Settop FRE207 User manual

USER’S MANUAL
Dual Slope
laSer level
FRE207A FRE207A
FRE205B FRE205B
FRE207 FRE207
FRE207A
FRE205B
FRE207

2
FRE207A FRE207A
FRE205B FRE205B
FRE207 FRE207
FRE207A
FRE205B
FRE207
USER’S MANUAL
CONTENTS
Equipment included in your FRE207 Settop 3
Exterior composition of the FRE207 Settop 4
Battery Charger 5
Instructions 6
Detector 8
Specifications 9
Safety Precautions 10

3
FRE207A FRE207A
FRE205B FRE205B
FRE207 FRE207
FRE207A
FRE205B
FRE207
USER’S MANUAL
EQUIPMENT INCLUDED IN YOUR FRE207 SETTOP
FRE201
Settop
Settop
FRE207
Glasses
Remote
control
Battery
charger Target

4
FRE207A FRE207A
FRE205B FRE205B
FRE207 FRE207
FRE207A
FRE205B
FRE207
USER’S MANUAL
EXTERIOR COMPOSITION OF THE FRE207 SETTOP
Plumb Laser module
Charger output
Bubble
level
Transport
handle
Optic Protection
LCD Screen
Key panel

5
FRE207A FRE207A
FRE205B FRE205B
FRE207 FRE207
FRE207A
FRE205B
FRE207
USER’S MANUAL
BATTERY CHARGER
The instrument is normally already charged when you receive it; however, it
is recommended that you charge the batteries before each use.
Insert the charger inside the compartment of the laser level or turn it on
through the battery pack. On the charger there will appear three charging
modes:
Blinking red light - battery not charged
Red light - battery charging
Green light - battery charged
Once the battery is charged, a green light will appear on the instrument. It
normally takes 7 hours to charge the device and once charged gives a use of
20 hours.

6
FRE207A FRE207A
FRE205B FRE205B
FRE207 FRE207
FRE207A
FRE205B
FRE207
USER’S MANUAL
AngulAr mode: press to
enter vAlues x And y
KeyboArd vAlues positive
on slope: chAnge the
direction of rotAtion
KeyboArd vAlues negAtive
on slope: chAnge the
direction of rotAtion
introduction of the vAlues
for x And y
rotAtion speed:
0-120-300-600
scAnning mode: by
pressing you cAn obtAin
worKing Angles with A
line of: 0-10-45-180-0
on/off mAnuAl mode
leveling AlArm system
ActivAtion: ActivAte
once the instrument is
leveled
INSTRUCTIONS

7
FRE207A FRE207A
FRE205B FRE205B
FRE207 FRE207
FRE207A
FRE205B
FRE207
USER’S MANUAL
INSTRUCTIONS
HORIZONTAL LEVELING MODE
Press the on key to turn on the instrument.
The level will automatically self-level.
The level has a range of self-levelling of 5 degrees.
Activate the alarm key.
Once self-levelled the level will start to rotate.
SLOPE MODE
The FRE207 level allows you to work with slope values of up to 8% for axes x and y. Once
the level is self-levelled in horizontal mode, press the G key.
The key to enter the value for x will start to blink.
Use the keys + (more) or – (less) to enter the slope. In the direction x press the key x/y to
introduce the value in y.
Use the keys + (more) or – (less) to enter the slope in y.
Press the x/y key again to confirm the slope data introduced.
After a few seconds, the level will search for the values introduced.
VERTICAL LINES MODE
Once the instrument is positioned in horizontal mode, it will automatically level itself. It
will project two plumb points and a vertical line.
OTHER FUNCTIONS
SCANNING MODE
This mode is used mainly for interior jobs. The beam is centred on a specific area. The beam
projects a line that works with the options of 10º, 45º , 90º y 180º.
REMOTE CONTROL
The remote control allows you to work via radio at a distance of 80 metres. The keys that
the remote control has have the same functions as the details on the display. To make it
easier it is better to use the remote control to avoid moving the keyboard.
importAnt: do not chArge AlKAline bAtteries As this could cAuse serious dAmAge to the instrument

8
FRE207A FRE207A
FRE205B FRE205B
FRE207 FRE207
FRE207A
FRE205B
FRE207
USER’S MANUAL
DETECTOR
The detector has a sensor in the window that allows it to detect the beam
when it is in rotation mode.
The detector has three functions:
a) On/off button
b) Three volume tones: sound off-low-high
c) Accuracy sensibility. You are able to obtain greater or lesser accuracy via
this function
When the detector is too high in relation to the laser level a low sound will
be emitted, when too low a fast sound, and when it is at the same level a
continuous sound will be emitted and will signal the centre of alignment
with the laser level.
The detector is powered by a 9v battery.

9
FRE207A FRE207A
FRE205B FRE205B
FRE207 FRE207
FRE207A
FRE205B
FRE207
USER’S MANUAL
SPECIFICATIONS
Accuracy: +- 2 mm 30 m.
Slope range: 10º
Self-levelling range: 5º
Type of laser: diode laser visible 635 nm
Class: Class 2 m
Measuring range: 500 m. with detector
Rotation speed: 60,120, 300, 600 revolutions per minute
Scanning angle: 10º,45º,90º,180º
Remote control: operational up to 20 metres
Power supply: dc 4.8-6v ( battery ni-mh)
replaceable battery pack (ni-mh)
or alkaline battery pack
Battery life: 20 hours of continuous work
Damp and dust protection: ip54
Dimensions: 160l x 160w x 185h
Weight: 3 kg (sin baterías)

10
FRE207A FRE207A
FRE205B FRE205B
FRE207 FRE207
FRE207A
FRE205B
FRE207
USER’S MANUAL
SAFETY PRECAUTIONS
Avoid direct eye exposure to the laser beam over a prolonged period. The
laser has a diode and powers that are not harmful to eyesight.
Place the instrument above eye level.
Do not try to repair the instrument yourself, contact the technical service
team for any problems.
When you mount the laser on the tripod make sure that it is securely fastened
with the tripod screws and that the legs of the tripod are stable.
The instrument should not be used or stored at temperatures of over 50
degrees.
Always store the instrument in its carry case when not in use to avoid potential
damage.
Avoid sudden changes of temperature. The instrument must be acclimatized
before use
