Sharp R-427DWM User manual

Intheinterestofuser-safetytheovenshouldberestoredtoitsoriginalconditionandonlypartsidenticaltothosespecifiedshould
be used.
WARNINGTOSERVICEPERSONNEL:Microwaveovenscontaincircuitrycapableofproducingveryhighvoltageand
current,contactwithfollowing partsmayresultin asevere,possiblyfatal, electricalshock.(HighVoltage Capacitor,
High Voltage Power Transformer, Magnetron, High Voltage Rectifier Assembly, High Voltage Harness etc..)
S70M146R427DS
MICROWAVE OVEN MODEL
SERVICE MANUAL
R-427DWM
ThisisasupplementalServiceManualforMicrowaveOvenmodelR-427DWM.
ThismodelisquitesimilartothebasemodelR-420DW(S/M#S60M144R420DE).
Thissupplementalmanualmustbeusedinconjunctionwiththebasemodelservicemanualforcompleteoperation,service,
safetyandreplacementpartsinformation.
PARTS LIST
Note: The parts marked “Д may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V.
"§" MARK: PARTS DELIVERY SECTION.
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
3- 2 FPNLCB316MRK0 M Control panel assembly 1 AX
3- 2-1 FUNTKB261MRE0 M Key Unit 1 AQ
5- 5 HPNL-B087MRE0 M Door Screen 1 AK
6- 7 TCAUAB031MRR0 M DHHS caution label -Spanish 1 AB
6- 8 TINSEB231MRR0 M Operation Manual-Spanish 1 AD
--- TCADCB013MRR0 M Cook Book 1 AW
SHARP CORPORATION This document has been published to be used for after
sales service only.
The contents are subject to change without notice.
SUPPLEMENTAL

OVEN DIAGRAM
1. One touch door open button.
Push to open door.
2. Door latches.
The oven will not operate unless the
door is securely closed.
3. Removable turntable support.
4. Removable turntable.
The turntable will rotate clockwise or
counterclockwise.
5. Oven lamp.
It will light when oven is operating or
door is opened.
6. Oven door with see-through window.
7. Ventilation openings. (Rear)
8. Auto-Touch control panel.
9. Time display: Digital display, 99
minutes 99 seconds.
10.Coupling.
11.Wave guide cover.
12.Power supply cord
TOUCH CONTROL PANEL
1
65
4
210
11
12
9
7
8
3
NOTE:
The directed features are disa-
bled after one minute when the
ovenisnotinuse.Thesefeatures
are automatically enabled when
the door is opened and closed or
theSTOP/CLEARpadispressed.
R-427DWM
