Sevenoak SK-F1X User manual

Follow Focus
SK-F1X
Warnings
Limited One-year Warranty
●Please read and follow these instructions, and keep
this manual in a safe place.
●Handle the unit with care.
●Clean the unit with a soft, dry cloth.
●Use only parts provided by the manufacturer.
●Make sure everything is secure before proceeding.
●Make sure the item is intact and that there are no
missing parts.
●Do not exceed the maximum load capacity.
●All photos are for illustrative purposes only.
Sevenoak provides a limited warranty that this product
is free from defects in materials and workmanship to the
original purchaser under normal use for a period of one
(1) year from the original purchase date or thirty (30)
days after replacement (the “Warranty Period”), whichever
occurs later.Our responsibility with respect to this limited
warranty shall be limited solely to repair or replacement,
at its option, of any product which fails during normal
consumer use.
To obtain warranty coverage during the Warranty period,
contact your place of purchase (”Seller”) to obtain a return
merchandise authorization (”RMA”) number, and return to
Seller the defective product along with proof of purchase
and the RMA number.
This warranty does not extend to damage or failure which
results from misuse, neglect, accident, alternation, abuse,
improper installation or maintenance. Except as provided
Herein, sevenoak makes neither any express Warranties
nor any implied warranties, including But not limited to any
implied warranty of Merchantability or fitness for a partic-
ular Purpose. This warranty provides you with specific legal
rights, and you may also have additional rights which vary
from state to state.
SK-F1X in Use
Attach Follow Focus SK-F1X to the right side of the lens.
Attach Follow Focus SK-F1X to the left side of the lens.

Components:
Specifications:
Product net weight: 0.36kg
Package Content:
1*Follow focus
1*66-77mm gear ring
1*77-88mm gear ring
1*88-99mm gear ring
1*Instruction
Features:
Compatible with standard 15mm rail system
Smooth fluid movements for easy focus adjustments
Easy to setup and remove
Solid and durable Aluminum construction
Adjustable height
Flippable gearbox
Can be used on either side of the lens
Removable magnetic marking disc
Includes three dierent sizes lens gear rings
1* Follow Focus
1*66-77mm
gear ring
1*77-88mm
gear ring
1*88-99mm
gear ring
Installation:
1. Choose the proper gear ring and attach it to the camera lens.
2. Install the follow focus wheel to either side according to you habit.
3. Loosen the locking screws on the follow focus, then attach the
follow focus to either side of the rails according to your habit.
4. Slide the follow focus to a proper position that is close to the camera
gear ring, then tighten the locking screw.
5. Adjust the height of the follow focus so that the wheel can properly
match with the gear ring, then tighten the locking screw.
6. Enjoy shooting with your follow focus! (The square hole in the follow
focus is compable with a whip or crank handle which is sold separately. )
Locking screw
Locking screw
Locking screw
Square hole
Locking screw
