Sentry Level-Lenz Instruction manual

Original Instructions
sentry-equip.com
966 Blue Ribbon Circle North, Oconomowoc,WI 53066 U.S.A. | [phone] | suppor[email protected]
Installation, Operation &Maintenance Manual
Sentry Level-Lenz Sight Level Indicator
Manual Sampling Accessories
S-LS-IOM-00490-0 9-16
Do not install, maintain, or operate this equipment without reading,
understanding, and following the appropriate Sentry Equipment Corp
instructions. Otherwise, injury, damage, or both may result.
Copyright
© 2016 by Sentry Equipment Corp. All rights reserved. All product and company
names are property of their respective owners. This document contains
proprietary information. No part of this document may be photocopied or
reproduced without the prior written consent of Sentry Equipment Corp.
Limit of Liability
Sentry Equipment Corp, its employees, agents, and the authors and contributors
to this document specically disclaim all liabilities and warranties, express or
implied (including warranties of merchantability and tness for a particular
purpose), for the accuracy, currency, completeness, and/or reliability of the
information contained herein and/or for the tness for any particular use and/or
for the performance of any material and/or equipment selected in whole or part
with the user of/or in reliance upon information contained herein. Selection of
materials and/or equipment is at the sole risk of the user of this publication.
Note
The information contained in this document is subject to change without notice.
Safety Information
Please read the entire manual before attempting to unpack, set up, or operate this
product. Pay careful attention to all Warnings, Cautions, and Notes. Failure to do so
could result in serious personal injury and/or equipment damage.
Use of Hazard Information
If multiple hazards exist, the signal word corresponding to the greatest hazard
shall be used.
Denitions
DANGER indicates a hazardous situation
which, if not avoided, will result in death
or serious injury.
WARNING indicates a hazardous
situation which, if not avoided, could
result in death or serious injury.
CAUTION, used with the safety alert
symbol, indicates a hazardous situation
which, if not avoided, could result in
minor or moderate injury.
NOTICE is used to address practices not
related to personal injury.
NOTE
Information that requires special emphasis.
TIP
Alternate techniques or clarifying information.
SHALL:
This word is understood to be mandatory.
SHOULD:
This word is understood to be advisory.
Standard Warranty
Sentry Equipment Corp (“Seller”) warrants products manufactured by it and
supplied hereunder (“Products”) to be free from defects in workmanship and, to
the extent materials are selected by Seller, to be free from defects in materials, in
each case for a period as dened in the table below:
Brand Product Line Warranty Period
Sentry® Steam & Water Sampling Products and Systems
Solid & Powder Sampling Products and Systems
Gas Sampling Products and Systems
Liquid & Slurry Sampling Products and Systems
Pipeline Integrity Products
Eighteen months from
date of shipment or
twelve months from
startup (whichever
occurs rst)
Waters
Equipment
Steam & Water Sampling Products and Systems Twelve months from
date of shipment
To view the full warranty, go to
www.sentry-equip.com/warranty.
General Safety Precautions
Product Selection, Installation, and Use
Improper selection, installation, or use can cause personal injury or property damage.
It is solely the responsibility of users, through their own analysis and testing, to select
products suitable for their specic application requirements, ensure they are properly
maintained, and limit their use to their intended purpose.
Follow proper local, state, and federal regulations for proper installation and operational
requirements.
Always use caution and common sense when working with any chemical. Read
the product label and Material Safety Data Sheets (MSDS) carefully and follow the
instructions exactly.
Potential Equipment Hazards
Hot surfaces! This equipment may have very hot
surfaces. If an operator contacts a hot surface, injury
may occur. Use protective clothing to prevent injury.
If other equipment comes in contact with a hot
surface, damage to the equipment may occur. Ensure
the area around this equipment is kept clear to
prevent this damage from occurring.
High pressures! This equipment may contain uids
at very high pressures. Prior to installing, removing,
or maintaining this equipment, ensure that the
equipment is isolated from all connecting piping, the
equipment is depressurized, the contents have been
drained, and the equipment is cool.
Freezing Temperatures! This equipment may have
very cold surfaces. If an operator contacts a cold
surface, injury may occur. Use protective clothing to
prevent injury. If other equipment comes in contact
with a cold surface, damage to the equipment may
occur. Ensure the area around this equipment is kept
clear to prevent this damage from occurring.
Freezing of uids in tube
can lead to rupture of the
tube wall and coil failures.
Take precautions to avoid
freezing, such as draining
the equipment when out
of service or installing the
equipment in an environment
protected from temperatures
below the freezing point of
the uids used.

Customer Support
With proven sampling expertise since 1924, Sentry products and services
provide business operations the critical insights to optimize process control and
product quality. We deliver true representative sampling and analysis techniques
to customers around the globe, empowering them to accurately monitor and
measure processes for improved production efficiency, output, and safety.
Standing behind our commitments, we are determined to tackle any application,
anywhere.
We know that running an efficient operation isn’t easy. It requires thorough,
careful analysis of controlled, real-time data achieved through reliable, accurate,
and repeatable process monitoring and measuring. By eectively conditioning,
sampling, and measuring gas, liquid, slurry, powder, solids, steam, or water within
their production environments, our customers obtain the critical insights they
need to control and optimize their processes.
Yet, controlling your processes also means reliable customer support throughout
the life cycle of your equipment.

Customer Service—General information, warranty claims, order management.

Installation Service—For systems that require specialized expertise upon
installation.

Technical Support—Troubleshooting, training, and technical manuals.

Field Service & Retrots—When a problem needs immediate attention.

Replacements Parts & Consumables—Order your replacement parts and
consumables.

Sentry ProShield Services—Select from four ProShield Guardian service plans
providing dierent levels of support to protect your large system investments
with regularly scheduled maintenance.
To learn more, go to
www.sentry-equip.com/support.
General Description
The Sentry® Level-Lenz sight level indicator oers a cost eective method for
process operators to conrm the level of liquid without disrupting the process
or ow. Sight level indicators provide a safe way for operators to visually monitor
liquid levels in closed loop sampling processes.
Sentry Level-Lenz sight level indicators are manufactured of quality materials and
safety tested to 150% of the rated pressure to assure long, dependable service at
economical prices. The Level-Lenz has threaded process connections, two viewing
windows, and a body of 316 stainless steel. The Level-Lenz has a double window,
one on the front and one on the side. The operator can ash light through the side
window to enhance visibility. The level indicator can be used for hydrocarbon and
water-based liquids.
Installation
Receiving
Examine the package for any shipping damage. If in doubt, take pictures of the
suspect area.
Remove unit(s) from the package and examine for any visible damage. Report
damages to the carrier at once. This is the responsibility of the consignee.
Mounting
(When shipped loose) Position the Level-Lenz so that the windows are centered at
the level that the process liquid is controlled to.
Mount the level indicator assembly securely to a bracket or backplate with two (2)
10-32 screws.
Connect to the bottom of the level indicator (ow must be upward).
Operation
Start the ow of panel.
Figure 1. Sentry Level-Lenz Dimensional Drawing
0 0
1.38 35
2.75 70 2
0 0
1.38 35 12
2.75 70
3.13 79
.19 5 1
0 0
1.38 35 1 2
2.75 70
.38 10
0 0
1.38 35
0
.75 19
2.00 51
10-32 UNF
(2 SIDES)
MOUNT
CONNECTION IDENTIFICATION
I.D. DESCRIPTION SIZE
1 INLET 3/8" FNPT
2 OUTLET 3/8" FNPT
