親愛的 SHARP 顧客
衷心感謝您購買 SHARP 液晶顯示器。為確保安全使用本機及多年使用本機，請務必在使用本產品前仔細閱
讀重要的安全注意事項。
重要事項：
請將顯示器的型號和序號抄在右側空格內，萬一本
機遺失或遭竊時將有助於資料的呈報。型號和製造
號碼標示於顯示器的背面。
型號：
製造號碼：
本產品僅適用於台灣。
重要資訊
馬來西亞印製
TINS-H631WJN1
21P12-MA-NS
TINS-H631WJN1

CT
-3
CT
-4
簡介 （續）
重要的安全注意事項
機殼的保養
•使用柔軟布料（棉質、法藍絨等）輕輕擦拭機殼表
面。
•使用沾染化學藥品的布料（濕潤/乾燥的布料類型
等），可能會造成主機殼的組件變形或產生裂縫。
•使用堅韌粗糙的布料或用力擦拭，可能會造成機殼
表面刮傷。
•如果機殼非常骯髒，請以浸泡用水稀釋過的中性清潔
劑然後徹底擰乾的柔軟布料（棉質、法藍絨等）擦
拭，然後用柔軟的乾布擦乾。
•機殼主要是以塑膠製造的。請避免使用苯、稀釋劑
和其他溶劑，因為這些可能會造成機殼變形並導致
塗妝脫落。
•請勿使用殺蟲劑或其他揮發性液體。
•此外，請勿使機殼長期接觸橡皮或乙烯基製品。塑膠
中的塑化劑可能會導致機殼變形或塗妝脫落。
•將本機放置於推車上搬運時，必
須小心注意安全。急停、用力過
度、地面不平等等，都會導致本
機從推車上掉落。
•水和潮濕—不要在近水之處使用
本機，例如在靠近洗澡盆、洗臉
盆、廚房洗滌槽、洗衣盆、游泳
池等，也不要在潮濕的地下室中
使用。
前方顯示器的保養
•在進行清理前請關閉主電源並從
牆上插座拔除交流電源線。
•以柔軟的布料（棉質、法藍絨
等）輕輕擦拭前方顯示器表面。
•若要保護前方顯示器，請勿使用
骯髒的布料、液態清潔劑或沾染
化學藥品的布料（濕潤/乾燥的布
料類型等）進行清理。這可能會
使前方顯示器的表面受損。
•使用堅韌的布料或用力擦拭可能
會刮傷前方顯示器表面。
•當前方顯示器的確髒污時，使用
柔軟濕潤的布料輕輕擦拭即可
（若用力擦拭可能會刮傷前方顯
示器表面）。
•若前方顯示器沾染灰塵，請使用
市售的抗靜電刷子進行清理。
請勿將顯示器安裝在空調機下方或加濕器附近等
會受到水滴影響的位置。
•水滴掉落在顯示器上並進入其中
可能會造成起火、電擊或故障。
建議您將顯示器安裝在距離空調
機出風口至少 1 m 的位置。
簡介
日常使用注意事項
請遵守下列事項
機殼的維護
•清理機殼時，請使用柔軟的布料（棉質、絲質等）輕輕擦拭。
•請勿使用沾有化學藥品的乾抹布或濕抹布，因為這會導致機殼本體的成分老化或破裂。
•注意，請勿使用菜瓜布或用力清理，因為這會造成機殼表面刮傷。
•若機殼過於髒污，請使用柔軟的布料（棉質、絲質等）浸泡少量稀釋過的中性清潔劑並擰乾進行清理，然後使用柔軟
的乾布擦拭。
•苯或稀釋劑之類的溶劑會導致機殼老化或使其塗層脫落。因此請勿使用該類溶劑清理機殼。
•因為塑膠中含有塑化劑，當機殼接觸某些物質時，就會導致機殼老化或塗妝脫落。因此請保持機殼遠離殺蟲劑之類的
揮發性物質。此外，請勿讓機殼長期接觸橡膠、樹脂之類的製品。
液晶顯示器的維護
•清理液晶顯示器前，請務必關閉顯示器並從插座上拔除電源線。
•清理液晶顯示器時，請使用乾的柔軟布料（棉質、絲質等）輕輕擦拭液晶顯示器表面。為了保護液晶顯示器，請勿使
用骯髒的布料、清潔劑或沾有化學藥品的乾抹布或濕抹布進行清理，因為這會導致面板表面剝落。
•注意，請勿使用菜瓜布或用力清理，因為這會造成面板表面刮傷。
•若液晶顯示器過於髒污，請使用柔軟布料（棉質、絲質等）浸泡少量清水清理（請勿用力清理，以避免造成面板表
面刮傷）。
•若液晶顯示器表面沾染灰塵，請使用市售清潔刷（抗靜電刷子）清理面板。
低功率電波輻射性電機管理辦法
•經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大功率或變更原設計
之特性及功能。
•低功率射頻電機之使用不得影響飛航安全及干擾合法通信，經發現有干擾現象時，應立即停用，並改善至無干擾時
方得繼續使用。前項合法通信，指依電信法規定作業之無線電通信。低功率射頻電機須忍受合法通信或工業、科學
及醫療用電波輻射性電機設備之干擾。

CT
-5
CT
-6
重要的安全注意事項（續）
•請勿在本機之上放置花瓶或任何
其他盛水的容器。
若有水滴濺到本機上，就可能引
起火災或觸電。
•台座—不要將本機放置於不穩定
的推車、台座、三腳架或桌面
上。不穩固的基座可能會使本機
掉落，導致嚴重的人身傷害以及
造成產品損壞。請僅使用本製造
商所推薦或與本產品配套出售的
推車、台座、三腳架、托架或桌
子。將本機安裝於牆上時，請務
必遵照本製造商的指示。而且只
可以使用本製造商所推薦的安裝
器材。
•通風—本機外殼上的散熱孔與其
他開口處都是用於散熱通風。請
勿堵塞這些散熱孔或開口處，通
風散熱不良會使本機過熱和/或縮
短本機的使用壽命。請勿將本機
置於臥床、沙發、地毯或其他類
似物品上，因為這些物品會堵塞
散熱通風孔。本機之設計不適用
於嵌入式安裝; 所以不要將本機置
於像書櫃、機架等封閉之處，除
非提供合適的通風或遵照本製造
商的指示安裝。
•萬一本機墜落且機殼受損，請務
必關閉本機電源，並拔除電源
線。如果繼續使用本機，可能會
導致火災發生或造成觸電。並與
客戶服務中心連絡。
•請勿打開機殼後蓋變更電路。機
殼中具有高電壓可能會造成觸電
和人身傷害。若需要維修，請連
絡客戶服務中心。
•本機所用之液晶顯示器用玻璃製
造的。因此，在受到強力撞擊或
遭到尖銳物品刻劃時會破損。萬
一液晶顯示器破碎，請小心不要
被碎玻璃割傷。
•熱源—請勿讓本機接近熱源，如
暖氣機、加熱器、爐灶或者其他
任何會產生熱能的產品（包括擴
大機在內）。
•為防止發生火災，請勿將任何種
類的蠟燭或火焰置於顯示器上或
其附近。
•為了防止火災或觸電的危險，請
勿將交流電源線置於顯示器或其
他重物下。
•請勿在本機之上放置重物或攀
爬於本機之上。這樣做可能導
致本機傾倒而造成傷害。特別
要注意附近的兒童和寵物。
•搬運顯示器前，請先拔除電源
線。若未先拔除，則電源線可能
受損造成觸電。
重要的安全注意事項（續）
液晶螢幕採用極高精度技術製造，有效像素達
到99.99%以上。
0.01%或以下的缺失像素，或者那些始終亮着的
像素不是故障。
在搬運顯示器時的注意事項
•在搬運顯示器時，切勿握持或施
加壓力於顯示器上。
任何時候都必須由兩個人或多人
用雙手搬運—顯示器的每一側用
一隻手握住。
如果顯示器不是放置在平穩的地方，電視可能有
掉落的危險。
很多尤其對於兒童的傷害，可以通過採取簡單的
預防措施而避免，例如：
•使用本顯示器製造商所推薦的櫥櫃或台座。
•僅使用可以安全支撐顯示器的家具。
•確保顯示器沒有外伸在支撐家具的邊緣。
•在沒有錨固家具和顯示器於適合的支座的情況下，勿
將顯示器放置在高的家具上（例如櫥櫃或書架）。
•請勿將顯示器放置在布料或其他放置在顯示器和支撐
家具之間的物質上。
•教導兒童有關攀爬家具以觸及顯示器或控制器的危
險。
•請勿長時間顯示靜止畫面，這可能會導致殘留影像。
•請將本機安裝於能夠很容易地將交流電源線從交流電
源插座和本機機背後的 AC INPUT（交流電源輸入）
端子上拔出的地方。
註
•以上圖片僅供參考; 實際項目可能有所不同。
簡介 （續） 簡介 （續）

CT
-7
CT
-8
C. 連接台座單位A. 隨機附件
1遙控器（g 1 支） 2“AAA”型鹼性電池（g 2 支） 3初始設定指南
4保證書
台座
B. 裝入電池
遙控器
123
2“AAA”型鹼性電池
•在裝入電池時，要注意電池端子
的極性要與電池艙內的極性標記
（e）和（f）一致。
4T-C60DL1X
4T-C70DL1X
5
台座
5
台座
5
螺絲釘
6
螺絲釘
6
L LR R
L R
4T-C60DK1X
■4T-C70DL1X
螺絲釘
6
螺絲釘
6
5台座 台座
“R” 5“L”
台座
5“R” 台座 “L”
5
台座
5“R” 台座 “L”
5
螺絲釘
6 螺絲釘 6 螺絲釘 6 螺絲釘 6
步驟 将支架配插入顯示器底部的开口中。
步驟 將螺絲釘插入顯示器後部的孔內並擰緊。
2
■■ 4T-C60DL1X
4T-C60DK1X
•
註
本手冊中使用的插圖是根據4T-C60DL1X 。

初始安裝 觀看電子手冊
CT
-9
CT
-10
第一次使用本顯示器時，請按照以下步驟逐一操作。視您的顯示器安裝與連接而定，可能不需要進行某些
步驟。
將天線連接線連接至天線端子。（對於 TV 機種）
將交流電源線插入交流電源插座。
注意 （對於 TV 機種）
F 型接頭只能以手指鎖緊。
將 RF 纜線連接至顯示器時，請勿使用工具鎖緊 F 型接頭。
若使用工具鎖緊，可能會導致顯示器受損。
（導致內部線路斷裂等）
F 型接頭
75 歐姆同軸纜線
•將顯示器放在靠近交流電源插座的位置，以便電源插頭就近使用。
注意
為避免電擊危險，切勿接觸連接了交流電的未絕緣零件或任何電線。
觀看內建操作手冊
內建操作指南顯示於螢幕上。您可以閱讀此裝
置的操作說明。
1按下 （首頁），顯示 HOME（首頁）
画面，然後按下 / / / 選擇
「設定」。
按下 / 選擇「應用程式」，按下
/ 選擇「手冊」，然後按下確定。
將顯示內建操作手冊畫面。
2選擇目錄時，將顯示其頁面。
附錄
疑難排解
下述問題並非一定由於故障而引起。將顯示器送修之前，請再次檢查顯示器。
案方決解的能可題問
•沒有電源。 •檢查是否按下了遙控器上的電源。
•AC電源線是否中斷連接？
•主電源是否被打開？
•遙控器無法運作。 •電池是否按極性（e、f) 放入？
•沒有影像。 •與其他組件的連接是否正確？
•沒有聲音。 •與其他組件的連接是否正確？
清除密碼
如果您忘記了密碼，請依照下列步驟來清除密碼。
1在 HOME（首頁）畫面中，選擇「設定」>「裝置偏好設定」>「關於」>「恢復原廠設定」，然後按下
確定。
2顯示器重置後將恢復原廠設定，需重設密碼。
註
•以防萬一，請記下密碼並妥善保管。
設備上的符號
•此標誌表示產品在交流電壓下工作。
•此標誌表示 II 類或雙重絕緣電器，其中產品不需要電氣接地的安全連接。
按下顯示器上的 (飛梭鍵)。
執行初始安裝。
•按照顯示器螢幕上的指示設置
設定。
將整線器插入束線帶。
將束線帶扣 (1) 往內壓，
將束線帶 (2) 往外拉並
完全鬆開。
1
2
束線帶
•
註
本手冊中使用的插圖是根據4T-C60DL1X 。

規格 附錄
CT
-11
CT
-12
項目 型號 4T-C60DL1X 4T-C60DK1X 4T-C70DL1X
153 cm 177 cm）離距線角對斜（板面晶液
解析度 8,294,400 像素 (3840 g 2160)
音頻放大器 10 W g 2
端子
(僅供售後服務使用)
3.5 mm 插孔
HDMI 1 (eARC/ARC)
(輸入 1)
HDMI (HDMI 輸入)，eARC/ARC
HDMI (HDMI 輸入) (輸入 2)
(輸入 3)
(輸入 4)
HDMI (HDMI 輸入)
HDMI 2
HDMI 3
HDMI (HDMI 輸入) HDMI 4
USB 1
AV IN
USB (DC5V 1.5A 輸出)
USB 2 USB (DC5V 1.5A 輸出)
LAN (乙太網絡)
(10/100 BASE-T)
網路連接器
輸出 耳機 ( 3.5 mm 立體聲)
螢幕顯示語言 英文 / 簡体中文 / 繁體中文 / 阿拉伯語 / 法語 / 葡萄牙語 / 俄語 / 泰語 /
越南語 / 印尼語 / 馬來語
額定電壓額定頻率 AC 110 V, 60 Hz
額定消耗電功率
206 W (0.6 W 待機 )215 W (0.6 W 待機 )
尺寸 不含台座 1358 g 799
g 83
含台座 1358 g 860 g 379
1564 g 904 g 77
1564 g 983
g 335
不含低座重量（含低座重量)
操作溫度 0°C 到 + 40°C
•作為不斷改進政策的一部份，SHARP 保留改進產品而變更設計和規格的權利，恕不另行通知。以上性能規格的數值為產
品設備的標稱值。個別設備的相關數值可能略有差異。
注意
•安裝液晶顯示器需要專業技術，因此必須由合格的維修人員進行。顧客不應自行嘗試安裝。SHARP 對由於安裝不當或安
裝造成的事故或傷害不承擔任何責任。
•開始操作前，請詳細閱讀托架隨附的說明。
商標
Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio, and the double-D symbol are trademarks
of Dolby Laboratories Licensing Corporation.
The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered
trademarks of HDMI Licensing Administrator, Inc.
The Wi-Fi CERTIFIED™ Logo is a certification mark of Wi-Fi Alliance®.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such
marks by SHARP Corporation is under license. Other trademarks and trade names are those of their respective
owners.
ANY USE OF THIS PRODUCT IN ANY MANNER OTHER THAN PERSONAL USE THAT COMPLIES WITH
THE MPEG-2 STANDARD FOR ENCODING VIDEO INFORMATION FOR PACKAGED MEDIA IS EXPRESSLY
PROHIBITED WITHOUTA LICENSE UNDER APPLICABLE PATENTS IN THE MPEG-2 PATENT PORTFOLIO, WHICH
LICENSE IS AVAILABLE FROM MPEG LA, LLC, 6312 S. Fiddlers Green Circle, Suite 400 E, Greenwood Village,
Colorado 80111 U.S.A.
THIS PRODUCT IS LICENSED UNDER THE VC-1 PATENT PORTFOLIO LICENSE FOR THE PERSONAL AND
NON-COMMERCIAL USE OF A CONSUMER TO (i) ENCODE VIDEO IN COMPLIANCE WITH THE VC-1 STANDARD
(“VC-1 VIDEO”) AND/OR (ii) DECODE VC-1 VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A
PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED
TO PROVIDE VC-1 VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY OTHER USE. ADDITIONAL
INFORMATION MAY BE OBTAINED FROM MPEG LA, L.L.C. SEE HTTP://WWW.MPEGLA.COM
THIS PRODUCT IS LICENSED UNDER THE AVC PATENT PORTFOLIO LICENSE FOR THE PERSONAL USE OF
A CONSUMER OR OTHER USES IN WHICH IT DOES NOT RECEIVE REMUNERATION TO (i) ENCODE VIDEO IN
COMPLIANCE WITH THE AVC STANDARD (“AVC VIDEO”) AND/OR (ii) DECODE AVC VIDEO THAT WAS ENCODED
BY A CONSUMER ENGAGED IN A PERSONAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO PROVIDER
LICENSED TO PROVIDE AVC VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY OTHER USE.
ADDITIONAL INFORMATION MAY BE OBTAINED FROM MPEG LA, L.L.C. SEE HTTP://WWW.MPEGLA.COM
THIS PRODUCT IS LICENSED UNDER THE MPEG-4 VISUAL PATENT PORTFOLIO LICENSE FOR THE PERSONAL
AND NON-COMMERCIAL USE OF A CONSUMER FOR (i) ENCODING VIDEO IN COMPLIANCE WITH THE MPEG-
4 VISUAL STANDARD (“MPEG-4 VIDEO”) AND/OR (ii) DECODING MPEG-4 VIDEO THAT WAS ENCODED BY A
CONSUMER ENGAGED IN A PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM
A VIDEO PROVIDER LICENSED BY MPEG LA TO PROVIDE MPEG-4 VIDEO. NO LICENSE IS GRANTED OR
SHALL BE IMPLIED FOR ANY OTHER USE. ADDITIONAL INFORMATION INCLUDING THAT RELATING TO
PROMOTIONAL, INTERNAL AND COMMERCIAL USES AND LICENSING MAY BE OBTAINED FROM MPEG LA,
L.L.C. SEE HTTP://WWW.MPEGLA.COM
17.5 kg (18.8 kg)
183 W (0.6 W 待機 )
1358 g 864g 300
17.5 kg (18.5 kg) 23.5 kg (24.0 kg)
光學 S/PDIF 數位聲音輸出
(數位聲音輸出)
•
•
為防止射頻干擾，配件電源線上有包含一個磁環，不可任意取下。
SERVICE ONLY
DIGITAL AUDIO
OUTPUT
音頻輸入，視訊輸入 3.5 迷你插孔*¹
(影音輸入)
PAL / SECAM / NTSC 3.58 / NTSC 4.43 / PAL 60 視頻彩色系統
請勿在傾斜狀態下安裝/壁掛顯示器。
寬 g 高 g 深(mm)
寬 g 高 g 深(mm)
僅 4T-C70DL1X
使用AV IN 的說明。
*¹
購買維修部件 （QCNWGA171WJPZ）。
需要 RCA 插孔轉換。

CT
-13
CT
-14
4T-C60DK1X 4T-C70DL1X
輪廓圖 輪廓圖 （續）
單位: 公釐
單位: 公釐
單位: 公釐
1564
77
40
335
119
1451
983 904
867
1541
壁掛用螺絲尺寸 M6
壁掛孔距規格 200 x 300
上/下側壁掛螺釘孔深度 30
上/下側壁掛螺釘規格 M6
壁掛用螺絲尺寸 M6
壁掛孔距規格 200 x 300
上/下側壁掛螺釘孔深度 30
上/下側壁掛螺釘規格 M6
壁掛用螺絲尺寸 M8
壁掛孔距規格 200 x 400
上側壁掛螺釘孔深度 17
17
13
下側壁掛- A 螺釘孔深度
下側壁掛- B 螺釘孔深度
上/下側壁掛螺釘規格 M8
119
400 582582
200 580
79
5
200195 388
1355
1355
1355
1355
1355
1355
1358
83
56
1333
799
1355
1355
1355
1355
1355
1355
864
752
1355
1355
1355
1355
1355
1355
1355
1355
1115 124
300
1355
1355
1355
300529 529
300529 529
4T-C60DL1X
200195 388
1358
1333
1202
83
56
152
379
860
752
799
16
61 16
65
1355
1355
A B

CT
-15
16 7
設備名稱：液晶顯示器， 型號（型式）：4T-C60DL1X / 4T-C60DK1X / 4T-C70DL1X
Equipment name Type designation (Type)
單元 Unit
限用物質及其化學符號
Restricted substances and its chemical symbols
鉛Lead
(Pb)
汞Mercury
(Hg)
鎘Cadmium
(Cd)
六價鉻
Hexavalent
chromium
(Cr+6)
多溴聯苯
Polybrominated
biphenyls
(PBB)
多溴二苯醚
Polybrominated
diphenyl ethers
(PBDE)
○○○○○○
○○○○○○
○○○○○○
電路板
後殼
面板 -○○○○○
電源線
其他線材 -○○○○○
配件 (例：遙控器等)
-○○○○○
備考1.〝超出0.1 wt %〞及〝超出0.01 wt %〞係指限用物質之百分比含量超出百分比含量基準值。
Note 1: “Exceeding 0.1 wt %” and “exceeding 0.01 wt %” indicate that the percentage content of the restricted
substance exceeds the reference percentage value of presence condition.
備考2. “○” 係指該項限用物質之百分比含量未超出百分比含量基準值。
Note 2: “○” indicates that the percentage content of the restricted substance does not exceed the percentage of
reference value of presence.
備考3. “–” 係指該項限用物質為排除項目。
Note 3: The “–” indicates that the restricted substance corresponds to the exemption.
Printed Circuit Board
Rear Cabinet
Panel
Electric current wires
Other Wiring Material
Accessories (Example:
Remote control etc.）

EN
-1
EN
-2
4T-C60DL1X
4T-C70DL1X
4T-C60DK1X
LCD MONITOR
Initial Setup Guide
4T-C60DL1X
4T-C70DL1X
4T-C60DK1X
LCD MONITOR
ENGLISH
Initial Setup Guide
Dear SHARP customer
Thank you for your purchase of the SHARP Liquid Crystal Monitor. To ensure safety and many
years of trouble-free operation of your product, please read the Important Safety Precautions
carefully before using this product.
IMPORTANT:
To aid reporting in case of loss or theft, please
record the Monitor’s model and serial numbers in
the space provided. The numbers are located at
the rear of the Monitor.
Model No.:
Serial No.:
This product is only for Taiwan.
Important Information
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
WARNING:
The lightning flash with arrow-head
symbol, within an equilateral triangle,
is intended to alert the user to the
presence of uninsulated “dangerous
voltage” within the product's
enclosure that may be of sufficient
magnitude to constitute a risk of
electric shock to persons.
The exclamation point within a
triangle is intended to alert the user
to the presence of important
operating and maintenance
(servicing) instructions in the
literature accompanying the product.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE
SLOT, FULLY INSERT.
CAUTION:
Printed in Malaysia
TINS-H631WJN1
21P12-MA-NS

EN
-3
EN
-4
Precautions For Daily Use
Observe the following items
Maintenance of the cabinet
• When cleaning the cabinet, use a soft cloth (made of cotton, oss, etc.) to clean gently.
• Do not use a dry or damp rag mixed with chemicals, as this could cause the ingredients of the cabinet body to
deteriorate or crack.
• Be careful not to use an abrasive cloth for cleaning or clean with excessive force, as this could scratch the surface
of the cabinet.
• If the cabinet is greatly soiled, clean with a soft cloth (made of cotton, oss, etc.) soaked with a small amount of
diluted neutral detergent and wrung out, and then clean with a soft dry cloth.
• Solvents such as benzene or thinner could cause the cabinet to deteriorate, or make its coating come off. Therefore
do not use such solvents to clean the cabinet.
• Because plasticizer is included in the plastics, deterioration or the coating peeling off could occur when the cabinet
comes into contact with some substances. Therefore keep it away from volatile substances such as insecticide. In
addition, do not let it come into contact with objects made of rubber, resin, etc. for a long time.
Maintenance of the LCD panel
• Before cleaning the LCD panel, be sure to turn off the Monitor set and unplug the power cord from the outlet.
• When cleaning the LCD panel, use a dry and soft cloth (made of cotton, oss, etc.) to clean the surface of the LCD
panel gently. For protecting the LCD panel, do not clean with a dirty cloth, detergent, or a dry or damp rag mixed
with chemicals, as this could cause peeling of the panel surface.
• Be careful not to clean with an abrasive cloth or with excessive force, as this could cause the panel surface to be
scratched.
• If the LCD panel is greatly soiled, clean it gently with a soft cloth (made of cotton, oss, etc.) soaked with a small
amount of water (Do not clean with excessive force, so as to avoid the scratch of the panel surface).
• If dust sticks on the surface of the LCD panel, clean the panel with a commercially available cleaning brush (anti-
static brush).
Introduction
Important safety precautions
Caring for the cabinet
• Use a soft cloth (cotton, annel, etc.) and gently
wipe the surface of the cabinet.
• Using a chemical cloth (wet/dry sheet type cloth,
etc.) may deform the components of the main unit
cabinet or cause cracking.
• Wiping with a hard cloth or using strong force may
scratch the surface of the cabinet.
• If the cabinet is very dirty, wipe with a soft cloth
(cotton, annel, etc.) soaked in neutral detergent
diluted with water and thoroughly wrung out, and
then wipe with a soft dry cloth.
• The cabinet is primarily made of plastic. Avoid using
benzene, thinner, and other solvents, as these may
deform the cabinet and cause the paint to peel off.
• Do not apply insecticides or other volatile liquids.
• Also, do not allow the cabinet to remain in contact
with rubber or vinyl products for a long period of
time. Plasticizers inside the plastic may cause the
cabinet to deform and cause the paint to peel off.
• When relocating the product
placed on a cart, it must be
moved with utmost care. Sudden
stops, excessive force and
uneven oor surface can cause
the product to fall from the cart.
• Water and moisture — Do not
use the product near water, such
as bathtub, washbasin, kitchen
sink, laundry tub, swimming pool
and in a wet basement.
Caring for the front panel
• Turn off the main power and
unplug the AC cord from the wall
outlet before handling.
• Gently wipe the surface of the
front panel with a soft cloth
(cotton, annel, etc.).
• To protect the front panel, do not
use a dirty cloth, liquid cleaners,
or a chemical cloth (wet/dry
sheet type cloth, etc.). This may
damage the surface of the front
panel.
• Wiping with a hard cloth or using
strong force may scratch the
surface of the front panel.
• Use a soft damp cloth to gently
wipe the front panel when it is
really dirty (It may scratch the
surface of the front panel when
wiped strongly).
• If the front panel is dusty, use an
anti-static brush, which is
commercially available, to clean
it.
Do not install the Monitor in a location in
which it will be subject to water drops such
as underneath an air conditioning unit or in
the vicinity of a humidifier
• Water drops falling onto the
Monitor and water entering
inside it may result in re, electric
shock, or malfunctions.
We recommend that you
install the Monitor at least 1 m
away from the outlet of an air
conditioner.
More than 1m.
Introduction (Continued)

EN
-5
EN
-6
Important safety precautions (Continued)
• Do not place vases or any other
water-lled containers on this
product.
The water may spill onto the
product causing re or electric
shock.
• Stand — Do not place the
product on an unstable cart,
stand, tripod or table. Doing
so can cause the product
to fall, resulting in serious
personal injuries as well as
damage to the product. Use
only a cart, stand, tripod,
bracket or table recommended
by the manufacturer or sold
with the product. When
mounting the product on a
wall, be sure to follow the
manufacturer’s instructions.
Use only the mounting
hardware recommended by the
manufacturer.
• Ventilation — The vents and
other openings in the cabinet
are designed for ventilation. Do
not cover or block these vents
and openings since insufcient
ventilation can cause
overheating and/or shorten the
life of the product. Do not place
the product on a bed, sofa,
rug or other similar surface,
since they can block ventilation
openings. This product is not
designed for built-in installation;
do not place the product in
an enclosed place such as a
bookcase or rack, unless proper
ventilation is provided or the
manufacturer’s instructions are
followed.
• In case the product is dropped
and the cabinet is damaged, be
sure to turn off the power of the
product, and unplug the power
cord. If you continue to use the
product, it may cause re or
electric shock. Contact customer
service center.
• Do not open the rear cover of
the cabinet to reconstruct the
circuits. There exists high
voltage within the cabinet and
it may cause electric shock and
injury. If maintenance is required,
contact customer service center.
• The LCD panel used in this
product is made of glass.
Therefore, it can break when
the product is struck forcefully or
with a sharp object. If the LCD
panel is broken, be careful not to
be injured by broken glass.
• Heat sources — Keep the
product away from heat sources
such as radiators, heaters,
stoves and other heat-generating
products (including ampliers).
• To prevent re, never place any
type of candle or naked ames
on the top or near the Monitor
set.
• To prevent re or shock hazard,
do not place the AC power cord
under the Monitor set or other
heavy items.
• Do not place heavy objects on
this product or stand on it.
Doing so could cause injury
if the product overturns. Take
special care near children
and pets.
• Unplug the power cord before
you move the Monitor set.
If not unplugged beforehand,
the power cord may become
damaged and cause electric
shock.
Important safety precautions (Continued)
Precautions when transporting the Monitor
• When transporting the Monitor,
never carry it by holding or
otherwise putting pressure onto
the display.
Be sure to always carry the
Monitor by two people holding it
with two hands — one hand on
each side of the Monitor.
If a Monitor is not positioned in a sufciently stable
location, it can be potentially hazardous due to falling.
Many injuries, particularly to children, can be avoided
by taking simple precautions such as:
• Using cabinets or stands recommended by the
manufacturer of the Monitor.
• Only using furniture that can safely support the
Monitor.
• Ensuring the Monitor is not overhanging the edge of
the supporting furniture.
• Not placing the Monitor on tall furniture (for example,
cupboards or bookcases) without anchoring both the
furniture and the Monitor to a suitable support.
• Not standing the Monitors on cloth or other materials
placed between the Monitor and supporting furniture.
• Educating children about the dangers of climbing on
furniture to reach the Monitor or its controls.
• Do not display a still picture for a long time, as this
could cause an afterimage to remain.
• Install the product on the place where the AC cord
can be unplugged easily from the AC outlet, or from
the AC INPUT terminal on the rear of the product.
NOTE
• The above are pictures for reference only; the actual
item might be different.
Introduction (Continued) Introduction (Continued)
The LCD panel is made with extremely high precision
techonology, and has 99.99% or more effective pixels.
The 0.01% or less missing pixels or those that are
always lit is not a malfunction.

EN
-7
EN
-8
1Remote control unit (m1) 2“AAA” size battery (m2) 3Initial setup guide
4Warranty certificate
B. Inserting the batteries
Remote control unit
123
2“AAA” size battery
• Place batteries with their terminals
corresponding to the (k) and
(l) indications in the battery
compartment. Recycle the battery
A. Supplied accessories C. Attaching the stand unit
4T-C60DL1X
4T-C70DL1X
5Stand base
5Stand base 5Stand base
6Screws
Screws
6
L LR R
L R
4T-C60DK1X
■4T-C70DL1X
■■ 4T-C60DL1X
4T-C60DK1X
Insert the stand assembly into the openings on the bottom of the Monitor.
Insert and tighten the screws into the holes on the bottom / rear of the Monitor.Step
Step
Soft cushion
5Stand base R 5Stand base L
6 Screws 6 Screws
Soft cushion
5Stand base R 5Stand base L
6 Screws 6 Screws
Soft cushion
Stand base R 55 Stand base L
6 Screws
■
2
6 Screws
NOTE
• This drawings used throughout this manual are based on the 4T-C60DL1X.

EN
-9
EN
-10
Initial installation
Viewing the Built-in Operation Manual
Displays the built-in operation manual on the
screen. You can read information about how to
use this device.
1Press (HOME) to display the HOME
screen, and then press / / / to
select “Settings”.
Press / to select “Apps”, press
/ to select “Manual”, and then press
確定 (ENTER).
This displays the built-in operation manual
screen.
2When you select contents, its page will be
displayed.
Appendix
Troubleshooting
The problems described below are not always caused by malfunctions. Check the Monitor again before
having the Monitor serviced.
noituloSelbissoPmelborP
• No power. • Check if you pressed 電源 (POWER) on the remote control unit.
• Is the AC cord disconnected?
• Has the power been turned on?
• Remote control unit does
not operate.
• Are batteries inserted with polarity (e, f) aligned?
• No picture. • Is connection to other components correct?
• No sound. • Is connection to other components correct?
CLEARING THE PASSWORD
If you forget the password, clear the password using the following procedure.
1From the HOME screen, select “Settings” > “Device Preferences” > “About” > “Factory reset”, and
then press 確定
(ENTER).
2When you perform a reset, the Monitor will be returned to the factory preset values, and you need to
set the password again.
NOTE
• As a precautionary measure, make a note of your password, and keep it in a safe place.
Viewing E-Manual
Follow the steps below one by one when using the Monitor for the rst time. Some steps may not be
necessary depending on your Monitor installation and connection.
Connect an antenna cable to the antenna terminal.
(For TV models)
Plug the AC cord into the AC outlet.
NOTICE
(For TV models)
F-type connector should be finger-
tightened only.
When connecting the RF cable to the Monitor set, do not
tighten F-type connector with tools.
If tools are used, it may cause damage to your Monitor set.
(The breaking of internal circuit, etc.)
F-type connector
75-ohm coaxial cable
• Place the Monitor close to the AC outlet, and keep the power
plug within reach.
Run the initial installation.
• Follow the guide on the Monitor screen to set the
settings.
Press (JOG-KEY) on the Monitor.
Cable tie
Bundle the cables into
cable tie.
Press cable tie clip (1)
and pull out cable tie (2)
completely to release.
Symbols placed on equipment
• This mark indicates the product operates on AC Voltage.
• This mark indicates a class II or double insulated electrical appliance wherein the product does not
require a safety connection to electrical earth (ground).
1
2
NOTE
• This drawings used throughout this manual are
based on the 4T-C60DL1X.

EN
-11
EN
-12
Specifications Appendix
Item Model
177 cm153 cmlenapDCL
Resolution 8,294,400 pixels (3840 g2160)
Audio amplifier 10 W g2
Terminals
SERVICE ONLY 3.5 mm jack
HDMI 1 (eARC/ARC) HDMI (HDMI input), eARC/ARC
HDMI 2 HDMI (HDMI input)
HDMI 3 HDMI (HDMI input)
HDMI 4 HDMI (HDMI input)
AUDIO in, VIDEO inAV IN
USB 1 USB(DC5V 1.5A output)
USB 2 USB(DC5V 1.5A output)
LAN
(10/100 BASE-T)
DIGITAL AUDIO
OUTPUT
Network connector
Optical S/PDIF digital audio output
OUTPUT Headphone ( 3.5 mm stereo)
3.5 mini jack٭¹
ilpmiS/hsilgnEegaugnalDSO ed Chinese/Traditional Chinese/Arabic/French/Portuguese/
Russian/Thai/Vietnamese/Indonesia/Malay
Power requirement AC 110 V, 60 Hz
Power consumption
206 W (0.6 W Standby) 215 W (0.6 W Standby)
Dimensions without stand 1358 g
W H D (mm)g g
W H D (mm)g g
799 83g1564 g904 77g
1358 g860 379g1564 g983 335g
with stand
23.5 kg (24.0 kg)17.5 kg (18.8 kg)
183 W (0.6 W Standby)
1358 g864 300g
17.5 kg (18.5 kg))dnatshtiw(dnatstuohtiwthgieW
Operating temperature 0°C to + 40°C
• As a part of policy of continuous improvement, SHARP reserves the right to make design and specication changes
for product improvement without prior notice. The performance specication gures indicated are nominal values of
production units. There may be some deviations from these values in individual units.
CAUTION
• Installing the Liquid Crystal Monitor requires special skill that should only be performed by qualied service personnel.
Customers should not attempt to do the work themselves. SHARP bears no responsibility for improper mounting or
mounting that results in accident or injury.
• Carefully read the instructions that come with the bracket before beginning work.
Trademarks
Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio, and the double-D symbol are trademarks
of Dolby Laboratories Licensing Corporation.
The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered
trademarks of HDMI Licensing Administrator, Inc.
The Wi-Fi CERTIFIED™ Logo is a certication mark of Wi-Fi Alliance®.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such
marks by SHARP Corporation is under license. Other trademarks and trade names are those of their respective
owners.
ANY USE OF THIS PRODUCT IN ANY MANNER OTHER THAN PERSONAL USE THAT COMPLIES WITH
THE MPEG-2 STANDARD FOR ENCODING VIDEO INFORMATION FOR PACKAGED MEDIA IS EXPRESSLY
PROHIBITED WITHOUT A LICENSE UNDER APPLICABLE PATENTS IN THE MPEG-2 PATENT PORTFOLIO,
WHICH LICENSE IS AVAILABLE FROM MPEG LA, LLC, 6312 S. Fiddlers Green Circle, Suite 400 E,
Greenwood Village, Colorado 80111 U.S.A.
THIS PRODUCT IS LICENSED UNDER THE VC-1 PATENT PORTFOLIO LICENSE FOR THE PERSONAL
AND NON-COMMERCIAL USE OF A CONSUMER TO (i) ENCODE VIDEO IN COMPLIANCE WITH THE VC-1
STANDARD (“VC-1 VIDEO”) AND/OR (ii) DECODE VC-1 VIDEO THAT WAS ENCODED BY A CONSUMER
ENGAGED IN A PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO
PROVIDER LICENSED TO PROVIDE VC-1 VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY
OTHER USE. ADDITIONAL INFORMATION MAY BE OBTAINED FROM MPEG LA, L.L.C.
SEE HTTP://WWW.MPEGLA.COM
THIS PRODUCT IS LICENSED UNDER THE AVC PATENT PORTFOLIO LICENSE FOR THE PERSONAL USE OF
A CONSUMER OR OTHER USES IN WHICH IT DOES NOT RECEIVE REMUNERATION TO (i) ENCODE VIDEO
IN COMPLIANCE WITH THE AVC STANDARD (“AVC VIDEO”) AND/OR (ii) DECODE AVC VIDEO THAT WAS
ENCODED BY A CONSUMER ENGAGED IN A PERSONAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO
PROVIDER LICENSED TO PROVIDE AVC VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY
OTHER USE. ADDITIONAL INFORMATION MAY BE OBTAINED FROM MPEG LA, L.L.C.
SEE HTTP://WWW.MPEGLA.COM
THIS PRODUCT IS LICENSED UNDER THE MPEG-4 VISUAL PATENT PORTFOLIO LICENSE FOR THE
PERSONAL AND NON-COMMERCIAL USE OF A CONSUMER FOR (i) ENCODING VIDEO IN COMPLIANCE
WITH THE MPEG-4 VISUAL STANDARD (“MPEG-4 VIDEO”) AND/OR (ii) DECODING MPEG-4 VIDEO THAT WAS
ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR WAS
OBTAINED FROM A VIDEO PROVIDER LICENSED BY MPEG LA TO PROVIDE MPEG-4 VIDEO. NO LICENSE
IS GRANTED OR SHALL BE IMPLIED FOR ANY OTHER USE. ADDITIONAL INFORMATION INCLUDING THAT
RELATING TO PROMOTIONAL, INTERNAL AND COMMERCIAL USES AND LICENSING MAY BE OBTAINED
FROM MPEG LA, L.L.C. SEE HTTP://WWW.MPEGLA.COM
4T-C60DL1X 4T-C60DK1X 4T-C70DL1X
•Ferrite Core is attached together with AC Cord for EMI improvement. Please do not dismantle for safety purpose.
•Do not install / mount the TV with tilting condition.
Video colour system PAL / SECAM / NTSC 3.58 / NTSC 4.43 / PAL 60
Instruction for using AV IN.
Requires RCA jack conversion.
Buy the service parts (QCNWGA171WJPZ).
٭¹
4T-C70DL1X only

EN
-13
EN
-14
4T-C70DL1X
1564
77
40
335
119
1451
983 904
867
1541
Unit : mm
Dimensional Drawing (Continued)
119
400 582582
200 580
79
5
Screw size for wall mount M8
VESA SPEC 200 x 400
UPPER VESA SCREW DEPTH
A B
17
17
13
UPPER/LOWER VESA SCREW TYPE M8
LOWER VESA-A SCREW DEPTH
LOWER VESA-B SCREW DEPTH
200195 388
Dimensional Drawing
1355
1355
1355
1355
1355
1355
1358
83
56
1333
799
1355
1355
1355
1355
1355
1355
864
752
1355
1355
1355
1355
1355
1355
1355
1355
1115 124
300
1355
1355
1355
300529 529
300529 529
VESA SPEC 200 x 300
UPPER/LOWER VESA SCREW DEPTH 30
UPPER/LOWER VESA SCREW TYPE M6
VESA SPEC 200 x 300
UPPER/LOWER VESA SCREW DEPTH 30
UPPER/LOWER VESA SCREW TYPE M6
Unit : mm
4T-C60DK1X
Unit : mm
4T-C60DL1X
200195 388
1358
1333
1202
83
56
152
379
860
752
799
16
61 16
65
1355
1355

EN
-15
16 7
設備名稱：液晶顯示器， 型號（型式）：4T-C60DL1X / 4T-C60DK1X / 4T-C70DL1X
Equipment name Type designation (Type)
單元 Unit
限用物質及其化學符號
Restricted substances and its chemical symbols
鉛Lead
(Pb)
汞Mercury
(Hg)
鎘Cadmium
(Cd)
六價鉻
Hexavalent
chromium
(Cr+6)
多溴聯苯
Polybrominated
biphenyls
(PBB)
多溴二苯醚
Polybrominated
diphenyl ethers
(PBDE)
○○○○○○
○○○○○○
○○○○○○
電路板
後殼
面板 -○○○○○
電源線
其他線材 -○○○○○
配件 (例：遙控器等)
-○○○○○
備考1.〝超出0.1 wt %〞及〝超出0.01 wt %〞係指限用物質之百分比含量超出百分比含量基準值。
Note 1: “Exceeding 0.1 wt %” and “exceeding 0.01 wt %” indicate that the percentage content of the restricted
substance exceeds the reference percentage value of presence condition.
備考2. “○” 係指該項限用物質之百分比含量未超出百分比含量基準值。
Note 2: “○” indicates that the percentage content of the restricted substance does not exceed the percentage of
reference value of presence.
備考3. “–” 係指該項限用物質為排除項目。
Note 3: The “–” indicates that the restricted substance corresponds to the exemption.
Printed Circuit Board
Rear Cabinet
Panel
Electric current wires
Other Wiring Material
Accessories (Example:
Remote control etc.）
