SereneLife SLFPS3 User manual

PropaneGasFirePitTable
SLFPS3
28 inches 40,000 BTU Square Gas Firepits
with Cover for Outside

www.SereneLifeHome.com2
DANGER
FIRE OR EXPLOSION HAZARD
If you smell gas:
• Shut o gas to the appliance.
• Extinguish any open ame.
• If odor continues, leave the area immediately.
• After leaving the area, call your gas supplier or re department.
Failure to follow these instructions could result in re or explosion, which could
cause property damage, personal injury, or death.
WARNING:
Do not store or use gasoline or other ammable vapors and liquids in the vicinity
of this or any other appliance. An LP-cylinder not connected for use shall not be
stored in the vicinity of this or any other appliance.
WARNING:
If the information in this manual is not followed exactly, a re or explosion may
result causing property damage, personal injury, or loss of life.
WARNING:
For outdoor use only. Installation and service must be performed by a qualied
installer, service agency, or the gas supplier.
WARNING:
Improper installation, adjustment, alteration, service or maintenance can cause
injury or property damage. Refer to the owner's information manual provided
with this appliance. For assistance or additional information consult a qualied
installer, services agency or the gas supplier.
INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.

www.SereneLifeHome.com 3
SAFETY INFORMATION
Before you assemble or operate this unit, please carefully read this entire
manual. Failure to do so may result in a re, explosion, injury or death.
WARNING
• The installation of this unit must adhere to local codes or Propane Storage and
Handling Code, CSA B149.2.
• THIS UNIT IS INTENDED FOR OUTDOOR USE ONLY! This product shall be used
outdoors, in a ventilated space and shall not be used in any enclosed area.
• This unit is to be used with propane gas only! (sold separately)
• Do not attach a remote gas supply to this unit.
• Only use propane gas for this unit.
• Solid fuels shall not be burned in this appliance.
• When igniting this unit, stay away from the burner as the ame will light up and
may cause injury.
• LP GAS WARNING: Do not use any more than 1/4in depth lava rocks/pumice
stones/LavaGIass above the burner holes. Doing so will suocate the ame.
• If the propane gas tank is leaking gas, you may hear, see, or smell a hiss.
Do the following:
1. Disconnect the propane gas tank.
2. Do not attempt to x the problem yourself.
3. Contact your gas supplier or re department for help.
• Applying too much propane may result in gas pooling and will not burn.
Allow fresh air into the unit so that the remaining gas may escape.
• Do not use a ame to check for gas leaks.
• Manifold pressure: 11 inch w.c. (2.74kPa).
• Use LP propane tanks with the following dimensions: diameter 12 in, height 18
in - capacity 20 lbs.
• You must use a propane tank that has a collar to protect the gas valve.
• DO NOT ll tank over 80 percent full.
• The tank system must be set up for vapor withdrawal.
• Discontinue use if any part of the propane tank is damaged. Rust and dents may
be hazardous and should be inspected by a gas supplier.
• Do not burn anything other than the provided materials for this re table.
• Keep away from the unit for the rst 20 minutes after igniting your unit for the
rst time, as lava rocks/pumice stones/LavaGlass could pop out and cause injury.
Should any rocks pop out, discard them.

www.SereneLifeHome.com4
• Always ensure that lava rocks/pumice stones/LavaGlass are completely dry before
use. Failure to do so will cause them to crack or pop.
• Do not operate unit until all parts are fully assembled.
• Do not paint or color any part of this heating unit.
• Unit may be hot while in use, do not attempt to move it while in use.
• Never leave this heating unit unattended while in use.
• This unit is not intended for cooking.
• Keep any ammable items away and do not use any other replace cover for this
unit.
• Keep a safe distance to avoid burning skin or clothing.
• Do not sit or rest hands or feet on this heating unit.
• Never place hands or ngers on upper portion of this unit while in use.
• Keep all electrical cords and fuel supply hose away from heated surfaces.
• Combustible material should not be within 60 inches of the top of the unit, or
within 48 inches around the entire unit.
• Keep the appliance area clear and free from combustible material, gasoline, and
other ammable vapors and liquids.
• Do not add water into the unit.
• Do not operate unit if any part has been under water. Immediately call a qualied
service technician to inspect the appliance and replace any part of the control
system and any gas control that has been under water.
• Do not disconnect any part while unit is in use.
• Do not store a spare propane tank on or near this unit.
• If the heating unit is indoors, detach the propane tank and leave outdoors.
• Always remove protective cover before operating (if applicable).
• Do not set the protective cover over the unit until it is turned o and completely
cooled down.
• Check for leaks after not using the unit for long periods of time.
• Children should never operate this unit. Children must be supervised while
near this unit.
• Keep gas tank at least 5 feet away from unit when lit. (if external tank)
• Maximum gas supply: 250 psi; Min. gas supply: 10 psi.

www.SereneLifeHome.com 5
• All installation and repair should be done by a qualied professional.
This unit should be inspected annually and cleaned regularly.
• Inspect all elements of this heating unit before each use. If there is damage, the
burner must be replaced.
• Keep the hose out from any pathways to eliminate any accidental damage.
(if external tank).
• Be aware of the hazards of high temperatures and stay away from the unit to
avoid any burns or injury.
• The gas supply tank should be constructed and marked with specications for
the LP gas tanks of the U.S. Department of Transportation or the National
Standard of Canada CAN/CSA-B339, LP gas tanks, spheres and tubes for
Transportation of Dangerous Goods; and Commission.
• The LP gas tank must have a listed overlling prevention device and a QCCI or
Type I, (CGA791) LP gas tank connection.
• This heating appliance appliance should not be used on plastic or articial wood
decks.
• Children and adults should be alerted to the hazards of high surface temperatures
and should stay away to avoid burns or clothing ignition.
• Young children should be carefully supervised when they are in the area of the
appliance.
• Clothing or other ammable materials should not be hung from the
appliance or placed on or near the appliance.
• Any guard or other protective device removed for servicing the appliance shall
be replaced prior to operating the appliance.
• Installation and repair should be done by a qualied service person.
The appliance should be inspected before use and at least annually by a
qualied service person. More frequent cleaning may be required as
necessary. It is imperative that the control compartment, burners and
circulating airways of the appliance are kept clean.

www.SereneLifeHome.com6
IF APPLICABLE:
• Allow heating item to cool completely before placing on lid.
• DO NOT use heating item while lid is installed. Always remove the lid while
heating item is in use.
WARNING
• Do not light or use gas unit if lava rocks are wet. Ensure lava rocks are completely
dry before igniting as intense heat could cause the rocks to crack.
• Lava rocks could hit somebody's face or eyes during initial start of this unit, so
please keep away from the rebowl for the rst 20 minutes after it has been
ignited.
• Do not exceed 1/4" depth of re glass or small lava rocks directly above burner
holes. Applying too many lava rocks/re glass may result in unburned gas
pooling in rebowl or repit. Ventilation is required to allow fresh air into
enclosure and any residual gas to escape.
WARNING
CAUTION: This heating item should not be used on plastic composite or articial
wood.
SCREEN
CORRECT INCORRECT
WARNING
DO NOT COVER THE IGNITION SCREEN when placing the lava
rock into the re bowl. Always keep the ignition screen visible.

www.SereneLifeHome.com 7
WARNING
When you turn the cylinder, the gas hose needs to be straightened during use.
Otherwise the hose may melt and cause a re.
SAFETY INFORMATION
Only use the regulator and hose assembly provided with this unit. Replacement
parts must be supplied directly by us.
Inspect the burner before use of this unit. If the burner shows any kind of
damage, do not operate the appliance. For assistance with repair or replacement
of the burner or any other parts, contact to us.
NOTE: You must follow all steps to properly assemble this heating item.
Make sure the gas valve is turned “OFF” before assembling. Do NOT attempt to
assemble without proper tools.

www.SereneLifeHome.com8
Combustible materials should not be within 60 inches of the top of the unit, or
within 48 inches around the entire unit.
HARDWARE
Before beginning assembly of this product be sure all parts are present. Compare
parts with package contents list and hardware contents list. If any part appears to
be missing or damaged do not begin assembly of this product and call customer
service immediately.
Estimated assembly time: 30 minutes
CONTENTS
ITEM DESCRIPTION
AA M6 x 12 Screw
BB M6 x 25 Screw
CC Nut
QTY
17
4
20
AA BB CC

www.SereneLifeHome.com 9
ASSEMBLY INSTRUCTIONS
• Please keep this owner’s manual for future reference.
• Do not exceed 1/4”depth of small lava rocks directly above burner holes.
Applying too many lava rocks may result in unburned gas pooling in the re
bowl. Ventilation is required to allow fresh air in and any residual gas to escape.
• Do not use if lava rocks are wet. Be sure lava rocks are dry before lighting as
intense heat could cause the rocks to crack.
Carefully remove all items from the carton. Be sure all packaging, both under the
re pit and around the re bowl, is removed before using.
A. Check each part before using the product. Make sure the gas supply system is
turned “OFF” before assembling. See Figure A.
Figure A

www.SereneLifeHome.com10
B. Locate the battery and remove from plastic. Unscrew the rubber cap of the
electric igniter and place AA battery into the battery case. Make sure the
positive pole ("+") is towards the cap.
Screw the cap back onto the battery case tightly. See Figure B.
C. Place the lava rock evenly in the re bowl. See Figure C.
Figure B
Figure C

www.SereneLifeHome.com 11
1. Check that the control knob (M) for the gas supply
system is turned to the“OFF”position before starting
any assembly.
2. Attach leg (G/H/I/J) to the metal stand (K) using 4 pcs.
screws (BB) and 4 pcs washers (CC).
3. Attach the 3 side panels (D/E/F) to the legs using
12 pcs screws (AA) and 12 pcs washers (CC).
4. Attach the door (C) to leg using 2 pc screw (AA).
5. Attach metal base to the bottom part of the table
top (B) using 4 pcs screws (AA) and 4 pcs washers (CC).
B
H
G

www.SereneLifeHome.com12
6. Put the lid
7. Place propane gas tank (not included) into the
metal stand (K). Make sure the gas tank sits on
the metal stand (K) completely.
Turn the preassembled wing screw on the
outer part of metal stand (K) clockwise to secure
the propane gas tank tightly.
8. Turn the cylinder valve on the tank clockwise to
close the propane tank.
Attach the preassembled regulator from the
table top (B) to the cylinder valve by turning the
regulator coupling nut clockwise. Make sure it
is fastened securely and tighten connections by
hand only.
9. Pour the box of lava rocks (L) into the rebowl.
CAUTION
To ensure proper function, the guard on this burner should be free of lava
rocks at all times.
K
A
K
CYLINDER VALVE
PRESSURE
RELIEF VALVE
BLEED-OFF
VALVE
BLACK COUPLING NUT
REGULATOR
turn clockwise to connect
turn clockwise
to reseal

www.SereneLifeHome.com 13
OPERATION
Before performing a leak test, be sure that no sparks can occur and you are in a
spacious outdoor area. Connect the propane gas tank to the regulator and turn the
valve on the unit to the“o” position. Brush a soap and water mixture on all
connections. Turn the gas supply on; if bubbles occur on any connection there may
be a leak. If you smell gas or a leak is discovered turn the gas valve o, disconnect
propane gas tank and do not use the appliance until the leak is repaired.
Do not use the heating unit without inspecting the gas hose. If there are signs of
wear or abrasion you must replace the hose (if applicable). Pumice stones/lava
rocks/LavaGlass could pop up and strike somebody’s face during the process of
lighting this unit; stand away from the unit for the rst 20 minutes after igniting.
Flame height should be a yellow/blue color between 2 - 10 inches in height.
Wait 50 minutes after extinguishing ame prior to placing a lid (if applicable) or
protective cover on heating item.
To Light
1. Make sure the control knob is in the "OFF" position.
2. Open the door and slowly open the valve on the propane gas tank by turning
the knob counterclockwise.
3. Close the door on the body.
4. Push the ignition control knob in fully and rotate about 1/4 turn counter-
clockwise until a click is heard, it may take several attemps to light the burner.
Once lit, keep holding down the control knob for 15 seconds.
5. If ignition doesn’t occur within a few seconds, release the control knob and
rotate to the "OFF" position. Wait for 5 minutes for gas to clear and then repeat
the above lighting instructions.
6. To adjust the ame, turn the control knob either clockwise or counterclockwise
depending on whether you want to lower or raise the ame.

www.SereneLifeHome.com14
To Extinguish
1. Turn control knob clockwise to the "HIGH" position; push and continue turning
the control knob to the "OFF" position.
2. Close the cylinder valve on the propane gas tank if you don't intend to use it for
a long time.
MAINTENANCE
• Before performing any maintenance always disconnect propane gas tank.
• Store your product indoors during winter months. Avoiding extreme cold
temperatures will prevent from exposure damage.
• Keep the heating item free and clear from combustible materials.
• Visually inspect burner for obstructions and keep tank enclosure free and clear
from debris.
• Use a soft brush to get rid of the mild stains, loose dirt and soil after the burner
and pumice stones/ lava rocks/LavaGlass are completely cooled down.
Wipe down with a soft cloth.
• Harsh weather conditions may cause stubborn stains, discoloration and possibly
rust pitting.
• Permanent damage may occur if powder or solvent comes in contact with
painted or plastic components on this heating unit.
• Keep the heating unit stored away from direct sunlight.
• If storing this unit inside, disconnect the propane gas tank from the gas valve.
• Not using manufacturer approved or supplied parts/accessories may result in a
defective condition and void the warranty of this heating unit.
• Always place lid (if applicable) or protective cover on heating item when not in
use.

www.SereneLifeHome.com 15
TROUBLESHOOTING
This product can expose you to a chemical or group of chemicals, which
may include “Lead and lead compounds” which is known in the state of
California to cause cancer, birth defects, or other reproductive harm.
For more info, go to https://www.p65warnings.ca.gov/.
Problem Cause Solution
Heating unit won’t
light
Igniter pin and burner are wet Dry o with a soft cloth
Igniter battery is incorrectly
inserted
Check which direction the
battery is inserted
Igniter pin is broken Contact us for parts
replacement
Electrode wire is loose or
disconnected
Reconnect wire to the
igniter box located inside
the re pit behind the
igniter box
Electrode wire is shorting
between valve and igniter pin
Contact us for parts
replacement
Burner won’t light
while using a
match
No gas ow Check that the gas tank
isn’t empty
Regulator isn’t connected
securely to the tank
Tighten regulator
connection to the gas tank
Gas ow is obstructed Check all hoses for kinks
and bends
Burner ports are clogged
Turn all gas ow
connections o. Insert an
opened paperclip
(or similar item) into each
of the burner ports to clear
them out.
Heating unit emits
a lot of black
smoke
Flame is obstructed at
burner ports
Check that all burner ports
are free of any small lava
rocks/pumice stones/
LavaGlass pieces
Regulator hose is kinked Straighten hose of all
bends or kinks

www.SereneLifeHome.com16
TROUBLESHOOTING
What's in the Box:
• Steel Tabletop and Panel
• Stainless Steel Fire Pan
• 201 SS Burner
• Copper Injector
• Control Knob
• Gas Valve
• Corrugated Pipe
• Pulse Igniter
• Thermocouple
• Fire Pin with Protective Guard
• PVC Cover
• Lava Rock
• Steel Cover Lid
• Battery
Problem Cause Solution
Sudden drop in
gas ow
No gas ow Check that the gas tank
isn’t empty
Excess ow safety valve has
been activated
Turn the control knob to
the ‘o’ position. Close the
tank valve and disconnect
propane gas tank. Turn the
control knob to ‘high“, wait
1 minute. Turn the control
knob back to the ‘o’
position. Reconnect
propane gas tank.
Light the re unit as
indicated in the ‘To Light’
section of this manual.
Flame blows out
easily
High or gusting winds Increase ame to ‘high’
No gas ow Check that the gas tank
isn’t empty
Excess ow safety valve has
been activated
See ‘sudden drop in gas
ow’ above

www.SereneLifeHome.com 17
Features:
• Not Convertible to Natural Gas
• With Fire Pit Cover Lid
• Stainless Steel Fire pan
• Assembled Gas Hose Regulator
• Adjustable Flame Height by Valve Knob
• Sturdy Metal Gas Fire Pit Table
• Easy to Put Propane Tank, In, and Out
• Stainless Steel Control Panel
• 40,000 BTU Stainless Steel Burner
• Constructs with Weather Resistant
• Sturdy Metal for Durability and Long-term Use
• Easy to Assemble with Two Persons, Takes 20-30 Minutes
• Safe and CSA Certied and Approved
• Comes with 1 pc. Independently Metal Table Top and 6.6 lbs. Decorative lave
Rock Set
• Creates an Elegant Atmosphere in the Garden, Terrace, Balcony or Backyard
Technical Specs:
• Construction Material: Metal +201 SS Fire Pan
• Heat Output: 40,000 BTU
• Regulator Valve with Gas Hose Length: 19.7'' -inches (500mm)
• Metal Cover: Metal and PVC Cover
• Primary Fuel Type: Liquid Propane
• Propane Tank Weight: 20lbs. (Not Included)
• Ignition Type: Pulse
• Battery Type: (1) x ‘AA’ Battery (not rechargeable)
• Product Dimension (L x W x H): 28'' x 28'' x 24.5'' -inches

Questions? Issues?
We are here to help!
Phone: [phone]
Email: suppor[email protected]
