Sharp Carousel R-1514 User manual

R-1514
• Clean and uncluttered design with concealed
Auto-Touch
®
Control Panel located behind the
oven's door; the controls are easy to reach and
hidden from view.
•Deluxe Stainless Steel appearance with smooth
glass window—elegant and practical.
•Large 14 1/8-inch diameter Carousel
®
turntable—the largest turntable of any
microwave oven in its class—for added capacity
and versatility.
•Sensor Cook
®
Center includes 11 Smart & Easy
®
sensor settings for the most popular
microwaved foods. No need to set times or
power levels—and no guesswork!
f
eatures
COLOR : Stainless Steel
with glass window
cookware
2 qt. oblong
4 qt. oval / 5 qt. round
Ideal for
6-8 servings
14
1
/ 8 "
Carousel
®
turntable
full size over the range
1.5 cu. ft.
1000 watts
R-1514 Over the Range Microwave Oven
•Interactive Cooking System with Custom Help
®
includes options for English,Spanish or French.
•Defrost Center quickly defrosts meats and
poultry by weight. Specific program for each
category assures excellent,even results.
•Keep Warm Plus lets you keep hot food hot
up to 30 minutes after cooking is finished
with no loss of food quality.
•Instant Action™Keys save time and make
microwaving easy! Touch once for each
serving— up to eight. Oven starts automatically.
•Powerful 300 CFM Ventilation System with
2-speed fan,work light and night light.

S
T
OP
C
LEA
R
LI
G
HT H
I
/
L
O
FAN HI
/
L
O
S
TAR
T
MIN
U
TEPL
US
OVEN CAPACITY 1.5 cu.ft.
COOKING UNIFORMITY Carousel Turntable System
14
1
/ 8 " diameter glass turntable
DISPLAY 7-digit,2-color,lighted
CONTROL Concealed Auto-Touch Controls
SPECIAL FEATURES Keep Warm Plus, Automatic Popcorn Sensor,Hot Water
Setting,Sensor Cook Center (baked potatoes, reheat,
fresh vegetables, ground meat,rice, fish & seafood,
frozen entrees, chicken breast,frozen vegetables),
Instant Action (fresh rolls & muffins,beverages, frozen rolls
& muffins),Defrost Center (ground meat,boneless poultry,
steaks/chops,bone-in poultry), Custom Help,Minute Plus,
Kitchen Timer,4-Stage Programming, 11 Variable Power
Levels, 300 CFM 2-Speed Ventilation Fan,Work Light
(high/low settings),Child Lock,Audible Signal Elimination,
Demonstration Mode
COLOR Stainless steel with glass window
OVEN INTERIOR Acrylic with light
OUTPUT POWER 1000 Watts
OUTSIDE DIMENSIONS (WHD) 29
15
/ 16 " x 16
1
/ 4 " x 15
9
/ 16 "
OVEN DIMENSIONS (WHD) 17
1
/ 2 " x 9
7
/ 8 " x 14
15
/ 16 "
APPROX.WEIGHT Net : 55 lb. Shipping : 63 lb.
AC LINE VOLTAGE 120 Volts,single phase,60 Hz, AC only
AC POWER REQUIRED 1.64 kW,14 Amps
SAFETY COMPLIANCE FCC,DHHS,UL listed
UPC CODE 074000 610422
OPTIONAL ACCESSORIES RK-240 Charcoal filter for non-ducted installations included
with product. Replacement filters available at extra cost.
Design and specifications subject to
change without notice.
Patent Pending
US patent application no.29/149,000
S
pecifications
R-1514 Over the Range
LIMITED WARRANTY : 7 years on
magnetron tube,1 year on all other parts,
1 year on related labor and in-home service.
See Operation Manual or your dealer for
complete details.
Sharp Electronics Corporation
Sharp Plaza • Mahwah • NJ 07430-2135
1-800-BE-SHARP •www.sharpusa.com
© 2002 Sharp Electronics Corporation
Dimension Express :
To receive the most current specifications,
call Dimension Express at [phone]
from a fax machine. Enter code 9026 for
instructions and a directory of Sharp
microwave oven products.
12.0"
30.0"
66" or more
from floor
30" or more from
cookingsurface
Each Sharp Over the Range
microwave oven can be
easily adapted for either
outside ventilation
(vertical or horizontal) or
non-vented, ductless
recirculation. Make sure
the top of oven will be at
least 66" from the floor and
at least 30" from the
cooking surface. A separate
15 amp.or greater electrical
receptacle must be located
in the cabinet directly
above the microwave oven.
