SereneLife SLCNX76 User manual

Propane Gas Fire Pit Table
SLCNX76
50,000 BTU Square Gas Firepits with Cover for Outside

www.SereneLifeHome.com2
DANGER
FIRE OR EXPLOSION HAZARD
If you smell gas:
• Shut off gas to the appliance.
• Extinguish any open flame.
• If odor continues, leave the area immediately.
• After leaving the area, call your gas supplier or fire department.
Failure to follow these instructions could result in fire or explosion, which
could cause property damage, personal injury, or death.
WARNING:
Do not store or use gasoline or other flammable vapors and liquids in the vicinity
of this or any other appliance. An LP-cylinder not connected for use shall not be
stored in the vicinity of this or any other appliance.
WARNING:
If the information in this manual is not followed exactly, a fire or explosion may
result causing property damage, personal injury, or loss of life.
WARNING:
For outdoor use only. Installation and service must be performed by a qualified
installer, service agency, or the gas supplier.
WARNING:
Improper installation, adjustment, alteration, service or maintenance can cause
injury or property damage. Refer to the owner's information manual provided
with this appliance. For assistance or additional information consult a qualified
installer, services agency or the gas supplier.
INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.

www.SereneLifeHome.com 3
SAFETY INFORMATION
Before you assemble or operate this unit, please carefully read this entire
manual. Failure to do so may result in a fire, explosion, injury or death.
WARNING
• The installation of this unit must adhere to local codes or Propane Storage and
Handling Code, CSA B149.2.
• THIS UNIT IS INTENDED FOR OUTDOOR USE ONLY! This product shall be used
outdoors, in a ventilated space and shall not be used in any enclosed area.
• This unit is to be used with propane gas only! (sold separately)
• Do not attach a remote gas supply to this unit.
• Only use propane gas for this unit.
• Solid fuels shall not be burned in this appliance.
• When igniting this unit, stay away from the burner as the flame will light up and
may cause injury.
• LP GAS WARNING: Do not use any more than 1/4 in depth lava rocks/pumice
stones/LavaGIass above the burner holes. Doing so will suffocate the flame.
• If the propane gas tank is leaking gas, you may hear, see, or smell a hiss.
Do the following:
1. Disconnect the propane gas tank.
2. Do not attempt to fix the problem yourself.
3. Contact your gas supplier or fire department for help.
• Applying too much propane may result in gas pooling and will not burn.
Allow fresh air into the unit so that the remaining gas may escape.
• Do not use a flame to check for gas leaks.
• Manifold pressure: 11 inch w.c. (2.74kPa).
• Use LP propane tanks with the following dimensions: diameter 12 in, height 18
in - capacity 20 lbs.
• You must use a propane tank that has a collar to protect the gas valve.
• DO NOT fill tank over 80 percent full.
• The tank system must be set up for vapor withdrawal.
• Discontinue use if any part of the propane tank is damaged. Rust and dents may
be hazardous and should be inspected by a gas supplier.
• Do not burn anything other than the provided materials for this fire table.
• Keep away from the unit for the first 20 minutes after igniting your unit for the
first time, as lava rocks/pumice stones/LavaGlass could pop out and cause injury.
Should any rocks pop out, discard them.

www.SereneLifeHome.com4
• Always ensure that lava rocks/pumice stones/LavaGlass are completely dry before
use. Failure to do so will cause them to crack or pop.
• Do not operate unit until all parts are fully assembled.
• Do not paint or color any part of this heating unit.
• Unit may be hot while in use, do not attempt to move it while in use.
• Never leave this heating unit unattended while in use.
• This unit is not intended for cooking.
• Keep any flammable items away and do not use any other fireplace cover for this
unit.
• Keep a safe distance to avoid burning skin or clothing.
• Do not sit or rest hands or feet on this heating unit.
• Never place hands or fingers on upper portion of this unit while in use.
• Keep all electrical cords and fuel supply hose away from heated surfaces.
• Combustible material should not be within 60 inches of the top of the unit, or
within 48 inches around the entire unit.
• Keep the appliance area clear and free from combustible material, gasoline, and
other flammable vapors and liquids.
• If the flame goes out while burning, turn the gas valve off. Wait 5 minutes before
repeating the initial lighting procedure.
Once you have a flame started, hold down the control knob for 1 minute.
• Do not add water into the unit.
• Do not operate unit if any part has been under water. Immediately call a qualified
service technician to inspect the appliance and replace any part of the control
system and any gas control that has been under water.
• Do not disconnect any part while unit is in use.
• Do not store a spare propane tank on or near this unit.
• If the heating unit is indoors, detach the propane tank and leave outdoors.
• Always remove protective cover before operating (if applicable).
• Do not set the protective cover over the unit until it is turned off and completely
cooled down.
• Check for leaks after not using the unit for long periods of time.
• Children should never operate this unit. Children must be supervised while
near this unit.
• Maximum gas supply: 250 psi; Min. gas supply: 10 psi.

www.SereneLifeHome.com 5
• All installation and repair should be done by a qualified professional.
This unit should be inspected annually and cleaned regularly.
• Inspect all elements of this heating unit before each use. If there is damage, the
burner must be replaced.
• Keep the hose out from any pathways to eliminate any accidental damage.
(if external tank).
• Be aware of the hazards of high temperatures and stay away from the unit to
avoid any burns or injury.
• The gas supply tank should be constructed and marked with specifications for
the LP gas tanks of the U.S. Department of Transportation or the National
Standard of Canada CAN/CSA-B339, LP gas tanks, spheres and tubes for
Transportation of Dangerous Goods; and Commission.
• The LP gas tank must have a listed overfilling prevention device and a QCCI or
Type I, (CGA791) LP gas tank connection.
• This heating appliance appliance should not be used on plastic or artificial wood
decks.
• Children and adults should be alerted to the hazards of high surface
temperatures and should stay away to avoid burns or clothing ignition.
• Young children should be carefully supervised when they are in the area of
the appliance.
• Clothing or other flammable materials should not be hung from the
appliance or placed on or near the appliance.
• Any guard or other protective device removed for servicing the appliance
shall be replaced prior to operating the appliance.
• Installation and repair should be done by a qualified service person.
The appliance should be inspected before use and at least annually by a
qualified service person. More frequent cleaning may be required as
necessary. It is imperative that the control compartment, burners and
circulating airways of the appliance are kept clean.

www.SereneLifeHome.com6
IF APPLICABLE:
• Allow heating item to cool completely before placing on lid.
• DO NOT use heating item while lid is installed. Always remove the lid while
heating item is in use.
SAFETY INFORMATION
Only use the regulator and hose assembly provided with this unit. Replacement
parts must be supplied directly by us.
Inspect the burner before use of this unit. If the burner shows any kind of damage,
do not operate the appliance. For assistance with repair or replacement of the
burner or any other parts, contact to us.
NOTE: You must follow all steps to properly assemble this heating item.
Make sure the gas valve is turned “OFF” before assembling. Do NOT attempt to
assemble without proper tools.
Min. Clearance
72in (182.8 cm)
Min. Clearance
48 in (121.9 cm)
Min. Clearance
48 in (121.9 cm)
Combustible materials should not be
within 72 inches of the top of the unit, or
within 48 inches around the entire unit.

www.SereneLifeHome.com 7
PARTS LIST
ITEM SPECIFICATION
1Body
2Guard
3Thermocouple
QTY
1 PC
1 PC
1 PC
4Ignition Pin
5Corrugated Pipe
6Gas valve
1 PC
1 PC
1 PC
7Burner
8Regulator hose
1 PC
1 PC
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
ITEM SPECIFICATION
9Reducing Nipple
10 Control Knob
11 Ignitor
QTY
1 PC
1 PC
1 PC
12 Groundwire
13 Lava rocks
14 PVC cover
1 PC
1 Box
1 PC
15 Battery (AAA)
1 PC

www.SereneLifeHome.com8
Check that the control knob for the gas supply system is turned to the “OFF”
position before starting any assembly.
OFF
CYLINDER VALVE
PRESSURE
RELIEF VALVE
BLEED-OFF
VALVE
BLACK COUPLING NUT
REGULATOR
turn clockwise to connect
turn clockwise
to reseal
Turn the cylinder valve on the tank clockwise to close the propane tank. Attach the
preassembled regulator from the Body to the cylinder valve by turning the regulator
coupling nut clockwise. Make sure it is fastened securely and tighten connections
by hand only.
Remove the rubber cap on the electronic igniter by
unscrewing and slide battery into the battery slot.
Make sure the positive side of the battery faces outwards.
Screw the electronic igniter cap over the battery tightly.

www.SereneLifeHome.com 9
ASSEMBLY INSTRUCTIONS
Pour the box of lava rocks into the firebowl.
CAUTION
To ensure proper function, the guard on
this burner should be free of lava rocks at all.
OPERATION
Before performing a leak test, be sure that no sparks can occur and you are in a
spacious outdoor area. Connect the propane gas tank to the regulator and turn
the valve on the unit to the“off” position. Spray or brush a soap and water mixture
on all connections. Turn the gas supply on; if bubbles occur on any connection
there may be a leak. If you smell gas or a leak is discovered turn the gas valve
off, disconnect propane gas tank and do not use the appliance until the leak
is repaired.
Do not use the heating unit without inspecting the gas hose. If there are signs of
wear or abrasion you must replace the hose (if applicable). Pumice stones/lava
rocks/LavaGlass could pop up and strike somebody’s face during the process of
lighting this unit; stand away from the unit for the first 20 minutes after igniting.
Flame height should be a yellow/blue color between 2 - 10 inches in height.
Wait 50 minutes after extinguishing flame prior to placing a lid (if applicable) or
protective cover on heating item.
To Light
1. Make sure the control knob is in the “OFF” position.
2. Open the door and slowly open the valve on the propane gas tank by turning
the knob counterclockwise.
3. Close the door on the body.
4. Push and hold in the electronic ignitor to create sparks within the electrode,
continue to hold.

www.SereneLifeHome.com10
5. Push in the control knob and turn to the “HIGH” position. Keep holding down
the control knob to allow gas to fow for 15 seconds.
6. If ignition doesn’t occur within a few seconds release the control knob and rotate
to the “OFF” position. Wait for 5 minutes for gas to clear and then repeat the
above lighting instructions.
7. Once the fire is lit, the flame intensity may be controlled by turning the control
knob between the “LOW” and “HIGH” positions.
To Extinguish
1. Turn control knob clockwise to the “HIGH” position; let the knob pop up and
continue turning the control knob to the “OFF” position.
2. Close the cylinder valve on the propane gas tank if you don’t intend to use it for
a long time.
MAINTENANCE
• Before performing any maintenance always disconnect propane gas tank.
• Store your product indoors during winter months. Avoiding extreme cold
temperatures will prevent exposure damage.
• Keep the heating item free and clear from combustible materials.
• Visually inspect burner for obstructions and keep tank enclosure free and clear
from debris.
• Use a soft brush to get rid of the mild stains, loose dirt and soil after the burner
and pumice stones/lava rocks/Lava Glass are completely cooled down.
Wipe down with a soft cloth.
• Harsh weather conditions may cause stubborn stains, discoloration and possibly
rust pitting.
• Permanent damage may occur if powder or solvent comes in contact with painted
or plastic components on this heating unit.
• Keep the heating unit stored away from direct sunlight.• If storing this unit inside, disconnect the propane gas tank from the gas valve.• Not using manufacturer approved or supplied parts/accessories may result in a defective condition and void the warranty of this heating unit.
• If desired, cover re pit to protect exterior surfaces and to help prevent build-up in air passages.
Note: Wait until fire pit is cool before covering.

www.SereneLifeHome.com 11
TROUBLESHOOTING
Problem Cause Solution
Heating unit won’t
light
Igniter pin and burner are wet Dry off with a soft cloth
Igniter battery is incorrectly
inserted
Check which direction the
battery is inserted
Igniter pin is broken Contact us for parts
replacement
Electrode wire is loose or
disconnected
Reconnect wire to the
igniter box located inside
the fire pit behind the
igniter box
Electrode wire is shorting
between valve and igniter pin
Contact us for parts
replacement
Burner won’t light
while using a
match
No gas flow Check that the gas tank
isn’t empty
Regulator isn’t connected
securely to the tank
Tighten regulator
connection to the gas tank
Gas flow is obstructed Check all hoses for kinks
and bends
Burner ports are clogged
Turn all gas flow
connections off. Insert an
opened paperclip
(or similar item) into each
of the burner ports to clear
them out.
Heating unit emits
a lot of black
smoke
Flame is obstructed at
burner ports
Check that all burner ports
are free of any small lava
rocks/pumice stones/
LavaGlass pieces
Regulator hose is kinked Straighten hose of all
bends or kinks

www.SereneLifeHome.com12
TROUBLESHOOTING
What's in the Box:
• 201 SS Burner
• Copper Injector
• Control Knob
• Gas Valve
• Igniter
• Corrugated Pipe
Problem Cause Solution
Sudden drop in
gas flow
No gas flow Check that the gas tank
isn’t empty
Excess flow safety valve has
been activated
Turn the control knob to
the ‘off’ position. Close the
tank valve and disconnect
propane gas tank. Turn the
control knob to ‘high“, wait
1 minute. Turn the control
knob back to the ‘off’
position. Reconnect
propane gas tank.
Light the fire unit as
indicated in the ‘To Light’
section of this manual.
Flame blows out
easily
High or gusting winds Increase flame to ‘high’
No gas flow Check that the gas tank
isn’t empty
Excess flow safety valve has
been activated
See sudden drop in gas
flow’ above
• Thermocouple
• Fire Pin with Protective Guard
• PVC Cover
• Lava Rock
• User manual

www.SereneLifeHome.com 13
Features:
• Not Convertible to Natural Gas
• Assembled Gas Hose Regulator
• Adjustable Flame Height by Valve Knob
• Sturdy Metal Gas Fire Pit Table
• Control Panel
• 50,000 BTU Stainless Steel Burner
• Constructs with Weather Resistant
• Safe and ETL Certified and Approved
• Decorative Lave Rock Set
• Creates an Elegant Atmosphere in the Garden, Terrace, Balcony, or Backyard
Technical Specs:
• Construction Material: MGO
• Heat Output: 50,000 BTU
• Regulator Valve with Gas Hose Length: 118.1'' -inches
• Primary Fuel Type: Liquid Propane
• Propane Tank Weight: 20lbs. (Not Included)
• Ignition Type: Pulse Ignition
• Product Dimension (L x W x H): 48 x 26.8 x12.6 -inches

Questions? Issues?
We are here to help!
Phone: [phone]
Email: suppor[email protected]
