Sharp Actius PC-MV14 Owner's manual

1
Supplement for PC-MV14
Specifications………………………………………………2
Re-installation Instructions……………………………….4
ERRATA………………………………..………………….9
ADDENDUM…………………………………..…..……...12

2
Specifications
Parts Specifications
CPU Mobile Intel® Pentium® III processor featuring enhanced Intel
SpeedStep® Technology at 1.20GHz-M
Primary cache 32KB (Integrated with CPU)
Secondary cache 512KB (Integrated with CPU)
ROM Including system BIOS,VGA BIOS, Plug&play compliant BIOS
Main memory SDRAM 256MB, expandable up to 768MB RAM
Video Max. 48MB (shared with system memory)
Panel 12.1” (30.7cm) XGA low-reflection TFT LCD
Video controller Integrated with chipset
Display
Resolution/color 1024 x 768 dots/16M colors by dithering function
Keyboard IBM compatible keyboard
Pointing device Glide pad (touch-sensitive control pad with 2 buttons )
Hard disk Approx. 40GB (C: Approx. 30GB, D: Approx. 10GB),
IDE interface
Floppy disk
(option/external)
USB interface 3.5”, 1.44MB/720KB
Writing CD-R:24x (max.)
Re-writing CD-RW:10x (max.)
Drive
Optical
*1
Reading CD-RW:24x (max.), CD-R:24x (max.), CD-ROM:24x (max.),
DVD-ROM (single layer):8x (max.),
DVD-ROM (double layer):6x (max.)
PC card slot Type II ×1 (PCMCIA 2.1 compliant) CardBus compliant
Audio system Speaker (monaural), sound system compliant with AC97 audio
Audio Audio output jack (stereo, S/PDIF compliant), external microphone
jack (monaural)
Video external display connector, S video connector
I/O ports
Others USB port (USB2.0 compliant) x 2, IEEE 1394 connector,
parallel port (mini)
Modem Data: 56Kbps (receive), 33.6Kbps (send), Fax: 14.4Kbps
LAN 100 BASE-TX/10 BASE-T
Radio technology DSSS (IEEE 802.11b) compliant
Frequency band 2400-2483.5MHz
Operating channels 11 channels
Wireless LAN
Data rate 1 / 2 / 5.5 /11 Mbps
Operating system*2 Microsoft® Windows® XP Professional Service Pack 1
AC adapter 100-240V, 50-60 Hz
Battery Rechargeable lithium ion battery
Battery life *3 Approx. 3.8 hours (standard battery pack only)
Approximately 7.6 hours (optional add-on battery pack
(CE-BL20) attached)
Battery charging time
(Charging time varies
depending on usage.)
Standard battery
pack only
Turned off/hibernation: Approx. 2.7 hours
Turned on: Approx. 4.5 hours
Power
Battery charging time
(Charging time varies
depending on usage.)
Optional add-on
battery pack
attached
Turned off/hibernation: Approx. 5.5 hours
Turned on: Approx. 9.0 hours

3
Dimensions
*No protrusion is included.
11.1" wide x 9.4" deep x 1.04" (min.)/1.13" (max.) high
(282mm x 239mm x 26.4mm(min.)/28.7mm(max.))
Optical drive installed About 4.21 lbs (1.91 kg)
Weights
Weight saver installed About 3.77 lbs (1.71 kg)
Temperature 50°F to 95°F (10°C to 35°C) Operating
environment Humidity 20% to 80% (non-condensation)
*1 Supporting the buffer underrun protection technology that prevents the buffer underrun error occurred
when the optical drive writes too fast for the buffer to supply data or if some other application is being
used. (Buffer is the storage place of the data read from the hard drive or another media and supplies the data
to the recording media smoothly.)
*2 This model (PC-MV14) does not support other operating systems than the pre-installed one.
*3 Battery life is based on BAPCo® MobileMark™ 2002. Battery life will vary based on many
factors including screen brightness, applications, features, battery conditioning, power management and
other customer preferences.

4
Re-installation Instructions
To recover your hard disk, you will use PowerQuest®EasyRestore™. Before starting re-
installation, read the following End User License Agreement first.
PowerQuest(R) EasyRestore (TM) End User License Agreement
IMPORTANT: Read this before using your copy of PowerQuest software.
This document is a legal agreement between you, the "end user," and PowerQuest Corporation. Use of the
software indicates your acceptance of these terms. As used in this License Agreement, the term "Software"
means the EasyRestore software included on the CD provided with this License Agreement.
1. PROPRIETARY RIGHTS. The Software is a proprietary product of PowerQuest Corporation
("PowerQuest") or its licensors and is protected under U.S. copyright laws and international treaty
provisions. Ownership of the Software and all copies, modifications, and merged portions thereof shall at
all times remain with PowerQuest or its licensors.
2. GRANT OF LICENSE. The Software is being licensed to you, which means you have the right to use the
Software only in accordance with this License Agreement. The Software contains pre-installed software for
disaster recovery purposes. The Software is only authorized for distribution together with a specific
computer. This License authorizes you to use the Software for disaster recovery purposes only, to restore
the hard disk image contained on the CD to the computer with which the CD and Software were originally
shipped.
3. NONPERMITTED USES. Without the express permission of PowerQuest, you may not (a) use, copy,
modify, alter, or transfer, electronically or otherwise, the Software or documentation except as expressly
permitted in this License Agreement, or (b) translate, reverse program, disassemble, decompile, or
otherwise reverse engineer the Software.
4. TECHNICAL SUPPORT. PowerQuest is NOT responsible to provide technical support. Any and all
technical support questions, regarding the Software, should be referred to the place of purchase.
5. U.S. GOVERNMENT RESTRICTED RIGHTS. If you are acquiring the Software on behalf of any unit
or agency of the United States Government, the following provision applies: It is acknowledged that the
Software and the documentation were developed at private expense and that no part is in the public domain
and that the Software and documentation are provided with RESTRICTED RIGHTS. Use, duplication, or
disclosure by the Government is subject to restrictions as set forth in subparagraph (c)(1)(ii) of the Rights in

5
Technical Data and Computer Software clause at DFARS 252.227-7013or subparagraphs (c)(1) and (2) of
the Commercial Computer Software-Restricted Rights at 48 CFR 52.227-19, as applicable.
Contractor/manufacturer is PowerQuest Corporation/P.O. Box 1911/Orem, UT 84059.
6. NO WARRANTY. The Software is being provided to you AS IS. PowerQuest does not warrant the
Software to end users. If the Software fails to perform substantially in accordance with the documentation
provided to your hardware supplier, PowerQuest will repair or replace the copy of the Software provided to
your hardware supplier and will authorize your hardware supplier to provide such repaired or replaced
Software to you without charge.
7. LIMITATION OF LIABILITY. NEITHER POWERQUEST NOR ITS SUPPLIERS SHALL IN ANY
EVENT BE LIABLE FOR ANY DAMAGES WHATSOEVER ARISING OUT OF OR RELATED TO
THE USE OF OR INABILITY TO USE THE SOFTWARE, INCLUDING BUT NOT LIMITED TO
DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, AND
DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, LOSS OF BUSINESS
INFORMATION, OR OTHER PECUNIARY LOSS, EVEN IF POWERQUEST CORPORATION HAS
BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES, WHETHER SUCH LIABILITY IS
BASED ON CONTRACT, TORT, WARRANTY, OR ANY OTHER LEGAL OR EQUITABLE
GROUNDS. BECAUSE SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF
LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES, THE ABOVE LIMITATION
MAY NOT APPLY TO YOU.
8. NO WAIVER. Any failure by either party to this agreement to enforce a specific part of the agreement in
a specific situation is not a waiver of rights under the agreement. The party may still enforce the rest of the
agreement in that situation and may still enforce some or all of the agreement in other situations.
9. This License Agreement constitutes the entire agreement between you and PowerQuest pertaining to its
subject matter. This License Agreement is governed by the laws of the State of Utah. Any litigation arising
from this license will be pursued only in the state or federal courts located in the State of Utah.
Copyright 1994-2003, PowerQuest Corporation. All rights reserved. U.S. Patents 5,675,769; 5,706,472; and
5,930,831; other patents pending in the U.S.A. and elsewhere. PowerQuest is a registered trademark and
EasyRestore is a trademark of PowerQuest Corporation.

6
Preparation for Re-installation
You can format the hard disk and re-install the preinstalled software with the provided
recovery CD-ROMs, and set the status of your computer to the same configuration as
shipped from the factory. The following items are necessary for re-installation:
• Product Recovery CD-ROMs
• Supplement for PC-MV14 (this booklet)
• Operation Manual
• It will take about 15 minutes to complete the re-installation.
• Use the Product Recovery CD-ROMs only for your computer.
• The Product Recovery CD-ROMs are not for sale. Keep them in a
secure place.
• Unless otherwise specified, the instructions in this booklet assume
that you are installing Windows XP into the C:\WINDOWS directory.
Backing up the data
Before formatting the hard disk, you should back up your data. For details on how to
back up your data, see the Windows Online Help.
Selecting the way to recover your system
Your computer has two drives (C: and D:) in its hard disk when it was shipped from
the factory. You can select the way to recover your system.
• Recovers C: drive only. (Recommended)
This process will format C: drive only and recover C: drive to the same status as
shipped from the factory. Nothing will be done to D: drive. The volume of the
drives will not be changed and current ones will be kept.
• Recovers both C: and D: drive.
This process will format both C: and D: drives, and contents of the hard disk are
restored to its original state in C: drive. The volume of the drives will be back to
the same as shipped from the factory.
• Formats hard disk and creates new partition.
This process will format the whole hard disk drive and creates a new partition. You
can select the volume of C: and D: drives. The contents of the hard disk are
restored to its original state in C: drive.

7
Formatting the drives and re-installing Windows XP
1. Make sure the computer is turned off.
2. If any peripheral devices are connected to your computer, disconnect them.
3. If the weight saver is installed in your computer, remove it and install the
optical drive
4. Connect the AC adapter; then, turn on the computer.
Be sure to connect the AC adapter. If the battery power becomes
significantly low, the installation process will be canceled.
5. When the message Press <F2> to enter SETUP appears, press F2. The Setup
Utility will open.
6. Insert the Product Recovery CD-ROM disk 1 into the optical drive.
7. In the Exit menu, select Load Setup Defaults; then, press Enter twice.
8. In Boot Sequence of the Boot menu, set CD-ROM Drive to the top of the list;
then, press Esc.
9. In the Exit menu, confirm Exit Saving Changes is highlighted and press Enter
twice. The system will restart.
10. Read the message on the screen, and select the way to recover your system;
then, press Enter.If you select Formats hard disk and creates new partition, go
to the next step. Otherwise, go to Step 12.
11. Select the volume of C: drive and press Enter.
12. Read the message and select Continue; then, press Enter.
Although the pointer may be shown on the screen, never touch the
keyboard or the glide pad during recovery except when the message
prompts you to. If you touch them, the re-installation will be canceled.
13. If you see the message asking you to replace the CD-ROM, remove the Product
Recovery CD-ROM disk 1 and insert the Product Recovery CD-ROM disk 2;
then, click OK.
14. If you see the message asking you to replace the CD-ROM, remove the Product
Recovery CD-ROM disk 2 and insert the Product Recovery CD-ROM disk 3;
then, click OK

8
15. When the re-installation process is completed, the system will restart
automatically.
16. When the message Press <F2> to enter SETUP appears, press F2. The Setup
Utility will open.
17. In the Exit menu, select Load Setup Defaults; then, press Enter twice.
18. In the Exit menu, confirm Exit Saving Changes is highlighted and press Enter
twice. The system will restart.
19. Set up Windows XP by following the instructions on the screen. When you
finish the setup, the recovery is completed. Make sure to set date and time and
remove the Product Recovery CD-ROM disk 3.

9
ERRATA
This section contains up date details of the provided operation manual. Please replace
any relevant sections of the manual as mentioned below.
Chapter 2 page6
(old) Special Keys (new) Special Keys
Windows Key Windows Key
Application Key Application Key
Chapter 2 page7
(old) CAUTION FOR LASER: Maximum output and wavelength of the laser:
144mW, 784nm(CD-R/RW)
(new) CAUTION FOR LASER: Maximum output and wavelength of the laser:
108mW, 784nm(CD-R/RW)
Chapter 2 page17
(old) (*1) Only 1024x768 dots appear even on the internal LCD screen of ……of
Monitor tab.
(new) (*1) Can be chosen for an external monitor only when it is capable of the
listed resolution modes. Cannot be set when displaying only on the LCD
monitor and on the LCD and the external monitor simultaneously.
Chapter 5 page9
(old) whole section of Confirming the Status of the Wireless Connection
(new)
Confirming the Status of the Wireless Connection
Before performing the following instructions, confirm the devices that you want to
communicate with are enabled for wireless LAN.
1. Click Wireless Network Connection icon ( or ) on the taskbar. If you
cannot find the icon click to show all kinds of icon. Wireless Network

10
Connection dialog box will appear. If Wireless Network Connection Status
dialog box appears, go to Step 7. If not, go to the next step.
2. Select a network you want to access in Available wireless networks in Wireless
Network Connection dialog box. If the network requires the Network key entered,
go to Step 4. If it is not set Network key, the caution message will appear.
When the network name you want to access does not appear, click
Advanced tab; then, Refresh button of Available networks in Wireless
Network Connection Properties dialog box; then, click OK.
3. When you agree with the message, check the box of Allow me to connect… and
go to Step 5.
4. Type the required Network key. (Refer to Connecting the WEP configured
network section.)
5. Click Connect button.
6. Click Wireless Network Connection icon ( ) on the taskbar.
7. In Wireless Network Connection Status dialog box, confirm your connection
status.
• The number of green signals ( ) shows the connection quality. The
more signals light on, the better quality is given to the computer.
• When the quality of connection is poor, adjust the distance between the
computer and other devices or the access point you are communicating
with and/or the facing direction of the computer.
Chapter 5 page9-10
(old) whole section of Connecting the WEP configured network
(new)
Connecting the WEP configured network
Wireless communication has security issues. Some networks are configured with
WEP (Wired Equivalent Privacy) keys or encryption keys to protect the transmitted
data. To connect into the WEP configured network, follow the steps below.
1. Right-click Wireless Network Connection icon ( ) on the taskbar and click
View Available Wireless Networks.
2. Select the network you want to connect in Available wireless networks of
Wireless Network Connection dialog box.
3. Type its encryption key in Network key field, type it again to confirm and click
Connect button.

11
• When you select a network that is not configured for encryption
settings in the step 2, the caution message will appear. If you agree to
connect to the unsecured network, check the box of Allow me to
connect to the selected wireless network, even though it is not secure.
• When the key index of your computer is different from that of the
network, you cannot access the network. Set the same key index with
the following steps. Note that some access points have the key index
options 0 through 3. Refer to the table below for matching.
1. Open the Wireless Network Connection Properties dialog box.
(Refer to the steps in Communicating with Other Computer
section.)
2. Select the network you want to access in Preferred networks section
and click Properties button.
3. Confirm the box of Data encryption (WEP enabled) is checked,
uncheck the box of The key is provided for me automatically and
set the key index.
Key index matching table
Access Point 1 Access Point 2 Your Computer
1 0 1
2 1 2
3 2 3
4 3 4
(ex. When your access point type is “Access Point 2”
and its key index is set to 0, set 1 to the key index of
your computer.)
Chapter 6 page 3
(old) USB key/Mouse Emulation defines whether USB devices (Keyboard or
mouse) can be used in MS-DOS mode.
(new) C3 State defines whether the system reduces power consumption while the
CPU is idling.
Chapter 6 page7
(old) USB FDD defines whether …….an operating system supporting USB.)
(new) USB FDD defines whether the system boots from the USB floppy disk drive.
When you set this item to Enabled, the system boots accordingly to the order set
in the Boot Sequence field. When you set it to Disabled, the system does not
boot from the USB floppy disk drive.

12
Troubleshooting page6 (the third line from the bottom)
(old) Remove MATSHITA UJDA730 DVD/CD-RW Drive (E:)
(new) Remove MATSHITA UJDA740 DVD/CD-RW Drive (E:)
Troubleshooting page8 (the last line)
(old) 2. Select the desired network in the Available networks list; then, Click
Connect button.
(new) 2. Select the desired network in the Available wireless networks list; then,
connect to the networks. (Refer to Confirming the Status of the Wireless
Connection section on page 9 of this supplement.)
ADDENDUM
This section provides some additional information.
Troubleshooting
Question: Why can't I connect to the network via an access point?
• You may accidentally enable IEEE802.1x authentication. Disable it with the
following steps.
1. Click start – Control Panel.
2. Click Network and Internet Connections – Network Connections. If Classic
view is selected, double-click Network Connections.
3. Right-click Wireless Network Connection and click Properties.
4. Click Wireless Networks tab, select the network in Preferred networks field and
click Properties button.
5. Select Authentication tab, then, uncheck the box of Enable IEEE802.1x
authentication for this network.
6. Click OK twice and close the window.
TINSE3517ACZZ
