Sharp YC-GS02E User manual

YC-GS02E, YC-GG02E
Microwave oven
User manual
*Product images are for illustration purpose only. Actual product may vary.
EN PTDE FR NLES PL IT

EN
A. Information on Disposal for Users
(private households)
1. In the European Union
Attention: If you want to dispose of this equipment, please do not use the
ordinary dustbin!
Used electrical and electronic equipment must be treated separately and
in accordance with legislation that requires proper treatment, recovery and
recycling of used electrical and electronic equipment.
Following the implementation by member states, private households within
the EU states may return their used electrical and electronic equipment to
designated collection facilities free of charge*.
In some countries* your local retailer may also take back your old product free
of charge if you purchase a similar new one.
*) Please contact your local authority for further details.
If your used electrical or electronic equipment has batteries or accumulators,
please dispose of these separately beforehand according to local requirements.
By disposing of this product correctly you will help ensure that the waste
undergoes the necessary treatment, recovery and recycling and thus prevent
potential negative effects on the environment and human health which could
otherwise arise due to inappropriate waste handling.
2. In other Countries outside the EU
If you wish to discard this product, please contact your local authorities and ask
for the correct method of disposal.
For Switzerland: Used electrical or electronic equipment can be returned free of
charge to the dealer, even if you don't purchase a new product.
Further collection facilities are listed on the homepage of www.swico.ch or
www.sens.ch.
B. Information on Disposal for Business Users
1. In the European Union
If the product is used for business purposes and you want to discard it:
Please contact your SHARP dealer who will inform you about the take-back of
the product. You might be charged for the costs arising from take-back and
recycling. Small products (and small amounts) might be taken back by your
local collection facilities.
For Spain: Please contact the established collection system or your local
authority for take-back of your used products.
2. In other Countries outside the EU
If you wish to discard of this product, please contact your local authorities and
ask for the correct method of disposal.
Attention:
Your product
is marked with
this symbol.
It means that
used electrical
and electronic
products should
not be mixed
with general
household
waste. There
is a separate
collection
system for these
products.
EN-1EN-1

SPECIFICATIONS
Model name: YC-GS02E YC-GG02E
AC Line Voltage 230-240 V, 50 Hz single phase 230-240 V, 50 Hz single phase
Distribution line fuse/circuit breaker 10 A 10 A
AC Power required: Microwave 1200 W 1200 W
Output power: Microwave 700 W (IEC 60705) 700 W (IEC 60705)
Grill 1000 W
Off Mode less than < 0,5W less than < 0,5W
Microwave Frequency 2450 MHz* (Group 2/Class B) 2450 MHz* (Group 2/Class B)
Outside Dimensions (W) x (H) x (D) mm 452 x 262 x 345 452 x 262 x 345
Cavity Dimensions (W) x (H) x (D)** mm 315 x 198 x 297 315 x 198 x 297
Oven Capacity 20 litres** 20 litres**
Turntable ø 245 mm ø 245 mm
Grill rack ø 190 mm
Weight approx. 11,3 kg approx. 12,5 kg
Oven lamp 20 W 20 W
* - This Product fulls the requirement of the European standard EN55011.
In conformity with this standard, this product is classied as group 2 class B equipment.
Group 2 means that the equipment intentionally generates radio-frequency energy in the form of electromagnetic radiation for the heat treatment of
food.
Class B equipment means that the equipment is suitable to be used in domestic establishments.
** - Internal capacity is calculated by measuring maximum width, depth and height. Actual capacity for holding food will be less than this.
AS PART OF A POLICY OF CONTINUOUS IMPROVEMENT, WE RESERVE THE RIGHT TO ALTER DESIGN AND SPECIFICATIONS
WITHOUT NOTICE.
EN-2EN-2

EN
OVEN AND ACCESSORIES
OVEN
1. Door
2. Door hinges
3. Oven lamp
4. Waveguide cover (DO NOT REMOVE)
5. Control panel
6. Coupling
7. Door latches
8. Oven cavity
9. Door seals and sealing surfaces
10. Door safety latches
11. Ventilation openings
12. Outer cabinet
13. Power supply cord
14. Door opening
ACCESSORIES:
Check to make sure the following accessories are provided:
15. Turntable (glass)
16. Turntable support
17. Coupling
18. Rack (only for YC-GG02E)
• Place the turntable support in the centre of the oven oor so that it can freely
rotate around the coupling. Then place the turntable on to the turntable
support so that it locates rmly into the coupling.
• To avoid turntable damage, ensure dishes and containers are lifted clear of
the turntable rim when removing them from the oven.
• The rack is designed for use with grill ovens only. Do not use the rack when
using the microwave function.
• For use of the rack, refer to the GRILLING SECTIONS.
Never touch the grill when it is hot.
NOTE: When you order accessories, please mention two items: part name and
model name.
NOTES:
• The waveguide cover is fragile. Care should be taken when cleaning inside the oven to
ensure that it is not damaged.
• After cooking fatty foods without a cover, always clean the cavity and especially the grill heating element thoroughly, these
must be dry and free from grease. Built-up grease may overheat and begin to smoke or catch re.
• Always operate the oven with the turntable and turntable support tted correctly. This promotes thorough, even cooking. A
badly tted turntable may rattle, may not rotate properly and could cause damage to the oven.
• All food and containers of food are always placed on the turntable for cooking.
• The turntable rotates clockwise or anti-clockwise. The rotary direction may change each time you start the oven. This does
not affect cooking performance.
WARNING: This symbol means that the surfaces are liable to get hot during use.The door, outer
cabinet, oven cavity, accessories and dishes will become very hot during operation. To prevent burns,
always use thick oven gloves.
11
12
13
123
5
7
4
8
9
10
14
6
YC-GG02E
15
17 16
Hub (inside)
18 —
EN-3EN-3

CONTROL PANEL
1. FUNCTION
Press to select microwave power level, timer
function or combination mode.
LOW / - 280W
MED - 560W
HIGH - 700W
GRILL - 100% Grill
GRILL (Combi 1) - 70% Grill, 30% Micro
GRILL (Combi 2) - 44% Grill, 56% Micro
TIMER - kitchen timer
2. TIMER knob
Turn TIMER knob to set cooking time. The longest
time is 30 minutes. Then the oven starts cooking
automatically.
NOTE: To increase the cooking/defrosting time,
turn the timer knob to the right. To decrease the
cooking/defrosting time, turn the timer knob to
the left.
TIMER sec/min
1,5
3,0
4,0
Combi.1
Combi.2
5,0
10,0
TIMER sec/min
1,5
3,0
4,0
5,0
10,0
YC-GG02EYC-GS02E
EN-4EN-4

EN
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS:
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
To avoid the danger of re.
The microwave oven should not be left unattended
during operation. Power levels that are too high, or
cooking times that are too long, may overheat foods
resulting in a re.
This oven is designed to be used on a countertop only. It is
not designed to be built into a kitchen unit.
Do not place the oven in a cabinet.
The electrical outlet must be readily accessible so that the
unit can be unplugged easily in an emergency.
The AC power supply must be 230-240 V, 50 Hz, with a
minimum 10 A distribution line fuse, or a minimum 10 A
distribution circuit breaker.
A separate circuit serving only this appliance should be
provided.
Do not place the oven in areas where heat is generated.
For example, close to a conventional oven.
Do not install the oven in an area of high humidity or
where moisture may collect.
Do not store or use the oven outdoors.
If smoke is observed, switch off or unplug the oven
and keep the door closed in order to stie any ames.
Use only microwave-safe containers and utensils.
Utensils should be checked to ensure that they are
EN-5EN-5

IMPORTANT SAFETY INSTRUCTIONS
suitable for use in microwave ovens.
When heating food in plastic or paper containers,
keep an eye on the oven due to the possibility of
ignition.
Clean the waveguide cover, the oven cavity, the
turntable and turntable support after use.
These must be dry and free from grease. Builtup
grease may overheat and begin to smoke or catch re.
Do not place ammable materials near the oven or
ventilation openings.
Do not block the ventilation openings.
Remove all metallic seals, wire twists, etc., from food and
food packages. Arcing on metallic surfaces may cause a
 r e .
Do not use the microwave oven to heat oil for deep frying.
The temperature cannot be controlled and the oil may
catch re.
To make popcorn, use only special microwave
popcorn makers.
Do not store food or any other items inside the oven.
Check the settings after you start the oven to ensure the
oven is operating as desired.
To avoid overheating and re, special care must be taken
when cooking or reheating foods with a high sugar or
fat content, for example, Sausage rolls, Pies or Christmas
pudding.
See the corresponding hints in the operation manual.
EN-6EN-6

EN
IMPORTANT SAFETY INSTRUCTIONS
To avoid the possibility of injury.
WARNING:
Do not operate the oven if it is damaged or
malfunctioning. Check the following before use:
a) Make sure the door closes properly and ensure it is not
misaligned or warped.
b) Check to make sure the hinges and safety door latches
are not broken or loose.
c) Ensure that the door seals and sealing surfaces have
not been damaged.
d) Make sure inside the oven cavity or on the door are no
dents.
e) Ensure that the power supply cord and plug are not
damaged.
If the door or door seals are damaged, the oven must not
be operated until it has been repaired by a competent
person.
Never adjust, repair or modify the oven yourself.
It is hazardous for anyone other than a competent
person to carry out any service or repair operation
which involves the removal of a cover which gives
protection against exposure to microwave energy.
Do not operate the oven with the door open or alter the
door safety latches in any way. Do not operate the oven
if there is an object between the door seals and sealing
surfaces.
EN-7EN-7

IMPORTANT SAFETY INSTRUCTIONS
Do not allow grease or dirt to build up on the door
seals and adjacent parts. Clean the oven at regular
intervals and remove any food deposits.
Follow the instructions for“Care and Cleaning”. Failure
to maintain the oven in a clean condition could lead
to a deterioration of the surface that could adversely
affect the life of the appliance and possibly result in a
hazardous situation.
Individuals with PACEMAKERS should check with their
doctor or the manufacturer of the pacemaker for
precautions regarding microwave ovens.
To avoid the possibility of electric shock.
Under no circumstances should you remove the outer
cabinet.
Never spill or insert any objects into the door lock
openings or ventilation openings. In the event of a spill,
turn off and unplug the oven immediately, and call an
authorised SHARP service agent.
Do not immerse the power supply cord or plug in water or
any other liquid.
Do not let the power supply cord hang over the edge of a
table or work surface.
Keep the power supply cord away from heated surfaces,
including the rear of the oven.
Keep the appliance and its cord out of reach of children
less than 8 years.
EN-8EN-8
