Sharp AR-6020V User manual

SERVICE MANUAL
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these parts with
specified ones for maintaining the safety and performance of the set.
SHARP CORPORATION This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
NOTE FOR SERVICING
[1] PRODUCT OUTLINE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
[2] SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
[3] CONSUMABLE PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
[4] EXTERNAL VIEW AND INTERNAL STRUCTURE . . . . . . . . . . . . . . . . . . . . . . . . 4-1
[5] ADJUSTMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
[6] SIMULATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
[7] TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1
[8] FIRMWARE UPDATE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
[9] MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-1
[10] DISASSEMBLY AND ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-1
[11] OPERATIONAL DESCRIPTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-1
[12] ELECTRICAL SECTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-1
[13] SERVICE WEB PAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-1
[14] TOOL LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-1
CONTENTS
CODE: 00ZAR6020VS2E
AR-6020V/6020V E
AR-6023V
AR-6020DV/6020DV E
AR-6023DV/6023DV E
AR-6020NV/6020NV E/6120NV
AR-6023NV/6023NV E
AR-6026NV/6026NV E
AR-6031NV/6031NV E/6131NV
MODEL
DIGITAL MULTIFUNCTIONAL
SYSTEM

CONTENTS
NOTE FOR SERVICING
1. Precautions for servicing . . . . . . . . . . . . . . . . . . . . . . . . . i
2. Warning for servicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . i
3. Note for installing site. . . . . . . . . . . . . . . . . . . . . . . . . . . . i
4. Note for handling PWB and electronic parts . . . . . . . . . .ii
5. Note for repairing/replacing the LSU . . . . . . . . . . . . . . . .ii
6. Note for handling the drum unit, the transfer unit,
the developing unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .ii
[1] PRODUCT OUTLINE
1. System diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
2. Option list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
3. Identification seal correspondence . . . . . . . . . . . . . . . 1-2
[2] SPECIFICATIONS
1. Basic specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2. Copy functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
3. Printer function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
4. Image send function. . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
5. Power Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
6. Power consumption . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
7. Dimensions and Weight . . . . . . . . . . . . . . . . . . . . . . . 2-11
8. Machine Occupied Area. . . . . . . . . . . . . . . . . . . . . . . 2-11
9. Ambient conditions. . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
[3] CONSUMABLE PARTS
1. Supply system table/Maintenance parts list. . . . . . . . . 3-1
2. Maintenance parts list . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
3. Environmental conditions. . . . . . . . . . . . . . . . . . . . . . . 3-2
4. Production number identification . . . . . . . . . . . . . . . . . 3-3
[4] EXTERNAL VIEW AND INTERNAL STRUCTURE
1. External view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
2. Internal view. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
3. Operation panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
4. Motor, solenoid, clutch . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
5. Sensor, switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
6. PWB. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
7. Cross sectional view . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
[5] ADJUSTMENTS
1. General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
2. Adjustment item list . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
3. Details of adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
[6] SIMULATION
1. General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
2. List of simulation . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-2
3. Details of simulation . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
[7] TROUBLESHOOTING
1. Error code list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1
2. Details of error codes and countermeasures . . . . . . . . 7-2
[8] FIRMWARE UPDATE
1. Preparation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
2. Install USB Driver procedure . . . . . . . . . . . . . . . . . . . . 8-1
3. Download Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3
4. Receive the ROM version . . . . . . . . . . . . . . . . . . . . . . 8-4
[9] MAINTENANCE
1. Necessary work for maintenance. . . . . . . . . . . . . . . . . 9-1
2. Maintenance timing display . . . . . . . . . . . . . . . . . . . . . 9-2
3. Maintenance list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-3
4. Maintenance display system . . . . . . . . . . . . . . . . . . . . 9-6
5. Note for replacement of consumable parts . . . . . . . . . 9-6
[10] DISASSEMBLY AND ASSEMBLY
1. Disassembly and Assembly table . . . . . . . . . . . . . . .10-1
2. Disassembly and assembly of each unit . . . . . . . . . . 10-2
[11] OPERATIONAL DESCRIPTIONS
1. Operation panel section . . . . . . . . . . . . . . . . . . . . . . . 11-1
2. RSPF section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-2
3. Scanner section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-6
4. Manual paper feed section. . . . . . . . . . . . . . . . . . . . . 11-8
5. Paper registration section . . . . . . . . . . . . . . . . . . . . . 11-9
6. Paper feed tray section . . . . . . . . . . . . . . . . . . . . . . 11-10
7. Paper exit section. . . . . . . . . . . . . . . . . . . . . . . . . . . 11-12
8. Duplex section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-13
9. OPC drum section . . . . . . . . . . . . . . . . . . . . . . . . . . 11-14
10. Toner supply section . . . . . . . . . . . . . . . . . . . . . . . . 11-16
11. Developing section. . . . . . . . . . . . . . . . . . . . . . . . . . 11-17
12. Transfer section . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-19
13. Fusing section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-21
14. Fan and filter section . . . . . . . . . . . . . . . . . . . . . . . . 11-25
[12] ELECTRICAL SECTION
1. Block diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-1
2. Power line diagram . . . . . . . . . . . . . . . . . . . . . . . . . . 12-3
3. Actual wiring chart . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-6
4. Signal list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-13
[13] SERVICE WEB PAGE
1. General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-1
2. Details and operation procedures . . . . . . . . . . . . . . . 13-1
[14] TOOL LIST
1. TOOL LIST. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-1

AR-6020V NOTE FOR SERVICING - i
AR-6020V Service Manual
NOTE FOR SERVICING
1. Precautions for servicing
1) When servicing, disconnect the power plug, the printer cable,
the network cable, and the telephone line from the machine,
except when performing the communication test, etc.
It may cause an injury or an electric shock.
2) There is a high temperature area inside the machine. Use
extreme care when servicing.
It may cause a burn.
3) There is a high voltage section inside the machine which may
cause an electric shock. Be careful when servicing.
4) Do not disassemble the laser unit. Do not insert a reflective
material such as a screwdriver in the laser beam path.
It may damage eyes by reflection of laser beams.
5) When servicing with the machine operating, be careful not to
place your hands by belts, gears, chains, and other drive com-
ponents.
6) Do not leave the machine with the cabinet disassembled.
Do not allow any person other than a serviceman to touch
inside the machine. It may cause an electric shock, a burn, or
an injury.
7) When servicing, do not breathe toner, developer, and ink
excessively. Do not get them in the eyes.
If toner, developer, or ink enters you eyes, wash it away with
water immediately, and consult a doctor if necessary.
8) The machine has got sharp edges inside. Be careful not to
damage fingers when servicing.
9) Do not throw toner or a toner cartridge in a fire. Otherwise,
toner may explode and burn you.
10) When replacing the lithium battery on the PWB, use only the
specified battery.
If a battery of different specification is used, the battery may
cause malfunction or breakdown of the machine.
11) When transporting a PWB, be sure to place the PWB in an
anti-static bag.
It may cause a breakdown or malfunctions.
2. Warning for servicing
1) Be sure to connect the power cord only to a power outlet that
meets the specified voltage and current requirements.
Avoid complex wiring, which may lead to a fire or an electric
shock.
2) If there is any abnormality such as a smoke or an abnormal
smell, interrupt the job and disconnect the power plug.
It may cause a fire or an electric shock.
3) Be sure to connect the grounding wire. If an electric leakage
occurs without grounding, a fire or an electric shock may result.
For proper machine functionality, the machine must be
grounded.
4) When connecting the grounding wire, never connect it to the fol-
lowing points.
It may cause an explosion, a fire or an electric shock.
- Gas tube
- Lightning conductor
- A water pipe or a water faucet, which is not recognized as a
grounding object by the authorities.
- Grounding wire for telephone line
5) Do not damage, break, or twist the power cord.
Do not put heavy objects on the power cable. Do not forcefully
bend or pull the power cable.
It may cause a fire or an electric shock.
6) Keep the power cable away from a heat source.
Do not insert the power plug with dust on it into a power outlet.
It may cause a fire or an electric shock.
7) Do not put a metallic object or a container with water in it inside
the machine.
It may cause a fire or an electric shock.
8) With wet or oily hands, do not touch the power plug, do not per-
form servicing, touch the power plug, insert a telephone jack, or
operate the machine with wet or oily hands.
It may cause an electric shock.
3. Note for installing site
Do not install the machine at the following sites.
1) Place of high temperature, high humidity, low temperature,
low humidity, place under an extreme change in tempera-
ture and humidity.
Paper may get damp and form moisture inside the machine,
causing paper jam or copy dirt.
For operating condition, refer to the specifications described
later.
2) Place with a lot of vibration
It may cause a breakdown.
3) Poorly ventilated place
An electro-static type copier will produce ozone inside it.
The quantity of ozone produced is designed to a low level so as
not to affect human bodies. However, continuous use of such a
machine may produce an odor of ozone. Install the machine in a
well ventilated place.
4) Place with direct sunlight.
Plastic parts and toner may be deformed, discolored, or may
undergo qualitative change.
It may cause a breakdown or copy quality issues.
5) Place which is full of organic gases such as ammonium
The organic photoconductor (OPC) drum used in the machine
may undergo qualitative change due to organic gases such as
ammonium.
Installation of this machine near a diazo-type copier may result
in copy quality issues.
6) Place with excessive dust
When dusts enter the machine, it may cause a breakdown or
copy quality issues.
7) Place near a wall
Some machines require intake and exhaust of air.
If intake and exhaust of air are not properly performed, copy dirt
or a breakdown may be a result.
8) Unstable or slant surface
If the machine drops or falls down, it may cause an injury or a
breakdown.
If there are optional paper desks and the copier desks specified,
it is recommendable to use them.
When using the optional desk, be sure to fix the adjuster and
lock the casters.
CAUTION
DOUBLE POLE/NEUTRAL FUSING
ATTENTION.
Double pôle/fusible sur le neutre

AR-6020V NOTE FOR SERVICING - ii
4. Note for handling PWB and electronic
parts
When handling the PWB and the electronic parts, be sure to
observe the following precautions in order to prevent against dam-
age by static electricity.
1) When in transit or storing, put the parts in an anti-static bag or
an anti-static case and do not touch them with bare hands.
2) When and after removing the parts from an anti-static bag
(case), use an earth band as shown below:
- Put an earth band to your arm, and connect it to the
machine.
- When repairing or replacing an electronic part, perform the
procedure on an anti-static mat.
5. Note for repairing/replacing the LSU
When replacing, be sure to observe the following items.
1) When replacing the LSU, be sure to disconnect the power plug
from the power outlet.
2) When replacing the LSU, follow the procedures described in
this Service Manual.
3) When checking the operations after repairing the LSU, keep all
the parts including the cover installed and perform the opera-
tion check.
4) Do not modify the LSU.
5) When visually checking the inside of the machine for the oper-
ation check, be careful not to allow laser beams to enter the
eyes.
If the above precaution is neglected or an undesignated work
is performed, safety may not be assured.
6. Note for handling the OPC drum unit, the
transfer unit, and the developer unit
When handling the OPC drum unit, the transfer unit, and the devel-
oper unit, strictly observe the following items.
If these items are neglected, a trouble may be generated in the
copy and print image quality.
(OPC drum)
1) Avoid working at a place with strong lights.
2) Do not expose the OPC drum to lights including interior lights
for a long time.
3) When the OPC drum is removed from the machine, cover it
with light blocking material. (When using paper, use about 10
sheets of paper to cover it.)
4) Be careful not to attach fingerprints, oil, grease, or other for-
eign material on the OPC drum surface.
(Transfer unit)
5) Be careful not to attach fingerprints, oil, grease, or other for-
eign material on the transfer roller.
(Developer unit)
1) Be careful not to attach fingerprints, oil, grease, or other for-
eign material on the developer unit.

AR-6020V PRODUCT OUTLINE 1-1
[1] PRODUCT OUTLINE
1. System diagram
A. 20/23 cpm machine
B. 26/31 cpm machine
MX-CS12 N
AR-RP11 N
AR-6020V/6020V E/6023V AR-6020DV/6020DV E
AR-6023DV/6023DV E
AR-6020NV/6020NV E
AR-6023NV/6023NV E
MX-VR12
AR-NB7 N
MX-EB21
AR-PB10
PRINTER
EXPANSION KIT
MX-USX5
SHARPDESK 5 LICENSE
KIT
MX-PK10
PS3 EXPANSION
KIT
MX-US10
SHARPDESK 10 LICENSE
KIT
MX-US50
SHARPDESK 50 LICENSE
KIT
MX-USA0
SHARPDESK 100 LICENSE
KIT
MX-CS13 N
MX-CS12 N
AR-DS19
AR-DS20
MX-USX1
SHARPDESK 1 LICENSE
KIT
AR-6120NV
AR-RP11 N
AR-6026NV/6026NV E
AR-6031NV/6031NV E
MX-VR12
AR-NB7 N
MX-EB21
AR-PB10
PRINTER
EXPANSION KIT
MX-USX5
SHARPDESK 5 LICENSE
KIT
MX-PK10
PS3 EXPANSION
KIT
MX-US10
SHARPDESK 10 LICENSE
KIT
MX-US50
SHARPDESK 50 LICENSE
KIT
MX-USA0
SHARPDESK 100 LICENSE
KIT
MX-CS13 N
MX-CS12 N
AR-DS19
AR-DS20
MX-USX1
SHARPDESK 1 LICENSE
KIT
AR-6131NV

AR-6020V PRODUCT OUTLINE 1-2
2. Option List
STD: Standard O : Option installation enable X : Option installation disable
*1 The AR-PB10 is required for PCL (SPLC only.)
*2 S/D Model: AR-NB7 N; N model: AR-PB10 is necessary.
3. Identification seal correspondence
S Model D Model N Model
Model/Option AR-6020V/
6020V E/
6023V
AR-6020DV/
6020DV E/
6023DV/
6023DV E
AR-6020NV/
6020NV E/
6023NV/
6023NV E
AR-6026NV/
6026NV E/
6031NV/
6031NV E
AR-6131NV AR-6120NV Note
Document
Feed System
AR-RP11 N Reversing single pass feeder (RSPF) O O O O STD STD
MX-VR12 Document cover STD O O O - -
Paper Feed
System
MX-CS12 N 500-sheet paper feed unit O O O O O O without motor
MX-CS13 N 500-sheet paper feed unit O O O O O O with motor
Stand AR-DS19 Stand (Large) O O O O O O
AR-DS20 Stand (Small) O O O O O O
Printer
Expansion
AR-NB7 N NETWORK EXPANSION KIT O O STD *1 STD *1 STD *1 STD *1
AR-PB10 PRINTER EXPANSION KIT
XX OOOO
MX-EB21 EXPANSION MEMORY BOARD O O O O O O
MX-PK10 *2 PS EXPANSION KIT O O O O O O
Application /
Solution
MX-USX1 SHARPDESK 1 LICENSE kit O O O O O O
MX-USX5 SHARPDESK 5 LICENSE kit O O O O O O
MX-US10 SHARPDESK 10 LICENSE kit O O O O O O
MX-US50 SHARPDESK 50 LICENSE kit O O O O O O
MX-USA0 SHARPDESK 100 LICENSE kit O O O O O O
MX-CS12N MX-CS13N MX-RP11N MX-EB21 AR-NB7N

AR-6020V SPECIFICATIONS 2 – 1
AR-6020V Service Manual
[2] SPECIFICATIONS
1.Basic specifications
A.Engine Composition
B.Engine speed (ppm)
(1)Tray 1, 2
(2) Bypass tray
C.Printable area
* When making original size/one-sided copies, the first sheet from
the bypass tray has no back end void setting.
D.First Copy Time
First copy time from the paper feeding unit
E.Engine resolution
F. Scanner section
(1)Resolution/Gradation
(2)Document table
Photoconductor OPC Drum (φ30mm)
Recording method Electronic Photo (Laser)
Developing method Dry-type Dual component Magnetic Brush
Development
Charging method Charged Saw-Tooth Method
Transfer method Transfer roller
Separation method Separation claw
Cleaning method Contact blade method
Fusing method Heat roller
Toner supply method Open the front cover and insert the cartridge
Toner supply while working Unavailable
Appearance Pastel white
Paper size (short
edge feed) 20cpm 23cpm 26cpm 31cpm
A4/ 8.5"x11" 20ppm 23ppm 26ppm 31ppm
A4R 14ppm 15ppm 18ppm 23ppm
8.5"x11"R 15ppm 16ppm 18ppm 23ppm
A5/ 5.5"x8.5"R 20ppm 23ppm 26ppm 31ppm
B5/ 16K 20ppm 23ppm 26ppm 31ppm
B5R 16ppm 18ppm 18ppm 23ppm
16KR 15ppm 16ppm 18ppm 23ppm
8.5x13" 12ppm 13ppm 16ppm 20ppm
B4/ 8.5"x14 12ppm 13ppm 16ppm 20ppm
A3 11ppm 12ppm 15ppm 17ppm
11"x17" 10ppm 11ppm 15ppm 17ppm
8K 11ppm 12ppm 15ppm 17ppm
Paper size (short
edge feed) 20cpm 23cpm 26cpm 31cpm
A4 16ppm 18ppm 24ppm 29ppm
8.5"x11" 16ppm 18ppm 24ppm 29ppm
A4R/ 8.5"x11"R 10ppm 11ppm 19ppm 25ppm
A5 16ppm 18ppm 25ppm 29ppm
5.5"x8.5" 16ppm 18ppm 25ppm 29ppm
A5R/ 5.5"x8.5"R 16cpm 18cpm 25ppm 29ppm
B5 16cpm 18cpm 24ppm 29ppm
16K 16cpm 18cpm 24ppm 29ppm
B5R/ 16KR 10ppm 11ppm 19ppm 25ppm
8.5x13" 10ppm 11ppm 16ppm 21ppm
B4 10ppm 11ppm 16ppm 21ppm
8.5"x14 10ppm 11ppm 16ppm 20ppm
A3 10ppm 11ppm 15ppm 18ppm
11"x17" 10ppm 11ppm 15ppm 18ppm
8K 10ppm 11ppm 15ppm 17ppm
A3 293x413mm
B4 253x357mm
A4 206x290mm
B5 178x250mm
A5 144x203mm
A5R 203x144mm
8K 266x383mm
16K 191x263mm
11x17 275x425mm
8.5x14 212x349mm
8.5x13.5 212x336mm
8.5x13.4 212x333mm
8.5x13 212x323mm
8.5x11 212x272mm
5.5x8.5 136x209mm
5.5x8.5R 209x136mm
Executive 180x260mm
Void area Front end: 1 to 4mm, Back end: 1 to 5mm, Both sides:
Max. 6mm
Image loss Front end: 4mm or less, Back end: 1 to 5mm, Right/Left :
Total 6mm or less
Loss width Front end/Back end: 4mm or less , Right/Left : Total
6mm or less
20cpm 23cpm 26cpm 31cpm
Platen
A4: 6.4
seconds
LT: 6.5
seconds
A4: 6.4
seconds
LT: 6.5
seconds
5.2seconds 5.2 seconds
20cpm 23cpm 26cpm 31cpm
Platen 12.5 seconds 12.5 seconds 10.9 seconds 10.9 seconds
Resolution
Copy <Writing>
600 x 600dpi
Print <Writing>
600 x 600dpi
Tone
Copy <Writing>
600 x 600dpi x 1bit
Print
<Writing>
SPLC : 600 x 600dpi x 1bit
PCL : 600 x 600dpi x 1bit
PS : 600 x 600dpi x 1bit
Scan Resolution for
Copying (dpi)
Monochrome
Document Glass 400x600dpi
RSPF 400x600dpi
Transmission Resolu-
tion (dpi) Refer to Image Send Function.
Exposure Lamp White LED
Scan Levels 256 levels
Output Levels
Monochrome : 1bit
Gray scale : 8bit
Full Color : RGB each color 8bit
Form Fixed original glass (Flatbed)
Scan Range 297x431mm
Standard Location of Original Rear Left
Original size detection No
Heater (scanner section) No
A3 293x413mm
B4 253x357mm
A4 206x290mm

AR-6020V SPECIFICATIONS 2 – 2
G.Document feeder
Standard sheet type
Type RSPF
Scan Speed Monochrome(A4/
8.5x11) Color(A4/8.5x11)
Copy
(400x600dpi)
20/23cpm :
Single:23sides/minute;
Duplex:11 sides/minute;
26/31cpm :
Single:23sides/minute;
No
Fax No No
Scan 1.27 msec/Line(Color), 0.423 msec/
Line(Gray scale/BW)
Original setup direction Upward standard (1toN feeding standard)
Original setup position Center alignment
Original Transport method Sheet-through method
Original feeding order From upper sheet
Original size Standard type
Original weight
<Single side>
Plain paper: 50-128g/m2, 13-32 lb.bond
<Double side>
Plain paper: 50-105g/m2, 13-28 lb.bond
Original Stack Capacity Max. 100 sheets (80g/m2, 21 lbs Bond) ,
or Max. height: 1/2 inch, 13mm or less
Not transportable original
type
The following documents are NOT
allowed;
OHP, second original drawing, tracing
paper, carbon paper, thermal paper,
wrinkled/broken/torn document, docu-
ment with cuts and pastes,
documents printed by an ink ribbon, and
perforated document except
2-punched/3-punched (Perforated docu-
ment by punch unit is allowed.).
Original size detection Yes
Original size to be detected Auto detection
Original feeding direction Right hand feeding
Original size Guide (Center) A3/A4, 11, B4/B5, 8-1/2, A4R/A5,
B5R, 5-1/2
Multi copy S-S, S-D (Only Duplex model) , D-D (Only
Duplex model) D-S
Stamp No
Type *2
11x17
8.5x14
8.5x13.5
216x343)
8.5x13.4
216x340)
8.5x13
216x330)
8.5x11
8.5x11R
5.5x8.5
5.5x8.5R*1
A3 B4 A4
A4R
B5
B5R
A5
A5R*1
8K
16K
16KR
Inch-1 Yes Yes No No No Yes Yes Yes N o Ye s No Ye s No No No No N o No No No
Inch-2 Yes No N o No Yes Ye s Yes Yes No Yes No Yes No No No No No No No No
Inch-3 Yes No N o Yes No Yes Yes Ye s No Ye s No Ye s No N o No No No No No No
AB-1 Yes Yes No No No Yes No No No Yes Yes Yes Yes Yes Yes Yes No No No No
AB- 2 Yes No N o No Yes Yes N o No No Yes Yes Yes Yes Ye s Yes Yes No No No No
AB- 3 Yes No N o No Yes Yes N o No No Yes Yes Yes Yes No No Ye s N o Yes Ye s Yes
AB- 4 Yes No N o Yes No Yes No No No Ye s Yes Yes Yes Yes Yes Yes No N o No N o
AB-5 Yes No Yes No No Yes No No No Yes Yes Yes Yes Yes Yes Yes No No No No

AR-6020V SPECIFICATIONS 2 – 3
H.Paper feed section
(1)Basic specifications
(2)Other paper type capacities
(3)Size of paper which can be fed
20/23 cpm 26/31 cpm
Form Standard: 250-sheet tray x1 + Multi Bypass(100)
Max.: 250-sheet tray x1 + 500-sheet tray x3 + Multi Bypass(100)
Standard: 500-sheet tray x 2 + Multi Bypass (100)
Max: 500-sheet tray x 4 + Multi Bypass (100)
Paper loading method To be loaded from the upper side with front loading system To be loaded from the upper side with front loading system
Heater None. None.
Item Tray Multi bypass
20/23 cpm 26/31 cpm 20/23/26/31 cpm
Paper Capacity Standard paper (80g/m2) 250 sheets 500 sheets x2 100 sheets
Paper size detection No
Paper Type setting Yes
Paper Size change User setting
Default paper size setting AB systems: A4 Inch systems: 8.5x11 --
Paper balance detection Paper empty only
Cassette handle grabbing from both direction Yes --
Paper Size Indication Window Depending on Paper Size sheet --
Paper Type Paper Tray Bypass Tray
Plain paper 20/23 cpm : 250 sheets (80g/m2)
26/31 cpm : 500 sheets (80g/m2)
100 sheets (55-80g/m2)
(For multi paper feed, 55-128g/m2)
Envelope -- AB system: 10 envelopes
Inch system: 5 envelopes
Others -- Single paper feed (transparency, label)
Paper Feeding Section
Main unit Optional tray
Tray (250 sheets) Tray (500 sheets) 1 Paper Feed Tray
(500 sheets) Multi Bypass
Paper Size
11x17 Yes Yes Yes Yes
8.5x14 216x356mm Yes Yes Yes Yes
8.5x13.5 216x343mm Yes Yes Yes Yes
8.5x13.4 216x340 mm Yes Yes Yes Yes
8.5x13 216x330 mm Yes Yes Yes Yes
8.5x11 Yes Yes Yes Yes
8.5x11R Yes Yes Yes Yes
7.25x10.5 *3 No No No Yes
7.25x10.5R *3 No No No Yes
5.5x8.5 No No No Yes
5.5x8.5R Yes Yes Yes Yes
A3 Yes Yes Yes Yes
B4 Yes Yes Yes Yes
A4 Yes Yes Yes Yes
A4R Yes Yes Yes Yes
B5 Yes Yes Yes Yes
B5R Yes Yes Yes Yes
A5 No No No Yes
A5R Yes Yes Yes Yes
B6R No No No Yes
A6R No No No Yes
8K Yes Yes Yes Yes
16K Yes Yes Yes Yes
16KR Yes Yes Yes Yes
Envelope*1 No No No
Yes
(Single feed is
available)
Custom No No No Yes
Extra No No No Yes

AR-6020V SPECIFICATIONS 2 – 4
*1: Supporting envelope: Monarch / Com-10 / DL
*2 Recommended media: SF-4A3F
*3 It can be fed, but not display.
I.Paper exit section
(1) Duplex
(2) Exit Capacity
(3) Rotate Sort
* The output in different 90 degrees direction when using 2 papers
feed trays.
Paper Type
Thin Paper 55-59g/m2 13-16lb bond Yes Yes Yes Yes
Plain Paper 60-105g/m2 16-28lb bond Yes Yes Yes Yes
Recycled Paper Yes Yes Yes Yes
Heavy paper 106-128g/m2 28 lb bond -
32 lb bond No No No
Yes
(A4 or less)
(Multi feed is
available)
Heavy paper 129-200g/m2 32 lb bond -
110 lb Cover No No No
Yes
(A4 or less)
(Multi feed is
available)
Heavy paper 201g/m2 and above
110 lb bond and above No No No No
OHP paper No No No Yes
Label *2 No No No Yes
Tab Paper No No No No
Paper Feeding Section
Main unit Optional tray
Tray (250 sheets) Tray (500 sheets) 1 Paper Feed Tray
(500 sheets) Multi Bypass
Type 1 Pass, Switchback type
Transportable Paper (Fixed)
Size/Weight Refer to the “Usable Paper Size and Weight”.
Other Duplex print using the manual bypass is not possible.
Ejection part Center part of the main unit
Ejection method Face-down ejection
Paper capacity for ejection 250 sheets
(A4/8.5x11:80g/m3)
Ejectable paper size and weight Refer to the “Usable Paper Size and Weight”.
Shifter function No
Detection of ejected paper No
Detection of full ejected paper There is no sensor to detect.
(The paper is counted by the software)
Output Tray It is possible to use the Multi Bypass and each paper tray.
Output Paper Size A4/A4R, B5/B5R, 16K/16KR, 8.5”x11”/8.5”x11”R
Output Paper Type
Thin paper(55-59g/m2 13-16 lb bond)
Plain paper(60-105g/m2 16-28 lb bond)
Recycled paper

AR-6020V SPECIFICATIONS 2 – 5
(4) Usable Paper Size and Weight (Main Unit Output Tray, Duplex Section)
*1: Supporting Envelope Monarch/Com-10/DL
J.Operation panel
(1)Display Device
(2)Key
Output Section
Duplex Section Main Unit Output tray
(Non-Offset)
Paper Size
11x17 Yes Yes
8.5x14 216x356mm Yes Yes
8.5x13.5 216x343mm Yes Yes
8.5x13.4 216x340 mm Yes Yes
8.5x13 216x330 mm Yes Yes
8.5x11 Yes Yes
8.5x11R Yes Yes
7.25x10.5 No Yes
7.25x10.5R No Yes
5.5x8.5 No Yes
5.5x8.5R No Yes
A3 Yes Yes
B4 Yes Yes
A4 Yes Yes
A4R Yes Yes
B5 Yes Yes
B5R Yes Yes
A5 No Yes
A5R Yes Yes
B6R No Yes
A6R No Yes
8K Yes Yes
16K Yes Yes
16KR Yes Yes
Envelope*1 - Yes
Extra - Yes
Custom - -
Paper Type
Thin Paper 55-59g/m2 13-16lb bond No Yes
Plain Paper 60-105g/m2 16-28lb bond Yes Yes
Recycled Paper Yes Yes
Heavy paper 106-128g/m2 28 lb bond -32 lb bond No Yes
Heavy paper 129-200g/m2 32 lb bond -110 lb Cover No Yes
Envelope - Yes
OHP - Yes
Label - Yes
Tab Paper - -
Form LCD Display with Back Light (custom LCD)
Number of Dots in display 167 segments
Color display Monochrome
LCD Drive Display Area (WxD) 51x77mm
LCD Back Light White LED backlight method
LCD Contrast Adjust No
Angle/Position Adjustment No
Model Simplex model
(Standard model)
Duplex model
(D model) N model
Basic Input Section
Start Key O O O
Clear Key O O O
Clear All Key (“CA”) O O O
Interrupt Key O O O
10 Key O O O
Power Saving Key*1 O O O
* key O O O
# key O O O
Mode area Printer Online Key O O O
Scanner Mode Key O O O

AR-6020V SPECIFICATIONS 2 – 6
*1 According to the BA, the icon of Power Saving Key can uses the key (crescent mark) to indicate.
K.Controller board
*1 Switching to “USB Host invalid” shall be available by Sim.
L.Memory/Hard disk
M.Warm-up time
* May be different depending on the environment.
N. Security
Function Selection Key
Ratio Selection Key O O O
Zoom Key O O O
Tray Selection Key O O O
Paper Size Selection Key O O O
Original Key O O O
Paper Key O O O
Exposure Setting Key O O O
Copy Image Quality Mode Selection Key O O O
2in1/4in1 Selection Key O O O
Margin Shift Selection Key O O O
E-Sort Key O O O
Edge/Center Erase Selection Key O O O
Dual Page Copy Key O O O
Duplex Mode Switch Key O O O
One-Touch Send Key(6 keys) O O O
ID Card Copy Key O O O
LED display items
Interrupt LED O O O
Start Key LED O O O
Power Saving LED O O O
Exposure Setting LED O O O
Copy Image Quality Mode LED O O O
Print Online LED O O O
Scan Mode LED O O O
ID Copy LED O O O
Error LED O O O
Data LED O O O
Model Simplex model
(Standard model)
Duplex model
(D model) N model
Standard model / D-
model
N-model
CPU H8S/2373 (16bit 1 chip microcomputer,
24.576MHz)
Interface
IEEE1284 Parallel No
IEEE 802.1x No
Ethernet
1 port (When Network
Expansion Kit is
expanded)
1 port
Interface 10Base-T, 100Base-
TX
10Base-T, 100Base-
TX
Support
Protocol TCP/IP (IPv4) TCP/IP (IPv4)
USB 2.0(High Speed)
(Host) *1
1 port (Side face)
(When Network
Expansion Kit is
expanded)
1 port (Side face)
USB 2.0(High Speed)
(Device) 1 port
USB Authentication No
ACRE Expansion I/F No
Ir-Simple I/F No
Video I/F No
Serial I/F (for coin
vender) No
Parallel I/F (For Coin
Vendor etc,) Supported by Service boarded
Memory Refer to Memory / Hard disk
Memory Slot No
Windows Premium Logo
acquisition No
WHQL acquisition Yes
Memory of MCU
board
64MB
Hard disk : not available
Number of sheets which can be scanned
TEST CHART B : 100 sheets
TEST CHART C : 80 sheets
Memory Expansion 128MB
20/23 cpm model 26/31 cpm model
Warm up time 25 seconds or less 20 seconds or less
Preheat Yes
Jam recovery time 15 sec
Admin/Service password scheme No

AR-6020V SPECIFICATIONS 2 – 7
2. Copy functions
A. Copy Ratio
* It can’t be set when using the RSPF.
B. Exposure/Copy image quality processing
C. Copy function
Item Contents
Copy Ratio (Fixed) AB Series
Inch Series
25%*,50,70,81,86,100,115,122,141,200,400%*
25%*,50,64,77,95,100,121,129,141,200,400%*
Zoom Platen
R-SPF
25-400%(376 levels by 1%)
50-200%(151 levels by 1%)
Preset Ratio None
XY Zoom Yes (25-400% for both horizontally and vertically, However, when R-
SPF is used, 50-200%)
Item Contents
Exposure Mode Auto/Text/Photo
Resolution
Writing: 600 x 600 dpi
Scanning: 400 (main) x 600 (sub) dpi (Photo Mode), 400 (main) x
600 (sub) dpi (AE, Text Mode)
Gradation Writing : 2 values
Scanning: 256 gradations
Number of manual steps 5 steps (Text/Photo)
Toner Save Mode Yes (the setting is different depending on the area)
Item Contents
Auto Paper Selection (APS) O
Auto Magnification Selection (AMS) O
Auto Tray Switching O
Support Mixed Original X
Stream Feeding Mode O
Memory Copy (SOPM) O
Rotation Copy O
e-Sort Sort Function O *Except for Interrupt Copy
Group Function O
Rotation Sort O
Sky Shot Prevention X
XY Zoom O
Dual Page Copy OC O *Except for enlarged copy
RSPF X
Margin Shift AB series 10mm(5, 10, 15, 20mm)
Inch series 1/2 inch (1/4,1/2,3/4,1 inch)
Edge+Center Erase AB series 10mm(5, 10, 15, 20mm)
Inch series 1/2 inch (1/4,1/2,3/4,1 inch)
B/W Reverse X
2in1 / 4 in 1 O
ID Card Copy O (can enlarge, because the ID Card Copy for all destinations.)
Off-set Print X
Preheat Function O(Terms can be specified by system setting)
Auto Power Shutoff O(Terms can be specified by system setting)
System Setting O
Duplex Copy O(Only for D-model/N-model)
Toner Save Mode O(Can be specified according to area/Settings can be changed by service
simulation)
Account Control O(Only copy can be controlled. Number of control: 20)

AR-6020V SPECIFICATIONS 2 – 8
3. Printer function
A. Driver supported OS
*1 New OS is supported according to the rule of the Document Solutions Group.
B. PDL emulation/Font
* When NW Expansion Kit and PS Expansion Kit are expanded, Nova-Light has optional font because it supports PS3.
C. Support print channel
* IPP,HTTP, and POP support SSL, but the Russia not support SSL.
OS *1
USB
Twain/
Button
Manager
Network
Twain/ SPLC Custom PCL6
Custom
PCL5e Custom PS PPD
Windows
Server 2003 No No No No No No No
Server 2003x64 No No No No No No No
Server 2008 No CD-ROM No CD-ROM No CD-ROM CD-ROM
Server 2008x64 No CD-ROM No CD-ROM No CD-ROM CD-ROM
Windows7 CD-ROM CD-ROM CD-ROM CD-ROM No CD-ROM CD-ROM
Windows7x64 CD-ROM CD-ROM CD-ROM CD-ROM No CD-ROM CD-ROM
Windows8 No No No No No No No
Windows8x64 No No No No No No No
Windows8.1 CD-ROM CD-ROM CD-ROM CD-ROM No CD-ROM CD-ROM
Windows8.1 x64 CD-ROM CD-ROM CD-ROM CD-ROM No CD-ROM CD-ROM
Windows8.1 CD-ROM CD-ROM CD-ROM CD-ROM No CD-ROM CD-ROM
Windows10 CD-ROM CD-ROM CD-ROM CD-ROM No CD-ROM CD-ROM
Windows10 x64 CD-ROM CD-ROM CD-ROM CD-ROM No CD-ROM CD-ROM
Server 2012 x64 No CD-ROM No CD-ROM No CD-ROM CD-ROM
Server 2016 x64 No CD-ROM No CD-ROM No CD-ROM CD-ROM
Mac
9 No No No No No No No
X 10.2 No No No No No No No
X 10.3 No No No No No No No
X 10.4 No No No No No No No
X 10.5 No No No No No No No
X 10.6 No No No No No CD-ROM No
X 10.7 No No No No No CD-ROM No
X 10.8 No No No No No CD-ROM No
X 10.9 No No No No No CD-ROM No
X 10.10 No No No No No CD-ROM No
X 10.11 No No No No No CD-ROM No
X 10.12 No No No No No CD-ROM No
PDL(command) Overseas Resident Font Optional Font
PCL6 compatible OPT European outline font=80 font types
Line printer font (BMP)=1 font types ---
ESC/P(VP-1100) compatible,
ESC/P_super compatible --- --- ---
Postscript3 compatible OPT*1 ---
Japanese font
Heisei font = 2 fonts
- Heisei Mincho W3
- Heisei Kaku Gothic W5
Outline font=136 fonts
S/D Model N Mode Printer Expansion Kit should
be extended for N model
USB(Device) USB1.1/USB2.0(High-Speed) --- USB1.1/USB2.0(High-Speed)
USB(Host) --- --- ---
Ethernet --- 10Base-T, 100Base-TX
PSERVER/RPRINT in NetWare environments --- --- ---
LPR --- --- Print channel of UNIX LPR/
LPD command compatible
IPP --- --- Print channel compliant with
IPP1.0
PAP Ether Talk (Apple Talk) --- --- ---
FTP --- --- ---
NetBEUI --- --- ---
Raw Port(Port9100) --- --- Support TCP port of No.9100
(Raw Port)
HTTP(Web Submit Print) --- --- ---
POP3(E-Mail To Print) --- --- ---
BMLinks --- --- ---

AR-6020V SPECIFICATIONS 2 – 9
D. Direct Print
(1)File Transmission Method
(2)File Format
*1: Network expansion kit for S/D model and Print expansion kit is needed.
*2: PS expansion kit is needed.
E. Print Function
Communication Method Operation Method Support
1FTP Pull Print After access to FTP service by operation panel and select the file, the printing is performed. No
2 Push Print Send the print instruction from PC to MFP by FTP client software. Yes
3 WEB Page Push Print It can view the data on client PC by the “send a print job” on web page, and send a print
instruction to MFP. No
4 E-mail Push Print Send the attached data of E-mail to MFP by client PC, the printing is performed. It can enter
the print set instruction in the body of E-mail. No
5USB flash
drive Pull Print Connect the USB memory to MFP, and select the data in USB memory by operation panel,
the printing is performed. No
6Shared
Folder Pull Print After access to Shared Folder by operation panel and select the file, the printing is per-
formed. No
File Type Extension Support
TIFF TIFF,TIF Yes*1
JPEG FIF,JPE,JPEG,JPG Yes*1
PCL PCL,PRN,TXT Yes*1
XPS XPS No
PDF PDF Yes*2
Encrypted PDF PDF No (only NULL password*2)
PS PS,PRN Yes*2
Function Contents PCL6
compatible
PostScript3
compatible SPLC
Bar-code Font JetCAPS BarDIMM emulation No No No
Network Tandem Print
2 units of MFP is connected tandem and
writing out is performed by 2 MFP working together. Only when HDD is
installed.
Divide jobs by PC and send them to MFPs.
No No No
ROPM One RIP processing enables plural numbers of printing out. Yes Yes Yes
Multi access support RIP processing shall be available during printing. And printing shall be
available during scanning. No No No
Paper direction setting for duplex
printing of letter head paper or
punch paper. [Support printing on
logo paper (SEGA AOK Company)]
As for papers having front/back attribute such as letter head or punching
paper, Front/back side and print order shall be corrected at duplex
printing.
No No No
Driver Distribution Function
The administrator can distribute driver to each client by Sharp Remote
Device Management.
Or it can use MSI to download and install.
No No No
Form Overlay The form is downloaded to the MFP in advance and only the data
contents is sent, then fit them into the form by MFP to print. No No No
Support Planet Press Support Planet Press by Object if Lune Inc. (software which performs
mapping of form (DL in advance) and variable data inside the printer.) No No No
Add support font Support Heisei fonts No Yes No
Support Morisawa fonts No No No
Bonjour for Macintosh environment
A technology developed by Apple Corps. To detect the peripherals on
the network automatically and connect. It enables users for dynamic
network connection with computers, peripherals and software.
No Yes No
Layout print Various layouts fitted to different print usage are available. Yes No No
Perfect binding Function that performs saddle stitch print by small amount of pages to
restrain adding of thickness by plural pages binding. No No No
Support Sharp Print System Support Print in anywhere. No No No
Support WSD The Discovery function of printer Yes Yes Yes
Rotation in 90 degrees function
When print image and size is coincide and different direction of paper is
indicated as the paper feed tray, the image is rotated 90 degrees
automatically to print. (However, direction change during job is not
available.)
Yes Yes Ye s
Printing position adjustment for
odd/even pages
Printing position of odd/even pages is adjusted. (They can be adjusted
separately.)
Value can be adjusted by the unit of mm/inch
No No No

AR-6020V SPECIFICATIONS 2 – 10
4.Image Send Function
A.Overview of Image Send Function
(1)Mode
(2)Support Image (N model: Standard, S/D model: NW
Expansion Kit is installed)
(3)Image Processing (N model: Standard, S/D model:
NW Expansion Kit is expanded)
*Only can be set in the Monochrome 2 levels.
B.Push Scan (Button Manager)
C.Pull Scan (TWAIN)
Print Policy Function
It is a function that a certain items are turned ON mandatorily, in order to
restrict the operation by user level. The target operations for restriction
are as follows;
Consideration should be taken in designing, so as to respond to
additional requests.
- User authentication every time
- Forced Retention
- Forced black and white print
- Obtain the login name of Windows
- Accounting Code
No No No
Toner Save Mode Toner Save Mode (1 step) No No No
Support RET Support simulated resolution No No No
Print density adjustment Function to switch in 5 stages. Yes Yes Yes
A4/Letter
Automatic
Switching Function
Automatic switching while output, it may not out of paper. No No No
Function Contents PCL6
compatible
PostScript3
compatible SPLC
Mode Sub Mode S/D model
N model/ S/D
model
(NW Expansion
Kit is installed)
Scanner
E-mail No No
FTP Server No No
Network Folder
(SMB) No No
Desktop No No
USB Memory No Yes
Internet Fax/
Direct SMTP -NoNo
Fax - No No
USB Twain Scan
(Including Button
Manager)
-YesNo
Network Twain
Scan -NoYes
ID Card Scan - Yes (Bu tt on
Manager) No
Mode Type Support
Scanner
File Format
(B/W)
TIFF Yes
PDF Yes
PDF/A No
Encrypted PDF No
XPS No
File Format
(Gray Scale)
Color TIFF Yes
JPEG Yes
PDF Yes
PDF/A No
Encrypted PDF No
Compact PDF(ACRE
installed) No
XPS No
File Format
(Color)
Color TIFF Yes
JPEG Yes
PDF Yes
PDF/A No
Encrypted PDF No
Compact PDF(ACRE
installed) No
XPS No
Mode Scanner
Exposure adjustment Auto Yes
Manual 5 levels
Original Type*
Text Yes
Photo Yes
Auto Yes
Resolution (Different
depending on file format/
sending method)
75x75dpi Yes
100x100dpi Yes
150x150dpi Yes
200x200dpi Yes
300x300dpi Yes
400x400dpi Yes
600x600dpi Yes
Hardware
Environment
(System) Shall meet the operating conditions of each OS
basically.
(HDD) 8MB or more: 100MB or more is recommended
(Monitor) 800x600dots or more
Shall be able to display 256 colors or more.
(Other) USB port (2.0)
Selectable
destination
Sharpdesk/ E-mail software/ Fax software/ OCR soft-
ware/ MS Word/ Any directory
Item Contents
Interface USB Twain: USB
Network Twain*:NIC
Hardware
Environment
(System)Shall meet the operating conditions of each OS
basically.
(HDD) 8MB or more: 100MB or more is recommended
(Monitor) 800x600dots or more
Shall be able to display 256 colors or more.
(Other) USB Twain: USB Port
Network Twain*:Network Port
Two-sided
Scan Yes
Color Mode B/W(Mono2)/ B/W(Error Diffusion)/Gray Scale/Full Color
Resolution 75dpi/ 100dpi/ 150dpi/ 200dpi/ 300dpi/ 400dpi/ 600dpi
or Custom: 50-9600dpi (simulated)
Scanning
Range
A3/ A4/ A4-R/A5-R/ B4/ B5/ B5-R/ Ledger/ Letter/
Letter-R/ Executive/ Executive-R/ Foolscap/ Invoice/
Invoice-R/ Legal/ 8.5x13.4/ 8.5x13.5(343 x216mm)/
Postcard/ 8K/ 16K/ 16K-R/ Auto/ Custom
Preview
Function Yes
Zoom Preview
Function Yes

AR-6020V SPECIFICATIONS 2 – 11
* For N model and S/D model while the network expansion kit was
expanded.
5. Power Source
6. Power consumption
The full configuration can be operated with the rated power source.
*1: when powered on, the thermal heater is OFF.
*2: Setting Range: 1-60 minutes (Blue Angel Standard)
*3: Revised Energy Conservation, Energy StarVer.2.0, Blue Angel
Standard
Rotation Scan Yes (90 / 180/ 270 degrees)
Quick Scan No
Brightness/
Contrast
Adjustment
Auto/ Manual(-100 - +100)
Gamma
Adjustment Yes
Color
Matching None / For Printer / For CRT / For LCD / ICM
Edge
Emphasis None / Normal / Sharp / Blur
B/W Reverse Yes
Selection of
Light Source
Color
Yes(Red/ Green/ Blue/ White)
Threshold
Setting Auto/ Manual (1-254)
Addition of
Void Area
Available (Lead Edge/Trail Edge: 2.5mm Right/Left:
3.0mm)
Storing of
Setting
Contents
Yes
Keeping of
Preview Image Ye s
Unit of Display
for Scanning
Range
Pixel/ mm/ inch
Notes’
Security
Feature
No
Overseas 100V Overseas 200V
Voltage 100-127V 12A
20/23 cpm : 220-
240V 5A
26/31 com : 220-
240V 8A
Frequency 50/60Hz 50/60Hz
Power code | Sharp model Fixed Type (Direct) Inlet or direct
Power Switch 1 switch
Overseas
100V
Overseas
200V
Max. power consumption *1
20/23 cpm :
1.2kW or
less
26/31 cpm :
1.44kW or
less
20/23 cpm
: 1.2kW or
less
26/31 cpm :
1.45kW or
less
Power Consumption when Network/Fax
standby: 1W or less
The condition of Network standby: Limited to
connection of the TCP/IP protocol.
No No
Time to go into preheat mode.*2 1min (Default)
Time to come back from preheat mode. 15sec
Time to go into sleep mode.
15 min (Default)
After printing out, shut off
immediately (Default 1sec)
Time to come back from sleep mode. *3 25sec
Item Contents

AR-6020V SPECIFICATIONS 2 – 12
7. Dimensions and Weight
* Include OPC Drum. Not include Toner/Developer.
8. Machine Occupied Area
9. Ambient conditions
Under the following environmental conditions, the print quality is
guaranteed.
1 Tray model (Floor to OC) 599(W) x 612(D) x 511(H) mm
1 Tray model (Floor to RSPF) 599(W) x 612(D) x 643(H) mm
4 Trays model (Floor to OC) 599(W) x 612(D) x 940(H)mm
Only main unit (with handle) 599(W) x 612(D) x 1012(H)mm
Main unit (with multi bypass tray
expanded) 599(W)x 612(D) mm
Dimensions occupied by the machine 909(W)x 612(D) mm
Weight *
Main unit (Standard model) 27.9kg(with OC)
33.5kg(with RSPF)
Main unit (Duplex model (D
model))
28.2kg(with OC)
33.8kg(with RSPF)
Main unit (Network sup-
ported duplex print model
(20/23 cpm N-model))
28.4kg(with OC)
34.0kg(with RSPF)
Network supported duplex
print 1 tray model (26/
31cpm N-model)
30.9 kg(with OC)
36.5 kg(with RSPF)
Network supported duplex
print 2 tray model (26/
31cpm N-model)
36.8 kg(with OC)
42.4 kg(with RSPF)
Standard model/D model/N model
Only main unit (with handle) 599(W)×612 (D)
Main unit (with multi bypass tray
expanded) 909(W)×612(D)
Standard environmental
conditions
Temperature 20 - 25 degrees C
Humidity 65 +/- 5 %RH
Usage environmental
conditions
Temperature 10 - 35 degrees C
Humidity 20 - 85 %RH
Atmospheric
pressure
590 - 1013 hPa
(height: 0 - 2000m)
Supply transportation
environmental conditions
(Term : 2 weeks)
- 20 - 45 degrees C (no condensation)
Supply storage
environmental conditions
(unopened)
- 10 - 40 degrees C (no condensation)
85%
60%
20%
10°C 30°C 35°C
Humidity (RH)
Temperature

AR-6020V CONSUMABLE PARTS 3-1
[3] CONSUMABLE PARTS
1.Supply system table
A. South and Central America
B. Europe
*1 Only for Eastern Europe
C. Australia, New Zealand
D. Asia
E. Middle East, Africa
No. Name Product name Content Life Remark
1Toner cartridge(Black) MX-237NT Toner cartridge x1 20K Life setting by A4 6% document
2Developer MX-312NV Developer x1 20cpm/23cpm : 75K
26cpm/31cpm : 100K
3Drum MX-312NR Drum x1 20cpm/23cpm : 75K
26cpm/31cpm : 100K
No. Name Product name Content Life Remark
1Toner cartridge(Black) MX-237GT Toner cartridge x1 20K Life setting by A4 6% document
2Toner cartridge(Black) MX-238GT*1 Toner cartridge x1 8.4K Life setting by A4 6% document
3Developer MX-312GV Developer x1 20cpm/23cpm : 75K
26cpm/31cpm : 100K
4Drum MX-312GR Drum x1 20cpm/23cpm : 75K
26cpm/31cpm : 100K
No. Name Product name Content Life Remark
1Toner cartridge(Black) MX-237GT Toner cartridge x1 23K Life setting by A4 6% document
and Toner save mode
2Toner cartridge(Black) MX-238GT Toner cartridge x1 10K Life setting by A4 6% document
and Toner save mode
3Developer MX-312GV Developer x1 20cpm/23cpm : 75K
26cpm/31cpm : 100K
4Drum MX-312GR Drum x1 20cpm/23cpm : 75K
26cpm/31cpm : 100K
No. Name Product name Content Life Remark
1Toner cartridge(Black) MX-237AT Toner cartridge x1 23K Life setting by A4 6% document
and Toner save mode
2Toner cartridge(Black) MX-238AT Toner cartridge x1 10K Life setting by A4 6% document
and Toner save mode
3Developer MX-312AV Developer x1 20cpm/23cpm : 75K
26cpm/31cpm : 100K
4Drum MX-312AR Drum x1 20cpm/23cpm : 75K
26cpm/31cpm : 100K
No. Name Product name Content Life Remark
1Toner cartridge(Black) MX-237FT Toner cartridge x1 23K Life setting by A4 6% document
and Toner save mode
2Toner cartridge(Black) MX-238FT Toner cartridge x1 10K Life setting by A4 6% document
and Toner save mode
3Developer MX-312FV Developer x1 20cpm/23cpm : 75K
26cpm/31cpm : 100K
4Drum MX-312FR Drum x1 20cpm/23cpm : 75K
26cpm/31cpm : 100K

AR-6020V CONSUMABLE PARTS 3-2
F. Iran
2.Maintenance parts list
A. AR-6020V/6020V E/6023V/6020DV/6020DV E/6023DV/6023DV E/6020NV/6020NV E/6120NV/6023NV/6023NV E
B. AR-6026N/6026NR/6031N/6031NR/6131N/X311N
* The other maintenance parts than the above are supplied as service parts.
3. Environmental conditions
A.Use conditions
B.Life(packed conditions)
Photoconductor drum (36 months from the production month)
Developer, toner (24 months from the production month)
No. Name Product name Content Life Remark
1Toner cartridge(Black) MX-237XT Toner cartridge x1 23K Life setting by A4 6% document
and Toner save mode
2Toner cartridge(Black) MX-238XT Toner cartridge x1 10K Life setting by A4 6% document
and Toner save mode
3Developer MX-312FV Developer x1 20cpm/23cpm : 75K
26cpm/31cpm : 100K
4Drum MX-312FR Drum x1 20cpm/23cpm : 75K
26cpm/31cpm : 100K
No. Name Product name Content Life Remark
1Heat roller MX-312UH Upper heat roller x1 150K
2Toner filter MX-312TF Toner filter x1 75K
No. Item Content Life Model name Remarks
1 Upper heat roller kit Upper heat roller x 1 150K MX-313UH
Fuser gear x 1
Upper heat roller bearing x 2
Upper cleaning pad x 1
Fusing separation pawl (upper) x 4
2 Lower heat roller kit Lower heat roller x 1 300K MX-312LH
Fusing separation pawl (lower) x 1
Fuser bearing (lower) x 2
3 Maintenance kit Drum separation pawl unit x 2 100K MX-312KA
Cleaner blade x 1
MC unit x 1
4 Drum frame unit Drum frame unit x 1 300K MX-312DU The life of the toner reception seat
attached to the drum frame is
300K, and it can be used up to 3
times.
(Supplied as a drum frame unit.)
5 Transfer roller unit Transfer roller unit x 1 150K MX-312TX
6 Paper feed roller kit Paper feed roller kit x 1 100K MX-312RT
7 Paper feed roller kit Paper feed roller kit x 1 100K MX-312MR
8 Fusing unit Fusing unit (120V heater lamp) x 1 150K MX-312FU1
9 Fusing unit Fusing unit (200V heater lamp) x 1 150K MX-312FU
10 Toner filter unit Toner filter unit x 1 100K MX-312TF
(UMIDITY
4EMPERATURE
5SEENVI
RONMENT
CONDITIONS
Standard environmental
conditions
Temperature 20 - 25 degrees C
Humidity 65 +/- 5%RH
Usage environmental
conditions
Temperature 10 - 35 degrees C
Humidity 20 - 85%RH
