Sharp Aquos LC-65XS1M User manual

Display / 顯示器 / 显示器
LC-65XS1M
AVC System / AVC 系統 / AVC 系统
TU-X1M
LCD COLOUR TELEVISION
液晶彩色電視機
液晶彩色電視機
ENGLISH
OPERATION MANUAL
使用說明書
使用說明書
LC-65XS1M OPERATION MANUAL 使用說明書 使用說明書
中文 (繁體)中文 (簡體)
Printed in Japan
日本印刷
日本印刷
TINS-D978WJN1
09P02-JA-KG
TINS-D978WJN1
09P02-JA-KG
LC-65XS1M
TU-X1M

Cover2_19A33X.indd 1Cover2_19A33X.indd 1 2007/07/11 16:51:172007/07/11 16:51:17

OPERATION MANUAL
Contents............................................................................. 1
Introduction........................................................................ 2
Dear SHARP customer ................................................. 2
Important Safety Precautions ........................................ 2
Trademarks................................................................... 2
Remote control unit....................................................... 3
Part name..................................................................... 4
Display (Front view/Side view) .................................. 4
AVC System (Front view/Rear view).......................... 4
AVC System (Bottom view) ...................................... 4
Preparation ........................................................................ 5
Supplied accessories .................................................... 5
Optional accessories..................................................... 5
Attaching the Stand ...................................................... 5
Inserting the batteries.................................................... 6
Using the remote control unit ........................................ 6
Cautions regarding the remote control unit............... 6
Quick guide ........................................................................ 7
Initial installation overview.............................................. 7
Before turning on the main power ................................. 8
Preparing the Display............................................... 8
Handling and precautions with the wall-mounted Display ... 8
Setting the TV and antenna cables........................... 9
Turning on and running the initial auto installation........ 10
Plugging the AC cord to the AC outlet ................... 10
Initial auto installation ............................................. 10
Watching TV ..................................................................... 11
Daily operation ............................................................ 11
Switching on/off..................................................... 11
Changing channels ................................................ 11
Selecting an external video source......................... 11
Auto power-off at a designated time ...................... 11
Selecting a sound mode ........................................ 12
Connecting external devices.......................................... 13
Introduction to connections......................................... 13
HDMI connection................................................... 14
Component connection ......................................... 14
S-VIDEO/VIDEO connection .................................. 14
Speaker/VCR connection....................................... 15
AQUOS LINK .................................................................... 16
Controlling HDMI devices using AQUOS LINK............. 16
AQUOS LINK connection............................................ 16
AQUOS LINK Setup.................................................... 17
Operating an AQUOS LINK device.............................. 18
Menu operation................................................................ 19
What is the MENU? .................................................... 19
Common operations .............................................. 19
TV/AV input mode menu items.................................... 20
PC input mode menu items ........................................ 21
Basic adjustment............................................................. 22
Picture Settings........................................................... 22
AV MODE .............................................................. 23
Audio Settings ............................................................ 23
ECO Settings .............................................................. 24
Channel Settings......................................................... 25
Auto Installation ..................................................... 25
Password settings ................................................. 26
Language Settings (language) ..................................... 26
Teletext ....................................................................... 26
Teletext language setting........................................ 27
Displaying Subpages ............................................. 27
Time display .......................................................... 27
Displaying Subtitles................................................ 27
Updating your TV via USB........................................... 28
Useful Viewing functions ................................................ 29
Selecting the picture size ............................................ 29
Selecting the WSS picture size automatically ......... 29
Selecting the WSS picture size manually................ 29
Selecting the picture size manually......................... 29
Selecting the HDMI picture size automatically ........ 30
Other picture and audio settings ................................. 30
Adjusting image position........................................ 30
Automatic volume adjustment................................ 30
Outputting audio only............................................. 30
Time display .......................................................... 30
Other useful features ...................................................... 31
Setting when using external devices ........................... 31
Input source settings ............................................. 31
Skipping specified inputs ....................................... 31
Colour system settings .......................................... 31
Additional features ...................................................... 31
Gallery Mode .............................................................. 32
Basic operation for Gallery Mode ................................ 32
Gallery Mode setting ................................................... 32
Troubleshooting for Gallery Mode........................... 33
Connecting a PC.............................................................. 34
Connecting a PC ........................................................ 34
Displaying a PC image on the screen.......................... 34
Selecting the picture size ....................................... 34
Adjusting the PC image automatically .................... 35
Adjusting the PC image manually........................... 35
Selecting input resolution ............................................ 35
RS-232C port specifications ....................................... 36
PC compatibility chart................................................. 37
RS-232C command list............................................... 37
Appendix .......................................................................... 38
Troubleshooting .......................................................... 38
Reset .......................................................................... 39
Identification................................................................ 39
Clearing the password ................................................ 39
When the Display cannot be operated…..................... 39
Using the universal remote control .............................. 40
Specifications ............................................................. 44
Dimensional drawings ................................................. 45
“TV” when used in this manual means the Display and AVC System.
The illustrations and the OSD in this operation manual are for explanation purposes and may vary slightly from the actual
operations.
•
•
Contents
1
ENGLISH
ENGLISH
LC-65XS1M_en.indd 1LC-65XS1M_en.indd 1 2009/01/15 16:02:382009/01/15 16:02:38

Cleaning—Unplug the AC cord from the AC outlet before cleaning the product. Use a damp cloth to clean the product.
Do not use liquid cleaners or aerosol cleaners.
Water and moisture—Do not use the product near water, such as bathtub, washbasin, kitchen sink, laundry tub,
swimming pool and in a wet basement.
Do not place vases or any other water-filled containers on this product. The water may spill onto the
product causing fire or electric shock.
Stand—Do not place the product on an unstable cart, stand, tripod or table. Doing so can cause the
product to fall, resulting in serious personal injuries as well as damage to the product. Use only a cart,
stand, tripod, bracket or table recommended by the manufacturer or sold with the product. When
mounting the product on a wall, be sure to follow the manufacturer’s instructions. Use only the mounting
hardware recommended by the manufacturer.
When relocating the product placed on a cart, it must be moved with utmost care. Sudden stops,
excessive force and uneven floor surface can cause the product to fall from the cart.
Ventilation—The vents and other openings in the cabinet are designed for ventilation. Do not cover or
block these vents and openings since insufficient ventilation can cause overheating and/or shorten the
life of the product. Do not place the product on a bed, sofa, rug or other similar surface, since they
can block ventilation openings. This product is not designed for built-in installation; do not place the
product in an enclosed place such as a bookcase or rack, unless proper ventilation is provided or the
manufacturer’s instructions are followed.
The LCD panel used in this product is made of glass. Therefore, it can break when the product is
struck forcefully or with a sharp object. If the LCD panel is broken, be careful not to be injured by broken glass.
Heat sources—Keep the product away from heat sources such as radiators, heaters, stoves and other heat-generating
products (including amplifiers).
Headphones—Do not set the volume at a high level. Hearing experts advise against extended listening at
high volume levels.
To prevent fire, never place any type of candle or naked flames on the top or near the TV set.
To prevent fire or shock hazard, do not place the AC cord under the TV set or other heavy items.
Do not display a still picture for a long time, as this could cause an afterimage to remain.
There is power consumption always if main plug is connected.
Servicing—Do not attempt to service the product yourself. Removing covers can expose you to high
voltage and other dangerous conditions. Request a qualified person to perform servicing.
Do not insert foreign objects. Placing objects into the vent holes (the holes on the rear on the Display) may cause fire and
electrocution. Be especially if young children are present.
The LCD panel is a very high technology product with 2,073,600 pixels, giving you fine picture details.
Due to the very large number of pixels, occasionally a few non-active pixels may appear on the screen as a fixed point of
blue, green or red. This is within product specifications and does not constitute a fault.
Precautions when transporting the Display
When transporting the Display, never carry it by holding onto the speakers. Be sure to always carry the Display by two
people holding it with two hands—one hand on each side of the Display.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Introduction
Dear SHARP customer
Thank you for your purchase of the SHARP LCD colour TV product. To ensure safety and many years of trouble-
free operation of your product, please read the Important Safety Precautions carefully before using this product.
Important Safety Precautions
Trademarks
“HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.”•
TruSurround XT, SRS and h®symbol are trademarks of SRS Labs, Inc.
TruSurround XT technology is incorporated under license from SRS Labs, Inc.
•
•
“x.v.Colour” and are trademarks of Sony Corporation.•
LCフォント、LCFONT、エルシーフォントand LC logo mark are registered trademarks of SHARP Corporation.
This product is embedded with LC Font technology, which was developed by SHARP Corporation for clearly displaying
easy-to-read characters on an LCD screen. However, other non-LCD fonts are used for displaying some screen pages.
•
2
LC-65XS1M_en.indd 2LC-65XS1M_en.indd 2 2009/01/15 16:02:392009/01/15 16:02:39

Introduction
Remote control unit
1
4
5
6
7
8
9
10
11
12
13
14
16
17
18
20
19
23
15
TV POWER (STANDBY/ON)
To switch the power on and off. (See
page 11.)
LIGHT D
When pressed, buttons that are
frequently used (CHr/s, VOLk/
VOLl, 0–9, Aand INPUT) will
light. The light will turn off if no
operations are performed within
about five seconds. This button is
used for performing operations in
low-light situations.
FUNCTION
Press this button briefly (for more
than 0.2 second), and the remote
control switches for DVD, SetTopBox
or VCR operation and currently
controlled devices will be indicated in
the LCD window.
See page 40 for how to use this unit
as a universal remote control.
LCD window
This screen shows which device you
are currently controlling (TV, DVD,
STB or VCR).
0–9
Set the channel. (See page 11.)
TELETEXT mode*: Set the page.
(See page 26.)
A(Flashback)
Press to return to the previously
selected channel or external input.
WIDE
Change the wide image mode. (See
pages 29 and 34.)
VOLk/ VOLl
Set the volume.
e(Mute)
Mute the sound.
R/G/Y/B (Colour) buttons
TELETEXT mode*: Select the page.
(See page 26.)
a/b/c/d(CURSOR)
Select a desired item on the setting
screen.
ENTER
Execute a command.
EXIT
Turn off the On-Screen Display.
Buttons for other useful
features
MPX
Select the sound multiplex mode.
(See page 12.)
AV-M (AV MODE)
Select a video setting. (See page
23.)
1
2
3
4
5
6
7
8
9
0
Q
W
E
DISP (DISPLAY)
Displays the channel or input
information.
Displays the time information
included in the Teletext broadcast*.
(See page 27.)
OPC
To switch the Optical Picture Control
on and off. (See page 22.)
GALLERY
Press to enter the Gallery Mode.
(See page 32.)
SLP (SLEEP)
Set the Seep timer. (See page 11.)
INPUT (INPUT SOURCE)
Select an input source. (TV, INPUT 1,
INPUT 2, INPUT 3, INPUT 4, INPUT
5, INPUT 6, INPUT 7 (PC)) (See
pages 11 and 31.)
IN1 IN2 IN3 (HDMI)
Select an HDMI (INPUT1, INPUT2,
INPUT3). (See pages 14 and 31.)
CHr/CHs
TV input mode: Select the channel.
(See page 11.)
TELETEXT mode*: Select the page.
(See page 26.)
MENU
Display the menu screen. (See page
19.)
RTN (RETURN)
MENU mode: Return to the previous
menu screen. (See page 19.)
Buttons for teletext and other
useful feature
Flip open the remote control cover
on the front.
m(Teletext)*
Select the TELETEXT mode*. (all
TV image, all TEXT image, TV/TEXT
image) (See page 26.)
k(Reveal hidden Teletext)*
TELETEXT mode*: Display hidden
characters. (See page 26.)
[ (SUBTITLE for TELETEXT)*
To turn the subtitles on and off. (See
page 27.)
3(Hold)
TELETEXT mode*: Stop updating
Teletext pages automatically. Press
3again to release the hold mode.
(See page 26.)
1(Subpage)
Display the Teletext* subpage
directly. (See page 27.)
v(Top/Bottom/Full)
TELETEXT mode*: Set the area of
magnification. (See page 26.)
FRZ (FREEZE)
Freeze a motion picture on the
screen.
AQUOS LINK buttons
If external equipment such as a
AQUOS BD Player is connected
via HDMI cables and is AQUOS LINK
compatible, you can use
these AQUOS LINK buttons. See
pages 16 to 18 for details.
R
T
Y
U
I
O
P
NOTE
This teletext function is not applicable for Hong Kong market.*3
LC-65XS1M_en.indd 3LC-65XS1M_en.indd 3 2009/01/15 16:02:402009/01/15 16:02:40

Introduction
Part name
Display (Front view/Side view)
1 2 3 4 5 8
9
10
67
AVC System (Front view/Rear view)
21 3 4 5 6 7
POWER (On/Off) button
POWER indicator
RESET button*
1
2
3
INPUT 3 (HDMI) terminal
INPUT 7 (PC) terminals
INPUT 4 terminals
4
5
6
Headphone jack7
WARNING
Excessive sound pressure from earphones and headphones can cause hearing loss.
Do not set the volume at a high level. Hearing experts advise against extended listening at high volume levels.
•
•
AVC System (Bottom view)
8 9 10
13 14 15 16 17 18 19
11 12
INPUT 5 terminals
INPUT 6 terminals
REC OUT terminals
ANT (Antenna terminal)
DC OUTPUT terminal
8
9
10
11
12
DIGITAL AUDIO OUTPUT terminal
INPUT 1 (HDMI) terminals
INPUT 2 (HDMI) terminal
RS-232C terminal
13
14
15
16
SERVICE ONLY terminal*
DISPLAY OUTPUT terminal
AC INPUT terminal
Usually do not connect anything to
this terminal as it is reserved only for
service personnel.
17
18
19
*
Product label is on the bottom of the
AVC System.
4
Volume down (f)/ up (e) buttons
Channel down (s)/up (r) buttons
INPUT button
MENU button
POWER (On/Off) button
1
2
3
4
5
POWER indicator**6* OPC: Optical Picture Control (See page 22.)
** See page 11 for the TV status indicator.
*** See page 39 for the RESET button.
SLEEP timer indicator
OPC indicator*
RESET button***
USB terminal
7
8
9
10
* See page 39 for the RESET button.
LC-65XS1M_en.indd 4LC-65XS1M_en.indd 4 2009/01/15 16:02:422009/01/15 16:02:42

Preparation
Supplied accessories
Optional accessories
The listed optional accessories are available for this LCD colour TV. Please purchase them at your nearest shop.
Additional optional accessories may be available in the near future. When purchasing, please read the newest catalogue for
compatibility and check the availability.
No. Part name Part number
1 Wall mount bracket AN-65AG2
2 Stand unit AN-65ST1
•
Attaching the Stand
For details, refer to the installation manual of the optional stand unit.
CAUTION
This Display should be used only with the stand unit AN-65ST1 (SHARP). The use of other stand units may result in unstable
installation and may cause serious injuries.
•
5
HDMI cable fixture (g1)
Page 9
Remote control unit (g1)
Pages 3 and 6
“AAA” size alkaline battery
(g2)
Page 6
HDMI cable (g1)
Pages 8 and 9
Operation manual
HDMI cable holder (g1)
Page 8
Power cord cover (g1)
This covers the compartment on the
back of the Display after installing the
wall mount brackets or stand units.
AC cord (g2)
Page 10
This cord is for regions other than
Singapore.
This cord is only for Singapore.
LC-65XS1M_en.indd 5LC-65XS1M_en.indd 5 2009/01/15 16:02:442009/01/15 16:02:44

Preparation
Inserting the batteries
Before using the TV for the first time, insert two supplied “AAA” size alkaline batteries. When the batteries become
depleted and the remote control unit fails to operate, replace the batteries with new “AAA” size batteries.
Open the battery cover.
Insert two supplied “AAA” size alkaline
batteries.
Place batteries with their terminals
corresponding to the (e) and (f)
indications in the battery compartment.
Close the battery cover.
CAUTION
Improper use of batteries can result in chemical leakage or explosion. Be sure to follow the instructions below.
Do not mix batteries of different types. Different types of batteries have different characteristics.
Do not mix old and new batteries. Mixing old and new batteries can shorten the life of new batteries or cause chemical
leakage in old batteries.
Remove batteries as soon as they have worn out. Chemicals that leak from batteries can cause a rash. If you find any
chemical leakage, wipe thoroughly with a cloth.
Do not overuse the light-up function of the LIGHT Dbutton, doing so may shorten the battery life.
Replace the batteries when the light on the LCD window or the light-up function becomes weak or
when the window becomes blurry.
Do not continue to use the remote control unit with the batteries running low. This may result in error
message or malfunction. Should this happen replace the batteries and leave it unused for a while.
Otherwise, you may open the rear battery cover and press the reset button. When you press the reset
button, your universal remote control settings will be deleted.
The remote control unit has a internal memory of external devices. In order not to lose the data, replace the batteries quickly.
The batteries supplied with this product may have a shorter life expectancy due to storage conditions.
If you will not be using the remote control unit for an extended period of time, remove the batteries from it.
When replacing the batteries, use alkaline batteries instead of zinc-carbon ones.
Note on disposing batteries:
The batteries provided contain no harmful materials such as cadmium, lead or mercury.
Regulations concerning used batteries stipulate that batteries may no longer be thrown out with the household rubbish.
Deposit any used batteries free of charge into the designated collection containers set up at commercial businesses.
Using the remote control unit
Use the remote control unit by pointing it towards the remote control sensor window. Objects between the remote
control unit and sensor window may prevent proper operation.
1
2
•
3
•
•
•
•
•
•
•
•
•
Cautions regarding the remote control unit
Do not subject the remote control unit to shock. In addition, do not soak the remote
control unit with liquids or place it in an area with high humidity.
Do not install or place the remote control unit under direct sunlight. The heat may cause
deformation of the unit.
The remote control unit may not work properly if the remote control sensor window of
the Display is under direct sunlight or strong lighting. In such cases, change the angle of
the lighting or the Display, or operate the remote control unit closer to the remote control
sensor window.
•
•
•
30º 30º
30º
30º
Reset
button
6
5 m
Remote control sensor
LC-65XS1M_en.indd 6LC-65XS1M_en.indd 6 2009/01/15 16:02:472009/01/15 16:02:47

Quick guide
Set the TV and antenna cables (Page 9)
Display:
Select the location of the TV.
HDMI cable fixture:
Connect the supplied HDMI cable with one side connected to the Display
as in step 1to the DISPLAY OUTPUT on the AVC System. Connect the
cable to the AVC System with the supplied HDMI cable fixture.
2
•
•
Prepare the Display (Page 8)
HDMI cable:
Connect the supplied HDMI cable to the HDMI terminal on the Display.
Fix the cable to the Display with the supplied HDMI cable holder then.
1
•
Connect external devices or sound components
(Pages 13–15)
If desired, connect external devices such as a DVD recorder.
Cables and terminals may vary depending on the devices you use.
3
•
•
Prepare remote control unit (Page 6)
Insert the supplied “AAA” size alkaline batteries into the remote control unit.
4
•
Turning on and running the initial auto installation
Turn on the TV power (Page 11)
Plug the AC cord into AC outlet.
Press POWER on the Display to turn on the main power of the Display.
5
•
•
Conduct initial auto installation (Page 10)
The initial auto installation wizard appears automatically (only the first time the TV is turned on).
6
•
Initial installation overview
Follow the steps below one by one when using the TV for the first time. Some steps may not be necessary
depending on your TV installation and connection.
Before turning on the main power
7
LC-65XS1M_en.indd 7LC-65XS1M_en.indd 7 2009/01/15 16:02:492009/01/15 16:02:49

Quick guide
Before turning on the main power
Preparing the Display
Make sure the Display is turned off before beginning work.
Before performing work, spread cushioning over the surface on which you will be laying the Display. This will
prevent it from being damaged.
Connecting the HDMI cable with the HDMI cable holder
•
•
NOTE
These are terminals for the speaker of the TV. Do not connect any other kind of cables.
Do not disconnect the speaker cable unless absolutely necessary. If you disconnect the speaker cable, confirm each colour of
the speaker plugs and speaker terminals (the order of the colour from left to right: red/black/white).
Handling and precautions with the wall-mounted Display
You can mount the Display on the wall using the optional AN-65AG2 bracket.
For details, refer to the instructions supplied with the optional bracket.
CAUTION
This Display should be mounted on the wall only with the AN-65AG2 (SHARP) wall mount bracket.
The use of other wall mount brackets may result in an unstable installation and may cause serious
injuries.
Installing the Liquid Crystal Television requires special skill that should only be performed by
qualified service personnel. Customers should not attempt to do the work themselves. SHARP bears
no responsibility for improper mounting or mounting that results in accident or injury.
Using an optional bracket to mount the Display
You can ask a qualified service personnel about using an optional AN-65AG2 bracket to mount the Display to the wall.
Carefully read the instructions that come with the bracket before beginning work.
*
•
•
•
•
•
•
•
NOTE
Detach the cable clamps on the rear of the Display when using the optional mount bracket.•
AN-65AG2
Vertical mounting
8
HDMI cable
(supplied) HDMI cable
holder
(supplied)
Press down on
the upper hook
and remove the
rear terminal cover,
pulling towards
you.
1Connect the
HDMI cable to
the Display.
2Affix the HDMI
cable holder by
pressing down.
3
Speaker cable*
Hanging on the wall
AN-65AG2 wall mount bracket.
(See the bracket instructions for details.)
About setting the Display angle
You can check the centre of the TV
screen using the mark engraved
on the wall mount bracket when
mounting the Display on the wall.
The centre of the TV screen is at mark
“A” on the wall bracket.
LC-65XS1M_en.indd 8LC-65XS1M_en.indd 8 2009/01/15 16:02:512009/01/15 16:02:51

12 3
Quick guide
Setting the TV and antenna cables
Connect the HDMI cable
to the DISPLAY OUTPUT
terminal on the AVC System.
1Attach the parts of the fixture
to the HDMI cable, pushing
the tab upward.
2Insert the tab for the fixture
into the fixture anchor hole on
the AVC System.
3
Handling the AVC System
CAUTION
Do not put a VCR or other device on top of the AVC System.
Keep enough space above and to the sides of the AVC
System.
Do not block the ventilation openings on the top and left side or
the exhaust fan on the right side.
Do not spread a thick cloth beneath the AVC System or cover it with one, as this can cause overheating and result in
malfunction.
•
•
•
•
5cm
5cm 5cm
NOTE
The POWER indicator of the AVC System lights up when the main power is turned on after connecting the Display and AVC System using the
supplied HDMI cable.
The HDMI cable should be firmly connected. Failure to do so will loosen the cable and cause a contact failure when moving the AVC System.
This can cause result in an error message appearing on the screen without a visible picture.
•
•
9
Standard
DIN45325 plug
(IEC 169-2) 75 q
coaxial cable
Connecting the HDMI cable with the
fixture
HDMI cable (supplied)
Do not use excessive
force when inserting/
removing the HDMI
cable. The terminal or
cable may become
damaged.
The fixture
anchor hole
LC-65XS1M_en.indd 9LC-65XS1M_en.indd 9 2009/01/15 16:02:532009/01/15 16:02:53

Turning on and running the initial auto installation
Plugging the AC cord to the AC outlet
Initial auto installation
When the TV powers on for the first time after purchase, the initial auto installation wizard appears. Follow the
menus and make the necessary settings one after another.
Confirm the following before turning on the power.
Are the Display and AVC System connected using the supplied HDMI cable?
Is the antenna cable connected?
Is the AC cord plugged in?
Press POWER on the Display.
The initial auto installation wizard appears.
Setting the on-screen display language.
Press a/bto select the desired language, and then press ENTER.
Selecting the location of the TV.
Press c/dto select where you will use this TV, and then press ENTER.
HOME: “STANDARD” will be the default value for the “AV MODE” setting.
STORE: “DYNAMIC (Fixed)” will be the default value for the “AV MODE” setting. If the “AV MODE” is changed, the TV will
automatically switch back to “DYNAMIC (Fixed)” when there is no signal input from the TV or remote control unit for 30
minutes.
Auto installation will be executed.
You do not need to do anything during the auto search.
NOTE
If you press RTN (RETURN) in step 2, the initial auto installation wizard does not appear. The auto installation function allows you to execute the
installation again from the Setup menu. (See page 25.)
•
•
•
1
•
2
3
4
•
•
•
•
•
Quick guide
10
AC cord*
AC cord*
Place the TV close to the AC
outlet, and keep the power
plug within reach.
Product shape varies in some countries.*
English
STOREHOME
AC outlet r
AC outlet r
LC-65XS1M_en.indd 10LC-65XS1M_en.indd 10 2009/01/15 16:02:552009/01/15 16:02:55

Watching TV
Daily operation
Switching on/off
Turning on/off the main power
Press POWER on the Display.
Switch it off by pressing POWER on the Display.
Standby mode
To standby mode
If the TV is switched on, you can switch it to standby
by pressing TV POWER on the remote control unit or
POWER on the AVC System.
Switching on from standby
From standby, press TV POWER on the remote
control unit or POWER on the AVC System.
E
E
Selecting an external video source
Once the connection is made,
press INPUT to display the “INPUT
SOURCE” screen, and then press a/
bto switch over to the appropriate
external source with ENTER.
POWER indicator status (Display/AVC
System)
POWER indicator Status
Off Power off
Blue Power on
Red Standby
NOTE
If you are not going to use this TV for a long period of time, be sure
to remove the AC cords from the AC outlet.
A small amount of electric power is still consumed even when
POWER is turned off.
•
•
Changing channels
With 0–9:
With CH r/s:
Auto power-off at a designated time
This function is conveniently used when, for instance,
going to bed while watching TV.
Press SLP (SLEEP).
Remaining time displays when sleep timer has been
set.
Each time you press SLP (SLEEP), the remaining
time switches as shown below.
1
•
2
0 hr. 30 min. 1 hr. 00 min. 1 hr. 30 min.
2 hr. 30 min. 2 hr. 00 min.
Off
Sleep Timer: Remain 2 hr. 00 min.
11
NOTE
When turning off the main power
using POWER on the Display, and
programmed timer recordings will
not be performed by the TV.
•
INPUT SOURCE
TV
INPUT1
INPUT2
INPUT3
INPUT4
INPUT5
LC-65XS1M_en.indd 11LC-65XS1M_en.indd 11 2009/01/15 16:02:562009/01/15 16:02:56

Watching TV
Selecting a sound mode
You can switch between multiple audio modes
when watching a multiple audio or stereo broadcast
programme.
In the NICAM TV broadcasts
When receiving a stereo signal
Each time you press MPX, the mode switches
between NICAM STEREO and MONO.
Stereo mode
B/G
STEREO
01
BBC1
B/G
MONO
PAL
NICAM
PAL
01
TV TV
BBC1
When receiving a bilingual signal
Each time you press MPX, the mode switches among
NICAM CH A, NICAM CH B, NICAM CH AB and
MONO.
Bilingual mode
B/G
CH A
01
BBC1
B/G
CH B
PAL
NICAM
PAL
NICAM
01
TV TV
BBC1
B/G
MONO
01
BBC1
B/G
CH AB
PAL PAL
NICAM
01
TV TV
BBC1
When receiving a monaural signal
Each time you press MPX, the mode switches
between NICAM MONO and MONO.
Monaural mode
B/G
MONO
01
BBC1
B/G
MONO
PAL
NICAM
PAL
01
TV TV
BBC1
In the TV mode of A2 TV broadcasts
When receiving a stereo signal
Each time you press MPX, the mode switches
between STEREO and MONO.
Stereo mode
B/G
STEREO
01
BBC1
B/G
MONO
PAL PAL
01
TV TV
BBC1
When receiving a bilingual signal
Each time you press MPX, the mode switches among
CH A, CH B and CH AB.
Bilingual mode
B/G
CH A
01
BBC1
B/G
CH B
PAL PAL
01
TV TV
BBC1
B/G
CH AB
PAL
01
TV
BBC1
When receiving a monaural signal
When you press MPX, “MONO” displays.
Monaural mode
B/G
MONO
PAL
01
TV
BBC1
NOTE
“BBC1”, “99” and “PAL” are tentative network name,
channel and colour system.
•
12
LC-65XS1M_en.indd 12LC-65XS1M_en.indd 12 2009/01/15 16:03:022009/01/15 16:03:02

Connecting external devices
Before connecting ...
Be sure to turn off the TV and any devices before making any connections.
Firmly connect a cable to a terminal or terminals.
Carefully read the operation manual of each external device for possible connection types. This also helps you get the best
possible audiovisual quality to maximise the potential of the TV and the connected device.
Refer to page 34 for connecting a PC to the AVC System.
Introduction to connections
The AVC System is equipped with the terminals as shown below. Find the cable corresponding the terminal and connect the device.
NOTE
The cables illustrated in pages 13–15 are commercially available items.
E
•
•
•
•
•
S-video cable*
When using an S-video cable, you also need to connect an audio cable (R/L).*
13
Audio/VCR (Page 15)
Video recording device
(Page 14)
Game console or camcorder
(Page 14)
HDMI-certified cable
DVI/HDMI cable
ø 3.5 mm stereo minijack cable
AV cable*
AV cable
Optical audio cable
AV cable
Component cable
Audio cable
HDMI device (Page 14)
or
or or
Rear view
Front view
LC-65XS1M_en.indd 13LC-65XS1M_en.indd 13 2009/01/15 16:03:042009/01/15 16:03:04

Connecting external devices
HDMI connection
The HDMI connections permit digital video and audio
transmission via a connection cable from a player/
recorder. The digital picture and sound data are
transmitted without data compression and therefore
lose none of their quality. Analogue/digital conversion
is no longer necessary in the connected devices,
which also would result in quality losses.
DVI/HDMI conversion
Using a DVI/HDMI cable, the digital video signals of
a DVD can also be played via the compatible
HDMI
connection. The sound must be fed in additionally.
When connecting a DVI/HDMI cable to the HDMI terminal,
the image may not come in clearly.
Both HDMI and DVI use the same HDCP copy protection
method.
NOTE
Video noise may occur depending on the type of HDMI cable used.
Make sure to use a certified HDMI cable.
When playing the HDMI image, the best possible format for the
picture will be detected and set automatically.
Supported video signal:
576i, 576p, 480i, 480p, 1080i, 720p, 1080p
See page 37 for PC signal compatibility.
•
•
•
•
Component connection
You will enjoy accurate colour reproduction and high
quality images through INPUT5 terminals or INPUT6
terminals when connecting a DVD player/recorder or
other device.
YPB
(CB)
LRPR
(CR)
COMPONENT AUDIO
S-VIDEO/VIDEO connection
You can use INPUT4 terminals when connecting to a
game console, camcorder, a DVD player/recorder or
other device.
NOTE
When using an S-video cable, you also need to connect an
audio cable (R/L).
The COMPONENT terminals of INPUT5 and INPUT6 and
S-VIDEO terminals of INPUT4 have priority over the VIDEO
input terminal for each.
•
•
14
DVI/HDMI
cable
ø 3.5 mm
stereo
minijack
cable
HDMI-certified
cable
Audio cable
Component
cable
AV cable
Example of connectable devices
DVD player/recorder E Blu-ray player/recorder
Game console
E
E
Example of connectable devices
VCR E DVD player/recorder
Blu-ray player/recorder
E
E
Example of connectable devices
VCR E DVD player/recorder
Blu-ray player/recorder
Game console E Camcorder
E
E
E
YPB
(CB)
PR
(CR)
After connecting
HDMI Audio Select
After connecting, you must set the audio signal
compatible with the cable you use for the HDMI
device.
Go to “MENU” > “Option” > “HDMI Audio
Select”.
Select “Digital” for audio signals via the
HDMI terminal. Select “Analogue” for audio
signals via the AUDIO jack (INPUT1 (HDMI)).
E
1
2
or
S-video cable
or
LC-65XS1M_en.indd 14LC-65XS1M_en.indd 14 2009/01/15 16:03:082009/01/15 16:03:08

Connecting external devices
DIGITAL AUDIO IN INPUT
VIDEO R L
Connecting a VCREConnecting an amplifier with digital audio
input
E
Speaker/VCR connection
Connect an amplifier/VCR with external speakers as shown below.
15
Optical audio cable
AV cable
VCRAmplifier with
digital audio input
LC-65XS1M_en.indd 15LC-65XS1M_en.indd 15 2009/01/15 16:03:112009/01/15 16:03:11

AQUOS LINK
Controlling HDMI devices using AQUOS LINK
What is AQUOS LINK?
Using the HDMI CEC (Consumer Electronics Control) protocol, with AQUOS LINK you
can interactively operate compatible system devices (AV amplifier, DVD, Blu-ray Disc
device) using a single remote control.
NOTE
Please check the availability of AQUOS LINK compatible AQUOS BD Player and AQUOS LINK
compatible audio system via the sale agent in your contry.
What you can do with AQUOS LINK
One Touch Play
When the TV is in standby mode, it automatically turns on and play back the image
from the HDMI source.
Single remote control operation
AQUOS LINK automatically recognises the connected HDMI devices and you can
control the TV and the devices as if using a universal remote control.
Operating Title list of external devices
You can also call up the external player’s Top menu or AQUOS BD Player’s Title list
provided that the devices support AQUOS LINK.
Multiple control of HDMI devices
You can select which HDMI device to operate using the OPTION.
Controlling the AQUOS LINK compatible audio system
You can adjust the volume and select the sound mode of the AQUOS LINK
compatible audio system.
NOTE
Point the remote control toward the TV, not to the connected HDMI device.
Video noise may occur depending on the type of HDMI-certified cable used. Make sure to use
a HDMI-certified cable.
Up to 3 pieces of HDMI recording equipment and one AV amplifier can be connected using
this system.
These operations affect the HDMI device selected as the current input source. If the device
does not operate, turn on the device and select the appropriate input source using INPUT.
When you insert/remove HDMI-certified cables or change connections, turn on all connected
HDMI devices before turning on the TV. Confirm that picture and audio are correctly output by
selecting “INPUT1”, “INPUT2” or “INPUT3” from the INPUT SOURCE menu.
•
✔
✔
✔
✔
✔
•
•
•
•
•
AQUOS LINK connection
First connect the AQUOS LINK compatible audio system or an AQUOS BD Player that supports the HDMI CEC
protocol.
NOTE
Refer to the operation manual of the device to be connected for further details.
After unplugging connection cables or changing the connection pattern, first turn on the main power of the Display with all
relevant devices’ power turned on. Change the external input source by pressing INPUT, select the appropriate input source
and verify the audiovisual output.
The cables illustrated in the following explanation are commercially available items.
•
•
•
16
LC-65XS1M_en.indd 16LC-65XS1M_en.indd 16 2009/01/15 16:03:122009/01/15 16:03:12

AQUOS LINK
Connecting an AQUOS BD
Player only
Connecting an AQUOS BD Player via the AQUOS LINK
compatible audio system
HDMI-certified cable
AQUOS LINK compatible
audio system
HDMI-certified cable
AQUOS BD Player
Optical
Fibre
cable
AQUOS BD Player
HDMI-certified
cable
AQUOS LINK Setup
AQUOS LINK Control
Set to “On” to enable AQUOS LINK functions.
Press MENU and the “MENU” screen displays.
Press c/dto select “Option”.
Press a/bto select “AQUOS LINK Setup”, and
then press ENTER.
Press a/bto select “AQUOS LINK Control”,
and then press ENTER.
Press c/dto select “On”, and then press
ENTER.
Auto Power On
If this is activated, the One Touch Play function
is enabled. While the TV is in standby mode, it
automatically turns on and plays back the image from
the HDMI source.
Repeat steps 1 to 3 in AQUOS LINK Control.
Press a/bto select “Auto Power On”, and then
press ENTER.
Press c/dto select “On”, and then press
ENTER.
NOTE
The factory default for this item is “Off”.
Selecting Recorder
You can select a recorder for the recording from
several connected recorders.
Repeat steps 1 to 3 in AQUOS LINK Control.
Press a/bto select “Selecting Recorder”, and
then press ENTER.
1
2
3
4
5
1
2
3
•
1
2
Select the recorder, and then press ENTER.
NOTE
If you have connected the AQUOS LINK compatible audio
system between the AVC System and a CEC-compatible
recorder, the external source’s indication changes from
“INPUT1” to “INPUT1 (Sub)”.
Selecting Channel Key
This function allows you to select the channel of the
connected HDMI device using the TV’s remote control
unit.
Repeat steps 1 to 3 in AQUOS LINK Control.
Press a/bto select “Selecting Channel Key”,
and then press ENTER.
Press a/bto select the input source of the
connected HDMI device you want to control
using the TV’s remote control unit, and then
press ENTER.
Press c/dto select “On”, and then press
ENTER.
3
•
1
2
3
4
17
LC-65XS1M_en.indd 17LC-65XS1M_en.indd 17 2009/01/15 16:03:132009/01/15 16:03:13

AQUOS LINK
Open the remote control unit’s flip cover, and
then press OPTION.
Press a/b to select “Setup Menu”, and then
press ENTER.
NOTE
If a connected device does not have this function or the device is in
a status where the menu cannot be displayed (recording, entering
standby, etc.), this function may not be available.
Playback of titles using AQUOS LINK
This section explains how to play back a title in the
AQUOS BD Player.
Open the remote control unit’s flip cover, and
then press OPTION.
Press a/bto select “Top Menu/Title List”, and
then press ENTER.
The linked recorder now powers on and the TV
automatically selects the appropriate external input
source.
The title list data from the connected AQUOS BD
Player displays.
Select the title with a/b/c/d, and then press
PLAY I.
Selecting media type for CEC-compatible
recorder
If your recorder has multiple storage media, select the
media type here.
Open the remote control unit’s flip cover, and
then press OPTION.
Press a/b to select “Media change”, and then
press ENTER.
Select the desired medium, such as DVD or
HDD. The media type changes every time you
press ENTER.
HDMI device selection
If multiple HDMI devices are connected in a daisy
chain, you can specify which device to control here.
Open the remote control unit’s flip cover, and
then press OPTION.
Press a/bto select “Model select”, and then
press ENTER. The HDMI device changes every
time you press ENTER.
Recording via the CEC-compatible
recorder’s EPG (only for recorders)
You can call up the CEC-compatible recorder’s EPG and
preset timer recordings using the TV’s remote control unit.
Open the remote control unit’s flip cover, and
then press OPTION.
Press a/b to select “Recorder EPG”, and then
press ENTER.
The external input source switches and the recorder’s
EPG is displayed.
Select the programme to record.
You can use a/b/c/d, RTN (RETURN), EXIT and
the coloured buttons.
NOTE
Refer to the operation manual of the recorder for details.
1
2
•
1
2
•
•
3
1
2
3
1
2
1
2
•
3
•
•
Operating an AQUOS LINK device
AQUOS LINK allows you to operate the HDMI-
connected device with one remote control.
Open the remote control unit’s flip cover.
Press PLAY Ito start playback of a title.
See this page, section “Playback of titles using
AQUOS LINK” if you want to start playback using the
list of the titles of the AQUOS BD Player.
Press FWD J to fast forward.
Press REV G to reverse.
Press STOP H to stop.
Press POWER to turn the HDMI-connected device
on/off.
Listening with the AQUOS LINK compatible audio system
You can opt to listen to the TV sound only from the
AQUOS LINK compatible audio system.
Open the remote control unit’s flip cover, and
then press OPTION.
AQUOS LINK Menu
Recorder EPG
Top Menu/Title List
Media change
By AQUOS AUDIO SP
By AQUOS SP
Sound mode change
Setup Menu
Model select
Press a/b to select “By AQUOS AUDIO SP”,
and then press ENTER.
The sound from the TV speaker and headphone
terminal is silenced and only the sound from the
AQUOS LINK compatible audio system is audible.
You can use VOLk/land M(Mute).
Listening with the AQUOS TV speaker system
You can opt to listen to the TV sound only from the
AQUOS TV speaker system.
Open the remote control unit’s flip cover, and
then press OPTION.
Press a/b to select “By AQUOS SP”, and then
press ENTER.
Manually changing the AQUOS LINK
compatible audio system’s sound mode
Open the remote control unit’s flip cover, and
then press OPTION.
Press a/b to select “Sound mode change”.
The sound mode changes every time you press
ENTER.
Refer to the operation manual of the AQUOS LINK
compatible audio system for details.
Calling up the menu of an external device
connected with the TV via HDMI
You can call up the menu of an HDMI CEC-compatible
external device (player, recorder, decoder, etc.) using
the “Setup Menu” function.
1
2
•
3
1
2
•
•
1
2
1
2
3
•
18
LC-65XS1M_en.indd 18LC-65XS1M_en.indd 18 2009/01/15 16:03:172009/01/15 16:03:17
