Sentry ST730S User manual

Anemometer
ST730S
Instruction Manual
ST730S
REACH
(SVHC)

730S
Anemometer
REACH
(SVHC)
RoHS
使用說明書
Instruction Manual

Table Content
1. Product Introduction----------------------1
1-1 Features-----------------------------------1
1-2 Application--------------------------------2
2. Safety Information----------------------------2
2-1 Cautions-------------------------------2
2-2 Safety Symbols--------------------------3
3. Specifications----------------------------------4
3-1 General Specification------------------4
3-2 Technical Specification----------------5
4. General Descripts-----------------------------6
4-1 Unit Diagram-----------------------------6
4-2 LCD Panel--------------------------------7
4-3 Battery Placement----------------------8
4-4 AC Power---------------------------------8
4-5 Sensor Tip Description-----------------9
5. Mode Functions------------------------------10
5-1 Air Velocity / Air Temperature
Measurement--------------------------11
5-2 Maximum/Minimum/Average
Measurement--------------------------11
5-3 Data Record / Recall------------------12
6. Advanced Set Functions-----------------13
6-1 Air Velocity Unit Setting--------------13
6-2 Temperature Setting------------------13
6-3 Backlight ON/OFF---------------------13

1
1. Product Introduction
Thank you for purchasing this Anemometer.
The Anemometer is an air velocity and
temperature of air measuring instrument. To
measure an air velocity, put sensor head face to
the air velocity value.
1-1 Features
Combination of hot wire and standard
thermister, deliver rapid and precise
measurement event at low air velocity.
Wide range measurement of air velocity,
fast response time.
Multi-function for air velocity measurement:
m/s, km/h, ft/min, mile/h.
Super large LCD with dual function display,
read the air velocity & temperature at the
same time.
Data hold and record / recall maximum,
minimum, and average reading.
Ultra low power consumption in shutdown
mode.
Auto power off after 10 Minutes of idle.

2
1-2 Applications
Air conditioner
Refrigerated case
Ventilation system
Furnace flow velocity
Fans / motors / blowers
Environmental testing
Manufacturing processes of semiconductor
technology
2. Safety Information
Read the following safety information carefully
before attempting to operate or service the meter.
Only qualified personal should perform repairs or
servicing not covered in this manual.
2-1 Cautions!
DO NOT submerge the unit in water.
This product is not designed for use in
medical evaluation. The product can only be
used to measure body temperature simply
for reference. They are meant for industrial
and scientific purpose.

3
2-2 Safety symbols
Dangerous, refer to this manual before using
the meter.
CE Certification
This instrument conforms to the following standards:
En61326: Electrical equipment for measurement,
control and laboratory use.
IEC61000-4-2: Electrostatic discharge immunity test.
IEC61000-4-3: Radiated, radio-frequency,
electromagnetic field immunity test.
IEC61000-4-8: Power frequency magnetic field
immunity test.
Tests were conducted using a frequency range of
80-1000 MHZ with the instrument in there orientations.
The average error for the three orientations is ±0.5°C
(±1.0°F) at 3V/m throughout the spectrum. However,
between 781-1000MHZ at 3V/m, the instrument may
not meet its stated accuracy.
Restrict to use of six substances within
electrical and electronic equipment (EEE), thereby
contribution to the protection of human health and the
environment.
The device may not be disposed in trash. It
promotes the re-use recycling and other forms of
recovery of used materials and component, and to
improve the environmental performance of all
operators (manufacturers, traders and treatment
facilities) involved in the life cycle of products. Dispose
of the product appropriately in accordance with the
regulations in force in your country.
The device of used materials content no
substances that list of proposed REACH substances of
very high concern.

4
3. Specification
3-1General Specification
Model 730S
Measurement Air Velocity : m/s, ft/min, km/h, mile/h, knots
Temperature: °C and °F
Sensors Air Velocity / Air Flow Sensor : Hot Wire
Operating Temp. 32~122°F (0~50°C), 10~90%RH
Storage Temp. -14~140°F (-10~60°C)
Record Function Yes (9 points)
Sample Time Approx. 0.5 sec.
AC Power YES
Multi-LCD Display YES
Max / Min / Avg YES
LCD Backlight YES
Data Hold YES
Auto Power Off 10 Minutes of idle
(30 Minutes with AC Power)
Dimensions
7.24”×2.75”×1.57” (184×70×40mm)
Telescope probe : approx. 70.8”
(1800mm) include wire rod.
Weight Approx. 12.8oz (363g) with battery
Accessories 9Vbattery, Instruction manual, Carrying
case, AC Input, USB Transmission line.

5
3-2 Technical Specification
Model 730S
Range
Air Velocity:
0~40m/s, 0~7,874ft/min, 0~144km/h,
0~89.5mile/h,0~77.75knots
Air Temperature: 32~158°F (0~70°C)
Resolution
Air Velocity:
0.01m/s, 0.1ft/min, 0.01km/h, 0.01mile/h
0.01knots
Air Temperature: 0.1°F(0.1°C)
Accuracy
(%reading)
Air Velocity:
±(0.03+3%)m/s, ±(5.9+3%)ft/min,
±(0.11+3%)km/h, ±(0.07+3%)mile/h,
±(0.06+3%)knots
Air Temperature: ±1.5°F (0.8°C)

6
4. General Descriptions
4-1Unit Diagram
○
1 Power Button
○
2 LCD Screen
○
3 REC (↲) Button
○
4 ▼Down Button
○
5 Hold Button
○
6 AC Input
○
7 Backlight Button
○
8 Mode (SET) Button
○
9 ▲Up Button
○
10 Probe Socket
○
11 Sensor Head
○
12 Probe Plug

7
4-2 LCD Panel
○
A Time Interval / Backlight
○
B Memory Space / Clear Memory
○
C Primary Reading
○
D MAX / MIN / AVG
○
E DATA Record / Recall / Log
○
F PC Link / EMS
○
G Low Battery
○
H Anemometer Hold
○
I Anemometer Unit
○
JTertiary Reading

8
Tilt stand
4-3 Battery Placement
The meter is powered by a 9V battery. When
symbol appear, the battery voltage drops below the
level for reliable operation, the user has to replace a
new battery. To change the battery, open the battery
cover on the back and replace the battery in the battery
compartment. Make sure the cover is well snapped
after the replacement of battery.
4-4 AC Power
Except battery power supply, the unit also consumes
AC power via USB cable: Plug the AC adapter to the
wall jack Option.

9
4-5 Sensor Tip Description
• Sensor Head:
○1 Air Direction Arrow
○2 Air Velocity Sensor
(Do not touch!)
○3 Temperature Sensor
To protect the sensors,
please telescope the
sensor head into the
wand when the meter is
not in use.
Air Velocity Measurement:
Place the sensor in the air current to be measured.
Have the air flow meet the sensor head in the direction
toward the arrow.
Warning! Do not touch the air velocity or
temperature thermistor inside the sensor
head.

10
5. Mode Function
It is easy to operate more measurement functions by
using ” ” button to change. The sequential
operations and explanations are shown in the following
flow-chat
Measuring
Mode
MAX
MIN
AVG
RECALL
Normal-Measuring mode
MAX-Display
maximum measuring
Mode
SET
MIN-Display
minimum measuring
AVG-Display
average measuring
Recall
thestoreddata
by

11
5-1 Air Velocity /
Air Temperature Measurement
Place the sensor in the air
stream. It will show the air
velocity value on the primary
reading and show the air
temperature value on the
tertiary reading. During
Measuring, press the “ ”
button once to hold the air
velocity value and the “ ”
symbol will appear on the LCD. Press the button again
to return to normal operation.
5-2 Maximum / Minimum /
Average Measurement
In measuring mode, press the
“” button to toggle the
“MAX/MIN/ AVG” mode and
measure a target, it will show
the MAX/ MIN/AVG value on
the primary reading.
During measuring, press the “ ” button once to hold
the measured value and the “” symbol will appear
on the LCD. Press the button again to return to normal
operation and the Max / MIN/AVG value will reset.

12
5-3 Data Record / Recall
Data Record:
The data can be recorded in
the measuring mode function.
Just press “ ” button once,
the value on the primary, and
tertiary readings will be
recorded in DATA# and
automatically point to next address DATA#+1.
Data Recall:
Press “ ” button to select the recall mode and
“RECALL” Symbol will appear on the LCD. Press “ ”
or “ ” button to recall the stored data. At the DATA0,
press “ ” button to clear the DATA1 to DATA9.

13
6. Advanced Set Functions
Press the “ ” button and hold for 3 seconds into the
advanced set function, the “SET” Symbol will appear on
the tertiary reading. Repeat to press the “ ” button
and hold for 3 seconds again or idle for 6 seconds to
exit this function. In the set function, press the “ ” or
“ ” button to adjust, press the “ ” button to set and
automatically toggle to next options. The sequential
operation and explanations are shown in the following
flow chat.
6-1 Air velocity Unit Setting
Press the “ ” or “ ” button to select the air
velocity unit. The unit symbol will flash on the LCD.
6-2 Temperature Setting
Press the “ ” or “ ” button to select the
°C or °F unit. The unit symbol will flash on the LCD.
6-3 Backlight ON/OFF
Press the “ ” button to turn the backlight on and
off.

730S
Anemometer
REACH
(SVHC)
RoHS
使用說明書
Instruction Manual

項次
1. 產品簡介---------------------------1
1-1 產品特色------------------------------1
1-2 適用範圍------------------------------1
2. 安全需知----------------------------2
2-1 注意事項------------------------------2
2-2 安全標準-----------------------------2
3. 規格--------------------------------3
3-1 一般規格----------------------3
3-2 技術規格---------------------------4
4. 操作方式----------------------------5
4-1 結構名稱說明--------------------------5
4-2 液晶面板說明--------------------------6
4-3 電池更換------------------------------7
4-4 外部供電------------------------------7
4-5 感測頭說明----------------------------8
5. 模式設定---------------------------9
5-1 風速 / 風溫量測----------------------10
5-2 最大值/最小值/平均值量----------------10
5-3 手動資料紀錄/讀取---------------------11
6. 進階設定功能----------------------12
6-1 風速單位切換-------------------------12
6-2 溫度單位切換-------------------------12
6-3 背光開關-----------------------------12

1
1. 產品簡介
感謝你購買本熱線式風速儀。此儀器使用高
精密熱線絲感測器來量測風速。此儀器在操作上也
非常容易，只要將感測頭(位於探棒前端)的受風面，
面項待測的氣流。在主顯示區就會立即出現風速讀
值。
1-1 產品特色
結合熱線絲感測器與標準熱敏電阻，可迅速且精確
測量極低風速。
同時擁有快速反應及大範圍風速量測。
可切換多樣風速單位:m/s, km/h, ft/min, mile/h
超大液晶螢幕及多重顯示可同時讀取風速及風溫
資料鎖定與計錄/資料讀取及最大值、最小值、平
均值。
閒置 10 分鐘自動關機(外接電源時 30 分鐘)
1-2 適用範圍
空調系統
冷凍櫃
通風系統
鍋爐風速
風扇/馬達/鼓風機
環境測試
半導體科技製造
