Sharp CD-XP205V User manual

CD-XP205V
No. S7256CDXP205V
CONTENTS Page
SAFETY PRECAUTION FOR SERVICE MANUAL ........................................................................................................... 2
VOLTAGE SELECTION..................................................................................................................................................... 2
AC POWER SUPPLY CORD AND AC PLUG ADAPTOR ................................................................................................. 2
SPECIFICATIONS ............................................................................................................................................................. 3
NAMES OF PARTS ........................................................................................................................................................... 4
DISASSEMBLY.................................................................................................................................................................. 6
REMOVING AND REINSTALLING THE MAIN PARTS..................................................................................................... 9
ADJUSTMENT ................................................................................................................................................................. 10
BLOCK DIAGRAM ........................................................................................................................................................... 15
SCHEMATIC DIAGRAM / WIRING SIDE OF P.W.BOARD............................................................................................. 18
NOTES ON SCHEMATIC DIAGRAM .............................................................................................................................. 39
TYPES OF TRANSISTOR AND LED............................................................................................................................... 39
VOLTAGE ........................................................................................................................................................................ 40
WAVEFORMS OF CD CIRCUIT...................................................................................................................................... 41
TROUBLESHOOTING ..................................................................................................................................................... 42
FUNCTION TABLE OF IC................................................................................................................................................ 46
FL DISPLAY..................................................................................................................................................................... 56
REPLACEMENT PARTS LIST/EXPLODED VIEW
SERVICE MANUAL
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
SHARP CORPORATION
• In the interests of user-safety the set should be restored to its
original condition and only parts identical to those specified be
used.
VIDEO CD MINI SYSTEM
MODEL CD-XP205V
CD-XP205V Video CD Mini System consisting of CD-XP205V
(main unit) and CP-XP205 (speaker system).
NTSC/PAL
All manuals and user guides at all-guides.com
all-guides.com

CD-XP205V
– 2 –
SAFETY PRECAUTION FOR SERVICE MANUAL
WARNINGS
THE AEL (ACCESSIBLE EMISSION LEVEL) OF THE LASER POWER OUTPUT IS LESS THAN CLASS 1 BUT THE LASER
COMPONENT IS CAPABLE OF EMITTING RADIATION EXCEEDING THE LIMIT FOR CLASS 1. THEREFORE IT IS
IMPORTANTTHATTHEFOLLOWINGPRECAUTIONSAREOBSERVEDDURINGSERVICINGTOPROTECTYOUREYES
AGAINST EXPOSURE TO THE LASER BEAM.
1-WHENTHECABINETISREMOVED,THEPOWERISTURNEDONWITHOUTACOMPACTDISCINPOSITIONANDTHE
PICKUP IS ON THE OUTER EDGE THE LASER WILL LIGHT FOR SEVERAL SECONDS TO DETECT A DISC. DO NOT
LOOK INTO THE PICKUP LENS.
2-THE LASER POWER OUTPUT OF THE PICKUP UNIT AND REPLACEMENT SERVICE PARTS ARE ALL FACTORY
PRESET BEFORE SHIPMENT.
DO NOT ATTEMPT TO READJUST THE LASER PICKUP UNIT DURING REPLACEMENT OR SERVICING.
3-UNDER NO CIRCUMSTANCES STARE INTO THE PICKUP LENS AT ANY TIME.
4-CAUTION-USE OF CONTROLS OR ADJUSTMENTS, OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
Before operating the unit on mains, check the preset voltage. If the voltage is different from your local voltage, adjust the voltage
as follows.
Turn theselector with ascrewdriver until theappropriate voltage numberappears inthewindow (110 V,127 V, 220V or 230V - 240 V AC).
VOLTAGE SELECTION
AC POWER SUPPLY CORD AND AC PLUG ADAPTOR
QACCE0012AW00
Laser Diode Properties
Material: GaAIAs
Wavelength: 780 nm
Emission Duration: continuous
Laser Output: max. 0.6 mW
QACCA0003AW00
QPLGA0004AWZZ
QPLGA0003AWZZ
All manuals and user guides at all-guides.com

– 3 –
CD-XP205V
General
Amplifier
Video CD
CD player
Tuner
Cassette deck
Power source AC 110/127/220/230 - 240 V, 50/60 Hz
Power consumption 133 W
Dimensions Width: 270 mm (10-5/8")
Height: 330 mm (13")
Depth: 355 mm (13-15/16")
Weight 7.5 kg (16.5 lbs.)
Output power MPO: 240 W (120 W + 120 W) (10 % T.H.D.)
RMS: 150 W (75 W + 75 W) (10 % T.H.D.)
RMS: 104 W (52 W + 52 W) (0.9 % T.H.D.)
Output terminals Speakers: 6 ohms
Headphones: 16 - 50 ohms (recommended: 32 ohms)
Video out: 1 Vp-p (75 ohms)
Input terminals Video/Auxiliary (audio signal): 500 mV/47 k ohms
Microphone: 1 mV/600 ohms
Video output format PAL/NTSC
Type 3-disc multi-play compact disc player
Signal readout Non-contact, 3-beam semiconductor laser pickup
D/A converter 1-bit D/A converter
Frequency response 20 - 20,000 Hz
Dynamic range 90 dB (1 kHz)
Frequency range FM: 88 - 108 MHz
AM: 531 - 1,602 kHz
Frequency response 50 - 14,000 Hz (Normal tape)
Signal/noise ratio 55 dB (TAPE 1, playback)
50 dB (TAPE 2, recording/playback)
Wow and flutter 0.3 % (WRMS)
Type 2-way type speaker system
5 cm (2") Tweeter
13 cm (5-1/8") Woofer
Maximum input power 150 W
Rated input power 75 W
Impedance 6 ohms
Dimensions Width: 220 mm (8-11/16")
Height: 330 mm (13")
Depth: 222 mm (8-6/8")
Weight 3.0 kg (6.6 lbs.)/each
SPECIFICATIONS
CD-XP205V
Specifications for this model are subject to change without
prior notice.
FOR A COMPLETE DESCRIPTION OF THE OPERATION OF THIS UNIT, PLEASE REFER
TO THE OPERATION MANUAL.
CP-XP205
All manuals and user guides at all-guides.com

CD-XP205V
– 4 –
NAMES OF PARTS
CD-XP205V
Front panel
1. Disc Tray
2. Timer Set Indicator
3. On/Stand-by Button
4. Tuner (Band) Button
5. Video CD/CD/MP3 Disc Button
6. Headphone Socket
7. Microphone Level Control
8. Microphone Socket
9. Tape (1 2) Button
10. Video/Auxiliary Button
11. Video CD Playback Control Button
12. Video CD On Screen Display On/Off Button
13. Video CD Digest/Time Search Button
14. Equaliser Mode Select/Extra Bass/Demo Mode Button
15. Disc Tray Open/Close Button
16. Disc Skip Button
17. Volume Up and Down Buttons
18. Tape 1 Cassette Compartment
19. Tape 2 Cassette Compartment
20. Video CD Skip or Previous,
CD/MP3 Disc Track Down or Fast Reverse,
Tape 2 Fast Wind, Tuner Preset Down Button
21. Video CD Skip or Next,
CD/MP3 Disc Track Up or Fast Forward,
Tape 2 Fast Wind, Tuner Preset Up Button
22. Clock Button
23. Timer/Sleep Button
24. Tape 2 Reverse Mode Select Button
25. Tape 2 Reverse Play Button
26. Video CD Play or Repeat or Select or Resume,
CD/MP3 Disc Play or Repeat, Tape 1 Play,
Tape 2 Forward Play Button
27. Video CD Stop or Return,
CD/MP3 Disc/Tape Stop Button
28. Tuning and Time Down Button
29. Memory/Set Button
30. Tape 2 Record Pause Button
31. Tuning and Time Up Button
3
2
1
4
9
10
11
12
13
14
15
16
17
19
5
6
7
818
20
26 2728 313029
2221 23
2524
Display
1. Disc Pause Indicator
2. Extra Bass Indicator
3. MP3 Disc Indicator
4. Disc Number Indicators
5. Tape 2 Record Indicator
6. FM Stereo Mode Indicator
7. FM Stereo Receiving Indicator
8. Timer Play Indicator
9. Sleep Indicator
10. Timer Recording Indicator
11. Disc Play Indicator
12. Disc Repeat Play Indicator
13. Karaoke Mode Indicator
14. Tape Reverse Mode Indicator
15. Tape 2 Reverse Play Indicator
16. Tape 1 Play or Tape 2 Forward Play Indicator
17. Memor
y
Indicator
2678103451 9
13
14
15 16 17
11
12
All manuals and user guides at all-guides.com

– 5 –
CD-XP205V
Rear panel
1. Cooling Fan
2. AC Voltage Selector
3. AC Power Lead
4. Transport Screw
5. FM 75 Ohms Aerial Terminal
6. FM Aerial Earth Terminal
7. AM Loop Aerial Socket
8. Span Selector Switch
9. Video/Auxiliary (Audio Signal) Input Sockets
10. Video Output Socket
11. Speaker Terminals
Note:
This product is equipped with a cooling fan inside, which begins to run at a specified
volume level for better heat radiation.
1. Tweeter
2. Woofer
3. Bass Reflex Duct
4. Speaker Wire
5
6
7
8
1
3
29
10
11
4
1
334
2
Remote control
1. Remote Control Transmitter
2. Disc Number Select Buttons
3. Echo Level Up and Down Buttons
4. Karaoke Mode Button
5. Video CD Auto/On Button
6. Video CD Playback Control Auto/Off Button
7. Video CD On Screen Display On/Off Button
8. Video CD Digest/Time Search Button
9. Video CD Bookmark Button
10. Tape 2 Record Pause Button
11. PAL/NTSC Select Button
12. Video CD/CD/MP3 Disc Button
13. Tuner (Band) Button
14. Tape (1 2) Button
15. Video/Auxiliary Button
16. On/Stand-by Button
17. MP3 Disc Display Button
18. Disc Direct Search Buttons
19. Extra Bass Button
20. Equaliser Mode Select Button
21. Volume Up and Down Buttons
22. Disc Memory Button
23. Disc Clear Button
24. Video CD Skip or Previous,
CD/MP3 Disc Track Down or Fast Reverse,
Tape 2 Fast Wind, Tuner Preset Down Button
25. Tape 2 Reverse Play Button
26. Video CD Stop or Return,
CD/MP3 Disc/Tape Stop Button
27. Disc Random Button
28. Video CD Skip or Next,
CD/MP3 Disc Track Up or Fast Forward,
Tape 2 Fast Wind, Tuner Preset Up Button
29. Disc Pause Button
30. Video CD Play or Repeat or Select or Resume,
CD/MP3 Disc Play or Repeat, Tape 1 Play,
Tape 2 Forward Play Button
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
21
20
19
18
17
16
22
25
23
24
26
27
28
29
30
Buttons with " " mark in the illustration can be operated on the remote control
only.
CD-XP205V
CP-XP205
All manuals and user guides at all-guides.com

CD-XP205V
– 6 –
1 Top Cabinet 1. Screw ...................... (A1) x4 6-1
2 Side Panel 1. Screw ...................... (B1) x8 6-1
(Left/Right)
3 CD Tray Cover/ 1. Turn on the power supply,.. 6-2
CD Player Unit open the disc tray, take out
the CD tray cover, and close.
(Note 1)
2. Screw ...................... (C1) x1
3. Hook........................ (C2) x3
4. Hook........................ (C3) x2
5. Socket ..................... (C4) x4
4 Rear Panel with 1. Screw .................... (D1) x12 6-2
Fan Motor 2. Socket ..................... (D2) x1
5 Main PWB 1. Screw ...................... (E1) x4 6-2, 7-1
2. Socket ..................... (E2) x4 7-1
3. Flat Cable ............... (E3) x1
4. Flat Wire.................. (E4) x1
6 Front Panel 1. Screw .......................(F1) x2 7-1
2. Hook.........................(F2) x2
3. Socket ......................(F3) x1
7 Mic PWB 1. Screw ...................... (G1) x2 7-1
2. Tip Wire................... (G2) x1
8 Display PWB 1. Screw .................... (H1) x12 7-2
2. Flat Cable ............... (H2) x1
9 Tape Mechanism 1. Open the cassette holder. 7-2
2. Screw...................... (J1) x5
10 Headphones PWB 1. Screw ...................... (K1) x1 7-2
11 Turntable 1. Hook.........................(L1) x2 7-3
2. Cover .......................(L2) x1
12 Loading Tray 1. Turn fully the lock lever in the 6-3
arrow direction .
2. Push the loading tray backward 7-4
to engage the claw with the
groove and remove it in the
direction of the arrow .. (M1) x6
13 Video CD PWB 1. Screw ...................... (N1) x2 7-5
(Note 2) 2. Hook........................ (N2) x1
3. Socket ..................... (N3) x4
14 CD Mechanism 1. Hook........................ (P1) x2 7-6
2. Hook........................ (P2) x2
DISASSEMBLY
Caution on Disassembly
Follow the below-mentioned notes when disassembling
the unit and reassembling it, to keep it safe and ensure
excellent performance:
1. Take cassette tape and compact disc out of the unit.
2. Be sure to remove the power supply plug from the wall
outlet before starting to disassemble the unit.
3.Takeoff nylon bandsorwire holders wheretheyneed to
beremovedwhendisassemblingtheunit.Afterservicing
theunit,be sure torearrangetheleads where theywere
before disassembling.
4. Take sufficient care on static electricity of integrated
circuits and other circuits when servicing.
Figure 6-2
STEP REMOVAL PROCEDURE FIGURE
Figure 6-1
Note 1: How to open the changer manually. (Fig. 6-3)
1. In this state, turn fully the lock lever in the arrow direction through
the hole on the loading tray bottom.
2. After that, push forward the loading tray.
Note 2:
1. After removing the connector for the optical pickup from the
connector,wraptheconductivealuminiumfoilaroundthefrontend
of the connector so as to protect the optical pickup from electro-
static damage.
(B1)x2
ø3x10mm
(A1)x2
ø3x12mm
(A1)x2
ø3x12mm
(B1)x2
ø3x10mm
(B1)x4
ø3x10mm
Rear
Panel
Side Panel
(Right)
Side Panel
(Left)
Top Cabinet Front
Panel
(C3)x1
CD Player
Unit
CD Tray Cover (C2)x3
1
1
2
2
(E1)x1
ø3x10mm
(C1)x1
ø3x10mm
(E1)x1
ø3x10mm
(D1)x1
ø3x10mm
Lug Wire
Main PWB
Rear
Panel
Pull
(C3)x1
Main
PWB
(D2)x1
(D1)x11
ø3x10mm
(C4)x4
VIDEO
CD PWB
Figure 6-3
Lock Lever
CD Player Unit
(Bottom View)
CD-XP205V
CD-XP205V
Note 3:
1. Be careful not to break the claw of the CD mechanism.
2. When fining back the cam gear assembly, let it lock by front
movement.
All manuals and user guides at all-guides.com
all-guides.com

– 7 –
CD-XP205V
Figure 7-1
Figure 7-2
Figure 7-3
Figure 7-4
Figure 7-5
Figure 7-6
(E2)x1
Tape
Mechanism
(F1)x2
ø3x10mm
Front
Panel
(F2)x1
(F2)x1
(E2)x1
(F3)x1
(E3)x1
(E2)x1
Main PWB
Transformer
PWB
Power PWB
(E1)x2
ø3x10mm
Display
PWB
Mic
PWB
(G1)x2
ø3x10mm
(G2)x1
(E2)x1
Headphones
PWB
(E4)x1
(H1)x12
ø3x10mm
Display PWB
Open
Cassette
Holder
Tape
Mechanism
(J1)x5
ø3x10mm
Lug Wire
Front Panel
(H2)x1
(K1)x1
ø3x10mm
Headphones
PWB
CD Player Unit
Loading
Tray
Turntable
(L2)x1
(L1)x2
(M1)x3
3
(M1)x3 Loading Tray
1
2
Loading
Tray
(N1)x2
ø3x10mm
(N3)x2 Video CD
PWB
(N2)x1
(N3)x2
CD
Mechanism (P2)x2
(P1)x1
(P1)x1 Loading Tray
All manuals and user guides at all-guides.com

CD-XP205V
– 8 –
Figure 8-1 Figure 8-2
1 Woofer 1. Front Panel ............. (A1) x1 8-1
2. Screw ...................... (A2) x4 8-2
2 Tweeter 1. Screw ...................... (B1) x2 8-2
STEP REMOVAL PROCEDURE FIGURE
Screwdriver
Driver should
be pried away
from Speaker Box.
(A1)x1
Speaker Box
Ass'y (A2)x4
ø4x12mm
(B1)x2
ø3x10mm
Speaker Box
Ass'y
Woofer
Tweeter
CP-XP205
All manuals and user guides at all-guides.com

– 9 –
CD-XP205V
REMOVING AND REINSTALLING THE MAIN PARTS
TAPE MECHANISM SECTION
Perform steps 1 to 6 and 9 of the disassembly method to
remove the tape mechanism.
How to remove the record/playback and erase
heads (TAPE 2) (See Fig. 9-1)
1. When you remove the screws (A1) x 2 pcs., the record/
playback head and three-dimensional head of the erasing
head can be removed.
How to remove the playback head (TAPE 1)
(See Fig. 9-2)
1. When you remove the screws (B1) x 2 pcs., the playback
head can be removed.
How to remove the pinch roller (TAPE 1/2)
(See Fig. 9-3)
1. Carefully bend the pinch roller pawl in the direction of the
arrow <A>, and remove the pinch roller (C1) x 1 pc., in the
direction of the arrow <B>.
Note:
When installing the pinch roller, pay attention to the spring
mounting position.
How to remove the belt (TAPE 2)
(See Fig. 9-4)
1.Removethemainbelt(D1)x1pc.,fromthetapemotorside.
2. Remove the FF/REW belt (D2) x 1 pc.
How to remove the belt (TAPE 1)
(See Fig. 9-4)
1.Removethemainbelt(E1)x1pc.,fromthetapemotorside.
2. Remove the FF/REW belt (E2) x 1 pc.
How to remove the tape motor (See Fig. 9-5)
1.Removethescrews(F1)x2pcs.,toremovethetapemotor.
Figure 9-1
Figure 9-2
Figure 9-3
Figure 9-4Figure 9-5
(A1)x2
Ø2x9mm
TAPE 2
Record/Playback
Head
Erase Head
Clutch Ass'y
(B1)x2
Ø2x9mm
TAPE 1
Playback
Head
Clutch Ass'y
Pinch Roller
(C1)x1 <A>
<B>
Pinch
Roller
Pawl
Pull
TAPE 2 TAPE 1
Main Belt
(E1)x1
TAPE 2
Main Belt
(D1)x1
TAPE 1
Main Belt
(D1)x1 Main Belt
(E1)x1
FF/REW
Belt
(D2)x1
FF/REW
Belt
(E2)x1
Tape
Motor
Tape
Motor
Tape Motor
(F1)x2
Ø2.6x5mm
Clutch Ass'y
All manuals and user guides at all-guides.com

CD-XP205V
– 10 –
How to remove the pickup (See Fig. 10-2)
1. Remove the stop washer (B1) x 1 pc., to remove the gear
(B2) x 1 pc.
2. Remove the screws (B3) x 2 pcs., to remove the shaft
(B4) x 1 pc.
3. Remove the pickup.
Note
After removing the connector for the optical pickup from the
connectorwraptheconductivealuminiumfoilaroundthefront
end of connector so as to protect the optical pickup from
electrostatic damage.
Figure 10-2
CD MECHANISM SECTION
Perform steps 1, 2, 3, 11, 12, 13 and 14 of the disassembly
method to remove the CD mechanism.
How to remove the loading motor
(See Fig. 10-1)
1. Remove the screw (A1) x 1 pc., to bend the hooks (A2) x 5
pcs., to remove the loading motor.
Figure 10-1
ADJUSTMENT
MECHANISM SECTION
••
••
•Driving Force Check
Torque Meter Specified Value
Play: TW-2111 Tape 1: Over 80 g
Tape 2: Over 80 g
••
••
•Torque Check
Torque Meter
Tape 2
Play: TW-2111 30 to 80 g.cm 30 to 80 g.cm
Fast forward: TW-2231 — 70 to 180 g.cm
Rewind: TW-2231 — 70 to 180 g.cm
Specified Value
Tape 1
Specified
Value
Adjusting
Point Instrument
Connection
Test Tape
Normal MTT-111 Variable 3,000 ±30 Hz Speaker
speed Resistor in Terminal
motor. (Load
resistance:
6 ohms)
••
••
•Tape Speed
Figure 10-3
(B3)x2
ø2.6x6mm
Shaft
(B4)x1
Stop Washer
(B1)x1
Gear
(B2)x1
CD Mechanism
Pickup
TAPE MECHANISM
Tape
Motor
Variable Resistor in motor
(A2)x5
(A1)x1
ø3x10mm
Loading
Motor PWB
Loading
Motor
Loading
Tray
All manuals and user guides at all-guides.com

– 11 –
CD-XP205V
Figure 11-2
CD ERROR CODE DESCRIPTION
Error Explanation
01 When Pickup set inner position, inner switch
cannot detect 'ON' level for 10 secs.
When tray moves to Open/Close, Open/Close switch
10* cannot detect 'ON' level for 7 secs.
When disc table rotate to target position.
Clamp switch cannot detect 'ON' level for 7 secs.
When disc table set to Disc1 position for 1 st time,
11* "CLAMP SW", "DISC NO SW" and "OPEN/CLOSE"
cannot detect 'ON' level for 14 secs.
31 When it changes to CD function, DSP cannot read
initial data.
T
T
EFBL
FDO
TE
Stopped
CH1=500 mV
DC 10:1 CH2=200 mV DC 10:1 CH3=1 V DC 10:1 500 ms/div
(500 ms/div)
NORM:20 kS/s
1
2
3
=Record Length=
Smoothing : ON CH1 : 0.000 V
CH2 : 0.000 V Main : 100K Zoom : 2k Mode : SINGLE Type : EDGE CH1
Delay : 0.0 ns
Hold off : 0.2 µs
CH3 : 0.00 V
CH4 : 0.00 V
BW : FULL
=Trigger==Filter= =Offset=
CH2
v/DIV
200 mV
1999/04/05 20:26:47
Test Stage Frequency Frequency
Display Setting/ Adjusting
Parts
Instrument
Connection
CD SECTION
••
••
• AM IF/RF
Signal generator: 400 Hz, 30%, AM modulated
*1. Input: Antenna Output: TP302
*2. Input: Antenna Output: TP301
TUNER SECTION
fL: Low-range frequency
fH: High-range frequency
AM IF 450 kHz 1,602 kHz T351 *1
AM Band — 531 kHz (fL): T306 *2
Coverage 1.1 ±0.1 V
AM Tracking 990 kHz 990 kHz (fL): T303 *1
Figure 11-1 ADJUSTMENT POINTS
Items adjusted automatically
(1)Offsetadjustment(The offset voltage between thehead
amplifier output and the VREF reference voltage is
compensated inside the IC.)
* Focus offset adjustment
* Tracking offset adjustment
(2) Tracking balance adjustment (waveform drawing
Fig. 11-2 EFBL)
(3)Gainadjustment(Thegainiscompensated insidetheIC
sothatthe loop gainatthegain crossover frequencywill
be 0 dB.)
* Focus gain adjustment
* Tracking gain adjustment
•Adjustment
Since this CD system incorporates the following automatic
adjustment functions, readjustment is not needed when
replacingthepickup.Therefore,differentPWBsandpickups
can be combined freely.
Each time a disc is changed, these adjustments are
performed automatically. Therefore, playback of each disc
can be performed under optimum conditions.
AM IF
FM RF TP302
FM IF
T301
T302
R356
T303
T306
IC301
L312
T351
CNP302
AM/FM LOOP
ANTENNA
FM BAND
COVERAGE fL
AM BAND
COVERAGE fL
AM TRACKING
fL
MAIN PWB
1
TP301
R316
SO302
FM ANTENNA
TERMINAL
* 'CHECKING'
IfErrorisdetected,'CHECKING'willbedisplayinsteadof'ER-
CD**' display. 'ER-CD**' display will only be display when
error had been detected for the 5 th times.
*1. Input: Antenna Output: TP301
*2. Input: Antenna Output: Speaker terminal
••
••
•FM RF
Signal generator: 1 kHz, 40 kHz dev., FM modulated
FM Band — 87.50 MHz T301 (fL): *1
Coverage 1.3 V ±0.1 V
FM RF 98.00 MHz 98.00 MHz L312 *2
(10-30 dB)
Test Stage Instrument
Connection
Frequency Frequency
Display Setting/ Adjusting
Point
••
••
•FM IF
Signal generator: 10.7 MHz, FM modulated
IF 10.7 MHz 98.00 MHz T302 *1
(Turn the
core of trans-
former T302
fully counter-
clock wise)
Test Stage Instrument
Connection
Frequency Frequency
Display Setting/
Adjusting
Point
*1. Input: Antenna Output: TP301
All manuals and user guides at all-guides.com
all-guides.com

CD-XP205V
– 12 –
TEST MODE
•Setting the test mode
Any one of test mode can be set by pressing several keys as follows.
<X-BASS> + <CD> + <POWER> TEST: CD operation test.
Function: -CD test mode.
-Enter test mode.
C D T E S T
OPEN/CLOSE operation is using manual.
<< >>,<< >>buttonsmakepick'sslidepossible.
Do TOC IL. Do normal play.
When these following key is input
into PLAY key, track number can
be appoint directly.
<<PLAY>> key input. <<MEMORY>> key input.
<< 1>> key: Track 4
<< 2>> key: Track 9
<< 3>> key: Track 15
<<STOP>> key input.
STOP
Laser ON.
<<MEMORY>> key input.
Tracking OFF play at that
specific point.
<<MEMORY>> key input.
Tracking ON play from
that specific point.
<<STOP>> key input.
STOP
IL isn't done
VOL — Last memory
BAL — CENTER
P.GEQ — FLAT
X-BASS — OFF
To cancel : Power OFF
Sliding the PICKUP with
<< >>, << >> button
must only be in STOP mode.
<<MEMORY>>
key input.
Adjustment result
automatically will
display as below.
for each 2 sec :
a) "FOFF_XX"
b) "TOFF_XX"
c) "TBAL_XX"
d) "TGAN_XX"
f) "FGAN_XX"
g) "RFLS_XX"
explanation:
a) Focus off set = "FOFF_XX"
b) Tracking off set = "TOFF_XX"
c) Tracking balance = "TBAL_XX"
d) Tracking Gain = "TGAN_XX"
f) Focus Gain = "FGAN_XX"
g) RF level shift = "RFLS_XX"
Adjustmentresultautomaticallywill
display as below for each 2 sec :
a) "FOFF_XX"
b) "TOFF_XX"
c) "TBAL_XX"
d) "TGAN_XX"
f) "FGAN_XX"
g) "RFLS_XX"
<<MEMORY>> key input.
All manuals and user guides at all-guides.com

– 13 –
CD-XP205V
Standard Specification of Stereo System Error Message Display Contents
Error Contents DISPLAY Notes
TAPE Mechanism Error. 'ER-TA**' 00: Tape Mechanism Error.
01: Initial Error.
CD Pickup Mechanism Error. 'ER-CD**' 01: PU-IN SW Detection NG.
CD Changer Mechanism Error. 'ER-CD**' 10: Changer Error.
(*) 11: Initial Error.
CD DSP Communication Error 'ER-CD**' 31: DSP COMMUNICATION ERROR
Focus Not Match. 'NO DISC'
IL Time Over. 'NOT READ'
TUN PLL Unlock. 'ER-TU**' 00: TUN Error.
01: PLL Unlock.
(*) CHECKING:
IfCD changermechanismerrorisdetected,'CHECKING'willbedisplay insteadof'ER-CD**'display'ER-CD**'willonlybedisplay
when CD changer mechanism error had been detected for the 5 th times.
Speaker abnormal detection and +B PROTECTION display
In case speaker abnormal detection or +B PROTECTION had occurred, it can be check by pressing 'POWER', 'VIDEO' and 'X-
BASS' key twice. Display will show "S** B**". S is referring to speaker abnormal detection and B is referring to +B PROTECTION.
** is in hex valve.
+B PROTECTION is condition when irregular process occur on power supply line.
Track 2 Video output terminal Chroma Peak Level
105 ±15 IRE
VIDEO CD SECTION
TEST DISC Model No. TVD-581A (NTSC/PAL)
• Checking of video output signal
Checking of color bar
Disc Adjusting Point Instrument
Connection
Figure 13-1 CHECKING OF VIDEO OUTPUT SIGNAL Figure 13-2
UNIT
Video Output Terminal
Video Input Terminal
TV
Color bar signal
waveform
100 100 88.5 75 70
75
41.5
33.5
50
-13.5 -25 -25
100 IRE
(0.714 V)
(1 V)
(0.286 V)
140 IRE
Horizontal
sync signal
40 IRE
40 IRE
Color Burst
20
-20
-40
Blue
Red
Green
Magenta
Cyan
Yellow
Gray
(59.94 Hz)
IH
All manuals and user guides at all-guides.com

CD-XP205V
– 14 –
Figure 14-1
Set the phase of color Phase check
Track 2 VIDEO OUT burst signal (B) to ±10°
180°-360°line.
Disc Checking Setting Checking
Item
Checking of vector scope waveform
( Check that the setting is within the illustrated range.)
Figure 14-2
Figure 14-3
Figure 14-4
Track 3 VIDEO OUT 150 line. Output level
±10 IRE
Disc Checking Setting Checking
Item
Checking the black-and-white level
Figure 14-5
90 80 70 60
50
40
30
20
10
360
350
340
330
320
310
300
290
280
270
260
250
240
230
220
210
200
190
180
170
160
150
140
130
120 110 100
103.4
167.1
240.8 283.4
347.1
60.8
-1
123 +180
+0
33
MG
R
BL
CY
G
YE
Vector scope waveform of color bar signal
TV monitor
Blue
Red
Green
Magenta
Cyan
Yellow
Gray
IRE
100
80
60
40
20
-20
-40 100%
12.5%
0%
NTSC
Waveform on 140 LINE
(This burst level
is 40 IRE)
140 IRE
TV monitor
TV monitor
Blue
Red
Green
Magenta
Cyan
Yellow
Gray
All manuals and user guides at all-guides.com

– 15 –
CD-XP205V
Figure 15 BLOCK DIAGRAM (1/3)
TO DISPLAY
SECTION TO MAIN
SECTION
1
2
3
4
5
6
1
2
3
4
5
6
7
8
40
30
31
32
41
47
46
53
75
65 66 67 68 70 71 72 52 51 73
5
18
36
30 23 11 9 1
2
3
4
7
8
22
21
20
19
18
17
44
49
50
7
14
15
16
3
13
23242526336474
7
8
9
10
O/C SW
CLAMP SW
CD RES
CLK
DI
DO
CE
DRF
WRG
A10 V (+B8)
+5 V (+B7)
CD-GND
L-CH
A_GND
R-CH
CNP12
CNP11
M3
T/T UP/DOWN
LOADING
MOTOR
M1
SPINDLE
MOTOR
M2
SLED
MOTOR
SW3
DISC
NUMBER
SW2
CLAMP
SW1
OPEN/
CLOSE
CONT2
TEST
CONT3
CONT4
CONT6
CE CL DI DO WRQ RES DEF XOUT XIN
EMPH
XVSS
RVSS
LVSS
VDD
VDD
LVDD
RVDD
XVDD
HFL
PH
FE
TE
TDO FDO
SPDO
SLDO
CONT5
VVDD
ADAVDD
1
2
3
4
5
6
1
2
3
4
5
6
1
2
3
4
5
6
CNP4
M
+
+
-
-
M
-
+
Q10
Q9
Q2
IC2
LC78636E
SERVO/SIGNAL
CONTROL
Q4
Q3
VOLTAGE
REGULATOR +3.4 V
(+B11)
+3.4 V (+B11)
XL2
16.9344 MHz
RFEV
LDD
PD
TIN2
TIN1
FIN2
FIN1
FE-
TE-
TE
HFL
FE
IC1
LA9235M
SERVO AMP.
TRACKING COIL
FOCUS COIL
PICKUP UNIT
+5 V
(+B7)
+5 V
(+B7)
LASER
DRIVER
+3.4 V
(+B11)
+5 V (+B7)
39
38
42
41
40
25
17
2
118 24 23 28
4
5
6
7
15
16
26
27
8142122 ~
9188 ~
45 44 43 41 3247
49 52 54
~~
8782
79
68
66
65
64
1
2
12
~
~
13
15
21
17
22
24
~
~
62
55
80
669
89 86 84 80
98 79 37 33 23 90 78 73 66 60 59
53
32
16
5
91
77
75
72
63
100
1 25 26 31 41 43 51 56 57 62 45 48
50 30
100
~
4
12
~
16
19
~
26
22
~
7
10
~
2
5
~
34
31
~
39
36
~
1
6
40
35
21
20
13
81
51
31
1
84
5
7
1
3
959493
28
~
~
30
32
23
25
~
2935 ~
M
TO ICM3
17, 19, 21, 22PIN
ICM4
IX0512AW
EPROM IC
OE_
CE_
DSC_C
ARCLK
AJN
ARFS
ICM3
ES3889F
VCD COMPANION
ICM2
ES3880F
VIDEO CD DECODER
IC6
TJM4558CD
OPE AMP.
LOE#
LROMCE#
LSC1#
AJN ARCLK ARFS
64
CNP1
ICM1
1625635T
DRAM
OUT6-
+B8
SP-
SP+
SL+
SL-
TR-
TR+
FO-
FO+
OUT6+
IN6+
IN6-
VCC4
SPDO
SLDO
FDO
TDO
IC3
M63001FP
FOCUS/TRACKING/
SPIN/SLED DRIVER
QM1
JK690
VIDEO OUT
VCC
19
QM6
QM5
+B12
+B13
+B12 +B12
~
+B12
+B13 +B12
+B12
4482
92
94
96
83
85
93
95
97
99
81
71
74
8
+B8
DGND
+6.5 V (+B4)
DISC NO. SW
CNP1
SW4
PICKUP IN
+B8
LR
LR
L
R
XOUT
XIN
XL1
27 MHz
All manuals and user guides at all-guides.com

CD-XP205V
– 16 –
Figure 16 BLOCK DIAGRAM (2/3)
IC101
AN7345K
PLAYBACK AND RECORD
/PLAYBACK AMP.
AUX R
L
R
L
JK690
VIDEO/AUX
FM+B
+B5
CLK
+B6 +B6
+B6 +B5
AM IF
OSC BUFF
FM IF
FM
OSC
B.P.F
SO302
FM ANTENNA
TERMINAL
–20dB
ATT
Q101~
Q104
Q107
Q108
Q601
Q602 Q603 Q604
10.7 MHz
450 kHz
FM
ANTENNA
REC/PLAY
CLK
CE
DI
DO DI CE
MO/ST
SWITCHING
+B5
FM/AM
IC302
LC72131
PLL(TUNER)
FM/AM OUT
L
R
BIA
S
T1/T
2
MUTING
P.B. REC.
AC BIAS
L
L
R
R
R
L
TAPE
TUNER
CD
PB
HEAD
ERASE
SWITCHING
SWITCHING
SWITCHING
BIAS
Q113
Q114
Q112
Q110
Q706
Q707
Q708
SWITCHING
Q109
BIAS/
OSC
Q111
L103
Q105
Q106
REC./P.B.
HEAD
TAPE 2
P.B. HEAD
TAPE 1
R-CH
L-CH
R-CH
L-CH
IC601
LC75341
AUDIO PROCESSOR
+B5
R
L
REC
R
L
R REC
L REC
SWITCHING
L(T2)
R(T2)
R(T1)
L(T1)
R
L
FM/AM
MPXIN
STEREO
AM RF IN
AM OSC IN AM OSC OUT
FM
Q360
VT
OSC
X352
4.5 MHz
AM BAND
COVERAGE
AM TRACKING
T303 T306
Q302
X351
456 kHz
ZD351
5.1V
MO/ST
VCO
FM
DET
FM+B
GND
AM IF
CF351
IC303
LA1832S
FM IF DET./
FM MPX./AM IF
AM MIX
CF352
T351
FM RF
OSC
FM
L312 T301
CF303T302
IC301
TA7358AP
FM FRONT END
BF301
21
4
24
2
1
18
910
18
11
16
3
15
10
9
7
23
14
12
13
19
7
18
13
21
4
2
24
23
9
16
12
11
15
1
5413
8
4
3
1
21
7
98517
6
21
21
20 22 11
17
1615
9
6
57 13
14
12
15
162324
4
7
H/N
P.B
REC
T1/T2
NOR/
HIGH
+B5
+B5
+B5 TAPE
MECHANISM
ASS'Y
MOTOR
DRIVER
SOLENOID
DRIVER
+B3
+B3
AM LOOP
ANTENNA
CNP302
CNP11
FROM
CD SECTION
BI601
3
1
2
8
17
+B5
LATCH
CLOCK
DATA
ROUT
LOUT
LIN
RIN
VCC QK1
22
23
31
32
36
35
41
12
13
42
40
96
7
1
5
2
3
ICK2
KIA4558P
OPE AMP.
ICK1
M65856SP
MIC AMP.
JK1
MIC
MIC IN
VRK1
MIC
VOLUME
L
R
All manuals and user guides at all-guides.com
all-guides.com

– 17 –
CD-XP205V
Figure 17 BLOCK DIAGRAM (3/3)
KIA7805AP
AN78L05
Q905
AC 110/127/220/230-240 V,
50/60 Hz
–VF
VF2 VF1
Q801
IC855
+B2
+B3
+B4
-B2
+B7
+B3
+B10
-
12 13 41
+B5
19
Q705
R
L
B
+B10
RX701
REMOTE
SENSOR
D803, D804
D802
RL914
JK701
HEADPHONES
M4
FAN
MOTOR
M
Q906
Q709
Q
601
Q
602 Q603 Q604
IC901
STK4029S
POWER AMP.
F804
T2A L 250V
VOLTAGE
REGULATOR
F803
T2A L 250V
F801
T4A L 250V
F802
T4A L 250V
R-OUT
L-OUT
Q901~
Q904
CLK
SO901
SPEAKER
TERMINAL
AC POWER
SUPPLY CORD
32
REC/PLAY
VLOAD
RESET
+B10 +B10
+B10
+B10
+B9
VDD VDD VDD
~
~
CE DI DO
XL700
4.194304 MHz
BIAS
T1/T2
AVDD
SW701-SW707
SW711-SW725
SW727-SW729
KEY
TO CD
SECTION
TO CD
SECTION
IC701
IX0560AW
SYSTEM
MICROCOMPUTER
FL701
FL DISPLAY
27
85
80
33 45
93
14
92
1245678
15
1
8
78
70
51
3
2
1
7
13
9
10
100
33
31
37
29
26
15
46
1112
9
10 16 17 20 21222324
41
79
5438 5251 50
55 49
48 40 25 13
39
34
T.F.
PT801
POWER
TRANSFORMER
SYSTEM
MUTE
~
~~
91
86
~
~~~
TAPE
MECHANISM
ASS'Y
RESET
SP DET.
SP RELAY
ON-OFF
FAN MOTOR
DRIVER
IC851
IC852
IC853
IC854
M_13V
LD+7V
+B5
+B10
A_10V
UNSW_5.6V
+B7
+B8
+B9
D_5V
A_5V
SW_5V
IC851, IC852
VOLTAGE
REGULATOR
IC853, IC854
VOLTAGE REGULATOR
VOLTAGE
REGULATOR
KIA7810AP
KIA7812AP
5655
SW801
VOLTAGE
SELECTOR
220V
127V
110V
230-240V
SW601
SPAN
SELECTOR
All manuals and user guides at all-guides.com

CD-XP205V
– 18 –
Figure 18 SCHEMATIC DIAGRAM (1/13)
A
B
C
D
E
F
G
H
123456
• NOTES ON SCHEMATIC DIAGRAM can be found on page 39.
0.7V
0V
0V
0V
0.7V
0V 0V
0V
0V
0V
0V 0.7V
0.7V 0V 0V
0V
9.3V
8.6V
9.3V
0V 3.4V
3.4V
0V
0V
0V
0V
0.7
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
24 23 22
1 2 3 4 5
2021
6 7 8
171819
CD(A_GND)
+B_PROTECT
SW_5V
SP_DET
SP_RLY
L-CH
D_5V
R_CH
LD+7V
A_5V
S_MUTE
GND(CD_GND)
GND
(A_GND)
GND(D_GND)
GND(M_GND)
UNSW_5.6V
A_+10V
M_+13.5V
–20dBATT
L
L
R
R
A_GND
T1_R
T1_L
A_GND
M_GND
ERASE
T2_R2
T2_R1
T2_L1
T2_L2
3
1
2
CD
TUNER
DECK
AUX
DI
CE
VSS
LOUT
LBASS
LTRE
LIN
L4
L3
L2
L1
CLK
VDD
VREF
ROUT
RBASS
RTRE
RIN
RSEL0
R4
R3
R2
R1
CCB
INTERFACE
+
–
+
–
+ –
+ –
+ –
+ –
+ –
+ –
LSEL0
–
+
–
+
Hich=T1
+
+
–
–
Hich=
C
112K
112K
8
7
1
4
6
5
3
2
D_GND
LD+7V
A-5V
D_5V
CD_GND
L-CH
A_GND
R-CH
8
7
6
5
4
3
2
1
P22 1 - E~H
TO POWER SECTION
TAPE 1
PLAYBACK HEAD
R-CH
L-CH 3
2
1
RECORD/
PLAYBACK HEAD
TAPE 2
1
1
23
23
CNP11
P27 12 - D
TO VIDEO CD SERVO PWB
MAIN PWB-A1 (1/3)
1
2
3
7
9
6
8
5
4
11
10
13
16
15
12
14
17
Q603, Q604: SYSTEM MUTE
SWITCHING
SWITCHING
SWITCHING
MU
T
SWITCHING
SWITCHING
SWITCHING
SWITCHING
SWITCHING
SWITCHING
+B
+B
+B
+B+B
+B
ERASE
HEAD
R-CH
L-CH 7
6
5
4
3
2
1
6
5
4
3
2
1
6
5
4
3
2
1
Q101
KTC3200 GR
C103
180P
Q103
KTC3200 GR
R105
3.3K
R103
2.2K
R107
47K
R109
4.7K
Q105
KTC3199 GR
C105
560P
C104
180P
C101
560P
C102
560P
Q102
KTC3200 GR
R104
2.2K
Q104
KTC3200 GR
R106
3.3K
R102
1K
R101
1K
R108
47K
R110
4.7K
C106
560P
Q106
KTC3199 GR
Q112
KTA1266 GR
C136
0.022
R146
10K
R147
10K
Q113
KRC104 M
C141
100/16
R149
150
Q114
KRC104 M
R112
15K
C112
100/25
R116
56 R122
10K
R118
100K
R120
3.9K C116
560P
C114
0.033
C118
47/25
R124
5.6K
C120
0.0022 R150
68K
R126 4.7K
Q
1
KTC3
1
R1
3
22
0
C1
22
/
R128
5.6K
C124 270P
R130 1.5K
C128
0 022
R132
100
IC101
R113
1K C109
330P
C107
330P
C108
330P
C110
330P
R111
15K
R115
56
C111
100/25
C113
0.033
R117
100K
R119
3.9K
R121
10K
C117
47/25
C115
560P
C119
0.0022
R127
4.7K
C121
0.022
R129
5.6K
C1
22
/
R133
C123
270P
C127
0 022
CNP101
R148
4.7K
C625
0.0022 R609
1.2K
R621
22K
C639
1/50
R620
22K
C640
22/50
R618
330
R619
330
Q603
KTC3199 GR
R617
2.2K
C637
0.001
C638
0.001
R616
2.2K
R614
4.7K R615
4.7K Q601
KTC3199 GR
R613
390
R605
10K C609
1/50
R611
2.2K
C636
0.001 C635
0.001
R610
2.2K
R612
390
Q602
KTC3199 GR
C611
0.0022
R607
3.9K
C602
0.022
C601
220/16
C653
220P
C652
220P C651
220P
C607
0.1 C605
0.1
C613
1/50
C615
4.7/50
C617
1/50
C629
0.001
C619
1/50
C621
1/50
C623
1/50
IC601
LC75341
AUDIO PROCESSOR
C
C6
1
1/5
R114
1K
R123
5.6K
Q604
KTC3199 GR
BI601
CNS601
C143
3.3/50
R131
1.5K
CNS102
BI102
FM SIGNAL
PLAYBACK SIGNAL
RECORD SIGNAL
CD SIGNAL
VIDEO SIGNAL
VIDEO OUT SIGNAL
MIC SIGNAL
All manuals and user guides at all-guides.com

– 19 –
CD-XP205V
Figure 19 SCHEMATIC DIAGRAM (2/13)
78 9 10 11 12
0V
0V
0.7V 0.7V
0V
0V
0V 0V
0V
11.7V
11.6V
11.6V
0V
0V
24
23
22
21
20
19
18
17
16
15
14
13
6 7 8
171819 13141516
9
10 11 12
REC_L
REC_R
CHASSIS
L-CH
R-CH
AUX IN
VIDEO OUT
CE
CLK
DI
DO
REC/PLAY
T-T1 T2
T_BIAS
A_+10V
D_GND
–20dBATT TUN_L
TUN_R
DI
CLK
DO
CE
A_+10V
D_GND
A GND
LVL_DET CE SPAN MIC IN KOK_LATCH DO CLK DI +B-PROTECT D_GND S_MUTE T_T1/T2 REC/PLAY T_BIAS M_+13.5V A+10V SW_5V UNSW5.6V SP_DET SP_RLY –20dB
1345689
10 11 12 13 14 15 16 17 18 19 20 21
CLK
VDD
VREF
ROUT
RBASS
RTRE
RIN
RSEL0
R4
R3
R2
R1
+
–
+
–
+
–
+ –
+ –
VCC
ALC GND ALC
RIPPLE
Nor/CrO2
+
+
–
–
Hich=CHROME
56K
56K
27
1
23
121
P21 10, 11 - H
TO TUNER SECTION
26
27
22
25
24
23
15
8
2
MUTING
MUTING
SWITCHING
BIAS
BIAS OSC
+B
+B
+B
+B
+B
+B
+B
+B
100 kHz/10 kHz
50 kHz/9 kHz
9
10
11
8
7
6
5
4
3
2
1
9
10
11
8
7
6
5
4
3
2
1
1
2
1
2
MIC IN
KOK_LATCH
CLK
DI
KOK IN(R)
KOK OUT(R)
KOK IN(L)
KOK OUT(L)
A_+10V
A_GND
D_GND
KOK OUT(R)
KOK OUT(L)
KOK IN(R)
KOK IN(L)
CNPK1
P30 6 - C
TO MIC PWB
CNP701
P24 1 - F
TO DISPLAY PWB
CNP2
P29 12 - C
TO
VIDEO CD PWB
R149
150
0.0022
R150
68K
R126 4.7K
Q108
KTC3199 GR
R136
220K
R138
10K R139
10K
Q107
KTC3199 GR
R137
220K
C133 22/50 C134 220/10 C135 0.022
C126
22/50
R128
5.6K
C124 270P
R130 1.5K
C128
0.022 R132
100
C132
47/25 R134
10K
IC101
IC101
AN7345K
PLAYBACK AND RECORD/
PLAYBACK AMP.
C119
0.0022
R127
4.7K
R129
5.6K
C125
22/50
R133
100
C123
270P
C127
0.022
C129 0.0033
R135
10K
C131
47/25
C139
0.039(ML)
C137
0.047(ML)
L103
330µH
C140
47/25
C138
0.0082(PP)
Q111
KTC3203 Y
R144
22K R145
4.7
R142
82(1/2W) Q109
KTA1266 GR
R140
47K
R158
220
Q110
KRC104 M
R141
4.7K
R143
47K
CNP601
JK690
VIDEO/AUX
BI602B
CNS602B
R690
6.8K
R694
1
R691
6.8K C690
390P
C691
390P R692
33K
R693
33K
4
1
C
ESSOR
R601 1K
R602 1K
C603
22/50
R604
10K
C610
1/50
R606
3.9K
C608
0.1
C606
0.1 C612
0.0022
C614
1/50 C616
4.7/50
C618
1/50 C620
1/50
C622
1/50
C624
1/50
R608
1.2K
C626
0.0022
R603 1K
C130 0.0033
C143
3.3/50
R131
1.5K
FFC701
C630
0.001
SW601
SPAN
SELECTOR
BI602 CNS602
All manuals and user guides at all-guides.com

CD-XP205V
– 20 –
A
B
C
D
E
F
G
H
123456
• NOTES ON SCHEMATIC DIAGRAM can be found on page 39.
Figure 20 SCHEMATIC DIAGRAM (3/13)
1 2 3
1 2 3 4
5
6 7 9
8
TP301
AM LOOP
ANTENNA
1
2
1
2
13
2
FM RF
FM OSC.
FM BAND
COVERAGE fL
FM IF
AM OSC.
AM ANTENNA
AM BAND
COVERAGE fL
AM TRACKING
OSC BUFF
+B
+B
+B
+B
+B
+B
C302
0.001
C323
0.022
C338
0.001
D302
DS1SS133
D301
DS1SS133
T303
T306 C335
560P
VD301
SVC348S
C334
22P(UJ)
R323
68K
IC301
TA7358AP
FM FRONT END
C303
10P(CH)
C304
0.01 C305
4.7P(CH) R302
10
C306
0.022
C307
10/50
VD302
SVC211C
C309
0.001
L312
C320
0.001
T301
R313
33K
D305
DS1SS133
C308
4.7P(CH)
R311
100K
CNP302
BF301
B.P.F
C312
0.022
C324
4.7P(UJ)
C311
18P
C310
15P(CH)
R314
22
VD303
SVC211C
C314
0.0047
C316
0.022
C317
0.001
R327
33
R325
47K
Q302
KTC3194 Y
C318
100P
R322
680
R3
7
47
0
C383
56P
C382
15P(CH)
C381
12P(CH)
R316
4.7K
CF303
T302
R309
10K
C313
22P
(CH)
R382
150
C3
0.
0
X352
4.5 MHz
C351 0 022
R336
10K
C331
0.047
C330
15P(UJ)
C332
0.022
C342
0.022
C315
0.0047
SO302
FM ANTENNA
TERMINAL
FM SIGNAL
AM SIGNAL
All manuals and user guides at all-guides.com
