Sharp Actius PC-AV18P User manual

1
Specifications for PC-AV18 P
Parts Specifications
CPU Low Voltage mobile AMD Athlon XP-M1800+ *1
Primary cache 128KB (Integrated in CPU)
Secondary cache 512KB (Integrated in CPU)
ROM Including system BIOS,VGA BIOS, Plug&play compliant BIOS
System DDR SDRAM 256MB, expandable up to 768MB RAM
Video 8/16/32MB (User selectable) (Default:32MB)
Panel 12.1” (30.7cm) XGA low-reflection TFT LCD
Video controller S3 Graphics ProSavage 8 (Integrated in KN266 Chipset)
Display
Resolution/color 1024 x 768 dots/16M colors by dithering function
Keyboard IBM compatible keyboard
Pointing device Glide pad (touch-sensitive control pad with 2 buttons )
Hard disk Approx. 40GB (C: Approx. 30GB, D: Approx. 10GB),
Ultra DMA 100
Floppy disk
(option/external)
USB interface 3.5”, 1.44MB/720KB
Writing CD-R: 24x (max.)
Re-writing CD-RW: 24x (max.) *3
Drive
Optical
*2
Reading CD-RW/R/ROM: 24x (max.),
DVD-ROM (single layer): 8x (max.),
DVD-ROM (double layer): 6x (max.)
PC card slot Type II ×1 (PC Card Standard) CardBus compliant
Audio system Speaker (monaural), sound system compliant with AC97 audio
Audio Audio output jack (stereo, S/PDIF compliant), external microphone
jack (monaural)
Video external display connector, S video connector
I/O ports
Others USB port x 2 (USB2.0), IEEE 1394 connector
Modem Data: 56Kbps (receive), 33.6Kbps (send), Fax: 14.4Kbps
LAN 100 BASE-TX/10 BASE-T
Radio technology IEEE802.11b compliantWireless LAN
Operating channels 11 channels
Operating system*4Microsoft® Windows® XP Professional Service Pack1
AC adapter 100-240V, 50-60 Hz
Battery Rechargeable lithium ion battery
Battery life *5Approx. 2.9 hours (standard battery pack only)
Approximately 5.8 hours (optional add-on battery pack
(CE-BL30) attached)
Battery charging time
(Charging time varies
depending on usage.)
Standard battery
pack only
Turned off/hibernation: Approx. 2.8 hours
Turned on: Approx. 6.1 hours
Power
Battery charging time
(Charging time varies
depending on usage.)
Optional add-on
battery pack
attached
Turned off/hibernation: Approx. 2.8 hours
Turned on: Approx. 6.1 hours

2
Dimensions
*No protrusion is included.
11.1" wide x 9.4" deep x 1.1" (min.)/1.2" (max.) high
(282mm x 239mm x 26.4mm(min.)/28.7mm(max.))
Optical drive installed About 4.33 lbs (1.96 kg)
Weights
Weight saver installed About 3.69 lbs (1.67 kg)
Temperature 50°F to 95°F (10°C to 35°C) Operating
environment Humidity 20% to 80% (non-condensation)
*1 Complaints with AMD PowerNow! Technology
*2 Supporting the buffer underrun protection technology which prevents the buffer underrun error occurred
when the optical drive writes too fast for the buffer to supply data or if some other application is being
used. (Buffer is the storage place of the data read from the hard drive or another media and supplies the
data to the recording media smoothly.)
*3 24x speed CD-RW writing/re-writing requires Ultra Speed CD-RW media. 10x requires High Speed CD-
RW media.
*4 This model (PC-AV18P) does not support other operating systems than the pre-installed one.
*5 Battery life is based on BAPCo® MobileMark™ 2002. Battery life will vary based on many
factors including screen brightness, applications, features, battery conditioning, power management and
other customer preferences.
TINSE3651ACZZ
