SGS EC1000 User manual

FOR YOUR SAFETY
PLEASE READ THESE INSTRUCTIONS CAREFULLY
AND RETAIN THEM FOR FUTURE USE.
OWNER’S MANUAL
EC1000
ENGINE CRANE
1 TONNE MAX CAPACITY

SPECIFICATION
Lifting capacity position 1 1000kg
Lifting capacity position 2 750kg
Lifting capacity position 3 500kg
Lifting capacity position 4 250kg
Maximum lifting height min. jib ext. 2020mm
Maximum lifting height max. jib ext. 2248mm
Length of jib position 1 902mm
Length of jib position 2 990mm
Length of jib position 3 1080mm
Length of jib position 4 1168mm
Height of frame 159mm
Length of frame 1251mm
Overall height 1400mm
Width of frame max 952mm
Distance between centre of rear wheels 597mm
WARNING
Do not overload. Overloading could cause damage or failure of the crane. Never exceed
the safe working loads indicated on the jib.
Never use the crane on an uneven floor surface as this could result in the crane tipping
over.
Always lock the legs and jib in position before lifting a load.
The nuts and bolts supplied with the crane are all high strength and should not be sub-
stituted for inferior types. Before each use ensure that all nuts and bolts are correctly
fitted and tight.
WWW.SGS-ENGINEERING.COM PAGE 2

OPERATING INSTRUCTIONS
WARNING: This double pump long ram is designed for lifting purposes only – not for
supporting loads. Do not load beyond its rated capacity.
IMPORTANT: It is possible that air has got into the hydraulic system causing poor
lifting performance. Purge any air from the system by fully opening the release valve
(turn handle counter-clockwise) then while holding the boom down operate the pump
handle rapidly several times.
TO RAISE LOAD: Close release valve by turning handle clockwise to a snug-tight posi-
tion. Do not over-tighten.
TO LOWER LOAD: Open release valve by turning handle counter-clockwise very
slowly. The speed of the lowering is controlled by how much the handle is turned.
NOTE: Before raising the legs to the storage position bolt (No. 6) and nut (No. 7) must
be inserted into the base support and tightened. If this procedure is not followed the
unit may fall over.
MAINTENANCE
IMPORTANT: When adding or replacing oil always use high grade hydraulic jack oil.
Avoid mixing different grades/types of oil. Do not use brake fluid, alcohol, glycerine,
detergent motor oil or dirty oil. Improper fluid can cause serious internal damage to
the ram.
When adding oil be very careful not to permit dirt or foreign matter to enter the sys-
tem. Check ram and plunger every 3 months for any signs of rust or corrosion. Clean
as needed and wipe with an oily cloth.
When not using the ram always leave the jib in the fully lowered position.
PAGE 3

ASSEMBLY
Note: during the assembly procedure nuts and bolts should be hand-tightened only.
Once assembly is complete nuts and bolts may be fully tightened.
1. Attach the castor wheels (No. 27) to the base using the nuts and bolts supplied.
2. Referring to the spare parts drawing, insert the left hand leg (No. 2) into the base
(No. 1) and lock the left leg in place using two locking pins (No. 4). Secure these
in place using two split-type pins. Now repeat this procedure for the right hand
leg.
3. Attach the main support post (No. 8) to the base assembly (No. 1) using five bolts
(No. 9) and five washers (No. 10).
4. Now secure the boom (No. 11) to the main support post (No. 8) using bolt (No.
12) washer (No. 13) and nut (No. 14).
5. Next the ram unit (No. 15) should be attached to the main support post (No.
8) using bolt (No. 16), nut and washer (No. 17). Then secure the ram unit to the
boom using bolt (No. 18), nut and washer (No. 17).
6. Insert the boom extension (No. 22) into the main boom (No. 11), secure in one of
the four positions using bolt (No. 9), nut and washer (No. 9 & 10).
7. Attach the hook and chain assembly (No. 24) to the boom using nut, bolt and
washer (No. 23 & 10).
8. Secure the handle (No. 19) to the main support post (No. 8) using four bolts (No.
21) and four washers (No. 20).
9. Now tighten all nuts and bolts.
WWW.SGS-ENGINEERING.COM PAGE 4

ITEM DESCRIPTION QTY
1 BASE 1
2 LEFT LEG 1
3 RIGHT LEG 1
4 LOCK PIN 4
5 SPLIT PIN 4
6 BOLT M6X30 1
7 NUT M6 1
8 MAIN SUPPORT POST 1
9 BOLT M14X90 6
10 NUT & WASHER M14 6
11 BOOM 1
12 BOLT M16X110 1
13 WASHER M16 1
14 NUT M16 1
ITEM DESCRIPTION QTY
15 RAM UNIT 1
16 BOLT M16X90 1
17 NUT & WASHER M16 3
18 BOLT M16X60 3
19 HANDLE 1
20 WASHER 8 12
21 BOLT M8X20 12
22 BOOM EXTENSION 1
23 BOLT M14X75 1
24 NUT & WASHER M14 1
25 JACK HANDLE 1
26 CHAIN & HOOK 1
27 CASTOR & FIXING 2
28 NUT M8 8
PAGE 5

TROUBLE SHOOTING
TROUBLE PROBABLE CAUSE REMEDY
Will not hold load. Dirt on valve seats. 1. Lower lifting boom. Close
the release valve and re-
move oil filler plug.
2. Place one foot on the leg
and pull up the lifting boom
to its full height by hand.
3. Open the release valve to
lower the lifting boom.
4. Replace worn seals.
Will not lift load.
Will not lift to its full
height.
Pump feels unsteady
under load. Pump will not
lower completely.
Air block. 1. Open the release valve and
remove oil filler plug.
2. Pump handle a couple of
full strokes and close the
release valve.
Pump will not lift to its
full height. Pump feels
unsteady under load.
The reservoir could be
overfilled. Low hydraulic
oil level.
Check the oil level. Remove the
filler plug.
Top up oil to correct level.
Pump feels unsteady
under load.
The cup seal could be
worn out.
Replace cup seal.
Will not lower completely. Air block. Unit requires
lubrication.
Release air from the hydraulic
pump by removing filler plug.
Oil external moving parts.
WWW.SGS-ENGINEERING.COM PAGE 6

EC Declaration of Conformity
This is an important document and should be retained
MANUFACTURER’S NAME:
TYPE OF EQUIPMENT:
PART NUMBER:
I, the undersigned, hereby declare that the equipment specied above
conforms to the above European Communities Directive(s) and
Standard(s).
PLACE:
DATE: (Signature)
Robert Wyatt
Company Secretary
Derby, UK
24th JUNE 2017
SGS Engineering (UK) Ltd
SGS Engineering (UK) Ltd
West Side Park
Raynesway
Derby, DE21 7AZ
Engine Crane
EC1000
2006/42/EC Machinery Directive
EN1494:2000 + A1:2008 Mobile or movable jacks and as
sociated lifting equipment
BS EN 14238: 2004
BS EN 12644 part 1: 2001
BS EN 12644 part 2: 2000
APPLICATION OF EC COUNCIL DIRECTIVES / STANDARD:
