Sharp Aquos LC 45GD7U User manual

LC-45GD7U
SERVICE MANUAL
LCD COLORTELEVISION
MODEL LC-45GD7U
In the interests of user-safety (Required by safety regulations in some countries) the set should be restored
to its original condition and only parts identical to those specified should be used.
CONTENTS Page
»LIST OF CHANGED PARTS ...........................................................................................................................2
»IMPORTANT SERVICE SAFETY PRECAUTION ........................................................................................3
»SPECIFICATIONS........................................................................................................................................6
»OPERATION MANUAL ................................................................................................................................7
»DIMENSIONS ............................................................................................................................................14
»REMOVING OF MAJOR PARTS................................................................................................................15
»PARTS LIST ...............................................................................................................................................18
»PACKING OF THE SET .............................................................................................................................23
OUTLINE
This model is based on the LC-45GD5U and is equipped with a redesigned speaker.This Service Manual
covers the modifications alone. For the other points, refer to the LC-45GD5U Service Manual.
SY5Q4LC45GD7U
SHARP CORPORATION This document has been published to be used for
after sales service only.
The contents are subject to change without notice.

2
LC-45GD7U
LIST OF CHANGED PARTS
Ref.No. Description LC-45GD5U LC-45GD7U Note
PWB ASSEMBLIES
AC INPUT Unit DUNTKD154VJ03 
DIGITAL TUNER Unit DKEYDD392VJ12 DKEYDD392VJ11 No parts changed
MAIN Unit DUNTKD393VJ03 DUNTKD393VJ02 Some parts changed
AV Unit DUNTKD405UJ02 DUNTKD405UJ01 No parts changed
KEY Unit DUNTKD406UJ02 DUNTKD406UJ01 No parts changed
R/C, LED Unit DUNTKD407UJ02 DUNTKD407UJ01 Some parts changed
SPEAKER TERMINAL-L Unit DUNTKD408UJ02 DUNTKD408UJ01 No parts changed
SPEAKER TERMINAL-R Unit DUNTKD409UJ02 DUNTKD409UJ01 No parts changed
BUS CONNECT Unit DUNTKD410UJ02 DUNTKD410UJ01 No parts changed
POWER SUPPLY Unit RDENCA142WJQZ 
LCD PANEL
45”Wide LCD Panel Unit RLCUCA015WJZZ 
MAIN Unit
R2369 Metal Oxide  VRS-CY1JF223JY *Add
R2370 Metal Oxide VRS-CY1JF223JY  *Delete
R/C, LED Unit
J2401 Jack QJAKJA014WJZZ QJAKJA009WJSA *Change
CABINET AND MECHANICAL PARTS
Please refer to a Parts list.
PACKING PARTS AND ACCESSORIES
Please refer to a Parts list.

3
LC-45GD7U
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121
2
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121
2
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121
2
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121
2
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212
SAFETY NOTICE
Many electrical and mechanical parts in LCD color
television have special safety-related characteristics.
These characteristics are often not evident from visual
inspection, nor can protection afforded by them be
necessarily increased by using replacement components
rated for higher voltage, wattage, etc.
Replacement parts which have these special safety
characteristics are identified in this manual; electrical
components having such features are identified by "å"
and shaded areas in the Replacement Parts List and
Schematic Diagrams.
For continued protection, replacement parts must be
identical to those used in the original circuit.
The use of a substitute replacement parts which do not
have the same safety characteristics as the factory
recommended replacement parts shown in this service
manual, may create shock, fire or other hazards.
CAUTION:
FOR CONTINUED PROTECTION
AGAINST A RISK OF FIRE REPLACE
ONLY WITH SAMETYPE FUSE.
F7003 (2A, 250V), F7801 (8A, 250V)
WARNING
1. For continued safety, no modification of any circuit
should be attempted.
2. Disconnect AC power before servicing.
BEFORE RETURNINGTHE RECEIVER
(Fire & Shock Hazard)
Before returning the receiver to the user, perform
the following safety checks:
1. Inspect all lead dress to make certain that leads are
not pinched, and check that hardware is not lodged
between the chassis and other metal parts in the
receiver.
2. Inspect all protective devices such as non-metallic
control knobs, insulation materials, cabinet backs,
adjustment and compartment covers or shields,
isolation resistor-capacitor networks, mechanical
insulators, etc.
3. To be sure that no shock hazard exists, check for
leakage current in the following manner.
»Plug the AC cord directly into a 120 volt AC outlet.
»Using two clip leads, connect a 1.5k ohm, 10 watt
resistor paralleled by a 0.15µF capacitor in series
with all exposed metal cabinet parts and a known
earth ground, such as electrical conduit or electrical
ground connected to an earth ground.
»Use an AC voltmeter having with 5000 ohm per volt,
or higher, sensitivity or measure the AC voltage drop
across the resistor.
»Connect the resistor connection to all exposed metal
parts having a return to the chassis (antenna, metal
cabinet, screw heads, knobs and control shafts,
escutcheon, etc.) and measure the AC voltage drop
across the resistor.
All checks must be repeated with the AC cord plug
connection reversed. (If necessary, a nonpolarized
adaptor plug must be used only for the purpose of
completing these checks.)
Any reading of 0.75 Vrms (this corresponds to 0.5
mA rms AC.) or more is excessive and indicates a
potential shock hazard which must be corrected
before returning the monitor to the owner.
IMPORTANT SERVICE SAFETY PRECAUTION
ËService work should be performed only by qualified service technicians who are thor-
oughly familiar with all safety checks and the servicing guidelines which follow:
DVM
AC SCALE
1.5k ohm
10W
TO EXPOSED
METAL PARTS CONNECT TO
KNOWN EARTH
GROUND
0.15 µF
TEST PROBE
A V

4
LC-45GD7U
PRECAUTION:
POUR LA PROTECTION CONTINUE
CONTRE LES RISQUES D'INCENDIE,
REMPLACER LE FUSIBLE
F7003 (2A, 250V), F7801 (8A, 250V)
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121
2
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121
2
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121
2
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212
AVIS POUR LA SECURITE
De nombreuses pièces, électriques et mécaniques, dans
les téléviseur ACL présentent des caractéristiques
spéciales relatives àla sécurité, qui ne sont souvent
pas évidentes àvue. Le degréde protection ne peut
pas être nécessairement augmentée en utilisant des
pièces de remplacement étalonnées pour haute tension,
puissance, etc.
Les pièces de remplacement qui présentent ces
caractéristiques sont identifiées dans ce manuel; les
pièces électriques qui présentent ces particularités sont
PRECAUTIONS A PRENDRE LORS DE LA REPARATION
ËNe peut effectuer la réparation qu' un technicien spécialisé qui s'est parfaitement
accoutumé à toute vérification de sécurité et aux conseils suivants.
identifiées par la marque "å" et hachurées dans la liste
des pièces de remplacement et les diagrammes
schématiques.
Pour assurer la protection, ces pièces doivent être
identiques àcelles utilisées dans le circuit d'origine.
L'utilisation de pièces qui n'ont pas les mêmes
caractéristiques que les pièces recommandées par
l'usine, indiquées dans ce manuel, peut provoquer des
électrocutions, incendies, radiations X ou autres
accidents.
AVERTISSEMENT
1. N'entreprendre aucune modification de tout circuit.
C'est dangereux.
2. Débrancher le récepteur avant toute réparation.
VERIFICATIONS CONTRE L'INCEN-DIE ET
LE CHOC ELECTRIQUE
Avant de rendre le récepteur à l'utilisateur, effectuer
les vérifications suivantes.
1. Inspecter tous les faisceaux de câbles pour s'assurer
que les fils ne soient pas pincés ou qu'un outil ne soit
pas placéentre le châssis et les autres pièces
métalliques du récepteur.
2. Inspecter tous les dispositifs de protection comme les
boutons de commande non-métalliques, les isolants,
ledos ducoffret, les couverclesoublindagesderéglage
et de compartiment, les réseaux de résistance-
capacité, les isolateurs mécaniques, etc.
3. S'assurer qu'il n'y ait pas de danger d'électrocution en
vérifiant la fuite de courant, de la facon suivante:
•Brancher le cordon d'alimentation directem-ent àune
prise de courant de 120V. (Ne pas utiliser de
transformateur d'isolation pour cet essai).
•A l'aide de deux fils àpinces, brancher une résistance
de 1.5 kΩ10 watts en parallèle avec un condensateur
de 0.15µF en série avec toutes les pièces métalliques
exposées du coffret et une terre connue comme une
conduite électrique ou une prise de terre branchée à
la terre.
•Utiliser un voltmètre CA d'une sensibilitéd'au moins
5000Ω/V pour mesurer la chute de tension en travers
de la résistance.
•Toucher avec la sonde d'essai les pièces métalliques
exposées qui présentent une voie de retour au châssis
(antenne, coffret métallique, tête des vis, arbres de
commande et des boutons, écusson, etc.) et mesurer
la chute de tension CA en-travers de la résistance.
Toutes les vérifications doivent être refaites après avoir
inversélafiche ducordond'alimentation.(Sinécessaire,
une prise d'adpatation non polarisée peut être utilisée
dans le but de terminer ces vérifications.)
Tous les courants mesurés ne doivent pas dépasser
0.5 mA.
Dans le cas contraire, il y a une possibilitéde choc
électrique qui doit être supprimée avant de rendre le
récepteur au client.
DVM
ECHELLE CA
1.5k ohm
10W
0.15 µF
SONDE D'ESSAI
AUX PIECES
METALLIQUES
EXPOSEES
BRANCHER A UNE
TERRE CONNUE
A V

5
LC-45GD7U
Precautions for using lead-free solder
1 Employing lead-free solder
"PWBs" of this model employs lead-free solder.The LF symbol indicates lead-free solder, and is attached on the
PWBs and service manuals.The alphabetical character following LF shows the type of lead-free solder.
Example:
2 Using lead-free wire solder
When fixing the PWB soldered with the lead-free solder, apply lead-free wire solder. Repairing with conventional
lead wire solder may cause damage or accident due to cracks.
As the melting point of lead-free solder (Sn-Ag-Cu) is higher than the lead wire solder by 40°C, we recommend
you to use a dedicated soldering bit, if you are not familiar with how to obtain lead-free wire solder or soldering bit,
contact our service station or service branch in your area.
3 Soldering
As the melting point of lead-free solder (Sn-Ag-Cu) is about 220°C which is higher than the conventional lead
solder by 40°C, and as it has poor solder wettability, you may be apt to keep the soldering bit in contact with the
PWB for extended period of time. However, since the land may be peeled off or the maximum heat-resistance
temperature of parts may be exceeded, remove the bit from the PWB as soon as you confirm the steady soldering
condition.
Lead-free solder contains more tin, and the end of the soldering bit may be easily corroded.Make sure to turn on
and off the power of the bit as required.
If a different type of solder stays on the tip of the soldering bit, it is alloyed with lead-free solder.Clean the bit after
every use of it.
When the tip of the soldering bit is blackened during use, file it with steel wool or fine sandpaper.
Be careful when replacing parts with polarity indication on the PWB silk.
Indicates lead-free solder of tin, silver and copper.
Lead-free wire solder for servicing
Part No, ★Description Code
ZHNDAi123250E J φ0.3mm 250g(1roll) BL
ZHNDAi126500E J φ0.6mm 500g(1roll) BK
ZHNDAi12801KE J φ1.0mm 1kg(1roll) BM
LFa

6
LC-45GD7U
SPECIFICATIONS
Item Model: LC-45GD7U
TV
Function
American TV Standard ATSC/NTSC System
VHF/UHF VHF 2-13ch, UHF 14-69ch
CATV 1-125ch
Audio multiplex BTSC System
Terminals AV in, COMPONENT in
INPUT 2 AV in, COMPONENT in
INPUT 4 HDMI in (Type-A) with HDCP
ANALOG ANTENNA 75 Unbalance, F Type for VHF/UHF/CATV in 1
INPUT 3 S-VIDEO in, AV in
OSD language English/French/Spanish/Portuguese
Power Requirement AC 120 V, 60 Hz for North America
AC 110 240 V, 50/60Hz for others
Power Consumption
Weight
Accessories Operation manual ( 1), Remote control unit ( 1), AC cord ( 1), "AAA" size
battery ( 2), Cable clamp ( 1), G-LINK cable ( 1), Cable tie ( 1)
TV-standard (CCIR)
Receiving
Channel
Rear INPUT 1
As part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement
without prior notice. The performance specification figures indicated are nominal values of production units. There may be some
deviations from these values in individual units.
LCD panel 45" Advanced Super View & BLACK TFT LCD
Number of dots 6,220,800 dots (1920 1080 3 dots)
Brightness 450 cd/m2
Backlight Life 60,000 hours (at Backlight Standard position)
Viewing angles H : 170oV : 170o
Audio out 10W 2
MONITOR/REC OUT S-VIDEO out, AV out
300 W
60.6 lbs./27.5 kg
G-LINK 3.5mm jack
INPUT 5 Audio in, DVI-I in with HDCP
Digital Terrestrial
Broadcast (8VSB)
2-69ch
Digital cable
(64/256 QAM)
1-135ch
DIGITAL ANTENNA 75 Unbalance, F Type 2 (for Digital Air 1/Digital Cable in 1)
DIGITAL AUDIO OUTPUT
Optical Digital audio output 1 (PCM/Dolby Digital)
i.LINK IEEE1394 2 with DTCP
CableCARD slot 68 pin PCMCIA 1
TV only
79.4 lbs./36.0 kg
TV with speaker and stand
68.3 lbs./31.0 kg
TV with speaker
Headphones 3.5mm jack Front
Dimension
(W H D) (in inches)
439/64 311/21131/32 (TV stand speaker)
Operating temperature 32oF to 104oF (0oC to 40oC)
439/64 293/64 4
31/64 (TV speaker)
439/64 311/21131/32 (TV stand)
439/64 2525/32 4
31/64 (TV only)
×
×
×
×
×
××
××
××
××
××
×× ××
××
×
×
×
××
×
Ω
Ω
_
++
+
+
++ +

7
LC-45GD7U
OPERATION MANUAL
Part names
TV (Front) TV (Rear)
POWER button
INPUT button*
Volume buttons (VOL / ) Channel
buttons**
(CH / )
* INPUT button works as
ENTER in TV Guide On
Screen
** Channel buttons work as
/ in TV Guide On
Screen
POWER indicator
OPC sensor
Remote control sensor
OPC indicator
DL indicator
SLEEP indicator
Headphone jack
*Press RESET if the TV cannot return to its original state after performing various operations.
AV MODE resets to DYNAMIC (Fixed)
TV channel returns to initial channel (Air:2ch, Cable:1 or 2ch)
Audio setting initializes
Dolby Virtual resets to off
Image position initializes
**Press SYSTEM RESET if the TV does not operate after starting up.
NOTE
Pressing RESET will not work if the TV is in standby mode.
INPUT 2
terminals
MONITOR OUT/
REC OUT terminals
i.LINK terminals
CableCARD
TM
slot
G-LINK terminal
DIGITAL AIR
IN terminal
RESET*
INPUT 3
terminals
SYSTEM
RESET**
ANALOG IN
terminal
AC INPUT terminal
RS-232C terminal
INPUT 1
terminals
INPUT 5 terminals
INPUT 4 terminal
DIGITAL AUDIO
OUTPUT terminal
DIGITAL
CABLE IN
terminal

8
LC-45GD7U
P Using external equipmentart names
Remote control unit
2
3
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
117
4
5
6
7
8
9
11
12
13
14
15
16
10
6AIR:Receives air signal.
7 CABLE: Receives cable signal.
8VOL/: Sets the volume.
9Virtual:Selects Virtual Dolby Surround settings.
10 INFO:
Displays the program information screen.
11 RECORD:
Records the program to equipment (capable of
recording).
In TV Guide On Screen, initiates the recording process.
12 EXIT: Turns off the menu screen and TV Guide On
Screen.
13 FAVORITE CH
A, B, C, D: Selects four preset favorite channels in four
different categories.
While watching, you can toggle the selected channels
by pressing A, B, C and D.
DAY /DAY :In TV Guide On Screen, moves forward
or backward in 24 hour increments in the listing grid.
14 AUDIO: Selects the MTS/SAP or the audio mode during
multi-channel audio broadcasts.
15 SLEEP: Sets the sleep timer.
16 i.LINK: Displays the i.LINK panel.
17 FUNCTION: Switches the remote control for TV, CBL/
SAT, VCR, DVD and AUDIO operation. Indicator lights
up for the current mode.
* To enter the code registration mode, you need to press
FUNCTION and DISPLAY at the same time.
18 LIGHT :When pressed all buttons on the remote
control unit will light. The lighting will turn off if no
operations are performed within about 5 seconds. This
button is used for performing operations in low-light
situations.
19 VIEW MODE: Selects the screen size.
20 ENT: Enters a channel selection when choosing with
the 0-9 buttons.
21 FLASHBACK: Returns to the previous channel or
external input mode.
22 INPUT: Selects a Liquid Crystal Television input source.
(TV, CableBox, INPUT 1, INPUT 2, INPUT 3, INPUT 4,
INPUT 5, i.LINK)
If the CableBox is set up in the TV Guide On Screen
setting menu, the CableBox option appears.
23 CH / : Selects the channel.
In the TV Guide On Screen, moves one page up or one
page down in the LISTINGS grid.
24 MUTE: Mutes the sound.
25 TV GUIDE: Displays TV Guide On Screen.
26 MENU: Displays the menu screen.
27 ////ENTER: Selects a desired item on the
screen.
28 RETURN: Returns to the previous menu screen.
29 FREEZE: Sets the still image. Press again to return to
normal screen.
30 CC: Displays captions when receiving closed-caption
signals.
31 EDIT: Registers favorite channel.
32 AV MODE: Selects an audio or video setting.
(AV mode: STANDARD, MOVIE, GAME,
USER, DYNAMIC (Fixed), DYNAMIC. PC mode:
STANDARD, USER.)
1TVPOWER: Switches the Liquid Crystal Television
power on or enters Standby mode.
2 DISPLAY: Displays the channel information.
3 SOURCE POWER: Turns the power of the external
equipment on and off.
4 External equipment operational buttons: Operates
the external equipment.
5 0 9/ (DOT): Sets the channel.
_
You can connect many types of external equipment to your TV, like a DVD player, VCR, Digital TV tuner, PC,
HDMI equipment, game console and camcorder. To view external source images, select the input source from
INPUT on the remote control unit or on the TV.
CAUTION
To protect all equipment, always turn off the TV before
connecting to a DVD player, VCR, Digital TV tuner, PC,
HDMI equipment, game console, camcorder or other
external equipment.
NOTE
Please refer to the relevant operation manual (DVD player,
PC, etc.) carefully before making connections.
Each time INPUT is pressed, the input source toggles.
Refer to your external equipment operation manual for
the signal type.
Displaying an external equipment image
Explanation here is for the setting when connecting
DVD to INPUT1 terminal.
To watch a DVD image, select "INPUT1" from "INPUT
SOURCE" menu using INPUT on the remote control
unit or on the TV.
INPUT SOURCE
TV
CableBox [TV]
INPUT1
INPUT2
INPUT3
INPUT4
INPUT5INPUT5
i.LINK
1
MENU
[Option ... Input Select]
Auto
COMPONENT
VIDEO
For INPUT1 signal
Select the desired signal type.
The setting is stored and can be selected on the
"INPUT SOURCE" menu.
Press MENU and the MENU screen displays.
2
3
Press / to select "Input Select", and then
press ENTER.
4
Press / to select "Option".
MENU
[Option ... Input Select]
Option
Input Select
Digital Noise Reduction
Output Select
Audio Only
Quick Shoot
[Fixed]
[Auto]
[Low]
[Off]
Caption Setup
Program Title Display [No]
NOTE
If the image does not come in clearly, you may need to
change the input signal type setting on the "Input Select"
menu.
Selecting the INPUT signal

9
LC-45GD7U
Using external equipment
Connecting a DVD player
You can use the INPUT 1, INPUT 2, INPUT 4 or INPUT 5 terminals when connecting to a DVD player and other
audiovisual equipment.
DVD player
Component
video cable
(commercially
available)
Audio cable
(commercially
available)
AV cable (commercially
available)
DVD player
3.5 mm stereo minijack cable
(commercially available) DVI cable (Commercially available)
When using component cable.
When using composite cable.
When using DVI cable. (INPUT 5)
DVD player
VCR
AV cable
(commercially
available)
Connecting aVCR
You can use the INPUT 3 terminal when connecting a VCR and other audiovisual equipment.
Game console/Camcorder
S-video cable
(commercially available)
Connecting a game console or camcorder
A game console, camcorder and some other audiovisual equipment are conveniently connected using the
INPUT 3 terminals.
NOTE
The S-video terminal has priority over the video terminals.
The G-LINK cable connection is necessary if you want to use the recording features of the TV Guide On Screen system
with your VCR.
AV cable
(commercially
available)
S-video cable
(commercially
available)
NOTE
The S-video terminal has priority over the video terminals.
This connection is
necessary when
using TV Guide On
Screen's recording
function.
(commercially
available)
(INPUT)(OUTPUT)
G-LINK cable
G-LINK
cable
This end is connected
to the TV.
1 inch
VCR
G-LINK wand
NOTE
When attempting to record copy protected material on a VCR or other recording device, the copy protection will activate
and the protected material will not be recorded correctly. In addition, attempting to display copy protected material on a
monitor connected via a VCR, whether for the purpose of viewing or not, will cause an inferior quality picture to be
displayed. This is not a fault of the equipment. Please view copy protected material by connecting the product directly to
the monitor.

10
LC-45GD7U
Using external equipment
Connecting a DigitalTV STB (Air or Cable)
You can use the INPUT 1, INPUT 2, INPUT 4 or INPUT 5 terminals when connecting a Digital TV STB (Air or
Cable) and other audiovisual equipment.
DigitalTV STB
Component video
cable
(commercially
available)
Audio cable
(commercially
available)
AV cable
(commercially
available)
DigitalTV STB
DigitalTV STB
3.5 mm stereo minijack cable
(commercially available)
DVI cable
(commercially available)
When using component cable.
When using composite cable.
When using DVI cable. (INPUT 5)
NOTE
If your cable-TV company has CableCARD security module available, you can also use the CableCARD security module
to receive HDTV programs.
G-LINK cable
Cable box connection
(forTV Guide On Screen)
NOTE
To receive TV program listings in the TV Guide On Screen system, please connect your cable box
using this input, marked "VIDEO". Do not connect the cable box to the "COMPONENT" video as you
will not receive any TV program listings.
G-LINK
cable
This end is connected
to the TV.
1 inch
Cable Box
G-LINK wand
Connecting HDMI equipment
Please use the INPUT 4 terminal when connecting HDMI equipment.
HDMI equipment
HDMI cable
(commercially available)
Displaying an image from HDMI equipment
To watch an HDMI equipment image, select
"INPUT4" from "INPUT SOURCE" menu
using INPUT on the remote control unit or
on the TV.
INPUT SOURCE
TV
CableBox [TV]
INPUT1
INPUT2
INPUT3
INPUT4
INPUT5INPUT5
i.LINK
1
Press MENU and the MENU screen displays.
2
3
Press / to select "HDMI Setup", and then
press ENTER.
4
Press / to select "Option".
MENU
[Option ... HDMI Setup]
Option
Digital Noise Reduction
Audio Only
HDMI Setup
[Low]
5
Press / to select the desired item and
press ENTER.
Press / / / to select the desired setting
and press ENTER.
6
NOTE
Refer to your external equipment operation manual for
the signal type.
Selectable items
Auto/RGB/YCbCr
4:4:4/YCbCr 4:2:2
Auto/ITU601/
ITU709
Standard/
Out of Standard
Enable/Disable
HDMI Setup
items
Signal
Type
Color
Matrix
Dynamic
Range
Auto View
Description
Select the signal type from
an HDMI terminal. Unless
the image quality looks
obviously poor, select Auto.
Select the internal color
space conversion method
when an RGB signal is
input. Normally, select
Auto.
Select the signal amplitude
range. Normally, select
Standard.
Set whether or not to use
VIEW MODE based on
signal recognition,
including an HDMI signal.

11
LC-45GD7U
Using external equipment Appendix
Connecting a PC
Use the INPUT 5 terminal to connect a PC.
PC with DVI terminal
3.5 mm stereo
minijack cable
(commercially
available)
DVI cable
(commercially
available)
3.5 mm stereo
minijack cable
(commercially
available)
PC with analog RGB terminal
RGB/DVI conversion
cable
(commercially
available)
To optical digital input of external audio devices
Optical fiber cable
Using Digital Audio Output
It is possible to output audio through the DIGITAL AUDIO OUTPUT terminal.
PCM audio outputs from the terminal.
Removing speakers
NOTE
To attach the speakers, perform the steps in reverse order.
CAUTION
Do not remove the stand and speaker from the TV
unless using an optional bracket to mount it.
Before performing work spread cushioning over the
base area to lay the TV on. This will prevent it from
being damaged.
1
2
Unfasten the screws.
Disconnect the cable from the speaker.

12
LC-45GD7U
Appendix
Removing the stand
Before detaching (or attaching) stand, unplug the AC cord from the AC input terminal.
CAUTION
Do not remove the stand from theTV unless using an optional wall mount bracket to mount it.
Before attaching/detaching stand
Before performing work make sure to turn off the TV.
Before performing work spread cushioning over the base area to lay the TV on. This will prevent it from being
damaged.
NOTE
To attach the stand, perform the above steps in reverse order.
2
Unfasten the four screws used to
secure the stand in place.
1
Unfasten the screw used to
secure the bracket in place.
Setting theTV on the wall
CAUTION
Installing the Liquid Crystal Television requires special skill that should only be performed by qualified service
personnel. Customers should not attempt to do the work themselves. SHARP bears no responsibility for improper
mounting or mounting that results in accident or injury.
Using an optional bracket to mount theTV
You can ask a qualified service professional about using an optional AN-37AG2 bracket to mount the TV to
the wall.
Carefully read the instructions that come with the bracket before beginning work.
Hanging on the wall
AN-37AG2 wall mount bracket. (See the bracket instructions
for details.)
About setting theTV angle
CAUTION
Do not remove the stand from the TV unless using an optional bracket to mount it.
Vertical mounting Angular mounting
3
Detach the stand from the TV.
(Hold the stand so it will not drop from
the edge of the base area.)
Angle ofTV
LC-45GD7U 5
o
5
o
RS-232C port specifications
Return codeCommand 4-digits Parameter 4-digits
PC Control of theTV
When a program is set, the TV can be controlled from the PC using the RS-232C terminal.
The input signal (PC/AV) can be selected, the volume can be adjusted and various other adjustments and
settings can be made, enabling automatic programmed playing.
Attach an RS-232C cable cross-type (commercially available) to the supplied Din/D-Sub RS-232C for the
connections.
NOTE
This operation system should be used by a person who is accustomed to using computers.
Communication conditions
Set the RS-232C communications settings on the PC to match the TV's communications conditions.
The TV's communications settings are as follows:
Baud rate:
Parity bit:
Data length:
Stop bit:
Flow control:
9,600 bps
8 bits
None
1 bit
None
Command format
Communication procedure
Send the control commands from the PC via the RS-232C connector.
The TV operates according to the received command and sends a response message to the PC.
Do not send multiple commands at the same time. Wait until the PC receives the OK response before sending
the next command.
Eight ASCII codes CR
Command 4-digits:Command. The text of four characters.
Parameter 4-digits:Parameter 0 9, x, blank, ?
Parameter
Input the parameter values, aligning left, and fill with blank(s) for the remainder. (Be sure that 4 values are input for the
parameter.)
When the input parameter is not within an adjustable range, "ERR" returns. (Refer to "Response code format".)
Any numerical value can replace the "x" on the table.
When "?" is input for some commands, the present setting value responds.
C1 C2 C3 C4 P1 P2 P3 P4
0055
100
30
0009
0
????
?
+
_
_

13
LC-45GD7U
Appendix Basic adjustment settings
Command table
Commands not indicated here are not guaranteed to operate.
CONTROL ITEM COMMAND
PARAMETER
CONTROL CONTENTS
POWER SETTING It shifts to standby.
It input-switches by the toggle. (It is the same as an input change key) It input-switches to TV. (A channel remains as it is. (Last memory)) It input-switches to INPUT1~INPUT5. It input-switches to i.LINK. An input change is also included. Although it can choose now, it is toggle operation in inside. Although it can choose now, it is toggle operation in inside.
(Toggle) Input terminal number (1 5) AUTO VIDEO COMPONENT DIGITAL PC ANALOG PC DIGITAL AV ANALOG AV (Toggle) STANDARD MOVIE USER GAME DYNAMIC (Fixed) DYNAMIC Volume (0 60) AV mode. ( 10) PC mode. (0 180) AV mode. ( 20) PC mode. (0 100) Only PC mode. (0 180) Only PC mode. (0 40) (Toggle) [AV]
An input change is included if it is not TV display. In Air, 2 69ch is effective. In Cable, 1 125ch is effective. If it is not TV display, it will input-switch to TV. (same function as CH ) If it is not TV display, it will input-switch to TV. (same function as CH ) Toggle operation of a closed caption.
(Toggle) Side Bar [AV] S.Stretch [AV] Zoom [AV] Stretch [AV] Normal [PC] Zoom [PC] Stretch [PC] Dot by Dot [PC] On Off OFF OFF TIMER 30 MIN. The channel number of TV The channel number of TV 1
The channel number of TV 1 (Toggle) (1 125) AUTO
POWR
ITGD ITVD IAVD INP1 INP5
INPUT SELECTION A TOGGLE
i.LINK
INPUT SELECTION B AV MODE SELECTION VOLUME POSITION VIEWMODE Dolby Virtual SLEEP TIMER CHANNEL Air/Cable SELECT CC
DIRECT (ANALOG) (DIGITAL) CH UP CH DOWN CHANNEL H-POSITIONH-POSITION V-POSITION CLOCK PHASE
INPUT 1 INPUT 5
AVMD
VOLM
HPOS
VPOS
CLCK
PHSE
ACDV
OFTM
DCCH CHUP CHDW CLCP
WIDE
0
x x
*
0 5 6 7 8 1 2 0
* * * * *
0 0
*
x x x
1 1 2 0 1 2 3 4 5 6 7 8
* *
1 2 3 4 5 6
*
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
* * * * * * *
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
*
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
* * * * * *
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
_
DIGITAL Air (Two-Part numbers, 2-digit plus 2-digit)(0101-9999)
(0-999) (0-999) (0-9999) (0-6383)
DIGITAL Cable (Two-Part numbers, 3-digit plus 3-digit) DIGITAL Cable (Two-Part numbers, 3-digit plus 3-digit) Front half of DIGITAL CABLE CHANNEL NO. (Designate major channel) Rear half of DIGITAL CABLE CHANNEL NO. (Designate minor channel)
DIRECT CHANNEL
DA2P * * * * DC2U * * * _ DC2 L * * * _
DIGITAL Cable (One-Part numbers, 5-digit, less than 10,000)
DC1 0 * * * *
DIGITAL Cable (One-Part numbers, 5-digit, more than 10,000)
DC1 1 * * * *
_ _
AIR CABLE AIR(Toggle)ACS L 0 _ _ _
AIR1___ CABLE2___
_ _
(Toggle)
AUDIO SELECTION ACHA x _ _ _
_ _
OFF TIMER 60 MIN. OFF TIMER 90 MIN.
2 3
_ _
_ _
_ _
OFF TIMER 120 MIN.4___
_ _
(Toggle) On Off
MUTE MU T E 0
1 2
_ _ _
_ _ _
_ _ _ _ _ _ _ _ _ _ _ _ _
INPUT5: AV mode. ( 90)***_
_ _ _ _
INPUT5: AV mode. ( 50)
***_
_ _ _ _ _ _
LINKx___
_ _ _ _ _ _ _
AUTO VIDEO COMPONENT AUTOINP2
INPUT 2 0
1 2
_ _ _
_ _ _
_ _ _ _ _ _ _ _ _ _
TV INPUT1-5
NOTE
If an underbar (_) appears in the parameter column, enter a space.
If an asterisk (*) appears, enter a value in the range indicated in brackets under CONTROL CONTENTS.
As long as that from which the parameter ( ) in the table is a numerical value, it may write anything.
Return code (0DH)
Response code format
Normal response
Problem response (communication error or incorrect command)
Return code (0DH)
OK
ERR
_
_
_
_
_
_
_ _ _ _
_
_
_
AV input mode menu items
List of AV menu items to help you with
operations
OPC
Backlight
Contrast
Brightness
Color
Tint
Sharpness
Advanced
C.M.S.
ColorTemp.
Sharpness Enhancement
Automatic Contrast
3D-Y/C
Monochrome
Film Mode
I/P Setting
No Signal Off
No Operation Off
EZ Setup
CH Setup
Antenna Setup-DIGITAL
Input Label
Parental CTRL
Position
Picture Flip
Standby Mode
Language
Treble
Bass
Balance
Dolby Virtual
Audio Only
3D Noise Reduction
Mosquito Noise Reduction
HDMI Setup
Input Select
Output Select
Quick Shoot
Caption Setup
ProgramTitle Display
Audio
Power Control
Setup
Option
CableCARD Menu
Video Setup
Audio Setup
i.LINK Setup
Digital Setup
Power Management
Input Signal
Auto Sync.
Input Label
Fine Sync.
Picture Flip
Standby Mode
Language
Power Control
Setup
Option
Audio Only
Input Select
Output Select
Quick Shoot
i.LINK Setup
Digital Setup
OPC
Backlight
Contrast
Brightness
Red
Green
Blue
Advanced
C.M.S.
Sharpness Enhancement
Audio
Treble
Bass
Balance
DolbyVirtual
*PC input mode menu items
List of PC menu items to help you with
operations
*When INPUT5 is set to PC.

14
LC-45GD7U
DIMENSIONS
Unit: inch/(mm)
7
7
/ 8 ( 200)
7
7
/
8
(
200)
38
15
/ 16 ( 989.1)
18
45
/
64
(
475)
18
45
/
64
(
475)
26
21
/ 32 ( 677)
43
9
/ 64 ( 1096)
11
31
/ 32 ( 304)
7
51
/ 64 ( 198) 4
31
/ 64 ( 114)
25
25
/
32
(
655)
2
7
/
16
(
62)
29
3
/
64
(
738)
31
1
/
2
(
800)
21
29
/
32
(
556.7)

15
LC-45GD7U
REMOVING OF MAJOR PARTS
7. Remove the 5 lock screws 9and detach the Wire Shield.
8. Remove the 11 lock screws 0. Disconnect [FA] connector. Detach the Center Angle.
9. Remove the KEY PWB.
9-1.Disconnect the [KM] connector.
9-2.Remove the 2 lock screws qfrom the Top Control Cover.
9-3.Remove the 3 lock screws wfrom the KEY PWB.
1. Remove theTerminal Covers 1.
2. Detach the SD Card Cover, BUS-CONE Cover, PC Card Cover, DVI Cover.
3. Remove the 2 lock screws 2and detach the Stand Cover.
4. Remove the 4 lock screws 3and detach the Stand.
5. Remove the 4 lock screws 4, the 2 SP Cords 5and detach the Speaker.
6. Remove the 13 lock screws 6, 6 lock screws 7, 9 lock screws 8and detach the Rear Cabinet.
9
Wire Shield
10
Center Angle
KEY PWB
Top Control Cover
11
12
10
[KM]
[FA]
PC Card Cover
BUS-CONE Cover
DVI Cover
SD Card cover
1
Terminal Cover
Terminal Cover
1
6
7
8
7
8
8
Rear Cabinet
Speaker
SP Cord (L)
SP Cord (R)
Stand
Stand Cover
34
4
5
5
2

16
LC-45GD7U
10. Disvonnect all the connectors from all the PWBs.
11. Remove the 6 lock screws eand detach the Fans.
12. Remove the 4 lock screws rand detach the AV Unit.
13. Remove the 8 lock screws tand detach the Power Supply PWB.
14. Remove the 5 lock screws yand detach the AC Input PWB.
15. Remove the 2 lock screws uand detach the Speaker Terminal (L) PWB.
16. Remove the 2 lock screws iand detach the Speaker Terminal (R) PWB.
17. Remove the 8 lock screws oand detach the Angle.
18. Remove the 2 lock screws pand detach the R/C, LED PWB.
[NP1]
[MN1]
[MN2]
[FB]
[PO][FD]
[AC]
[PA]
[PG]
[DP]
[PD]
[AC]
[NV4]
[MN3]
[NP3]
[DA]
[SP]
[SP]
[MN]
[PA]
[RA]
[FC]
[FD]
[LV]
[BC]
15
16
17
19
18
19
13 13
14
Fan
Fan
AV Unit
Power Supply PWB
AC Input PWB
SPEAKER
TERMINAL
(L) PWB
SPEAKER
TERMINAL
(R) PWB
Angle Angle
20
R/C, LED PWB

17
LC-45GD7U
19. Remove the 4 lock screws aand detach the AV terminal Cover (R).
20. Remove the 1 lock screw sand detach the AV terminal Cover (B).
21. Remove the 9 lock screws dand detach the DIGITAL PWB Shield.
22. Remove the 4 lock screws fand detach the DIGITAL PWB Angle.
23. Remove the 2 lock screws gand the 2 lock screws h, and detach the AV terminal Cover (D).
24. Remove the 1 lock screw jand detach the DIGITAL PWB.
25. Remove the 3 lock screws kand detach the Earth Lug and the Barrier sheet.
26. Remove the 2 lock screws and detach the MAIN PWB.
27. Remove the 7 lock screws
30 and detach the Heat sink (AV), and the AV PWB.
28. Remove the 2 lock screws
31 and detach the BUS-CON Unit.
29. Remove the 10 lock screws 32 and detach the LCD Panel Ass'y.
21
22
AV Terminal Cover (R)
AV Terminal Cover (B)
AV Terminal
Cover (D)
AV PWB
MAIN PWB
DIGITAL PWB
DIGITAL PWB Shield
DIGITAL PWB Angle
BUS-CON Unit
Earth Lug
25
26
23
24
27
28
29
31 30
Heat
sink (AV)
Barrier
sheet
32
32
32
32
3232
LCD Panel Ass’y
Side Angle Side Angle

18
LC-45GD7U
Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics
identified in this manual; electrical components having such features
are identified by åand shaded areas in the Replacement Parts Lists
and Schematic Diagrams.The use of a substitute replacement part
which dose no have the same safety characteristic as the factory
recommended replacement parts shown in this service manual may
create shock, fire or other hazards.
"HOWTO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
in USA: Contact your nearest SHARP Parts Distributor to order.
For location of SHARP Parts Distributor, Please call Toll-
Free; 1-800-BE-SHARP
★ MARK: SPARE PARTS-DELIVERY SECTION
LISTE DES PIECES
CHANGE DES PIECES
Les pi`eces de rechange qui pr élelesentent ces caract éleristiques
sp éleciales de s élecurit éle, sont identifi élees dans ce manuel :
lespi`eces élelectriques qui pr élesentent ces particularit éles, sont
rep éler élee par la marque ået sont hachur élees dans les listes de
pi`eces et dans les diagrammes sch élematiques.
La substitution d'une pi`ece de rechange par une autre qui ne pr
éLesente pas les m éoemes caract éLeristiques de s élecurit éle que
la pi`ece recommand élee parl'usine et dans ce manuel de service,
peut provoquer une éLelectrocution, un incendie ou toutautre sinistre.
"COMMENT COMMANDER LES PIECES DE
RECHANGE"
Pour que votre commande soit rapidement et correctement remplie,
veuillez fournir les renseignements suivants.
1. NUMERO DU MODELE 2. NO. DE REF
3. NO. DE PIECE 4. DESCRIPTION
in CANADA: Contact SHARP Electronics of Canada Limited
Phone [phone]
PRINTEDWIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
DUNTKD154VJ03 – AC INPUT Unit —
DKEYDD392VJ11 – DIGITAL TUNER Unit —
DUNTKD393VJ02 – MAIN Unit —
DUNTKD405UJ01 – AV Unit —
DUNTKD406UJ01 – KEY Unit —
DUNTKD407UJ01 – R/C, LED Unit —
DUNTKD408UJ01 – SPEAKER TERMINAL-L Unit —
DUNTKD409UJ01 – SPEAKER TERMINAL-R Unit —
DUNTKD410UJ01 – BUS CONNECT Unit —
RDENCA142WJQZ – POWER SUPPLY Unit —
LCD PANEL
NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
RLCUCA015WJZZ J 45” Wide LCD Panel Unit
DUNTKD407UJ01
R/C, LED Unit
J2401 QJAKJA009WJSA J Jack AE
DUNTKD393VJ02
MAIN Unit
R2369 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA

19
Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
LC-45GD7U
1 CCABAB120WJ01 J Front Cabinet Ass’y BR
1-1 Not Available – Front Cabinet —
1-2 GCOVAA829WJKA J R/C, LED Decoration Cover AG
1-3 Not Available – Badge, SHARP —
1-4 PSPAHA633WJKZ J Mask Spacer, x6 AC
1-5 TLABZA861WJSA J HDMI Label AD
1-6 TLABZA862WJSA J TV GUIDE Label
2 CCABBA655WJ01 J Rear Cabinet Ass’y BT
2-1
Not Available – Rear Cabinet —
2-2 GCOVAA838WJKA J VESA-Hole Cover, x4 AE
2-4 GCOVAB325WJKA J PC Slot Cover AH
2-5 GCOVAB393WJKA J SUB AV Cover AG
2-6 HiNDP5733CESB J AQUOS Label AD
2-7 LHLDWA055WJKZ J Wire Holder AC
2-8 LHLDWA057WJKZ J Wire Holder FOR CABLE AE
2-9 LHLDWA102WJKZ J Wire Holder AB
2-10 LHLDZ0132CEZZ J Speaker Box Bush, x2 AD
2-12 XEBSN30P10000 J Screw, x11 SP-COV8,AV-COV3 AA
2-13 GCOVAB407WJKA J Side SP Cover (Top), x2
2-14 GCOVAB408WJKA J Side SP Cover (Bottom), x2
3 CCOVAB396WJ01 J Top Control Cover Ass’y AP
3-1 Not Available – Top Control Cover —
3-2 JBTN-A307WJKA J Operation Button AK
3-3 JBTN-A340WJKA J Power Button AG
3-4 MSPRCA049WJFW J Spring for Power Button AC
4 CDAi-A220WJ05 J Stand Base Ass’y BK
4-1 Not Available – Stand Base —
4-2 LANGKA564WJZZ J Stand Base Angle
4-3 PSPAZA476WJZZ J LEG-Cushion-A, x4 AC
4-4 PSPAZA477WJZZ J LEG-Cushion-B, x4 AD
4-5 XEBS940P12000 J Screw, x10 BASEYOU AB
5 CHNG-A129WJ04 J Stand Hinge Ass’y BH
5-1 Not Available – Stand Hinge —
5-2 GDAi-A237WJSB J Stand Support BE
5-3 GDAi-A222WJF8 J Swivel Base AW
5-4 LX-NZA013WJFN J Nut AE
5-5 PSPAZA773WJZZ J Spacer, x4
5-6 PSPAZA931WJZZ J Spacer, x2 AC
5-7 XCSS750P30000 J Screw, x4 AC
6 CANGKA450WJ01 J Fan Angle Ass’y AP
6-1 Not Available – Fan Angle —
6-2 PSPAGA187WJ00 J Spacer, x4 AB
6-3 XBPS730P06WS0 J Screw, x2 AA
7 CANGKA450WJ02 J Fan Angle Ass’y AQ
7-1 Not Available – Fan Angle —
7-2 LHLDWA043WJKZ J Wire Holder, x2 AB
7-3 PSPAGA187WJ00 J Spacer, x4 AB
7-4 XBPS730P06WS0 J Screw, x2 AA
8 CANGKA452WJ01 J Center Angle Ass’y BH
8-1 Not Available – Center Angle —
8-2 LANGKA466WJFW J Support Angle, x4 AF
8-3 LHLDWA055WJKZ J Wire Holder AC
8-4 PSPAGA187WJ00 J Spacer, x4 AB
8-5 XBPS730P06WS0 J Screw, x2 AA
9 CSLDMA823WJ01 J Wire Shield Ass’y AU
9-1 Not Available – Wire Shield —
9-2 PSLDMA878WJZZ J Sheet(210x35) AK
9-3 PSLDMA879WJZZ J Sheet(90x20) AH
9-4 PSLDMA880WJZZ J Sheet(20x20) AD
9-5 PSPAHA652WJZZ J Himeron A, x2 AB
10 CCHSMA246WJ01 J Tray Chassis Ass’y AV
10-1 Not Available – Tray Chassis —
CABINET AND MECHANICAL PARTS 10-2 PSPAHA652WJZZ J Spacer A AB
11 CSLDMA802WJ01 J Digital PWB Shield Ass’y AW
11-1 Not Available – Digital PWB Shield —
11-2 PSPAHA653WJZZ J Spacer B AA
12 Not Available – Under Speaker Ass’y —
12-1 CPNLSA054WJ01 J Speaker Panel Ass’y BQ
12-2 RSP-ZA139WJN2 J Under Speaker BW
13 XBBS940P25000 J Screw for SP-Box, x4 AB
14 RLCUCA015WJZZ J 45” Wide LCD Panel Unit
15 DUNTKD154VJ03 – AC INPUT Unit —
16 DKEYDD392VJ11 – DIGITAL TUNER Unit —
17 DUNTKD393VJ02 – MAIN Unit —
18 DUNTKD405UJ01 – AV Unit —
19 DUNTKD406UJ01 – KEY Unit —
20 DUNTKD407UJ01 – R/C, LED Unit —
21 DUNTKD408UJ01 – SPEAKER TERMINAL-L Unit —
22 DUNTKD409UJ01 – SPEAKER TERMINAL-R Unit —
23 DUNTKD410UJ01 – BUS CONNECT Unit —
24 RDENCA142WJQZ – POWER SUPPLY Unit —
25 GCOVAB368WJKA J Terminal Cover (R) AN
26 GCOVAB369WJKA J Terminal Cover (TOP) AV
27 GCOVAB370WJKA J Terminal Cover (L) AS
28 GCOVAA678WJKA J SD Card Cover AE
29 GCOVAB162WJKA J BUS CONNECT Cover AD
30 GCOVAB329WJKC J Stand Cover AU
31 GCOVAB414WJKA J Screw Cap, x4 AD
32 GCOVHA042WJKA J PC Card Cover AE
33 GCOVAB390WJKA J AV Terminal Cover R AS
34 GCOVAB391WJKA J AV Terminal Cover B AK
35 GCOVAB392WJKA J AV Terminal Cover D AL
36 HiNDPB426WJSA J Model Label AL
37 LANGKA606WJFW J
BUS CONNECT PWB Angle AE
38 LHLDWA048WJKZ J Wire Holder, x2 (BUS ANG) (SP-ANG) AB
39 LANGQA013WJFW J AC INPUT PWB Angle AH
40 LHLDWA055WJKZ J Holder AC
41 LANGKA608WJFW J Under SP Angle (R) AH
42 LANGKA609WJFW J Under SP Angle (L) AH
43 LANGKA333WJFW J Mask Angle, x2 AG
45 LX-BZA051WJF7 J Screw M4-10(EARTH LUG) AB
46 LX-BZA145WJN1 J Screw, x4 AB
M3X6+NYLON WASHR
47 LHLDWA119WJKZ J Wire Holder AC
48 LHLDWA080WJKZ J Wire Holder (AV) AB
49 NSFTZ0134CEFW J Screw, x4 Shaft DVI/232C (AV) AD
50 NFANR0126CEZZ J DC Fan, x3 (80X80MM) AT
51 PSLDMA807WJFW J HDMI Shield (Bottom) (AV) AG
52 PSLDMA870WJFW J HDMI Shield (Top) (AV) AG
53 PMLT-A126WJZZ J Gasket AF
54 PMLT-A274WJZZ J Gasket, x2 (TRAYBTM) AE
55 PMLT-A275WJZZ J Gasket, x3 (TRAYBTM) AK
56 PMLT-A277WJZZ J Gasket (TRAYBTM) AL
57 PMLT-A279WJZZ J Gasket, x2 (MAINANGL) AC
58 PRDARA268WJFW J Heat Sink (AV) AF
60 PSLDMA801WJZZ J DIGITAL PWB Shield (TOP) AS
61 PSLDMA867WJZZ J Conducting Shield AG
62 PSPAZA632WJKZ J Cooling Sheet (IC8101 TOP)AD
63 PSPAZA635WJKZ J Cooling Sheet (IC2502 TOP)AC
64 PSPAZA700WJKZ J Cooling Sheet (IC82502 BTM) AD
65 PSPAZA701WJKZ J Cooling Sheet, x2 AD
(IC1804,3700)
66 PSPAZA812WJZZ J PWB_Support AD
67 PSPAZA872WJKZ J Cooling Sheet (IC3300 TOP)AN
68 PSPAZA879WJKZ J Cooling Sheet AQ
(IC8451/8454 EMI)
69 PSPAZA880WJKZ J Cooling Sheet (IC3800 BTM) AC
70 PSPAZA881WJKZ J Cooling Sheet AE
(IC3401+3403)
71 PSPAZA882WJKZ J Cooling Sheet AE
(IC1806+08+Q1812)
72 PSPAZA883WJKZ J Cooling Sheet (IC8601 TOP)AC

20
Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
LC-45GD7U
CABINET AND MECHANICAL PARTS
(Continued)
73 PSPAZA884WJKZ J Cooling Sheet AE
(TU8001 TOP)
74 PSPAZA886WJKZ J Cooling Sheet (IC9603 TOP)AB
75 PSPAZA887WJKZ J Cooling Sheet AE
(SC9401SOLDRSIDE)
76 PZETKA165WJZZ J Barrier sheet (Insulator) AL
77 QCNW-D998WJQZ J Connecting Cord AT
(DA:AV-DIGITAL)
78 QCNW-E003WJQZ J Connecting Cord AL
(DC:AV-BUSCONNE)
79 QCNW-D872WJQZ J Connecting Cord AH
(KM:KEY-MAIN)
80 QCNW-E001WJQZ J Connecting Cord AM
(RA:LED-AV)
81 QCNCMA201WJZZ J Connector AH
(FC SOKETYOU)
82 QCNW-D498WJQZ J Connecting Cord AN
(DP+PD:MN,DIG-PW)
83 QCNW-D952WJQZ J Connecting Cord AG
(RFSW-JACK(BLAK))
84 QCNW-D953WJQZ J Connecting Cord AG
(RFSW-TUNER(RED))
85 QEARPA203WJFW J Conductor AE
86 QCNW-D495WJQZ J Connecting Cord AG
(AC:POW-AC_IN)
87 QCNW-D497WJQZ J Connecting Cord AM
(PA:AV-POW)
88 QCNW-D873WJQZ J Connecting Cord AP
(MN:MAIN-INV)
89 QCNW-D874WJQZ J Connecting Cord AP
(PG:POW-INV)
90 QCNW-D999WJQZ J Connecting Cord AG
(SP:AV-SP_L,R)
91 QCNW-E002WJQZ J Connecting Cord AG
(FD:AV-POW)
92 QCNW-E004WJQZ J Connecting Cord AM
(PO:POW-LCD_CONT)
93 QCNW-E065WJQZ J Connecting Cord BA
(LV:MAIN-LCD_CNT)
94 QEARZA091WJZZ J Ground-Part (AL TAPE) AC
95 RCORF0107CEZZ J Core (MAIN-POW) AM
96 RCORFA034WJZZ J Core (MAIN-AV) AM
97 XBBS740P06000 J Screw, x11 (C-ANG/CAB-A) AA
98 XBBS830P06000 J Screw, x14 AA
(COVER,JACK5/COV5,AC2,C-ANG2)
99 XBBS940P08000 J Screw, x2 AB
(FOR HINJI COVER)
100 XBBSN50P12JS0 J Screw, x4 (STAND/SET) AF
101 XBPS730P06WS0 J Screw, x63 (CAP BISS) AA
102 XBPS830P04WS0 J Screw, x2 AA
(FOR LEAK OF LIG)
103 GCOVAB448WJZZ J DVI Cover AD
104 XBPSN30P20XS0 J Screw, x6 (FAN/ANG) AB
105 XEBS930P08000 J Screw, x2 AA
(FOR POWER PWB)
106 XEBS930P10000 J Screw, x25 AA
(COVER,JACK4/COV3,SP2,T-COV1)
107 XEBS940P20000 J Screw, x13 (FOR CAB-B) AB
108 XJBS850P25000 J Screw, x4 (STAND YO) AC
109 Not Available – No.Label —
110 PSPAZA957WJZZ J Spacer AC
111 PMLT-A284WJZZ J Gasket AC
112 PMLT-A285WJZZ J Gasket AD
113 LHLDWA127WJKZ J Wire Holder AF
114 QEARZA092WJZZ J Graud-Part (AL-TAPE), x2 AD
