SGS WDN2000 User manual

FOR YOUR SAFETY
PLEASE READ THESE INSTRUCTIONS CAREFULLY
AND RETAIN THEM FOR FUTURE USE.
OWNER’S MANUAL
WDN2000 & WDN4000
WHEEL DOLLIES

PAGE 3
PAGE 2
SPECIFICATION
WARNING
Read and understand instructions before use.
Always wear eye/face and hand protection.
WARNING! Ensure Health & Safety, local authority, and
general workshop practice regulations are adhered to
when using this equipment.
WARNING
• Familiarise yourself with this product’s application and limitations, as
well as the specific warnings below relating to their use.
• Ensure the Wheel Dollies are in sound condition and good working or-
der. take action for immediate repair or replacement of damaged parts.
• Use genuine parts only. The use of improper parts may be dangerous
and will invalidate the warranty.
• Wheel Dollies should only be used in suitable, well lit areas.
• Wheel Dollies must be used in pairs at either the front or rear of the
vehicle. They must never be used diagonally.
• Keep general area clean and tidy and free from obstructions.
• Use Wheel Dollies on level and solid ground, preferably concrete. Do
not attempt use on rough or uneven ground.
• Maintain the Wheel Dollies in good condition.
• Wnsure there are no passengers in the vehicle.
TOOL MODEL WDN2000 / WDN4000
LIFTING CAPACITY PER SKATE 450 KG
MAXIMUM TYPE WIDTH 360 MM
WEIGHT 18 KG
WWW.SGS-ENGINEERING.COM

PAGE 5
PAGE 4
WARNING
• Ensure there are no passengers in the vehicle.
• Ensure the Wheel Dollies are free to move and that there are no ob-
structions in the area of use.
• When not in use store Wheel Dolies in a safe, dry, childproof area.
• DO NOT start or drive the vehicle whilst it is raised on wheel dollies.
• DO NOT allow untrained persons to operate the Wheel Dollies.
• DO NOT leave the vehicle unattended whilst it is raised on the Wheel
Dollies.
• DO NOT operate the Wheel Dollies when you are tired or under the
influence of alcohol, drugs or intoxicating medication.
• DO NOT get the Wheel Dollies wet or use in damp or wet locations or
areas where there is condensation.
• DO NOT exceed the rated capacity of the Wheel Dollies. remember
that the front of a vehicle is usually heavier than the rear.
• DO NOT use the Wheel Dollies to support a vehicle in order to work
underneath it.
• Maintain correct balance and footing when moving vehicle. ensure the
floor is not slippery and wear non-slip shoes. Ensure all non-essential
persons keep a safe distance whilst the Wheel Dollies are in use.
• IMPORTANT - We recommend that at least 2 persons are involved in
manoeuvring the vehicle when supported on wheel dollies. the vehi-
cle’s weight provides a large amount of inertia which has to be over-
come to get the vehicle moving and more importantly, stopped.
• WARNING! The warnings, cautions and instructions covered in this
manual cannot cover all possible conditions and situations that may oc-
cur. It must be understood that common sense and caution are factors
which cannot be built into this product, but must be applied by the
operator
PARTS
No Description Qty Part No
1 Pan 2 901959
2 Swivel Caster 8 903545
3 Spring Washer 12mm 32 900376
4 Cap Nut 12mm 32 903350
WWW.SGS-ENGINEERING.COM

EC Declaration of Conformity
This is an important document and should be retained
MANUFACTURER’S NAME:
TYPE OF EQUIPMENT:
PART NUMBER:
I, the undersigned, hereby declare that the equipment specied above
conforms to the above European Communities Directive(s) and
Standard(s).
PLACE:
DATE: (Signature)
Robert Wyatt
Company Secretary
Derby, UK
24th MAY 2018
SGS Engineering (UK) Ltd
SGS Engineering (UK) Ltd
West Side Park
Raynesway
Derby, DE21 7AZ
WHEEL DOLLIES
WDN2000
2006/42/EC Machinery Directive
EN 1494:20000+A1:2008
APPLICATION OF EC COUNCIL DIRECTIVES / STANDARD:
