SharkNinja Operating Shark Rotator Powered Lift-Away ZU630 Series User manual

Rotator®
Powered Lift-Away®
Upright Vacuum with
Self-Cleaning Brushroll
Rotator®
Powered Lift-Away®
ASPIRATEUR VERTICAL
L’aspirateur avec Brosse
Rotative Autonettoyante
Rotator®
Powered Lift-Away®
Aspiradora vertical con
cepillo giratorio de
auto-limpieza
ZU630 Series\Série ZU60\ZU630 Serie
OWNER’S GUIDE
GUIDE DE L’UTILISATEUR
GUÍA DEL USUARIO

sharkclean.com sharkclean.com
GENERAL WARNINGS
When using an electrical appliance,
basic precautions should always be
followed, including the following:
1. Your vacuum cleaner may consist of
a motorized nozzle, wand, hose, and/
or vacuum pod. This device contains
electrical connections, electrical
wiring, and moving parts that
potentially present risk to the user.
2. Use only identical replacement parts.
3.
Carefully observe and follow the
instructions provided below to avoid
improper use of the appliance. DO NOT
use the vacuum for any purpose other
than those described in this manual.
4. Before use, carefully inspect all parts
for any damage. DO NOT use if any
parts are damaged.
5. The use of an extension cord is
NOT recommended.
6. This vacuum cleaner contains no
serviceable parts.
USE WARNINGS
7. This appliance can be used by
persons with reduced physical,
sensory or mental capabilities or
lack of experience and knowledge
if they have been given supervision
or instruction concerning use of
the appliance in a safe way and
understand the hazards involved.
Cleaning and user maintenance shall
not be made by children.
a) Keep the appliance and its cord
out of reach of children. DO NOT
allow the appliance to be used by
children. DO NOT allow to be used
as a toy. Close supervision is
necessary when used near children.
8. Always turn off the vacuum cleaner
before connecting or disconnecting
any motorized nozzles or other
accessories.
9. DO NOT handle plug or vacuum
cleaner with wet hands.
10. DO NOT use without filters in place.
11. Only use Shark® branded filters
and accessories. Failure to do so
will also void the warranty.
12. DO NOT damage the power cord:
a) DO NOT pull or carry vacuum
cleaner by the cord or use the
cord as a handle.
b) DO NOT unplug by pulling on
cord. Grasp the plug, not the cord.
c) DO NOT run the vacuum cleaner
over the power cord, close a door
on the cord, pull the cord around
sharp corners, or leave the cord
near heated surfaces.
13. DO NOT put any objects into nozzle
or accessory openings. DO NOT use
with any opening blocked; keep free
of dust, lint, hair, and anything that
may reduce airflow.
14. DO NOT use if nozzle or accessory
airflow is restricted. If the air paths or
the motorized floor nozzle become
blocked, turn the vacuum cleaner
off and unplug from electrical outlet.
Remove all obstructions before you
plug in and turn on the unit again.
15. Keep nozzle and all vacuum
openings away from hair, face,
fingers, uncovered feet, or loose
clothing.
WARNING
To reduce the risk of fire, electric shock, injury, or property damage:
IMPORTANT SAFETY INSTRUCTIONS
FOR HOUSEHOLD USE ONLY • PLEASE READ CAREFULLY BEFORE USE
If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit,
contact a qualified electrician. DO NOT force into outlet or try to modify to fit.
To reduce the risk of electric shock, this appliance has a polarized plug (one blade
is wider than the other). This plug will fit in a polarized outlet only one way. If the
plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a
qualified electrician to install the proper outlet. Do not change the plug in any way.
SAVE THESE INSTRUCTIONS
16. DO NOT use if vacuum cleaner is
not working as it should, or has been
dropped, damaged, left outdoors, or
dropped into water.
17. Use extra care when cleaning
on stairs.
18. DO NOT leave the vacuum cleaner
unattended while plugged in.
19. When powered on, keep the vacuum
cleaner moving over the carpet surface
at all times to avoid damaging the
carpet fibers.
20. DO NOT place vacuum cleaner
on unstable surfaces such as chairs
or tables.
21. Your Shark® vacuum may not be
designed to stand up on its own. When
taking a break from cleaning, you may
need to lean it against furniture or a
wall, or lay it flat on the floor. Using
the vacuum for an application where
the unit lacks stability may result in
personal injury.
22. DO NOT use to pick up:
a) Liquids
b) Large objects
c) Hard or sharp objects
(glass, nails, screws, or coins)
d) Large quantities of dust (drywall
dust, fireplace ash, or embers).
DO NOT use as an attachment to
power tools for dust collection.
e) Smoking or burning objects
(hot coals, cigarette butts,
or matches)
f) Flammable or combustible
materials (lighter fluid, gasoline,
or kerosene)
g) Toxic materials (chlorine bleach,
ammonia, or drain cleaner)
23. DO NOT use in the following areas:
a) Poorly lit areas
b) Wet or damp surfaces
c) Outdoor areas
d) Spaces that are enclosed and may
contain explosive or toxic fumes
or vapors (lighter fluid, gasoline,
kerosene, paint, paint thinners,
mothproofing substances, or
flammable dust)
24. Turn off all controls before plugging in
or unplugging the vacuum.
25. Unplug from electrical outlet
when not in use and before
any maintenance or cleaning.
26. Hand wash with water only.
Washing with cleaning chemicals
could damage the unit.
27. During cleaning or routine
maintenance, DO NOT cut anything
other than hair, fibers, or string
wrapped around the brushroll.
28. Allow all filters to air-dry completely
before replacing in the vacuum to
prevent liquid from being drawn
into electric parts.
29. Make sure the dust cup and all filters
are in place after routine maintenance.
30. If provided, secure the power
cord around the two cord hooks
during storage.

sharkclean.com sharkclean.com
1. Insert Wand into Floor Nozzle.
2. Insert Handle into wand.
3. Place Pod onto wand and slide down to connect.
4. Connect Hose into back of pod, until it clicks into place.
For proper operation, ensure all parts are firmly clicked into place.
ASSEMBLY ASSEMBLY
2
(Clic)
3
(Clic)
4
(Clic)
1
(Clic)

NOTE: For deep cleaning per ASTM F 608 (embedded dirt
in carpets) please set to Carpet/Low Pile.
sharkclean.com sharkclean.com
WHAT DOES THE BRUSHROLL INDICATOR
LIGHT MEAN?
Solid Green: The brushroll is spinning and
working as it should.
Solid Red: There is a jam in the brushroll
area. Turn your vacuum o and remove
any blockages.
Flashing Red*: The motorized floor nozzle is
overheating. Turn your vacuum o and wait
45 minutes for it to cool down.
*See Troubleshooting section for further
instructions.
WHOLE-HOME CLEANING WHOLE-HOME CLEANING
SETTINGS
BRUSHROLL INDICATOR LIGHT
INDICATOR LIGHT
CLEANING MODES
To engage brushroll, turn power on, select a
surface setting, then step on floor nozzle and
tilt handle back.
UPRIGHT LIFT-AWAY®
ABOVE-FLOOR ABOVE-FLOOR—EXTENDED REACH
Wand
Release
Press the Handle Release Button to detach
the handle to clean above-floor areas. Insert
accessories directly into handle.
L
i
f
t
A
w
a
y
®
Press the Power button to turn the
vacuum on or o.
Slide the selector switch to the
appropriate surface setting:
For thick carpets and area rugs:
Set switch to Thick Carpet/Area Rug.
For cleaning low-pile carpets:
Set switch to Carpet/Low Pile to
increase the speed of the brushroll to
remove stuck-on dust and debris.
For bare floors or above-floor areas:
Set switch to Hard Floor.
Press the Wand Release Button to detach
the wand to clean with more reach. Insert
accessories directly into wand.
Press Lift-Away Button to lift pod o
motorized floor nozzle. You are now ready to
clean those hard-to-reach places.

sharkclean.com sharkclean.com
AVAILABLE ACCESSORIES
A
G
H
D
C
B
A8"Crevice Tool
This slim tool is great for cleaning in tight
spaces, between couch cushions, and in
hard-to-reach areas.
BUpholstery Tool
Perfect for large-particle pickup, dusting,
and removing stubborn pet hair and lint from
furniture and other upholstered surfaces.
CDusting Brush
This brush dusts and cleans delicate
surfaces. Great for use on fans, blinds,
lampshades, and keyboards.
DDuster Crevice Tool
Two cleaning tools in one: the crevice tool
gives you extended reach to clean in tight
spaces, while the soft brush lets you dust
delicate surfaces.
EPet Multi-Tool
A single convertible tool for cleaning tough
pet messes two ways: use the sti bristle
brush to clean stuck-on debris, or take o
the bristles to reveal an upholstery tool
perfect for removing stubborn pet hair and
large piles of debris.
FSelf-Cleaning Pet Power Brush
Picks up pet hair and loose debris.
Powerfully deep-cleans dander out of
upholstery and other surfaces.
GDust-Away® Hard Floor Attachment
Durable enough for cleaning big crumbs
and debris but gentle enough for delicate
dusting on hardwood and tile floors.
HCanister Caddy
Transforms your Rotator®into a canister
vacuum, giving you the freedom to roll the
pod along while keeping cleaning tools
close by.
NOTE: Not all accessories come with all units. Please see the enclosed Quick Start Guide for your unit's
configuration. To order additional accessories, visit sharkaccessories.com.
EMPTYING THE DUST CUP
IMPORTANT: Unplug the power cord before performing any maintenance.
Hold dust cup over a trash bin and press the
empty-release latch on the bottom to empty
dust and debris into trash.
E F
Pull up on Dust Cup Release Latch on the handle
and lift dust cup o pod.
Press Top Empty Release Latch to access
dust screen and remove built-up debris as
necessary.
