Sepura Tetra stp8 series User manual

sepura

TETRA Terminals

Product Guide

MOD-10-1164

Issue 11

MOD-10-1164

sepura

TETRA Terminals

Product Guide

14-09-2012

Page 2 of 46

Issue 11

Contents

CONVENTIONS _______________________________________________3

REGULATORY STATEMENTS ___________________________________4

Compliance with Standards _________________________________________________ 4

North American and Canadian markets ________________________________________ 5

Marchés nord-américain et canadien__________________________________________ 7

OPERATIONAL REQUIREMENTS ________________________________9

Operating Conditions_______________________________________________________ 9

IP, IEC and ATEX Ratings ___________________________________________________ 9

HANDHELD RADIO RANGE ____________________________________10

STP Series Radios ________________________________________________________ 11

STP Series Belt Clip and “Klick Fast” Stud ___________________________________ 24

SRH3500, SRH3800, SRH3900_______________________________________________ 27

MOBILE / GATEWAY RADIO RANGE ____________________________32

SRG3000 Mobile / Gateway Transceiver ______________________________________ 33

Standard Console_________________________________________________________ 34

Colour Console___________________________________________________________ 34

Handset Based Console ___________________________________________________ 35

Applications Interface Unit _________________________________________________ 36

Mobile / Gateway Radio Accessories _________________________________________ 36

Mobile / Gateway Radio Audio Control _______________________________________ 37

RADIO OPERATION __________________________________________38

HEALTH AND SAFETY ________________________________________39

User Information__________________________________________________________ 39

Compliance with Standards ________________________________________________ 43

GLOSSARY _________________________________________________44

ACKNOWLEDGEMENTS ______________________________________45

NOTICE ____________________________________________________46

Contact Details ___________________________________________________________ 46

MOD-10-1164

sepura

TETRA Terminals

Product Guide

14-09-2012

Page 3 of 46

Issue 11

CONVENTIONS

This guide uses the following formatting and graphical conventions.

Convention

Description

Note icon. Emphasises related, reinforcing, or important information.

Tip icon. Suggests alternative methods for accomplishing tasks or

procedures.

Caution icon. Indicates actions or processes that require caution from the

user.

MOD-10-1164

sepura

TETRA Terminals

Product Guide

14-09-2012

Page 4 of 46

Issue 11

REGULATORY STATEMENTS

COMPLIANCE WITH STANDARDS

RADIATION PROTECTION

The radios fully comply with the NRPB specification EN50360 (EN50361) and the ICNIRP

guidelines for exposure to electromagnetic fields mandated for mobile phones (2W per kg

over a 10g sample).

ELECTRO MAGNETIC COMPATIBILITY

The radios meet the EMC requirements specified by the ETSI specifications:

ETSI EN 301 489-1,

ETSI EN 301 489-18

TYPE APPROVAL

The radios have been self-certified against the R&TTE Directive EN 303 035-1 and are CE

marked accordingly.

ENVIRONMENTAL

The radios fully comply with the following environmental regulatory requirements:

The MIL STD 810E standard for Salt Fog:

The MIL STD 810E standard for Driving Sand (SRH3000 radios only)

The radios have been self-certified to fully comply with all environmental aspects detailed by

ETSI EN 300 019. These include mechanical and climatic tests covering such things as drop,

vibration, bump and shock as well as temperature and humidity.

STP8X SPECIFIC ENVIRONMENTS

The STP8X radio is designed to work in the following hazardous environments.

GAS ENVIRONMENT

The STP8X radio complies with the following specifications for operation in a gas environment

International IECEx Specifications: Ex ib IIC T4 Gb (-20°C <= Ta <= +55°C)

European ATEX Specification II 2G Ex ib IIC T4 Gb (-20°C<=Ta<=+55°C)

DUST ENVIRONMENT

The STP8X radio complies with the following specifications for operation in a dust

environment:

International IECEx Specifications: Ex ib IIIC T90°C Db (-20°C<=Ta <= +55°C)

European ATEX Specification II 2D Ex ib IIIC T90°C (-20°C<=Ta<=+55°C) Db IP6x

MOD-10-1164

sepura

TETRA Terminals

Product Guide

14-09-2012

Page 5 of 46

Issue 11

STP8X CONDITIONS FOR SAFE USE

The equipment has been impact tested according to the low risk of mechanical danger. Care

should be taken to avoid mechanical impact.

Use only Sepura approved batteries, antennas and accessories.

The battery pack must not be removed or replaced in the hazardous area.

The antenna must not be removed / replaced in the hazardous area.

The RuSC cover or RuSC connector must not be removed or replaced in the hazardous area.

RADIO OPERATION

The radios meet the requirements specified by the ETSI specification EN 300 394-1.

SAFETY AND VEHICLE CERTIFICATION AGENCY (VCA)

The radios fully comply with the User Safety specification EN60950, and the Automotive

Directive detailed in 2006/28/EC.

NORTH AMERICAN AND CANADIAN MARKETS

The following regulatory statements apply to users in the North American and/or Canadian

markets.

SRG3900 RADIOS

Changes or modifications not expressly approved by the party responsible for compliance

could void the user‟s authority to operate the equipment (FCC rule part 15.21).

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful interference, and (2) this device must

accept any interference received, including interference that may cause undesired operation.

(FCC Rule Part 15.19(a)(3)).

NOTE: This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference when the equipment is operated in a

commercial environment. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instruction manual, may cause

harmful interference to radio communications. Operation of this equipment in a residential

area is likely to cause harmful interference in which case the user will be required to correct

the interference at his own expense (FCC Rule Part 15.105).

To ensure that RF exposure to the General Public is minimised and the level maintained

below the accepted guidelines, all antenna installations should be installed with reference to

SPR-DOC-0360 Sepura‟s “Vehicle Antenna Installation Guide”

This Class A digital apparatus complies with Canadian ICES-003.

MOD-10-1164

sepura

TETRA Terminals

Product Guide

14-09-2012

Page 6 of 46

Issue 11

To reduce potential radio interference to other users, the antenna type and its gain should be

so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that

permitted for successful communication

This radio is intended for use in occupational/controlled applications where users have been

made aware of the potential for exposure and can exercise control over their exposure. This

radio device is NOT authorized for general population, consumer or similar use.

STP80XX/STP81XX/STP82XX RADIOS

Changes or modifications not expressly approved by the party responsible for compliance

could void the user‟s authority to operate the equipment (FCC rule part 15.21).

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful interference, and (2) this device must

accept any interference received, including interference that may cause undesired operation.

(FCC Rule Part 15.19(a)(3)).

NOTE: This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference when the equipment is operated in a

commercial environment. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instruction manual, may cause

harmful interference to radio communications. Operation of this equipment in a residential

area is likely to cause harmful interference in which case the user will be required to correct

the interference at his own expense (FCC Rule Part 15.105).

This Class A digital apparatus complies with Canadian ICES-003.

The use of third-party belt-clips, holsters, and similar accessories should not contain metallic

components in its assembly. The use of these accessories that do not satisfy these

requirements may not comply with appropriate RF exposure compliance requirements, and

should not be used.

To reduce potential radio interference to other users, the antenna type and its gain should be

so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that

permitted for successful communication

This radio is intended for use in occupational/controlled applications where users have been

made aware of the potential for exposure and can exercise control over their exposure. This

radio device is NOT authorized for general population, consumer or similar use.

MOD-10-1164

sepura

TETRA Terminals

Product Guide

14-09-2012

Page 7 of 46

Issue 11

MARCHÉS NORD-AMÉRICAIN ET CANADIEN

Les déclarations de conformité suivantes s’appliquent aux utilisateurs des marchés nord-

américain et/ou canadien.

RADIOS SRG3900

Les changements ou modifications qui ne sont pas expressément approuvés par la partie

responsable de la conformité peuvent annuler le droit de l’utilisateur à exploiter l’appareil.

(Règlement de la FCC, article 15.21)

Cet appareil est conforme à l’article 15 du règlement de la FCC. Son utilisation est sujette aux

deux conditions suivantes : (1) cet appareil ne doit pas engendrer d'interférences nuisibles, et

(2) cet appareil doit accepter toute interférence reçue, y compris les interférences qui

pourraient avoir des effets non désirés sur son fonctionnement. (Règlement de la FCC, article

15.19(a)(3)).

NOTE : Cet appareil a été testé et s’est avéré être conforme aux limites d’un appareil

numérique de Classe A, en vertu de l’article 15 du règlement de la FCC. Ces limites sont

conçues pour assurer une protection raisonnable contre les interférences nuisibles lorsque

l’équipement est exploité dans un environnement commercial. Cet équipement génère, utilise

et peut émettre de l’énergie de radiofréquence et, s’il n’est pas installé et utilisé

conformément au manuel d’instruction, il peut provoquer des interférences nuisibles pour les

communications radio. Le fonctionnement de cet appareil dans une zone résidentielle est

susceptible de provoquer des interférences nuisibles, auquel cas l’utilisateur est tenu de

corriger les interférences à ses propres frais (Règlement de la FCC, article 15.105)

Pour assurer que l'exposition aux radiofréquences du grand public soit réduit au minimum et

que le niveau soit maintenu en dessous des normes acceptées, toute installation d'antenne

doit être effectuée en référence au document SPR-DOC-0360 - Sepura "Guide d'installation

d’antennes en véhicules"

Cet appareil numérique de la Classe A est conforme à la norme ICES-003 du Canada.

Pour réduire les interférences radio potentielles pour les autres utilisateurs, le type d’antenne

et son gain doivent être choisis de façon à ce que la puissance isotrope rayonnée équivalente

(PIRE) ne dépasse pas les valeurs nécessaires à une communication efficace.

Cette radio a été conçue pour un usage professionnel dans un environnement contrôlé, où

les utilisateurs sont pleinement conscients du danger potentiel de l’exposition à laquelle ils

sont soumis et peuvent exercer un contrôle sur cette exposition. Ce dispositif radio N’EST

PAS autorisé pour l’ensemble de la population, les consommateurs en général, ni pour une

utilisation similaire.

RADIOS STP80XX/STP81XX/STP82XX

Les changements ou modifications qui ne sont pas expressément approuvés par la partie

responsable de la conformité peuvent annuler le droit de l’utilisateur à exploiter l’appareil.

(Règlement de la FCC, article 15.21)

Cet appareil est conforme à l’article 15 du règlement de la FCC. Son utilisation est sujette aux

deux conditions suivantes : (1) cet appareil ne doit pas engendrer d'interférences nuisibles, et

(2) cet appareil doit accepter toute interférence reçue, y compris les interférences qui

MOD-10-1164

sepura

TETRA Terminals

Product Guide

14-09-2012

Page 8 of 46
