DS-2CD852F Network Camera
Technical Manual

Hikvision Technical Manual
©2006 –2011 by HIKVISION. All rights reserved.
2
Notices
The information in this documentation is subject to change without notice and does not represent any
commitment on behalf of HIKVISION. HIKVISION disclaims any liability whatsoever for incorrect data
that may appear in this documentation. The product(s) described in this documentation are furnished
subject to a license and may only be used in accordance with the terms and conditions of such license.
Copyright © 2006-2011 by HIKVISION. All rights reserved.
This documentation is issued in strict confidence and is to be used only for the purposes for
which it is supplied. It may not be reproduced in whole or in part, in any form, or by any means or
be used for any other purpose without prior written consent of HIKVISION and then only on the
condition that this notice is included in any such reproduction. No information as to the contents or
subject matter of this documentation, or any part thereof, or arising directly or indirectly therefrom,
shall be given orally or in writing or shall be communicated in any manner whatsoever to any third party
being an individual, firm, or company or any employee thereof without the prior written consent of
HIKVISION. Use of this product is subject to acceptance of the HIKVISION agreement required to use
this product. HIKVISION reserves the right to make changes to its products as circumstances may
warrant, without notice.
This documentation is provided “as-is,” without warranty of any kind.
Please send any comments regarding the documentation to:
[e-mail]
Find out more about HIKVISION at www.hikvision.com

Hikvision Technical Manual
©2006 –2011 by HIKVISION. All rights reserved.
3
Contents
1. Key Features
2. Specifications
3. Order Models
4. Dimension
5. Accessories

Hikvision Technical Manual
©2006 –2011 by HIKVISION. All rights reserved.
4
1.Key Features
Up to 2 megapixel (1600 × 1200) resolution, and real time video encoding at HD 720P
H.264 or MPEG4 video compression with high compression ratio
Progressive scan CMOS, capture motion video without incised margin
Support ePTZ
Support dual stream, and the sub-stream used for the mobile phone surveillance
Up to 32 GB SD/SDHC card for local storage
Two-way audio
Completed function: PTZ control, alarm and so on

Hikvision Technical Manual
©2006 –2011 by HIKVISION. All rights reserved.
5
Specification
Model
Parameter
DS-2CD852F
2 Megapixel CMOS Network Box Camera
Camera
Image Sensor
1/3”Progressive Scan CMOS
Min. Illumination
0.5 Lux @ (F1.2, AGC ON), 0.1 Lux @ (F1.2, AGC ON, sensitivity × 5)
Shutter Time
Auto
Lens Mount
C/CS mount
Auto-iris
---
Day & Night
Electronic
Compression Standard
Video Compression
H.264 (MPEG4 optional)
Bit Rate
32 Kbps - 8 Mbps
Audio Compression
OggVorbis
Dual Stream
Yes
Max. Image Resolution
1600 × 1200
Frame Rate
50 HZ: 5 fps (1600 x 1200), 12.5 fps (1280 x 720)
60 HZ: 5 fps (1600 x 1200), 10 fps (1280 x 720)
Image Settings
Saturation, Brightness, Contrast adjustable by client software or web
browser
Network
Alarm Trigger
Motion detection
Protocols
TCP/IP, HTTP, DHCP, DNS, RTP/RTSP, PPPoE
(FTP, SMTP, NTP, SNMP optional)
Security
Password protection
Interface
Audio Input
1-ch, 3.5 mm audio interface (2.0 - 2.4 Vp-p, 1 kΩ)
Audio Output
1-ch, 3.5 mm audio interface (Line level, 600 Ω)
Communication Interface
1 RJ45 10 M/100 M Ethernet port and 1 RS-485 interface
Alarm Input
1
Alarm Output
1
Video Output
1Vp-p composite output (75 Ω/BNC)
Local Storage
Built-in SD/SDHC slot, up to 32 GB
General
Operating Conditions
-10 °C –60 °C (14 °F –140 °F)
Humidity 90% or less (non-condensing)
Power Supply
12 V DC ± 10%
Power Consumption
Max. 3 W

Hikvision Technical Manual
©2006 –2011 by HIKVISION. All rights reserved.
6
Dimension
63 x 67 x 127.7 mm (2.48” x 2.64” x 5.03”)
Weight
650 g (1.43 lbs)
Order Models
DS-2CD852F
Dimension
Unit: mm
Accessories
Indoor wall mount Indoor/Outdoor Wall Mount
DS-1212ZJ DS-1213ZJ
Indoor/Outdoor camera housing Indoor camera housing
DS-1311HZ (DS-1312HZ, DS-1313HZ) DS-1320HZ
