Sharp DV-L80S Application guide

Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
57
DV-L80S/W
IC1806 VHiNJM4560M-1 NJM4560M, Current AG
Detector Common Amp
IC2201 VHiTK15430V-1 TK15430V, 75Ohm Driver AN
IC3001 VHiTC7W14U/-1 TC7W14U AG
IC3201 VHiMB8346BV-1 MB8346BV AN
IC5100 VHiNJU7012F-1 NJU7012F AE
IC5501 VHiBR93L46F-1 BR93L46F, E2PROM AG
IC5502 RH-iX1750GEZZ IX1750GE, TV Micon AX
IC5503 VHiS875045B-1 S875045B, 5V REG AH
IC5504 VHiLPV358MM-1 LPV358MM AF
IC6604 VHiTC4053BF1E TC4053BF AF
IC6605 VHiTC4053BF1E TC4053BF AF
IC6606 VHiNJM4560M-1 NJM4560M, Audio Amp AG
IC6607 VHiNJM4560M-1 NJM4560M, Pre Amp AG
IC6608 VHiNJM4560M-1 NJM4560M, Audio Amp AG
IC6609 VHiNJM4560M-1 NJM4560M, Audio Amp AG
IC6610 VHiTPA0152+-1 TPA0152+, Power Amp AQ
IC6611 VHiPCM1604Y-1 PCM1604Y, Audio DAC AU
IC6612 VHiBA032LBS-1 BA032LBS, 3.2V REG AE
IC9001 VHiMB3785V/-1 MB3785V, Switching Control AQ
TRANSISTORS
Q201 VS2SA1576//-1 2SA1576 AB
Q202 VS2SA1576//-1 2SA1576 AB
Q301 VS2SA1576//-1 2SA1576 AB
Q302 VS2SA1298Y/-1 2SA1298Y AB
Q303 VS2SA1298Y/-1 2SA1298Y AB
Q304 VS2SA1298Y/-1 2SA1298Y AB
Q305 VSDTC144EE/-1 DTC144EE AA
Q501 VSDTA144EE/-1 DTA144EE AA
Q502 VSDTC144EE/-1 DTC144EE AA
Q503 VS2SA1298Y/-1 2SA1298Y AB
Q702 VS2SC4081//-1 2SC4081 AB
Q703 VS2SC4081//-1 2SC4081 AB
Q704 VS2SC4081//-1 2SC4081 AB
Q705 VS2SC4081//-1 2SC4081 AB
Q706 VS2SC4081//-1 2SC4081 AB
Q707 VS2SC4081//-1 2SC4081 AB
Q708 VSDTC114EE/-1 DTC114EE AB
Q1800 VS2SA1774F/-1 2SA1774F AA
Q1801 VSDTA114YE/-1 DTA114YE AB
Q1802 VS2SC4738Y/-1 2SC4738Y AA
Q1804 VSDTC144EE/-1 DTC144EE AA
Q1805 VS2SC2411KR-1 2SC2411KR AC
Q1806 VS2SA1036KR-1 2SA1036KR AC
Q1807 VS2SA1774F/-1 2SA1774F AA
Q2201 VSFMMT717//-1 FMMT717 AE
Q2202 VSDTC144EE/-1 DTC144EE AA
Q2216 VSDTA114EE/-1 DTA114EE AB
Q2217 VS2SD1306-E1E 2SD1306-E AD
Q2218 VSDTA114EE/-1 DTA114EE AB
Q2219 VSDTC144EE/-1 DTC144EE AA
Q2222 VSDTA114EE/-1 DTA114EE AB
Q2250 VSDTA114EE/-1 DTA114EE AB
Q2251 VSDTC144EE/-1 DTC144EE AA
Q5505 VS2SC4738Y/-1 2SC4738Y AA
Q5506 VS2SC4738Y/-1 2SC4738Y AA
Q5511 VSCPH3303//-1 CPH3303 AD
Q5513 VSDTC144EE/-1 DTC144EE AA
Q5514 VS3LN01S///-1 3LN01S AC
Q6601 VSDTA114EE/-1 DTA114EE AB
Q6602 VSDTA114EE/-1 DTA114EE AB
Q6603 VS2SC4213B/-1 2SC4213B AC
Q6604 VS2SC4213B/-1 2SC4213B AC
Q6605 VS2SC4213B/-1 2SC4213B AC
Q6606 VS2SC4213B/-1 2SC4213B AC
Q6607 VS2SC4213B/-1 2SC4213B AC
Q6608 VS2SC4213B/-1 2SC4213B AC
Q6609 VSDTA114EE/-1 DTA114EE AB
Q6610 VS2SC4213B/-1 2SC4213B AC
Q6611 VS2SC4213B/-1 2SC4213B AC
Q6612 VS2SC4213B/-1 2SC4213B AC
Q6613 VS2SC4213B/-1 2SC4213B AC
Q6614 VSDTA144EE/-1 DTA144EE AA
Q9001 VSCPH3109//-1 CPH3109 AD
12.REPLACEMENT PARTS LIST/
EXPLODEDVIEWS
ELECTRICAL PARTS LIST
Parts marked with " å " are important for maintaining the safety of the
set. Be sure to replace these parts with specified ones for maintaining
the safety and performance of the set.
" HOW TO ORDER REPLACEMENT PARTS "
★MARK : SPARE PARTS-DELIVERY SECTION : ALL JAPAN
To have your order filled promptly and correctly, please furnish
the following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
5. PRICE CODE
åMARK: SAFETY RELATED PARTS
PWB ASSEMBLY IS NOT REPLACEMENT ITEM
Ref. No. Part No. ★Description Code
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
DUNTK6002KE51 Main PWB Unit —
DUNTK5945KE50 Operate PWB Unit —
DUNTK6003KE51 LCD PWB Unit —
DUNTK5949KE51 Charge PWB Unit —
DUNTK5948KE51 Connector PWB Unit —
DUNTK6002KE51
MAIN PWB UNIT
INTEGRATED CIRCUITS
åCP9001 VHiCCP2E40/-1 CCP2E40, 1.6A AD
åCP9002 VHiCCP2E40/-1 CCP2E40, 1.6A AD
åCP9003 VHiCCP2E50/-1 CCP2E50, 2A AD
IC201 RH-iX1709GEZZ IX1709GE, AY
Gamma S-P Tone
IC202 VHiMC44722A-1 MC44722A, Video Encoder AX
IC301 RH-iX1517GEZZ IX1517GE, RF Processor AX
IC305 VHiBA10393F-1 BA10393F, OP Amp AC
IC401 RH-iX1690GEN2 IX1690GE, BE
Front End Engine
IC402 RH-iX3350CEZZ IX3350CE, 16M EDO DRAM AX
IC501 RH-iX1747GEZZ IX1747GE, Flash Memory AY
IC502 RH-iX1687GEZZ IX1687GE, Micro Com. BD
IC503 RH-iX1694GEZZ IX1694GE, 4M EDO DRAM AU
IC504 RH-iX1430CEZZ IX1430CE, Inverter AF
IC505 VHiBR93L66F-1 BR93L66F, E2PROM AH
IC506 VHiTC4S66F/-1 TC4S66F AD
IC507 VHiSNT1G08C-1 SNT1G08C AD
IC508 VHiSNT1G08C-1 SNT1G08C AD
IC601 RH-iX1721GEZZ IX1721GE, AV Decoder BK
IC602 RH-iX3455CEZZ IX3455CE, 16M SDRAM AZ
IC603 RH-iX3455CEZZ IX3455CE, 16M SDRAM AZ
IC701 VHiNJM2904M-1 NJM2904M, OP Amp AE
IC702 VHiAN8473NA-1 AN8473NA, Spin Driver AM
IC705 VHiAN8738SB-1 AN8738SB AL
IC1800 VHiSNT1G08C-1 SNT1G08C AD
IC1801 VHiTHC221AF-1 THC221AF AG
IC1802 VHiBA7046F/-1 BA7046F AF
IC1804 VHiiR3Y29AM-1 IR3Y29AM, LCD Decoder AV
IC1805 VHiTC4S66F/-1 TC4S66F AD

Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
58
DV-L80S/W
L603 VP-NM100KR42N Peaking, 10µHAB
L701 VPAWM4R7J1R7N Peaking, 4.7µHAC
L702 VPAWM100J2R6N Peaking, 10µHAC
L1801 VPAWM330J4R4N Peaking, 33µHAC
L1802 VPAWM330J4R4N Peaking, 33µHAC
L1803 VPAWM100J2R6N Peaking, 10µHAC
L1806 VPAWM470J6R4N Peaking, 47µHAC
L1807 VPAWM2R7J1R2N Peaking, 2.7µHAC
L1808 VPAWM2R7J1R2N Peaking, 2.7µHAC
L2201 VPAWM2R2J1R1N Peaking, 2.2µHAC
L3204 VPAWM470J6R4N Peaking, 47µHAC
L5501 VPAWM470J6R4N Peaking, 47µHAC
L9005 RCiLP0160GEZZ Coil, CiLP0160GE AD
L9006 RCiLP0160GEZZ Coil, CiLP0160GE AD
L9007 RCiLP0160GEZZ Coil, CiLP0160GE AD
L9009 VPAWM470J6R4N Peaking, 47µHAC
L9010 VPAWM470J6R4N Peaking, 47µHAC
L9011 VPAWM470J6R4N Peaking, 47µHAC
L9012 VPAWM470J6R4N Peaking, 47µHAC
L9013 VPM6N100MR75N Peaking, 10µHAC
R9049 VPM6N100MR75N Peaking, 10µHAC
åT9001 RTRNZ0149GEZZ Transformer AH
CAPACITORS
C201 VCSATE1AJ476M 47 10V Tantalum AD
C202 VCKYCY1HB103K 0.01 50V Ceramic AA
C203 VCKYCY1HB103K 0.01 50V Ceramic AA
C204 VCKYCY1HB103K 0.01 50V Ceramic AA
C205 VCKYCY1HB103K 0.01 50V Ceramic AA
C206 VCKYCY1HB103K 0.01 50V Ceramic AA
C207 VCKYCY1HB103K 0.01 50V Ceramic AA
C208 VCSATE1AJ476M 47 10V Tantalum AD
C209 VCSATE1AJ476M 47 10V Tantalum AD
C210 VCKYCY1HB103K 0.01 50V Ceramic AA
C211 VCSATE1AJ476M 47 10V Tantalum AD
C212 VCKYCY1HB103K 0.01 50V Ceramic AA
C213 VCKYCY1HB103K 0.01 50V Ceramic AA
C214 VCKYCY1HB103K 0.01 50V Ceramic AA
C215 VCSATE1AJ476M 47 10V Tantalum AD
C216 VCKYCY1AF105Z 1 10V Ceramic AC
C217 VCKYCY1HB103K 0.01 50V Ceramic AA
C218 VCKYCY1HB103K 0.01 50V Ceramic AA
C219 VCSATE1AJ476M 47 10V Tantalum AD
C220 VCKYCY1HB103K 0.01 50V Ceramic AA
C221 VCSATE1AJ476M 47 10V Tantalum AD
C301 VCSATE1AJ476M 47 10V Tantalum AD
C302 VCSATE1AJ476M 47 10V Tantalum AD
C303 VCKYCY1HB103K 0.01 50V Ceramic AA
C304 VCKYCY1HB103K 0.01 50V Ceramic AA
C305 VCSATE1AJ476M 47 10V Tantalum AD
C306 VCKYCY1CB104K 0.1 16V Ceramic AB
C307 VCSATE1AJ476M 47 10V Tantalum AD
C308 VCKYCY1AF105Z 1 10V Ceramic AC
C309 VCKYCY1HB152K 1500p 50V Ceramic AA
C310 VCKYCY1AF105Z 1 10V Ceramic AC
C311 VCSATE1AJ476M 47 10V Tantalum AD
C312 VCKYCY1CB104K 0.1 16V Ceramic AB
C313 VCKYCY1AF105Z 1 10V Ceramic AC
C314 VCKYCY1CB104K 0.1 16V Ceramic AB
C315 VCKYCY1AF105Z 1 10V Ceramic AC
C316 VCKYCY1AF105Z 1 10V Ceramic AC
C317 VCKYCY1AF105Z 1 10V Ceramic AC
C318 VCKYCY1HB472K 4700p 50V Ceramic AA
C319 VCKYCY1HB472K 4700p 50V Ceramic AA
C320 VCKYCY1CB104K 0.1 16V Ceramic AB
C321 VCKYCY1CB104K 0.1 16V Ceramic AB
C322 VCKYCY1CB104K 0.1 16V Ceramic AB
C323 VCKYCY1AF105Z 1 10V Ceramic AC
C324 VCKYCY1CB104K 0.1 16V Ceramic AB
C325 VCSAPD0JJ225M 2.2 6.3V Tantalum AD
C326 VCSATE1AJ476M 47 10V Tantalum AD
C327 VCKYCY1CB104K 0.1 16V Ceramic AB
C328 VCKYCY1HB102K 1000p 50V Ceramic AA
C329 VCKYCY1HB102K 1000p 50V Ceramic AA
C330 VCKYCY1HB102K 1000p 50V Ceramic AA
Q9002 VS2SA2010//-1 2SA2010 AD
Q9003 VS2SA2010//-1 2SA2010 AD
Q9004 VS2SA2010//-1 2SA2010 AD
Q9901 VSFMMT717//-1 FMMT717 AE
Q9902 VSFMMT717//-1 FMMT717 AE
Q9903 VSFMMT717//-1 FMMT717 AE
Q9905 VSFMMT717//-1 FMMT717 AE
Q9907 VSFMMT717//-1 FMMT717 AE
Q9909 VSFMMT717//-1 FMMT717 AE
Q9913 VS2SA1774F/-1 2SA1774F AA
Q9914 VSDTC124EE/-1 DTC124EE AA
DIODES AND LED’S
D301 VHDDAP222//-1 DAP222 AA
D501 VHDMA132K//-1 MA132K AA
D502 VHDDAP222//-1 DAP222 AA
D503 VHDDA227///-1 DA227 AB
D505 VHDMA132K//-1 MA132K AA
D506 VHDMA132K//-1 MA132K AA
D508 VHDMA132K//-1 MA132K AA
D510 VHDMA132K//-1 MA132K AA
D511 VHDDA227///-1 DA227 AB
D702 VHDDA221///-1 DA221 AB
D1800 VHDDAN222//-1 DAN222 AA
D1801 VHDHVU17TRF-1 HVU17TRF AE
D1802 VHDDAP222//-1 DAP222 AA
D2201 VHDMA716///-1 MA716 AC
D2202 VHDMA716///-1 MA716 AC
D2203 VHDMA716///-1 MA716 AC
D2204 VHDDAP222//-1 DAP222 AA
D2205 VHDMA132K//-1 MA132K AA
D3602 VHDDA227///-1 DA227 AB
D5501 VHDDA227///-1 DA227 AB
D5502 VHDMA132K//-1 MA132K AA
D5503 VHDHVU17TRF-1 HVU17TRF AE
D5504 VHDDAN222//-1 DAN222 AA
D5505 RH-PX0421CEZZ PhotoDiode AD
D5509 VHDMA132K//-1 MA132K AA
D5510 VHDMA132K//-1 MA132K AA
D6601 VHDDA227///-1 DA227 AB
D6603 VHDiMN10///-1 IMN10 AB
D9001 VHDFS1J3///-1 FS1J3 AD
D9002 VHDFS1J3///-1 FS1J3 AD
D9003 VHDFS1J3///-1 FS1J3 AD
D9004 VHDMA4S159/-1 MA4S159 AC
D9005 VHDMA4S159/-1 MA4S159 AC
D9006 RH-EX1000GEZZ Zener, EX1000GE AD
D9007 RH-EX1004GEZZ Zener, EX1004GE AD
D9008 RH-EX0999GEZZ Zener, EX0999GE AD
D9902 VHDiMN10///-1 IMN10 AB
J6001 VHPGP1F562T-1 PhotoDiode AQ
TH5501 RH-HZ0025CEZZ Thermistor AC
PACKAGED CIRCUITS
X601 RCRSC0031GEZZ Crystal, CRSC0031GE AK
X1800 RCRSC0096TAZZ Crystal, CRSC0096TA AL
X5502 RCRSC0032TAZZ Crystal, CRSC0032TA AG
FILTERS
FL501 RFiLC0207GEZZ Filter, FiLC0207GE AD
X5501 RFiLC0208GEZZ Filter, FiLC0208GE AD
COILS AND TRANSFORMER
L201 VPAWM470J6R4N Peaking, 47µHAC
L202 VPAWM100J2R6N Peaking, 10µHAC
L301 VPAWM100J2R6N Peaking, 10µHAC
L302 VPAWM100J2R6N Peaking, 10µHAC
L303 VPAWM100J2R6N Peaking, 10µHAC
L406 VP-NM100KR42N Peaking, 10µHAB
L501 VPAWM470J6R4N Peaking, 47µHAC
L601 VP-NM100KR42N Peaking, 10µHAB
DUNTK6002KE51
MAIN PWB UNIT(Continued)

Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
59
DV-L80S/W
C630 VCKYCY1HB102K 1000p 50V Ceramic AA
C631 VCKYCY1CB104K 0.1 16V Ceramic AB
C632 VCSATD1AJ107M 100 10V Tantalum AF
C633 VCSATE0JJ686M 68 6.3V Tantalum AE
C634 VCKYCY1CB104K 0.1 16V Ceramic AB
C635 VCKYCY1CB104K 0.1 16V Ceramic AB
C636 VCKYCY1CB104K 0.1 16V Ceramic AB
C637 VCKYCY1CB104K 0.1 16V Ceramic AB
C638 VCKYCY1CB104K 0.1 16V Ceramic AB
C639 VCKYCY1CB104K 0.1 16V Ceramic AB
C640 VCSATE1AJ476M 47 10V Tantalum AD
C641 VCKYCY1CB104K 0.1 16V Ceramic AB
C642 VCSATE0JJ107M 100 6.3V Tantalum AE
C643 VCKYCY1CB104K 0.1 16V Ceramic AB
C644 VCCCCY1HH2R0C 2p 50V Ceramic AA
C646 VCSATD0JJ227M 220 6.3V Tantalum AH
C647 VCKYCY1CB104K 0.1 16V Ceramic AB
C648 VCSATE0JJ686M 68 6.3V Tantalum AE
C649 VCSATE0JJ686M 68 6.3V Tantalum AE
C650 VCSATE0JJ107M 100 6.3V Tantalum AE
C702 VCKYCY1CB104K 0.1 16V Ceramic AB
C703 VCKYCY1CB104K 0.1 16V Ceramic AB
C704 VCCCCY1HH101J 100p 50V Ceramic AA
C705 VCCCCY1HH101J 100p 50V Ceramic AA
C706 VCCCCY1HH101J 100p 50V Ceramic AA
C707 VCKYCY1CB104K 0.1 16V Ceramic AB
C708 VCKYCY1CB104K 0.1 16V Ceramic AB
C709 VCKYCY1CB104K 0.1 16V Ceramic AB
C710 VCKYCY1CB104K 0.1 16V Ceramic AB
C711 VCKYCY1CB104K 0.1 16V Ceramic AB
C713 VCKYCY1EB153K 0.015 25V Ceramic AA
C714 VCKYCY1EB153K 0.015 25V Ceramic AA
C715 VCKYCY1EB153K 0.015 25V Ceramic AA
C716 VCSATE1AJ476M 47 10V Tantalum AD
C717 VCKYCY1CB104K 0.1 16V Ceramic AB
C718 VCKYCY1CB104K 0.1 16V Ceramic AB
C719 VCSATE1AJ476M 47 10V Tantalum AD
C720 VCKYCY1CB104K 0.1 16V Ceramic AB
C721 VCKYCY1CB104K 0.1 16V Ceramic AB
C722 VCKYCY1HB561K 560p 50V Ceramic AA
C723 VCKYCY1HB561K 560p 50V Ceramic AA
C724 VCKYCY1HB561K 560p 50V Ceramic AA
C725 VCKYCY1HB102K 1000p 50V Ceramic AA
C726 VCSATE1AJ476M 47 10V Tantalum AD
C727 VCKYCY1HB332K 3300p 50V Ceramic AA
C728 VCKYCY1HB332K 3300p 50V Ceramic AA
C729 VCKYCY1HB182K 1800p 50V Ceramic AA
C730 VCSATE1AJ476M 47 10V Tantalum AD
C731 VCKYCY1CB104K 0.1 16V Ceramic AB
C732 VCSATE1AJ476M 47 10V Tantalum AD
C733 VCKYCY1CB104K 0.1 16V Ceramic AB
C734 VCCCCY1HH271J 270p 50V Ceramic AA
C735 VCKYCY1CB104K 0.1 16V Ceramic AB
C736 VCCCCY1HH181J 180p 50V Ceramic AA
C737 VCKYCY1HB102K 1000p 50V Ceramic AA
C738 VCKYCY1EB103K 0.01 25V Ceramic AA
C739 VCKYCY1HB102K 1000p 50V Ceramic AA
C740 VCKYCY1CB104K 0.1 16V Ceramic AB
C741 VCKYCY1HB102K 1000p 50V Ceramic AA
C742 VCKYCY1HB103K 0.01 50V Ceramic AA
C744 VCSATD1AJ107M 100 10V Tantalum AF
C745 VCKYCY1HB102K 1000p 50V Ceramic AA
C746 VCKYCY1CB104K 0.1 16V Ceramic AB
C761 VCKYCY1EB103K 0.01 25V Ceramic AA
C763 VCKYCY1HB103K 0.01 50V Ceramic AA
C764 VCSATE1AJ476M 47 10V Tantalum AD
C766 VCKYCY1CB104K 0.1 16V Ceramic AB
C767 VCKYCY1CB104K 0.1 16V Ceramic AB
C769 VCSATE1AJ476M 47 10V Tantalum AD
C770 VCSATA0JJ226M 22 6.3V Tantalum AD
C771 VCKYCY1HB103K 0.01 50V Ceramic AA
C772 VCSATE1AJ476M 47 10V Tantalum AD
C773 VCSATE1AJ476M 47 10V Tantalum AD
C1800 VCKYTV1CF105Z 1 16V Ceramic AB
C1801 VCKYCY1HB222K 2200p 50V Ceramic AA
C331 VCKYCY1HB102K 1000p 50V Ceramic AA
C342 VCKYCY1CB104K 0.1 16V Ceramic AB
C343 VCCCCY1EH821J 820p 25V Ceramic AB
C401 VCKYCY1CB104K 0.1 16V Ceramic AB
C402 VCKYCY1CB104K 0.1 16V Ceramic AB
C403 VCKYCY1CB104K 0.1 16V Ceramic AB
C404 VCKYCY1CB104K 0.1 16V Ceramic AB
C405 VCKYCY1CB104K 0.1 16V Ceramic AB
C406 VCSATE1AJ476M 47 10V Tantalum AD
C407 VCKYCY1CB104K 0.1 16V Ceramic AB
C408 VCKYCY1CB104K 0.1 16V Ceramic AB
C409 VCSATE1AJ476M 47 10V Tantalum AD
C410 VCKYCY1CB104K 0.1 16V Ceramic AB
C411 VCKYCY1CB104K 0.1 16V Ceramic AB
C412 VCKYCY1CB104K 0.1 16V Ceramic AB
C413 VCKYCY1CB104K 0.1 16V Ceramic AB
C414 VCKYCY1CB104K 0.1 16V Ceramic AB
C415 VCKYCY1CB104K 0.1 16V Ceramic AB
C416 VCKYCY1CB104K 0.1 16V Ceramic AB
C417 VCKYCY1CB104K 0.1 16V Ceramic AB
C501 VCKYCY1HB103K 0.01 50V Ceramic AA
C502 VCSATE0JJ476M 47 6.3V Tantalum AF
C503 VCKYCY1CB104K 0.1 16V Ceramic AB
C504 VCKYCY1HB103K 0.01 50V Ceramic AA
C505 VCKYCY1HB103K 0.01 50V Ceramic AA
C506 VCKYCY1HB103K 0.01 50V Ceramic AA
C507 VCKYCY1AF105Z 1 10V Ceramic AC
C508 VCKYCY1HB103K 0.01 50V Ceramic AA
C509 VCKYCY1HB103K 0.01 50V Ceramic AA
C510 VCKYCY1HB103K 0.01 50V Ceramic AA
C511 VCKYCY1HB103K 0.01 50V Ceramic AA
C512 VCKYCY1HB103K 0.01 50V Ceramic AA
C513 VCKYCY1HB472K 4700p 50V Ceramic AA
C514 VCSATE1AJ226M 22 10V Tantalum AD
C515 VCKYCY1HB103K 0.01 50V Ceramic AA
C516 VCKYCY1HB103K 0.01 50V Ceramic AA
C517 VCKYCY1HB103K 0.01 50V Ceramic AA
C518 VCKYCY1HB103K 0.01 50V Ceramic AA
C519 VCSATD1AJ107M 100 10V Tantalum AF
C520 VCKYCY1AF105Z 1 10V Ceramic AC
C521 VCKYCY1HB103K 0.01 50V Ceramic AA
C522 VCSATA1AJ106M 10 10V Tantalum AC
C523 VCKYCY1EB103K 0.01 25V Ceramic AA
C601 VCSATD0JJ227M 220 6.3V Tantalum AH
C602 VCKYCY1CB104K 0.1 16V Ceramic AB
C603 VCKYCY1CB104K 0.1 16V Ceramic AB
C604 VCKYCY1CB104K 0.1 16V Ceramic AB
C605 VCKYCY1CB104K 0.1 16V Ceramic AB
C606 VCKYCY1CB104K 0.1 16V Ceramic AB
C607 VCKYCY1CB104K 0.1 16V Ceramic AB
C608 VCKYCY1CB104K 0.1 16V Ceramic AB
C609 VCSATD0JJ227M 220 6.3V Tantalum AH
C610 VCSATE1AJ476M 47 10V Tantalum AD
C611 VCKYCY1CB104K 0.1 16V Ceramic AB
C612 VCKYCY1CB104K 0.1 16V Ceramic AB
C613 VCKYCY1CB104K 0.1 16V Ceramic AB
C614 VCKYCY1CB104K 0.1 16V Ceramic AB
C615 VCKYCY1CB104K 0.1 16V Ceramic AB
C616 VCKYCY1CB104K 0.1 16V Ceramic AB
C617 VCKYCY1CB104K 0.1 16V Ceramic AB
C618 VCKYCY1CB104K 0.1 16V Ceramic AB
C619 VCKYCY1CB104K 0.1 16V Ceramic AB
C620 VCSATE1AJ476M 47 10V Tantalum AD
C621 VCKYCY1CB104K 0.1 16V Ceramic AB
C622 VCKYCY1CB104K 0.1 16V Ceramic AB
C623 VCSATE1AJ476M 47 10V Tantalum AD
C624 VCKYCY1CB104K 0.1 16V Ceramic AB
C625 VCKYCY1CB104K 0.1 16V Ceramic AB
C626 VCKYCY1CB104K 0.1 16V Ceramic AB
C627 VCSATE1AJ476M 47 10V Tantalum AD
C628 VCKYCY1CB104K 0.1 16V Ceramic AB
C629 VCKYCY1CB104K 0.1 16V Ceramic AB
DUNTK6002KE51
MAIN PWB UNIT(Continued)

Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
60
DV-L80S/W
C1802 VCCCCY1HH101J 100p 50V Ceramic AA
C1803 VCCCCY1HH221J 220p 50V Ceramic AA
C1804 VCKYTV1CF105Z 1 16V Ceramic AB
C1805 VCCCCY1HH121J 120p 50V Ceramic AA
C1806 VCCCCY1HH121J 120p 50V Ceramic AA
C1807 VCKYTV1CF105Z 1 16V Ceramic AB
C1808 VCCCCY1HH331J 330p 50V Ceramic AA
C1809 VCCCCY1HH391J 390p 50V Ceramic AA
C1810 VCSATE1CJ226M 22 16V Tantalum AE
C1811 RC-KZ0082TAZZ 11 10V Ceramic AC
C1812 VCKYCY1HB103K 0.01 50V Ceramic AA
C1813 VCKYCY1HB103K 0.01 50V Ceramic AA
C1814 VCCCCY1EH821J 820p 25V Ceramic AB
C1815 VCKYCY1AF105Z 1 10V Ceramic AC
C1816 VCKYCY1AF105Z 1 10V Ceramic AC
C1817 VCKYCY1HB103K 0.01 50V Ceramic AA
C1818 VCKYCY1HB103K 0.01 50V Ceramic AA
C1819 VCKYCY1AF105Z 1 10V Ceramic AC
C1820 VCKYCY1CB104K 0.1 16V Ceramic AB
C1821 VCKYCY1AF105Z 1 10V Ceramic AC
C1822 VCKYCY1CB104K 0.1 16V Ceramic AB
C1823 VCKYCY1CB104K 0.1 16V Ceramic AB
C1824 VCKYCY1HB103K 0.01 50V Ceramic AA
C1825 VCCCCY1HH5R0C 5p 50V Ceramic AA
C1826 VCKYCY1CB104K 0.1 16V Ceramic AB
C1827 VCKYCY1AF105Z 1 10V Ceramic AC
C1828 VCKYCY1CF474Z 0.47 16V Ceramic AB
C1829 VCSATN1AJ225M 2.2 10V Tantalum AC
C1830 VCKYCY1CB104K 0.1 16V Ceramic AB
C1831 VCKYCY1HB103K 0.01 50V Ceramic AA
C1832 VCKYCY1HB103K 0.01 50V Ceramic AA
C1833 VCKYCY1AF105Z 1 10V Ceramic AC
C1834 VCKYCY1HB103K 0.01 50V Ceramic AA
C1835 VCKYCY1HB103K 0.01 50V Ceramic AA
C1836 VCCCCY1HH390J 39p 50V Ceramic AA
C1837 VCKYCY1HB103K 0.01 50V Ceramic AA
C1838 VCSATA1AJ106M 10 10V Tantalum AC
C1839 VCKYCY1HB103K 0.01 50V Ceramic AA
C1840 VCCCCY1HH270J 27p 50V Ceramic AA
C1841 VCKYCY1HB103K 0.01 50V Ceramic AA
C1843 VCCCCY1HH681J 680p 50V Ceramic AB
C1844 VCCCCY1HH270J 27p 50V Ceramic AA
C1845 VCKYCY1CB104K 0.1 16V Ceramic AB
C1846 VCKYCY1CB104K 0.1 16V Ceramic AB
C1847 VCKYCY1CB104K 0.1 16V Ceramic AB
C1848 VCKYCY1HF473Z 0.047 50V Ceramic AA
C1849 VCKYCY1HB103K 0.01 50V Ceramic AA
C1850 VCSATE1AJ476M 47 10V Tantalum AD
C1851 VCSATE1AJ476M 47 10V Tantalum AD
C1852 VCSATE1AJ476M 47 10V Tantalum AD
C1853 VCSATE1AJ476M 47 10V Tantalum AD
C1854 VCSATA1AJ106M 10 10V Tantalum AC
C1856 VCKYCY1CB104K 0.1 16V Ceramic AB
C1857 VCKYCY1CF474Z 0.47 16V Ceramic AB
C1858 VCKYCY1EF104Z 0.1 25V Ceramic AA
C1859 VCKYCY1EF104Z 0.1 25V Ceramic AA
C1864 VCKYCY1CB104K 0.1 16V Ceramic AB
C1865 VCKYCY1CB104K 0.1 16V Ceramic AB
C1866 VCKYCY1CB104K 0.1 16V Ceramic AB
C1867 VCKYCY1CB104K 0.1 16V Ceramic AB
C1868 VCCCCY1HH331J 330p 50V Ceramic AA
C1869 VCSATE1CJ226M 22 16V Tantalum AE
C1870 VCEAPX1EW107M 100 25V Electrolytic AD
C1871 VCEAPF1CW107M 100 16V Electrolytic AD
C2201 VCKYCY1CB104K 0.1 16V Ceramic AB
C2202 VCSATE1AJ476M 47 10V Tantalum AD
C2204 VCKYCY1CB104K 0.1 16V Ceramic AB
C2205 VCKYCY1CB104K 0.1 16V Ceramic AB
C2206 VCSATE1AJ476M 47 10V Tantalum AD
C2207 VCKYCY1CB104K 0.1 16V Ceramic AB
C2209 VCKYCY1CB104K 0.1 16V Ceramic AB
C2210 VCSATD0JJ227M 220 6.3V Tantalum AH
DUNTK6002KE51
MAIN PWB UNIT(Continued) C2211 VCSATE1AJ336M 33 10V Tantalum AG
C2212 VCSATE1AJ336M 33 10V Tantalum AG
C2213 VCSATD0JJ227M 220 6.3V Tantalum AH
C2214 RC-KZ0082TAZZ 1 10V Ceramic AC
C2217 VCEA0A0JW477M 470 6.3V Electrolytic AC
C3001 VCKYCY1CB104K 0.1 16V Ceramic AB
C3002 VCSATE1AJ476M 47 10V Tantalum AD
C3029 VCKYCY1AF105Z 1 10V Ceramic AC
C3030 VCSATA0JJ226M 22 6.3V Tantalum AD
C3042 VCKYCY1CB104K 0.1 16V Ceramic AB
C5101 VCKYCY1EB223K 0.022 25V Ceramic AA
C5501 VCKYCY1CB104K 0.1 16V Ceramic AB
C5503 VCCCCY1HH101J 100p 50V Ceramic AA
C5504 VCCCCY1HH101J 100p 50V Ceramic AA
C5505 VCCCCY1HH101J 100p 50V Ceramic AA
C5506 VCCCCY1HH101J 100p 50V Ceramic AA
C5507 VCCCCY1HH101J 100p 50V Ceramic AA
C5508 VCKYCY1HB103K 0.01 50V Ceramic AA
C5509 VCKYCY1HB103K 0.01 50V Ceramic AA
C5510 VCCCCY1HH6R0D 6p 50V Ceramic AA
C5511 VCCCCY1HH101J 100p 50V Ceramic AA
C5512 VCKYCY1AF105Z 1 10V Ceramic AC
C5513 VCSATE1AJ476M 47 10V Tantalum AD
C5514 VCCCCY1HH101J 100p 50V Ceramic AA
C5515 VCCCCY1HH101J 100p 50V Ceramic AA
C5516 VCCCCY1HH470J 47p 50V Ceramic AA
C5517 VCCCCY1HH101J 100p 50V Ceramic AA
C5518 VCCCCY1HH101J 100p 50V Ceramic AA
C5519 VCCCCY1HH101J 100p 50V Ceramic AA
C5520 VCKYCY1CB104K 0.1 16V Ceramic AB
C5521 VCCCCY1HH101J 100p 50V Ceramic AA
C5522 VCCCCY1HH101J 100p 50V Ceramic AA
C5523 VCCCCY1HH101J 100p 50V Ceramic AA
C5524 VCCCCY1HH101J 100p 50V Ceramic AA
C5525 VCCCCY1HH101J 100p 50V Ceramic AA
C5526 VCCCCY1HH471J 470p 50V Ceramic AA
C5527 VCCCCY1HH471J 470p 50V Ceramic AA
C5528 VCCCCY1HH471J 470p 50V Ceramic AA
C5529 VCCCCY1HH471J 470p 50V Ceramic AA
C5530 VCCCCY1HH101J 100p 50V Ceramic AA
C5531 VCCCCY1HH471J 470p 50V Ceramic AA
C5533 VCCCCY1HH101J 100p 50V Ceramic AA
C5534 VCCCCY1HH101J 100p 50V Ceramic AA
C5535 VCCCCY1HH101J 100p 50V Ceramic AA
C5536 VCCCCY1HH101J 100p 50V Ceramic AA
C5538 VCKYCY1EB223K 0.022 25V Ceramic AA
C5539 VCCCCY1HH120J 12p 50V Ceramic AA
C5540 VCCCCY1HH120J 12p 50V Ceramic AA
C5541 VCKYCY1HB102K 1000p 50V Ceramic AA
C5542 VCKYCY1CB104K 0.1 16V Ceramic AB
C5543 VCKYCY1CB104K 0.1 16V Ceramic AB
C5544 VCKYCY1HB103K 0.01 50V Ceramic AA
C5545 VCKYCY1HB103K 0.01 50V Ceramic AA
C5546 VCKYCY1CB104K 0.1 16V Ceramic AB
C5547 VCKYCY1CB104K 0.1 16V Ceramic AB
C6610 VCSATA1AJ106M 10 10V Tantalum AC
C6611 VCSATA1AJ106M 10 10V Tantalum AC
C6612 VCKYCY1CB104K 0.1 16V Ceramic AB
C6613 VCKYCY1CB104K 0.1 16V Ceramic AB
C6614 VCSATA1AJ106M 10 10V Tantalum AC
C6615 VCCCCY1HH331J 330p 50V Ceramic AA
C6616 VCKYCY1AF105Z 1 10V Ceramic AC
C6617 VCKYCY1AF105Z 1 10V Ceramic AC
C6618 VCKYCY1HB222K 2200p 50V Ceramic AA
C6619 VCCCCY1HH331J 330p 50V Ceramic AA
C6620 VCSATA1AJ106M 10 10V Tantalum AC
C6621 VCSATD0JJ227M 220 6.3V Tantalum AH
C6622 VCSATA1AJ106M 10 10V Tantalum AC
C6623 VCSATA1AJ106M 10 10V Tantalum AC
C6624 VCKYCY1HB222K 2200p 50V Ceramic AA
C6625 VCKYCY1HB103K 0.01 50V Ceramic AA
C6626 VCSATA1AJ106M 10 10V Tantalum AC
C6627 VCSATE1DJ106M 10 20V Tantalum AD
C6628 VCKYCY1AF105Z 1 10V Ceramic AC
C6629 VCKYCY1AF105Z 1 10V Ceramic AC

Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
61
DV-L80S/W
C9031 VCSATD1AJ157M 150 10V Tantalum AG
C9032 VCSATD1AJ157M 150 10V Tantalum AG
C9033 VCSATD1AJ157M 150 10V Tantalum AG
C9034 VCKYCY1AF105Z 1 10V Ceramic AC
C9035 VCKYCY1AF105Z 1 10V Ceramic AC
C9036 VCKYCY1AF105Z 1 10V Ceramic AC
C9037 RC-KZ0046TAZZ 4.7 35V Ceramic AD
C9038 RC-KZ0046TAZZ 4.7 35V Ceramic AD
C9039 RC-KZ0046TAZZ 4.7 35V Ceramic AD
C9040 RC-KZ0046TAZZ 4.7 35V Ceramic AD
C9043 RC-KZ0046TAZZ 4.7 35V Ceramic AD
C9044 RC-KZ0046TAZZ 4.7 35V Ceramic AD
C9045 RC-KZ0046TAZZ 4.7 35V Ceramic AD
C9046 RC-KZ0046TAZZ 4.7 35V Ceramic AD
C9047 VCSATD0JJ227M 220 6.3V Tantalum AH
C9905 VCKYCY1HB103K 0.01 50V Ceramic AA
C9906 VCKYCY1HB103K 0.01 50V Ceramic AA
C9907 VCKYCY1HB103K 0.01 50V Ceramic AA
C9908 VCKYCY1HB103K 0.01 50V Ceramic AA
RESISTORS
R205 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R206 VRS-CY1JF820J 82 1/16W Metal Oxide AA
R207 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R208 VRS-CY1JF242F 2.4k 1/16W Metal Oxide AA
R209 VRS-CY1JF820J 82 1/16W Metal Oxide AA
R210 VRS-CY1JF152F 1.5k 1/16W Metal Oxide AA
R212 VRS-CY1JF820J 82 1/16W Metal Oxide AA
R214 VRS-CY1JF820J 82 1/16W Metal Oxide AA
R215 VRS-CY1JF182F 1.8k 1/16W Metal Oxide AA
R217 VRS-CY1JF820J 82 1/16W Metal Oxide AA
R219 VRS-CY1JF820J 82 1/16W Metal Oxide AA
R221 VRS-CY1JF820J 82 1/16W Metal Oxide AA
R222 VRS-CY1JF181J 180 1/16W Metal Oxide AA
R224 VRS-CY1JF820J 82 1/16W Metal Oxide AA
R225 VRS-CY1JF181F 180 1/16W Metal Oxide AA
R227 VRS-CY1JF820J 82 1/16W Metal Oxide AA
R229 VRS-CY1JF820J 82 1/16W Metal Oxide AA
R230 VRS-CY1JF181J 180 1/16W Metal Oxide AA
R231 VRS-CY1JF181F 180 1/16W Metal Oxide AA
R233 VRS-CY1JF820J 82 1/16W Metal Oxide AA
R234 VRS-CY1JF181J 180 1/16W Metal Oxide AA
R236 VRS-CY1JF820J 82 1/16W Metal Oxide AA
R237 VRS-CY1JF181F 180 1/16W Metal Oxide AA
R238 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R243 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R244 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R245 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R246 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R247 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R248 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R301 VRS-TW2ED470J 47 1/4W Metal Oxide AA
R303 VRS-TW2ED470J 47 1/4W Metal Oxide AA
R304 VRS-TW2ED470J 47 1/4W Metal Oxide AA
R305 VRS-CY1JF222J 2.2k 1/16W Metal Oxide AA
R306 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R307 VRS-CY1JF222J 2.2k 1/16W Metal Oxide AA
R308 VRS-CY1JF471J 470 1/16W Metal Oxide AA
R309 VRS-CY1JF471J 470 1/16W Metal Oxide AA
R310 VRS-CY1JF471J 470 1/16W Metal Oxide AA
R311 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R313 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R314 VRS-CY1JF335J 3.3M 1/16W Metal Oxide AA
R315 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R316 VRS-CY1JF335J 3.3M 1/16W Metal Oxide AA
R317 VRS-CY1JF151J 150 1/16W Metal Oxide AA
R318 VRS-CY1JF151J 150 1/16W Metal Oxide AA
R319 VRS-CY1JF151J 150 1/16W Metal Oxide AA
R333 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R334 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R336 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R341 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R343 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R344 VRS-CY1JF334J 330k 1/16W Metal Oxide AA
R345 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
C6630 VCKYCY1AF105Z 1 10V Ceramic AC
C6631 VCCCCY1HH680J 68p 50V Ceramic AA
C6632 VCCCCY1HH680J 68p 50V Ceramic AA
C6633 VCKYCY1AF105Z 1 10V Ceramic AC
C6634 VCKYCY1AF105Z 1 10V Ceramic AC
C6635 VCCCCY1HH680J 68p 50V Ceramic AA
C6636 VCCCCY1HH680J 68p 50V Ceramic AA
C6637 VCSATA1AJ106M 10 10V Tantalum AC
C6638 VCSATA1AJ106M 10 10V Tantalum AC
C6639 VCSATA1AJ106M 10 10V Tantalum AC
C6640 VCSATA1AJ106M 10 10V Tantalum AC
C6641 VCKYCY1CB683K 0.068 16V Ceramic AC
C6642 VCKYCY1CB683K 0.068 16V Ceramic AC
C6643 VCKYCY1CB393K 0.039 16V Ceramic AA
C6644 VCKYCY1CB393K 0.039 16V Ceramic AA
C6645 VCKYCY1HB222K 2200p 50V Ceramic AA
C6646 VCKYCY1HB222K 2200p 50V Ceramic AA
C6647 VCKYCY1HB222K 2200p 50V Ceramic AA
C6648 VCKYCY1HB222K 2200p 50V Ceramic AA
C6649 VCKYCY1CF474Z 0.47 16V Ceramic AB
C6650 VCKYCY1CF474Z 0.47 16V Ceramic AB
C6651 VCKYCY1CF474Z 0.47 16V Ceramic AB
C6652 VCKYCY1HB332K 3300p 50V Ceramic AA
C6653 VCSATE1AJ476M 47 10V Tantalum AD
C6654 VCSATE1AJ476M 47 10V Tantalum AD
C6655 VCKYCY1CB104K 0.1 16V Ceramic AB
C6656 VCKYCY1AF105Z 1 10V Ceramic AC
C6657 VCKYCY1CB104K 0.1 16V Ceramic AB
C6659 VCKYCY1CB104K 0.1 16V Ceramic AB
C6660 VCSATE1AJ476M 47 10V Tantalum AD
C6661 VCSATE1AJ476M 47 10V Tantalum AD
C6662 VCKYCY1HB102K 1000p 50V Ceramic AA
C6663 VCKYCY1HB103K 0.01 50V Ceramic AA
C6664 VCSATJ0JJ107M 100 6.3V Tantalum AE
C6665 VCKYCY1HB102K 1000p 50V Ceramic AA
C6666 VCKYCY1AF105Z 1 10V Ceramic AC
C6667 VCKYCY1AF105Z 1 10V Ceramic AC
C6668 VCEAPF0JW476M 47 6.3V Electrolytic AB
C6669 VCKYCY1CB104K 0.1 16V Ceramic AB
C6670 VCSATA1AJ106M 10 10V Tantalum AC
C6671 VCKYCY1CB104K 0.1 16V Ceramic AB
C6672 VCSATA1AJ106M 10 10V Tantalum AC
C6673 VCKYCY1HB103K 0.01 50V Ceramic AA
C9001 VCCCCY1HH181J 180p 50V Ceramic AA
C9002 VCKYTV1CB105K 1 16V Ceramic AC
C9003 VCKYCY1CB104K 0.1 16V Ceramic AB
C9004 VCKYCY1CB104K 0.1 16V Ceramic AB
C9005 VCCCCY1HH471J 470p 50V Ceramic AA
C9006 VCKYCY1HB472K 4700p 50V Ceramic AA
C9007 VCKYCY1HB102K 1000p 50V Ceramic AA
C9008 VCKYCY1HB562K 5600p 50V Ceramic AA
C9009 VCKYCY1CB104K 0.1 16V Ceramic AB
C9010 VCKYCY1CB104K 0.1 16V Ceramic AB
C9011 VCCCCY1HH471J 470p 50V Ceramic AA
C9012 VCCCCY1HH471J 470p 50V Ceramic AA
C9013 VCKYCY1HB102K 1000p 50V Ceramic AA
C9014 VCKYCY1HB102K 1000p 50V Ceramic AA
C9015 VCKYCY1HB102K 1000p 50V Ceramic AA
C9016 VCKYCY1HB102K 1000p 50V Ceramic AA
C9017 VCKYCY1CB104K 0.1 16V Ceramic AB
C9018 VCKYCY1CB104K 0.1 16V Ceramic AB
C9019 VCKYCY1HB102K 1000p 50V Ceramic AA
C9020 VCKYCY1HB102K 1000p 50V Ceramic AA
C9021 VCKYCY1HB102K 1000p 50V Ceramic AA
C9022 VCKYTV1CB105K 1 16V Ceramic AC
C9023 VCKYCY1HB102K 1000p 50V Ceramic AA
C9024 VCKYCY1HB102K 1000p 50V Ceramic AA
C9025 VCKYCY1HB102K 1000p 50V Ceramic AA
C9027 RC-KZ0075TAZZ 2.2 16V Ceramic AC
C9028 RC-KZ0075TAZZ 2.2 16V Ceramic AC
C9029 RC-KZ0069TAZZ 10 16V Ceramic AE
C9030 RC-KZ0075TAZZ 2.2 16V Ceramic AC
DUNTK6002KE51
MAIN PWB UNIT(Continued)

Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
62
DV-L80S/W
R401 VRS-CY1JF151J 150 1/16W Metal Oxide AA
R403 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R407 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R408 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R410 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R411 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R412 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R414 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R415 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R417 VRS-CY1JF221J 220 1/16W Metal Oxide AA
R418 VRS-CY1JF221J 220 1/16W Metal Oxide AA
R419 VRS-CY1JF221J 220 1/16W Metal Oxide AA
R420 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R421 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R423 VRS-CY1JF220J 22 1/16W Metal Oxide AA
R424 VRS-CY1JF220J 22 1/16W Metal Oxide AA
R425 VRS-CY1JF332J 3.3k 1/16W Metal Oxide AA
R427 VRS-CY1JF220J 22 1/16W Metal Oxide AA
R428 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R430 VRS-CY1JF220J 22 1/16W Metal Oxide AA
R432 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R433 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R434 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R435 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R501 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R502 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R503 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R504 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R505 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R506 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R507 VRS-CY1JF332J 3.3k 1/16W Metal Oxide AA
R508 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R509 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R510 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R511 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R512 VRS-CY1JF562J 5.6k 1/16W Metal Oxide AA
R513 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R517 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R518 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R519 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R522 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R523 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R524 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R525 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R526 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R527 VRS-CY1JF154J 150k 1/16W Metal Oxide AA
R528 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R529 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R531 VRS-CY1JF100J 10 1/16W Metal Oxide AA
R532 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R533 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R534 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R535 VRS-CY1JF562J 5.6k 1/16W Metal Oxide AA
R536 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R537 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R538 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R539 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R540 VRS-CY1JF473J 47k 1/16W Metal Oxide AA
R541 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R542 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R543 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R544 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R545 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R546 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R549 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R550 VRS-CY1JF473J 47k 1/16W Metal Oxide AA
R552 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R553 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R554 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R561 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R562 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R565 VRS-CY1JF473J 47k 1/16W Metal Oxide AA
DUNTK6002KE51
MAIN PWB UNIT(Continued) R567 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R568 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R571 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R572 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R573 VRS-CY1JF222J 2.2k 1/16W Metal Oxide AA
R576 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R577 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R601 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R603 VRS-CY1JF221J 220 1/16W Metal Oxide AA
R604 VRS-CY1JF221J 220 1/16W Metal Oxide AA
R605 VRS-CY1JF221J 220 1/16W Metal Oxide AA
R606 VRS-CY1JF221J 220 1/16W Metal Oxide AA
R607 VRS-CY1JF221J 220 1/16W Metal Oxide AA
R608 VRS-CY1JF391J 390 1/16W Metal Oxide AA
R612 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R613 VRS-CY1JF334J 330k 1/16W Metal Oxide AA
R614 VRS-CY1JF560F 56 1/16W Metal Oxide AA
R615 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R616 VRS-CY1JF391F 390 1/16W Metal Oxide AA
R618 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R619 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R620 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R622 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R624 VRS-CY1JF680F 68 1/16W Metal Oxide AA
R625 VRS-CY1JF680F 68 1/16W Metal Oxide AA
R626 VRS-CY1JF561J 560 1/16W Metal Oxide AA
R627 VRS-CY1JF560F 56 1/16W Metal Oxide AA
R629 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R636 VRS-CY1JF8R2J 8.2 1/16W Metal Oxide AA
R637 VRS-CY1JF151J 150 1/16W Metal Oxide AA
R639 VRS-CY1JF100J 10 1/16W Metal Oxide AA
R707 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R708 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R709 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R712 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R714 VRS-CY1JF273J 27k 1/16W Metal Oxide AA
R715 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R716 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R717 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R718 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R719 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R721 VRS-CY1JF273J 27k 1/16W Metal Oxide AA
R722 VRS-CY1JF273J 27k 1/16W Metal Oxide AA
R724 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R725 VRS-CY1JF822J 8.2k 1/16W Metal Oxide AA
R726 VRS-CY1JF153J 15k 1/16W Metal Oxide AA
R727 VRS-CY1JF153J 15k 1/16W Metal Oxide AA
R728 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R729 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R730 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R731 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R732 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R733 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R734 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R735 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R736 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R739 VRS-CY1JF822J 8.2k 1/16W Metal Oxide AA
R740 VRS-CY1JF822J 8.2k 1/16W Metal Oxide AA
R741 VRS-CY1JF822J 8.2k 1/16W Metal Oxide AA
R742 VRS-CY1JF182J 1.8k 1/16W Metal Oxide AA
R743 VRS-CY1JF182J 1.8k 1/16W Metal Oxide AA
R744 VRS-CY1JF182J 1.8k 1/16W Metal Oxide AA
R745 VRS-CY1JF152J 1.5k 1/16W Metal Oxide AA
R746 VRS-CY1JF152J 1.5k 1/16W Metal Oxide AA
R747 VRS-CY1JF332J 3.3k 1/16W Metal Oxide AA
R748 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R749 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R750 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R751 VRS-CY1JF563J 56k 1/16W Metal Oxide AA
R752 VRS-CY1JF562J 5.6k 1/16W Metal Oxide AA
R753 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R754 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R755 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R756 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R757 VRS-CY1JF103J 10k 1/16W Metal Oxide AA

Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
63
DV-L80S/W
R758 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R759 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R760 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R761 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R762 VRS-CY1JF123J 12k 1/16W Metal Oxide AA
R763 VRS-CY1JF153J 15k 1/16W Metal Oxide AA
R764 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R767 VRS-CY1JF472J 4.7k 1/16W Metal Oxide AA
R769 VRS-CY1JF392J 3.9k 1/16W Metal Oxide AA
R770 VRS-CY1JF223J 22k 1/16W Metal Oxide AA
R771 VRS-CY1JF223J 22k 1/16W Metal Oxide AA
R775 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R776 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R778 VRS-CY1JF563J 56k 1/16W Metal Oxide AA
R779 VRS-CY1JF104J 100k 1/16W Metal Oxide AA
R861 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R862 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R866 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R868 VRS-CY1JF8R2J 8.2 1/16W Metal Oxide AA
R1800 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R1801 VRS-CY1JF474F 470k 1/16W Metal Oxide AA
R1802 VRS-CY1JF134F 130k 1/16W Metal Oxide AA
R1803 VRS-CY1JF223J 22k 1/16W Metal Oxide AA
R1804 VRS-CY1JF223F 22k 1/16W Metal Oxide AA
R1805 VRS-CY1JF222J 2.2k 1/16W Metal Oxide AA
R1806 VRS-CY1JF222J 2.2k 1/16W Metal Oxide AA
R1807 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R1808 VRS-CY1JF474J 470k 1/16W Metal Oxide AA
R1809 VRS-CY1JF331J 330 1/16W Metal Oxide AA
R1810 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R1811 VRS-CY1JF104F 100k 1/16W Metal Oxide AA
R1812 VRS-CY1JF331J 330 1/16W Metal Oxide AA
R1813 VRS-CY1JF331J 330 1/16W Metal Oxide AA
R1816 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R1817 VRS-CY1JF683J 68k 1/16W Metal Oxide AA
R1818 VRS-CY1JF393J 39k 1/16W Metal Oxide AA
R1819 VRS-CY1JF153J 15k 1/16W Metal Oxide AA
R1820 VRS-CY1JF391J 390 1/16W Metal Oxide AA
R1821 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R1822 VRS-CY1JF333J 33k 1/16W Metal Oxide AA
R1823 VRS-CY1JF564J 560k 1/16W Metal Oxide AA
R1824 VRS-CY1JF104J 100k 1/16W Metal Oxide AA
R1826 VRS-CY1JF183J 18k 1/16W Metal Oxide AA
R1827 VRS-CY1JF333J 33k 1/16W Metal Oxide AA
R1828 VRS-CY1JF683J 68k 1/16W Metal Oxide AA
R1829 VRS-CY1JF472F 4.7k 1/16W Metal Oxide AA
R1830 VRS-CY1JF272F 2.7k 1/16W Metal Oxide AA
R1831 VRS-CY1JF105J 1M 1/16W Metal Oxide AA
R1832 VRS-CY1JF104J 100k 1/16W Metal Oxide AA
R1833 VRS-CY1JF822J 8.2k 1/16W Metal Oxide AA
R1835 VRS-CY1JF562J 5.6k 1/16W Metal Oxide AA
R1836 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R1838 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R1839 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R1840 VRS-CY1JF272J 2.7k 1/16W Metal Oxide AA
R1841 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R1842 VRS-CY1JF272J 2.7k 1/16W Metal Oxide AA
R1843 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R1844 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R1845 VRS-CY1JF272J 2.7k 1/16W Metal Oxide AA
R1846 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R1847 VRS-CY1JF183J 18k 1/16W Metal Oxide AA
R1848 VRS-CY1JF471F 470 1/16W Metal Oxide AA
R1849 VRS-CY1JF562J 5.6k 1/16W Metal Oxide AA
R1850 VRS-CY1JF224J 220k 1/16W Metal Oxide AA
R1851 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R1852 VRS-CY1JF561J 560 1/16W Metal Oxide AA
R1853 VRS-CY1JF562J 5.6k 1/16W Metal Oxide AA
R1854 VRS-CY1JF822J 8.2k 1/16W Metal Oxide AA
R1855 VRS-CY1JF334J 330k 1/16W Metal Oxide AA
R1856 VRS-CY1JF224J 220k 1/16W Metal Oxide AA
R1858 VRS-CY1JF562J 5.6k 1/16W Metal Oxide AA
DUNTK6002KE51
MAIN PWB UNIT(Continued) R1859 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R1860 VRS-CY1JF105J 1M 1/16W Metal Oxide AA
R1861 VRS-CY1JF223J 22k 1/16W Metal Oxide AA
R1864 VRS-CY1JF106J 10M 1/16W Metal Oxide AA
R1865 VRS-CY1JF433J 43k 1/16W Metal Oxide AA
R1867 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R1868 VRS-CY1JF563J 56k 1/16W Metal Oxide AA
R1869 VRS-CY1JF474J 470k 1/16W Metal Oxide AA
R1870 VRS-CY1JF685J 6.8M 1/16W Metal Oxide AA
R1871 VRS-CY1JF153J 15k 1/16W Metal Oxide AA
R1872 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R1873 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R1874 VRS-CY1JF273J 27k 1/16W Metal Oxide AA
R1875 VRS-CY1JF473J 47k 1/16W Metal Oxide AA
R1876 VRS-CY1JF563J 56k 1/16W Metal Oxide AA
R1877 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R1878 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R1879 VRS-TQ2BD100J 10 1/8W Metal Oxide AA
R1880 VRS-TW2ED220J 22 1/4W Metal Oxide AB
R1881 VRS-CY1JF102F 1k 1/16W Metal Oxide AA
R1882 VRS-CY1JF222F 2.2k 1/16W Metal Oxide AA
R1884 VRS-CY1JF100J 10 1/16W Metal Oxide AA
R1885 VRS-CY1JF102F 1k 1/16W Metal Oxide AA
R1886 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R1888 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R1890 VRS-CY1JF473J 47k 1/16W Metal Oxide AA
R1891 VRS-CY1JF393J 39k 1/16W Metal Oxide AA
R1892 VRS-CY1JF473J 47k 1/16W Metal Oxide AA
R1893 VRS-CY1JF104J 100k 1/16W Metal Oxide AA
R1894 VRS-CY1JF223J 22k 1/16W Metal Oxide AA
R1896 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R1897 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R1899 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R1961 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R2201 VRS-CY1JF560F 56 1/16W Metal Oxide AA
R2202 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R2203 VRS-CY1JF821J 820 1/16W Metal Oxide AA
R2204 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R2205 VRS-CY1JF681J 680 1/16W Metal Oxide AA
R2206 VRS-CY1JF681J 680 1/16W Metal Oxide AA
R2208 VRS-CY1JF471J 470 1/16W Metal Oxide AA
R2209 VRS-CY1JF223J 22k 1/16W Metal Oxide AA
R2210 VRS-CY1JF223J 22k 1/16W Metal Oxide AA
R2227 VRS-CY1JF391J 390 1/16W Metal Oxide AA
R2232 VRS-CY1JF221J 220 1/16W Metal Oxide AA
R2237 VRS-CY1JF750J 75 1/16W Metal Oxide AA
R2242 VRS-CY1JF750J 75 1/16W Metal Oxide AA
R2249 VRS-CY1JF750J 75 1/16W Metal Oxide AA
R2254 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R2257 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R2261 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R2263 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R2265 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R3001 VRS-CY1JF750J 75 1/16W Metal Oxide AA
R3209 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R3218 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R3220 VRS-CY1JF473J 47k 1/16W Metal Oxide AA
R3221 VRS-CY1JF473J 47k 1/16W Metal Oxide AA
R5101 VRS-CY1JF104J 100k 1/16W Metal Oxide AA
R5102 VRS-CY1JF223J 22k 1/16W Metal Oxide AA
R5501 VRS-CY1JF473J 47k 1/16W Metal Oxide AA
R5502 VRS-CY1JF473J 47k 1/16W Metal Oxide AA
R5503 VRS-CY1JF223J 22k 1/16W Metal Oxide AA
R5504 VRS-CY1JF123J 12k 1/16W Metal Oxide AA
R5506 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R5507 VRS-CY1JF473J 47k 1/16W Metal Oxide AA
R5509 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R5513 VRS-CY1JF471J 470 1/16W Metal Oxide AA
R5514 VRS-CY1JF471J 470 1/16W Metal Oxide AA
R5515 VRS-CY1JF471J 470 1/16W Metal Oxide AA
R5516 VRS-CY1JF471J 470 1/16W Metal Oxide AA
R5517 VRS-CY1JF471J 470 1/16W Metal Oxide AA
R5519 VRS-CY1JF564F 560k 1/16W Metal Oxide AA
R5520 VRS-CY1JF564F 560k 1/16W Metal Oxide AA
R5521 VRS-CY1JF332J 3.3k 1/16W Metal Oxide AA

Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
64
DV-L80S/W
DUNTK6002KE51
MAIN PWB UNIT(Continued)
R5522 VRS-CY1JF182J 1.8k 1/16W Metal Oxide AA
R5523 VRS-CY1JF471J 470 1/16W Metal Oxide AA
R5525 VRS-CY1JF471J 470 1/16W Metal Oxide AA
R5526 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R5527 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R5529 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R5532 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R5535 VRS-CY1JF471J 470 1/16W Metal Oxide AA
R5536 VRS-CY1JF471J 470 1/16W Metal Oxide AA
R5537 VRS-CY1JF471J 470 1/16W Metal Oxide AA
R5538 VRS-CY1JF471J 470 1/16W Metal Oxide AA
R5539 VRS-CY1JF471J 470 1/16W Metal Oxide AA
R5540 VRS-CY1JF471J 470 1/16W Metal Oxide AA
R5541 VRS-CY1JF471J 470 1/16W Metal Oxide AA
R5542 VRS-CY1JF471J 470 1/16W Metal Oxide AA
R5543 VRS-CY1JF471J 470 1/16W Metal Oxide AA
R5544 VRS-CY1JF471J 470 1/16W Metal Oxide AA
R5545 VRS-CY1JF471J 470 1/16W Metal Oxide AA
R5546 VRS-CY1JF471J 470 1/16W Metal Oxide AA
R5547 VRS-CY1JF471J 470 1/16W Metal Oxide AA
R5548 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R5551 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R5556 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R5557 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R5558 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R5559 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R5560 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R5561 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R5562 VRS-CY1JF564J 560k 1/16W Metal Oxide AA
R5563 VRS-CY1JF561J 560 1/16W Metal Oxide AA
R5564 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R5565 VRS-CY1JF106J 10M 1/16W Metal Oxide AA
R5567 VRS-CY1JF105J 1M 1/16W Metal Oxide AA
R5568 VRS-CY1JF471J 470 1/16W Metal Oxide AA
R5569 VRS-CY1JF104J 100k 1/16W Metal Oxide AA
R5572 VRS-CY1JF471J 470 1/16W Metal Oxide AA
R5573 VRS-CY1JF471J 470 1/16W Metal Oxide AA
R5574 VRS-CY1JF471J 470 1/16W Metal Oxide AA
R5575 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R5577 VRS-CY1JF334F 330k 1/16W Metal Oxide AA
R5578 VRS-CY1JF273F 27k 1/16W Metal Oxide AA
R5579 VRS-CY1JF474F 470k 1/16W Metal Oxide AA
R5580 VRS-CY1JF334F 330k 1/16W Metal Oxide AA
R5582 VRS-CY1JF474F 470k 1/16W Metal Oxide AA
R6607 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R6608 VRS-CY1JF332J 3.3k 1/16W Metal Oxide AA
R6609 VRS-CY1JF332J 3.3k 1/16W Metal Oxide AA
R6610 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R6611 VRS-CY1JF104J 100k 1/16W Metal Oxide AA
R6612 VRS-CY1JF104J 100k 1/16W Metal Oxide AA
R6613 VRS-CY1JF104J 100k 1/16W Metal Oxide AA
R6614 VRS-CY1JF821J 820 1/16W Metal Oxide AA
R6615 VRS-CY1JF104J 100k 1/16W Metal Oxide AA
R6616 VRS-CY1JF272J 2.7k 1/16W Metal Oxide AA
R6618 VRS-CY1JF473J 47k 1/16W Metal Oxide AA
R6619 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R6620 VRS-CY1JF272J 2.7k 1/16W Metal Oxide AA
R6621 VRS-CY1JF474J 470k 1/16W Metal Oxide AA
R6622 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R6623 VRS-CY1JF100J 10 1/16W Metal Oxide AA
R6624 VRS-CY1JF100J 10 1/16W Metal Oxide AA
R6625 VRS-CY1JF473J 47k 1/16W Metal Oxide AA
R6626 VRS-CY1JF100J 10 1/16W Metal Oxide AA
R6627 VRS-CY1JF821J 820 1/16W Metal Oxide AA
R6628 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R6629 VRS-CY1JF183J 18k 1/16W Metal Oxide AA
R6630 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R6631 VRS-CY1JF183J 18k 1/16W Metal Oxide AA
R6632 VRS-CY1JF183J 18k 1/16W Metal Oxide AA
R6633 VRS-CY1JF183J 18k 1/16W Metal Oxide AA
R6634 VRS-CY1JF183J 18k 1/16W Metal Oxide AA
R6635 VRS-CY1JF183J 18k 1/16W Metal Oxide AA
R6636 VRS-CY1JF183J 18k 1/16W Metal Oxide AA
R6637 VRS-CY1JF104J 100k 1/16W Metal Oxide AA
R6638 VRS-CY1JF104J 100k 1/16W Metal Oxide AA
R6639 VRS-CY1JF104J 100k 1/16W Metal Oxide AA
R6640 VRS-CY1JF104J 100k 1/16W Metal Oxide AA
R6641 VRS-CY1JF183J 18k 1/16W Metal Oxide AA
R6642 VRS-CY1JF153J 15k 1/16W Metal Oxide AA
R6643 VRS-CY1JF153J 15k 1/16W Metal Oxide AA
R6644 VRS-CY1JF153J 15k 1/16W Metal Oxide AA
R6645 VRS-CY1JF153J 15k 1/16W Metal Oxide AA
R6646 VRS-CY1JF222J 2.2k 1/16W Metal Oxide AA
R6647 VRS-CY1JF222J 2.2k 1/16W Metal Oxide AA
R6648 VRS-CY1JF152J 1.5k 1/16W Metal Oxide AA
R6649 VRS-CY1JF152J 1.5k 1/16W Metal Oxide AA
R6650 VRS-CY1JF821J 820 1/16W Metal Oxide AA
R6651 VRS-CY1JF821J 820 1/16W Metal Oxide AA
R6652 VRS-CY1JF821J 820 1/16W Metal Oxide AA
R6653 VRS-CY1JF821J 820 1/16W Metal Oxide AA
R6654 VRS-CY1JF473J 47k 1/16W Metal Oxide AA
R6655 VRS-CY1JF473J 47k 1/16W Metal Oxide AA
R6656 VRS-CY1JF473J 47k 1/16W Metal Oxide AA
R6657 VRS-CY1JF473J 47k 1/16W Metal Oxide AA
R6658 VRS-CY1JF392J 3.9k 1/16W Metal Oxide AA
R6659 VRS-CY1JF392J 3.9k 1/16W Metal Oxide AA
R6660 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R6661 VRS-CY1JF272J 2.7k 1/16W Metal Oxide AA
R6662 VRS-CY1JF272J 2.7k 1/16W Metal Oxide AA
R6664 VRS-CY1JF104J 100k 1/16W Metal Oxide AA
R6665 VRS-CY1JF683J 68k 1/16W Metal Oxide AA
R6666 VRS-CY1JF334J 330k 1/16W Metal Oxide AA
R6667 VRS-CY1JF684J 680k 1/16W Metal Oxide AA
R6668 VRS-CY1JF104J 100k 1/16W Metal Oxide AA
R6669 VRS-CY1JF222J 2.2k 1/16W Metal Oxide AA
R6670 VRS-TW2ED1R8J 1.8 1/4W Metal Oxide AA
R6671 VRS-TW2ED1R8J 1.8 1/4W Metal Oxide AA
R6672 VRS-CY1JF331J 330 1/16W Metal Oxide AA
R6673 VRS-CY1JF331J 330 1/16W Metal Oxide AA
R6674 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R6675 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R6676 VRS-CY1JF272J 2.7k 1/16W Metal Oxide AA
R6677 VRS-CY1JF272J 2.7k 1/16W Metal Oxide AA
R6678 VRS-CY1JF272J 2.7k 1/16W Metal Oxide AA
R6679 VRS-CY1JF272J 2.7k 1/16W Metal Oxide AA
R6680 VRS-CY1JF272J 2.7k 1/16W Metal Oxide AA
R6681 VRS-CY1JF272J 2.7k 1/16W Metal Oxide AA
R6682 VRS-CY1JF122J 1.2k 1/16W Metal Oxide AA
R6683 VRS-CY1JF122J 1.2k 1/16W Metal Oxide AA
R6684 VRS-CY1JF123J 12k 1/16W Metal Oxide AA
R6685 VRS-CY1JF123J 12k 1/16W Metal Oxide AA
R7701 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R7702 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R7703 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R7706 VRS-CY1JF563J 56k 1/16W Metal Oxide AA
R7707 VRS-CY1JF273J 27k 1/16W Metal Oxide AA
R7710 VRS-CY1JF821J 820 1/16W Metal Oxide AA
R7713 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R7716 VRS-CY1JF473J 47k 1/16W Metal Oxide AA
R7717 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R7718 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R9001 VRS-CY1JF182F 1.8k 1/16W Metal Oxide AA
R9002 VRS-CY1JF182F 1.8k 1/16W Metal Oxide AA
R9003 VRS-CY1JF103F 10k 1/16W Metal Oxide AA
R9004 VRS-CY1JF103F 10k 1/16W Metal Oxide AA
R9005 VRS-CY1JF273F 27k 1/16W Metal Oxide AA
R9006 VRS-CY1JF103F 10k 1/16W Metal Oxide AA
R9007 VRS-CY1JF103F 10k 1/16W Metal Oxide AA
R9008 VRS-CY1JF393F 39k 1/16W Metal Oxide AA
R9009 VRS-CY1JF103F 10k 1/16W Metal Oxide AA
R9010 VRS-CY1JF272F 2.7k 1/16W Metal Oxide AA
R9011 VRS-CY1JF822F 8.2k 1/16W Metal Oxide AA
R9012 VRS-CY1JF103F 10k 1/16W Metal Oxide AA
R9013 VRS-CY1JF105J 1M 1/16W Metal Oxide AA
R9014 VRS-CY1JF105J 1M 1/16W Metal Oxide AA
R9016 VRS-CY1JF473F 47k 1/16W Metal Oxide AA
R9017 VRS-CY1JF104J 100k 1/16W Metal Oxide AA

Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
65
DV-L80S/W
R639 RBLN-0061TAZZ Balun, BLN-0061TA AD
R869 RBLN-0056TAZZ Balun, BLN-0056TA AC
R2258 RBLN-0056TAZZ Balun, BLN-0056TA AC
R2259 RBLN-0056TAZZ Balun, BLN-0056TA AC
R2260 RBLN-0056TAZZ Balun, BLN-0056TA AC
R3222 RBLN-0052TAZZ Balun, BLN-0052TA AC
R3223 RBLN-0052TAZZ Balun, BLN-0052TA AC
R5583 RBLN-0053TAZZ Balun, BLN-0053TA AB
R6686 RBLN-0077TAZZ Balun, BLN-0077TA AB
R6687 RBLN-0077TAZZ Balun, BLN-0077TA AB
R6688 RBLN-0082GEZZ Balun, BLN-0082GE
R6689 RBLN-0082GEZZ Balun, BLN-0082GE
R6690 RBLN-0082GEZZ Balun, BLN-0082GE
R6691 RBLN-0082GEZZ Balun, BLN-0082GE
R6692 RBLN-0082GEZZ Balun, BLN-0082GE
R6693 RBLN-0082GEZZ Balun, BLN-0082GE
R6694 RBLN-0082GEZZ Balun, BLN-0082GE
R9042 RBLN-0053TAZZ Balun, BLN-0053TA AB
R9043 RBLN-0053TAZZ Balun, BLN-0053TA AB
R9044 RBLN-0053TAZZ Balun, BLN-0053TA AB
R9045 RBLN-0053TAZZ Balun, BLN-0053TA AB
R9047 RBLN-0053TAZZ Balun, BLN-0053TA AB
R9048 RBLN-0053TAZZ Balun, BLN-0053TA AB
R9050 RBLN-0061TAZZ Balun, BLN-0061TA AD
R9053 RBLN-0092GEZZ Balun, BLN-0092GE AB
R9054 RBLN-0053TAZZ Balun, BLN-0053TA AB
R9056 RBLN-0051TAZZ Balun, BLN-0051TA AC
R9057 RBLN-0051TAZZ Balun, BLN-0051TA AC
R9058 RBLN-0051TAZZ Balun, BLN-0051TA AC
R9059 RBLN-0051TAZZ Balun, BLN-0051TA AC
R9922 RBLN-0093GEZZ Balun, BLN-0093GE AB
S801 QSW-M0062GEZZ Switch, LD AE
S802 QSW-M0062GEZZ Switch, Tray AE
S803 QSW-M0063GEZZ Switch, LCD AC
TP1800 QPLGN0675TAZZ Plug, 6Pin AD
DUNTK5945KE50
OPERATE PWB UNIT
DIODES
D4001 VHDDA221///-1 DA221 AB
D4002 VHDDA221///-1 DA221 AB
CAPACITORS
C4001 VCKYCY1CB104K 0.1 16V Ceramic AB
C4002 VCKYCY1CB104K 0.1 16V Ceramic AB
RESISTORS
R4001 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R4002 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R4003 VRS-CY1JF221J 220 1/16W Metal Oxide AA
R4004 VRS-CY1JF271J 270 1/16W Metal Oxide AA
R4005 VRS-CY1JF391J 390 1/16W Metal Oxide AA
R4006 VRS-CY1JF681J 680 1/16W Metal Oxide AA
R4008 VRS-CY1JF221J 220 1/16W Metal Oxide AA
R4009 VRS-CY1JF271J 270 1/16W Metal Oxide AA
R4010 VRS-CY1JF391J 390 1/16W Metal Oxide AA
R4011 VRS-CY1JF681J 680 1/16W Metal Oxide AA
R4012 VRS-CY1JF152J 1.5k 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
CN4001 QSOCN0671TAZZ Socket, 6Pin AC
S4001 QSW-K0115GEZZ Switch, Control AC
S4002 QSW-K0115GEZZ Switch, UP/Still AC
S4003 QSW-K0115GEZZ Switch, Right/Skip/Forward AC
S4004 QSW-K0115GEZZ Switch, DVD/TV/IN AC
S4005 QSW-K0115GEZZ Switch, Vol Up AC
S4006 QSW-K0115GEZZ Switch, Play/Enter AC
S4007 QSW-K0115GEZZ Switch, Down/Stop AC
S4008 QSW-K0115GEZZ Switch, Left/Skip/Back AC
S4009 QSW-K0115GEZZ Switch, Shift AC
S4010 QSW-K0115GEZZ Switch, Vol Down AC
DUNTK6002KE51
MAIN PWB UNIT(Continued)
R9018 VRS-CY1JF223F 22k 1/16W Metal Oxide AA
R9019 VRS-CY1JF822F 8.2k 1/16W Metal Oxide AA
R9020 VRS-CY1JF123F 12k 1/16W Metal Oxide AA
R9021 VRS-CY1JF182F 1.8k 1/16W Metal Oxide AA
R9022 VRS-CY1JF122F 1.2k 1/16W Metal Oxide AA
R9023 VRS-CY1JF822F 8.2k 1/16W Metal Oxide AA
R9024 VRS-CY1JF103F 10k 1/16W Metal Oxide AA
R9025 VRS-CY1JF103F 10k 1/16W Metal Oxide AA
R9026 VRS-CY1JF103F 10k 1/16W Metal Oxide AA
R9027 VRS-CY1JF103F 10k 1/16W Metal Oxide AA
R9028 VRS-CY1JF105J 1M 1/16W Metal Oxide AA
R9029 VRS-CY1JF105J 1M 1/16W Metal Oxide AA
R9030 VRS-CY1JF103F 10k 1/16W Metal Oxide AA
R9031 VRS-CY1JF334J 330k 1/16W Metal Oxide AA
R9032 VRS-CY1JF104J 100k 1/16W Metal Oxide AA
R9035 VRS-CY1JF561F 560 1/16W Metal Oxide AA
R9036 VRS-CY1JF331F 330 1/16W Metal Oxide AA
R9037 VRS-CY1JF561F 560 1/16W Metal Oxide AA
R9038 VRS-CY1JF561F 560 1/16W Metal Oxide AA
R9046 VRS-TV1JD000J 0 1/16W Metal Oxide AA
R9051 VRS-TV1JD000J 0 1/16W Metal Oxide AA
R9052 VRS-TV1JD000J 0 1/16W Metal Oxide AA
R9077 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R9078 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R9079 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R9080 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R9081 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R9901 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R9902 VRS-CY1JF561J 560 1/16W Metal Oxide AA
R9903 VRS-CY1JF153J 15k 1/16W Metal Oxide AA
R9904 VRS-CY1JF391J 390 1/16W Metal Oxide AA
R9905 VRS-CY1JF473J 47k 1/16W Metal Oxide AA
R9906 VRS-CY1JF473J 47k 1/16W Metal Oxide AA
R9909 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R9910 VRS-CY1JF681J 680 1/16W Metal Oxide AA
R9913 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R9914 VRS-CY1JF681J 680 1/16W Metal Oxide AA
R9917 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R9918 VRS-CY1JF181J 180 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
CN301 QSOCN3072TAZZ Socket, 30Pin AE
CN302 QPLGN0676TAZZ Plug, 6Pin AE
CN705 QSOCN1371TAZZ Socket, 13Pin AD
CN1103 QSOCN0971TAZZ Socket, 9Pin AC
CN1800 QPLGN1376TAZZ Plug, 13Pin AF
CN1801 QPLGN1076TAZZ Plug, 10Pin AE
CN1803 QPLGN1276TAZZ Plug, 12Pin AF
CN5001 QSOCN0671TAZZ Socket, 6Pin AC
CN9001 QSOCN2071TAZZ Socket, 20Pin AD
J2202 QJAKE0062TAZZ Jack, Video AF
J6002 QJAKE0263GEZZ Jack, Phone AE
J6003 QJAKJ0066CEZZ Jack, LS/RS Out AE
J6004 QJAKJ0066CEZZ Jack, C/S.W Out AE
P706 QPLGN0276TAZZ Plug, 2Pin AD
RMC3001 RRMCU0012TAZZ Remote Receiver AL
R239 RBLN-0052TAZZ Balun, BLN-0052TA AC
R240 RBLN-0052TAZZ Balun, BLN-0052TA AC
R241 RBLN-0052TAZZ Balun, BLN-0052TA AC
R349 RBLN-0061TAZZ Balun, BLN-0061TA AD
R436 RBLN-0056TAZZ Balun, BLN-0056TA AC
R437 RBLN-0056TAZZ Balun, BLN-0056TA AC
R438 RBLN-0056TAZZ Balun, BLN-0056TA AC
R439 RBLN-0056TAZZ Balun, BLN-0056TA AC
R564 RBLN-0052TAZZ Balun, BLN-0052TA AC
R602 RBLN-0093GEZZ Balun, BLN-0093GE AB
R609 RBLN-0077TAZZ Balun, BLN-0077TA AB
R610 RBLN-0083GEZZ Balun, BLN-0083GE AB
R611 RBLN-0083GEZZ Balun, BLN-0083GE AB
R631 RBLN-0052TAZZ Balun, BLN-0052TA AC
R634 RBLN-0067CEZZ Balun, BLN-0067CE AC
R635 RBLN-0052TAZZ Balun, BLN-0052TA AC

Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
66
DV-L80S/W
DUNTK5945KE50
OPERATE PWB UNIT(Continued)
S4011 QSW-K0115GEZZ Switch, Return AC
S4012 QSW-K0115GEZZ Switch, Power AC
DUNTK6003KE51
LCD PWB UNIT
INTEGRATED CIRCUITS
IC1900 VHiLZ9GK21+-1 LZ9GK21+, AQ
LCD CTL Processor
IC1901 VHiNJM2107F-1 NJM2107F AE
IC1999 VHiSN1GU04C-1 SN1GU04C AD
TRANSISTOR
Q1900 VS2SC4738Y/-1 2SC4738Y AA
DIODES
D1900 VHDMA132K//-1 MA132K AA
D1901 VHDMA716///-1 MA716 AC
D1902 VHDHVU200A/-1 HVU200A AC
D1904 RH-EX1393CEZZ Zener, EX1393CE AB
COILS
L1901 VPAWM2R7J1R2N Peaking, 2.7µHAC
L1902 VPAWM2R7J1R2N Peaking, 2.7µHAC
L1903 VPAWM3R9J1R5N Peaking, 3.9µHAD
L1904 VPAWM1R8JR98N Peaking, 1.8µHAC
L1905 RCiLP0323TAZZ Coil, CiLP0323TA AD
L1906 RCiLP0323TAZZ Coil, CiLP0323TA AD
CONTROL
R1914 RVR-M7959TAZZ Variable Resistor AC
CAPACITORS
C1900 VCCCCY1HH101J 100p 50V Ceramic AA
C1901 VCKYCY1CB104K 0.1 16V Ceramic AB
C1902 VCKYCY1HB103K 0.01 50V Ceramic AA
C1903 VCKYCY1HB103K 0.01 50V Ceramic AA
C1904 VCKYCY1CB104K 0.1 16V Ceramic AB
C1905 VCKYCY1HB561K 560p 50V Ceramic AA
C1906 VCKYCY1CB104K 0.1 16V Ceramic AB
C1907 VCKYCY1CB104K 0.1 16V Ceramic AB
C1908 VCKYCY1CB104K 0.1 16V Ceramic AB
C1909 VCKYCY1HB561K 560p 50V Ceramic AA
C1910 VCSATA1AJ106M 10 10V Tantalum AC
C1911 VCSATA1AJ106M 10 10V Tantalum AC
C1912 VCKYCY1CB104K 0.1 16V Ceramic AB
C1913 VCCCCY1HH820J 82p 50V Ceramic AA
C1914 VCKYCY1CB104K 0.1 16V Ceramic AB
C1915 VCKYCY1CB104K 0.1 16V Ceramic AB
C1916 VCKYCY1CF224Z 0.22 16V Ceramic AA
C1917 VCKYCY1CB104K 0.1 16V Ceramic AB
C1918 VCKYCY1CB104K 0.1 16V Ceramic AB
C1919 VCKYCY1CB104K 0.1 16V Ceramic AB
C1920 VCCCCY1HH330J 33p 50V Ceramic AA
C1921 VCCCCY1HH101J 100p 50V Ceramic AA
C1922 VCCCCY1HH101J 100p 50V Ceramic AA
C1923 VCCCCY1HH101J 100p 50V Ceramic AA
C1924 VCCCCY1HH101J 100p 50V Ceramic AA
C1925 VCCCCY1HH101J 100p 50V Ceramic AA
C1926 VCCCCY1HH101J 100p 50V Ceramic AA
C1927 VCKYCY1CB104K 0.1 16V Ceramic AB
C1928 VCCCCY1HH101J 100p 50V Ceramic AA
C1929 VCKYCY1CB104K 0.1 16V Ceramic AB
C1930 VCCCCY1HH101J 100p 50V Ceramic AA
C1931 VCKYCY1CB104K 0.1 16V Ceramic AB
C1933 VCKYCY1CB104K 0.1 16V Ceramic AB
C1934 VCKYCY1AF105Z 1 10V Ceramic AC
C1935 VCCCCY1HH220J 22p 50V Ceramic AA
C1936 VCCCCY1HH220J 22p 50V Ceramic AA
C1937 VCKYCY1HB102K 1000p 50V Ceramic AA
C1938 VCKYCY1HB561K 560p 50V Ceramic AA
C1939 VCKYCY1CB104K 0.1 16V Ceramic AB
C1940 VCKYCY1CB104K 0.1 16V Ceramic AB
C1941 VCKYCY1CB104K 0.1 16V Ceramic AB
C1942 VCCCCY1HH6R0D 6p 50V Ceramic AA
C1943 VCKYCY1CB104K 0.1 16V Ceramic AB
C1945 VCCCCY1HH100D 10p 50V Ceramic AA
C1946 VCCCCY1HH221J 220p 50V Ceramic AA
C1947 VCKYCY1HB102K 1000p 50V Ceramic AA
C1948 VCKYCY1AF105Z 1 10V Ceramic AC
C1949 VCCCCY1HH121J 120p 50V Ceramic AA
C1950 VCKYCY1CB104K 0.1 16V Ceramic AB
C1951 VCKYCY1EF104Z 0.1 25V Ceramic AA
C1952 VCKYCY1AF105Z 1 10V Ceramic AC
C1953 VCKYCY1AF105Z 1 10V Ceramic AC
C1954 VCKYCY1CB104K 0.1 16V Ceramic AB
C1955 VCEAEA1HW225M 2.2 50V Electrolytic AB
C1956 VCKYCY1CB104K 0.1 16V Ceramic AB
C1958 VCCCCY1HH330J 33p 50V Ceramic AA
C1959 VCSATA1EJ105M 1 25V Tantalum AC
C1960 RC-KZ0069TAZZ 10 35V Ceramic AE
C1961 RC-KZ0069TAZZ 10 35V Ceramic AE
C1962 RC-KZ0069TAZZ 10 35V Ceramic AE
C1966 VCKYCY1HF103Z 0.01 50V Ceramic AA
RESISTORS
R1900 VRS-CY1JF561J 560 1/16W Metal Oxide AA
R1901 VRS-CY1JF561J 560 1/16W Metal Oxide AA
R1903 VRS-CY1JF561J 560 1/16W Metal Oxide AA
R1906 VRS-CY1JF561J 560 1/16W Metal Oxide AA
R1907 VRS-CY1JF561J 560 1/16W Metal Oxide AA
R1908 VRS-CY1JF561J 560 1/16W Metal Oxide AA
R1909 VRS-CY1JF561J 560 1/16W Metal Oxide AA
R1910 VRS-CY1JF561J 560 1/16W Metal Oxide AA
R1911 VRS-CY1JF561J 560 1/16W Metal Oxide AA
R1912 VRS-CY1JF561J 560 1/16W Metal Oxide AA
R1913 VRS-CY1JF561J 560 1/16W Metal Oxide AA
R1915 VRS-CY1JF224J 220k 1/16W Metal Oxide AA
R1917 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R1918 VRS-CY1JF105J 1M 1/16W Metal Oxide AA
R1919 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R1921 VRS-CY1JF391J 390 1/16W Metal Oxide AA
R1922 VRS-CY1JF562F 5.6k 1/16W Metal Oxide AA
R1923 VRS-CY1JF473J 47k 1/16W Metal Oxide AA
R1924 VRS-CY1JF392J 3.9k 1/16W Metal Oxide AA
R1925 VRS-CY1JF683J 68k 1/16W Metal Oxide AA
R1926 VRS-CY1JF273J 27k 1/16W Metal Oxide AA
R1927 VRS-CY1JF683J 68k 1/16W Metal Oxide AA
R1928 VRS-CY1JF105J 1M 1/16W Metal Oxide AA
R1929 VRS-CY1JF564J 560k 1/16W Metal Oxide AA
R1930 VRS-CY1JF564J 560k 1/16W Metal Oxide AA
R1931 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R1932 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R1936 VRS-CY1JF272J 2.7k 1/16W Metal Oxide AA
R1937 VRS-CY1JF332J 3.3k 1/16W Metal Oxide AA
R1938 VRS-CY1JF101J 100 1/16W Metal Oxide AA
R1939 VRS-CY1JF331J 330 1/16W Metal Oxide AA
R1941 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R1943 VRS-CY1JF273J 27k 1/16W Metal Oxide AA
R1944 VRS-CY1JF333J 33k 1/16W Metal Oxide AA
R1945 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R1946 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R1947 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R1953 VRS-CY1JF122J 1.2k 1/16W Metal Oxide AA
R1955 VRS-CY1JF222J 2.2k 1/16W Metal Oxide AA
R1956 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R1957 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R1959 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R1961 VRS-CY1JF000J 0 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
CN1900 QSOCN3271TAZZ Socket, 32Pin AE
CN1901 QSOCN0672TAZZ Socket, 6Pin AC

Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
67
DV-L80S/W
CN1902 QPLGN1376TAZZ Plug, 13Pin AF
CN1903 QPLGN1076TAZZ Plug, 10Pin AE
CN1904 QPLGN1276TAZZ Plug, 12Pin AF
P1804 QPLGN0263TAZZ Plug, 2Pin AB
P1805 QPLGN0263TAZZ Plug, 2Pin AB
DUNTK5949KE51
CHARGE PWB UNIT
DIODE
D9801 VHDSC0162//-1 SC0162 AC
COIL
L9801 RCiLF0318GEZZ Coil, CiLF0318GE AG
CAPACITORS
C9801 VCKYTV1EB104K 0.1 25V Ceramic AB
C9802 VCKYCY1HF473Z 0.047 50V Ceramic AA
RESISTOR
R9802 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
CN901 QPLGN0176FJZZ Plug, 4Pin AD
CN9981 QCNCM3058TAZZ Connector, 30Pin AF
åF901 QFS-L5021GEZZ Fuse, 5A AF
åF9801 QFS-L4021GEZZ Fuse, 4A AF
J9801 QJAKC0021GEZZ Jack, DC AD
DUNTK5948KE51
CONNECTOR PWB UNIT
INTEGRATED CIRCUIT
IC901 VHiMB3832AA-1 MB3832AA, AS
Li-ion Battery Chargers
TRANSISTORS
Q901 VSFW111////-1 FW111 AK
Q904 VSFW111////-1 FW111 AK
Q905 VSRN1904///-1 RN1904 AC
Q906 VSFW111////-1 FW111 AK
Q907 VSDTC144EE/-1 DTC144EE AA
Q908 VSFTS1002++-1 FTS1002++ AF
Q909 VSCPH3303//-1 CPH3303 AD
Q910 VSRN1904///-1 RN1904 AC
Q911 VS3LN01S///-1 3LN01S AC
Q912 VS3LN01S///-1 3LN01S AC
Q913 VS3LN01S///-1 3LN01S AC
DIODES
D901 VHDDAN222//-1 DAN222 AA
D902 VHDDAN222//-1 DAN222 AA
D904 RH-EX1400CEZZ Zener, EX1400CE AB
D905 VHDDAN222//-1 DAN222 AA
D906 VHDF1J3E+++-1 F1J3E+++ AE
D909 VHDDAN222//-1 DAN222 AA
D910 VHDMA132K//-1 MA132K AA
COILS
L901 RCiLP0162GEZZ Coil, CiLP0162GE AF
L902 RCiLP0162GEZZ Coil, CiLP0162GE AF
CAPACITORS
C901 VCEAPF1CW107M 100 16V Electrolytic AD
C902 VCKYTV1EB104K 0.1 25V Ceramic AB
C903 VCEAPF1CW107M 100 16V Electrolytic AD
DUNTK6003KE51
LCD PWB UNIT(Continued) C904 VCKYCY1CB104K 0.1 16V Ceramic AB
C905 VCKYCY1CB104K 0.1 16V Ceramic AB
C906 RC-KZ0075TAZZ 2.2 16V Ceramic AC
C907 VCCCCY1HH391J 390p 50V Ceramic AA
C908 VCKYTV1CB224K 0.22 16V Ceramic AB
C909 VCKYTV1CB224K 0.22 16V Ceramic AB
C910 VCKYCY1CB104K 0.1 16V Ceramic AB
C911 VCKYCY1CB333K 0.033 16V Ceramic AA
C912 VCEAPF1CW107M 100 16V Electrolytic AD
C913 VCKYCY1HB102K 1000p 50V Ceramic AA
C914 VCEAPF1CW226M 22 16V Electrolytic AB
C917 RC-KZ0069TAZZ 10 16V Ceramic AE
C918 VCEAPF0JW107M 100 6.3V Electrolytic AC
C919 RC-KZ0085TAZZ 10 35V Ceramic AF
RESISTORS
R901 VRS-CY1JF105J 1M 1/16W Metal Oxide AA
R902 VRS-CY1JF105J 1M 1/16W Metal Oxide AA
R903 VRS-CY1JF123J 12k 1/16W Metal Oxide AA
R904 VRS-CY1JF123J 12k 1/16W Metal Oxide AA
R906 VRS-CY1JF154J 150k 1/16W Metal Oxide AA
R907 VRS-CY1JF105J 1M 1/16W Metal Oxide AA
R909 VRS-CY1JF105J 1M 1/16W Metal Oxide AA
R910 VRS-CY1JF105J 1M 1/16W Metal Oxide AA
R911 VRS-CY1JF105J 1M 1/16W Metal Oxide AA
R912 VRN-TV2EFR10F 0.1 1/4W Metal Film AC
R914 VRS-CY1JF105J 1M 1/16W Metal Oxide AA
R915 VRS-CY1JF100J 10 1/16W Metal Oxide AA
R916 VRS-CY1JF103F 10k 1/16W Metal Oxide AA
R917 VRS-CY1JF123J 12k 1/16W Metal Oxide AA
R918 VRS-CY1JF102J 1k 1/16W Metal Oxide AA
R919 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R920 VRS-CY1JF474J 470k 1/16W Metal Oxide AA
R921 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R922 VRS-CY1JF512J 5.1k 1/16W Metal Oxide AA
R923 VRS-CY1JF153F 15k 1/16W Metal Oxide AA
R924 VRS-CY1JF682F 6.8k 1/16W Metal Oxide AA
R925 VRS-CY1JF333J 33k 1/16W Metal Oxide AA
R926 VRS-CY1JF392J 3.9k 1/16W Metal Oxide AA
R927 VRS-CY1JF123F 12k 1/16W Metal Oxide AA
R928 VRS-CY1JF102F 1k 1/16W Metal Oxide AA
R929 VRS-CY1JF564J 560k 1/16W Metal Oxide AA
R930 VRS-CY1JF564J 560k 1/16W Metal Oxide AA
R931 VRS-CY1JF104J 100k 1/16W Metal Oxide AA
R932 VRS-CY1JF223J 22k 1/16W Metal Oxide AA
R933 VRS-CY1JF103J 10k 1/16W Metal Oxide AA
R939 VRS-CY1JF561J 560 1/16W Metal Oxide AA
R940 VRN-TV2EFR10F 0.1 1/4W Metal Film AC
R941 VRS-CY1JF393F 39k 1/16W Metal Oxide AA
R943 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R946 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R947 VRS-CY1JF000J 0 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
CN902 QSOCN0972TAZZ Socket, 9Pin AC
CN903 QSOCN2072TAZZ Socket, 20Pin AD
CN904 QCNCW3089TAZZ Connector, 30Pin AF

Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
68
DV-L80S/W
CABINET PARTS
1 CCABA3150GE01 Cabinet A Ass’y BG
1-2 GFTAT0103GEKA Disc Lid AQ
1-3 HBDGS0102GESA DVD Badge AD
1-4 HDECP0267GESA D Panel AK
1-5 HDECQ2264GESA A/C Window AE
1-6 JBTN-3075GESA Eject Button AG
1-7 LHLDZ2148GEZZ Damper Holder AD
1-8 LX-HZ0030TAFF Screw AA
1-9 MLEVP0335GEZZ D. Cover Lock AD
1-10 MSPRC0250GEZZ Lock Spring 2 AC
1-11 MSPRD0199GEZZ Lock Spring AD
1-12 MSPRD0200GEZZ Up Spring AE
1-13 NSFTT0190GEZZ D. Cover Shaft AD
1-14 PDMP-0033GEZZ Damper AE
1-15 PZETK0016GEZZ Cover AA
1-16 XiPSN20P04000 Screw AA
1-17 GCOVA0111GESA Jack Cover 2 AF
2 CCABB3003GE02 Cabinet B Ass’y BD
2-2 GLEGM9000GEZZ Stand AF
2-3 LHLDZ2147GEZZ Stand Holder AD
2-4 PGUMM0059GEZZ Stopper Rubber AB
2-5 PZETK0013GEZZ Insulate AG
2-6 PZETK0014GEZZ Insulate Small AB
2-7 GCOVA0110GESA Jack Cover 1 AF
3 CCABC1009GE01 Cabinet C Ass’y AX
4 GCABD1009GEKA Cabinet D(L80S) AX
4 GCABD1012GEKA Cabinet D(L80W) AX
5 LANGT9194GEZZ LCD Fixing Angle AC
6 LX-HZ3094CEFD Screw AA
7 MHNG-3022GEZZ Hinge L AM
8 MHNG-3023GEZZ Hinge R AG
9 MLEVP0334GEZZ LCD Lock Lever AD
10 MSPRC0247GEZZ Lock Lever Spring AB
11 PCAPH0102GEZZ LCD Rubber Cap AB
12 PCOVW0104GEZZ Insulate Sheet AC
13 PSPAZ0622GEZZ Spacer AC
14 VSP0028PB438N Speaker AN
16 HDECQ2263GESA R/C Window AE
17 JBTN-3076GESA Button AK
18 JBTN-3077GESA Cross Key AK
19 JBTN-3105GESA Decision Key AK
20 CANGT9193GE01 Angle Ass’y AG
21 LX-HZ0018TAZZ Screw AA
22 XiPSD20P03000 Screw AA
28 TLABM4447GEZZ Serial Label(L80S) AE
28 TLABM4468GEZZ Serial Label(L80W) AE
28 TLABM4469GEZZ Serial Label(L80WA) AE
28 TLABM4470GEZZ Serial Label(L80WX) AE
29 XiPSN20P04000 Screw AA
31 QCNW-8081GEZZ Sled Harness AE
32 DUNTK5945KE50 Operate PWB Unit —
33 RUNTK0821GEZZ Inverter Unit BB
34 QTANZ0007GEZZ Battery Connection TerminalAM
35 RLCDT0002GEZZ Back Light Module CR
(Panel Include)
36 DUNTK6002KE51 Main PWB Unit —
37 DUNTK6003KE51 LCD PWB Unit —
38 DUNTK5949KE51 Charge PWB Unit —
39 DUNTK5948KE51 Connector PWB Unit —
40 QCNW-8367GEZZ Spin FFC AD
41 QCNW-8368GEZZ Main-Operation FFC AE
42 QCNW-8369GEZZ Main-Charge FFC 2 AE
43 QCNW-8370GEZZ LCD-Inverter FFC AE
44 QCNW-8371GEZZ Main-Charge FFC 1 AE
45 QCNW-8372GEZZ Main-LCD Harness AL
46 QCNW-8373GEZZ Main-LCD Harness AK
47 QCNW-8374GEZZ Main-LCD Harness AK
SUPPLIED ACCESSORIES
åQACCB0016TAZZ AC Cord(L80S/W) AV
åQACCK0002TAZZ AC Cord(L80WA) AM
åQACCL0020TAZZ AC Cord(L80WX) AP
QCNW-8340GEZZ S-Video/Video Cord AS
QCNW-8341GEZZ Audio Cord AP
QCNW-8550GEZZ Audio Cord x2(L80S/WX)
RPHOH0001GEZZ Earphones AR
RRMCG1282GESA Remote Control Unit AQ
TiNS-3922GEZZ Quick Start Guide(L80S) AQ
TiNS-3766GEZZ Operation Manual AF
TiNS-3920GEZZ Operation Manual AZ
(DEUTSCH)(L80S)
TiNS-3921GEZZ Operation Manual AZ
(ENGLISH)(L80S)
TiNS-3930GEZZ Operation Manual AX
(L80W/WA/WX)
åUADP-0213GEZZ AC Adapter BC
UBATL0011TAZZ Lithium Battery AE
MECHANISM PARTS
1 DMECD0004GE03 Mechanism Ass'y BQ
2 NSFTD0063GEZZ Main Guide AH
3 LHLDZ2070GEZZ Sled Unit AD
4 NGERH1328GEZZ Intermediate Gear AC
5 RMOTV1037GEZZ Sled Motor AN
6 MSPRP0199GEZZ Grip Spring AC
7 PCUSG0013GEZZ Insulator AC
8 PCOVP3021GEZZ PU Cover AF
9 LX-WZ1053GE00 Cut Washer AA
10 QCNW-8367GEZZ Spindle Motor FFC AD
11 XAPSF17P03000 Screw M1.7 X L3 AA
12 XAPSN17P06000 Screw M1.7 X L6 Ni PlatingAB
13 LX-BZ3220GEZZ Screw M1.2 X L2.7 AB
14 NGERH1327GEZZ Main Guide Gear AC
15 NGERH1329GEZZ Motor Pinion AC
16 QCNW-8081GEZZ Sled Lead Wire AE
17 MSPRP1217GEZZ Earth Spring AD
PACKING PARTS
(NOT REPLACEMENT ITEM)
SPAKC4568GEZZ Packing Case —
(L80W/WA/WX)
SPAKC4578GEZZ Packing Case(L80S) —
SPAKF0220GEZZ Packing Material —
SPAKF0237GEZZ Packing Material(L80S) —
SPAKP0195GEZZ Polyethylene Bag —
SPAKP0196GEZZ Polyethylene Bag —
SPAKX1100GEZZ Packing Add. —
SPAKX1101GEZZ Packing Add. —
SSAKA0100TAZZ Polyetylene Bag, —
Accessories(L80W/WA/WX)
SSAKA0170CEZZ Polyetylene Bag, —
Accessories(L80S)
SPAKL0047CEZZ Stopper —

Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
69
DV-L80S/W
MECHANISM EXPLODED VIEW
A
B
C
D
E
F
G
H
123456
15 5
*1
*2
*2
7
5
15 16
3
13
4
9
14
2
10
12
17
8
6
11
7
7
When replacement or a
djustment of the parts in
this frame is necessary,
replace or adjust the
mechanism ass'y
(adjustment of the parts
is completed).
[Notes]
*1. When soldering the sled lead wire y,
it must be made in a soldering iron tip
temperature of 290±20˚C and within 3
seconds.
*2. Press-fit dimension of motor pinion t.
5.4±0.1
1

Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
70
DV-L80S/W
CABINET EXPLODED VIEW
A
B
C
D
E
F
G
H
123456
M
L
N
G
H
D
JI
K
L
M
N
G
(J)
(K)
(I)
E
P
E
IJK
F
A
C
F
C
B
A
H
D
21
3
9
10 38
39
31
42
36
29
29
29
29
34
7
2-3
2-7
2-2
29
16
2-6
2-4
29
28
29
846
47
1-5
18
19
32
41
20
12
22
17
1-12 1-131-14 1-7
1-16
1-8
1-3
1-2
1-6
1-9
1-10
1-11
33
13
6
6
14
37
5
5
6
43
14
6
4
11
35
21
2-5
45
40
P
44
1-17
1-4
1-15
