Sevenoak SK-JA20 User manual

Carbon Fiber Jib Arm
SK-JA20
Warnings
Limited One-year Warranty
●Please read and follow these instructions, and keep this
manual in a safe place.
● Handle the unit with care.
●Clean the unit with a soft, dry cloth.
●Use only parts provided by the manufacturer.
●Make sure everything is secure before proceeding.
●Make sure the item is intact and that there are no missing
parts.
●Do not exceed the maximum load capacity.
●All photos are for illustrative purposes only.
Sevenoak provides a limited warranty that this product
is free from defects in materials and workmanship to the
original purchaser under normal use for a period of one
(1) year from the original purchase date or thirty (30)
days after replacement (the “Warranty Period”),
whichever occurs later.Our responsibility with respect to
this limited warranty shall be limited solely to repair or
replacement, at its option, of any product which fails
during normal consumer use.
To obtain warranty coverage during the Warranty period,
contact your place of purchase (”Seller”) to obtain a
return merchandise authorization (”RMA”) number, and
return to Seller the defective product along with proof of
purchase and the RMA number.
This warranty does not extend to damage or failure
which results from misuse, neglect, accident, alternation,
abuse, improper installation or maintenance. Except as
provided Herein, sevenoak makes neither any express
Warranties nor any implied warranties, including But not
limited to any implied warranty of Merchantability or
fitness for a particular Purpose. This warranty provides
you with specific legal rights, and you may also have
additional rights which vary from state to state.

Attached the L shape bracket to the camera mounting plate on
the jib arm, then lock the L shapre bracket. Now you can mount
the camera onto the L shape bracket and start shooting.
The Max working size of this jib arm is as follow.
The Min working size of this jib arm is as follow.
This Jib arm can be mounted on the tripod to make it
more steady and easier for your shooting.
The L shape bracket can turn 90 degree to fit for dierent
shooting invironment. You can use the included 1/4” screw
to fix the L shape bracket, then use the set screw to fix the L
shape bracket to avoid any movements during shooting.
2393 2220
1188(MAX)
490(MIN)
290
Specification
SK-JA20 Net weight: 2.30KG
Max load capacity: 5KG
Max working radius: 1.12m
Min working radius: 0.49m
Max working size:
2.2*0.06*0.29m
Components:
Main body
L shape bracket
2* 1/4” screw
2.5mm Hex Wrench
2* set screw
3.0mm wrench
3/8” screw
Min working size:
1.17*0.06*0.29m
Note: Please do not screw o the components, just unscrew
them to an adjustable position.
Sevenoak SK-JA20 is a tripod mounted camera crane system
designed to allow you to smoothly boom your camera up, down
and move your camera in an infinite number of 360 degree
arcs. When balanced properly and used correctly, SK-JA20
enables you to move your camera precisely and fluidly and get
that marvelous picture or short film. It’s perfect for wedding
videographers, documentary producers, music video produc-
tions or for anyone who has the need for a jib arm.
Assemble the L shape bracket for low angle shooting
