Sharp Actius PC-MP30 User manual

i
Notice for All Users
•Consult the operation manual for proper use of your computer.
•The product and the accessories are subject to change without prior notice.
•SHARP assumes no responsibility for results arising from use of pre-installed and
third party software. Consult the software vendor for resolution of problems.
(Read the service condition of the software before use.)
•SHARP assumes no responsibility for problems caused by incorrect handling,
repairs, defects, battery replacement or any other cause.

ii
Notice for Users in the USA
FCC Statement
WARNING - FCC Regulations state that any unauthorized changes or modifications
to this equipment not expressly approved by the manufacturer could void the user’s
authority to operate this equipment.
Note: This equipment have been tested and found to comply with the limits for a
Class B digital device pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning
the equipments off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the distance between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
A shielded I/F cable is required to insure compliance with FCC regulation for Class
B computing equipment.
* As an ENERGY STAR®Partner, SHARP has determined that this product meets
the ENERGY STAR®guidelines for energy efficiency.
Declaration of Conformity
SHARP PERSONAL COMPUTER, PC-MP Series
This device complies with part 15 of the FCC rules. Operation is subject to the following
conditions:(1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Responsible Party: SHARP ELECTRONICS CORPORATION
Sharp Plaza, Mahwah, New Jersey 07430-2135
TEL: 1-800-BE-SHARP
This device complies with the FCC RF exposure requirements.

iii
About the Modem
This equipment complies with Part 68 of FCC rules. On the bottom of this
equipment is a label that contains, among other information, the FCC registration
number and ringer equivalence number (REN) for this equipment. If requested, this
information must be provided to the telephone company.
The modem jack of this equipment complies with Sub-part F of Part 68 of FCC
rules.
The REN is used to determine the quantity of devices which may be connected to the
telephone line. Excessive RENs on the telephone line may result in the devices not
ringing in response to an incoming call. In most, but not all areas, the sum of the
RENs should not exceed five (5.0). To be certain of the number of devices that may
be connected to the line, as determined by the total RENs contact the telephone
company to determine the maximum REN for the calling areas.
If the terminal equipment causes harm to the telephone network, the telephone
company will notify you in advance that temporary discontinuance of service may be
required. But if advance notice isn't practical, the telephone company will notify the
customer as soon as possible. Also, you will be advised of your right to file a
complaint with the FCC if you believe it necessary.
The telephone company may make changes in its facilities, equipment, operations, or
procedures that could affect the operation of the equipment. If this happens, the
telephone company will provide advance notice in order for you to make the
necessary modifications in order to maintain uninterrupted service.
If trouble is experienced with this equipment, please contact Sharp Electronics Corp.
for repair and (or) warranty information (Refer to the end of this section). If the
trouble is causing harm to the telephone network, the telephone company may
request you remove the equipment from the network until the problem is resolved.
The equipment cannot be used on public coin service provided by the telephone
company. Connection to Party Line Service is subject to state tariffs. (Contact the
state public utility commission, public service commission or corporation
commission for information.)

iv
The Telephone Consumer Protection Act of 1991 makes it unlawful for any person
to use a computer or other electronic device, including fax machines, to send any
message unless such message clearly contains in a margin at the top or bottom of
each transmitted page or on the first page of the transmission, the date and time it is
sent and an identification of the business or other entity, or other individual sending
the message and the telephone number of the sending machine or such business,
other entity, or individual. (The telephone number provided may not be a 900
number or any other number for which charges exceed local or long-distance
transmission charges.) To program this information, refer to the manual of the
communication software.
Warning
Disposal of this product may be regulated due to environmental considerations.
For disposal or recycling information, please contact your local authorities or the
Electronics Industries Alliance: www.eiae.org
Copyright
It is the intent of Sharp that this product be used in full compliance with the
copyright laws of the United States and that prior permission be obtained from
copyright owners whenever necessary.
Product Information and Customer Assistance
For Product Information and Customer Assistance:
Call: 1-800-BE-SHARP (237-4277)
Sharp Systems of America
5901 Bolsa Avenue, Huntington Beach, CA 92647
Home Page: http://www.sharpsystems.com
E-mail address: ssa-s[email protected]

v
CAUTION:
TO PREVENT ELECTRICAL SHOCK, DISCONNECT THE AC CORD AND
REMOVE THE BATTERY BEFORE SERVICING.
CAUTION:
FOR A COMPLETE ELECTRICAL DISCONNECTION, PULL OUT THE MAIN
PLUG AND THE BATTERY.
VORSICHT:
UM DIE STROMZUFUHR VOLLSTÄNDIG ZU UNTERBRECHEN, DEN
NETZSTECKER HERAUSZIEHEN UND DIE BATTERIE ÈNTFERNEN.
ATTENTION:
POUR UN ARRET TOTAL DU SYSTEME, DECONNECTEZ LA PRISE DE
COURANT SECTEUR ET LA BATTERIE.
VARNING:
FÖR TOTAL ELEKTRISK URKOPPLING, KOPPLA UR KONTAKTEN OCH TA
UR BATTERIET.
PRECAUCION:
PARA UNA COMPLETA DESCONEXION ELECTRICA DESENCHUFE LA
CLAVIJA DE LA RED Y LA BATERIA.

vi
Safety Precautions
General
•Follow all cautions and instructions marked on your computer.
•Except as described elsewhere in this manual, refer all servicing to qualified
personnel. Immediately shut off your computer and seek servicing under the
following conditions:
•when the power cord or plug is damaged or frayed
•when liquid is spilled on your computer
•when your computer has been dropped or the cabinet has been damaged
Location
•Do not expose your computer to direct sunlight.
•Try to avoid dusty environments.
•Keep your computer away from any magnetic devices and TVs.
•Keep your computer away from heaters.
•Keep your computer away from excessive humidity or fluids such as rain, snow,
water spray, juice, coffee, steam, etc.
•Keep your computer away from extremely high or low temperature.
•Do not move your computer from an extremely cold place to an extremely warm
place. A temperature difference of more than 18°F (10°C) will cause condensation
inside the unit, which may cause damage. (In this case, turn off your computer and
leave it for about an hour to completely dry the unit.)
•Do not block or cover slots or openings on the cabinet. They protect your computer
from overheating.
•Do not place your computer on an unstable or uneven work surface.
•Care should be exercised when using on heat sensitive surfaces or your lap as the
base of your computer will get hot.
•Do not use your computer on your lap or any part of your body for an extended
period during operation or charging to avoid injury from heat exposure.
Usage
•Never push any objects into cabinet openings. They may touch dangerous voltage
points or short parts that could result in fire or electrical shock.

vii
•Do not press or place heavy objects on your computer. Strong pressure can
damage the cabinet or make your computer fail.
•If your computer or the AC power cord experiences an abnormal situation such as
heat generation or smoking, or produces an abnormal odor, turn off your computer,
unplug the power cord, and remove the battery pack immediately.
•Turn off your computer before installing or removing any peripheral devices except
when connecting USB devices, a PC card, etc.
•Never subject your computer to sudden shocks or extreme vibration.
•Do not drop your computer or hit it with other equipment.
•Do not scratch the surface of the LCD screen.
•Turn off your computer and disconnect the AC power cord before cleaning.
•When carrying your computer:
•Turn off your computer.
•Remove external media such as a PC card from the slot.
•Disconnect the external peripherals, cables and cords if connected.
•Do not subject your computer to shocks.
•Do not hold your computer by the display unit.
Otherwise, your computer may be damaged or the stored data might be lost.
Battery Pack Precautions
CAUTION
DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED.
REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE
RECOMMENDED BY THE MANUFACTURER. DISCARD USED BATTERIES
ACCORDING TO THE INSTRUCTIONS.

viii
Handling
•Never put the battery pack in a fire, as it could explode and cause injury.
•Do not attempt to open or alter the battery pack.
•Do not place the battery pack where it might get hotter than 140°F (60°C).
•The battery pack must be kept from metal objects such as keys. They might trigger
a short circuit and consequently cause the battery pack to heat up and explode.
•Do not allow liquids to come in contact with the battery pack.
•Care must be taken not to drop the pack. A violent shock damages the pack.
•Do not solder anything to the battery terminals.
Charging
•Charge the battery pack only with the AC adapter and AC power cord included
with your computer.
Discharging
•Do not use the battery pack for any other purpose than powering your computer.
Storage
•Store the battery pack in a cool and dry place. Do not store it in a place having
temperatures of above 140°F (60°C).
•Recharge the stored battery pack before using it.
AC Power Precautions
•Plug the AC power cord directly in the wall jack. Plugging too many leads into a
single socket may result in fire.
•Never plug in or remove the AC power cord or AC adapter with wet hands for
prevention of electric shock.
•The included AC power cord must be appropriate for the voltage used in your area.
Using an inappropriate cord can cause fire.
•Unplug the AC power cord when not using your computer for a long period.
•Never disassemble, repair, or modify the AC adapter.
•Never modify, twist, forcibly bend or pull, or place heavy objects on top of the AC
cord to avoid damaging it. Using a damaged cord can cause fire or electric shock.

ix
•Be sure to hold the plug of the AC power cord when removing it from a wall
socket.
•Check the AC power cord and power connectors periodically for damage. Change
the power cord immediately if damage is found.
Modem Precautions
IMPORTANT SAFETY INSTRUCTIONS
When using your telephone equipment, basic safety precautions should always be
followed to reduce the risk of fire, electric shock and injury to persons, including the
following:
•Do not use this product near water, for example, near a bath tub, wash bowl,
kitchen sink or laundry tub, in a wet basement or near a swimming pool.
•Avoid using a telephone (other than a cordless type) during an electrical storm.
There may be a remote risk of electric shock from lightning.
•Do not use the telephone to report a gas leak in the vicinity of the leak.
•Never install telephone wiring during lightning storms.
•During thunder storms, you should turn off your computer, unplug the AC power
cord and remove the modem cable from your computer.
•Never install telephone jacks in wet locations unless the jack is specifically
designed for wet locations.
•Never touch uninsulated telephone wires or terminals unless the telephone line has
been disconnected at the network interface.
•Use caution when installing or modifying telephone lines.
•Save these instructions.
Wireless LAN Precautions
•Disable the integrated antenna and do not communicate with wireless LAN in
specific environments where radio-susceptible equipment is nearby, on airplanes,
in hospitals, for example.
•Disable the integrated antenna and do not communicate with wireless LAN in
crowded places for prevention of cardiac pacemaker interference.
•Maintain a space of at least 8.7” (22cm) between a cardiac pacemaker and the
active wireless LAN antenna.

x
•Maintain a space of at least 7.9” (20cm) between the antenna and your body while
communicating.
•Never disassemble or alter the wireless LAN unit.
•Do not remove the certification label on the wireless LAN unit.
Product Conformance
The wireless LAN unit equipped with your computer is in conformance with federal
requirements. No license is required for use of the device.
Notice of Radio Interference
The wireless LAN unit equipped with your computer operates at 2.4GHz that is also
used for microwaves, science or medical devices, other similar radio stations
(hereafter called “other radio stations”), etc.
•Prior to using the wireless LAN function with your computer, confirm that no
“other radio stations” are operating nearby.
•If interference with “other radio stations” is experienced, change the current
channel set to your computer or move your computer. If it fails, stop operating your
computer.
PC Disposal or Transfer
Prior to the disposal or transfer of your computer, you should erase the data from
hard disks.
To remove the data from your hard disk drive, you will need to:
•“Delete” the data by placing it in your recycle bin.
•Empty the recycle bin.
•Format the hard disk drives.
•Recover the system.
The above procedures do not completely delete all data from your hard disks.
When a file is deleted, the disk location where it was stored is marked as unallocated
space available for new data. It means that the old data is still there and can be
recovered. It allows for malicious persons to recover the “deleted” data and misuse
it. To avoid the data spillage, users must thoroughly erase all the data from the hard
disks.

xi
The following measures are recommended for permanent data deletion:
•Use special software or paid services for thoroughly erasing data
•Hammer, or strongly magnetize, the hard disk to destroy the stored data
Be sure to delete the software, such as operating system(s) or applications, on your
hard disk when transferring your computer, to avoid conflict with the software
agreement(s).
Other Precautions
•Periodic back-up copies of your important data should be made to protect your data
in the event of hard disk failure or loss of the data. Use other storage devices for the
backup.
•Your computer is integrated with a magnet on the right side of the display. Be sure
to keep magnetic cards and floppy disks away from the right side of your computer
to prevent the data on the cards or floppy disks from being erased.
•Your computer has a sensor on the right side of the keyboard that responds to the
magnet. If the magnet gets close to the sensor:
•The backlight will be turned off.
•The system may enter the standby or the hibernate mode according to the
setting. (See Chapter 2.)
Magnet

xii
For Your Health
•Take regular breaks of ten to fifteen minutes after every hour of continuously
viewing the screen to relieve your eyes.
•Adjust the brightness for comfortable viewing. (Brightness level of about 500 lux is
recommended.)
•Do not use your computer in an environment where sunlight or indoor lighting
reflects off the screen.
•Position the display slightly below eye level and give a space of 15.8” (40cm)
through 23.7” (60cm) between you and the display.

xiii
Notice of Computer Security
The Windows operating system on this computer provides the Security Center, which
manages the security features of the computer. It provides the status of the following
security functions and enables you to change the settings.
•Firewall
•Automatic Updates
•Virus Protection
Be sure to confirm that the three functions are “ON” to ensure the safety of the
computer.
To open the Security Center, click start – Control Panel – Security Center.
Firewall
The firewall function blocks unauthorized connection to this computer through the
Internet or a network.
Automatic Updates
The automatic updates function periodically detects new security programs to be
installed and automatically installs them.
Virus Protection
The Norton AntiVirus software, which automatically checks the virus infection, is
preinstalled in this computer. To protect the computer against new viruses and other
security threats, the virus definition file of the software must be updated. The virus
protection function monitors whether the definition file is latest. On your computer
with the preinstalled Norton AntiVirus software, however, the software monitors the
definition file and notifies you when the file needs to be updated.
When the Windows setup is finished, be sure to complete the Norton AntiVirus
wizard and LiveUpdate to update the definition file. (You must establish the
connection to the Internet for the update.)
After completing the Norton AntiVirus wizard and LiveUpdate;
* The Virus Protection in the Windows Security Center always displays as ON
regardless of the definition file status. Since the preinstalled Norton Antivirus
software manages virus check on your computer, be sure to perform the
LiveUpdate.

xiv
* You can enable the LiveUpdate automatically to run and update the file if any
updates are detected. (Refer to the Virus Protection section in the Appendixes.)
* You will have the message “Your computer might be at risk” at the bottom right of
the screen when one of the Firewall and Automatic updates is set to OFF.

xv
Notice of Security with Wireless Devices
Wireless LAN provides data transfer by means of electric waves instead of LAN
cables between communicating devices such as personal computers and a wireless
LAN station. Wireless LAN has an advantage of simple and ubiquitous LAN
connection in the ranges where electric waves are available. Since electric waves can
penetrate through walls and reach everywhere, wireless LAN without proper security
settings includes some security threats and can produce the situations mentioned
below.
•Eavesdropping
Malicious third parties can intercept the transmission and monitor your mail to
steal personal information such as an identification number, password, and credit
card number.
•Intruding
Malicious third parties can connect to a personal or office network without
authorization and illegally perform the following:
•Obtaining access to confidential customer records or sensitive corporate
information (Information leakage)
•Faking the original information (Spoofing)
•Altering the monitored original data and transmitting (Falsification)
•Spreading computer viruses resulting in the destruction of data or systems
(Destruction)
Although wireless LAN cards and wireless LAN stations (Access Points) have
security measures against the threats above, no security settings may have been
configured at the time of your purchase.
All security features must be configured according to reference manuals of the
wireless LAN devices, which results in reducing vulnerability to the attacks described
above.
Use the wireless devices with a clear understanding that wireless LAN includes
vulnerabilities that could allow attackers to simply bypass security features.
Security measures are important for all users to understand for a safe use of wireless
LAN. SHARP encourages all users to configure the security settings with their own
judgment and responsibility.

xvi
About This Manual
Notice
Information in this manual is subject to change without notice and does not represent a
commitment on the part of SHARP Corporation and its sales subsidiaries.
SHARP Corporation and its sales subsidiaries shall not be liable for technical or editorial
errors or omissions contained herein; nor for incidental or consequential damages resulting
from the furnishing, performance, or use of this material.
SHARP strongly recommends that separate permanent written records be kept of all important
data. Data may be lost or altered in virtually any electronic memory product under certain
circumstances. Therefore, SHARP assumes no responsibility for data lost or otherwise
rendered unusable whether as a result of improper use, repairs, defects, battery replacement,
use after the specified battery life has expired, or any other causes.
SHARP assumes no responsibility directly or indirectly, for financial losses or claims from
third persons resulting from the use of this product and any of its functions, such as stolen
credit card numbers, the loss of or alteration of stored data, etc.
Copyright
© 2004 SHARP Corporation
This document contains or refers to proprietary information which is protected by copyright.
All rights are reserved. Copying or other reproduction of this document is prohibited without
the prior written permission of SHARP Corporation.
Trademarks
Transmeta and Efficeon are trademarks of Transmeta Corporation.
Microsoft and Windows are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries. Windows Media is a registered
trademark or trademark of Microsoft Corporation in the United States and/or other
countries.
WinDVD is a registered trademark of InterVideo, Inc.
Dolby and the double-D symbol are registered trademarks of Dolby Laboratories.
PowerQuest is a registered trademark and EasyRestore is a trademark of PowerQuest
Corporation.
BAPCo is a U.S. Registered Trademark of the Business Applications Performance
Corporation.
MobileMark is a U.S. Registered Trademark of the Business Applications Performance
Corporation.
All other brand and product names are trademarks or registered trademarks of their
respective holders.

xvii
Recording Important Information
For future reference, please record the following information in the spaces provided
below.
Model Number:
Serial Number:
Date of purchase:
Dealer’s Name:
Place of purchase:
Password:
The serial number is printed on a sticker located on the bottom of the computer.

xviii
Manual Conventions
This manual uses a set of style conventions described below.
Notes and Cautions are italicized with icons:
A note icon informs you of a special technique or information that may
help you perform a task or better understand a process.
A caution icon alerts you to something that may cause problems or
damage to hardware, software or data.
Key Labels on the Keyboard, when referred to in the instructions, are shown in
boldface:
Press Enter to continue.
When two or more keys are pressed simultaneously, the key labels are separated by a
plus (+) sign:
Run Task Manager by pressing Ctrl+Alt+Delete.
Sample Entries are shown in lower cases of different typeface.
c:\windows\system
Words/Texts on Screen, such as window titles or possible parameters, are italicized:
Double-click this icon to display the Power Options Properties dialog box.
Set the item to Enabled.
Screens reproduced in this manual may differ slightly from the screens you see on
your computer.
Section Titles in other parts of this manual are italicized:
Refer to Connecting to AC Power Source section of Chapter 1.

xix
Table of Contents
Notice for All Users....................................................................................................i
Notice for Users in the USA......................................................................................ii
Safety Precautions ....................................................................................................vi
Notice of Computer Security..................................................................................xiii
Notice of Security with Wireless Devices ...............................................................xv
About This Manual.................................................................................................xvi
Recording Important Information..........................................................................xvii
Manual Conventions.............................................................................................xviii
Table of Contents ...................................................................................................xix
Overview of Computer ..........................................................................................xxii
Basic Operations
Connecting to AC Power Source............................................................................1-1
Turning Off Your Computer ..................................................................................1-4
Choosing Power Source .........................................................................................1-4
Resetting System ....................................................................................................1-6
Using Touchpad......................................................................................................1-7
Using Keyboard......................................................................................................1-9
Using Remote Control..........................................................................................1-10
Using Optical Drive..............................................................................................1-14
Controlling Volume..............................................................................................1-21
Adjusting Display.................................................................................................1-22
Sharing Your Computer .......................................................................................1-24
Battery and Power Management
Battery Pack............................................................................................................2-1
Power Saving..........................................................................................................2-8

xx
Peripherals
Peripheral Device Ports.......................................................................................... 3-1
Optional External Floppy Disk Drive Unit ............................................................3-3
External Display.....................................................................................................3-6
Audio System......................................................................................................... 3-9
USB Device..........................................................................................................3-11
PC Card ................................................................................................................3-12
Printer................................................................................................................... 3-15
Communication Functions
Built-in Modem......................................................................................................4-1
LAN Unit ............................................................................................................... 4-5
Wireless LAN.......................................................................................................4-11
Network Setup Utility ..........................................................................................4-22
Setup Utility
Running Setup Utility ............................................................................................5-1
Main Menu .............................................................................................................5-3
Advanced Menu ..................................................................................................... 5-4
Security Menu ........................................................................................................5-4
Boot Menu..............................................................................................................5-7
Exit Menu...............................................................................................................5-7
DirectHD Function
DirectHD Utility..................................................................................................... 6-1
Connecting MP Series to Host Computer ..............................................................6-4
Disconnecting MP Series from Host Computer ..................................................... 6-6
Password Function ................................................................................................. 6-7
INSTANT PLAY
Using INSTANT PLAY.........................................................................................7-1
INSTANT PLAY Setup Menu............................................................................... 7-7
