide
Product Precautions
Handle the camera with care. Do not abuse the camera. Avoid striking or shaking it. Improper handling or
storage could damage the camera.
Do not pull or damage the camera cable.
During camera use, do not wrap the unit in any material. This will cause the internal temperature of the unit
to increase.
Do not expose the camera to moisture, or do not try to operate it in wet areas.
Do not operate the camera beyond its temperature, humidity and power source ratings.
While the camera is not being used, keep the lens or lens cap on the camera to prevent dust or
contamination from getting in the Sensor or filter area and scratching or damaging this area.
Do not keep the camera under the following conditions:
In wet, moist, and high humidity areas
Under hot direct sunlight
In high temperature areas
Near an object that releases a strong magnetic or electric field
Areas with strong vibrations
Apply the power that satisfies the requirements specified in this document to the camera.
Use a soft cloth to clean the camera. Use pressured air spray to clean the surface of the glass. DO not
scratch the surface of the glass.
The camera is a general-purpose electronic device; using the camera for the equipment that may threaten
human life or cause dangers to human bodies directly in case of failure or malfunction of the camera is not
guaranteed. Use the camera for special purposes at your own risk.

No.15S085-04
3/44
STC-SCS231POE,STC-SBS231POE
Product Specifications and User’s Guide
Table of Contents
1INTRODUCTION.................................................................................................... 6
1.1 Features .................................................................................................................................... 6
1.2 Naming Method ........................................................................................................................6
2SPECIFICATIONS ................................................................................................. 7
2.1 Electronic Specifications (STC-SBS231POE / STC-SCS231POE)........................................7
2.2 Spectral Sensitivity Characteristics .......................................................................................8
STC-SBS231POE............................................................................................................................... 82.2.1
STC-SCS231POE (Sensor spectral response, without IR cut filter) .............................................. 82.2.2
2.3 Mechanical Specifications....................................................................................................... 9
2.4 Environmental Specifications.................................................................................................9
Upper side of camera.................................................................................................................................................... 9
2.5 Connector Specifications...................................................................................................... 10
RJ45 Connector .............................................................................................................................. 102.5.1
Power and control signal connector ..............................................................................................112.5.2
Equivalent Circuit for the Input Pin of the I/O Connector............................................................. 132.5.3
Typical Input Circuit........................................................................................................................ 142.5.4
Typical Output Circuit..................................................................................................................... 152.5.5
Input and Output Signal Timing (Hardware Trigger)..................................................................... 162.5.6
Input and Output Signal Timing (Software Trigger)...................................................................... 172.5.7
3DIMENSIONS ...................................................................................................... 18
3.1 STC-SBS231POE.................................................................................................................... 18
3.2 STC-SCS231POE.................................................................................................................... 19
4SENSOR INFORMATION .................................................................................... 20
4.1 Pixel Transferring Image........................................................................................................ 20
5CAMERA OPERATIONAL MODES..................................................................... 21
5.1Normal Mode........................................................................................................................... 21
5.2 Pulse width trigger mode....................................................................................................... 21

No.15S085-04
4/44
STC-SCS231POE,STC-SBS231POE
Product Specifications and User’s Guide
Timing.............................................................................................................................................. 215.2.1
Exposure Timing with the Positive Polarity Trigger Signal.......................................................... 225.2.2
Exposure Timing with the Negative Polarity Trigger Signal ........................................................ 225.2.3
5.3 Edge Preset Trigger Mode..................................................................................................... 23
Timing.............................................................................................................................................. 235.3.1
Exposure Timing with the Positive Polarity Trigger Signal.......................................................... 245.3.2
Exposure Timing with the Negative Polarity Trigger signal......................................................... 245.3.3
5.4 Edge Preset Trigger Mode (Trigger Input While the Image Is Out)..................................... 25
Timing.............................................................................................................................................. 255.4.1
6CAMERA OPERATION........................................................................................ 26
6.1 GenICam command list ......................................................................................................... 26
6.2 Save and load the camera setting data ................................................................................ 29
The camera settings saving........................................................................................................... 296.2.1
The camera settings loading.......................................................................................................... 306.2.2
The camera settings loading when the camere power is on........................................................ 306.2.3
The camera settings initialization.................................................................................................. 306.2.4
6.3 Gain ......................................................................................................................................... 31
Analog gain ..................................................................................................................................... 316.3.1
Digital gain ...................................................................................................................................... 316.3.2
6.4 Black level............................................................................................................................... 31
6.5 ALC (Auto Light Control)....................................................................................................... 32
ALC control method........................................................................................................................ 336.5.1
AGC (Auto Gain Contorl)................................................................................................................ 336.5.2
Auto shutter .................................................................................................................................... 346.5.3
ALC settings procedure ................................................................................................................. 346.5.4
6.6 White balance (Only available for the color cameras) ........................................................ 35
White balance control methods..................................................................................................... 356.6.1
6.6.1.1 OFF............................................................................................................................................... 35
6.6.1.2 Auto white balance...................................................................................................................... 36
6.6.1.3 Push to set white balance........................................................................................................... 36
6.6.1.4 Preset white balance1 to 3.......................................................................................................... 36
White balance calculate area setting............................................................................................. 376.6.2
6.7 Gamma correction.................................................................................................................. 38
Gamma table writing....................................................................................................................... 386.7.1
6.8 ROI (Region of Interest)......................................................................................................... 39
6.9 Trigger..................................................................................................................................... 40
Trigger signal processing procedure ............................................................................................ 406.9.1
6.1 The camera settings (GenICam parameters) control with SDK.......................................... 41

No.15S085-04
5/44
STC-SCS231POE,STC-SBS231POE
Product Specifications and User’s Guide
Integer type parameter control ...................................................................................................... 416.1.1
Float type parameter control.......................................................................................................... 416.1.2
Enumeration type parameter control............................................................................................. 416.1.3
String type paramter control.......................................................................................................... 426.1.4
Boolean type parameter control.................................................................................................... 426.1.5
Command type paramter control................................................................................................... 426.1.6
7REVISION HISTORY ........................................................................................... 43

No.15S085-04
6/44
STC-SCS231POE,STC-SBS231POE
Product Specifications and User’s Guide
1 Introduction
This document describes the specification of the following cameras:
STC-SCS231POE (2.3M Color)
STC-SBS231POE (2.3M Monochrome)
1.1 Features
CMOS (Global Shutter)
GigE Interface
Support PoE (Power over Ethernet)
The maximum allowed frame rate is 41.6 fps (8bit)
1.2 Naming Method
STC-SxS231POE
Figure 1: Naming Method
B: Mono Chrome
C: Color

No.15S085-04
7/44
STC-SCS231POE,STC-SBS231POE
Product Specifications and User’s Guide
2 Specifications
2.1 Electronic Specifications (STC-SBS231POE / STC-SCS231POE)
製品
STC-SBS231POE
STC-SCS231POE
Imager
1/1.2" 2.3Meg Monochrome progressive CMOS
(Sony: IMX249)
1/1.2" 2.3Meg color progressive CMOS
(Sony: IMX249)
Shutter Type
Global Shutter
Active Picture Elements
1920 (H) x 1200 (V)
Cell Size
5.86 (H) x 5.86 (V) µm
Scanning System
Progressive
Scanning mode
Full scanning (Full resolution) / ROI
Frame rate
8bit:41.6 fps、10bit:22.8fps、10bitPacked:30.4fps、
12bit:22.8bit、12bitPacked:30.4fps
ADC bit depth
12bit, 10bit
Video Output Format
Mono8,Mono10,Mono10Packed,
Mono12,Mono12Packed
BayerBG8, BayerBG10, BayerBG10Packed,
BayerBG12, BayerBG12Packed
Noise
Level
@ 8bit output
≤ 1.5 Digit (Gain 0 dB)
@ 10bit output
≤ 6 Digit (Gain 0 dB)
@ 12bit output
≤ 24 Digit (Gain 0 dB)
Sensitivity
580 Lux
1120 Lux
Minimum Scene Illumination
Less than 1 Lux
Less than 4.8 Lux
ALC
Auto shutter / Auto gain (AGC) / Manual (Default: Auto shutter OFF, AGC OFF)
Electronic Shutter
34 useconds to 16,777,215 useconds
12bit: Edge Preset Trigger, Free run mode: 34 useconds to 16,777,215 useconds
Pulse Width Trigger: 25 useconds to 16,777,215 useconds
8bit,10bit: Edge Preset Trigger, Free run mode: 39 useconds to 16,777,215 useconds
Pulse Width Trigger:: 20 useconds to 16,777,215 useconds
Gain
Analog
0 to 24 dB (Default: 0dB)
Digital
0 to 9.5 dB (Default: 0dB)
Gamma
Gamma 1.0 or up loadable gamma table (Default:1.0)
Binning Function
Not supported
Decimation Function
Individual x2 Horizontal, Vertical decimation
Mirror image
Horizontal / Vertical / Horizontal and vertical / Off (Default: Off)
ROI Function
Variable ROI setting through the communication
White Balance
N/A
Auto / Manual / Push to Set (Default: Manual)
Operational Mode
Continuous / Edge preset trigger /
Pulse width trigger (Min. active pulse duration: 19.3939useconds @ 10bits, 24.8889useconds @
12bits) (Default: Continuous)
Communication
UART communication through Ethernet port
Interface
IEEE802.3af CLASS2 (1000BASE-T)
Protocol
GigE Vision® 1.2 and GenICam™ Standard Version 2.1 (SFNC 1.4)
I/O
One opt-isolated input and two open collector outputs
Power
Input Voltage
+10.8 to +26.4 Vdc
Consumption
(Max/Default)
+12V: 3.0W, +24V: 3.6W, PoE: 3.0W
Table 1: Electronic Specifications of STC-SCS231POE/ STC-SBS231POE

No.15S085-04
8/44
STC-SCS231POE,STC-SBS231POE
Product Specifications and User’s Guide
2.2 Spectral Sensitivity Characteristics
STC-SBS231POE2.2.1
Figure 2: Sensor Spectral Response (Mono)
STC-SCS231POE (Sensor spectral response, without IR cut filter)2.2.2
Figure 3: Sensor Spectral Response (Color)

No.15S085-04
9/44
STC-SCS231POE,STC-SBS231POE
Product Specifications and User’s Guide
2.3 Mechanical Specifications
Model Number
STC-SBS231POE
STC-SCS231POE
Dimensions
35 (W) x 35 (H) x 53.4 (D) mm *
35 (W) x 35 (H) x 53.7 (D) mm *
Optical Filter
No Filter
IR cut filter
Optical Center Accuracy
Positional accuracy in Horizontal and Vertical directions:: +/- 0.3 mm
Rotational accuracy of Horizontal and Vertical: +/- 2.0 deg.
Material
Aluminum Alloy(AC)
Lens Mount
C mount
Connectors
RJ45 connector
Power- I/O connector: HR10A-7R-6PB (Hirose) or equivalent
Camera Mount Screws
Two 1/4” Tripod screw holes: (One on each top and bottom plate),
Twelve M4 screws holes: (Four on each top and bottom plate, two on each side plate)
Weight
Approximately 100g
* excluding the connectors
Table 2: Mechanical Specifications
2.4 Environmental Specifications
Model Number
STC-SBS231POE / STC-SCS231POE
Operational
Temperature
Minimum
Environmental Temperature -5⁰C
Maximum
Camera housing temperature (top plate) shall not exceed 60⁰C
(This corresponds to an environmental temperature of approximately 40⁰C)
Storage temperature
Environmental Temperature: -20⁰C to 65⁰C
Storage humidity
Less than 85%
Vibration
20Hz to 200Hz to 20Hz (5min./cycle), acceleration 10G, XYZ 3 directions, 30 min. each)
Shock
Acceleration 38G, half amplitude 6ms, XYZ 3 directions, 3 times each
Standard Compliancy
EMS: EN61000-6-2, EMI: EN55011
RoHS
RoHS Compliance
Table 3: Environmental Specifications
Note: When the camera is used in surrounding temperatures that exceed 40⁰C, please make sure that the camera
is set up to properly radiate heat (maintaining the camera’s top case plate’s temperature to be less than 60⁰C).
Taking these steps will maintain the heat rating of the electronic components of the camera.
Upper side of camera
Measuring point

No.15S085-04
10/44
STC-SCS231POE,STC-SBS231POE
Product Specifications and User’s Guide
2.5 Connector Specifications
Figure 4: Camera Connector
RJ45 Connector2.5.1
This product is PoE compliant.
Please supply power (+10.8 to +26.4Vdc) through the power-I/O connector when using non-PoE-compliant
NIC.
Pin Assignment LED
Pin No.
Signal Name
1
TA+
2
TA-
3
TB+
4
TC+
5
TC-
6
TB-
7
TD+
8
TD-
Figure 5: LED Information (on 1GB NIC)
Please use a 1GB supported NIC, Network Switcher and LAN cable. Check that the NIC and Network
Switcher being used is “1GB transferring”.
For the detail of Connection, please see “System Configurations (Example Connections)”.
Green LED
Orange LED
Status
Green Light ON
Orange Light ON
Power ON(1GB NIC)
Green Light OFF
Orange Light OFF
Power ON(100MB NIC)
Green Light ON
Orange Light Blinking
1Gb Transferring
Green Light OFF
Orange Light Blinking
100 Mb Transferring
he camera is powered-on
Green light: ON
Orange light: Blinking
1 GB Transferring
Green light: OFF
Orange light: Blinking
100 MB Transferring
Power-I/O Connector
RJ45 Connector
Orange LED
Green LED

No.15S085-04
11/44
STC-SCS231POE,STC-SBS231POE
Product Specifications and User’s Guide
Power and control signal connector2.5.2
HR10A-7R-6PB（Hirose）or equivalent
This connector is for the power supply and input /output signals.
The power from this connector is priority power for the camera when the power supplies through this connector
and PoE at same time.
Use HR10A-7P-6S (Hirose) or equivalent for the cable side.
Pin No.
Signal Name
IN /
OUT
Voltage
1
GND
IN
0V
2
I/O-1
OUT
+3.3V Open Collector
3
I/O-2
OUT
+3.3V Open Collector
4
TRG_In-
(Opt. Isolated -)
IN
Low: Smaller than +1.0V
High: +3.0 to +26.4V
*Potential difference between TRG_In-
and TRG_In+
5
TRG_In+
(Opt. Isolated +)
IN
6
POWER IN
IN
+10.8 to +26.4 Vdc
Table 4: Pin Assignment (Power –I/O Connector)
Output signals can be assigned through the camera setting communication.
(Device Code = 00H, Command = F0H and F1H)
Configuration of I/O-1 (Pin No.2) and I/O-2 (Pin No.3)
Output pin can be assigned through register setting or GenICam Command.
Table 5: IO port Command List
※Note: I/O-1 can be assigned only by F0H[3..0] and F1[3], and I/O-2 can be assigned only by F0H[7..4] and
F1[4].
Command No.
GenICam command
F0H[3..0]
F1[3]
F0H[7..4]
F1[4]
I/O-1 (Pin No.2) / I/O-2 (Pin No.3)
For I/O-1 (Pin No. 2)
For I/O-2 (Pin No.3)
0H
(initial setting)
-
0H
-
FrameTriggerWait
(initial setting for I/O-1)
1H
Set Value
1H
Set Value
UserOutput
2H
-
2H
(initial setting)
ExposureActive
(initial setting for I/O-2)
3H
-
3H
-
TriggerAuxiliary
4H
-
4H
TriggerInternal
5H
-
5H
SensorReadOut
6H
-
6H
StrobeSignal
7H-FH
-
7H-FH
-
For Test Use Only

No.15S085-04
12/44
STC-SCS231POE,STC-SBS231POE
Product Specifications and User’s Guide
1) FrameTriggerWait
The user can check the camera condition (camera exposure and image output processing by the
trigger signal with this FrameTriggerWait signal).
This signal is LOW for the period from the trigger input signal to the image output.
a) High status (3.3V): No processing by the trigger signal. The camera accepts the trigger signal.
b) Low status (0V): The camera is exposed and the image output processes by the trigger signal.
The camera default setting is the input trigger signal is INVALID while at the low status of this signal.
When the exposure starts while the image output by the next trigger signal, please change the
camera setting (Device code: 00H, Command No. : 13H) to accept the trigger signal while the
image outputs.
The noise appears on the image when the exposure begins while the image is output. The noise
appears on the image when the start exposure while the image is output. In this case, please
change the “H reset” for the exposure start mode (Device code: 00H, Command No. : 12H) to
change the exposure start point to the next HD timing.
2) UserOutput
The status of the UserOutput signal can change with the “UserOutputValue”.
3) ExposureActive
The user can check the exposure time with the ExposureActive signal.
4) TriggerAuxiliary
The TriggerAuxiliary signal is the input trigger signal.
5) TriggerInternal
The TriggerInternal signal is the input trigger signal with the trigger delay time.
6) SensorReadOut
The SensorReadOut signal is the FVAL signal, which is the image output period of the time.
7) StrobeSignal
The StrobeSignal signal is the strobe control signal.

No.15S085-04
13/44
STC-SCS231POE,STC-SBS231POE
Product Specifications and User’s Guide
Equivalent Circuit for the Input Pin of the I/O Connector2.5.3
Figure 6: Input / Output Circuit

No.15S085-04
14/44
STC-SCS231POE,STC-SBS231POE
Product Specifications and User’s Guide
Typical Input Circuit2.5.4
(+3.0 to +26.4V 3 to 5mA )
(+3.0 to +26.4V 3 to 5mA )

No.15S085-04
15/44
STC-SCS231POE,STC-SBS231POE
Product Specifications and User’s Guide
Typical Output Circuit2.5.5
Note:
Value of Vcc and Pull up register can be set within the spec of transistor.

No.15S085-04
16/44
STC-SCS231POE,STC-SBS231POE
Product Specifications and User’s Guide
Input and Output Signal Timing (Hardware Trigger)2.5.6 Case of “External Hardware Trigger”, “Positive Edge Trigger”, “Edge Preset Exposure”,
Camera internal processing
Output Signal
External hardware trigger
Photocoupler output
Debounce
Trigger delay
Exposure
Video output
FrameTriggerWait
ExposureActive
TriggerAuxiliary
TriggerInternal
SensorReadOut
StrobeSignal
Parameter "StrobeSignalDelay"on GenICam Parameter "StrobeSignalOnTime"on GenICam
Parameter "TriggerDelay"on GenICam
less than 15us
Parameter "LineDebounceTime"on GenICam
Parameter "ExposureTime"on GenICam
As for the trigger polarity, please refer to
parameter "TriggerActivation"on GenICam

No.15S085-04
17/44
STC-SCS231POE,STC-SBS231POE
Product Specifications and User’s Guide
Input and Output Signal Timing (Software Trigger)2.5.7 Case of “Software Trigger”, “Positive Edge Trigger”, “Edge Preset Exposure”,
Camera internal processing
Output Signal
Software trigger,PLC
Trigger delay
Exposure
Video output
FrameTriggerWait
ExposureActive
TriggerAuxiliary
TriggerInternal
SensorReadOut
StrobeSignal
Parameter "StrobeSignalDelay"on GenICam Parameter "StrobeSignalOnTime"on GenICam
TriggerDelay on GenICam
Parameter "ExposureTime"on GenICam
As for the trigger polarity, please refer to
parameter "TriggerActivation"on GenICam

No.15S085-04
18/44
STC-SCS231POE,STC-SBS231POE
Product Specifications and User’s Guide
3 Dimensions
3.1 STC-SBS231POE
Unit: mm
Figure 4: Mechanical Dimensions

No.15S085-04
19/44
STC-SCS231POE,STC-SBS231POE
Product Specifications and User’s Guide
3.2 STC-SCS231POE
Unit: mm
Figure 5: Mechanical Dimensions

No.15S085-04
20/44
STC-SCS231POE,STC-SBS231POE
Product Specifications and User’s Guide
4 Sensor information
4.1 Pixel Transferring Image
STC-SBS231POE (Monochrome)
Pixel (n) of Data: nth pixel being transferred
STC-SCS231POE (Color)
Pixel (m,n) of Data: nth pixel of the mth line being transferred
Pixel1 of
Data
Pixel2 of
Data
Pixel22 of
Data
Pixe21 of
Data
Pixel12 of
Data
Pixel11 of
Data
