Sharp R-21FBSTM Instruction Manual

800W (IEC 60705)
OPERATION MANUAL
with COOKBOOK
R-21FBSTM /
R-22FBSTM
MICROWAVE OVEN
R-21+22FBSTM Operation Manual 22/10/2003 09:40 Page A

OPERATION MANUAL
This operation manual contains important information which you
should read carefully before using your microwave oven.
IMPORTANT:
There may be a serious risk to health if this operation manual is
not followed or if the oven is modified so that it operates with the
door open.
If you require any advice or assistance regarding your
Sharp product, please visit our website:
www.sharp.co.uk/customersupport
Customers without Internet access may telephone:
08705 274277 (9am - 5pm)
[phone] (from Ireland)
R-21+22FBSTM Operation Manual 24/07/2003 09:30 Page B

1
CONTENTS
YOUR OVEN AND ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
CONTROL PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
SAFETY:
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 6
OPERATION:
Heating Category . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
How Your Oven Works . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Before Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Microwave Power Levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Setting the Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
How to Operate Your Oven . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 - 11
Automatic Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12 - 15
CONVENIENT FUNCTIONS:
Sequence Cooking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Auto Minute . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
COOKING ADVICE:
Microwave Cooking Advice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17 - 18
Suitable Cookware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Defrosting Advice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Reheating Advice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
AFTERCARE:
Cleaning and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23 - 24
To Replace the Mains Plug . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Calling for Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
COOKBOOK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26 - 39
GUARANTEE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
R-21+22FBSTM Operation Manual 24/07/2003 09:30 Page 1

2
YOUR OVEN AND ACCESSORIES
1
2
9
4678 5
OVEN:
1. Front trim
2. Oven lamp
3. Control panel
4. Waveguide cover (DO NOT REMOVE)
5. Seal packing
6. Oven cavity
7. Door seals and sealing surfaces
8. Door latches
9. Door opening handle
10. Fixing points (4 points)
11. Ventilation openings
12. Outer cabinet
13. Power cord support clip
14. Power cord
3
15
16
ACCESSORIES:
Check to make sure the following accessories are
provided:
15. Turntable 16. Roller stay
17. 4 fixing screws (not shown)
•Place the roller stay in the seal packing on the
floor of the cavity, then place the turntable on
to the roller stay, ensuring it is located firmly.
•To avoid turntable damage, ensure dishes or
containers are lifted clear of the turntable rim
when removing them from the oven.
NOTES:
•The waveguide cover is fragile. Care should be taken when cleaning inside the oven to ensure that it
is not damaged.
•After cooking fatty foods without a cover, always clean the cavity thoroughly, this must be dry and
free from grease. Built-up grease may overheat and begin to smoke or catch fire.
•Always operate the oven with the turntable and roller stay fitted correctly. This promotes thorough,
even cooking. A badly fitted turntable may rattle, may not rotate properly and could cause damage
to the oven.
•The turntable rotates clockwise or anti-clockwise. The rotary direction may change each time you
start the oven. This does not affect cooking performance.
•When you order accessories, please quote both the PA RT NAME and MODEL NUMBER to
your dealer or SHARP approved service facility. The model number is located at the bottom of the
control panel.
WARNING:
The door, front trim, oven cavity, turntable and dishes will become very hot during
operation. To prevent burns, always use thick oven gloves.
14
13 11
10
12
R-21+22FBSTM Operation Manual 24/07/2003 09:30 Page 2

3
CONTROL PANEL
1
2
3
1. DIGITAL DISPLAY
2. INDICATORS
The appropriate indicator will flash or light up,
just above each symbol according to the
instruction. When an indicator is flashing,
press the required button (having the same
symbol) or do the necessary operation.
Stir
Turn over
Weight
Microwave power level
Cook
BUTTONS AND KNOB:
3. AUTOMATIC
4. POWER LEVEL
5. STOP
6. START/AUTO MINUTE
7. TIME/WEIGHT
4
5
6
7
R-21+22FBSTM Operation Manual 24/07/2003 09:30 Page 3

4
IMPORTANT SAFETY INSTRUCTIONS
•Remove all packing materials including the
feature sticker (if present). Do not remove the
plastic film from the inside of the oven window
as this protects it from dirt.
The waveguide cover prevents food and grease
from entering the waveguide
area where it could cause
damage.
DO NOT REMOVE THE
WAVEGUIDE COVER.
•Make sure the power supply cord is
undamaged (See “ELECTRICAL
CONNECTION” on page 6).
Do not allow the power supply cord to
run over any hot or sharp surfaces, such
as the hot air vent area at the top rear of
the oven.
•The socket must be readily accessible so that it
can be easily unplugged in an emergency.
•Do not use the oven outdoors.
Oven Use:
•The oven is for domestic use only.
•Never operate the oven when empty.
•Do not leave or store anything inside the oven
when not in use.
•Never attempt to use the oven with the door
open. It is important not to force or tamper
with the door safety latches.
•Never operate the oven with any object caught
in the door.
•Do not insert fingers or objects in the holes of
the door latch openings as this may damage
the oven and cause an electric shock.
Pacemaker: If you have a heart pacemaker,
consult your doctor or the pacemaker
manufacturer prior to oven use. FIRE: If smoke is observed, switch off
and unplug the appliance and keep the
door closed in order to stifle any flames.
PLEASE READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
LIQUIDS: Microwave heating of
beverages can result in delayed eruptive
boiling, therefore care has to be taken
when handling the container. Stir the
liquid prior to and during heating/
reheating, let liquid stand for at least 20
seconds in the oven after cooking.
INSTALLATION
WARNING:
Inspect the Oven:
•Check the oven carefully for damage
before and regularly after installation.
•Make sure the door closes properly,
that it is not misaligned or warped.
•Check the hinges and door safety
latches are not broken or loose.
•Ensure the door seal and sealing
surfaces are not damaged.
•Inspect the oven interior and door for
dents.
IMPORTANT:
If any damage is apparent, do not
operate the oven in any way, until it has
been repaired by a SHARP trained
engineer. (See page 25 for details).
WARNING: Do not allow children
to use the oven without supervision
until adequate instructions have been
given, so that the child is able to use the
oven in a safe way and understands the
hazards of improper use.
R-21+22FBSTM Operation Manual 24/07/2003 09:30 Page 4

5
INSTALLATION
•This appliance has been tested and approved for use near domestic gas, electric and induction
hobs only.
•Sufficient space between hob and microwave should be allowed to prevent overheating of
microwave oven, surrounding cupboard and accessories.
•Do not operate the hob without pans
when the microwave oven is operating.
•The cupboard must be a minimum of
500 mm (A) above the worktop and
must not be installed directly above a
hob or other kitchen appliance e.g.
conventional oven or refrigerator.
•Care should be taken when attending
to the microwave oven while the hob
is on.
•The front of the oven can be cleaned
with mild soap and water.
Do not use commercial oven cleaners,
abrasive harsh cleaners, or those that
contain Sodium Hydroxide.
AA
SAFE USE OF THE APPLIANCE
1. Remove all packaging and check carefully for
any signs of damage.
2. Fit the appliance into the kitchen cupboard
slowly, and without force, until the front
frame of the oven seals against the front
opening of the cupboard.
3. Ensure the appliance
is stable and not
leaning. Ensure that a
5mm gap is kept
between the
cupboard door above
and the top of the
frame (see diagram).
4. Fix the oven in position with
the screws provided.
The fixing points are located
on the top and bottom
corners of the oven (see
diagram, item 10, on page 2).
5. It is important to ensure that the installation
of this product conforms to the instructions in
this operation manual and the hob
manufacturer’s installation instructions.
If you require assistance concerning the
installation of the appliance, please contact
your nearest authorized Sharp service agent,
see page 25 for details.
5 mm
INSTALLING THE APPLIANCE
R-21+22FBSTM Operation Manual 24/07/2003 09:30 Page 5

6
INSTALLATION
IMPORTANT!
•The fuse from the cut-off plug should be
removed and the plug disposed of in a safe
manner.
•Under no circumstances should the cut-off
plug be inserted into a socket outlet as a
serious electric shock may occur.
•The plug must not be used without the fuse
cover fitted.
•If you have any doubt about your microwave
oven obtain the help of a qualified electrician.
•When replacing the plug please ensure that
you use a BSI or ASTA approved plug to
BS1363, this should be fitted with a brown
coloured 13 amp fuse approved by BSI or
ASTA to BS1362. If you have any doubt about
electrical connection seek the help of a
qualified electrician.
WARNING: THIS APPLIANCE
MUST BE EARTHED
To wire an appropriate plug, follow the wiring
code given in `To replace the mains plug’ on
page 25.
ELECTRICAL CONNECTION.
•Do not allow water to come into contact with
the power supply cord or plug.
•Insert the plug properly into the socket.
•Do not connect other appliances to the same
socket using an adaptor plug.
•If the power supply cord is damaged, it must
be replaced by a SHARP approved service
facility or a similarly qualified person to avoid a
hazard.
•When removing the plug from the socket
always grip the plug, never the cord as this may
damage the power supply cord and the
connections inside the plug.
•If the plug fitted to your oven is a rewireable
type and in the event of the socket outlet in
your home not being compatible with the plug
supplied, remove the plug properly (do not cut
off).
•If the plug fitted to your oven is a non-
rewirable type and in the event of the socket
outlet in your home not being compatible with
the plug supplied, cut-off the mains plug.
•Refit with a suitable type, observing the wiring
code given in `To replace the mains plug’ on
page 25.
•The electrical outlet should be readily accessible so
that the unit can be unplugged easily in an emergency.
•The socket should not be postioned behind the
cupboard.
•The best position is above the cupboard, see (A).
When not connecting the power supply cord to position (A) it
should be removed from the support clip (see diagram, item 13,
on page 2) and routed under the oven.
•Connect the appliance a single phase 230-240V/50Hz
alternating current via a correctly installed earth socket.
The socket must be fused with a ≥10A fuse.
•If the appliance is to be operated in a non-European
country, the supply voltage, current type and frequency of the appliance indicated on
the rating plate must correspond with the specification of your power supply.
The rating plate can be found on the inside face of the control panel.
•The power supply cord may only be replaced by an electrician.
•Before installing, tie a piece of string to the power supply cord to facilitate connection to point (A)
when the appliance is being installed.
•When inserting the appliance into the high-sided cupboard, DO NOT crush the power supply cord.
CONNECTING THE APPLIANCE TO THE POWER SUPPLY
(A)
R-21+22FBSTM Operation Manual 24/07/2003 09:30 Page 6

7
HEATING CATEGORY
The heating category (a letter A to E) developed
by MAFF (Ministry of Agriculture, Fisheries and
Food) with microwave oven and food
manufacturers indicates the ability of the oven to
heat small quantities of food (up to 500g [1lb
2oz]). It does not represent the general
performance of the oven.
HOW YOUR OVEN WORKS
Microwaves are energy waves, similar to those
used for TV and radio signals.
Electrical energy is converted into microwave
energy, which is directed into the oven cavity via
a waveguide. To prevent food and grease entering
the wave guide it is protected by the waveguide
cover.
Microwaves cannot pass through metal, because
of this the oven cavity is made of metal and there
is a fine metal mesh on the door.
During cooking the microwaves bounce off the
sides of the oven cavity at random.
Microwaves will pass through certain materials,
such as glass and plastic, to heat the food.
(See ‘Suitable Cookware’ on page 19).
Water, sugar and fat in food absorb microwaves
which cause them to vibrate. This creates heat by
friction, in the same way your hands get warm
when you rub them together.
The outer areas of the food are heated by the
microwave energy, then the heat moves to the
centre by conduction, as it does in conventional
cooking. It is important to turn, rearrange or stir
food to ensure even heating.
Once cooking is complete, the oven
automatically stops producing microwaves.
Standing time is necessary after cooking, as it
enables the heat to disperse equally throughout
the food.
Microwave output power
in Watts (based on
international (IEC 60705)
standard).
600 700 800 900 1000 Watts
OVEN
OUTPUT
POWER
Less heating time required
More heating time required
OVEN
OUTPUT
CATEGORY
Less heating time required
More heating time required
Letter representing the
oven heating category.
Microwave Symbol.
A B C D E
Food packs carry cooking instructions for heating
categories A to E. Follow instructions for the
letter corresponding to the oven’s heating
category. The higher the output power and
heating category of the oven the less heating time
is required as shown opposite.
R-21+22FBSTM Operation Manual 24/07/2003 09:30 Page 7

8
BEFORE OPERATION
Plug in the oven.
1. The oven display will flash:
2. Press the STOP button.
3. The display will show:
1.
2.
3.
x1
MICROWAVE POWER LEVELS
Power Level Press the Percentage
POWER
LEVEL button
HIGH x 1 100P
MEDIUM HIGH x 2 70P
MEDIUM x 3 50P
MEDIUM LOW x 4 30P
(Defrost)
LOW x 5 10P
(Defrost)
•Your oven has 5 power levels, as shown
opposite.
•To change the power level for cooking, enter
the cooking time and then press the POWER
LEVEL button.
Power level:
The microwave power level is varied by the
microwave energy switching on and off.
When using power levels other than 100P you
will be able to hear the microwave energy pulsing
on and off as the food cooks or defrosts.
IMPORTANT: The microwave power level will
cook at 100P unless you press the POWER
LEVEL button to the desired setting.
Check the power level:
To check the microwave power level during
cooking, press the POWER LEVEL button.
As long as your finger is pressing the POWER
LEVEL button the power level will be displayed.
The oven continues to count down although the
display will show the power level.
POWER LEVEL
BUTTON
R-21+22FBSTM Operation Manual 24/07/2003 09:30 Page 8
