SEW ST-2001 User manual

INSTRUCTION MANUAL
AC DIGITAL
PORTABLE VOLTMETER
ST-2001

INDEX PAGE
1.INTRODUCTION........................ 1
2.SAFETY NOTES......................... 2
3.FEATURES................................ 3
4.SPECIFICATIONS...................... 4
5.GENERAL.................................. 5
6.INSTRUMENT LAYOUT............... 6-8
7.MEASUREMENT......................... 9
8.MAINTENANCE......................... 10
NOTE
This meter has been designed and tested according
to CE Safety Requirements for Electronic Measuring
Apparatus, IEC / EN 61010-1 and other safety
standards. Follow all warnings to ensure safe
operation.
WARNING
READ "SAFETY NOTES" (NEXT PAGE) BEFORE
USING THE METER.
1. INTRODUCTION
- 1 -

INDEX PAGE
1.INTRODUCTION........................ 1
2.SAFETY NOTES......................... 2
3.FEATURES................................ 3
4.SPECIFICATIONS...................... 4
5.GENERAL.................................. 5
6.INSTRUMENT LAYOUT............... 6-8
7.MEASUREMENT......................... 9
8.MAINTENANCE......................... 10
NOTE
This meter has been designed and tested according
to CE Safety Requirements for Electronic Measuring
Apparatus, IEC / EN 61010-1 and other safety
standards. Follow all warnings to ensure safe
operation.
WARNING
READ "SAFETY NOTES" (NEXT PAGE) BEFORE
USING THE METER.
1. INTRODUCTION
- 1 -

2.SAFETY NOTES
Read the following safety information carefully
before attempting to operate or service the meter.
Use the meter only as specified in this manual.
Otherwise, the protection provided by the meter
may be impaired.
Rated environmental conditions
(1) Indoor Use.
(2) Installation Category .
(3) Pollution Degree 2.
(4) Altitude up to 2000 meters.
(5) Relative humidity 80% max.
(6) Ambient temperature 0~40°C
Observe the International Electrical Symbols
listed below
Meter is protected throughout by double
insulation or reinforced insulation.
Warning ! Risk of electric shock.
Caution ! Refer to this manual before using
the meter.
Alternating current.
.
- 2 -
3.FEATURES
Complies with CE standard EN61010-1.
Water proof design, protection class: IP54
Precision meter for factory maintenance, field
servicing and educational purposes.
Easy to carry handle that doubles as a convenient
stand.
Large Liquid Crystal Display (112x59mm)
Back light function.
Analog scale with Bar-graph for viewing. (100 bars)
10000-count LCD (high resolution)
ACV Ranges: 99.99mV~800.0V
5 manual ranges controlled by rotary switch
Data Hold function
Low battery indication
9V power supply
Best resolution of 0.01mV (10uV)
- 3 -
AC

2.SAFETY NOTES
Read the following safety information carefully
before attempting to operate or service the meter.
Use the meter only as specified in this manual.
Otherwise, the protection provided by the meter
may be impaired.
Rated environmental conditions
(1) Indoor Use.
(2) Installation Category .
(3) Pollution Degree 2.
(4) Altitude up to 2000 meters.
(5) Relative humidity 80% max.
(6) Ambient temperature 0~40°C
Observe the International Electrical Symbols
listed below
Meter is protected throughout by double
insulation or reinforced insulation.
Warning ! Risk of electric shock.
Caution ! Refer to this manual before using
the meter.
Alternating current.
.
- 2 -
3.FEATURES
Complies with CE standard EN61010-1.
Water proof design, protection class: IP54
Precision meter for factory maintenance, field
servicing and educational purposes.
Easy to carry handle that doubles as a convenient
stand.
Large Liquid Crystal Display (112x59mm)
Back light function.
Analog scale with Bar-graph for viewing. (100 bars)
10000-count LCD (high resolution)
ACV Ranges: 99.99mV~800.0V
5 manual ranges controlled by rotary switch
Data Hold function
Low battery indication
9V power supply
Best resolution of 0.01mV (10uV)
- 3 -
AC

AC Voltages
- 4 -
4.SPECIFICATIONS(All at 23°C±5°C, 80%R.H)
Resolution
10uV
100uV
1mV
10mV
100mV
Range
100.00mV
1000.0mV
10.000V
100.00V
800.0V
Accuracy
50/60HZ: ±(0.3%+5dgt)
40~400HZ: ±(0.5%+6dgt)
50/60HZ: ±(0.3%+5dgt)
40~400HZ: ±(0.5%+6dgt)
50/60HZ: ±(0.3%+5dgt)
40~400HZ: ±(0.5%+6dgt)
50/60HZ: ±(0.3%+5dgt)
40~400HZ: ±(0.5%+6dgt)
50/60HZ: ±(0.3%+5dgt)
40~400HZ: ±(0.5%+6dgt)
5.GENERAL
Operating Temperature & Humidity
0°C~40°C, 80% Max. R.H.
Storage Temperature & Humidity
-10°C~50°C, 80% Max. R.H.
Power source
1.5V (AA) battery x 6.
Dimensions
Approx. 177mm(L) x 200mm(W) x 105mm(D)
with holster
Weight
Approx. 1210g (batteries and holster included)
Safety Standards
EN 61010-1 CAT 1000V / CAT 600V
EN 61326-1
Low Battery Indication
" " sign appears on the display when the battery
voltage drops below accurate operating level.
Accessories
Instruction Manual
Batteries
Test leads AL-11-5 (Optional)
Alligator (Optional)
Holster (Optional)
- 5 -
<

AC Voltages
- 4 -
4.SPECIFICATIONS(All at 23°C±5°C, 80%R.H)
Resolution
10uV
100uV
1mV
10mV
100mV
Range
100.00mV
1000.0mV
10.000V
100.00V
800.0V
Accuracy
50/60HZ: ±(0.3%+5dgt)
40~400HZ: ±(0.5%+6dgt)
50/60HZ: ±(0.3%+5dgt)
40~400HZ: ±(0.5%+6dgt)
50/60HZ: ±(0.3%+5dgt)
40~400HZ: ±(0.5%+6dgt)
50/60HZ: ±(0.3%+5dgt)
40~400HZ: ±(0.5%+6dgt)
50/60HZ: ±(0.3%+5dgt)
40~400HZ: ±(0.5%+6dgt)
5.GENERAL
Operating Temperature & Humidity
0°C~40°C, 80% Max. R.H.
Storage Temperature & Humidity
-10°C~50°C, 80% Max. R.H.
Power source
1.5V (AA) battery x 6.
Dimensions
Approx. 177mm(L) x 200mm(W) x 105mm(D)
with holster
Weight
Approx. 1210g (batteries and holster included)
Safety Standards
EN 61010-1 CAT 1000V / CAT 600V
EN 61326-1
Low Battery Indication
" " sign appears on the display when the battery
voltage drops below accurate operating level.
Accessories
Instruction Manual
Batteries
Test leads AL-11-5 (Optional)
Alligator (Optional)
Holster (Optional)
- 5 -
<

(5)HOLD Button
(6)Back light Button
(7)Handle
(8)Holster
6.INSTRUMENT LAYOUT
(1)Rotary Switch
(2)Large LCD
(3)Red testing terminal
(4)Black testing terminal
- 6 - - 7-
(1) Rotary switch
The rotary switch selects the range for different
voltages.
(2) Large LCD (112x59mm)
10000-count LCD.
Analog scale with Bar-graph for viewing(100
bars).
(3) Red testing terminal
This is the red testing terminal for AC voltage
measurement. Use the red test lead to connect.
(4) Black testing terminal
This is the black testing terminal for AC voltage
measurement. Use the black test lead to connect.
(5) HOLD Button
Pressing the HOLD button (HOLD annunciator
turns on) makes the meter stop updating the LCD
display. HOLD function can be cancelled by
changing the range or pushing the HOLD button
again.
(6) Back light Button
Press the " " button to enable the back light
function. The backlight function will last for about
8 seconds. Or you can press the " " button again
to disable the function.
(1)
(2) (3)
(4)
(5)
(6)
(7)
(8)

(5)HOLD Button
(6)Back light Button
(7)Handle
(8)Holster
6.INSTRUMENT LAYOUT
(1)Rotary Switch
(2)Large LCD
(3)Red testing terminal
(4)Black testing terminal
- 6 - - 7-
(1) Rotary switch
The rotary switch selects the range for different
voltages.
(2) Large LCD (112x59mm)
10000-count LCD.
Analog scale with Bar-graph for viewing(100
bars).
(3) Red testing terminal
This is the red testing terminal for AC voltage
measurement. Use the red test lead to connect.
(4) Black testing terminal
This is the black testing terminal for AC voltage
measurement. Use the black test lead to connect.
(5) HOLD Button
Pressing the HOLD button (HOLD annunciator
turns on) makes the meter stop updating the LCD
display. HOLD function can be cancelled by
changing the range or pushing the HOLD button
again.
(6) Back light Button
Press the " " button to enable the back light
function. The backlight function will last for about
8 seconds. Or you can press the " " button again
to disable the function.
(1)
(2) (3)
(4)
(5)
(6)
(7)
(8)

(7) Handle
Easy-to-carry handle that doubles as a
convenient stand.
Pull to rotate
Rotate the handle at different angles
The handle functions as a stand
(8) Holster
Rugged holster for protection.
- 8 - -9-
7. MEASUREMENT
Before proceeding with measurement , read the
safety notes.
AC Voltage measurement
(1) Insert the Red test lead to the Red testing
terminal and insert the black test lead to the
Black testing terminal.
(2) Select the appropriate range for ACV
measurement. If the magnitude of the voltage
is unknown, select the highest range first
(800V). Then reduce the range until the
desired resolution is reached.
(3) Obtain the reading from the Large LCD directly.
Red
Black

(7) Handle
Easy-to-carry handle that doubles as a
convenient stand.
Pull to rotate
Rotate the handle at different angles
The handle functions as a stand
(8) Holster
Rugged holster for protection.
- 8 - -9-
7. MEASUREMENT
Before proceeding with measurement , read the
safety notes.
AC Voltage measurement
(1) Insert the Red test lead to the Red testing
terminal and insert the black test lead to the
Black testing terminal.
(2) Select the appropriate range for ACV
measurement. If the magnitude of the voltage
is unknown, select the highest range first
(800V). Then reduce the range until the
desired resolution is reached.
(3) Obtain the reading from the Large LCD directly.
Red
Black

-10 -
8. MAINTENANCE
Battery replacement
When the low battery warning symbol appears,
replace with new batteries as follows
(1) Disconnect the test leads from the instrument and
turn off the power.
(2) Unscrew the battery cover and replace with new
batteries.
(3) Close the battery cover and screw.
Cleaning and Storage
Periodically wipe the case with a damp cloth and
detergent. Do not use abrasives or solvents.
If the meter is not used for over 60 days, remove the
batteries for storage.
WARNING
To avoid electrical shock or damage to the meter,
do not get water inside the case.
Due to our policy of constant improvement and development, we reserve
the right to change specifications without notice.
-11 -
CAT - Is for measurements performed at the
source of the low voltage installation.
CAT - Is for measurements performed in the
building installation.
CAT - Is for measurement performed on circuits
directly connected to the low voltage
installation.
CAT - Is for measurements performed on circuits
not directly Connected to Mains.
Batteries
Screw

-10 -
8. MAINTENANCE
Battery replacement
When the low battery warning symbol appears,
replace with new batteries as follows
(1) Disconnect the test leads from the instrument and
turn off the power.
(2) Unscrew the battery cover and replace with new
batteries.
(3) Close the battery cover and screw.
Cleaning and Storage
Periodically wipe the case with a damp cloth and
detergent. Do not use abrasives or solvents.
If the meter is not used for over 60 days, remove the
batteries for storage.
WARNING
To avoid electrical shock or damage to the meter,
do not get water inside the case.
Due to our policy of constant improvement and development, we reserve
the right to change specifications without notice.
-11 -
CAT - Is for measurements performed at the
source of the low voltage installation.
CAT - Is for measurements performed in the
building installation.
CAT - Is for measurement performed on circuits
directly connected to the low voltage
installation.
CAT - Is for measurements performed on circuits
not directly Connected to Mains.
Batteries
Screw
