Sfa Sanispeed 2 User manual

SHOWER

04.13

FR NOTICE D’INSTALLATION

UK INSTALLATION INSTRUCTIONS

DE INSTALLATIONSHINWEISE

IT STRUZIONI PER L’INSTALLAZIONE

ES MANUAL DE INSTALACIÓN

PT MANUAL DE INSTALAÇÃO

NL INSTALLATIE VOORSCHRIFTEN

SE INSTALLATIONSANVISNING

DK INSTALLATIONSVEJLEDNING

INSTALLASJONSANVISING

FI ASENNUSOHJEET

FELSZERELÉSI ÉS KEZELÉSI ÚTMUTATÓ

PL INSTRUKCJA INSTALACJI



MANUAL DE INSTALARE

CZ !"##

TR KURULUM KILAVUZU

119

SANIPUMP

SANISHOWER

SANIDOUCHE



2'+*,(6 (*.$7$67$6+6

KR 설치내용서

24 5

678

✓✓

✓

✓✓

✓

4 m max

××

Ø 40mm

Ø 32/40mm

Ø 32/40 mm

Ø 22/32 mm

✓

Ø 3

2/40m

25x40 20x32

32x55

Ø 32 mm

3232

Ø 22 mm Ø 32 mm

22 mm

32 m

12 cm

mini

14,5 cm

40 cm mini

Ø 32 mmØ 40 mm

TEL FAX

France 03 44 94 46 19

United Kingdom 08457 650011 (Call from a land line) 020 8842 1671

Ireland 1850 23 24 25 (LOW CALL) + 353 46 97 33 093

Australia +61 298 826 200 +61 298 826 950

Deutschland 0800 82 27 82 0 (060 74) 30928-90

Italia 0382 6181 +39 0382 618200

España +34 93 544 60 76 +34 93 462 18 96

Portugal +351 219 112 785 +351 219 577 000

Suisse Schweiz Svizzera

+41 44 748 17 44 +41 44 748 17 43

TEL FAX

Benelux +31 475 487100 +31 475 486515

Sverige 08-744 15 18 08-404 15 39

Norge +47 951 61 131

Polska (+4822) 732 00 33 (+4822) 751 35 16

(495) 258 29 51 (495) 258 29 51

$eská Republika +420 266 712 855 +420 266 712 856

România +40 256 245 092 +40 256 245 029

Türkiye +90 212 275 30 88 +90 212 275 90 58

+86(0)21 6218 8969 +86(0)21 6218 8970

SERVICE HELPLINES

TEL

08457 650011

all from a land line

)

1850 23 24 25

(

ALL

)

+61

298

826

200

SANIDOUCHE

SANISHOWER

SANIPUMP

D60

EN 12050-2

220-240 V - 50 Hz

250 W - 1,3 A - IP44 -

(class 1) - 3,5 KG

EN12050-2

FRANCE

SOCIÉTÉ FRANÇAISE

D’ASSAINISSEMENT

8, rue d’Aboukir - 75002 Paris

Tél. +33 1 44 82 39 00

Fax +33 1 44 82 39 01

UNITED KINGDOM

SANIFLO Ltd.,

Howard House, The Runway

South Ruislip Middx.,

HA4 6 SE

Tel. +44 208 842 0033/4040

Fax +44 208 842 1671

IRELAND

SANIRISH Ltd

IDA Industrial Estate

Edenderry - County Offaly

Tel. + 353 46 9733 102

Fax + 353 46 97 33 093

AUSTRALIA

SANIFLO AUSTRALIA

Unit 9/10, 25 Gibbes Street Pty Ltd

Chatswood NSW 2067

Tel. +61 298 826 200

Fax +61 298 826 950

DEUTSCHLAND

SFA SANIBROY GmbH

Waldstr. 23 Geb. B5 - 63128

Dietzenbach CH-8954

Tel. (060 74) 30928-0

Fax (060 74) 30928-90

ITALIA

SFA ITALIA spa

Via del Benessere, 9

27010 Siziano (PV)

Tel. 03 82 61 81

Fax 03 82 61 8200

ESPAÑA

GRUPO SFA

C/ Vinyalets,1 - P.I. Can Vinyalets

08130 Sta. - Perpètua de Mogoda -

Barcelona

Tel. +34 93 544 60 76

Fax +34 93 462 18 96

PORTUGAL

SFA, Lda.

Sintra Business Park, ed.01-1ºP

2710-089 SINTRA

Tel. +351 219 112 785

Fax +351 219 577 000

SUISSE SCHWEIZ SVIZZERA

SFA SANIBROY AG

Steinhaldenstrasse 28

Geroldwill CH-8954

Tel. +41 44 748 17 44

Fax +41 44 748 17 43

BENELUX

SFA BENELUX B.V.

Voltaweg 4

6101 XK Echt

Tel. +31 475 487100

Fax +31 475 486515

SVERIGE

SANIFLO AB

BOX 797

S-191 27 Sollentuna

Tel. +08-404 15 30

Fax + 08-404 15 39

POLSKA

SFA POLAND

ul. Kolejowa 33

05-092 £omianki/Warszawa

Tel. (+4822) 732 00 32

Fax (+4822) 751 35 16

ESKÁ REPUBLIKA

SFA-SANIBROY, spol. s r.o

Na Košince - 180 00 PRAHA 8 - Libeň

Tel . +420 266 712 855

Fax , +420 266 712 856

ROMANIA

SFA SANIFLO S.R.L.

Strada Leonard Nicolae, nr. 2A

Timişoara 300454

Tel. +40 256 245 092

Fax +40 256 245 029

TÜRKIYE

SFA SANIHYDRO LTD STI

Ortaklar Caddesi No:7 Ünal Apt. D: 2

34394 MECIDIYEKÖY - ISTANBUL

Tel . +90 212 275 30 88

Fax , +90 212 275 90 58

CHINA

KOREA

www.SFA.biz

sales@sanio-korea.kr

Service information : www.sfa.biz

2,5

10 20 30 40 50 60L/min

max10m

max20m

max 30m

max 40m

1DESCRIPTION

This lifting station is (manufactured in a

factory which is quality) certiﬁed to ISO

9001. Installed and used correctly, the unit

will give consistent and reliable service.

This device is not designed for

persons (including child-

ren) with limited physical, sensory

or mental abilities, or those with

minimal experience and knowledge,

unless they are monitored and are

given the necessary instructions for

using the device, with the help of a

person responsible for their safety.

Monitor children and make sure they

do not play with the device.

2APPLICATIONS

This device is a compact lifting sta-

tion designed to evacuate waste water

from private dwellings (except for water

coming from WC's).

SANIVITE

, SANISPEED

and SANIPUMP

are designed to handle the waste eva-

cuation from a bath domestic kitchen sink,

dishwasher and washing machine - all

working at the same time if required. Its

powerful pump will deal with every day nor-

mal usage. SANISHOWER® FLAT/ SANI-

DOUCHE® FLAT is designed to handle the

waste from a shower only.

Sanispeed will take the above at a heavier

duty rate of usage.

SANISHOWER®/SANIPUMP 1®is desig-

ned to take the waste from a shower and

handbasin.

This appliance conforms to EN 12050-3

and the European standards concerning

electrical safety and electromagnetic

compatibility.

3INSTALLATION

The unit should be installed in the same

space as the connected facilities and

should be accessible for possible service.

The ﬁtting and working of your appliance

must meet local regulations and the EN

12056-4 standard.

To optimise the latest technical deve-

lopments concerning soundprooﬁng

incorporated into this unit, it is impor-

tant to:

slXTHEDISCHARGEPIPECORRECTLYWITH

distances of not more than one metre

between the fastenings.

CONNECTION TO THE ELECTRICAL

SUPPLY

The electrical installation

should be carried out by a quali-

ﬁed person.

The unit should be connected to a fully

earthed electrical supply. All wiring must

CONFORM TO "3  REQUIREMENTS

for electrical installations. The unit requires

a 220/240V single phase AC 50 Hz supply

(UK speciﬁcation). Do not connect the unit to

a conventional plug and socket. It must be

wired into a fused, unswitched, ﬁxed

wiring connector ﬁtted with a 5 amp

fuse. The wires in the mains lead are colou-

red in accordance with the following code:

"ROWN,IVE

"LUE.EUTRAL

'REEN9ELLOWn%ARTH

Warning: Ensure the electricity is

turned OFF at the main switch board

before wiring to connector.

All work on cable, pressure chamber

and motor should only be carried out

4COMMISSIONINGTHE

UNIT

Once electrical and plumbing connections

have been made, check that all seals, and

connections are watertight.

Check both the discharge pipework from

the unit and the other sanitary appliances

connections.

5MAINTENANCE

WARNING !!!

If away for a long period, we recommend

that you turn off the water supply to the

WC served by the unit.

CARE OF YOUR UNIT

In order to remove scale and clean the

lifting station, use a household descalent

(like SANIFLO Cleanser/descalent).

6FAULT FINDING / REMEDIES

SYMPTOMS PROBABLE CAUSES REMEDIES

s4HEMOTORDOESNOTACTIVATE s4HEELECTRICALPOWERSUPPLY

ISNOTACTIVE

s4HEELECTRICALPOWERSUPPLYIS

DEFECTIVE

s4HEMOTORORTHECONTROLSYSTEM

ISDEFECTIVE

s2ESTORETHEELECTRICALSUPPLY

s#HECKTHEELECTRICALPOWER

supply

s/THERWISEASKANAPPROVED

repair agent to intervene

s4HEMOTORINTERMITTENTLY

activates

s4HECONNECTEDSANITARYDEVICES

ARELEAKING

s4HENONRETURNVALVEISFAULTY

s#HECKTHEINSTALLATIONUPSTREAM

s#LEANORREPLACETHENONRETURN

valve

s4HEMOTOROPERATESNORMALLYBUT

continues to run for a long time

s4HELENGTHORHEIGHTOFTHE

INSTALLATIONISOVERTHE

SPECIlCATIONORTHEREARETOO

MANYBENDSELBOWS

s4HELIFTINGSTATIONCOVERPLATEIS

OCCLUDED

s#HECKTHEINSTALLATION

s/THERWISEASKANAPPROVED

repair agent to intervene

s4HEUNITSTOPS s4HEUNITHASBEENRUNNINGFOR

TOOLONGTHERMALCUTOUT

s7AITFORRESETTHENASKAN

approved repair agent to

intervene

s#LOUDYWATERCOMESUPINTO

the shower basin (units with

side inlets)

s3HOWERINSTALLEDTOOLOWAS

COMPAREDWITHTHELIFTINGSTATION

s(INGEDSIDEINLETDISCS

CLOGGEDUP

s#HECKTHEINSTALLATION

s#LEANTHEHINGEDDISCS

s/THERWISEASKANAPPROVED

repair agent to intervene

IN ALL CASES, YOU MUST DISCONNECT

THE MACERATOR FROM THE POWER SUPPLY

7GUARANTEE

2 years guarantee as from its date of purchase subject to correct installation and correct use.

Warning : Do not dispose of solvents, paints (do not wash paint brushes in sink), caustic,

acid or other chemicals into these products.

by a qualiﬁed Saniﬂo servicing agent,

as special tools are required.
