15.REPLACEMENT PARTS LIST/
EXPLODED VIEWS
ELECTRICAL PARTS LIST
Parts marked with " å " are important for maintaining the safety of the
set. Be sure to replace these parts with specified ones for maintaining
the safety and performance of the set.
" HOW TO ORDER REPLACEMENT PARTS "
★MARK : SPARE PARTS-DELIVERY SECTION : ALL JAPAN
To have your order filled promptly and correctly, please furnish
the following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
5. PRICE CODE
åMARK: SAFETY RELATED PARTS
PWB ASSEMBLY IS NOT REPLACEMENT ITEM
Ref. No. Part No. ★Description Code
IC6202 VHiTC4053BF-1 TC4053BF, Multiplexer AG
IC6203 VHiTC4053BF-1 TC4053BF, Multiplexer AG
IC6601 VHiPQ20WZ11-1 PQ20WZ1U, Batt REG AG
IC6602 VHiNJM4560M-1 NJM4560M, Audio Amp AG
TRANSISTORS
Q112 VS2SA1774F/-1 2SA1774F AA
Q115 VSFMMT717//-1 FMMT717 AE
Q118 VSFMMT717//-1 FMMT717 AE
Q121 VSDTA114EE/-1 DTA114EE AB
Q122 VSFMMT717//-1 FMMT717 AE
Q123 VSFMMT717//-1 FMMT717 AE
Q201 VS2SC4738Y/-1 2SC4738Y AA
Q202 VS2SA1576//-1 2SA1576 AB
Q203 VS2SC4738Y/-1 2SC4738Y AA
Q204 VS2SA1576//-1 2SA1576 AB
Q211 VSDTC124EE/-1 DTC124EE AA
Q301 VS2SA1576//-1 2SA1576 AB
Q304 VSDTC144EE/-1 DTC144EE AA
Q307 VS2SA1298Y/-1 2SA1298Y AB
Q308 VS2SA1298Y/-1 2SA1298Y AB
Q309 VS2SA1298Y/-1 2SA1298Y AB
Q701 VSDTA144EE/-1 DTA144EE AA
Q702 VSDTC144EE/-1 DTC144EE AA
Q705 VSDTC144EE/-1 DTC144EE AA
Q1801 VS2SC4738Y/-1 2SC4738Y AA
Q1803 VSDTC144EE/-1 DTC144EE AA
Q1804 VSDTA144EE/-1 DTA144EE AA
Q1805 VSDTA144EE/-1 DTA144EE AA
Q1806 VSDTA144EE/-1 DTA144EE AA
Q1807 VS2SA1576//-1 2SA1576 AB
Q1808 VS2SA1774F/-1 2SA1774F AA
Q1900 VSDTA114YE/-1 DTA114YE AB
Q2004 VSDTA114EE/-1 DTA114EE AB
Q2005 VSDTA114EE/-1 DTA114EE AB
Q2102 VSDTC114EE/-1 DTC114EE AB
Q2103 VSDTA144EE/-1 DTA144EE AA
Q2104 VSDTC114EE/-1 DTC114EE AB
Q2201 VSDTA144EE/-1 DTA144EE AA
Q2202 VSDTC144EE/-1 DTC144EE AA
Q2203 VSDTC144EE/-1 DTC144EE AA
Q2204 VS2SC4738Y/-1 2SC4738Y AA
Q2205 VS2SC4738Y/-1 2SC4738Y AA
Q2206 VS2SA1576//-1 S2SA1576 AB
Q2311 VSDTC114EE/-1 DTC114EE AB
Q2312 VSDTC114EE/-1 DTC114EE AB
Q3102 VSDTA144EE/-1 DTA144EE AA
Q3103 VS2SC4738Y/-1 2SC4738Y AA
Q3201 VS2SC4738Y/-1 2SC4738Y AA
Q3202 VS2SC4738Y/-1 2SC4738Y AA
Q3203 VSDTA144EE/-1 DTA144EE AA
Q3204 VSDTA144EE/-1 DTA144EE AA
Q3601 VS2SA1362GR-1 2SA1362GR AC
Q6000 VS2SD1306-E1E 2SD1306 AD
Q6001 VS2SD1306-E1E 2SD1306 AD
Q6002 VSDTA114EE/-1 DTA114EE AB
Q6612 VS2SC4213B/-1 2SC4213B AC
Q6613 VS2SC4213B/-1 2SC4213B AC
Q6615 VS2SC4213B/-1 2SC4213B AC
Q6616 VS2SC4213B/-1 2SC4213B AC
DIODES
D112 VHDDAN222//-1 DAN222 AA
D301 VHDDAP222//-1 DAP222 AA
D501 VHDMA132K//-1 DMA132K AA
D502 VHDMA132K//-1 DMA132K AA
D1802 VHDDAN222//-1 DAN222 AA
D1807 VHDMA132K//-1 MA132K AA
D2000 VHDMA132K//-1 MA132K AA
D2002 VHDMA132K//-1 MA132K AA
D2101 VHDMA716///-1 MA716 AC
D2102 VHDMA716///-1 MA716 AC
D2301 VHDDAP222//-1 DAP222 AA
D2302 VHDMA132K//-1 MA132K AA
D2303 VHDMA132K//-1 MA132K AA
15-1
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
DUNTK5869KE52 Main PWB Unit —
DUNTK5870KE52 LCD PWB Unit —
DUNTK5755XJ6B Operate PWB Unit —
DUNTK5869KE52
MAIN PWB UNIT
INTEGRATED CIRCUITS
IC201 VHiMC44722A-1 MC44722A, Video Enc. AX
IC303 RH-iX1517GEZZ IX1517GE, RF Processor AX
IC401 RH-iX1484GEZZ IX1484GE, 4M DRAM AU
IC402 RH-iX1474GEZZ IX1474GE, DEM/ECC BG
IC501 RH-iX1626GEZZ IX1626GE, Flash Memory AX
IC504 RH-iX1478GEZZ IX1478GE, Micro Com. BA
IC506 RH-iX1618GEZZ IX1618GE, 1M SRAM AR
IC512 RH-iX1535GEZZ IX1535GE, Host I/F AN
IC601 RH-iX1608GEZZ IX1608GE, Source Decoder BM
IC602 RH-iX0750TAZZ IX0750TA, 16 SDRAM AX
IC701 VHiAN8473NS-1 AN8473NS, Spin Driver AN
IC702 VHiBA5933FP-1 BA5933FP AM
IC703 VHi10324AFV-1 10324AFV AF
IC704 RH-iX1531CEZZ IX1531CE, Multiplexer AF
IC707 RH-iX1473GEZZ IX1473GE, Servo Processor BA
IC801 VHiPCM1716E-1 PCM1716E AV
IC901 RH-iX1516GEZZ IX1516GE, Gamma S-P Tone AV
IC1801 VHiiR3Y29BM-1 IR3Y29BM, LCD Decoder AT
IC1900 VHiBA7046F/-1 BA7046F AF
IC1901 VHiTHC221AF-1 THC221AF AG
IC1902 VHiTC4S81F/-1 TC4S81F AC
IC2101 VHiNJM2535V-1 NJM2535V, AE
Input Video Selector
IC2102 VHiTK15400/-1 TK15400 AK
IC2103 VHiTC4S66F/-1 TC4S66F, SW AD
IC3200 RH-iX1625GEN2 IX1625GE AT
IC3201 VHiMB8346BV-1 MB8346BV AN
IC3202 VHiBR93L46F-1 BR93L46F AG
IC3205 VHiS875045B-1 S875045B AH
IC3301 VHiTC7W14U/-1 TC7W14U AG
IC3601 VHiTK11835/-1 TK11835 AH
IC6000 VHiNJM4560M-1 NJM4560M, Audio Amp AG
IC6002 VHiTDA7053/-1 TDA7053 AL

Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
76
DV-L70U
C118 VCKYCY1CF104Z 0.1 16V Ceramic AA
C201 VCSATE0JJ476M 47 6.3V Tantalum AF
C202 VCKYCY1EB103K 0.01 25V Ceramic AA
C203 VCSATE1AJ476M 47 10V Tantalum AD
C204 VCCCCY1HH270J 27p 50V Ceramic AA
C205 VCCCCY1HH560J 56p 50V Ceramic AA
C206 VCCCCY1HH390J 39p 50V Ceramic AA
C207 VCCCCY1HH150J 15p 50V Ceramic AA
C208 VCKYCY1EB103K 0.01 25V Ceramic AA
C210 VCKYCY1EB103K 0.01 25V Ceramic AA
C211 VCCCCY1HH270J 27p 50V Ceramic AA
C212 VCCCCY1HH560J 56p 50V Ceramic AA
C213 VCCCCY1HH390J 39p 50V Ceramic AA
C214 VCCCCY1HH150J 15p 50V Ceramic AA
C216 VCKYCY1EB103K 0.01 25V Ceramic AA
C219 VCSATE1AJ476M 47 10V Tantalum AD
C220 VCKYCY1HF103Z 0.01 50V Ceramic AA
C226 VCSATE1AJ476M 47 10V Tantalum AD
C228 VCKYCY1HF103Z 0.01 50V Ceramic AA
C229 VCSATA0JJ106M 10 6.3V Tantalum AD
C230 VCKYCY1HF103Z 0.01 50V Ceramic AA
C237 VCEA0A0JW477M 470 6.3V Electrolytic AC
C238 VCEA0A0JW477M 470 6.3V Electrolytic AC
C301 VCKYCY1AF105Z 1 10V Ceramic AC
C302 VCKYCY1AF105Z 1 10V Ceramic AC
C303 VCKYCY1AF105Z 1 10V Ceramic AC
C304 VCKYCY1AF105Z 1 10V Ceramic AC
C305 VCKYCY1CB104K 0.1 16V Ceramic AB
C306 VCKYCY1CB104K 0.1 16V Ceramic AB
C308 VCKYCY1EB103K 0.01 25V Ceramic AA
C310 VCKYCY1AF105Z 1 10V Ceramic AC
C312 VCKYCY1EB103K 0.01 25V Ceramic AA
C315 VCSATE1AJ476M 47 10V Tantalum AD
C331 VCKYCY1EB103K 0.01 25V Ceramic AA
C332 VCKYCY1AF105Z 1 10V Ceramic AC
C333 VCKYCY1CB104K 0.1 16V Ceramic AB
C334 VCKYCY1CB104K 0.1 16V Ceramic AB
C335 VCKYCY1HB472K 4700p 50V Ceramic AA
C336 VCKYCY1HB472K 4700p 50V Ceramic AA
C337 VCKYCY1CB104K 0.1 16V Ceramic AB
C340 VCSATE1AJ226M 22 10V Tantalum AD
C341 VCKYCY1CB104K 0.1 16V Ceramic AB
C342 VCKYCY1CB104K 0.1 16V Ceramic AB
C343 VCKYCY1CB104K 0.1 16V Ceramic AB
C344 VCKYCY1HB102K 1000p 50V Ceramic AA
C345 VCKYCY1HB102K 1000p 50V Ceramic AA
C346 VCKYCY1AF105Z 1 10V Ceramic AC
C351 VCKYCY1EB103K 0.01 25V Ceramic AA
C353 VCSATE1AJ476M 47 10V Tantalum AD
C354 VCKYCY1CB104K 0.1 16V Ceramic AB
C355 VCSATE1AJ476M 47 10V Tantalum AD
C362 VCSATE1AJ476M 47 10V Tantalum AD
C363 VCKYCY1EB103K 0.01 25V Ceramic AA
C371 VCKYCY1CB104K 0.1 16V Ceramic AB
C372 VCSAPD0JJ225M 2.2 6.3V Tantalum AD
C373 VCSATE1AJ476M 47 10V Tantalum AD
C374 VCKYCY1CB104K 0.1 16V Ceramic AB
C401 VCKYCY1HB471K 470p 50V Ceramic AA
C402 VCSATE1AJ476M 47 10V Tantalum AD
C404 VCKYCY1CB104K 0.1 16V Ceramic AB
C405 VCSATE1AJ476M 47 10V Tantalum AD
C406 VCCCCY1HH331J 330p 50V Ceramic AA
C407 VCCCCY1HH331J 330p 50V Ceramic AA
C408 VCKYCY1CB333K 0.033 16V Ceramic AA
C409 VCKYCY1EB103K 0.01 25V Ceramic AA
C410 VCCCCY1HH220J 22p 50V Ceramic AA
C411 VCKYCY1AF105Z 1 10V Ceramic AC
C412 VCKYCY1EB103K 0.01 25V Ceramic AA
C413 VCKYCY1AF105Z 1 10V Ceramic AC
C414 VCKYCY1EB103K 0.01 25V Ceramic AA
C415 VCKYCY1HB471K 470p 50V Ceramic AA
C416 VCKYCY1EB103K 0.01 25V Ceramic AA
C417 VCKYCY1CB104K 0.1 16V Ceramic AB
C418 VCKYCY1EB103K 0.01 25V Ceramic AA
C419 VCKYCY1EB103K 0.01 25V Ceramic AA
15-2
D3100 VHDDAN222//-1 DAN222 AA
D3101 VHDDA227///-1 DA227 AB
D3102 VHDDA227///-1 DA227 AB
D3103 VHDDAN222//-1 DAN222 AA
D3106 VHDDA221///-1 DA221 AB
D3107 VHDDA221///-1 DA221 AB
D3108 VHDDA221///-1 DA221 AB
D3109 VHDHVU17TRF-1 HVU17TRF AE
D3113 VHDMA132K//-1 MA132K AA
D3151 VHDMA132K//-1 MA132K AA
D3152 VHDDAN222//-1 DAN222 AA
D3159 VHDMA132K//-1 MA132K AA
D3202 RH-PX0421CEZZ PhotoDiode AD
D3301 VHDMA132K//-1 MA132K AA
D3601 VHDMA132K//-1 MA132K AA
D3602 VHDDA227///-1 DA227 AB
D6001 VHDDAN222//-1 DAN222 AA
TH3100 RH-HZ0025CEZZ Thermistor AC
PACKAGED CIRCUITS
X601 RCRSC0031GEZZ Crystal, CRSC0031GE AK
X702 RCRSC0035GEZZ Crystal, CRSC0035GE AG
X1801 RCRSC0087TAZZ Crystal, CRSC0087TA AK
FILTERS
FL501 RFiLC0196GEZZ Filter, FiLC0196GE AE
X3100 RFiLC0201GEZZ Filter, FiLC0201GE AD
COILS
L201 VPAWM470J6R4N Peaking, 47µHAC
L203 VPAWM270J3R9N Peaking, 27µHAC
L204 VPAWM270J3R9N Peaking, 27µHAC
L205 VPAWM270J3R9N Peaking, 27µHAC
L206 VPAWM270J3R9N Peaking, 27µHAC
L209 VPAWM470J6R4N Peaking, 47µHAC
L301 VPAWM100J2R6N Peaking, 10µHAC
L303 VPAWM100J2R6N Peaking, 10µHAC
L304 VPAWM100J2R6N Peaking, 10µHAC
L351 VPAWM100J2R6N Peaking, 10µHAC
L401 VPAWM470J6R4N Peaking, 47µHAC
L403 VPAWM470J6R4N Peaking, 47µHAC
L501 VPAWM470J6R4N Peaking, 47µHAC
L502 VPAWM1R0JR70N Peaking, 1µHAC
L511 VPAWM470J6R4N Peaking, 47µHAC
L512 VPAWM470J6R4N Peaking, 47µHAC
L701 VPAWM100J2R6N Peaking, 10µHAC
L801 VPAWM470J6R4N Peaking, 47µHAC
L1803 VPAWM470J6R4N Peaking, 47µHAC
L1804 VPAWM470J6R4N Peaking, 47µHAC
L2001 VPAWM470J6R4N Peaking, 47µHAC
L2002 VPAWM470J6R4N Peaking, 47µHAC
L2202 VPAWM100J2R6N Peaking, 10µHAC
L3001 RCiLF0391TAZZ Coil, CiLF0391TA AG
L3002 RCiLF0391TAZZ Coil, CiLF0391TA AG
L3100 VPAWM470J6R4N Peaking, 47µHAC
L3203 VPAWM470J6R4N Peaking, 47µHAC
L3204 VPAWM470J6R4N Peaking, 47µHAC
L3601 VPAWM470J6R4N Peaking, 47µHAC
L3602 RCiLP0158GEZZ Coil, 150µHAE
L3603 VPAWM100J2R6N Peaking, 10µHAC
L3604 VPAWM470J6R4N Peaking, 47µHAC
L6001 RCiLF0391TAZZ Coil, CiLF0391TA AG
L6002 RCiLF0391TAZZ Coil, CiLF0391TA AG
CAPACITORS
C111 VCEAPF0GW227M 220 4V Electrolytic AB
C112 VCEAPF0JW107M 100 6.3V Electrolytic AC
C114 VCKYCY1CF104Z 0.1 16V Ceramic AA
C115 VCKYCY1CF104Z 0.1 16V Ceramic AA
C116 VCKYCY1CF104Z 0.1 16V Ceramic AA
C117 VCKYCY1CF104Z 0.1 16V Ceramic AA
DUNTK5869KE52
MAIN PWB UNIT(Continued)

Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
77
DV-L70U
C716 VCKYCY1EB103K 0.01 25V Ceramic AA
C718 VCKYCY1HB222K 2200p 50V Ceramic AA
C719 VCKYCY1HB332K 3300p 50V Ceramic AA
C720 VCKYCY1EB103K 0.01 25V Ceramic AA
C721 VCKYCY1CB473K 0.047 16V Ceramic AA
C724 VCCCCY1HH100D 10p 50V Ceramic AA
C725 VCCCCY1HH9R0D 9p 50V Ceramic AA
C727 VCKYCY1EB103K 0.01 25V Ceramic AA
C728 VCKYCY1EB103K 0.01 25V Ceramic AA
C729 VCCCCY1HH101J 100p 50V Ceramic AA
C730 VCKYCY1EB103K 0.01 25V Ceramic AA
C731 VCKYCY1HB472K 4700p 50V Ceramic AA
C732 VCKYCY1EB103K 0.01 25V Ceramic AA
C733 VCKYCY1HB472K 4700p 50V Ceramic AA
C734 VCKYCY1EB103K 0.01 25V Ceramic AA
C735 VCKYCY1CB473K 0.047 16V Ceramic AA
C736 VCKYCY1EB103K 0.01 25V Ceramic AA
C737 VCCCCY1HH221J 220p 50V Ceramic AA
C738 VCKYCY1EB103K 0.01 25V Ceramic AA
C739 VCKYCY1HB471K 470p 50V Ceramic AA
C740 VCCCCY1HH221J 220p 50V Ceramic AA
C741 VCKYCY1EB103K 0.01 25V Ceramic AA
C742 VCKYCY1EB103K 0.01 25V Ceramic AA
C743 VCKYCY1HB272K 2700p 50V Ceramic AA
C744 VCKYCY1EB103K 0.01 25V Ceramic AA
C745 VCKYCY1EB103K 0.01 25V Ceramic AA
C746 VCKYCY1EB103K 0.01 25V Ceramic AA
C747 VCKYCY1EB153K 0.015 25V Ceramic AA
C748 VCKYCY1EB103K 0.01 25V Ceramic AA
C749 VCCCCY1HH470J 47p 50V Ceramic AA
C751 VCKYCY1EB103K 0.01 25V Ceramic AA
C752 VCKYCY1EB103K 0.01 25V Ceramic AA
C753 VCSATE0JJ476M 47 6.3V Tantalum AF
C754 VCSATE1AJ476M 47 10V Tantalum AD
C755 VCSATE1AJ476M 47 10V Tantalum AD
C758 VCSATE1DJ106M 10 20V Tantalum AD
C762 VCKYCY1CB104K 0.1 16V Ceramic AB
C763 VCSATE1AJ476M 47 10V Tantalum AD
C764 VCKYCY1CB104K 0.1 16V Ceramic AB
C766 VCKYCY1CB104K 0.1 16V Ceramic AB
C767 VCSATE1AJ476M 47 10V Tantalum AD
C770 VCKYCY1HB222K 2200p 50V Ceramic AA
C774 VCKYCY1HF103Z 0.01 50V Ceramic AA
C775 VCKYCY1HF103Z 0.01 50V Ceramic AA
C776 VCKYCY1HF103Z 0.01 50V Ceramic AA
C801 VCSATA1AJ106M 10 10V Tantalum AC
C802 VCKYCY1CB104K 0.1 16V Ceramic AB
C803 VCSATA1AJ106M 10 10V Tantalum AC
C804 VCSATD1AJ107M 100 10V Tantalum AF
C805 RC-KZ0162GEZZ 4700p AB
C806 RC-KZ0162GEZZ 4700p AB
C829 VCKYCY1CB104K 0.1 16V Ceramic AB
C901 VCKYCY1HF103Z 0.01 50V Ceramic AA
C902 VCKYCY1HF103Z 0.01 50V Ceramic AA
C903 VCKYCY1HF103Z 0.01 50V Ceramic AA
C904 VCKYCY1HF103Z 0.01 50V Ceramic AA
C905 VCKYCY1CF104Z 0.1 16V Ceramic AA
C906 VCSATE1AJ476M 47 10V Tantalum AD
C1802 VCEAPF1AW476M 47 10V Electrolytic AB
C1803 RC-KZ0082TAZZ 1 10V AC
C1804 VCKYCY1HF103Z 0.01 50V Ceramic AA
C1805 VCKYCY1HF103Z 0.01 50V Ceramic AA
C1806 VCCCCY1EH821J 820p 25V Ceramic AB
C1807 VCKYCY1AF105Z 1 10V Ceramic AC
C1808 VCKYCY1AF105Z 1 10V Ceramic AC
C1809 VCKYCY1HF103Z 0.01 50V Ceramic AA
C1810 VCKYCY1HF103Z 0.01 50V Ceramic AA
C1811 VCKYCY1AF105Z 1 10V Ceramic AC
C1812 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1813 VCKYCY1AF105Z 1 10V Ceramic AC
C1814 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1815 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1816 VCKYCY1HF103Z 0.01 50V Ceramic AA
C1817 VCCCCY1HH5R0C 5p 50V Ceramic AA
C1818 VCKYCY1CF104Z 0.1 16V Ceramic AA
15-3
C420 VCKYCY1EB103K 0.01 25V Ceramic AA
C421 VCKYCY1EB103K 0.01 25V Ceramic AA
C424 VCCCCY1HH101J 100p 50V Ceramic AA
C426 VCKYCY1CB104K 0.1 16V Ceramic AB
C427 VCKYCY1EB103K 0.01 25V Ceramic AA
C428 VCKYCY1EB103K 0.01 25V Ceramic AA
C429 VCSATE1AJ476M 47 10V Tantalum AD
C430 VCKYCY1EB103K 0.01 25V Ceramic AA
C431 VCKYCY1EB103K 0.01 25V Ceramic AA
C432 VCKYCY1EB103K 0.01 25V Ceramic AA
C440 VCKYCY1CB104K 0.1 16V Ceramic AB
C441 VCKYCY1CB104K 0.1 16V Ceramic AB
C451 VCSATE1AJ476M 47 10V Tantalum AD
C452 VCSATE1AJ476M 47 10V Tantalum AD
C453 VCSATE1AJ476M 47 10V Tantalum AD
C454 VCSATE1AJ476M 47 10V Tantalum AD
C455 VCKYCY1CB104K 0.1 16V Ceramic AB
C502 VCKYCY1EB103K 0.01 25V Ceramic AA
C503 VCKYCY1EB103K 0.01 25V Ceramic AA
C505 VCSATE0JJ476M 47 6.3V Tantalum AF
C506 VCKYCY1CB104K 0.1 16V Ceramic AB
C507 VCKYCY1EB103K 0.01 25V Ceramic AA
C511 VCKYCY1EB103K 0.01 25V Ceramic AA
C512 VCKYCY1EB103K 0.01 25V Ceramic AA
C513 VCKYCY1CB104K 0.1 16V Ceramic AB
C517 VCKYCY1EB103K 0.01 25V Ceramic AA
C519 VCSATA0JJ226M 22 6.3V Tantalum AD
C520 VCKYCY1EB103K 0.01 25V Ceramic AA
C521 VCKYCY1EB103K 0.01 25V Ceramic AA
C522 VCSATA1AJ106M 10 10V Tantalum AC
C524 VCKYCY1EB103K 0.01 25V Ceramic AA
C530 VCKYCY1EB103K 0.01 25V Ceramic AA
C531 VCKYCY1EB103K 0.01 25V Ceramic AA
C532 VCKYCY1EB103K 0.01 25V Ceramic AA
C550 VCKYCY1EB103K 0.01 25V Ceramic AA
C551 VCKYCY1EB103K 0.01 25V Ceramic AA
C552 VCKYCY1EB103K 0.01 25V Ceramic AA
C553 VCKYCY1EB103K 0.01 25V Ceramic AA
C561 VCKYCY1EB822K 8200p 25V Ceramic AA
C601 VCEAPF0GW227M 220 4V Electrolytic AB
C602 VCKYCY1EB103K 0.01 25V Ceramic AA
C603 VCKYCY1CB104K 0.1 16V Ceramic AB
C604 VCKYCY1HB102K 1000p 50V Ceramic AA
C605 VCKYCY1CB104K 0.1 16V Ceramic AB
C606 VCKYCY1EB103K 0.01 25V Ceramic AA
C607 VCKYCY1EB103K 0.01 25V Ceramic AA
C608 VCKYCY1CB104K 0.1 16V Ceramic AB
C609 VCKYCY1CB104K 0.1 16V Ceramic AB
C610 VCKYCY1CB104K 0.1 16V Ceramic AB
C611 VCSATE0JJ476M 47 6.3V Tantalum AF
C612 VCKYCY1EB103K 0.01 25V Ceramic AA
C613 VCKYCY1CB104K 0.1 16V Ceramic AB
C614 VCKYCY1HB102K 1000p 50V Ceramic AA
C615 VCKYCY1CB104K 0.1 16V Ceramic AB
C616 VCKYCY1HB102K 1000p 50V Ceramic AA
C617 VCSATE0JJ476M 47 6.3V Tantalum AF
C618 VCKYCY1HB102K 1000p 50V Ceramic AA
C619 VCKYCY1HB102K 1000p 50V Ceramic AA
C620 VCCCCY1HH1R0C 1p 50V Ceramic AA
C621 VCKYCY1EB103K 0.01 25V Ceramic AA
C622 VCCCCY1HH6R0D 6p 50V Ceramic AA
C623 VCKYCY1CB104K 0.1 16V Ceramic AB
C625 VCKYCY1EB103K 0.01 25V Ceramic AA
C626 VCKYCY1HB102K 1000p 50V Ceramic AA
C627 VCKYCY1EB103K 0.01 25V Ceramic AA
C628 VCKYCY1CB104K 0.1 16V Ceramic AB
C631 VCCCCY1HH0R5C 0.5p 50V Ceramic AA
C702 VCKYCY1EB103K 0.01 25V Ceramic AA
C703 VCKYCY1EB103K 0.01 25V Ceramic AA
C704 VCKYCY1CF104Z 0.1 16V Ceramic AA
C705 VCKYCY1CF104Z 0.1 16V Ceramic AA
C713 VCKYCY1HB332K 3300p 50V Ceramic AA
DUNTK5869KE52
MAIN PWB UNIT(Continued)

Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
78
DV-L70U
15-4
C1819 VCKYCY1AF105Z 1 10V Ceramic AC
C1820 VCSATN1AJ225M 2.2 10V Tantalum AC
C1821 VCKYCY1CF474Z 0.47 16V Ceramic AB
C1825 VCKYCY1HF103Z 0.01 50V Ceramic AA
C1827 VCKYCY1HF103Z 0.01 50V Ceramic AA
C1828 VCSATA1AJ106M 10 10V Tantalum AC
C1831 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1833 VCKYCY1HF103Z 0.01 50V Ceramic AA
C1834 VCKYCY1HF103Z 0.01 50V Ceramic AA
C1836 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1837 VCKYCY1HF473Z 0.047 50V Ceramic AA
C1838 VCKYCY1HF103Z 0.01 50V Ceramic AA
C1839 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1840 VCSATA1AJ106M 10 10V Tantalum AC
C1841 VCSATD1AJ107M 100 10V Tantalum AF
C1842 VCKYCY1AF105Z 1 10V Ceramic AC
C1843 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1844 VCEAPF0JW107M 100 6.3V Electrolytic AC
C1845 VCSATE1AJ476M 47 10V Tantalum AD
C1847 VCSATD1AJ107M 100 10V Tantalum AF
C1900 VCKYTV1CF105Z 1 16V Ceramic AB
C1901 VCKYCY1HB222K 2200p 50V Ceramic AA
C1902 VCCCCY1HH101J 100p 50V Ceramic AA
C1903 VCKYTV1CF105Z 1 16V Ceramic AB
C1904 VCCCCY1HH331J 330p 50V Ceramic AA
C1905 VCCCCY1HH221J 220p 50V Ceramic AA
C1906 VCKYTV1CF105Z 1 16V Ceramic AB
C1907 VCCCCY1HH121J 120p 50V Ceramic AA
C1908 VCCCCY1HH121J 120p 50V Ceramic AA
C1909 VCCCCY1HH391J 390p 50V Ceramic AA
C2002 VCKYCY1AF105Z 1 10V Ceramic AC
C2012 VCEAPF0JW107M 100 6.3V Electrolytic AC
C2013 VCSATA1AJ106M 10 10V Tantalum AC
C2014 VCEAPF0JW107M 100 6.3V Electrolytic AC
C2104 RC-KZ0082TAZZ 1 10V AC
C2108 VCSATE0JJ107M 100 6.3V Tantalum AE
C2109 VCSATE1AJ336M 33 10V Tantalum AG
C2110 RC-KZ0082TAZZ 1 10V AC
C2111 VCKYCY1CF104Z 0.1 16V Ceramic AA
C2112 VCKYCY1CF473Z 0.047 16V Ceramic AA
C2113 RC-KZ0082TAZZ 1 10V AC
C2201 VCKYCY1CF104Z 0.1 16V Ceramic AA
C2202 VCSATA0JJ106M 10 6.3V Tantalum AD
C2205 VCSATE1AJ476M 47 10V Tantalum AD
C2206 VCSATE1AJ476M 47 10V Tantalum AD
C2207 VCSATE1AJ476M 47 10V Tantalum AD
C3028 VCKYCY1CF104Z 0.1 16V Ceramic AA
C3029 VCKYCY1AF105Z 1 10V Ceramic AC
C3030 VCSATA0JJ226M 22 6.3V Tantalum AD
C3037 VCKYCY1EB223K 0.022 25V Ceramic AA
C3042 VCKYTV1EB104K 0.1 25V Ceramic AB
C3101 VCCCCY1HH471J 470p 50V Ceramic AA
C3102 VCCCCY1HH471J 470p 50V Ceramic AA
C3103 VCCCCY1HH471J 470p 50V Ceramic AA
C3104 VCCCCY1HH221J 220p 50V Ceramic AA
C3107 VCCCCY1HH101J 100p 50V Ceramic AA
C3108 VCCCCY1HH101J 100p 50V Ceramic AA
C3109 VCCCCY1HH471J 470p 50V Ceramic AA
C3110 VCCCCY1HH471J 470p 50V Ceramic AA
C3111 VCCCCY1HH221J 220p 50V Ceramic AA
C3112 VCCCCY1HH471J 470p 50V Ceramic AA
C3113 VCCCCY1HH221J 220p 50V Ceramic AA
C3114 VCCCCY1HH221J 220p 50V Ceramic AA
C3115 VCCCCY1HH471J 470p 50V Ceramic AA
C3116 VCCCCY1HH471J 470p 50V Ceramic AA
C3117 VCCCCY1HH471J 470p 50V Ceramic AA
C3118 VCCCCY1HH471J 470p 50V Ceramic AA
C3119 VCCCCY1HH220J 22p 50V Ceramic AA
C3120 VCCCCY1HH471J 470p 50V Ceramic AA
C3121 VCKYCY1HF103Z 0.01 50V Ceramic AA
C3122 VCKYCY1HF103Z 0.01 50V Ceramic AA
C3123 VCKYCY1HF103Z 0.01 50V Ceramic AA
DUNTK5869KE52
MAIN PWB UNIT(Continued) C3124 VCSATE1AJ476M 47 10V Tantalum AD
C3125 VCKYCY1AF105Z 1 10V Ceramic AC
C3126 VCCCCY1HH470J 47p 50V Ceramic AA
C3129 VCCCCY1HH471J 470p 50V Ceramic AA
C3130 VCKYCY1HF103Z 0.01 50V Ceramic AA
C3131 VCKYCY1CF104Z 0.1 16V Ceramic AA
C3132 VCCCCY1HH471J 470p 50V Ceramic AA
C3133 VCCCCY1HH471J 470p 50V Ceramic AA
C3134 VCCCCY1HH471J 470p 50V Ceramic AA
C3135 VCCCCY1HH471J 470p 50V Ceramic AA
C3136 VCCCCY1HH471J 470p 50V Ceramic AA
C3137 VCCCCY1HH471J 470p 50V Ceramic AA
C3138 VCCCCY1HH471J 470p 50V Ceramic AA
C3139 VCCCCY1HH471J 470p 50V Ceramic AA
C3140 VCCCCY1HH471J 470p 50V Ceramic AA
C3142 VCCCCY1HH471J 470p 50V Ceramic AA
C3143 VCCCCY1HH471J 470p 50V Ceramic AA
C3144 VCCCCY1HH471J 470p 50V Ceramic AA
C3145 VCSATA1AJ106M 10 10V Tantalum AC
C3361 VCKYCY1CF104Z 0.1 16V Ceramic AA
C3362 VCSATE1AJ476M 47 10V Tantalum AD
C3601 VCSATE1AJ476M 47 10V Tantalum AD
C3602 VCKYCY1HB102K 1000p 50V Ceramic AA
C3603 VCSATE1AJ476M 47 10V Tantalum AD
C3604 VCKYCY1CF104Z 0.1 16V Ceramic AA
C6000 VCSATA1AJ106M 10 10V Tantalum AC
C6001 VCSATA1AJ106M 10 10V Tantalum AC
C6003 VCSATA1AJ106M 10 10V Tantalum AC
C6004 VCSATA1AJ106M 10 10V Tantalum AC
C6005 RC-KZ0161GEZZ 3900p 50V Ceramic AB
C6006 RC-KZ0161GEZZ 3900p 50V Ceramic AB
C6007 VCKYCY1AF105Z 1 10V Ceramic AC
C6008 VCKYCY1CB104K 0.1 16V Ceramic AB
C6009 VCEAPF1CW106M 10 16V Electrolytic AB
C6010 VCKYCY1CB104K 0.1 16V Ceramic AB
C6011 VCKYCY1AF105Z 1 10V Ceramic AC
C6012 VCKYCY1AF105Z 1 10V Ceramic AC
C6013 VCEAPF1CW106M 10 16V Electrolytic AB
C6014 VCEAPF1CW106M 10 16V Electrolytic AB
C6021 VCSATJ0JJ107M 100 6.3V Tantalum AE
C6022 VCKYCY1EB103K 0.01 25V Ceramic AA
C6051 VCKYCY1AF105Z 1 10V Ceramic AC
C6052 VCKYCY1AF105Z 1 10V Ceramic AC
C6055 VCKYCY1EB223K 0.022 25V Ceramic AA
C6056 VCKYCY1EB223K 0.022 25V Ceramic AA
C6202 VCKYCY1CF104Z 0.1 16V Ceramic AA
C6203 VCKYCY1CF104Z 0.1 16V Ceramic AA
C6300 VCKYCY1CF104Z 0.1 16V Ceramic AA
C6630 VCKYCY1EB103K 0.01 25V Ceramic AA
C6631 VCEAPF1CW106M 10 16V Electrolytic AB
C6632 VCKYCY1CB104K 0.1 16V Ceramic AB
C6633 VCKYCY1CB104K 0.1 16V Ceramic AB
C6634 VCEAPF1CW106M 10 16V Electrolytic AB
C6635 VCEAPF1CW106M 10 16V Electrolytic AB
C6638 VCKYCY1CB683K 0.068 16V Ceramic AC
C6639 VCKYCY1CB683K 0.068 16V Ceramic AC
C6640 VCKYCY1CB104K 0.1 16V Ceramic AB
C6641 VCKYCY1CB104K 0.1 16V Ceramic AB
C6642 VCKYCY1HF103Z 0.01 50V Ceramic AA
C6643 VCKYCY1HF103Z 0.01 50V Ceramic AA
C6644 VCKYCY1CB104K 0.1 16V Ceramic AB
C7001 VCKYCY1HB102K 1000p 50V Ceramic AA
RESISTORS
R113 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R114 VRS-CY1JF222J 2.2k 1/16W Metal Oxide AA
R119 VRS-TW2ED820J 82 1/4W Metal Oxide AB
R120 VRS-CY1JF681J 680 1/16W Metal Oxide AA
R123 VRS-CY1JF153J 15k 1/16W Metal Oxide AA
R124 VRS-CY1JF561J 560 1/16W Metal Oxide AA
R125 VRS-CY1JF122J 1.2k 1/16W Metal Oxide AA
R126 VRS-CY1JF561J 560 1/16W Metal Oxide AA
R201 VRS-CY1JF181J 180 1/16W Metal Oxide AA
R204 VRS-CY1JF681J 680 1/16W Metal Oxide AA
R205 VRS-CY1JF392J 3.9k 1/16W Metal Oxide AA

Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
79
DV-L70U
15-5
R507 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R508 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R509 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R511 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R512 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R513 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R514 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R517 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R518 VRS-CY1JF473J 47k 1/16W Metal Oxide AA
R519 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R520 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R521 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R522 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R523 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R524 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R525 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R527 VRS-CY1JF100J 10 1/16W Metal Oxide AA
R528 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R529 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R530 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R531 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R532 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R533 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R534 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R535 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R551 VRS-CY1JF560J 56 1/16W Metal Oxide AA
R552 VRS-CY1JF560J 56 1/16W Metal Oxide AA
R553 VRS-CY1JF560J 56 1/16W Metal Oxide AA
R563 VRS-CY1JF151J 150 1/16W Metal Oxide AA
R564 VRS-CY1JF151J 150 1/16W Metal Oxide AA
R565 VRS-CY1JF151J 150 1/16W Metal Oxide AA
R566 VRS-CY1JF151J 150 1/16W Metal Oxide AA
R567 VRS-CY1JF151J 150 1/16W Metal Oxide AA
R568 VRS-CY1JF151J 150 1/16W Metal Oxide AA
R569 VRS-CY1JF151J 150 1/16W Metal Oxide AA
R571 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R572 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R573 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R581 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R582 VRS-CY1JF100J 10 1/16W Metal Oxide AA
R583 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R589 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R590 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R591 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R592 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R595 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R596 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R597 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R598 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R599 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R603 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R624 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R630 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R632 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R634 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R635 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R636 VRS-CY1JF560J 56 1/16W Metal Oxide AA
R638 VRS-CY1JF560J 56 1/16W Metal Oxide AA
R641 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R642 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R643 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R644 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R645 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R647 VRS-CY1JF560J 56 1/16W Metal Oxide AA
R648 VRS-CY1JF560J 56 1/16W Metal Oxide AA
R649 VRS-CY1JF560J 56 1/16W Metal Oxide AA
R652 VRS-CY1JF560J 56 1/16W Metal Oxide AA
R653 VRS-CY1JF564J 560k 1/16W Metal Oxide AA
R654 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R657 VRS-CY1JF4R7J 4.7 1/16W Metal Oxide AA
R658 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R670 VRS-TV1JD100J 10 1/16W Metal Oxide AA
R701 VRS-TW2ED1R0J 1 1/4W Metal Oxide AB
R702 VRS-TW2ED1R0J 1 1/4W Metal Oxide AB
R703 VRS-CY1JF151J 150 1/16W Metal Oxide AA
R207 VRS-CY1JF681J 680 1/16W Metal Oxide AA
R208 VRS-CY1JF391J 390 1/16W Metal Oxide AA
R211 VRS-CY1JF391J 390 1/16W Metal Oxide AA
R212 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R215 VRS-CY1JF201F 200 1/16W Metal Oxide AA
R217 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R218 VRS-CY1JF681J 680 1/16W Metal Oxide AA
R219 VRS-CY1JF392J 3.9k 1/16W Metal Oxide AA
R221 VRS-CY1JF681J 680 1/16W Metal Oxide AA
R222 VRS-CY1JF391J 390 1/16W Metal Oxide AA
R224 VRS-CY1JF201F 200 1/16W Metal Oxide AA
R225 VRS-CY1JF391J 390 1/16W Metal Oxide AA
R226 VRS-CY1JF181J 180 1/16W Metal Oxide AA
R228 VRS-CY1JF181J 180 1/16W Metal Oxide AA
R233 VRS-CY1JF181J 180 1/16W Metal Oxide AA
R269 VRS-CY1JF182J 1.8k 1/16W Metal Oxide AA
R270 VRS-CY1JF152F 1.5k 1/16W Metal Oxide AA
R271 VRS-CY1JF152F 1.5k 1/16W Metal Oxide AA
R272 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R273 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R274 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R275 VRS-CY1JF100J 10 1/16W Metal Oxide AA
R290 VRS-CY1JF220J 22 1/16W Metal Oxide AA
R302 VRS-CY1JF222J 2.2k 1/16W Metal Oxide AA
R304 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R307 VRS-TW2ED470J 47 1/4W Metal Oxide AA
R308 VRS-TW2ED470J 47 1/4W Metal Oxide AA
R312 VRS-CY1JF471J 470 1/16W Metal Oxide AA
R329 VRS-CY1JF123J 12k 1/16W Metal Oxide AA
R330 VRS-CY1JF822J 8.2k 1/16W Metal Oxide AA
R331 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R332 VRS-CY1JF391J 390 1/16W Metal Oxide AA
R350 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R352 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R353 VRS-CY1JF151J 150 1/16W Metal Oxide AA
R354 VRS-CY1JF103F 10k 1/16W Metal Oxide AA
R355 VRS-CY1JF683F 68k 1/16W Metal Oxide AA
R369 VRS-CY1JF335J 3.3M 1/16W Metal Oxide AA
R391 VRS-TW2ED470J 47 1/4W Metal Oxide AA
R392 VRS-TW2ED470J 47 1/4W Metal Oxide AA
R393 VRS-CY1JF471J 470 1/16W Metal Oxide AA
R394 VRS-CY1JF335J 3.3M 1/16W Metal Oxide AA
R395 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R396 VRS-CY1JF222J 2.2k 1/16W Metal Oxide AA
R397 VRS-CY1JF471J 470 1/16W Metal Oxide AA
R401 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R402 VRS-CY1JF562J 5.6k 1/16W Metal Oxide AA
R403 VRS-CY1JF103F 10k 1/16W Metal Oxide AA
R404 VRS-CY1JF153F 15k 1/16W Metal Oxide AA
R405 VRS-CY1JF471J 470 1/16W Metal Oxide AA
R406 VRS-CY1JF471J 470 1/16W Metal Oxide AA
R409 VRS-CY1JF562J 5.6k 1/16W Metal Oxide AA
R412 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R413 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R414 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R416 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R417 VRS-CY1JF224J 220k 1/16W Metal Oxide AA
R418 VRS-CY1JF274J 270k 1/16W Metal Oxide AA
R419 VRS-CY1JF221J 220 1/16W Metal Oxide AA
R422 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R423 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R424 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R428 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R440 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R441 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R450 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R500 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R501 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R502 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R504 VRS-CY1JF332J 3.3k 1/16W Metal Oxide AA
R505 VRS-CY1JF332J 3.3k 1/16W Metal Oxide AA
R506 VRS-CY1JF332J 3.3k 1/16W Metal Oxide AA
DUNTK5869KE52
MAIN PWB UNIT(Continued)

Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
80
DV-L70U
15-6
R704 VRS-CY1JF151J 150 1/16W Metal Oxide AA
R709 VRS-TW2ED1R0J 1 1/4W Metal Oxide AB
R717 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R718 VRS-CY1JF822J 8.2k 1/16W Metal Oxide AA
R720 VRS-CY1JF123J 12k 1/16W Metal Oxide AA
R721 VRS-CY1JF821J 820 1/16W Metal Oxide AA
R724 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R725 VRS-CY1JF222J 2.2k 1/16W Metal Oxide AA
R728 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R729 VRS-CY1JF273J 27k 1/16W Metal Oxide AA
R733 VRS-CY1JF222J 2.2k 1/16W Metal Oxide AA
R737 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R738 VRS-CY1JF822J 8.2k 1/16W Metal Oxide AA
R740 VRS-CY1JF473J 47k 1/16W Metal Oxide AA
R741 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R742 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R744 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R756 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R758 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R760 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R761 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R768 VRS-CY1JF331J 330 1/16W Metal Oxide AA
R769 VRS-CY1JF331J 330 1/16W Metal Oxide AA
R771 VRS-CY1JF123J 12k 1/16W Metal Oxide AA
R772 VRS-CY1JF123J 12k 1/16W Metal Oxide AA
R774 VRS-CY1JF123J 12k 1/16W Metal Oxide AA
R778 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R779 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R781 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R782 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R786 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R789 VRS-CY1JF335J 3.3M 1/16W Metal Oxide AA
R790 VRS-CY1JF333J 33k 1/16W Metal Oxide AA
R791 VRS-CY1JF124J 120k 1/16W Metal Oxide AA
R793 VRS-CY1JF222J 2.2k 1/16W Metal Oxide AA
R794 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R795 VRS-CY1JF473J 47k 1/16W Metal Oxide AA
R796 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R797 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R801 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R802 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R811 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R819 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R820 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R821 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R822 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R831 VRS-CY1JF8R2J 8.2 1/16W Metal Oxide AA
R851 VRS-CY1JF100J 10 1/16W Metal Oxide AA
R852 VRS-CY1JF100J 10 1/16W Metal Oxide AA
R871 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R872 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R891 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R894 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R895 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R898 VRS-CY1JF824J 820k 1/16W Metal Oxide AA
R901 VRS-CY1JF820J 82 1/16W Metal Oxide AA
R902 VRS-CY1JF220J 22 1/16W Metal Oxide AA
R903 VRS-CY1JF820J 82 1/16W Metal Oxide AA
R904 VRS-CY1JF820J 82 1/16W Metal Oxide AA
R905 VRS-CY1JF820J 82 1/16W Metal Oxide AA
R906 VRS-CY1JF820J 82 1/16W Metal Oxide AA
R907 VRS-CY1JF820J 82 1/16W Metal Oxide AA
R908 VRS-CY1JF820J 82 1/16W Metal Oxide AA
R909 VRS-CY1JF820J 82 1/16W Metal Oxide AA
R910 VRS-CY1JF820J 82 1/16W Metal Oxide AA
R911 VRS-CY1JF820J 82 1/16W Metal Oxide AA
R912 VRS-CY1JF820J 82 1/16W Metal Oxide AA
R918 VRS-CY1JF820J 82 1/16W Metal Oxide AA
R922 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R932 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R1801 VRS-CY1JF181J 180 1/16W Metal Oxide AA
R1802 VRS-CY1JF151J 150 1/16W Metal Oxide AA
DUNTK5869KE52
MAIN PWB UNIT(Continued) R1803 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R1805 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R1806 VRS-CY1JF391J 390 1/16W Metal Oxide AA
R1807 VRS-CY1JF333J 33k 1/16W Metal Oxide AA
R1809 VRS-CY1JF104J 100k 1/16W Metal Oxide AA
R1810 VRS-CY1JF183J 18k 1/16W Metal Oxide AA
R1811 VRS-CY1JF333J 33k 1/16W Metal Oxide AA
R1812 VRS-CY1JF683J 68k 1/16W Metal Oxide AA
R1813 VRS-CY1JF472F 4.7k 1/16W Metal Oxide AA
R1814 VRS-CY1JF272F 2.7k 1/16W Metal Oxide AA
R1815 VRS-CY1JF105J 1M 1/16W Metal Oxide AA
R1817 VRS-CY1JF822J 8.2k 1/16W Metal Oxide AA
R1818 VRS-CY1JF562J 5.6k 1/16W Metal Oxide AA
R1820 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R1822 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R1823 VRS-CY1JF392J 3.9k 1/16W Metal Oxide AA
R1824 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R1825 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R1826 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R1827 VRS-CY1JF183J 18k 1/16W Metal Oxide AA
R1828 VRS-CY1JF222J 2.2k 1/16W Metal Oxide AA
R1829 VRS-CY1JF562J 5.6k 1/16W Metal Oxide AA
R1830 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R1831 VRS-CY1JF561J 560 1/16W Metal Oxide AA
R1832 VRS-CY1JF562J 5.6k 1/16W Metal Oxide AA
R1833 VRS-CY1JF334J 330k 1/16W Metal Oxide AA
R1834 VRS-CY1JF334J 330k 1/16W Metal Oxide AA
R1835 VRS-CY1JF822J 8.2k 1/16W Metal Oxide AA
R1838 VRS-CY1JF223J 22k 1/16W Metal Oxide AA
R1839 VRS-CY1JF223J 22k 1/16W Metal Oxide AA
R1843 VRS-CY1JF474J 470k 1/16W Metal Oxide AA
R1844 VRS-CY1JF685J 6.8M 1/16W Metal Oxide AA
R1846 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R1847 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R1848 VRS-CY1JF273J 27k 1/16W Metal Oxide AA
R1850 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R1851 VRS-CY1JF153J 15k 1/16W Metal Oxide AA
R1854 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R1856 VRS-CY1JF224J 220k 1/16W Metal Oxide AA
R1858 VRS-CY1JF683J 68k 1/16W Metal Oxide AA
R1859 VRS-CY1JF393J 39k 1/16W Metal Oxide AA
R1860 VRS-CY1JF223J 22k 1/16W Metal Oxide AA
R1863 VRS-CY1JF152J 1.5k 1/16W Metal Oxide AA
R1864 VRS-CY1JF152J 1.5k 1/16W Metal Oxide AA
R1865 VRS-CY1JF152J 1.5k 1/16W Metal Oxide AA
R1868 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R1871 VRS-CY1JF153J 15k 1/16W Metal Oxide AA
R1873 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R1900 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R1901 VRS-CY1JF474F 470k 1/16W Metal Oxide AA
R1902 VRS-CY1JF134F 130k 1/16W Metal Oxide AA
R1903 VRS-CY1JF331J 330 1/16W Metal Oxide AA
R1904 VRS-CY1JF474J 470k 1/16W Metal Oxide AA
R1905 VRS-CY1JF223F 22k 1/16W Metal Oxide AA
R1906 VRS-CY1JF222J 2.2k 1/16W Metal Oxide AA
R1907 VRS-CY1JF104F 100k 1/16W Metal Oxide AA
R2011 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R2012 VRS-CY1JF222J 2.2k 1/16W Metal Oxide AA
R2104 VRS-CY1JF750J 75 1/16W Metal Oxide AA
R2105 VRS-CY1JF750J 75 1/16W Metal Oxide AA
R2106 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R2107 VRS-CY1JF391J 390 1/16W Metal Oxide AA
R2111 VRS-CY1JF221J 220 1/16W Metal Oxide AA
R2113 VRS-CY1JF221J 220 1/16W Metal Oxide AA
R2201 VRS-CY1JF332J 3.3k 1/16W Metal Oxide AA
R2202 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R2203 VRS-CY1JF222J 2.2k 1/16W Metal Oxide AA
R2204 VRS-CY1JF682J 6.8k 1/16W Metal Oxide AA
R2205 VRS-CY1JF562J 5.6k 1/16W Metal Oxide AA
R2208 VRS-CY1JF181J 180 1/16W Metal Oxide AA
R2209 VRS-CY1JF750J 75 1/16W Metal Oxide AA
R2210 VRS-CY1JF561J 560 1/16W Metal Oxide AA
R2301 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R3100 VRS-CY1JF223J 22k 1/16W Metal Oxide AA
R3112 VRS-CY1JF821J 820 1/16W Metal Oxide AA

Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
81
DV-L70U
15-7
R3113 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R3114 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R3115 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R3116 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R3117 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R3118 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R3119 VRS-CY1JF223J 22k 1/16W Metal Oxide AA
R3121 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R3122 VRS-CY1JF332J 3.3k 1/16W Metal Oxide AA
R3123 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R3124 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R3125 VRS-CY1JF182J 1.8k 1/16W Metal Oxide AA
R3126 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R3128 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R3129 VRS-CY1JF223J 22k 1/16W Metal Oxide AA
R3130 VRS-CY1JF223J 22k 1/16W Metal Oxide AA
R3131 VRS-CY1JF223J 22k 1/16W Metal Oxide AA
R3132 VRS-CY1JF223J 22k 1/16W Metal Oxide AA
R3133 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R3137 VRS-CY1JF223J 22k 1/16W Metal Oxide AA
R3138 VRS-CY1JF105J 1M 1/16W Metal Oxide AA
R3139 VRS-CY1JF272J 2.7k 1/16W Metal Oxide AA
R3140 VRS-CY1JF272J 2.7k 1/16W Metal Oxide AA
R3141 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R3142 VRS-CY1JF105J 1M 1/16W Metal Oxide AA
R3145 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R3146 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R3149 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R3150 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R3151 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R3152 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R3153 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R3154 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R3155 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R3156 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R3157 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R3158 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R3159 VRS-CY1JF223J 22k 1/16W Metal Oxide AA
R3160 VRS-CY1JF223J 22k 1/16W Metal Oxide AA
R3161 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R3162 VRS-CY1JF223J 22k 1/16W Metal Oxide AA
R3163 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R3164 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R3165 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R3166 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R3167 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R3168 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R3170 VRS-CY1JF153J 15k 1/16W Metal Oxide AA
R3171 VRS-CY1JF223J 22k 1/16W Metal Oxide AA
R3172 VRS-CY1JF223J 22k 1/16W Metal Oxide AA
R3173 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R3181 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R3182 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R3183 VRS-CY1JF154J 150k 1/16W Metal Oxide AA
R3185 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R3186 VRS-CY1JF683J 68k 1/16W Metal Oxide AA
R3187 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R3190 VRS-CY1JF223J 22k 1/16W Metal Oxide AA
R3192 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R3194 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R3195 VRS-CY1JF223J 22k 1/16W Metal Oxide AA
R3196 VRS-CY1JF223J 22k 1/16W Metal Oxide AA
R3197 VRS-CY1JF101J 100k 1/16W Metal Oxide AA
R3198 VRS-CY1JF223J 22k 1/16W Metal Oxide AA
R3203 VRS-TV1JD000J 0 1/16W Metal Oxide AA
R3204 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R3207 VRS-CY1JF473J 47k 1/16W Metal Oxide AA
R3208 VRS-CY1JF473J 47k 1/16W Metal Oxide AA
R3209 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R3217 VRS-CY1JF243F 24k 1/16W Metal Oxide AA
R3218 VRS-CY1JF153F 15k 1/16W Metal Oxide AA
R3219 VRS-CY1JF104J 100k 1/16W Metal Oxide AA
DUNTK5869KE52
MAIN PWB UNIT(Continued) R3220 VRS-CY1JF473J 47k 1/16W Metal Oxide AA
R3221 VRS-CY1JF473J 47k 1/16W Metal Oxide AA
R3222 VRS-CY1JF561J 560 1/16W Metal Oxide AA
R3223 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R3231 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R3232 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R3233 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R3234 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R3235 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R3236 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R3301 VRS-CY1JF750J 75 1/16W Metal Oxide AA
R3601 VRS-TW2ED1R5J 1.5 1/4W Metal Oxide AB
R3602 VRS-CY1JF151J 150 1/16W Metal Oxide AA
R3603 VRS-CY1JF221J 220 1/16W Metal Oxide AA
R3604 VRS-CY1JF154J 150k 1/16W Metal Oxide AA
R3605 VRS-CY1JF433J 43k 1/16W Metal Oxide AA
R3606 VRS-TW2ED1R5J 1.5 1/4W Metal Oxide AB
R6000 VRS-CY1JF183J 18k 1/16W Metal Oxide AA
R6001 VRS-CY1JF183J 18k 1/16W Metal Oxide AA
R6002 VRS-CY1JF474J 470k 1/16W Metal Oxide AA
R6003 VRS-CY1JF474J 470k 1/16W Metal Oxide AA
R6004 VRS-CY1JF183J 18k 1/16W Metal Oxide AA
R6005 VRS-CY1JF183J 18k 1/16W Metal Oxide AA
R6006 VRS-CY1JF821J 820 1/16W Metal Oxide AA
R6007 VRS-CY1JF821J 820 1/16W Metal Oxide AA
R6008 VRS-CY1JF473J 47k 1/16W Metal Oxide AA
R6009 VRS-CY1JF473J 47k 1/16W Metal Oxide AA
R6012 VRS-CY1JF272J 2.7k 1/16W Metal Oxide AA
R6013 VRS-CY1JF272J 2.7k 1/16W Metal Oxide AA
R6015 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R6016 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R6051 VRS-CY1JF182J 1.8k 1/16W Metal Oxide AA
R6052 VRS-CY1JF104J 100k 1/16W Metal Oxide AA
R6053 VRS-CY1JF152J 1.5k 1/16W Metal Oxide AA
R6054 VRS-CY1JF222J 2.2k 1/16W Metal Oxide AA
R6055 VRS-CY1JF182J 1.8k 1/16W Metal Oxide AA
R6056 VRS-CY1JF104J 100k 1/16W Metal Oxide AA
R6057 VRS-CY1JF152J 1.5k 1/16W Metal Oxide AA
R6058 VRS-CY1JF222J 2.2k 1/16W Metal Oxide AA
R6060 VRS-CY1JF151J 150 1/16W Metal Oxide AA
R6061 VRS-CY1JF151J 150 1/16W Metal Oxide AA
R6062 VRS-CY1JF562J 5.6k 1/16W Metal Oxide AA
R6063 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R6064 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R6066 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R6070 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R6071 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R6090 VRS-CY1JF104J 100k 1/16W Metal Oxide AA
R6091 VRS-CY1JF104J 100k 1/16W Metal Oxide AA
R6210 VRS-CY1JF104J 100k 1/16W Metal Oxide AA
R6212 VRS-CY1JF104J 100k 1/16W Metal Oxide AA
R6213 VRS-CY1JF104J 100k 1/16W Metal Oxide AA
R6214 VRS-CY1JF104J 100k 1/16W Metal Oxide AA
R6617 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R6621 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R6022 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R6023 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R6660 VRS-CY1JF151J 150 1/16W Metal Oxide AA
R6661 VRS-CY1JF151J 150 1/16W Metal Oxide AA
R6662 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R6663 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R6664 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R6665 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R6683 VRS-CY1JF822J 8.2k 1/16W Metal Oxide AA
R6684 VRS-CY1JF822J 8.2k 1/16W Metal Oxide AA
R6685 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R6686 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R6687 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R6688 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R6689 VRS-CY1JF104J 100k 1/16W Metal Oxide AA
R6691 VRS-CY1JF122J 1.2k 1/16W Metal Oxide AA
R6692 VRS-CY1JF222J 2.2k 1/16W Metal Oxide AA
R6694 VRS-CY1JF474J 470k 1/16W Metal Oxide AA
R6695 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R7001 VRS-CY1JF103J 10k 1/16W Metal Oxide AA

Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
82
DV-L70U
DUNTK5869KE52
MAIN PWB UNIT(Continued)
R7007 VRS-CY1JF471J 470 1/16W Metal Oxide AA
R7019 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R7020 VRS-CY1JF473J 47k 1/16W Metal Oxide AA
R7021 VRS-CY1JF682J 6.8k 1/16W Metal Oxide AA
R7022 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R7023 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R7024 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R7026 VRS-CY1JF223J 22k 1/16W Metal Oxide AA
R7042 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R7050 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R7754 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R9193 VRS-CY1JF223J 22k 1/16W Metal Oxide AA
CONTROL
R6010 RVR-A4015GEZZ Variable Resistor AF
MISCELLANEOUS PARTS
CN301 QSOCN3087TAZZ Socket, 30Pin AF
CN302 QPLGN0276TAZZ Plug, 2Pin AD
CN702 QSOCN1372TAZZ Socket, 13Pin AD
CN802 QSOCN1436TAZZ Socket, 14Pin AE
CN1801 QPLGN1476TAZZ Plug, 14Pin AG
CN1802 QPLGN1476TAZZ Plug, 14Pin AG
CN5000 QSOCN1286TAZZ Socket, 12Pin AD
FB101 RBLN-0055TAZZ Balun, BLN-0055TA AB
FB102 RBLN-0055TAZZ Balun, BLN-0055TA AB
FB103 RBLN-0055TAZZ Balun, BLN-0055TA AB
FB114 RBLN-0052TAZZ Balun, BLN-0052TA AC
FB201 RBLN-0052TAZZ Balun, BLN-0052TA AC
FB302 RBLN-0052TAZZ Balun, BLN-0052TA AC
FB401 RBLN-0052TAZZ Balun, BLN-0052TA AC
FB402 RBLN-0052TAZZ Balun, BLN-0052TA AC
FB404 RBLN-0052TAZZ Balun, BLN-0052TA AC
FB551 RBLN-0052TAZZ Balun, BLN-0052TA AC
FB601 RBLN-0052TAZZ Balun, BLN-0052TA AC
FB603 RBLN-0052TAZZ Balun, BLN-0052TA AC
FB701 RBLN-0052TAZZ Balun, BLN-0052TA AC
FB702 RBLN-0052TAZZ Balun, BLN-0052TA AC
FB802 RBLN-0052TAZZ Balun, BLN-0052TA AC
FB804 RBLN-0056TAZZ Balun, BLN-0056TA AC
FB815 RBLN-0056TAZZ Balun, BLN-0056TA AC
FB816 RBLN-0056TAZZ Balun, BLN-0056TA AC
FB3100 RBLN-0052TAZZ Balun, BLN-0052TA AC
FB3101 RBLN-0052TAZZ Balun, BLN-0052TA AC
FB3201 RBLN-0052TAZZ Balun, BLN-0052TA AC
FB3202 RBLN-0052TAZZ Balun, BLN-0052TA AC
FB3206 RBLN-0056TAZZ Balun, BLN-0056TA AC
FB3207 RBLN-0056TAZZ Balun, BLN-0056TA AC
FB3208 RBLN-0056TAZZ Balun, BLN-0056TA AC
FB3209 RBLN-0056TAZZ Balun, BLN-0056TA AC
FB3210 RBLN-0056TAZZ Balun, BLN-0056TA AC
FB3211 RBLN-0056TAZZ Balun, BLN-0056TA AC
FB3212 RBLN-0056TAZZ Balun, BLN-0056TA AC
FB6001 RBLN-0056TAZZ Balun, BLN-0056TA AC
FB6002 RBLN-0056TAZZ Balun, BLN-0056TA AC
J6000 VHPGP1F562T-1 PhotoDiode AQ
J6001 QJAKE0263GEZZ Jack AE
J6002 QJAKE0062TAZZ Jack AF
S501 QSW-M0024TAZZ Switch, LCD AE
S502 QSW-M0024TAZZ Switch, LD AE
S1001 QSW-M0024TAZZ Switch, Tray AE
W3361 RRMCU0012TAZZ Remote Receiver AL
DUNTK5870KE52
LCD PWB UNIT
INTEGRATED CIRCUITS
IC1000 VHiMB3800PV-1 MB3800PV AL
IC1101 VHiLZ9GJ18/-1 LZ9GJ18 AQ
15-8
IC1102 VHiNJM2107F-1 NJM2107F AE
IC1103 VHiNJM4560M-1 NJM4560M AG
TRANSISTORS
Q1100 VS2SD999LK/-1 2SD999LK AC
Q1101 VS2SC4738Y/-1 2SC4738Y AA
Q1102 VS2SC2411KR-1 2SC2411KR AC
Q1103 VS2SA1036KR-1 2SA1036KR AC
DIODES
D1103 VHDMA132K//-1 MA132K AA
D1104 VHDMA716///-1 DMA716 AC
D1105 VHDHVU200A/-1 HVU200A AC
D1106 RH-EX0852CEZZ Zener, EX0852CE AC
D1107 RH-EX0852CEZZ Zener, EX0852CE AC
D1108 VHDMA132K//-1 MA132K AA
D1109 VHDMA132K//-1 MA132K AA
D1110 VHDMA132K//-1 MA132K AA
COILS AND TRANSFORMER
L1101 VPAWM2R7J1R2N Peaking, 2.7µHAC
L1102 VPAWM2R7J1R2N Peaking, 2.7µHAC
L1103 VPAWM4R7J1R7N Peaking, 4.7µHAC
L1104 VPAWM470J6R4N Peaking, 47µHAC
L1105 VPAWM470J6R4N Peaking, 47µHAC
L1106 VPAWM470J6R4N Peaking, 47µHAC
L1107 VPAWM470J6R4N Peaking, 47µHAC
L1108 VPAWM150J3R2N Peaking, 15µHAC
L1109 VPAWM2R7J1R2N Peaking, 2.7µHAC
L1110 VPAWM4R7J1R7N Peaking, 4.7µHAC
åT1100 RTRNZ0127GEZZ Transformer AF
CONTROLS
R1102 RVR-M7951TAZZ Variable Resistor AC
R1103 RVR-M7959TAZZ Variable Resistor AC
R1104 RVR-M7949TAZZ Variable Resistor AC
CAPACITORS
C1100 VCCCCY1HH101J 100p 50V Ceramic AA
C1101 VCSATE1AJ476M 47 10V Tantalum AD
C1102 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1103 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1104 VCKYCY1CB104K 0.1 16V Ceramic AB
C1105 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1107 VCKYCY1HB103K 0.01 50V Ceramic AA
C1108 VCKYCY1HB103K 0.01 50V Ceramic AA
C1111 VCKYCY1HB561K 560p 50V Ceramic AA
C1112 VCKYCY1HB561K 560p 50V Ceramic AA
C1114 VCSATA1AJ106M 10 10V Tantalum AC
C1115 VCSATA1AJ106M 10 10V Tantalum AC
C1116 VCKYCY1CF224Z 0.22 16V Ceramic AA
C1117 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1118 VCKYCY1HB102K 1000p 50V Ceramic AA
C1119 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1120 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1121 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1122 VCCCCY1HH820J 82p 50V Ceramic AA
C1123 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1124 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1125 VCKYCY1CF224Z 0.22 16V Ceramic AA
C1126 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1127 RC-KZ0052TAZZ 4.7 16V AC
C1128 RC-KZ0046TAZZ 4.7 35V AD
C1129 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1130 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1131 VCCCCY1HH330J 33p 50V Ceramic AA
C1132 RC-KZ0052TAZZ 4.7 16V AC
C1133 RC-KZ0052TAZZ 4.7 16V AC
C1134 RC-KZ0052TAZZ 4.7 16V AC
C1135 RC-KZ0046TAZZ 4.7 35V AD
C1136 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1137 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1138 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1139 VCKYCY1CF104Z 0.1 16V Ceramic AA

Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
83
DV-L70U
R1143 VRS-CY1JF391J 390 1/16W Metal Oxide AA
R1144 VRS-CY1JF562F 5.6k 1/16W Metal Oxide AA
R1145 VRS-CY1JF473J 47k 1/16W Metal Oxide AA
R1146 VRS-CY1JF392J 3.9k 1/16W Metal Oxide AA
R1147 VRS-CY1JF683J 68k 1/16W Metal Oxide AA
R1148 VRS-CY1JF273J 27k 1/16W Metal Oxide AA
R1149 VRS-CY1JF564J 560k 1/16W Metal Oxide AA
R1150 VRS-CY1JF564J 560k 1/16W Metal Oxide AA
R1151 VRS-CY1JF683J 68k 1/16W Metal Oxide AA
R1152 VRS-CY1JF105J 1M 1/16W Metal Oxide AA
R1154 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R1155 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R1159 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R1161 VRS-CY1JF222J 2.2k 1/16W Metal Oxide AA
R1163 VRS-CY1JF272J 2.7k 1/16W Metal Oxide AA
R1164 VRS-CY1JF332J 3.3k 1/16W Metal Oxide AA
R1166 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R1167 VRS-CY1JF331J 330 1/16W Metal Oxide AA
R1169 VRS-CY1JF100J 10 1/16W Metal Oxide AA
R1170 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R1171 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R1173 VRS-TQ2BD100J 10 1/8W Metal Oxide AA
R1174 VRS-CY1JF221F 220 1/16W Metal Oxide AA
R1175 VRS-CY1JF221F 220 1/16W Metal Oxide AA
R1176 VRS-TW2ED220J 22 1/4W Metal Oxide AB
R1178 VRS-CY1JF221F 220 1/16W Metal Oxide AA
R1179 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R1181 VRS-CY1JF100J 10 1/16W Metal Oxide AA
R1182 VRS-CY1JF273J 27k 1/16W Metal Oxide AA
R1183 VRS-CY1JF333J 33k 1/16W Metal Oxide AA
R1187 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R1188 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R1189 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R1190 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R1191 VRS-CY1JF561J 560 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
CN1100 QPLGN1476TAZZ Plug, 14Pin AG
CN1101 QPLGN1476TAZZ Plug, 14Pin AG
CN1102 QPLGN0263TAZZ Plug, 2Pin AB
CN1103 QPLGN0263TAZZ Plug, 2Pin AB
CN1104 QSOCN3272TAZZ Socket, 32Pin AF
CN1105 QSOCN0686TAZZ Socket, 6Pin AC
FB1101 RBLN-0055TAZZ Balun, BLN-0055TA AB
FB1102 RBLN-0055TAZZ Balun, BLN-0055TA AB
FB1121 RBLN-0052TAZZ Balun, BLN-0052TA AC
FB1122 RBLN-0052TAZZ Balun, BLN-0052TA AC
FB1123 RBLN-0052TAZZ Balun, BLN-0052TA AC
FB1124 RBLN-0052TAZZ Balun, BLN-0052TA AC
DUNTK5755XJ6B
OPERATE PWB UNIT
DIODES
D5001 VHDDA221///-1 DA221 AB
D5002 VHDDA221///-1 DA221 AB
D5003 VHDDA221///-1 DA221 AB
D5004 VHDDA221///-1 DA221 AB
RESISTORS
R5010 VRS-CY1JF122J 1.2k 1/16W Metal Oxide AA
R5011 VRS-CY1JF821J 820 1/16W Metal Oxide AA
R5012 VRS-CY1JF681J 680 1/16W Metal Oxide AA
R5013 VRS-CY1JF471J 470 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
CN5001 QSOCN1286TAZZ Socket, 12Pin AD
S5001 QSW-K0096TAZZ Switch, LCD Size AC
S5002 QSW-K0096TAZZ Switch, LCD Light AC
S5003 QSW-K0096TAZZ Switch, DVD/TV AC
S5004 QSW-K0096TAZZ Switch, Retarn AC
S5005 QSW-K0096TAZZ Switch, Enter AC
DUNTK5870KE52
LCD PWB UNIT(Continued)
C1140 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1141 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1142 VCKYCY1AF105Z 1 10V Ceramic AC
C1143 VCCCCY1HH330J 33p 50V Ceramic AA
C1144 VCCCCY1HH330J 33p 50V Ceramic AA
C1145 VCKYCY1HB102K 1000p 50V Ceramic AA
C1146 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1147 VCKYCY1HB561K 560p 50V Ceramic AA
C1148 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1149 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1150 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1151 VCCCCY1HH101J 100p 50V Ceramic AA
C1152 VCKYCY1HB102K 1000p 50V Ceramic AA
C1153 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1154 VCKYCY1AF105Z 1 10V Ceramic AC
C1155 VCCCCY1HH221J 220p 50V Ceramic AA
C1156 VCCCCY1HH271J 270p 50V Ceramic AA
C1157 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1158 VCKYCY1EF104Z 0.1 25V Ceramic AA
C1159 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1160 VCKYCY1EF104Z 0.1 25V Ceramic AA
C1161 VCKYCY1CF474Z 0.47 16V Ceramic AB
C1162 VCKYCY1EF104Z 0.1 25V Ceramic AA
C1163 RC-KZ0084TAZZ 1 25V AC
C1164 RC-KZ0084TAZZ 1 25V AC
C1165 VCCCCY1HH330J 33p 50V Ceramic AA
C1166 VCKYCY1AF105Z 1 10V Ceramic AC
C1167 VCKYCY1AF105Z 1 10V Ceramic AC
C1169 VCSATA1EJ105M 1 25V Tantalum AC
C1170 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1171 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1174 VCCCCY1HH101J 100p 50V Ceramic AA
C1175 VCCCCY1HH101J 100p 50V Ceramic AA
C1176 VCCCCY1HH101J 100p 50V Ceramic AA
C1177 VCCCCY1HH101J 100p 50V Ceramic AA
C1178 VCCCCY1HH101J 100p 50V Ceramic AA
C1179 VCCCCY1HH101J 100p 50V Ceramic AA
C1180 VCCCCY1HH101J 100p 50V Ceramic AA
C1181 VCSATE1AJ476M 47 10V Tantalum AD
C1182 VCCCCY1HH101J 100p 50V Ceramic AA
C1183 VCCCCY1HH101J 100p 50V Ceramic AA
C1184 VCCCCY1HH101J 100p 50V Ceramic AA
C1185 VCCCCY1HH101J 100p 50V Ceramic AA
C1186 VCKYCY1CF334Z 0.33 16V Ceramic AA
C1187 VCKYCY1CF334Z 0.33 16V Ceramic AA
C1188 VCKYCY1CB104K 0.1 16V Ceramic AB
C1189 VCCCCY1HH100D 10p 50V Ceramic AA
C1191 VCSATE1AJ476M 47 10V Tantalum AD
C1192 VCSATE1CJ226M 22 16V Tantalum AE
RESISTORS
R1100 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R1101 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R1111 VRS-CY1JF561J 560 1/16W Metal Oxide AA
R1112 VRS-CY1JF561J 560 1/16W Metal Oxide AA
R1113 VRS-CY1JF561J 560 1/16W Metal Oxide AA
R1114 VRS-CY1JF561J 560 1/16W Metal Oxide AA
R1115 VRS-CY1JF561J 560 1/16W Metal Oxide AA
R1116 VRS-CY1JF561J 560 1/16W Metal Oxide AA
R1117 VRS-CY1JF273J 27k 1/16W Metal Oxide AA
R1118 VRS-CY1JF222J 2.2k 1/16W Metal Oxide AA
R1119 VRS-CY1JF561J 560 1/16W Metal Oxide AA
R1120 VRS-CY1JF561J 560 1/16W Metal Oxide AA
R1121 VRS-CY1JF222J 2.2k 1/16W Metal Oxide AA
R1122 VRS-CY1JF561J 560 1/16W Metal Oxide AA
R1123 VRS-CY1JF561J 560 1/16W Metal Oxide AA
R1124 VRS-CY1JF561J 560 1/16W Metal Oxide AA
R1125 VRS-CY1JF561J 560 1/16W Metal Oxide AA
R1126 VRS-CY1JF681J 680 1/16W Metal Oxide AA
R1127 VRS-CY1JFXXXF
R1135 VRS-CY1JF224J 220k 1/16W Metal Oxide AA
R1142 VRS-CY1JF105J 1M 1/16W Metal Oxide AA
15-9

Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
84
DV-L70U
15-10
CABINET PARTS
1 CCABA1113GE01 Cabinet A Ass'y BA
(Main Unit, Upper)
1-4 HDECQ2105GESA Disc Decoration Panel AN
1-5 TLABS0421GEZZ Laser Caution Label AD
2 JBTN-2989GESA Key Tree AP
3 CPNLC2696GE01 Operation Panel Ass'y AR
4 JBTN-2990GESA Open Button AE
5 MSPRD0198GEZZ Lock Release SPR AC
6 CCABB1222GE01 Cabinet B Ass'y AY
(Main Unit, Lower)
6-2 PZETK0012GEZZ Main PWB Isolating Sheet AL
6-3 GLEGM9055CESC Stand AF
6-4 LHLDZ1718CEZZ Stand Holder AC
6-5 LX-HZ3090CEFF M1.7-4B Tight Screw AA
6-6 PGUMM0059GEZZ Stopper Rubber AB
7 CFTAT1031GE02 Disc Cover Ass'y AY
7-2 HDECP0263GESA Decoration Plate AM
7-3 HDECP0262GESA Disc Window AD
7-4 HBDGS3017GESA DVD Badge AG
7-5 PGiDM0183GEZZ Ratchet Housing AE
7-6 LSTPP0012GEZZ Ratchet Stopper AE
7-7 MSPRC0227GEZZ Ratchet SPR AB
8 MSPRC0245GEZZ Spring
11 CCABC1002GE01 Cabinet C Ass'y(LCD, Rear) AX
11-2 HBDGB3032GESE SHARP Logo Badge AF
12 CCABD1002GE01 Cabinet D Ass'y(LCD Panel) AX
12-2 PCOVP0102GEZZ Speaker Cover R AC
12-3 PCOVP0103GEZZ Speaker Cover L AC
12-4 PSPAH0102GEZZ Speaker Spacer R AD
12-5 PSPAH0103GEZZ Speaker Spacer L AD
12-6 LX-HZ3094CEFD Collar B Tight Screw AA
12-7 PCOVP0106GEZZ Speaker Cover M
13 JBTN-2994GESA LCD Lock Button AE
14 MHNG-3021GEZZ Hinge L AN
16 JBTN-2993GESA Power SW Knob AE
17 PCAPH0102GEZZ LCD Rubber Cap AB
20 XiPSF20P04000 Screw(M2 X 4) AA
21 XiPSN20P08000 Screw(M2 X 6) AA
22 XiPSN20P06000 Screw(M2 X 8) AA
23 LX-HZ0018TAFN P Tight Screw(M2 X 6) AA
24 LX-HZ0030TAFF B Tight Screw(M2 X 4) AA
25 RDENC0579GEZZ Power Unit BD
26 DUNTK5869KE52 Main PWB Unit —
27 DUNTK5870KE52 LCD PWB Unit —
28 RiNV-0003GEZZ Inverter Unit BB
29 DUNTK5755XJ6B Operate PWB Unit —
30 QCNW-8100GEZZ Power FFC AE
31 QCNW-8099GEZZ Operation FFC AF
33 CCNW-8096GE01 LCD-MAIN Harness AQ
33-1 QCNW-8096GEZZ Connecting Cord AK
33-2 QCNW-8098GEZZ Connecting Cord AK
33-3 MHNG-1071GEZZ Hinge R AG
34 QCNW-8161GEZZ Harness for LCD Frame AC
Earth
35 QCNW-8097GEZZ Spindle Motor FFC AE
36 QCNW-8117GEZZ Inverter FFC AF
37 RSP-Z0005GEZZ Speaker AP
38 RLCDT0001GEZZ LCD Panel CS
39 XWHJZ21-02040 Washer AA
40 XWHSD32-05080 Speaker Washer AA
DUNTK5755XJ6B
OPERATE PWB UNIT(Continued)
S5006 QSW-K0096TAZZ Switch, Left AC
S5007 QSW-K0096TAZZ Switch, Play AC
S5008 QSW-K0096TAZZ Switch, Right AC
S5009 QSW-K0096TAZZ Switch, Stop AC
S5010 QSW-K0096TAZZ Switch, Down AC
S5011 QSW-K0096TAZZ Switch, Still/Pause AC
S5012 QSW-K0096TAZZ Switch, Up AC
S5013 QSW-K0096TAZZ Switch, Skip/Forward AC
S5014 QSW-K0096TAZZ Switch, Top Menu AC
S5015 QSW-K0096TAZZ Switch, Skip Back AC
S5016 QSW-K0096TAZZ Switch, Menu AC
SUPPLIED ACCESSORIES
åQACCD3062GEZZ AC PowerCord AQ
QCNW-8340GEZZ S-Video/Video Cord
QCNW-8341GEZZ Audio Cord
RRMCG1223GESA Remote Control Unit AW
TiNS-3698GEZZ Operation Manual AT
åUADP-0194GEZZ AC Adapter BK
UBATU0241GEZZ Battery AE
SSAKA0096CEZZ Polystylene Sack —
SSAKA0100TAZZ Polystylene Bag, —
Accessories
SPAKC4224GEZZ Packing Case —
SPAKF0195GEZZ Packing Material —
SPAKX1079GEZZ Packing Add. —
TGAN-3207GEZZ Guarantee Card —
PACKING PARTS
(NOT REPLACEMENT ITEM)
MECHANISM PARTS
1 DMECD0004GE01 Mechanism Ass'y —
2 NSFTD0063GEFW Main Guide AG
3 LHLDZ2070GEZZ Sled Unit AD
4 NGERH1328GEZZ Intermediate Gear AC
5 RMOTV1037GEZZ Sled Motor AN
6 MSPRP0199GEZZ Grip Spring AC
7 PCUSG0004GEZZ Insulator AC
8 PCOVP3021GEZZ PU Cover AF
9 LX-WZ1053GE00 Cut Washer AA
10 QCNW-8097GEZZ Spindle Motor FFC AE
11 XAPSF17P03000 Screw M1.7 X L3 AA
12 XAPSN17P06000 Screw M1.7 X L6 Ni PlatingAB
13 LX-BZ3220GEFF Screw M1.2 X L2.7 AB
14 NGERH1327GEZZ Main Guide Gear AC
15 NGERH1329GEZZ Motor Pinion AC
16 QCNW-8081GEZZ Sled Lead Wire AE
17 MSPRP1217GEZZ Earth Spring AD

Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
85
DV-L70U
MECHANISM EXPLODED VIEW
15-11
A
B
C
D
E
F
G
H
123456
7
7
5
3
13
4
9
12
14
2
15
15 5
16
17
*1
*2
*2
10
6
11
7
1
8
[Notes]
*1. When soldering the sled lead wire y,
it must be made in a soldering iron tip
temperature of 290±20˚C and within 3
seconds.
*2. Press-fit dimension of motor pinion t.
When replacement or a
djustment of the parts in
this frame is necessary,
replace or adjust the
mechanism ass'y
(adjustment of the parts
is completed).
5.8±0.1

Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
87
DV-L70U
16. PACKING OFTHE SET
16-1
★SPAKC4224GEZZ
(Packing Case)
★SPAKX1079GEZZ
(Packing Add.)
★TGAN-3207GEZZ
(Guarantee Card)
TiNS-3698GEZZ
(Operation Manual)
★SSAKA0100TAZZ
(Polystylene Bag, Accessories)
★SPAKF0195GEZZ
(Packing Meterial)
UBATU0241GEZZ
(Battery)
UADP-0194GEZZ
(AC Adapter)
QACCD3062GEZZ
(AC Power Cord)
QCNW-8340GEZZ
(S-Video/Video Cord)
QCNW-8341GEZZ
(Audio Cord)
RRMCG1223GESA
(Remote Control Unit)
★SSAKA0096CEZZ
(Polystylene Sack)
å
å
★Not Replacement Items

Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
88
DV-L70U
SHARP CORPORATION
AV Systems Group
Quality & Reliability Control Center
Yaita, Tochigi 329-2193, Japan
COPYRIGHT C 1999 BY SHARP CORPORATION
ALL RIGHTS RESERVED.
No part of this publication may be reproduced,
stored in a retrieval system, or transmitted in
any form or by any means, electronic, mechanical,
photocopying, recording, or otherwise, without
prior written permission of the publisher.
TQ0766-S
Dec. 1999 Printed in JAPAN
SA. NS
DV-L70U
