1PolaRxS_PRO
1.1 Rear Panel Connectors
The rear panel features three connectors.
Note that two additional connectors may be present on your receiver. These additional connectors are
not connected.
1.1.1 MAIN (TNC)
Connect an active GNSS antenna to this connector. The gain at the connector (antenna gain minus
cable losses) must be in the range 15 to 50dB.
By default, the receiver provides a 5V DC supply on the MAIN connector to feed the antenna. Other
voltages can be imposed through pin ANT_EXT of the IN connector on the front panel (see section
1.2.6). The maximum supported current is 200mA.

_______________________________________________________________________ 1 PolaRxS_PRO
PolaRxS Product Family Hardware Manual v1.3.0 7
Never inject a DC voltage into the MAIN connector as it may damage the receiver. For instance,
when using a splitter to distribute the antenna signal to several receivers, make sure that no more than
one output of the splitter passes DC. Use DC-blocks otherwise.
1.1.2 PPS OUT (BNC)
xPPS output (5V, output impedance 50Ohms). The rate and polarity of the xPPS output signal are
specified by the setPPSParameters command. The pulse duration is 1.2ms.
1.1.3 REF OUT (BNC)
This connector provides access to the 10-MHz reference signal from the internal ultra low noise
OCXO. It is a sinusoidal signal with an unloaded peak-to-peak amplitude of 1.1V. Output impedance
is 50 Ohms.

_______________________________________________________________________ 1 PolaRxS_PRO
PolaRxS Product Family Hardware Manual v1.3.0 8
1.2 Front Panel Connectors
The front panel features 8 ODU connectors, which are described in the following sections. These
connectors are all of type ODU MINI SNAP Series F. The pinout of the female connectors and the
ODU part number of the corresponding male connectors is shown below.
3 pins
4 pins
5 pins
7 pins
S40F1C-P03MJG0-50CP S40F1C-T04MFD0-50CP S40F1C-P05MFD0-50CP S40F1C-T07MCD0-50CP
1.2.1 COM1
This 7-pin connector provides access to the first serial port (COM1).
Pin #
Description
1
Not connected
2
Signal ground (GND)
3
Not connected
4
Not connected
5
Receive Data (RXD – input to the receiver )
6
Transmit Data (TXD – output from the receiver)
7
Not connected
The receiver behaves as Data Terminal Equipment (DTE).
Log button (not applicable)
Power button
POWER LED
LANLINK LED
TRACK LED
GP LED
PVT LED
LOG LED

_______________________________________________________________________ 1 PolaRxS_PRO
PolaRxS Product Family Hardware Manual v1.3.0 9
1.2.2 COM2
This 7-pin connector provides access to the second serial port (COM2).
Pin #
Description
1
+5V DC output
2
Signal ground (GND)
3
Clear To Send (CTS – input)
4
Request To Send (RTS – output)
5
Receive Data (RXD – input)
6
Transmit Data (TXD – output)
7
Not connected
The receiver behaves as Data Terminal Equipment (DTE).
Pin#1 provides a 5V DC voltage, e.g. to allow feeding a Bluetooth™ device.
1.2.3 COM3-4/USB
This 7-pin connector can be configured in two modes:
COM3 and COM4 mode
USB mode.
The electrical level at pin#7 defines the operating mode.
1.2.3.1 COM3-4 mode
This mode is selected by leaving pin#7 unconnected.
1.2.3.2 USB mode
This mode is selected by applying 5V DC to pin#7.
Pin #
Description
1
Not connected
2
GND
3
COM4 RX
4
COM4 TX
5
COM3 RX
6
COM3 TX
7
Leave unconnected
Pin #
Description
1
Not connected
2
GND
3
USB D-
4
Reserved
5
USB D+
6
Reserved
7
USB Vbus

_______________________________________________________________________ 1 PolaRxS_PRO
PolaRxS Product Family Hardware Manual v1.3.0 10
1.2.4 Ethernet
Pin #
Description
1
TxD+
2
TxD-
3
RxD+
4
RxD-
1.2.5 OUT
Pin #
Description
1
Reserved
2
GND
3
GP1 output, 3.3V. Use the command setGPIOFunctionality to set the level
of this pin.
4
GP2 output, 3.3V. Use the command setGPIOFunctionality to set the level
of this pin.
5
nRST_OUT. Open-collector output, driven low when the receiver is resetting.
1.2.6 IN
Pin #
Description
1
Reserved, leave unconnected.
2
GND
3
Reserved, leave unconnected.
4
nRST_IN. Driving this pin low resets the receiver. Internally pulled-up.
Debouncing and deglitching is foreseen.
5
EVENTA, 3.3V CMOS, 5V tolerant, 100k pull down resistor. This is the first
digital input for external event timing, see Firmware User Manual for operation.
6
EVENTB, 3.3V CMOS, 5V tolerant, 100k pull down resistor. This is the
second digital input for external event timing, see Firmware User Manual for
operation.
7
ANT_EXT, external antenna power. Can be used to apply an external supply
voltage to the antenna. The voltage applied to ANT_EXT (VANT) determines the
voltage source on the MAIN and AUX1 connectors, as follows:
if VANT<2.0V or ANT_EXT left open, the antenna is powered by the internal
5V supply;
if 3.0V<VANT<4.0V, there is no power provided to the MAIN connector;
if 5.0V<VANT<12.0V, the antenna power supply is taken from ANT_EXT.
Warning:
Exceeding 12.0V for VANT, or drawing more than 200mA from the antenna
connector can permanently damage the receiver.
1.2.7
Pin #
Description
1
Reserved
2
Reserved
3
Reserved
4
Reserved

_______________________________________________________________________ 1 PolaRxS_PRO
PolaRxS Product Family Hardware Manual v1.3.0 11
5
Reserved
1.2.8 PWR
If you are using a different power adaptor than the one provided by Septentrio, make sure that it can
sustain a current of 1.5A.
1.3 Log Button
The log button is not functional on the PolaRxS: it has no effect.
1.4 Status LEDs
LED Name
LED Behaviour
POWERLED
LED lights when the receiver is switched on.
LANLINKLED
LED blinks when sending or receiving data over Ethernet.
LOGLED
LED lights when data is being written to the internal SD memory card. If the
logging rate is larger than 1 Hz, LED lights continuously.
PVTLED
LED lights when a PVT solution is available.
GPLED
General-purpose LED. The function of this LED is configured with the
setLEDMode command. By default, this LED has the DIFFCORLED
function (see below).
DIFFCORLED
Differential correction indicator. In rover PVT mode, this LED reports the
number of satellites for which differential corrections have been provided in the
last received differential correction message (RTCM or CMR).
LED behaviour
Number of satellites with corrections
LED is off
No differential correction message received
blinks fast and
continuously (10 times per
second)
0
blinks once, then pauses
1, 2
blinks twice, then pauses
3, 4
blinks 3 times, then
pauses
5, 6
blinks 4 times, then
pauses
7, 8
blinks 5 times, then
pauses
9 or more
The LED is solid ’ON’ when the receiver is outputting differential corrections
as a static base station.
TRACKLED
LED behaviour
Number of satellites in tracking
blinks fast and
continuously (10 times per
second)
0
blinks once, then pauses
1, 2
blinks twice, then pauses
3, 4
blinks 3 times, then
pauses
5, 6
blinks 4 times, then
7, 8
Pin #
Description
1
Power: 9 to 30V DC
2
ON/OFF. When this pin is tied to pin#1, the receiver is always on, regardless
of the state of the on/off button.
3
GND

_______________________________________________________________________ 1 PolaRxS_PRO
PolaRxS Product Family Hardware Manual v1.3.0 12
pauses
blinks 5 times, then
pauses
9 or more
1.5 Cables
Cable Name: CBLe_COM_1,8 Part #: 200416
This cable can be connected to either the COM1 or COM2 connector. Note that RTS/CTS lines are
only available when connected to COM2.
Cable Name: CBLe_GPO_OE_5 Part #: 201203
Open-ended cable to be used with the OUT connector (see pinout in section 1.2.5).
Pin#
Wire Color
1
Blue
2
Blue/Black
3
Orange
4
Green
5
Brown
Cable Name: CBLe_GPI_OE Part #: 200419
Open-ended cable to be used with the IN connector (see pinout in section 1.2.6).
Pin#
Wire Color
1
Orange
2
Green
3
Yellow
4
Black
5
Red
6
Purple
7
Brown
Do not leave the red and purple wires floating. Tie them to ground if not used. This is to avoid
crosstalk effects that could lead to spurious level transitions on the EventA and EventB inputs.
Cable Name: CBLe_USB Part #: 201202
USB cable to be connected to the COM3-4/USB connector.
Cable Name: CBLe_ETH_MS Part #: 200418
Ethernet cable (straight) to be connected to the ETH connector.
Cable Name: CBLe_ETH_MX Part #: 200417

_______________________________________________________________________ 1 PolaRxS_PRO
PolaRxS Product Family Hardware Manual v1.3.0 13
Ethernet cable (crossed) to be connected to the ETH connector.
Cable Name: CBLe_PWR_OE Part #: 200422
Open-ended cable for the PWR connector (see pinout in section 1.2.8).
Pin#
Wire Color
1
Blue and green (these two wires are both connected to Pin#1)
2
Red
3
Black and Purple (these two wires are both connected to Pin#3)
1.6 Internal Logging on SD Memory Card
The receiver incorporates a SD memory card for internal logging. Refer to the “How-to…” section of
the Firmware User Manual to learn how to use this feature.
To prevent data corruption, logging is protected against accidental power outages. There is no need to
unmount the SD memory card before switching off the receiver.
1.7 Applicable Software Package
The PolaRxS_PRO is compatible with Septentrio’s SSRC3 Software Packages.
1.8 Hardware Specifications
Power consumption: Nominal operation: 6.5W typical
During initial OCXO warm-up: up to 10W.
Receiver switched off (i.e. POWERLED not lit): 1.6W typical. This is
because the internal OCXO remains powered even when the power button is
in the “off” state.
Size: 284 x 140 x 37 mm (length including connectors)
Temperature Range: -40 to +60 °C (operational)
-55 to +85 °C (storage)
Ingress Protection: IP65
Shock: MIL-STD-810F, 516.5
Vibration: MIL-STD-810F, 514.5
