-1
Important
Information
IMPORTANT
For your assistance in reporting the loss or theft of your
Projector, please record the Serial Number located on
the bottom of the projector and retain this information.
Before recycling the packaging, please be sure that
you have checked the contents of the carton thoroughly
against the list of “Supplied Accessories” on page 11.
Before using the projector, please read this operation manual carefully.
OPERATION MANUAL ENGLISH
Model No.: XV-Z91E
Serial No.:
ENGLISH
WARNING:
To reduce the risk of fire or electric shock, do not expose this product to rain or moisture.
WARNING:
Intense light source. Do not look into the beam or view it directly. Be especially careful that children do not look
directly into the beam.
CAUTION:
To reduce the risk of electric shock, do not remove cabinet. No user-serviceable parts are inside. Refer servicing
to qualified service personnel.
WARNING:
The cooling fan in this projector continues to run for about 90 seconds after the projector is turned off. During
normal operation, when turning the power off always use the OFF button on the projector or on the remote
control. Ensure the cooling fan has stopped before disconnecting the power cord.
DURING NORMAL OPERATION, NEVER TURN THE PROJECTOR OFF BY DISCONNECTING THE POWER
CORD. FAILURE TO OBSERVE THIS WILL RESULT IN PREMATURE LAMP FAILURE.
Downloaded From projector-manual.com Sharp Manuals
-3
Important
Information
IMPORTANT SAFEGUARDS
ATTENTION: Please read all of these instructions before you operate your Projector for
the first time. Save these instructions for future reference.
“
”
—
—
Downloaded From projector-manual.com Sharp Manuals
-5
Important
Information
IMPORTANT SAFEGUARDS
Temperature Monitor Function
“ ” “ ”
“ ”
•
Lamp Monitor Function
“ ” “ ”
“ ”
Using the Terminal Cover
Attaching the Terminal Cover
Removing the Terminal Cover
Downloaded From projector-manual.com Sharp Manuals
-7
Important
Information
Outstanding Features
1. DMD™*1(Digital Micromirror Device) Chip
2. Five Speed Primary Colour Wheel
3. Advanced Video Circuitry
4. Low Noise Design
5. Lens Shift Function
6. 2D Keystone Correction
7. For use with DTV*2
8. Easy-to-use Graphical User Interface (GUI)
9. Colour Temperature Adjustment
10. Gamma Correction Function
11. Picture Setting Function
PICTURE SETTING
12. Component Video Input
13. Direct Computer Compatibility
Downloaded From projector-manual.com Sharp Manuals
-13
Setup & Connections
Projector
VCR, Laser disc player,
DVD player or DTV decoder
Connecting to Video Equipment
Connecting to a DVD Player and DTV Decoder
DVD player
or
DTV decoder
CAUTION
•
Projector
Connecting to a DVD player and DTV decoder with Component output (for INPUT 1)
Connecting to a DVD player and DTV decoder with component output (for INPUT 2)
“ ” “ ”
RGB/COMP.
CAUTION
•
Projector
DVD player
or
DTV decoder
Downloaded From projector-manual.com Sharp Manuals
-15
Setup & Connections
Operating the Remote Control
The remote control can be used to control the projec-
tor within the range shown on the left.
• The signal from the remote control can be reflected off a
screen for easy operation. However, the effective distance
of the signal may differ due to the screen material.
Remote Control
Remote Control
˚˚
˚
˚
˚
Using the remote control in a dark
room
LIGHT
LIGHT
Connecting a computer with RGB output
•
CAUTION
•
• “ ”
•
•
•
Connecting to a Computer
Downloaded From projector-manual.com Sharp Manuals
-17
Setup & Connections
Using the Swivel Stand
Setting Up the Screen
CAUTION
•
•
•
Removing the Swivel Stand
Attaching the Swivel Stand
°
°
°
Downloaded From projector-manual.com Sharp Manuals
-19
Setup & Connections
Keystone Correction
•
Description of 2D Keystone Correction
Selected item Description
Horizontal Keystone Correction
Vertical Keystone Correction
KEYSTONE
“ ” “
”
KEYSTONE
•
• “ ” “ ”
• “ ” “ ”
Downloaded From projector-manual.com Sharp Manuals
-21
Setup & Connections
Adjusting the Projection Distance
•
•
•
•
“ ” “ ”
•
•
•
When using a
normal screen (4:3)
When using a wide
screen (16:9)
– – – – –
Downloaded From projector-manual.com Sharp Manuals
-23
Setup & Connections
Rear Projection
•
• ’
•
Projection Using a Mirror
•
•
•
•
CAUTION
•
•
•
•
•
• ’
Ceiling-mount Projection
Image Projection
Downloaded From projector-manual.com Sharp Manuals
-25
Operation Buttons
Adjusting the Picture Aspect Ratio
Downloaded From projector-manual.com Sharp Manuals

-2
Important
Information
LAMP REPLACEMENT
BEFORE REMOVING THE SCREW, DISCONNECT POWER CORD.
HOT SURFACE INSIDE. ALLOW 1 HOUR TO COOL BEFORE
REPLACING THE LAMP. REPLACE WITH SAME SHARP LAMP
UNIT TYPE BQC-XVZ90+++1 ONLY. UV RADIATION : CAN CAUSE
EYE DAMAGE. TURN OFF LAMP BEFORE SERVICING.
MEDIUM PRESSURE LAMP : RISK OF EXPLOSION.
POTENTIAL HAZARD OF GLASS PARTICLES IF LAMP HAS
RUPTURED. HANDLE WITH CARE. SEE OPERATION MANUAL.
DU REMPLACEMENT DE LA LAMPE.
PRECAUTIONS A OBSERVER LORS
DEBRANCHER LE CORDON D’ALIMENTATION AVANT DE RETIRER LES VIS.
L’INTERIEUR DU BOITIER ETANT EXTREMEMENT CHAUD, ATTENDRE
1 HEURE AVANT DE PROCEDER AU REMPLACEMENT DE LA LAMPE.
NE REMPLACER QUE PAR UNE LAMPE SHARP DE TYPE BQC-XVZ90+++1.
RAYONS ULTRAVIOLETS : PEUVENT ENDOMMAGER LES YEUX.
ETEINDRE LA LAMPE AVANT DE PROCEDER A L’ENTRETIEN.
LAMPE A MOYENNE PRESSION: RISQUE D’EXPLOSION.
DANGERPOTENTIEL DE PARTICULES DE VERRE EN CAS D’ECLATEMENT DE LA LAMPE.
A MANIPULER AVEC PRECAUTION, SE REPORTER AU MODE D’EMPLOI.
CAUTION
Caution Concerning the Lamp Replacement
There is potential glass particles hazard if the lamp ruptures.
WARNING:
Some IC chips in this product include confidential and/or trade secret property belonging to Texas Instruments.
Therefore you may not copy, modify, adapt, translate, distribute, reverse engineer, reverse assemble or discompile
the contents thereof.
ENGLISH
Downloaded From projector-manual.com Sharp Manuals
-4
Important
Information
IMPORTANT SAFEGUARDS
Ó
É
Caution Concerning the Lamp Unit
There is a potential hazard of glass particles if the lamp ruptures. In case of
lamp rupture, contact your nearest Sharp Authorised Projector Dealer or
Service Centre for a replacement.
See Replacing the Lamp on page 46.
Cautions Concerning the Setup of the Projector
For minimal servicing and to maintain high image quality, SHARP recommends
that this projector be installed in an area free from humidity, dust and cigarette
smoke. When the projector is subjected to these environments, the lens and
part of filter must be cleaned more often than usual. As long as the projector
is properly maintained in this manner, use in these environments will not reduce
the overall operation life. Please note that all internal cleaning must be
performed by a Sharp Authorised Projector Dealer or Service Centre.
Do not expose the projector to extreme heat or cold.
Operating temperature: +5 C to +35 C
Storage temperature: 20 C to +60 C
Notes on Operation
The exhaust ventilative hole, the lamp cage cover and adjacent areas may
get extremely hot during projector operation. To prevent injury, do not touch
these areas until they have sufficiently cooled down.
Allow at least 30 cm of space between the exhaust ventilative hole and the
nearest wall or obstruction.
If the cooling fan becomes obstructed, a protection device will automatically
turn off the projector lamp. This does not indicate a malfunction. Remove
the projector power cord from the wall outlet and wait at least 10 minutes.
Then turn on the power by plugging the power cord back in. This will return
the projector to the normal operating condition.
This caution is found at the bottom of the projector. See Caution Concerning the Lamp Replacement
on page 2 for its location.
WARNING: High brightness light source. Do not stare into the beam of light, or view directly. Be especially careful that
children do not stare directly into the beam of light.
Downloaded From projector-manual.com Sharp Manuals
-6
Important
Information
Contents
Important Information
IMPORTANT SAFEGUARDS ................... 3
Contents................................................... 6
Outstanding Features ............................. 7
Part Names .............................................. 8
Supplied Accessories ............................. 11
Connections ............................................ 12
Power Supply ............................................ 12
Connecting to Video Equipment ............... 12
Connecting to a DVD Player and
DTV Decoder ....................................... 13
Connecting to a Computer ........................ 14
Operating the Remote Control .................. 15
Power ON/OFF .......................................... 16
Zooming and Focusing ............................. 16
Setting Up the Screen ............................. 17
Using the Swivel Stand .............................. 17
Using the Lens Shift .................................. 18
Keystone Correction .................................. 19
Placement of the Projected Image
Using the Keystone Correction ............ 20
Adjusting the Projection Distance ............. 21
Image Projection ..................................... 23
Rear Projection .......................................... 23
Projection Using a Mirror ........................... 23
Ceiling-mount Projection ........................... 23
Setup & Connections Operation Buttons Basic Operation
Maintenance &
Troubleshooting Appendix
Using the Operation Buttons ................. 24
Selecting the Input Signal Source ............. 24
Adjusting the Picture Aspect Ratio............ 24
Using the Menu Screen .......................... 26
Basic Operations ....................................... 26
Menu Bars ................................................. 27
Adjusting the Picture ................................. 29
Adjusting the Computer and
DVD/DTV Images ................................. 33
Lamp/Maintenance Indicators ................ 44
Lamp Maintenance .................................. 45
Confirming the Lamp Usage Time ............ 45
Replacing the Lamp .................................. 46
Cleaning the Ventilative Holes ............... 49
Using the Kensington Lock .................... 50
Troubleshooting ...................................... 50
Connecting Pin Assignments ................ 51
(RS-232C) Specifications
and Command Settings ..................... 52
Computer Compatibility Chart ............... 54
Dimensions .............................................. 55
Specifications .......................................... 56
Glossary ................................................... 57
Index ......................................................... 58
Turning On/Off the On-screen Display ...... 36
Selecting the Signal Type .......................... 36
Setting the Video Signal
(VIDEO menu only) .............................. 37
Selecting a Background Image ................. 37
Adjustments for the Screen Position
and Size ............................................... 38
Selecting the Menu Screen Position.......... 40
Selecting the Menu Colour ........................ 40
Automatic Power Shut-off Function ........... 41
Reversing/Inverting Projected Images ...... 42
Selecting the On-screen
Display Language ................................ 42
Advanced Picture Adjustment ................... 43
Operation Buttons
Setup &
Connections
Basic Operation
Maintenance &
Troubleshooting
Appendix
Downloaded From projector-manual.com Sharp Manuals

-1
Important
Information
IMPORTANT
For your assistance in reporting the loss or theft of your
Projector, please record the Serial Number located on
the bottom of the projector and retain this information.
Before recycling the packaging, please be sure that
you have checked the contents of the carton thoroughly
against the list of “Supplied Accessories” on page 11.
Before using the projector, please read this operation manual carefully.
OPERATION MANUAL ENGLISH
Model No.: XV-Z91E
Serial No.:
ENGLISH
WARNING:
To reduce the risk of fire or electric shock, do not expose this product to rain or moisture.
WARNING:
Intense light source. Do not look into the beam or view it directly. Be especially careful that children do not look
directly into the beam.
CAUTION:
To reduce the risk of electric shock, do not remove cabinet. No user-serviceable parts are inside. Refer servicing
to qualified service personnel.
WARNING:
The cooling fan in this projector continues to run for about 90 seconds after the projector is turned off. During
normal operation, when turning the power off always use the OFF button on the projector or on the remote
control. Ensure the cooling fan has stopped before disconnecting the power cord.
DURING NORMAL OPERATION, NEVER TURN THE PROJECTOR OFF BY DISCONNECTING THE POWER
CORD. FAILURE TO OBSERVE THIS WILL RESULT IN PREMATURE LAMP FAILURE.
Downloaded From projector-manual.com Sharp Manuals
-3
Important
Information
IMPORTANT SAFEGUARDS
ATTENTION: Please read all of these instructions before you operate your Projector for
the first time. Save these instructions for future reference.
For your own protection and prolonged operation of your Projector, be sure to read the following “IMPORTANT
SAFEGUARDS”carefully, before use.
This projector has been engineered and manufactured to ensure your personal safety. But IMPROPER USE CAN
RESULT IN POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARDS. In order not to defeat the safeguards
incorporated into this Projector, observe the following basic rules for its installation, use and servicing.
17. Unplug the Projector equipment from the wall outlet and
refer servicing to qualified service personnel under the
following conditions:
a. When the power cord or plug is damaged or frayed.
b. If liquid has been spilled into the Projector.
c. If the Projector has been exposed to rain or water.
d. If the Projector does not operate normally when
you follow the operating instructions. Adjust only
those controls that are covered by the operating
instructions, as improper adjustment of other
controls may cause damage and will often require
extensive work by a qualified technician to restore
the Projector to normal operation.
e. If the Projector has been dropped or the cabinet
has been damaged.
f. When the Projector exhibits a distinct change in
performance—this indicates a need for service.
18. When replacement parts are required, be sure the ser-
vice technician has used replacement parts specified by
the manufacturer that have the same characteristics as
the original parts. Unauthorised substitutions may result
in fire, electric shock, or other hazards.
19. This Projector is provided with one of the following types
of plugs. If the plug should fail to fit into the power outlet,
please contact your electrician.
Do not defeat the safety purpose of the plug.
a. Two-wire type mains plug.
b. Three-wire grounding type mains plug with a
grounding terminal.
This plug will only fit into a grounding type power
outlet.
1. Unplug the Projector from the wall outlet before cleaning.
2. Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.
3. Do not use attachments not recommended by the
Projector manufacturer, as they may cause hazards.
4. Do not use the Projector near water; for example, near a
bathtub, washbowl, kitchen sink, laundry tub, in a wet
basement, near a swimming pool, etc. Never spill liquid
into the projector.
5. Do not place the Projector on an unstable cart, stand, or
table. The Projector may fall, which may cause serious
injury to a child or an adult, and/or serious damage to the
unit.
6. Wall or Ceiling Mounting—The product should be
mounted to a wall or ceiling only as recommended by
the manufacturer.
7. Projector equipment and cart
combinations should be moved
with care. Quick stops, excessive
force, and uneven surfaces may
cause the equipment and cart
combination to overturn.
8. Slots and openings in the cabinet back and bottom are
provided for ventilation. To ensure reliable operation of
the Projector and to protect it from overheating, these
openings must not be blocked or covered. The openings
should never be covered with cloth or other material.
9. This Projector should never be placed near or over a
radiator or heating vent. The Projector should not be
placed in a built-in installation such as a bookcase unless
proper ventilation is provided.
10. The Projector should be operated only from the type of
power source indicated on the back of the projector or in
the specifications. If you are not sure of the type of power
supplied to your home, consult your Projector dealer or
local power company.
11. Do not place the Projector where the cord will be abused
by persons walking on it.
12. Follow all warnings and instructions marked on the
Projector.
13. To prevent damage to the projector due to lightning and
power-line surges, unplug the projector from the power
outlet, when not in use.
14. Do not overload wall outlets and extension cords with too
many products, because this can result in fire or electric
shock.
15. Never push objects of any kind into the Projector through
the cabinet slots as they may touch high-voltage points
or cause a short circuit. This could result in a fire or electric
shock.
16. Do not attempt to service the Projector yourself. Opening
or removing covers may expose you to dangerous voltage
or other hazards. Refer all servicing to qualified service
personnel.
Downloaded From projector-manual.com Sharp Manuals
-5
Important
Information
IMPORTANT SAFEGUARDS
Temperature Monitor Function
If the projector starts to overheat due to setup problems, “TEMP.”and “ ”
will blink in the lower-left corner of the picture. If the temperature continues to
rise, the lamp will turn off, the TEMPERATURE WARNING indicator on the
projector will blink, and after a 90-second cooling-off period the power will
shut off. Refer to “Lamp/Maintenance Indicators”on page 44 for details.
•The cooling fan regulates the internal temperature, and its performance is
automatically controlled. The sound of the fan may change during projector
operation due to changes in the fan speed.
Lamp Monitor Function
When the projector is turned on after the lamp has been used for 2,400 hours,
“LAMP”and “”will blink in the lower-left corner of the picture to advise you
to replace the lamp. See page 46 for lamp replacement. If the lamp has been
used for 2,500 hours, the projector power will automatically turn off and the
projector will enter standby mode. Refer to “Lamp/Maintenance Indicators”
on page 44 for details.
Using the Terminal Cover
When the projector is used on a desktop, high mounted or ceiling mounted,
attach the terminal cover (supplied) to hide the connecting cables.
Attaching the Terminal Cover
Align with the tabs on the projector and then press the terminal cover in
the direction of the arrow.
Tighten the two screws on the bottom of the projector.
Removing the Terminal Cover
Loosen the two screws on the bottom of the projector.
Raise the terminal cover and pull it out in the direction of the arrow.
Tighten the screws
Loosen the screws
Downloaded From projector-manual.com Sharp Manuals
-7
Important
Information
Outstanding Features
1. DMD™*1(Digital Micromirror Device) Chip
The DMD Chip allows for a higher contrast image. It enables smoother expression of details of an image,
and high picture quality for an exciting theatre experience.
*1Digital Light Processing, DLP, Digital Micromirror Device and DMD are trademarks of Texas Instruments.
2. Five Speed Primary Colour Wheel
The colour wheel consists of only the three primary colours of the light and creates a higher contrast image
with high colour purity.
3. Advanced Video Circuitry
The video circuit setup is designed for obtaining optimal images from audiovisual equipment. The circuit
optimizes high optical performance that originates in the DMD chip and the five speed primary colour
wheel, to realise outstanding video images.
4. Low Noise Design
A new optical engine has been developed for this product to minimise fan noise for undisturbed viewing.
5. Lens Shift Function
The digital shift function optically adjusts the vertical position of images. The function allows for simple
adjustment when setting up the projector for the first time.
6. 2D Keystone Correction
The 2D keystone correction function electrically corrects the size of projected images. The function
enables diagonal projection and the wider range settings.
7. For use with DTV*2
Allows projection of DTV images and 16:9 wide-screen images when connected to a DTV decoder or
similar video systems.
*2DTV is the umbrella term used to describe the new digital television system in the United States.
8. Easy-to-use Graphical User Interface (GUI)
A multi-colour menu system, which allows for simple image adjustments.
9. Colour Temperature Adjustment
The function can be used to adjust the colour temperature to suit the type of image input to the projector.
10. Gamma Correction Function
The gamma value setting can be adjusted according to the input source for optimal image contrast.
11. Picture Setting Function
The values in various adjustment settings can be stored. The function can be used to select the values to
suit the type of image input to the projector by pressing the PICTURE SETTING button on the projector or
on the remote control.
12. Component Video Input
Utilises a component video input signal (Y, PB, PR). The video signal is input as separate components to
provide superior colour and image quality.
13. Direct Computer Compatibility
A multi-scan RGB input accepts signals from VGA (640 dots 480 lines) and Macintosh (from 13" compatible
computers) without the need for any additional hardware.
Downloaded From projector-manual.com Sharp Manuals
-13
Setup & Connections




Projector
VCR, Laser disc player,
DVD player or DTV decoder
Connecting to Video Equipment
Connecting to a DVD Player and DTV Decoder


DVD player
or
DTV decoder


CAUTION
•
Projector
Connecting to a DVD player and DTV decoder with Component output (for INPUT 1)
Connecting to a DVD player and DTV decoder with component output (for INPUT 2)


“ ” “ ”
RGB/COMP.
CAUTION
•
Projector
DVD player
or
DTV decoder


Downloaded From projector-manual.com Sharp Manuals
-15
Setup & Connections
Operating the Remote Control
The remote control can be used to control the projec-
tor within the range shown on the left.
• The signal from the remote control can be reflected off a
screen for easy operation. However, the effective distance
of the signal may differ due to the screen material.
Remote Control
Remote Control
45˚
7 m
30˚
30˚
45˚
30˚
Using the remote control in a dark
room
The backlights of the operation buttons can be turned
on for five seconds and off by pressing LIGHT. If you
want to turn off the backlights while they are on, press
LIGHT again.
Connecting a computer with RGB output
Connect one of the computer-RGB cable to the INPUT 2 COMPONENT/RGB port on the projector.
Connect the other end to the Corresponding terminal on a computer.
•Make sure to turn both the projector and the video equipment off, before connecting.
Connect an RS-232C cable (null modem, cross type, commercially available) to the serial port on the computer.
CAUTION
•Do not connect or disconnect an RS-232C cable to or from the computer while it is on. This may damage your computer.
•Refer to “Computer Compatibility Chart”on page 54 for a list of computer signals compatible with the projector. Use with computer
signals other than those listed may cause some of the functions not to work.
•The RS-232C function may not operate if your computer port is not correctly set up. Please refer to the operation manual of the computer for
details.
•The arrows ( , ) in the configuration above indicate the direction of the signals.
•A Macintosh adaptor may be required for use with some Macintosh computers. Contact your nearest Sharp Authorised Projector Dealer or
Service Centre.
Connecting to a Computer
Computer-RGB cable
LIGHT button
Downloaded From projector-manual.com Sharp Manuals
-17
Setup & Connections
Using the Swivel Stand
Setting Up the Screen
You can adjust the angle and direction of the projected image by using
the Swivel Stand.
Unlock the lever on the Swivel Stand.
Adjust the angle and direction of the projected image as you want
by lifting up the projector and rotating the projector on the Swivel
Stand.
Lock the lever on the Swivel Stand.
CAUTION
•Do not hold the lens when lifting, lowering or rotating the projector.
•When lowering the projector, be careful not to get your fingers caught in the
area between the Swivel Stand and the projector.
•When the height or direction of the projector is adjusted, the image may become
distorted (keystoned), depending on the relative positions of the projector
and the screen. See page 19 for details on the keystone correction.
Removing the Swivel Stand
Lift the projector ( ) with pressing the removing-stand button on the
back of the projector ( ).
Attaching the Swivel Stand
Align the tabs on the front bottom of the projector ( ). While holding
down the button ( ), place the projector onto the Swivel Stand ( ) to
attach.
Press the projector down firmly to attach
it to the Swivel Stand to make sure it is
securely attached to the Swivel Stand.
Adjustable up to
±10°from the
standard position.
Adjustable up to
±25°from the
standard position.
Adjustable up to
±3°from the
standard position.
Removing-
stand button
Downloaded From projector-manual.com Sharp Manuals
-19
Setup & Connections
Keystone Correction
This function can be used to adjust the Keystone
settings.
•For details about using the menu screen, see page 26.
Description of 2D Keystone Correction
Selected item Description
Horizontal Keystone Correction
Vertical Keystone Correction
Press KEYSTONE on the projector or on the
remote control.
Press /to select “H Keystone”or “V
Keystone”.
Press /to move the mark on the selected
adjustment item to the desired setting.
To return to the normal screen, press KEYSTONE
again.
•Straight lines and the edges of the displayed image may
appear jagged, when adjusting the Keystone setting.
•When adjusting “H Keystone”and “V Keystone”at the same
time, the values of adjustable angles for each setting
become smaller.
•The “Digital Shift”and “Subtitle”cannot be adjusted when
Keystone correction is applied.
Downloaded From projector-manual.com Sharp Manuals
-21
Setup & Connections
Adjusting the Projection Distance
•Refer to pages 19 and 20 about the function of Keystone correction and placement of projector using the correction.
•Decide the placement of the projector referring to the figures on the table and the diagram below according to the size of
your screen and the input signal.
(a) Maximum projection distance
(b) Minimum projection distance
(c) Horizontal placement range when projection distance is maximum.
(d) Horizontal placement range when projection distance is minimum.
(e) Vertical placement range when projection distance is maximum.
(f) Vertical placement range when projection distance is minimum.
•The aspect ratio of the projected image shifts slightly when the
lens shift is at a position other than the top position.
•The aspect ratio of the projected image also shifts slightly
when the “H Keystone”and “V Keystone”functions are
adjusted simultaneously.
•Keystone correction cannot be applied to On Screen Display.
•When Keystone correction is applied, the resolution of image
can be deteriorated to some extent.
•There are errors of ±3% in the formulas below.
When using a
normal screen (4:3)
When using a wide
screen (16:9)
Screen size
(4:3)( )
Projection distance and Keystone correction
Maximum projection distance Minimum projection distance
Horizontal Placement range (d)
Diag.
508cm (200")
381cm (150")
254cm (100")
213cm (84")
183cm (72")
152cm (60")
102cm (40")
Horizontal Placement range (c)
Projection
distance (a)
–
5.6 m (18' 5")
3.7 m (12' 3")
3.1 m (10' 2")
2.7 m (8' 9")
2.2 m (7' 3")
1.5 m (4'11")
Composite, S-video
480 /P, 1080
–
1.7 m (5' 7")
1.1 m (3' 7")
0.9 m (2'11")
0.8 m (2' 7")
0.6 m (1'12")
0.4 m (1' 4")
720P
–
1.2 m (3'11")
0.8 m (2' 7")
0.6 m (1'12")
0.5 m (1' 8")
0.4 m (1' 4")
0.3 m (12")
RGB
–
0.9 m (2'11")
0.6 m (1'12")
0.5 m (1' 8")
0.4 m (1' 4")
0.3 m (12")
0.2 m ( 8")
Vertical
placement range
(e)
–
1.2 m (3'11")
0.8 m (2' 7")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.3 m (12")
Projection
distance (b)
6.2 m (20' 4")
4.6 m (15' 3")
3.1 m (10' 2")
2.6 m (8' 6")
2.2 m (7' 3")
1.8 m (6")
1.2 m (3'11")
Composite, S-video
480 /P, 1080
1.5 m (4'11")
1.1 m (3' 7")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.4 m (1' 4")
0.3 m (12")
720P
1.1 m (3' 7")
0.8m (2' 7")
0.5m (1' 8")
0.4 m (1' 4")
0.3m (12")
0.3 m (12")
0.2 m ( 8")
RGB
0.8 m (2' 7")
0.6 m (1'12")
0.4 m (1' 4")
0.3 m (12")
0.3 m (12")
0.2 m ( 8")
0.1 m ( 4")
Vertical
placement range
(f)
1.4 m (4' 7")
1.0 m (3' 3")
0.7 m (2' 4")
0.5 m (1' 8")
0.5 m (1' 8")
0.4 m (1' 4")
0.2 m ( 8")
Screen size
(16:9)( )
Projection distance and Keystone correction
Maximum projection distance Minimum projection distance
Diag.
508cm (200")
381cm (150")
338cm (133")
269cm (106")
254cm (100")
234cm (92")
213cm (84")
183cm (72")
152cm (60")
102cm (40")
Projection
distance (a)
8.2 m (26'11")
6.1 m (20' 1")
5.4 m (17'10")
4.3 m (14' 2")
4.1 m (13' 4")
3.7 m (12' 3")
3.4 m (11' 2")
2.9 m (9' 7")
2.4 m (7'11")
1.6 m (5' 3")
Composite, S-video
480 /P, 1080
2.5 m (8' 2")
1.8 m (5'11")
1.6 m (5' 3")
1.3 m (4' 3")
1.2 m (3'11")
1.1 m (3' 7")
1.0 m (3' 3")
0.8 m (2' 7")
0.7 m (2' 4")
0.4 m (1' 4")
720P
1.8 m (5'11")
1.3 m (4' 3")
1.1 m (3' 7")
0.9 m (2'11")
0.9 m (2'11")
0.8 m (2' 7")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.3 m (12")
RGB
1.4 m (4' 7")
1.0 m (3' 3")
0.9 m (2'11")
0.7 m (2' 4")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.4 m (1' 4")
0.4 m (1' 4")
0.2 m ( 8")
Vertical
placement range
(e)
1.8 m (5'11")
1.4 m (4' 7")
1.2 m (3'11")
0.9 m (2'11")
0.9 m (2'11")
0.8 m (2' 7")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.3 m (12")
Projection
distance (b)
6.8 m (22' 2")
5.1 m (16' 7")
4.5 m (14' 9")
3.6 m (11' 8")
3.4 m (11')
3.1 m (10' 2")
2.8 m (9' 3")
2.4 m (7'11")
2.0 m (6' 7")
1.3 m (4' 3")
Composite, S-video
480 /P, 1080
1.6 m (5' 3")
1.2 m (3'11")
1.1 m (3' 7")
0.8 m (2' 7")
0.8 m (2' 7")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.4 m (1' 4")
0.3 m (12")
720P
1.2 m (3'11")
0.9 m (2'11")
0.8 m (2' 7")
0.6 m (1'12")
0.6 m (1'12")
0.5 m (1' 8")
0.5 m (1' 8")
0.4 m (1' 4")
0.3 m (12")
0.2 m ( 8")
RGB
0.9 m (2'11")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.4 m (1' 4")
0.4 m (1' 4")
0.4 m (1' 4")
0.3 m (12")
0.2 m ( 8")
0.1 m ( 4")
Vertical
placement range
(f)
1.5 m (4'11")
1.1 m (3' 7")
1.0 m (3' 3")
0.8 m (2' 7")
0.7 m (2' 4")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.4 m (1' 4")
0.2 m ( 8")
Horizontal Placement range (c) Horizontal Placement range (d)
Downloaded From projector-manual.com Sharp Manuals
-23
Setup & Connections
Rear Projection
•Place a translucent screen between the projector and
the audience.
•Use the projector’s menu screen to reverse the
projected image. (See page 42 for use of this
function.)
•Optimal image quality can be achieved when the projector
is positioned perpendicular to the screen with all feet flat
and leveled.
Projection Using a Mirror
•When the distance between the projector and a
screen is not sufficient for normal rear projection, you
can use a mirror to reflect the image onto the screen.
•Place a mirror (normal flat type) in front of the lens.
•Project the normal image onto the mirror.
•The image reflected from the mirror is projected onto
the translucent screen.
CAUTION
•When using a mirror, be sure to carefully position both the
projector and the mirror so the light does not shine into the
eyes of the audience.
•It is recommended that you use the optional Sharp
ceiling-mount bracket for this installation.
•Before mounting the projector, remove the Swivel
Stand. (See page 17 for removing and attaching the
Swivel Stand.)
•Before mounting the projector, contact your nearest
Sharp Authorised Projector Dealer or Service Centre
to obtain the recommended ceiling-mount bracket
(sold separately). (AN-TK202 ceiling-mount bracket,
AN-TK201 extension tube, AN-60KT ceiling adaptors
for AN-TK202 or AN-TK201)
•When the projector is in the inverted position, use the
upper edge of the screen as the base line.
•Use the projector’s menu screen to select the
appropriate projection mode. (See page 42 for use
of this function.)
Ceiling-mount Projection
Image Projection
Downloaded From projector-manual.com Sharp Manuals
-25
Operation Buttons
Adjusting the Picture Aspect Ratio
Downloaded From projector-manual.com Sharp Manuals

-2
Important
Information
LAMP REPLACEMENT
BEFORE REMOVING THE SCREW, DISCONNECT POWER CORD.
HOT SURFACE INSIDE. ALLOW 1 HOUR TO COOL BEFORE
REPLACING THE LAMP. REPLACE WITH SAME SHARP LAMP
UNIT TYPE BQC-XVZ90+++1 ONLY. UV RADIATION : CAN CAUSE
EYE DAMAGE. TURN OFF LAMP BEFORE SERVICING.
MEDIUM PRESSURE LAMP : RISK OF EXPLOSION.
POTENTIAL HAZARD OF GLASS PARTICLES IF LAMP HAS
RUPTURED. HANDLE WITH CARE. SEE OPERATION MANUAL.
DU REMPLACEMENT DE LA LAMPE.
PRECAUTIONS A OBSERVER LORS
DEBRANCHER LE CORDON D’ALIMENTATION AVANT DE RETIRER LES VIS.
L’INTERIEUR DU BOITIER ETANT EXTREMEMENT CHAUD, ATTENDRE
1 HEURE AVANT DE PROCEDER AU REMPLACEMENT DE LA LAMPE.
NE REMPLACER QUE PAR UNE LAMPE SHARP DE TYPE BQC-XVZ90+++1.
RAYONS ULTRAVIOLETS : PEUVENT ENDOMMAGER LES YEUX.
ETEINDRE LA LAMPE AVANT DE PROCEDER A L’ENTRETIEN.
LAMPE A MOYENNE PRESSION: RISQUE D’EXPLOSION.
DANGERPOTENTIEL DE PARTICULES DE VERRE EN CAS D’ECLATEMENT DE LA LAMPE.
A MANIPULER AVEC PRECAUTION, SE REPORTER AU MODE D’EMPLOI.
CAUTION
Caution Concerning the Lamp Replacement
There is potential glass particles hazard if the lamp ruptures.
WARNING:
Some IC chips in this product include confidential and/or trade secret property belonging to Texas Instruments.
Therefore you may not copy, modify, adapt, translate, distribute, reverse engineer, reverse assemble or discompile
the contents thereof.
ENGLISH
Downloaded From projector-manual.com Sharp Manuals
-4
Important
Information
IMPORTANT SAFEGUARDS
+35˚C
+5˚C
CAUTION
PRECAUCIÓN
PRÉCAUTION
BQC-XVZ90+++1
Caution Concerning the Lamp Unit
There is a potential hazard of glass particles if the lamp ruptures. In case of
lamp rupture, contact your nearest Sharp Authorised Projector Dealer or
Service Centre for a replacement.
See “Replacing the Lamp”on page 46.
Cautions Concerning the Setup of the Projector
For minimal servicing and to maintain high image quality, SHARP recommends
that this projector be installed in an area free from humidity, dust and cigarette
smoke. When the projector is subjected to these environments, the lens and
part of filter must be cleaned more often than usual. As long as the projector
is properly maintained in this manner, use in these environments will not reduce
the overall operation life. Please note that all internal cleaning must be
performed by a Sharp Authorised Projector Dealer or Service Centre.
•Do not expose the projector to extreme heat or cold.
Operating temperature: +5°C to +35°C
Storage temperature: –20°C to +60°C
Notes on Operation
•The exhaust ventilative hole, the lamp cage cover and adjacent areas may
get extremely hot during projector operation. To prevent injury, do not touch
these areas until they have sufficiently cooled down.
•Allow at least 30 cm of space between the exhaust ventilative hole and the
nearest wall or obstruction.
•If the cooling fan becomes obstructed, a protection device will automatically
turn off the projector lamp. This does not indicate a malfunction. Remove
the projector power cord from the wall outlet and wait at least 10 minutes.
Then turn on the power by plugging the power cord back in. This will return
the projector to the normal operating condition.
This caution is found at the bottom of the projector. See “Caution Concerning the Lamp Replacement”
on page 2 for its location.
LAMP REPLACEMENT
BEFORE REMOVING THE SCREW, DISCONNECT POWER CORD.
HOT SURFACE INSIDE. ALLOW 1 HOUR TO COOL BEFORE
REPLACING THE LAMP. REPLACE WITH SAME SHARP LAMP
UNIT TYPE BQC-XVZ90+++1 ONLY. UV RADIATION : CAN CAUSE
EYE DAMAGE. TURN OFF LAMP BEFORE SERVICING.
MEDIUM PRESSURE LAMP : RISK OF EXPLOSION.
POTENTIAL HAZARD OF GLASS PARTICLES IF LAMP HAS
RUPTURED. HANDLE WITH CARE. SEE OPERATION MANUAL.
DU REMPLACEMENT DE LA LAMPE.
PRECAUTIONS A OBSERVER LORS
DEBRANCHER LE CORDON D’ALIMENTATION AVANT DE RETIRER LES VIS.
L’INTERIEUR DU BOITIER ETANT EXTREMEMENT CHAUD, ATTENDRE
1 HEURE AVANT DE PROCEDER AU REMPLACEMENT DE LA LAMPE.
NE REMPLACER QUE PAR UNE LAMPE SHARP DE TYPE BQC-XVZ90+++1.
RAYONS ULTRAVIOLETS : PEUVENT ENDOMMAGER LES YEUX.
ETEINDRE LA LAMPE AVANT DE PROCEDER A L’ENTRETIEN.
LAMPE A MOYENNE PRESSION : RISQUE D’EXPLOSION.
DANGER POTENTIEL DE PARTICULES DE VERRE EN CAS D’ECLATEMENT DE LA LAMPE.
A MANIPULER AVEC PRECAUTION, SE REPORTER AU MODE D’EMPLOI.
CAUTION
WARNING: High brightness light source. Do not stare into the beam of light, or view directly. Be especially careful that
children do not stare directly into the beam of light.
Downloaded From projector-manual.com Sharp Manuals
-6
Important
Information
Contents
Important Information
IMPORTANT SAFEGUARDS ................... 3
Contents................................................... 6
Outstanding Features ............................. 7
Part Names .............................................. 8
Supplied Accessories ............................. 11
Connections ............................................ 12
Power Supply ............................................ 12
Connecting to Video Equipment ............... 12
Connecting to a DVD Player and
DTV Decoder ....................................... 13
Connecting to a Computer ........................ 14
Operating the Remote Control .................. 15
Power ON/OFF .......................................... 16
Zooming and Focusing ............................. 16
Setting Up the Screen ............................. 17
Using the Swivel Stand .............................. 17
Using the Lens Shift .................................. 18
Keystone Correction .................................. 19
Placement of the Projected Image
Using the Keystone Correction ............ 20
Adjusting the Projection Distance ............. 21
Image Projection ..................................... 23
Rear Projection .......................................... 23
Projection Using a Mirror ........................... 23
Ceiling-mount Projection ........................... 23
Setup & Connections Operation Buttons Basic Operation
Maintenance &
Troubleshooting Appendix
Using the Operation Buttons ................. 24
Selecting the Input Signal Source ............. 24
Adjusting the Picture Aspect Ratio............ 24
Using the Menu Screen .......................... 26
Basic Operations ....................................... 26
Menu Bars ................................................. 27
Adjusting the Picture ................................. 29
Adjusting the Computer and
DVD/DTV Images ................................. 33
Lamp/Maintenance Indicators ................ 44
Lamp Maintenance .................................. 45
Confirming the Lamp Usage Time ............ 45
Replacing the Lamp .................................. 46
Cleaning the Ventilative Holes ............... 49
Using the Kensington Lock .................... 50
Troubleshooting ...................................... 50
Connecting Pin Assignments ................ 51
(RS-232C) Specifications
and Command Settings ..................... 52
Computer Compatibility Chart ............... 54
Dimensions .............................................. 55
Specifications .......................................... 56
Glossary ................................................... 57
Index ......................................................... 58
Turning On/Off the On-screen Display ...... 36
Selecting the Signal Type .......................... 36
Setting the Video Signal
(VIDEO menu only) .............................. 37
Selecting a Background Image ................. 37
Adjustments for the Screen Position
and Size ............................................... 38
Selecting the Menu Screen Position.......... 40
Selecting the Menu Colour ........................ 40
Automatic Power Shut-off Function ........... 41
Reversing/Inverting Projected Images ...... 42
Selecting the On-screen
Display Language ................................ 42
Advanced Picture Adjustment ................... 43
Operation Buttons
Setup &
Connections
Basic Operation
Maintenance &
Troubleshooting
Appendix
Downloaded From projector-manual.com Sharp Manuals

-1
Important
Information
IMPORTANT
For your assistance in reporting the loss or theft of your
Projector, please record the Serial Number located on
the bottom of the projector and retain this information.
Before recycling the packaging, please be sure that
you have checked the contents of the carton thoroughly
against the list of “Supplied Accessories” on page 11.
Before using the projector, please read this operation manual carefully.
OPERATION MANUAL ENGLISH
Model No.: XV-Z91E
Serial No.:
ENGLISH
WARNING:
To reduce the risk of fire or electric shock, do not expose this product to rain or moisture.
WARNING:
Intense light source. Do not look into the beam or view it directly. Be especially careful that children do not look
directly into the beam.
CAUTION:
To reduce the risk of electric shock, do not remove cabinet. No user-serviceable parts are inside. Refer servicing
to qualified service personnel.
WARNING:
The cooling fan in this projector continues to run for about 90 seconds after the projector is turned off. During
normal operation, when turning the power off always use the OFF button on the projector or on the remote
control. Ensure the cooling fan has stopped before disconnecting the power cord.
DURING NORMAL OPERATION, NEVER TURN THE PROJECTOR OFF BY DISCONNECTING THE POWER
CORD. FAILURE TO OBSERVE THIS WILL RESULT IN PREMATURE LAMP FAILURE.
Downloaded From projector-manual.com Sharp Manuals
-3
Important
Information
IMPORTANT SAFEGUARDS
ATTENTION: Please read all of these instructions before you operate your Projector for
the first time. Save these instructions for future reference.
For your own protection and prolonged operation of your Projector, be sure to read the following “IMPORTANT
SAFEGUARDS”carefully, before use.
This projector has been engineered and manufactured to ensure your personal safety. But IMPROPER USE CAN
RESULT IN POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARDS. In order not to defeat the safeguards
incorporated into this Projector, observe the following basic rules for its installation, use and servicing.
17. Unplug the Projector equipment from the wall outlet and
refer servicing to qualified service personnel under the
following conditions:
a. When the power cord or plug is damaged or frayed.
b. If liquid has been spilled into the Projector.
c. If the Projector has been exposed to rain or water.
d. If the Projector does not operate normally when
you follow the operating instructions. Adjust only
those controls that are covered by the operating
instructions, as improper adjustment of other
controls may cause damage and will often require
extensive work by a qualified technician to restore
the Projector to normal operation.
e. If the Projector has been dropped or the cabinet
has been damaged.
f. When the Projector exhibits a distinct change in
performance—this indicates a need for service.
18. When replacement parts are required, be sure the ser-
vice technician has used replacement parts specified by
the manufacturer that have the same characteristics as
the original parts. Unauthorised substitutions may result
in fire, electric shock, or other hazards.
19. This Projector is provided with one of the following types
of plugs. If the plug should fail to fit into the power outlet,
please contact your electrician.
Do not defeat the safety purpose of the plug.
a. Two-wire type mains plug.
b. Three-wire grounding type mains plug with a
grounding terminal.
This plug will only fit into a grounding type power
outlet.
1. Unplug the Projector from the wall outlet before cleaning.
2. Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.
3. Do not use attachments not recommended by the
Projector manufacturer, as they may cause hazards.
4. Do not use the Projector near water; for example, near a
bathtub, washbowl, kitchen sink, laundry tub, in a wet
basement, near a swimming pool, etc. Never spill liquid
into the projector.
5. Do not place the Projector on an unstable cart, stand, or
table. The Projector may fall, which may cause serious
injury to a child or an adult, and/or serious damage to the
unit.
6. Wall or Ceiling Mounting—The product should be
mounted to a wall or ceiling only as recommended by
the manufacturer.
7. Projector equipment and cart
combinations should be moved
with care. Quick stops, excessive
force, and uneven surfaces may
cause the equipment and cart
combination to overturn.
8. Slots and openings in the cabinet back and bottom are
provided for ventilation. To ensure reliable operation of
the Projector and to protect it from overheating, these
openings must not be blocked or covered. The openings
should never be covered with cloth or other material.
9. This Projector should never be placed near or over a
radiator or heating vent. The Projector should not be
placed in a built-in installation such as a bookcase unless
proper ventilation is provided.
10. The Projector should be operated only from the type of
power source indicated on the back of the projector or in
the specifications. If you are not sure of the type of power
supplied to your home, consult your Projector dealer or
local power company.
11. Do not place the Projector where the cord will be abused
by persons walking on it.
12. Follow all warnings and instructions marked on the
Projector.
13. To prevent damage to the projector due to lightning and
power-line surges, unplug the projector from the power
outlet, when not in use.
14. Do not overload wall outlets and extension cords with too
many products, because this can result in fire or electric
shock.
15. Never push objects of any kind into the Projector through
the cabinet slots as they may touch high-voltage points
or cause a short circuit. This could result in a fire or electric
shock.
16. Do not attempt to service the Projector yourself. Opening
or removing covers may expose you to dangerous voltage
or other hazards. Refer all servicing to qualified service
personnel.
Downloaded From projector-manual.com Sharp Manuals
-5
Important
Information
IMPORTANT SAFEGUARDS
Temperature Monitor Function
If the projector starts to overheat due to setup problems, “TEMP.”and “ ”
will blink in the lower-left corner of the picture. If the temperature continues to
rise, the lamp will turn off, the TEMPERATURE WARNING indicator on the
projector will blink, and after a 90-second cooling-off period the power will
shut off. Refer to “Lamp/Maintenance Indicators”on page 44 for details.
•The cooling fan regulates the internal temperature, and its performance is
automatically controlled. The sound of the fan may change during projector
operation due to changes in the fan speed.
Lamp Monitor Function
When the projector is turned on after the lamp has been used for 2,400 hours,
“LAMP”and “”will blink in the lower-left corner of the picture to advise you
to replace the lamp. See page 46 for lamp replacement. If the lamp has been
used for 2,500 hours, the projector power will automatically turn off and the
projector will enter standby mode. Refer to “Lamp/Maintenance Indicators”
on page 44 for details.
Using the Terminal Cover
When the projector is used on a desktop, high mounted or ceiling mounted,
attach the terminal cover (supplied) to hide the connecting cables.
Attaching the Terminal Cover
1Align with the tabs on the projector and then press the terminal cover in
the direction of the arrow.
2Tighten the two screws on the bottom of the projector.
Removing the Terminal Cover
1Loosen the two screws on the bottom of the projector.
2Raise the terminal cover and pull it out in the direction of the arrow.
2Tighten the screws
1Loosen the screws
1
2
Downloaded From projector-manual.com Sharp Manuals
-7
Important
Information
Outstanding Features
1. DMD™*1(Digital Micromirror Device) Chip
The DMD Chip allows for a higher contrast image. It enables smoother expression of details of an image,
and high picture quality for an exciting theatre experience.
*1Digital Light Processing, DLP, Digital Micromirror Device and DMD are trademarks of Texas Instruments.
2. Five Speed Primary Colour Wheel
The colour wheel consists of only the three primary colours of the light and creates a higher contrast image
with high colour purity.
3. Advanced Video Circuitry
The video circuit setup is designed for obtaining optimal images from audiovisual equipment. The circuit
optimizes high optical performance that originates in the DMD chip and the five speed primary colour
wheel, to realise outstanding video images.
4. Low Noise Design
A new optical engine has been developed for this product to minimise fan noise for undisturbed viewing.
5. Lens Shift Function
The digital shift function optically adjusts the vertical position of images. The function allows for simple
adjustment when setting up the projector for the first time.
6. 2D Keystone Correction
The 2D keystone correction function electrically corrects the size of projected images. The function
enables diagonal projection and the wider range settings.
7. For use with DTV*2
Allows projection of DTV images and 16:9 wide-screen images when connected to a DTV decoder or
similar video systems.
*2DTV is the umbrella term used to describe the new digital television system in the United States.
8. Easy-to-use Graphical User Interface (GUI)
A multi-colour menu system, which allows for simple image adjustments.
9. Colour Temperature Adjustment
The function can be used to adjust the colour temperature to suit the type of image input to the projector.
10. Gamma Correction Function
The gamma value setting can be adjusted according to the input source for optimal image contrast.
11. Picture Setting Function
The values in various adjustment settings can be stored. The function can be used to select the values to
suit the type of image input to the projector by pressing the PICTURE SETTING button on the projector or
on the remote control.
12. Component Video Input
Utilises a component video input signal (Y, PB, PR). The video signal is input as separate components to
provide superior colour and image quality.
13. Direct Computer Compatibility
A multi-scan RGB input accepts signals from VGA (640 dots 480 lines) and Macintosh (from 13" compatible
computers) without the need for any additional hardware.
Downloaded From projector-manual.com Sharp Manuals
-13
Setup & Connections




Projector
VCR, Laser disc player,
DVD player or DTV decoder
Connecting to Video Equipment
Connecting to a DVD Player and DTV Decoder


DVD player
or
DTV decoder


CAUTION
•
Projector
Connecting to a DVD player and DTV decoder with Component output (for INPUT 1)
Connecting to a DVD player and DTV decoder with component output (for INPUT 2)


“ ” “ ”
RGB/COMP.
CAUTION
•
Projector
DVD player
or
DTV decoder


Downloaded From projector-manual.com Sharp Manuals
-15
Setup & Connections
Operating the Remote Control
The remote control can be used to control the projec-
tor within the range shown on the left.
• The signal from the remote control can be reflected off a
screen for easy operation. However, the effective distance
of the signal may differ due to the screen material.
Remote Control
Remote Control
45˚
7 m
30˚
30˚
45˚
30˚
Using the remote control in a dark
room
The backlights of the operation buttons can be turned
on for five seconds and off by pressing LIGHT. If you
want to turn off the backlights while they are on, press
LIGHT again.
Connecting a computer with RGB output
Connect one of the computer-RGB cable to the INPUT 2 COMPONENT/RGB port on the projector.
Connect the other end to the Corresponding terminal on a computer.
•Make sure to turn both the projector and the video equipment off, before connecting.
Connect an RS-232C cable (null modem, cross type, commercially available) to the serial port on the computer.
CAUTION
•Do not connect or disconnect an RS-232C cable to or from the computer while it is on. This may damage your computer.
•Refer to “Computer Compatibility Chart”on page 54 for a list of computer signals compatible with the projector. Use with computer
signals other than those listed may cause some of the functions not to work.
•The RS-232C function may not operate if your computer port is not correctly set up. Please refer to the operation manual of the computer for
details.
•The arrows ( , ) in the configuration above indicate the direction of the signals.
•A Macintosh adaptor may be required for use with some Macintosh computers. Contact your nearest Sharp Authorised Projector Dealer or
Service Centre.
Connecting to a Computer
Computer-RGB cable
LIGHT button
Downloaded From projector-manual.com Sharp Manuals
-17
Setup & Connections
Using the Swivel Stand
Setting Up the Screen
You can adjust the angle and direction of the projected image by using
the Swivel Stand.
Unlock the lever on the Swivel Stand.
Adjust the angle and direction of the projected image as you want
by lifting up the projector and rotating the projector on the Swivel
Stand.
Lock the lever on the Swivel Stand.
CAUTION
•Do not hold the lens when lifting, lowering or rotating the projector.
•When lowering the projector, be careful not to get your fingers caught in the
area between the Swivel Stand and the projector.
•When the height or direction of the projector is adjusted, the image may become
distorted (keystoned), depending on the relative positions of the projector
and the screen. See page 19 for details on the keystone correction.
Removing the Swivel Stand
Lift the projector ( ) with pressing the removing-stand button on the
back of the projector ( ).
Attaching the Swivel Stand
Align the tabs on the front bottom of the projector ( ). While holding
down the button ( ), place the projector onto the Swivel Stand ( ) to
attach.
Press the projector down firmly to attach
it to the Swivel Stand to make sure it is
securely attached to the Swivel Stand.
Adjustable up to
±10°from the
standard position.
Adjustable up to
±25°from the
standard position.
Adjustable up to
±3°from the
standard position.
Removing-
stand button
Downloaded From projector-manual.com Sharp Manuals
-19
Setup & Connections
Keystone Correction
This function can be used to adjust the Keystone
settings.
•For details about using the menu screen, see page 26.
Description of 2D Keystone Correction
Selected item Description
Horizontal Keystone Correction
Vertical Keystone Correction
Press KEYSTONE on the projector or on the
remote control.
Press /to select “H Keystone”or “V
Keystone”.
Press /to move the mark on the selected
adjustment item to the desired setting.
To return to the normal screen, press KEYSTONE
again.
•Straight lines and the edges of the displayed image may
appear jagged, when adjusting the Keystone setting.
•When adjusting “H Keystone”and “V Keystone”at the same
time, the values of adjustable angles for each setting
become smaller.
•The “Digital Shift”and “Subtitle”cannot be adjusted when
Keystone correction is applied.
Downloaded From projector-manual.com Sharp Manuals
-21
Setup & Connections
Adjusting the Projection Distance
•Refer to pages 19 and 20 about the function of Keystone correction and placement of projector using the correction.
•Decide the placement of the projector referring to the figures on the table and the diagram below according to the size of
your screen and the input signal.
(a) Maximum projection distance
(b) Minimum projection distance
(c) Horizontal placement range when projection distance is maximum.
(d) Horizontal placement range when projection distance is minimum.
(e) Vertical placement range when projection distance is maximum.
(f) Vertical placement range when projection distance is minimum.
•The aspect ratio of the projected image shifts slightly when the
lens shift is at a position other than the top position.
•The aspect ratio of the projected image also shifts slightly
when the “H Keystone”and “V Keystone”functions are
adjusted simultaneously.
•Keystone correction cannot be applied to On Screen Display.
•When Keystone correction is applied, the resolution of image
can be deteriorated to some extent.
•There are errors of ±3% in the formulas below.
When using a
normal screen (4:3)
When using a wide
screen (16:9)
Screen size
(4:3)( )
Projection distance and Keystone correction
Maximum projection distance Minimum projection distance
Horizontal Placement range (d)
Diag.
508cm (200")
381cm (150")
254cm (100")
213cm (84")
183cm (72")
152cm (60")
102cm (40")
Horizontal Placement range (c)
Projection
distance (a)
–
5.6 m (18' 5")
3.7 m (12' 3")
3.1 m (10' 2")
2.7 m (8' 9")
2.2 m (7' 3")
1.5 m (4'11")
Composite, S-video
480 /P, 1080
–
1.7 m (5' 7")
1.1 m (3' 7")
0.9 m (2'11")
0.8 m (2' 7")
0.6 m (1'12")
0.4 m (1' 4")
720P
–
1.2 m (3'11")
0.8 m (2' 7")
0.6 m (1'12")
0.5 m (1' 8")
0.4 m (1' 4")
0.3 m (12")
RGB
–
0.9 m (2'11")
0.6 m (1'12")
0.5 m (1' 8")
0.4 m (1' 4")
0.3 m (12")
0.2 m ( 8")
Vertical
placement range
(e)
–
1.2 m (3'11")
0.8 m (2' 7")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.3 m (12")
Projection
distance (b)
6.2 m (20' 4")
4.6 m (15' 3")
3.1 m (10' 2")
2.6 m (8' 6")
2.2 m (7' 3")
1.8 m (6")
1.2 m (3'11")
Composite, S-video
480 /P, 1080
1.5 m (4'11")
1.1 m (3' 7")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.4 m (1' 4")
0.3 m (12")
720P
1.1 m (3' 7")
0.8m (2' 7")
0.5m (1' 8")
0.4 m (1' 4")
0.3m (12")
0.3 m (12")
0.2 m ( 8")
RGB
0.8 m (2' 7")
0.6 m (1'12")
0.4 m (1' 4")
0.3 m (12")
0.3 m (12")
0.2 m ( 8")
0.1 m ( 4")
Vertical
placement range
(f)
1.4 m (4' 7")
1.0 m (3' 3")
0.7 m (2' 4")
0.5 m (1' 8")
0.5 m (1' 8")
0.4 m (1' 4")
0.2 m ( 8")
Screen size
(16:9)( )
Projection distance and Keystone correction
Maximum projection distance Minimum projection distance
Diag.
508cm (200")
381cm (150")
338cm (133")
269cm (106")
254cm (100")
234cm (92")
213cm (84")
183cm (72")
152cm (60")
102cm (40")
Projection
distance (a)
8.2 m (26'11")
6.1 m (20' 1")
5.4 m (17'10")
4.3 m (14' 2")
4.1 m (13' 4")
3.7 m (12' 3")
3.4 m (11' 2")
2.9 m (9' 7")
2.4 m (7'11")
1.6 m (5' 3")
Composite, S-video
480 /P, 1080
2.5 m (8' 2")
1.8 m (5'11")
1.6 m (5' 3")
1.3 m (4' 3")
1.2 m (3'11")
1.1 m (3' 7")
1.0 m (3' 3")
0.8 m (2' 7")
0.7 m (2' 4")
0.4 m (1' 4")
720P
1.8 m (5'11")
1.3 m (4' 3")
1.1 m (3' 7")
0.9 m (2'11")
0.9 m (2'11")
0.8 m (2' 7")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.3 m (12")
RGB
1.4 m (4' 7")
1.0 m (3' 3")
0.9 m (2'11")
0.7 m (2' 4")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.4 m (1' 4")
0.4 m (1' 4")
0.2 m ( 8")
Vertical
placement range
(e)
1.8 m (5'11")
1.4 m (4' 7")
1.2 m (3'11")
0.9 m (2'11")
0.9 m (2'11")
0.8 m (2' 7")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.3 m (12")
Projection
distance (b)
6.8 m (22' 2")
5.1 m (16' 7")
4.5 m (14' 9")
3.6 m (11' 8")
3.4 m (11')
3.1 m (10' 2")
2.8 m (9' 3")
2.4 m (7'11")
2.0 m (6' 7")
1.3 m (4' 3")
Composite, S-video
480 /P, 1080
1.6 m (5' 3")
1.2 m (3'11")
1.1 m (3' 7")
0.8 m (2' 7")
0.8 m (2' 7")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.4 m (1' 4")
0.3 m (12")
720P
1.2 m (3'11")
0.9 m (2'11")
0.8 m (2' 7")
0.6 m (1'12")
0.6 m (1'12")
0.5 m (1' 8")
0.5 m (1' 8")
0.4 m (1' 4")
0.3 m (12")
0.2 m ( 8")
RGB
0.9 m (2'11")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.4 m (1' 4")
0.4 m (1' 4")
0.4 m (1' 4")
0.3 m (12")
0.2 m ( 8")
0.1 m ( 4")
Vertical
placement range
(f)
1.5 m (4'11")
1.1 m (3' 7")
1.0 m (3' 3")
0.8 m (2' 7")
0.7 m (2' 4")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.4 m (1' 4")
0.2 m ( 8")
Horizontal Placement range (c) Horizontal Placement range (d)
Downloaded From projector-manual.com Sharp Manuals
-23
Setup & Connections
Rear Projection
•Place a translucent screen between the projector and
the audience.
•Use the projector’s menu screen to reverse the
projected image. (See page 42 for use of this
function.)
•Optimal image quality can be achieved when the projector
is positioned perpendicular to the screen with all feet flat
and leveled.
Projection Using a Mirror
•When the distance between the projector and a
screen is not sufficient for normal rear projection, you
can use a mirror to reflect the image onto the screen.
•Place a mirror (normal flat type) in front of the lens.
•Project the normal image onto the mirror.
•The image reflected from the mirror is projected onto
the translucent screen.
CAUTION
•When using a mirror, be sure to carefully position both the
projector and the mirror so the light does not shine into the
eyes of the audience.
•It is recommended that you use the optional Sharp
ceiling-mount bracket for this installation.
•Before mounting the projector, remove the Swivel
Stand. (See page 17 for removing and attaching the
Swivel Stand.)
•Before mounting the projector, contact your nearest
Sharp Authorised Projector Dealer or Service Centre
to obtain the recommended ceiling-mount bracket
(sold separately). (AN-TK202 ceiling-mount bracket,
AN-TK201 extension tube, AN-60KT ceiling adaptors
for AN-TK202 or AN-TK201)
•When the projector is in the inverted position, use the
upper edge of the screen as the base line.
•Use the projector’s menu screen to select the
appropriate projection mode. (See page 42 for use
of this function.)
Ceiling-mount Projection
Image Projection
Downloaded From projector-manual.com Sharp Manuals
-25
Operation Buttons
Adjusting the Picture Aspect Ratio
Downloaded From projector-manual.com Sharp Manuals

-2
Important
Information
Caution Concerning the Lamp Replacement
There is potential glass particles hazard if the lamp ruptures.
WARNING:
Some IC chips in this product include confidential and/or trade secret property belonging to Texas Instruments.
Therefore you may not copy, modify, adapt, translate, distribute, reverse engineer, reverse assemble or discompile
the contents thereof.
ENGLISH
Downloaded From projector-manual.com Sharp Manuals
-4
Important
Information
IMPORTANT SAFEGUARDS
Caution Concerning the Lamp Unit
There is a potential hazard of glass particles if the lamp ruptures. In case of
lamp rupture, contact your nearest Sharp Authorised Projector Dealer or
Service Centre for a replacement.
See Replacing the Lamp on page 46.
Cautions Concerning the Setup of the Projector
For minimal servicing and to maintain high image quality, SHARP recommends
that this projector be installed in an area free from humidity, dust and cigarette
smoke. When the projector is subjected to these environments, the lens and
part of filter must be cleaned more often than usual. As long as the projector
is properly maintained in this manner, use in these environments will not reduce
the overall operation life. Please note that all internal cleaning must be
performed by a Sharp Authorised Projector Dealer or Service Centre.
Do not expose the projector to extreme heat or cold.
Operating temperature: +5 C to +35 C
Storage temperature: 20 C to +60 C
Notes on Operation
The exhaust ventilative hole, the lamp cage cover and adjacent areas may
get extremely hot during projector operation. To prevent injury, do not touch
these areas until they have sufficiently cooled down.
Allow at least 30 cm of space between the exhaust ventilative hole and the
nearest wall or obstruction.
If the cooling fan becomes obstructed, a protection device will automatically
turn off the projector lamp. This does not indicate a malfunction. Remove
the projector power cord from the wall outlet and wait at least 10 minutes.
Then turn on the power by plugging the power cord back in. This will return
the projector to the normal operating condition.
This caution is found at the bottom of the projector. See Caution Concerning the Lamp Replacement
on page 2 for its location.
WARNING: High brightness light source. Do not stare into the beam of light, or view directly. Be especially careful that
children do not stare directly into the beam of light.
Downloaded From projector-manual.com Sharp Manuals
-6
Important
Information
Contents
Important Information
IMPORTANT SAFEGUARDS ................... 3
Contents................................................... 6
Outstanding Features ............................. 7
Part Names .............................................. 8
Supplied Accessories ............................. 11
Connections ............................................ 12
Power Supply ............................................ 12
Connecting to Video Equipment ............... 12
Connecting to a DVD Player and
DTV Decoder ....................................... 13
Connecting to a Computer ........................ 14
Operating the Remote Control .................. 15
Power ON/OFF .......................................... 16
Zooming and Focusing ............................. 16
Setting Up the Screen ............................. 17
Using the Swivel Stand .............................. 17
Using the Lens Shift .................................. 18
Keystone Correction .................................. 19
Placement of the Projected Image
Using the Keystone Correction ............ 20
Adjusting the Projection Distance ............. 21
Image Projection ..................................... 23
Rear Projection .......................................... 23
Projection Using a Mirror ........................... 23
Ceiling-mount Projection ........................... 23
Setup & Connections Operation Buttons Basic Operation
Maintenance &
Troubleshooting Appendix
Using the Operation Buttons ................. 24
Selecting the Input Signal Source ............. 24
Adjusting the Picture Aspect Ratio............ 24
Using the Menu Screen .......................... 26
Basic Operations ....................................... 26
Menu Bars ................................................. 27
Adjusting the Picture ................................. 29
Adjusting the Computer and
DVD/DTV Images ................................. 33
Lamp/Maintenance Indicators ................ 44
Lamp Maintenance .................................. 45
Confirming the Lamp Usage Time ............ 45
Replacing the Lamp .................................. 46
Cleaning the Ventilative Holes ............... 49
Using the Kensington Lock .................... 50
Troubleshooting ...................................... 50
Connecting Pin Assignments ................ 51
(RS-232C) Specifications
and Command Settings ..................... 52
Computer Compatibility Chart ............... 54
Dimensions .............................................. 55
Specifications .......................................... 56
Glossary ................................................... 57
Index ......................................................... 58
Turning On/Off the On-screen Display ...... 36
Selecting the Signal Type .......................... 36
Setting the Video Signal
(VIDEO menu only) .............................. 37
Selecting a Background Image ................. 37
Adjustments for the Screen Position
and Size ............................................... 38
Selecting the Menu Screen Position.......... 40
Selecting the Menu Colour ........................ 40
Automatic Power Shut-off Function ........... 41
Reversing/Inverting Projected Images ...... 42
Selecting the On-screen
Display Language ................................ 42
Advanced Picture Adjustment ................... 43
Operation Buttons
Setup &
Connections
Basic Operation
Maintenance &
Troubleshooting
Appendix
Downloaded From projector-manual.com Sharp Manuals

-1
Important
Information
IMPORTANT
Before using the projector, please read this operation manual carefully.
OPERATION MANUAL ENGLISH
Model No.: XV-Z91E
Serial No.:
ENGLISH
WARNING:
WARNING:
CAUTION:
WARNING:
OFF
Downloaded From projector-manual.com Sharp Manuals
-3
Important
Information
IMPORTANT SAFEGUARDS
ATTENTION: Please read all of these instructions before you operate your Projector for
the first time. Save these instructions for future reference.
For your own protection and prolonged operation of your Projector, be sure to read the following IMPORTANT
SAFEGUARDS carefully, before use.
This projector has been engineered and manufactured to ensure your personal safety. But IMPROPER USE CAN
RESULT IN POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARDS. In order not to defeat the safeguards
incorporated into this Projector, observe the following basic rules for its installation, use and servicing.
17. Unplug the Projector equipment from the wall outlet and
refer servicing to qualified service personnel under the
following conditions:
a. When the power cord or plug is damaged or frayed.
b. If liquid has been spilled into the Projector.
c. If the Projector has been exposed to rain or water.
d. If the Projector does not operate normally when
you follow the operating instructions. Adjust only
those controls that are covered by the operating
instructions, as improper adjustment of other
controls may cause damage and will often require
extensive work by a qualified technician to restore
the Projector to normal operation.
e. If the Projector has been dropped or the cabinet
has been damaged.
f. When the Projector exhibits a distinct change in
performance this indicates a need for service.
18. When replacement parts are required, be sure the ser-
vice technician has used replacement parts specified by
the manufacturer that have the same characteristics as
the original parts. Unauthorised substitutions may result
in fire, electric shock, or other hazards.
19. This Projector is provided with one of the following types
of plugs. If the plug should fail to fit into the power outlet,
please contact your electrician.
Do not defeat the safety purpose of the plug.
a. Two-wire type mains plug.
b. Three-wire grounding type mains plug with a
grounding terminal.
This plug will only fit into a grounding type power
outlet.
1. Unplug the Projector from the wall outlet before cleaning.
2. Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.
3. Do not use attachments not recommended by the
Projector manufacturer, as they may cause hazards.
4. Do not use the Projector near water; for example, near a
bathtub, washbowl, kitchen sink, laundry tub, in a wet
basement, near a swimming pool, etc. Never spill liquid
into the projector.
5. Do not place the Projector on an unstable cart, stand, or
table. The Projector may fall, which may cause serious
injury to a child or an adult, and/or serious damage to the
unit.
6. Wall or Ceiling Mounting The product should be
mounted to a wall or ceiling only as recommended by
the manufacturer.
7. Projector equipment and cart
combinations should be moved
with care. Quick stops, excessive
force, and uneven surfaces may
cause the equipment and cart
combination to overturn.
8. Slots and openings in the cabinet back and bottom are
provided for ventilation. To ensure reliable operation of
the Projector and to protect it from overheating, these
openings must not be blocked or covered. The openings
should never be covered with cloth or other material.
9. This Projector should never be placed near or over a
radiator or heating vent. The Projector should not be
placed in a built-in installation such as a bookcase unless
proper ventilation is provided.
10. The Projector should be operated only from the type of
power source indicated on the back of the projector or in
the specifications. If you are not sure of the type of power
supplied to your home, consult your Projector dealer or
local power company.
11. Do not place the Projector where the cord will be abused
by persons walking on it.
12. Follow all warnings and instructions marked on the
Projector.
13. To prevent damage to the projector due to lightning and
power-line surges, unplug the projector from the power
outlet, when not in use.
14. Do not overload wall outlets and extension cords with too
many products, because this can result in fire or electric
shock.
15. Never push objects of any kind into the Projector through
the cabinet slots as they may touch high-voltage points
or cause a short circuit. This could result in a fire or electric
shock.
16. Do not attempt to service the Projector yourself. Opening
or removing covers may expose you to dangerous voltage
or other hazards. Refer all servicing to qualified service
personnel.
Downloaded From projector-manual.com Sharp Manuals
-5
Important
Information
IMPORTANT SAFEGUARDS
Temperature Monitor Function
If the projector starts to overheat due to setup problems, TEMP. and
will blink in the lower-left corner of the picture. If the temperature continues to
rise, the lamp will turn off, the TEMPERATURE WARNING indicator on the
projector will blink, and after a 90-second cooling-off period the power will
shut off. Refer to Lamp/Maintenance Indicators on page 44 for details.
The cooling fan regulates the internal temperature, and its performance is
automatically controlled. The sound of the fan may change during projector
operation due to changes in the fan speed.
Lamp Monitor Function
When the projector is turned on after the lamp has been used for 2,400 hours,
LAMP and will blink in the lower-left corner of the picture to advise you
to replace the lamp. See page 46 for lamp replacement. If the lamp has been
used for 2,500 hours, the projector power will automatically turn off and the
projector will enter standby mode. Refer to Lamp/Maintenance Indicators
on page 44 for details.
Using the Terminal Cover
When the projector is used on a desktop, high mounted or ceiling mounted,
attach the terminal cover (supplied) to hide the connecting cables.
Attaching the Terminal Cover
Align with the tabs on the projector and then press the terminal cover in
the direction of the arrow.
Tighten the two screws on the bottom of the projector.
Removing the Terminal Cover
Loosen the two screws on the bottom of the projector.
Raise the terminal cover and pull it out in the direction of the arrow.
Tighten the screws
Loosen the screws
Downloaded From projector-manual.com Sharp Manuals
-7
Important
Information
Outstanding Features
1. DMD™*1(Digital Micromirror Device) Chip
The DMD Chip allows for a higher contrast image. It enables smoother expression of details of an image,
and high picture quality for an exciting theatre experience.
*1Digital Light Processing, DLP, Digital Micromirror Device and DMD are trademarks of Texas Instruments.
2. Five Speed Primary Colour Wheel
The colour wheel consists of only the three primary colours of the light and creates a higher contrast image
with high colour purity.
3. Advanced Video Circuitry
The video circuit setup is designed for obtaining optimal images from audiovisual equipment. The circuit
optimizes high optical performance that originates in the DMD chip and the five speed primary colour
wheel, to realise outstanding video images.
4. Low Noise Design
A new optical engine has been developed for this product to minimise fan noise for undisturbed viewing.
5. Lens Shift Function
The digital shift function optically adjusts the vertical position of images. The function allows for simple
adjustment when setting up the projector for the first time.
6. 2D Keystone Correction
The 2D keystone correction function electrically corrects the size of projected images. The function
enables diagonal projection and the wider range settings.
7. For use with DTV*2
Allows projection of DTV images and 16:9 wide-screen images when connected to a DTV decoder or
similar video systems.
*2DTV is the umbrella term used to describe the new digital television system in the United States.
8. Easy-to-use Graphical User Interface (GUI)
A multi-colour menu system, which allows for simple image adjustments.
9. Colour Temperature Adjustment
The function can be used to adjust the colour temperature to suit the type of image input to the projector.
10. Gamma Correction Function
The gamma value setting can be adjusted according to the input source for optimal image contrast.
11. Picture Setting Function
The values in various adjustment settings can be stored. The function can be used to select the values to
suit the type of image input to the projector by pressing the PICTURE SETTING button on the projector or
on the remote control.
12. Component Video Input
Utilises a component video input signal (Y, PB, PR). The video signal is input as separate components to
provide superior colour and image quality.
13. Direct Computer Compatibility
A multi-scan RGB input accepts signals from VGA (640 dots ×480 lines) and Macintosh (from 13" compatible
computers) without the need for any additional hardware.
Downloaded From projector-manual.com Sharp Manuals
-13
Setup & Connections




Projector
VCR, Laser disc player,
DVD player or DTV decoder
Connecting to Video Equipment
Connecting to a DVD Player and DTV Decoder


DVD player
or
DTV decoder


CAUTION
Projector
Connecting to a DVD player and DTV decoder with Component output (for INPUT 1)
Connecting to a DVD player and DTV decoder with component output (for INPUT 2)


RGB/COMP.
CAUTION
Projector
DVD player
or
DTV decoder


Downloaded From projector-manual.com Sharp Manuals
-15
Setup & Connections
Operating the Remote Control
Remote Control
Remote Control
45
7 m
30
30
45
30
Using the remote control in a dark
room
The backlights of the operation buttons can be turned
on for five seconds and off by pressing LIGHT. If you
want to turn off the backlights while they are on, press
LIGHT again.
Connecting a computer with RGB output
+Connect one of the computer-RGB cable to the INPUT 2 COMPONENT/RGB port on the projector.
×Connect the other end to the Corresponding terminal on a computer.
Make sure to turn both the projector and the video equipment off, before connecting.
Connect an RS-232C cable (null modem, cross type, commercially available) to the serial port on the computer.
CAUTION
Do not connect or disconnect an RS-232C cable to or from the computer while it is on. This may damage your computer.
Refer to Computer Compatibility Chart on page 54 for a list of computer signals compatible with the projector. Use with computer
signals other than those listed may cause some of the functions not to work.
The RS-232C function may not operate if your computer port is not correctly set up. Please refer to the operation manual of the computer for
details.
The arrows ( , ) in the configuration above indicate the direction of the signals.
A Macintosh adaptor may be required for use with some Macintosh computers. Contact your nearest Sharp Authorised Projector Dealer or
Service Centre.
+×
Connecting to a Computer
Computer-RGB cable
LIGHT button
Downloaded From projector-manual.com Sharp Manuals
-17
Setup & Connections
Using the Swivel Stand
Setting Up the Screen
You can adjust the angle and direction of the projected image by using
the Swivel Stand.
+Unlock the lever on the Swivel Stand.
×Adjust the angle and direction of the projected image as you want
by lifting up the projector and rotating the projector on the Swivel
Stand.
Lock the lever on the Swivel Stand.
CAUTION
Do not hold the lens when lifting, lowering or rotating the projector.
When lowering the projector, be careful not to get your fingers caught in the
area between the Swivel Stand and the projector.
When the height or direction of the projector is adjusted, the image may become
distorted (keystoned), depending on the relative positions of the projector
and the screen. See page 19 for details on the keystone correction.
+
×

Removing the Swivel Stand
Lift the projector (×) with pressing the removing-stand button on the
back of the projector (+).
Attaching the Swivel Stand
Align the tabs on the front bottom of the projector (+). While holding
down the button (×), place the projector onto the Swivel Stand () to
attach.
Press the projector down firmly to attach
it to the Swivel Stand to make sure it is
securely attached to the Swivel Stand.
Adjustable up to
±10 from the
standard position.
Adjustable up to
±25 from the
standard position.
Adjustable up to
±3 from the
standard position.
Removing-
stand button
Downloaded From projector-manual.com Sharp Manuals
-19
Setup & Connections
Keystone Correction
This function can be used to adjust the Keystone
settings.
For details about using the menu screen, see page 26.
Description of 2D Keystone Correction
Selected item Description
Horizontal Keystone Correction
Vertical Keystone Correction
+Press KEYSTONE on the projector or on the
remote control.
×Press /to select H Keystone or V
Keystone .
Press /to move the mark on the selected
adjustment item to the desired setting.
To return to the normal screen, press KEYSTONE
again.
Straight lines and the edges of the displayed image may
appear jagged, when adjusting the Keystone setting.
When adjusting H Keystone and V Keystone at the same
time, the values of adjustable angles for each setting
become smaller.
The Digital Shift and Subtitle cannot be adjusted when
Keystone correction is applied.
× 
+ 
Downloaded From projector-manual.com Sharp Manuals
-21
Setup & Connections
Adjusting the Projection Distance
Refer to pages 19 and 20 about the function of Keystone correction and placement of projector using the correction.
Decide the placement of the projector referring to the figures on the table and the diagram below according to the size of
your screen and the input signal.
(a) Maximum projection distance
(b) Minimum projection distance
(c) Horizontal placement range when projection distance is maximum.
(d) Horizontal placement range when projection distance is minimum.
(e) Vertical placement range when projection distance is maximum.
(f) Vertical placement range when projection distance is minimum.
The aspect ratio of the projected image shifts slightly when the
lens shift is at a position other than the top position.
The aspect ratio of the projected image also shifts slightly
when the H Keystone and V Keystone functions are
adjusted simultaneously.
Keystone correction cannot be applied to On Screen Display.
When Keystone correction is applied, the resolution of image
can be deteriorated to some extent.
There are errors of ±3% in the formulas below.
When using a
normal screen (4:3)
When using a wide
screen (16:9)
Screen size
(4:3)( )
Projection distance and Keystone correction
Maximum projection distance Minimum projection distance
Horizontal Placement range (d)
Diag.
508cm (200")
381cm (150")
254cm (100")
213cm (84")
183cm (72")
152cm (60")
102cm (40")
Horizontal Placement range (c)
Projection
distance (a)
5.6 m (18' 5")
3.7 m (12' 3")
3.1 m (10' 2")
2.7 m (8' 9")
2.2 m (7' 3")
1.5 m (4'11")
Composite, S-video
480 /P, 1080
1.7 m (5' 7")
1.1 m (3' 7")
0.9 m (2'11")
0.8 m (2' 7")
0.6 m (1'12")
0.4 m (1' 4")
720P
1.2 m (3'11")
0.8 m (2' 7")
0.6 m (1'12")
0.5 m (1' 8")
0.4 m (1' 4")
0.3 m (12")
RGB
0.9 m (2'11")
0.6 m (1'12")
0.5 m (1' 8")
0.4 m (1' 4")
0.3 m (12")
0.2 m ( 8")
Vertical
placement range
(e)
1.2 m (3'11")
0.8 m (2' 7")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.3 m (12")
Projection
distance (b)
6.2 m (20' 4")
4.6 m (15' 3")
3.1 m (10' 2")
2.6 m (8' 6")
2.2 m (7' 3")
1.8 m (6")
1.2 m (3'11")
Composite, S-video
480 /P, 1080
1.5 m (4'11")
1.1 m (3' 7")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.4 m (1' 4")
0.3 m (12")
720P
1.1 m (3' 7")
0.8m (2' 7")
0.5m (1' 8")
0.4 m (1' 4")
0.3m (12")
0.3 m (12")
0.2 m ( 8")
RGB
0.8 m (2' 7")
0.6 m (1'12")
0.4 m (1' 4")
0.3 m (12")
0.3 m (12")
0.2 m ( 8")
0.1 m ( 4")
Vertical
placement range
(f)
1.4 m (4' 7")
1.0 m (3' 3")
0.7 m (2' 4")
0.5 m (1' 8")
0.5 m (1' 8")
0.4 m (1' 4")
0.2 m ( 8")
Screen size
(16:9)( )
Projection distance and Keystone correction
Maximum projection distance Minimum projection distance
Diag.
508cm (200")
381cm (150")
338cm (133")
269cm (106")
254cm (100")
234cm (92")
213cm (84")
183cm (72")
152cm (60")
102cm (40")
Projection
distance (a)
8.2 m (26'11")
6.1 m (20' 1")
5.4 m (17'10")
4.3 m (14' 2")
4.1 m (13' 4")
3.7 m (12' 3")
3.4 m (11' 2")
2.9 m (9' 7")
2.4 m (7'11")
1.6 m (5' 3")
Composite, S-video
480 /P, 1080
2.5 m (8' 2")
1.8 m (5'11")
1.6 m (5' 3")
1.3 m (4' 3")
1.2 m (3'11")
1.1 m (3' 7")
1.0 m (3' 3")
0.8 m (2' 7")
0.7 m (2' 4")
0.4 m (1' 4")
720P
1.8 m (5'11")
1.3 m (4' 3")
1.1 m (3' 7")
0.9 m (2'11")
0.9 m (2'11")
0.8 m (2' 7")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.3 m (12")
RGB
1.4 m (4' 7")
1.0 m (3' 3")
0.9 m (2'11")
0.7 m (2' 4")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.4 m (1' 4")
0.4 m (1' 4")
0.2 m ( 8")
Vertical
placement range
(e)
1.8 m (5'11")
1.4 m (4' 7")
1.2 m (3'11")
0.9 m (2'11")
0.9 m (2'11")
0.8 m (2' 7")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.3 m (12")
Projection
distance (b)
6.8 m (22' 2")
5.1 m (16' 7")
4.5 m (14' 9")
3.6 m (11' 8")
3.4 m (11')
3.1 m (10' 2")
2.8 m (9' 3")
2.4 m (7'11")
2.0 m (6' 7")
1.3 m (4' 3")
Composite, S-video
480 /P, 1080
1.6 m (5' 3")
1.2 m (3'11")
1.1 m (3' 7")
0.8 m (2' 7")
0.8 m (2' 7")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.4 m (1' 4")
0.3 m (12")
720P
1.2 m (3'11")
0.9 m (2'11")
0.8 m (2' 7")
0.6 m (1'12")
0.6 m (1'12")
0.5 m (1' 8")
0.5 m (1' 8")
0.4 m (1' 4")
0.3 m (12")
0.2 m ( 8")
RGB
0.9 m (2'11")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.4 m (1' 4")
0.4 m (1' 4")
0.4 m (1' 4")
0.3 m (12")
0.2 m ( 8")
0.1 m ( 4")
Vertical
placement range
(f)
1.5 m (4'11")
1.1 m (3' 7")
1.0 m (3' 3")
0.8 m (2' 7")
0.7 m (2' 4")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.4 m (1' 4")
0.2 m ( 8")
Horizontal Placement range (c) Horizontal Placement range (d)
Downloaded From projector-manual.com Sharp Manuals
-23
Setup & Connections
Rear Projection
Place a translucent screen between the projector and
the audience.
Use the projector s menu screen to reverse the
projected image. (See page 42 for use of this
function.)
Optimal image quality can be achieved when the projector
is positioned perpendicular to the screen with all feet flat
and leveled.
Projection Using a Mirror
When the distance between the projector and a
screen is not sufficient for normal rear projection, you
can use a mirror to reflect the image onto the screen.
Place a mirror (normal flat type) in front of the lens.
Project the normal image onto the mirror.
The image reflected from the mirror is projected onto
the translucent screen.
CAUTION
When using a mirror, be sure to carefully position both the
projector and the mirror so the light does not shine into the
eyes of the audience.
It is recommended that you use the optional Sharp
ceiling-mount bracket for this installation.
Before mounting the projector, remove the Swivel
Stand. (See page 17 for removing and attaching the
Swivel Stand.)
Before mounting the projector, contact your nearest
Sharp Authorised Projector Dealer or Service Centre
to obtain the recommended ceiling-mount bracket
(sold separately). (AN-TK202 ceiling-mount bracket,
AN-TK201 extension tube, AN-60KT ceiling adaptors
for AN-TK202 or AN-TK201)
When the projector is in the inverted position, use the
upper edge of the screen as the base line.
Use the projector s menu screen to select the
appropriate projection mode. (See page 42 for use
of this function.)
Ceiling-mount Projection
Image Projection
Downloaded From projector-manual.com Sharp Manuals
-25
Operation Buttons
Adjusting the Picture Aspect Ratio
Downloaded From projector-manual.com Sharp Manuals

Important
Information
-8
Part Names
Projector
Numbers next to the part names refer to the main pages in this manual where the topic is explained.
Front and Top View
16
5
5
POWER indicator
4
Exhaust ventilative hole
LAMP
REPLACEMENT indicator
TEMPERATURE
WARNING indicator
19
ADJUSTMENT buttons
(∂/ƒ/ß/©)
26
UNDO button
26
MENU button
24
RESIZE button
24
INPUT button
17
Swivel Stand
LOCK/UNLOCK lever
15
Remote control sensor
9
Lens cap
Zoom knob
16
Exhaust ventilative hole
4
Focus ring
16
18
Lens shift dial
26
ENTER button
19
KEYSTONE button
POWER buttons
(ON/OFF)
16
32
PICTURE SETTING button
Side and Rear View
Downloaded From projector-manual.com Sharp Manuals -10
Part Names
Inserting the batteries
13
Pull down the tab on the
battery cover and
remove the cover
towards the direction of
the arrow.
2Insert two AA size
batteries, making sure
the polarities match the
and marks inside
the battery compartment.
Insert the lower tab of
the battery cover into
the opening, and press
the cover until it clicks
in place.
Top View
Remote Control
LIGHT button
16
24
35
36
19
26 26
26
24
24 24
24
32
15
POWER buttons (ON/OFF)
ENTER button
19
KEYSTONE button
UNDO button
INPUT 1 button
INPUT 2 button
INPUT 4 button
AUTO SYNC button RESIZE button
PICTURE SETTING button
MENU button
ADJUSTMENT buttons
(∂/ƒ/ß/©)
INPUT 3 button
RGB/COMP. button
Front View
Top View
Remote control signal transmitters
Battery cover
Battery
compartment
Battery
cover
Downloaded From projector-manual.com Sharp Manuals

Important
Information
-9
Part Names
Projector
Numbers next to the part names refer to the main pages in this manual where the topic is explained.
Side and Rear View
13
13
49
Intake ventilative hole
AC socket
Intake ventilative hole
49
13
INPUT 1 COMPONENT
terminals (RCA)
INPUT 4 VIDEO terminal (RCA)
13
INPUT 3 S-VIDEO terminal
(4-pin Mini DIN)
INPUT 2 COMPONENT/
RGB port
14 RS-232C port
(9-pin D-sub)
15
Remote control sensor
12
Attaching the Lens Cap
After putting the lens cap strap on the lens cap, pass the other end of
the strap through the hole under the projector, next to the lens.
Downloaded From projector-manual.com Sharp Manuals
-11
Supplied Accessories
Remote control
Power cord
(For U.K., Hong Kong
and Singapore)
• Use the power cord that corresponds to the wall outlet in your
country.
Computer-RGB
cable
21 pin RCA
conversion adaptor
Terminal cover Lens cap
Video cable
Two AA size batteries
Lens cap strap
(For Australia
and New Zealand)
Projector Operation manual
Screws for terminal cover
(For Europe except U.K.)
Downloaded From projector-manual.com Sharp Manuals

Important
Information
-8
Part Names
Projector
Numbers next to the part names refer to the main pages in this manual where the topic is explained.
Front and Top View
POWER indicator
Exhaust ventilative hole
LAMP
REPLACEMENT indicator
TEMPERATURE
WARNING indicator
ADJUSTMENT buttons
(∂/ƒ/ß/©)
UNDO button
MENU button
RESIZE button
INPUT button
Swivel Stand
LOCK/UNLOCK lever
Remote control sensor
Lens cap
Zoom knob
Exhaust ventilative hole
Focus ring
Lens shift dial
ENTER button
KEYSTONE button
POWER buttons
(ON/OFF)
PICTURE SETTING button
Side and Rear View
Downloaded From projector-manual.com Sharp Manuals -10
Part Names
Inserting the batteries
13
Pull down the tab on the
battery cover and
remove the cover
towards the direction of
the arrow.
2Insert two AA size
batteries, making sure
the polarities match the
ⴐand ⴑmarks inside
the battery compartment.
Insert the lower tab of
the battery cover into
the opening, and press
the cover until it clicks
in place.
Top View
Remote Control
LIGHT button
16
24
35
36
19
26 26
26
24
24 24
24
32
15
POWER buttons (ON/OFF)
ENTER button
19
KEYSTONE button
UNDO button
INPUT 1 button
INPUT 2 button
INPUT 4 button
AUTO SYNC button RESIZE button
PICTURE SETTING button
MENU button
ADJUSTMENT buttons
(∂/ƒ/ß/©)
INPUT 3 button
RGB/COMP. button
Front View
Top View
Remote control signal transmitters
Battery cover
Battery
compartment
Battery
cover
Downloaded From projector-manual.com Sharp Manuals

Important
Information
-9
Part Names
Projector
Numbers next to the part names refer to the main pages in this manual where the topic is explained.
Side and Rear View
Intake ventilative hole
AC socket
Intake ventilative hole
INPUT 1 COMPONENT
terminals (RCA)
INPUT 4 VIDEO terminal (RCA)
INPUT 3 S-VIDEO terminal
(4-pin Mini DIN)
INPUT 2 COMPONENT/
RGB port
RS-232C port
(9-pin D-sub)
Remote control sensor
Attaching the Lens Cap
After putting the lens cap strap on the lens cap, pass the other end of
the strap through the hole under the projector, next to the lens.
Downloaded From projector-manual.com Sharp Manuals
-11
Supplied Accessories
Remote control
Power cord
(For U.K., Hong Kong
and Singapore)
• Use the power cord that corresponds to the wall outlet in your
country.
Computer-RGB
cable
21 pin RCA
conversion adaptor
Terminal cover Lens cap
Video cable
Two AA size batteries
Lens cap strap
(For Australia
and New Zealand)
Projector Operation manual
Screws for terminal cover
(For Europe except U.K.)
Downloaded From projector-manual.com Sharp Manuals

Setup & Connections
-12
Power Supply
Connecting the Power Cord
Plug the supplied power cord into the AC socket on the back of the projector.
Connections
Power cord
CAUTION
• Make sure the power cord is firmly connected into the AC socket.
• The projector will enter the standby mode as you re-plug it into the AC socket, when unplugging the power cord after turning the power
off by pressing the POWER button. However, if the projector was turned off by disconnecting the power cord or by a power failure, the
projector will automatically turn on when plugging the power cord again.
1Connect one end of the S-video cable (commercially
available) to the INPUT 3 S-VIDEO terminal, or one end
of the video cable to the INPUT 4 VIDEO terminal on
the projector.
2Connect the other end of the S-video cable or the video
cable to the S-video output or Video output terminal of
the video source.
The S-video input terminal uses a video signal system where
the picture is separated into a colour and luminance signal
to realise a higher-quality image.
• For higher quality video, you may use the S-video input terminal on the
projector. An S-video cable is commercially available.
• If your video equipment does not have an S-video output terminal, use
the composite video output terminal.
Connecting to Video Equipment
Connecting a video source (VCR, laser disc player, DVD player or DTV decoder) using the INPUT 3
S-VIDEO and INPUT 4 VIDEO terminals
You can connect your projector to a VCR, laser disc player, DVD player, DTV* decoder and other video equipment.
* DTV is the umbrella term used to describe the new digital television system in the United States.
CAUTION
• Make sure to turn both the projector and the video equipment off, before connecting.
• As this projector is not equipped with audio input terminals, commercially available audio equipment or your own equipment (such as
speakers or amplifiers) should be used.
Downloaded From projector-manual.com Sharp Manuals
-14
Connecting a computer with analog RGB output
1
2
“ ” “ ”
RGB/COMP.
Connecting to a Computer
12
Connecting to a DVD Player and DTV Decoder
Connecting to a DTV decoder with analog RGB output
1
2
“ ” “ ”
RGB/COMP.
CAUTION
•
DTV decoder
Projector
1
2
Downloaded From projector-manual.com Sharp Manuals

-1
Important
Information
IMPORTANT
For your assistance in reporting the loss or theft of your
Projector, please record the Serial Number located on
the bottom of the projector and retain this information.
Before recycling the packaging, please be sure that
you have checked the contents of the carton thoroughly
against the list of “Supplied Accessories” on page 11.
Before using the projector, please read this operation manual carefully.
OPERATION MANUAL ENGLISH
Model No.: XV -Z91E
Serial No.:
ENGLISH
WARNING:
To reduce the risk of fire or electric shock, do not expose this product to rain or moisture.
WARNING:
Intense light source. Do not look into the beam or view it directly. Be especially careful that children do not look
directly into the beam.
CAUTION:
To reduce the risk of electric shock, do not remove cabinet. No user-serviceable parts are inside. Refer servicing
to qualified service personnel.
WARNING:
The cooling fan in this projector continues to run for about 90 seconds after the projector is turned off. During
normal operation, when turning the power off always use the OFF button on the projector or on the remote
control. Ensure the cooling fan has stopped before disconnecting the power cord.
DURING NORMAL OPERATION, NEVER TURN THE PROJECTOR OFF BY DISCONNECTING THE POWER
CORD. FAILURE TO OBSERVE THIS WILL RESULT IN PREMATURE LAMP FAILURE.
Downloaded From projector-manual.com Sharp Manuals
-3
Important
Information
IMPORTANT SAFEGUARDS
ATTENTION: Please read all of these instructions before you operate your Projector for
the first time. Save these instructions for future reference.
ForyourownprotectionandprolongedoperationofyourProjector,besuretoreadthefollowing “IMPORTANT
SAFEGUARDS ”carefully,beforeuse.
Thisprojectorhasbeenengineeredandmanufacturedtoensureyourpersonalsafety.ButIMPROPERUSECAN
RESULT IN POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARDS. In order not to defeat the safeguards
incorporatedintothisProjector,observethefollowingbasicrulesforitsinstallation,useandservicing.
17. UnplugtheProjectorequipmentfromthewalloutletand
referservicingtoqualifiedservicepersonnelunderthe
followingconditions:
a. Whenthepowercordorplugisdamagedorfrayed.
b. IfliquidhasbeenspilledintotheProjector.
c. IftheProjectorhasbeenexposedtorainorwater.
d. IftheProjectordoes not operate normally when
youfollowtheoperatinginstructions.Adjustonly
thosecontrolsthatarecoveredbytheoperating
instructions, as improper adjustment of other
controlsmaycausedamageandwilloftenrequire
extensiveworkbyaqualifiedtechniciantorestore
theProjectortonormaloperation.
e. IftheProjectorhasbeendroppedorthecabinet
hasbeendamaged.
f. WhentheProjectorexhibitsadistinctchangein
performance —thisindicatesaneedforservice.
18. Whenreplacementpartsarerequired,besuretheser-
vicetechnicianhasusedreplacementpartsspecifiedby
themanufacturerthathavethesamecharacteristicsas
theoriginalparts.Unauthorisedsubstitutionsmayresult
infire,electricshock,orotherhazards.
19. ThisProjectorisprovidedwithoneofthefollowingtypes
ofplugs.Iftheplugshouldfailtofitintothepoweroutlet,
pleasecontactyourelectrician.
Donotdefeatthesafetypurposeoftheplug.
a. Two-wiretypemainsplug.
b. Three-wire grounding type mains plug with a
groundingterminal.
Thisplugwillonlyfitintoagroundingtypepower
outlet.
1. UnplugtheProjectorfromthewalloutletbeforecleaning.
2. Do not use liquid cleaners or aerosol cleaners. Use a
dampclothforcleaning.
3. Do not use attachments not recommended by the
Projectormanufacturer,astheymaycausehazards.
4. DonotusetheProjectornearwater;forexample,neara
bathtub,washbowl, kitchen sink,laundrytub,in awet
basement,nearaswimmingpool,etc.Neverspillliquid
intotheprojector.
5. DonotplacetheProjectoronanunstablecart,stand,or
table.TheProjectormayfall,whichmaycauseserious
injurytoachildoranadult,and/orseriousdamagetothe
unit.
6. Wall or Ceiling Mounting —The product should be
mountedtoawallorceilingonlyasrecommendedby
themanufacturer.
7. Projector equipment and cart
combinations should be moved
withcare.Quickstops,excessive
force,andunevensurfacesmay
cause the equipment and cart
combinationtooverturn.
8. Slotsandopeningsinthecabinetbackandbottomare
providedforventilation.Toensurereliableoperationof
the Projector and to protect it from overheating, these
openingsmustnotbeblockedorcovered.Theopenings
shouldneverbecoveredwithclothorothermaterial.
9. This Projector should never be placed near or over a
radiator or heating vent. The Projector should not be
placedinabuilt-ininstallationsuchasabookcaseunless
properventilationisprovided.
10. TheProjectorshouldbeoperatedonlyfromthetypeof
powersourceindicatedonthebackoftheprojectororin
thespecifications.Ifyouarenotsureofthetypeofpower
suppliedtoyourhome,consultyourProjectordealeror
localpowercompany.
11. DonotplacetheProjectorwherethecordwillbeabused
bypersonswalkingonit.
12. Follow all warnings and instructions marked on the
Projector.
13. Topreventdamagetotheprojectorduetolightningand
power-linesurges,unplugtheprojectorfromthepower
outlet,whennotinuse.
14. Donotoverloadwalloutletsandextensioncordswithtoo
manyproducts,becausethiscanresultinfireorelectric
shock.
15. NeverpushobjectsofanykindintotheProjectorthrough
thecabinetslotsastheymaytouchhigh-voltagepoints
orcauseashortcircuit.Thiscouldresultinafireorelectric
shock.
16. DonotattempttoservicetheProjectoryourself.Opening
orremovingcoversmayexposeyoutodangerousvoltage
orotherhazards.Referallservicingtoqualifiedservice
personnel.
Downloaded From projector-manual.com Sharp Manuals
-5
Important
Information
IMPORTANT SAFEGUARDS
Temperature Monitor Function
Iftheprojectorstartstooverheatduetosetupproblems, “TEMP. ”and “ ”
willblinkinthelower-leftcornerofthepicture.Ifthetemperaturecontinuesto
rise,thelampwillturnoff,theTEMPERATUREWARNINGindicatoronthe
projectorwillblink,andaftera90-secondcooling-offperiodthepowerwill
shutoff.Referto “Lamp/MaintenanceIndicators ”onpage44fordetails.
•Thecoolingfanregulatestheinternaltemperature,anditsperformanceis
automaticallycontrolled.Thesoundofthefanmaychangeduringprojector
operationduetochangesinthefanspeed.
Lamp Monitor Function
Whentheprojectoristurnedonafterthelamphasbeenusedfor2,400hours,
“LAMP ”and “”willblinkinthelower-leftcornerofthepicturetoadviseyou
toreplacethelamp.Seepage46forlampreplacement.Ifthelamphasbeen
usedfor2,500hours,theprojectorpowerwillautomaticallyturnoffandthe
projectorwillenterstandbymode.Referto “Lamp/MaintenanceIndicators ”
onpage44fordetails.
Using the Terminal Cover
Whentheprojectorisusedonadesktop,highmountedorceilingmounted,
attachtheterminalcover(supplied)tohidetheconnectingcables.
Attaching the Terminal Cover
Alignwiththetabsontheprojectorandthenpresstheterminalcoverin
thedirectionofthearrow.
Tightenthetwoscrewsonthebottomoftheprojector.
Removing the Terminal Cover
Loosenthetwoscrewsonthebottomoftheprojector.
Raisetheterminalcoverandpullitoutinthedirectionofthearrow.
Tightenthescrews
Loosenthescrews
Downloaded From projector-manual.com Sharp Manuals
-7
Important
Information
Outstanding Features
1. DMDª* 1(Digital Micromirror Device) Chip
TheDMDChipallowsforahighercontrastimage.Itenablessmootherexpressionofdetailsofanimage,
andhighpicturequalityforanexcitingtheatreexperience.
*1DigitalLightProcessing,DLP,DigitalMicromirrorDeviceandDMDaretrademarksofTexasInstruments.
2. Five Speed Primary Colour Wheel
Thecolourwheelconsistsofonlythethreeprimarycoloursofthelightandcreatesahighercontrastimage
withhighcolourpurity.
3. Advanced Video Circuitry
Thevideocircuitsetupisdesignedforobtainingoptimalimagesfromaudiovisualequipment.Thecircuit
optimizeshighopticalperformancethatoriginatesintheDMDchipandthefivespeedprimarycolour
wheel,torealiseoutstandingvideoimages.
4. Low Noise Design
Anewopticalenginehasbeendevelopedforthisproducttominimisefannoiseforundisturbedviewing.
5. Lens Shift Function
Thedigitalshiftfunctionopticallyadjuststheverticalpositionofimages.Thefunctionallowsforsimple
adjustmentwhensettinguptheprojectorforthefirsttime.
6. 2D Keystone Correction
The2Dkeystonecorrectionfunctionelectricallycorrectsthesizeofprojectedimages.Thefunction
enablesdiagonalprojectionandthewiderrangesettings.
7. For use with DTV* 2
AllowsprojectionofDTVimagesand16:9wide-screenimageswhenconnectedtoaDTVdecoderor
similarvideosystems.
*2DTVistheumbrellatermusedtodescribethenewdigitaltelevisionsystemintheUnitedStates.
8. Easy-to-use Graphical User Interface (GUI)
Amulti-colourmenusystem,whichallowsforsimpleimageadjustments.
9. Colour Temperature Adjustment
Thefunctioncanbeusedtoadjustthecolourtemperaturetosuitthetypeofimageinputtotheprojector.
10. Gamma Correction Function
Thegammavaluesettingcanbeadjustedaccordingtotheinputsourceforoptimalimagecontrast.
11. Picture Setting Function
Thevaluesinvariousadjustmentsettingscanbestored.Thefunctioncanbeusedtoselectthevaluesto
suitthetypeofimageinputtotheprojectorbypressingthe PICTURE SETTING buttonontheprojectoror
ontheremotecontrol.
12. Component Video Input
Utilisesacomponentvideoinputsignal(Y,P B,P R).Thevideosignalisinputasseparatecomponentsto
providesuperiorcolourandimagequality.
13. Direct Computer Compatibility
Amulti-scanRGBinputacceptssignalsfromVGA(640dots 480lines)andMacintosh(from13"compatible
computers)withouttheneedforanyadditionalhardware.
Downloaded From projector-manual.com Sharp Manuals
-13
Setup & Connections
1
2To S-video output terminal
2To video output terminal
1
Projector
VCR, Laser disc player,
DVD player or DTV decoder
Connecting to Video Equipment
Connecting to a DVD Player and DTV Decoder
2To component output
terminals
1
Component cable
(commercially available)
DVD player
or
DTV decoder
1Connect each RCA connector of a component cable to the corresponding
RCA INPUT 1 terminals on the projector.
2Connect the other end of the cable to the corresponding terminals on a DVD
player or DTV decoder.
CAUTION
•Make sure to turn both the projector and the video equipment off, before
connecting.
S-video cable (commercially available)
Video cable
Projector
Connecting to a DVD player and DTV decoder with Component output (for INPUT 1)
Connecting to a DVD player and DTV decoder with component output (for INPUT 2)
1Connect the 3 RCA to 15-pin D-Sub cable to INPUT 2 COMPONENT/RGB port on the projector.
2Use the above cables to connect the DTV decoder or DVD player.
When connecting this projector to analog RGB output of the DTV decoder, select “Component”for “Signal Type”on the
OSD menu or press RGB/COMP. on the remote control. (See page 36.)
CAUTION
•Make sure to turn both the projector and the video equipment off, before connecting.
Projector
3 RCA to 15-pin D-sub cable
(sold separately AN-C3CP) DVD player
or
DTV decoder
1
2
Downloaded From projector-manual.com Sharp Manuals
-15
Setup & Connections
Operating the Remote Control
The remote control can be used to control the projec-
tor within the range shown on the left.
• The signal from the remote control can be reflected off a
screen for easy operation. However, the effective distance
of the signal may differ due to the screen material.
Remote Control
Remote Control
45 ˚
7m
30 ˚
30 ˚
45 ˚
30 ˚
Using the remote control in a dark
room
Thebacklightsoftheoperationbuttonscanbeturned
onforfivesecondsandoffbypressing LIGHT .Ifyou
wanttoturnoffthebacklightswhiletheyareon,press
LIGHT again.
Connecting a computer with RGB output
Connectoneofthecomputer-RGBcabletotheINPUT2COMPONENT/RGBportontheprojector.
ConnecttheotherendtotheCorrespondingterminalonacomputer.
•Makesuretoturnboththeprojectorandthevideoequipmentoff,beforeconnecting.
ConnectanRS-232Ccable(nullmodem,crosstype,commerciallyavailable)totheserialportonthecomputer.
CAUTION
•DonotconnectordisconnectanRS-232Ccabletoorfromthecomputerwhileitison.Thismaydamageyourcomputer.
•Referto “ComputerCompatibilityChart ”onpage54foralistofcomputersignalscompatiblewiththeprojector.Usewithcomputer
signalsotherthanthoselistedmaycausesomeofthefunctionsnottowork.
•TheRS-232Cfunctionmaynotoperateifyourcomputerportisnotcorrectlysetup.Pleaserefertotheoperationmanualofthe computerfor
details.
•Thearrows( , )intheconfigurationaboveindicatethedirectionofthesignals.
•AMacintoshadaptormayberequiredforusewithsomeMacintoshcomputers.ContactyournearestSharpAuthorisedProjectorDeal eror
ServiceCentre.
Connecting to a Computer
Computer-RGBcable
LIGHTbutton
Downloaded From projector-manual.com Sharp Manuals
-17
Setup & Connections
Using the Swivel Stand
Setting Up the Screen
Youcanadjusttheangleanddirectionoftheprojectedimagebyusing
theSwivelStand.
UnlocktheleverontheSwivelStand.
Adjusttheangleanddirectionoftheprojectedimageasyouwant
byliftinguptheprojectorandrotatingtheprojectorontheSwivel
Stand.
LocktheleverontheSwivelStand.
CAUTION
•Donotholdthelenswhenlifting,loweringorrotatingtheprojector.
•Whenloweringtheprojector,becarefulnottogetyourfingerscaughtinthe
areabetweentheSwivelStandandtheprojector.
•Whentheheightordirectionoftheprojectorisadjusted,theimagemaybecome
distorted (keystoned), depending on the relativepositions of the projector
andthescreen.Seepage19fordetailsonthekeystonecorrection.
Removing the Swivel Stand
Lifttheprojector( )withpressingtheremoving-standbuttononthe
backoftheprojector( ).
Attaching the Swivel Stand
Alignthetabsonthefrontbottomoftheprojector( ).Whileholding
downthebutton( ),placetheprojectorontotheSwivelStand( )to
attach.
Presstheprojectordownfirmlytoattach
ittotheSwivelStandtomakesureitis
securelyattachedtotheSwivelStand.
Adjustableupto
–10 °fromthe
standardposition.
Adjustableupto
–25 °fromthe
standardposition.
Adjustableupto
–3 °fromthe
standardposition.
Removing-
standbutton
Downloaded From projector-manual.com Sharp Manuals
-19
Setup & Connections
Keystone Correction
This function can be used to adjust the Keystone
settings.
•Fordetailsaboutusingthemenuscreen,seepage26.
Description of 2D Keystone Correction
Selected item Description
Horizontal Keystone Correction
Vertical Keystone Correction
Press KEYSTONE on the projector or on the
remotecontrol.
Press /to select “H Keystone ”or “V
Keystone ”.
Press /tomovethe markontheselected
adjustmentitemtothedesiredsetting.
Toreturntothenormalscreen,press KEYSTONE
again.
•Straightlinesandtheedgesofthedisplayedimagemay
appearjagged,whenadjustingtheKeystonesetting.
•Whenadjusting “HKeystone ”and “VKeystone ”atthesame
time, the values of adjustable angles for each setting
becomesmaller.
•The “DigitalShift ”and “Subtitle ”cannotbeadjustedwhen
Keystonecorrectionisapplied.
Downloaded From projector-manual.com Sharp Manuals
-21
Setup & Connections
Adjusting the Projection Distance
•Refertopages19and20aboutthefunctionofKeystonecorrectionandplacementofprojectorusingthecorrection.
•Decidetheplacementoftheprojectorreferringtothefiguresonthetableandthediagrambelowaccordingtothesizeof
yourscreenandtheinputsignal.
(a) Maximumprojectiondistance
(b) Minimumprojectiondistance
(c) Horizontalplacementrangewhenprojectiondistanceismaximum.
(d) Horizontalplacementrangewhenprojectiondistanceisminimum.
(e) Verticalplacementrangewhenprojectiondistanceismaximum.
(f) Verticalplacementrangewhenprojectiondistanceisminimum.
•Theaspectratiooftheprojectedimageshiftsslightlywhenthe
lensshiftisatapositionotherthanthetopposition.
•Theaspectratiooftheprojectedimagealsoshiftsslightly
whenthe “HKeystone ”and “VKeystone ”functionsare
adjustedsimultaneously.
•KeystonecorrectioncannotbeappliedtoOnScreenDisplay.
•WhenKeystonecorrectionisapplied,theresolutionofimage
canbedeterioratedtosomeextent.
•Thereareerrorsof–3%intheformulasbelow.
When using a
normal screen (4:3)
When using a wide
screen (16:9)
Screensize
(4:3)( )
ProjectiondistanceandKeystonecorrection
Maximumprojectiondistance Minimumprojectiondistance
HorizontalPlacementrange(d)
Diag.
508cm (200")
381cm (150")
254cm (100")
213cm (84")
183cm (72")
152cm (60")
102cm (40")
HorizontalPlacementrange(c)
Projection
distance(a)
–
5.6m (18’ 5")
3.7m (12’ 3")
3.1m (10’ 2")
2.7m (8’ 9")
2.2m (7’ 3")
1.5m (4’11")
Composite,S-video
480 /P,1080
–
1.7m (5’ 7")
1.1m (3’ 7")
0.9m (2’11")
0.8m (2’ 7")
0.6m (1’12")
0.4m (1’ 4")
720P
–
1.2m (3’11")
0.8m (2’ 7")
0.6m (1’12")
0.5m (1’ 8")
0.4m (1’ 4")
0.3m (12")
RGB
–
0.9m (2’11")
0.6m (1’12")
0.5m (1’ 8")
0.4m (1’ 4")
0.3m (12")
0.2m ( 8")
Vertical
placementrange
(e)
–
1.2m (3’11")
0.8m (2’ 7")
0.7m (2’ 4")
0.6m (1’12")
0.5m (1’ 8")
0.3m (12")
Projection
distance(b)
6.2m (20’ 4")
4.6m (15’ 3")
3.1m (10’ 2")
2.6m (8’ 6")
2.2m (7’ 3")
1.8m (6")
1.2m (3’11")
Composite,S-video
480 /P,1080
1.5m (4’11")
1.1m (3’ 7")
0.7m (2’ 4")
0.6m (1’12")
0.5m (1’ 8")
0.4m (1’ 4")
0.3m (12")
720P
1.1m (3’ 7")
0.8m (2’ 7")
0.5m (1’ 8")
0.4m (1’ 4")
0.3m (12")
0.3m (12")
0.2m ( 8")
RGB
0.8m (2’ 7")
0.6m (1’12")
0.4m (1’ 4")
0.3m (12")
0.3m (12")
0.2m ( 8")
0.1m ( 4")
Vertical
placementrange
(f)
1.4m (4’ 7")
1.0m (3’ 3")
0.7m (2’ 4")
0.5m (1’ 8")
0.5m (1’ 8")
0.4m (1’ 4")
0.2m ( 8")
Screensize
(16:9)( )
ProjectiondistanceandKeystonecorrection
Maximumprojectiondistance Minimumprojectiondistance
Diag.
508cm (200")
381cm (150")
338cm (133")
269cm (106")
254cm (100")
234cm (92")
213cm (84")
183cm (72")
152cm (60")
102cm (40")
Projection
distance(a)
8.2m (26’11")
6.1m (20’ 1")
5.4m (17’10")
4.3m (14’ 2")
4.1m (13’ 4")
3.7m (12’ 3")
3.4m (11’ 2")
2.9m (9’ 7")
2.4m (7’11")
1.6m (5’ 3")
Composite,S-video
480 /P,1080
2.5m (8’ 2")
1.8m (5’11")
1.6m (5’ 3")
1.3m (4’ 3")
1.2m (3’11")
1.1m (3’ 7")
1.0m (3’ 3")
0.8m (2’ 7")
0.7m (2’ 4")
0.4m (1’ 4")
720P
1.8m (5’11")
1.3m (4’ 3")
1.1m (3’ 7")
0.9m (2’11")
0.9m (2’11")
0.8m (2’ 7")
0.7m (2’ 4")
0.6m (1’12")
0.5m (1’ 8")
0.3m (12")
RGB
1.4m (4’ 7")
1.0m (3’ 3")
0.9m (2’11")
0.7m (2’ 4")
0.7m (2’ 4")
0.6m (1’12")
0.5m (1’ 8")
0.4m (1’ 4")
0.4m (1’ 4")
0.2m ( 8")
Vertical
placementrange
(e)
1.8m (5’11")
1.4m (4’ 7")
1.2m (3’11")
0.9m (2’11")
0.9m (2’11")
0.8m (2’ 7")
0.7m (2’ 4")
0.6m (1’12")
0.5m (1’ 8")
0.3m (12")
Projection
distance(b)
6.8m (22’ 2")
5.1m (16’ 7")
4.5m (14’ 9")
3.6m (11’ 8")
3.4m (11’)
3.1m (10’ 2")
2.8m (9’ 3")
2.4m (7’11")
2.0m (6’ 7")
1.3m (4’ 3")
Composite,S-video
480 /P,1080
1.6m (5’ 3")
1.2m (3’11")
1.1m (3’ 7")
0.8m (2’ 7")
0.8m (2’ 7")
0.7m (2’ 4")
0.6m (1’12")
0.5m (1’ 8")
0.4m (1’ 4")
0.3m (12")
720P
1.2m (3’11")
0.9m (2’11")
0.8m (2’ 7")
0.6m (1’12")
0.6m (1’12")
0.5m (1’ 8")
0.5m (1’ 8")
0.4m (1’ 4")
0.3m (12")
0.2m ( 8")
RGB
0.9m (2’11")
0.7m (2’ 4")
0.6m (1’12")
0.5m (1’ 8")
0.4m (1’ 4")
0.4m (1’ 4")
0.4m (1’ 4")
0.3m (12")
0.2m ( 8")
0.1m ( 4")
Vertical
placementrange
(f)
1.5m (4’11")
1.1m (3’ 7")
1.0m (3’ 3")
0.8m (2’ 7")
0.7m (2’ 4")
0.7m (2’ 4")
0.6m (1’12")
0.5m (1’ 8")
0.4m (1’ 4")
0.2m ( 8")
HorizontalPlacementrange(c) HorizontalPlacementrange(d)
Downloaded From projector-manual.com Sharp Manuals
-23
Setup & Connections
Rear Projection
•Placeatranslucentscreenbetweentheprojectorand
theaudience.
•Use the projector ’s menu screen to reverse the
projected image. (See page 42 for use of this
function.)
•Optimalimagequalitycanbeachievedwhentheprojector
ispositionedperpendiculartothescreenwithallfeetflat
andleveled.
Projection Using a Mirror
•When the distance between the projector and a
screenisnotsufficientfornormalrearprojection,you
canuseamirrortoreflecttheimageontothescreen.
•Placeamirror(normalflattype)infrontofthelens.
•Projectthenormalimageontothemirror.
•Theimagereflectedfromthemirrorisprojectedonto
thetranslucentscreen.
CAUTION
•Whenusingamirror,besuretocarefullypositionboththe
projectorandthemirrorsothelightdoesnotshineintothe
eyesoftheaudience.
•ItisrecommendedthatyouusetheoptionalSharp
ceiling-mountbracketforthisinstallation.
•Before mounting the projector, remove the Swivel
Stand.(Seepage17forremovingandattachingthe
SwivelStand.)
•Beforemountingtheprojector,contactyournearest
SharpAuthorisedProjectorDealerorServiceCentre
to obtain the recommended ceiling-mount bracket
(soldseparately).(AN-TK202ceiling-mountbracket,
AN-TK201extensiontube,AN-60KTceilingadaptors
forAN-TK202orAN-TK201)
•Whentheprojectorisintheinvertedposition,usethe
upperedgeofthescreenasthebaseline.
•Use the projector ’s menu screen to select the
appropriateprojectionmode.(Seepage42foruse
ofthisfunction.)
Ceiling-mount Projection
Image Projection
Downloaded From projector-manual.com Sharp Manuals
-25
Operation Buttons
Adjusting the Picture Aspect Ratio
Downloaded From projector-manual.com Sharp Manuals

Setup & Connections
-12
Power Supply
Connecting the Power Cord
Plug the supplied power cord into the AC socket on the back of the projector.
Connections
Power cord
CAUTION
• Make sure the power cord is firmly connected into the AC socket.
• The projector will enter the standby mode as you re-plug it into the AC socket, when unplugging the power cord after turning the power
off by pressing the POWER button. However, if the projector was turned off by disconnecting the power cord or by a power failure, the
projector will automatically turn on when plugging the power cord again.
1Connect one end of the S-video cable (commercially
available) to the INPUT 3 S-VIDEO terminal, or one end
of the video cable to the INPUT 4 VIDEO terminal on
the projector.
2Connect the other end of the S-video cable or the video
cable to the S-video output or Video output terminal of
the video source.
The S-video input terminal uses a video signal system where
the picture is separated into a colour and luminance signal
to realise a higher-quality image.
• For higher quality video, you may use the S-video input terminal on the
projector. An S-video cable is commercially available.
• If your video equipment does not have an S-video output terminal, use
the composite video output terminal.
Connecting to Video Equipment
Connecting a video source (VCR, laser disc player, DVD player or DTV decoder) using the INPUT 3
S-VIDEO and INPUT 4 VIDEO terminals
You can connect your projector to a VCR, laser disc player, DVD player, DTV* decoder and other video equipment.
* DTV is the umbrella term used to describe the new digital television system in the United States.
CAUTION
• Make sure to turn both the projector and the video equipment off, before connecting.
• As this projector is not equipped with audio input terminals, commercially available audio equipment or your own equipment (such as
speakers or amplifiers) should be used.
Downloaded From projector-manual.com Sharp Manuals
-14
When the RS-232C port on the projector is connected to a computer with an RS-232C cable (null modem, cross
type, commercially available), the computer can be used to control the projector and check the status of the
projector. See pages 52 and 53 for details.
Connecting a computer with analog RGB output
1Connect the computer-RGB cable end to the INPUT 2 COMPONENT/RGB port on the projector.
2Connect the other end to the computer.
When connecting this projector to a DVD player or DTV decoder, select “RGB”for “Signal Type”on the OSD menu or press
RGB/COMP. on the remote control. (See page 36.)
Connecting to a Computer
Computer-RGB cable
RS-232C cable
(null modem, cross type, commercially available)
12
Connecting to a DVD Player and DTV Decoder
Connecting to a DTV decoder with analog RGB output
1Connect the computer-RGB cable to the INPUT 2 COMPONENT/RGB port.
2Connect the other end to the corresponding terminal on a DTV decoder.
When connecting this projector to analog RGB output of the DTV decoder, select “Component”for “Signal Type”on the
OSD menu or press RGB/COMP. on the remote control. (See page 36.)
CAUTION
•Make sure to turn both the projector and the video equipment off, before connecting.
DTV decoder
Projector
Computer-RGB cable
1
2
Downloaded From projector-manual.com Sharp Manuals

-1
Important
Information
IMPORTANT
For your assistance in reporting the loss or theft of your
Projector, please record the Serial Number located on
the bottom of the projector and retain this information.
Before recycling the packaging, please be sure that
you have checked the contents of the carton thoroughly
against the list of “Supplied Accessories” on page 11.
Before using the projector, please read this operation manual carefully.
OPERATION MANUAL ENGLISH
Model No.: XV-Z91E
Serial No.:
ENGLISH
WARNING:
To reduce the risk of fire or electric shock, do not expose this product to rain or moisture.
WARNING:
Intense light source. Do not look into the beam or view it directly. Be especially careful that children do not look
directly into the beam.
CAUTION:
To reduce the risk of electric shock, do not remove cabinet. No user-serviceable parts are inside. Refer servicing
to qualified service personnel.
WARNING:
The cooling fan in this projector continues to run for about 90 seconds after the projector is turned off. During
normal operation, when turning the power off always use the OFF button on the projector or on the remote
control. Ensure the cooling fan has stopped before disconnecting the power cord.
DURING NORMAL OPERATION, NEVER TURN THE PROJECTOR OFF BY DISCONNECTING THE POWER
CORD. FAILURE TO OBSERVE THIS WILL RESULT IN PREMATURE LAMP FAILURE.
Downloaded From projector-manual.com Sharp Manuals
-3
Important
Information
IMPORTANT SAFEGUARDS
ATTENTION: Please read all of these instructions before you operate your Projector for
the first time. Save these instructions for future reference.
For your own protection and prolonged operation of your Projector, be sure to read the following “IMPORTANT
SAFEGUARDS”carefully, before use.
This projector has been engineered and manufactured to ensure your personal safety. But IMPROPER USE CAN
RESULT IN POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARDS. In order not to defeat the safeguards
incorporated into this Projector, observe the following basic rules for its installation, use and servicing.
17. Unplug the Projector equipment from the wall outlet and
refer servicing to qualified service personnel under the
following conditions:
a. When the power cord or plug is damaged or frayed.
b. If liquid has been spilled into the Projector.
c. If the Projector has been exposed to rain or water.
d. If the Projector does not operate normally when
you follow the operating instructions. Adjust only
those controls that are covered by the operating
instructions, as improper adjustment of other
controls may cause damage and will often require
extensive work by a qualified technician to restore
the Projector to normal operation.
e. If the Projector has been dropped or the cabinet
has been damaged.
f. When the Projector exhibits a distinct change in
performance—this indicates a need for service.
18. When replacement parts are required, be sure the ser-
vice technician has used replacement parts specified by
the manufacturer that have the same characteristics as
the original parts. Unauthorised substitutions may result
in fire, electric shock, or other hazards.
19. This Projector is provided with one of the following types
of plugs. If the plug should fail to fit into the power outlet,
please contact your electrician.
Do not defeat the safety purpose of the plug.
a. Two-wire type mains plug.
b. Three-wire grounding type mains plug with a
grounding terminal.
This plug will only fit into a grounding type power
outlet.
1. Unplug the Projector from the wall outlet before cleaning.
2. Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.
3. Do not use attachments not recommended by the
Projector manufacturer, as they may cause hazards.
4. Do not use the Projector near water; for example, near a
bathtub, washbowl, kitchen sink, laundry tub, in a wet
basement, near a swimming pool, etc. Never spill liquid
into the projector.
5. Do not place the Projector on an unstable cart, stand, or
table. The Projector may fall, which may cause serious
injury to a child or an adult, and/or serious damage to the
unit.
6. Wall or Ceiling Mounting—The product should be
mounted to a wall or ceiling only as recommended by
the manufacturer.
7. Projector equipment and cart
combinations should be moved
with care. Quick stops, excessive
force, and uneven surfaces may
cause the equipment and cart
combination to overturn.
8. Slots and openings in the cabinet back and bottom are
provided for ventilation. To ensure reliable operation of
the Projector and to protect it from overheating, these
openings must not be blocked or covered. The openings
should never be covered with cloth or other material.
9. This Projector should never be placed near or over a
radiator or heating vent. The Projector should not be
placed in a built-in installation such as a bookcase unless
proper ventilation is provided.
10. The Projector should be operated only from the type of
power source indicated on the back of the projector or in
the specifications. If you are not sure of the type of power
supplied to your home, consult your Projector dealer or
local power company.
11. Do not place the Projector where the cord will be abused
by persons walking on it.
12. Follow all warnings and instructions marked on the
Projector.
13. To prevent damage to the projector due to lightning and
power-line surges, unplug the projector from the power
outlet, when not in use.
14. Do not overload wall outlets and extension cords with too
many products, because this can result in fire or electric
shock.
15. Never push objects of any kind into the Projector through
the cabinet slots as they may touch high-voltage points
or cause a short circuit. This could result in a fire or electric
shock.
16. Do not attempt to service the Projector yourself. Opening
or removing covers may expose you to dangerous voltage
or other hazards. Refer all servicing to qualified service
personnel.
Downloaded From projector-manual.com Sharp Manuals
-5
Important
Information
IMPORTANT SAFEGUARDS
Temperature Monitor Function
If the projector starts to overheat due to setup problems, “TEMP.”and “ ”
will blink in the lower-left corner of the picture. If the temperature continues to
rise, the lamp will turn off, the TEMPERATURE WARNING indicator on the
projector will blink, and after a 90-second cooling-off period the power will
shut off. Refer to “Lamp/Maintenance Indicators”on page 44 for details.
•The cooling fan regulates the internal temperature, and its performance is
automatically controlled. The sound of the fan may change during projector
operation due to changes in the fan speed.
Lamp Monitor Function
When the projector is turned on after the lamp has been used for 2,400 hours,
“LAMP”and “”will blink in the lower-left corner of the picture to advise you
to replace the lamp. See page 46 for lamp replacement. If the lamp has been
used for 2,500 hours, the projector power will automatically turn off and the
projector will enter standby mode. Refer to “Lamp/Maintenance Indicators”
on page 44 for details.
Using the Terminal Cover
When the projector is used on a desktop, high mounted or ceiling mounted,
attach the terminal cover (supplied) to hide the connecting cables.
Attaching the Terminal Cover
Align with the tabs on the projector and then press the terminal cover in
the direction of the arrow.
Tighten the two screws on the bottom of the projector.
Removing the Terminal Cover
Loosen the two screws on the bottom of the projector.
Raise the terminal cover and pull it out in the direction of the arrow.
Tighten the screws
Loosen the screws
Downloaded From projector-manual.com Sharp Manuals
-7
Important
Information
Outstanding Features
1. DMDª* 1(Digital Micromirror Device) Chip
The DMD Chip allows for a higher contrast image. It enables smoother expression of details of an image,
and high picture quality for an exciting theatre experience.
*1Digital Light Processing, DLP, Digital Micromirror Device and DMD are trademarks of Texas Instruments.
2. Five Speed Primary Colour Wheel
The colour wheel consists of only the three primary colours of the light and creates a higher contrast image
with high colour purity.
3. Advanced Video Circuitry
The video circuit setup is designed for obtaining optimal images from audiovisual equipment. The circuit
optimizes high optical performance that originates in the DMD chip and the five speed primary colour
wheel, to realise outstanding video images.
4. Low Noise Design
A new optical engine has been developed for this product to minimise fan noise for undisturbed viewing.
5. Lens Shift Function
The digital shift function optically adjusts the vertical position of images. The function allows for simple
adjustment when setting up the projector for the first time.
6. 2D Keystone Correction
The 2D keystone correction function electrically corrects the size of projected images. The function
enables diagonal projection and the wider range settings.
7. For use with DTV*2
Allows projection of DTV images and 16:9 wide-screen images when connected to a DTV decoder or
similar video systems.
*2DTV is the umbrella term used to describe the new digital television system in the United States.
8. Easy-to-use Graphical User Interface (GUI)
A multi-colour menu system, which allows for simple image adjustments.
9. Colour Temperature Adjustment
The function can be used to adjust the colour temperature to suit the type of image input to the projector.
10. Gamma Correction Function
The gamma value setting can be adjusted according to the input source for optimal image contrast.
11. Picture Setting Function
The values in various adjustment settings can be stored. The function can be used to select the values to
suit the type of image input to the projector by pressing the PICTURE SETTING button on the projector or
on the remote control.
12. Component Video Input
Utilises a component video input signal (Y, PB, PR). The video signal is input as separate components to
provide superior colour and image quality.
13. Direct Computer Compatibility
A multi-scan RGB input accepts signals from VGA (640 dots 2480 lines) and Macintosh (from 13" compatible
computers) without the need for any additional hardware.
Downloaded From projector-manual.com Sharp Manuals
-13
Setup & Connections




Projector
VCR, Laser disc player,
DVD player or DTV decoder
Connecting to Video Equipment
Connecting to a DVD Player and DTV Decoder


DVD player
or
DTV decoder


CAUTION
•
Projector
Connecting to a DVD player and DTV decoder with Component output (for INPUT 1)
Connecting to a DVD player and DTV decoder with component output (for INPUT 2)


“ ” “ ”
RGB/COMP.
CAUTION
•
Projector
DVD player
or
DTV decoder


Downloaded From projector-manual.com Sharp Manuals
-15
Setup & Connections
Operating the Remote Control
The remote control can be used to control the projec-
tor within the range shown on the left.
• The signal from the remote control can be reflected off a
screen for easy operation. However, the effective distance
of the signal may differ due to the screen material.
Remote Control
Remote Control
45˚
7 m
30˚
30˚
45˚
30˚
Using the remote control in a dark
room
The backlights of the operation buttons can be turned
on for five seconds and off by pressing LIGHT. If you
want to turn off the backlights while they are on, press
LIGHT again.
Connecting a computer with RGB output
1Connect one of the computer-RGB cable to the INPUT 2 COMPONENT/RGB port on the projector.
2Connect the other end to the Corresponding terminal on a computer.
•Make sure to turn both the projector and the video equipment off, before connecting.
Connect an RS-232C cable (null modem, cross type, commercially available) to the serial port on the computer.
CAUTION
•Do not connect or disconnect an RS-232C cable to or from the computer while it is on. This may damage your computer.
•Refer to “Computer Compatibility Chart”on page 54 for a list of computer signals compatible with the projector. Use with computer
signals other than those listed may cause some of the functions not to work.
•The RS-232C function may not operate if your computer port is not correctly set up. Please refer to the operation manual of the computer for
details.
•The arrows (→, ↔) in the configuration above indicate the direction of the signals.
•A Macintosh adaptor may be required for use with some Macintosh computers. Contact your nearest Sharp Authorised Projector Dealer or
Service Centre.
12
Connecting to a Computer
Computer-RGB cable
LIGHT button
Downloaded From projector-manual.com Sharp Manuals
-17
Setup & Connections
Using the Swivel Stand
Setting Up the Screen
You can adjust the angle and direction of the projected image by using
the Swivel Stand.
1Unlock the lever on the Swivel Stand.
2Adjust the angle and direction of the projected image as you want
by lifting up the projector and rotating the projector on the Swivel
Stand.
3Lock the lever on the Swivel Stand.
CAUTION
•Do not hold the lens when lifting, lowering or rotating the projector.
•When lowering the projector, be careful not to get your fingers caught in the
area between the Swivel Stand and the projector.
•When the height or direction of the projector is adjusted, the image may become
distorted (keystoned), depending on the relative positions of the projector
and the screen. See page 19 for details on the keystone correction.
1
2
3
Removing the Swivel Stand
Lift the projector (2) with pressing the removing-stand button on the
back of the projector (1).
Attaching the Swivel Stand
Align the tabs on the front bottom of the projector (1). While holding
down the button (2), place the projector onto the Swivel Stand (3) to
attach.
Press the projector down firmly to attach
it to the Swivel Stand to make sure it is
securely attached to the Swivel Stand.
Adjustable up to
±10°from the
standard position.
Adjustable up to
±25°from the
standard position.
Adjustable up to
±3°from the
standard position.
Removing-
stand button
Downloaded From projector-manual.com Sharp Manuals
-19
Setup & Connections
Keystone Correction
This function can be used to adjust the Keystone
settings.
•For details about using the menu screen, see page 26.
Description of 2D Keystone Correction
Selected item Description
Horizontal Keystone Correction
Vertical Keystone Correction
1Press KEYSTONE on the projector or on the
remote control.
2Press /to select “H Keystone”or “V
Keystone”.
3Press /to move the mark on the selected
adjustment item to the desired setting.
4To return to the normal screen, press KEYSTONE
again.
•Straight lines and the edges of the displayed image may
appear jagged, when adjusting the Keystone setting.
•When adjusting “H Keystone”and “V Keystone”at the same
time, the values of adjustable angles for each setting
become smaller.
•The “Digital Shift”and “Subtitle”cannot be adjusted when
Keystone correction is applied.
2 3
1 4
Downloaded From projector-manual.com Sharp Manuals
-21
Setup & Connections
Adjusting the Projection Distance
•Refer to pages 19 and 20 about the function of Keystone correction and placement of projector using the correction.
•Decide the placement of the projector referring to the figures on the table and the diagram below according to the size of
your screen and the input signal.
± °
(a) Maximum projection distance
(b) Minimum projection distance
(c) Horizontal placement range when projection distance is maximum.
(d) Horizontal placement range when projection distance is minimum.
(e) Vertical placement range when projection distance is maximum.
(f) Vertical placement range when projection distance is minimum.
•The aspect ratio of the projected image shifts slightly when the
lens shift is at a position other than the top position.
•The aspect ratio of the projected image also shifts slightly
when the “H Keystone”and “V Keystone”functions are
adjusted simultaneously.
•Keystone correction cannot be applied to On Screen Display.
•When Keystone correction is applied, the resolution of image
can be deteriorated to some extent.
•There are errors of ±3% in the formulas below.
When using a
normal screen (4:3)
When using a wide
screen (16:9)
Screen size
(4:3)( )
Projection distance and Keystone correction
Maximum projection distance Minimum projection distance
Horizontal Placement range (d)
Diag.
508cm (200")
381cm (150")
254cm (100")
213cm (84")
183cm (72")
152cm (60")
102cm (40")
Horizontal Placement range (c)
Projection
distance (a)
–
5.6 m (18' 5")
3.7 m (12' 3")
3.1 m (10' 2")
2.7 m (8' 9")
2.2 m (7' 3")
1.5 m (4'11")
Composite, S-video
480 /P, 1080
–
1.7 m (5' 7")
1.1 m (3' 7")
0.9 m (2'11")
0.8 m (2' 7")
0.6 m (1'12")
0.4 m (1' 4")
720P
–
1.2 m (3'11")
0.8 m (2' 7")
0.6 m (1'12")
0.5 m (1' 8")
0.4 m (1' 4")
0.3 m (12")
RGB
–
0.9 m (2'11")
0.6 m (1'12")
0.5 m (1' 8")
0.4 m (1' 4")
0.3 m (12")
0.2 m ( 8")
Vertical
placement range
(e)
–
1.2 m (3'11")
0.8 m (2' 7")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.3 m (12")
Projection
distance (b)
6.2 m (20' 4")
4.6 m (15' 3")
3.1 m (10' 2")
2.6 m (8' 6")
2.2 m (7' 3")
1.8 m (6")
1.2 m (3'11")
Composite, S-video
480 /P, 1080
1.5 m (4'11")
1.1 m (3' 7")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.4 m (1' 4")
0.3 m (12")
720P
1.1 m (3' 7")
0.8m (2' 7")
0.5m (1' 8")
0.4 m (1' 4")
0.3m (12")
0.3 m (12")
0.2 m ( 8")
RGB
0.8 m (2' 7")
0.6 m (1'12")
0.4 m (1' 4")
0.3 m (12")
0.3 m (12")
0.2 m ( 8")
0.1 m ( 4")
Vertical
placement range
(f)
1.4 m (4' 7")
1.0 m (3' 3")
0.7 m (2' 4")
0.5 m (1' 8")
0.5 m (1' 8")
0.4 m (1' 4")
0.2 m ( 8")
Screen size
(16:9)( )
Projection distance and Keystone correction
Maximum projection distance Minimum projection distance
Diag.
508cm (200")
381cm (150")
338cm (133")
269cm (106")
254cm (100")
234cm (92")
213cm (84")
183cm (72")
152cm (60")
102cm (40")
Projection
distance (a)
8.2 m (26'11")
6.1 m (20' 1")
5.4 m (17'10")
4.3 m (14' 2")
4.1 m (13' 4")
3.7 m (12' 3")
3.4 m (11' 2")
2.9 m (9' 7")
2.4 m (7'11")
1.6 m (5' 3")
Composite, S-video
480 /P, 1080
2.5 m (8' 2")
1.8 m (5'11")
1.6 m (5' 3")
1.3 m (4' 3")
1.2 m (3'11")
1.1 m (3' 7")
1.0 m (3' 3")
0.8 m (2' 7")
0.7 m (2' 4")
0.4 m (1' 4")
720P
1.8 m (5'11")
1.3 m (4' 3")
1.1 m (3' 7")
0.9 m (2'11")
0.9 m (2'11")
0.8 m (2' 7")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.3 m (12")
RGB
1.4 m (4' 7")
1.0 m (3' 3")
0.9 m (2'11")
0.7 m (2' 4")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.4 m (1' 4")
0.4 m (1' 4")
0.2 m ( 8")
Vertical
placement range
(e)
1.8 m (5'11")
1.4 m (4' 7")
1.2 m (3'11")
0.9 m (2'11")
0.9 m (2'11")
0.8 m (2' 7")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.3 m (12")
Projection
distance (b)
6.8 m (22' 2")
5.1 m (16' 7")
4.5 m (14' 9")
3.6 m (11' 8")
3.4 m (11')
3.1 m (10' 2")
2.8 m (9' 3")
2.4 m (7'11")
2.0 m (6' 7")
1.3 m (4' 3")
Composite, S-video
480 /P, 1080
1.6 m (5' 3")
1.2 m (3'11")
1.1 m (3' 7")
0.8 m (2' 7")
0.8 m (2' 7")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.4 m (1' 4")
0.3 m (12")
720P
1.2 m (3'11")
0.9 m (2'11")
0.8 m (2' 7")
0.6 m (1'12")
0.6 m (1'12")
0.5 m (1' 8")
0.5 m (1' 8")
0.4 m (1' 4")
0.3 m (12")
0.2 m ( 8")
RGB
0.9 m (2'11")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.4 m (1' 4")
0.4 m (1' 4")
0.4 m (1' 4")
0.3 m (12")
0.2 m ( 8")
0.1 m ( 4")
Vertical
placement range
(f)
1.5 m (4'11")
1.1 m (3' 7")
1.0 m (3' 3")
0.8 m (2' 7")
0.7 m (2' 4")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.4 m (1' 4")
0.2 m ( 8")
Horizontal Placement range (c) Horizontal Placement range (d)
Downloaded From projector-manual.com Sharp Manuals
-23
Setup & Connections
Rear Projection
•Place a translucent screen between the projector and
the audience.
•Use the projector’s menu screen to reverse the
projected image. (See page 42 for use of this
function.)
•Optimal image quality can be achieved when the projector
is positioned perpendicular to the screen with all feet flat
and leveled.
Projection Using a Mirror
•When the distance between the projector and a
screen is not sufficient for normal rear projection, you
can use a mirror to reflect the image onto the screen.
•Place a mirror (normal flat type) in front of the lens.
•Project the normal image onto the mirror.
•The image reflected from the mirror is projected onto
the translucent screen.
CAUTION
•When using a mirror, be sure to carefully position both the
projector and the mirror so the light does not shine into the
eyes of the audience.
•It is recommended that you use the optional Sharp
ceiling-mount bracket for this installation.
•Before mounting the projector, remove the Swivel
Stand. (See page 17 for removing and attaching the
Swivel Stand.)
•Before mounting the projector, contact your nearest
Sharp Authorised Projector Dealer or Service Centre
to obtain the recommended ceiling-mount bracket
(sold separately). (AN-TK202 ceiling-mount bracket,
AN-TK201 extension tube, AN-60KT ceiling adaptors
for AN-TK202 or AN-TK201)
•When the projector is in the inverted position, use the
upper edge of the screen as the base line.
•Use the projector’s menu screen to select the
appropriate projection mode. (See page 42 for use
of this function.)
Ceiling-mount Projection
Image Projection
Downloaded From projector-manual.com Sharp Manuals
-25
Operation Buttons
Adjusting the Picture Aspect Ratio
↔
↔
↔
Downloaded From projector-manual.com Sharp Manuals

-16
Setup & Connections
Power ON/OFF
Press POWER ON.
•The blinking green LAMP REPLACEMENT indicator
shows that the lamp is warming up. Wait until the
indicator stops blinking before operating the projector.
•If the power is turned off and then immediately turned
on again, it may take a short while before the lamp
turns on.
•After the projector is unpacked and turned on for the first
time, a slight odor may be emitted from the exhaust
ventilative hole. This odor will soon disappear with use.
When the power is on, the LAMP REPLACEMENT
indicator illuminates, indicating the status of the
lamp.
Green: Lamp is ready.
Green blinking: Warming up. / Cooling down.
Red: Change the lamp.
Press POWER OFF.
•Press POWER OFF again while the confirmation
message is displayed. Then, message “Terminating.
Please wait.”will appear.
•If you accidentally pressed POWER OFF and do not want
to turn off the power, wait until the confirmation message
disappears.
•When POWER OFF is pressed twice, the POWER indicator
will illuminate in red and the cooling fan will run for about
90 seconds. The projector will then enter standby mode.
•Wait until the cooling fan stops running before disconnecting
the power cord.
•The power can be turned on again by pressing POWER
ON. When the power is turned on, the POWER indicator
and the LAMP REPLACEMENT indicators illuminate in
green.
TEMP. LAMP POWER
POWER (ON/OFF)
buttons
Zooming and Focusing
The picture can be zoomed in or out, and focused by the Zoom knob and the Focus ring.
1Slide the Zoom knob. The image can be adjusted
to the desired size within the zoom range.
2Rotate the Focus ring until the image on the screen
becomes clear.
1
2
A dimly lit screen is displayed for a short time
(about 20 seconds) to reduce lamp damage.
Downloaded From projector-manual.com Sharp Manuals
-18
Setup & Connections
DOWN UP
Lens shift dial UP
DOWN
The picture can be adjusted within the shift range of the lens by rotating the lens shift dial on the top of the
projector using your finger.
Using the Lens Shift
Projector Projected Image
Downloaded From projector-manual.com Sharp Manuals
-20
Setup & Connections
Place the projector at a distance from the screen that allows images to
be projected onto the screen by referring to “Adjusting the Projection
Distance”on pages 21 and 22.
Placement of the Projected Image Using the Keystone Correction
: Screen area
1Project the test pattern of the Keystone correction function onto the
screen. Rotate the Focus ring until the image on the screen becomes
clear. (See page 16.)
2Change the projection angle using the Swivel Stand to properly
project images onto the screen. (See page 17).
3Align the edge of the screen closest to the projector with the test
pattern by adjusting the zoom and the Swivel Stand. (See pages 16
and 17.)
4Adjust the Keystone function so that the size of the projected image
matches the screen size. (See page 19.)
5Align the image on the screen by adjusting the zoom function and the
Swivel Stand.
6Adjust the focus so that the projected image is in focus at the centre
of the screen. (See page 16.)
•The aspect ratio of the projected image shifts slightly when the lens
shift is at a position other than the top position.
•The aspect ratio of the projected image also shifts slightly when the “H
Keystone”and “V Keystone”functions are adjusted simultaneously.
Downloaded From projector-manual.com Sharp Manuals
-22
Setup & Connections
Adjusting the Projection Distance
Upper and Lower Lens Shift Position
• This projector is equipped with a lens shift function that lets you adjust the projection height.
• Adjust it to match the setup configuration.
• The screen can be moved maximum the length of one screen vertically using the lens shift.
• Optimal image quality is produced with the projector positioned perpendicular to the screen with all feet flat and level. Tilting or angling
the projector will reduce the effectiveness of the lens shift function.
Screen size: 254 cm (100 inches)
Aspect ratio: 4:3
90
90
Screen
Upper and Lower Lens Shift Position (Ceiling Mount)
When the projector is in the inverted position, use the upper edge of the screen as the base line, and exchange
the lower and upper lens shift values.
Screen
Upper lens shift position
(High mount setup)
Lower lens shift position
(Desktop setup)
Lens centre
Lens centre
90
90
Screen size: 254 cm (100 inches)
Aspect ratio: 4:3
Lower edge of screen (White portion) =
Standard (0) point
Downloaded From projector-manual.com Sharp Manuals
-24
Operation Buttons
Selecting the Input Signal Source
Using the Operation Buttons
Press INPUT on the projector, INPUT 1, INPUT 2, INPUT 3
or INPUT 4 on the remote control to select the desired input
mode.
•When no signal is received, “NO SIGNAL”will be displayed.
When a signal that the projector is not preset to receive is
received, “NOT REG.”will be displayed.
On-screen Display
Adjusting the Picture Aspect Ratio
This function allows you to modify or customize the
picture display mode to enhance the input image.
Depending on the input signal, you can choose
NORMAL, BORDER or STRETCH image.
Press RESIZE. Each time RESIZE is pressed, the
picture mode changes as shown on the next page.
INPUT button
INPUT 1 Mode
INPUT 4 Mode
INPUT 2 Mode
INPUT 3 Mode
Downloaded From projector-manual.com Sharp Manuals

-1
Important
Information
IMPORTANT
For your assistance in reporting the loss or theft of your
Projector, please record the Serial Number located on
the bottom of the projector and retain this information.
Before recycling the packaging, please be sure that
you have checked the contents of the carton thoroughly
against the list of “Supplied Accessories” on page 11.
Before using the projector, please read this operation manual carefully.
OPERATION MANUAL ENGLISH
Model No.: XV-Z91E
Serial No.:
ENGLISH
WARNING:
To reduce the risk of fire or electric shock, do not expose this product to rain or moisture.
WARNING:
Intense light source. Do not look into the beam or view it directly. Be especially careful that children do not look
directly into the beam.
CAUTION:
To reduce the risk of electric shock, do not remove cabinet. No user-serviceable parts are inside. Refer servicing
to qualified service personnel.
WARNING:
The cooling fan in this projector continues to run for about 90 seconds after the projector is turned off. During
normal operation, when turning the power off always use the OFF button on the projector or on the remote
control. Ensure the cooling fan has stopped before disconnecting the power cord.
DURING NORMAL OPERATION, NEVER TURN THE PROJECTOR OFF BY DISCONNECTING THE POWER
CORD. FAILURE TO OBSERVE THIS WILL RESULT IN PREMATURE LAMP FAILURE.
Downloaded From projector-manual.com Sharp Manuals
-3
Important
Information
IMPORTANT SAFEGUARDS
ATTENTION: Please read all of these instructions before you operate your Projector for
the first time. Save these instructions for future reference.
For your own protection and prolonged operation of your Projector, be sure to read the following “IMPORTANT
SAFEGUARDS”carefully, before use.
This projector has been engineered and manufactured to ensure your personal safety. But IMPROPER USE CAN
RESULT IN POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARDS. In order not to defeat the safeguards
incorporated into this Projector, observe the following basic rules for its installation, use and servicing.
17. Unplug the Projector equipment from the wall outlet and
refer servicing to qualified service personnel under the
following conditions:
a. When the power cord or plug is damaged or frayed.
b. If liquid has been spilled into the Projector.
c. If the Projector has been exposed to rain or water.
d. If the Projector does not operate normally when
you follow the operating instructions. Adjust only
those controls that are covered by the operating
instructions, as improper adjustment of other
controls may cause damage and will often require
extensive work by a qualified technician to restore
the Projector to normal operation.
e. If the Projector has been dropped or the cabinet
has been damaged.
f. When the Projector exhibits a distinct change in
performance—this indicates a need for service.
18. When replacement parts are required, be sure the ser-
vice technician has used replacement parts specified by
the manufacturer that have the same characteristics as
the original parts. Unauthorised substitutions may result
in fire, electric shock, or other hazards.
19. This Projector is provided with one of the following types
of plugs. If the plug should fail to fit into the power outlet,
please contact your electrician.
Do not defeat the safety purpose of the plug.
a. Two-wire type mains plug.
b. Three-wire grounding type mains plug with a
grounding terminal.
This plug will only fit into a grounding type power
outlet.
1. Unplug the Projector from the wall outlet before cleaning.
2. Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.
3. Do not use attachments not recommended by the
Projector manufacturer, as they may cause hazards.
4. Do not use the Projector near water; for example, near a
bathtub, washbowl, kitchen sink, laundry tub, in a wet
basement, near a swimming pool, etc. Never spill liquid
into the projector.
5. Do not place the Projector on an unstable cart, stand, or
table. The Projector may fall, which may cause serious
injury to a child or an adult, and/or serious damage to the
unit.
6. Wall or Ceiling Mounting—The product should be
mounted to a wall or ceiling only as recommended by
the manufacturer.
7. Projector equipment and cart
combinations should be moved
with care. Quick stops, excessive
force, and uneven surfaces may
cause the equipment and cart
combination to overturn.
8. Slots and openings in the cabinet back and bottom are
provided for ventilation. To ensure reliable operation of
the Projector and to protect it from overheating, these
openings must not be blocked or covered. The openings
should never be covered with cloth or other material.
9. This Projector should never be placed near or over a
radiator or heating vent. The Projector should not be
placed in a built-in installation such as a bookcase unless
proper ventilation is provided.
10. The Projector should be operated only from the type of
power source indicated on the back of the projector or in
the specifications. If you are not sure of the type of power
supplied to your home, consult your Projector dealer or
local power company.
11. Do not place the Projector where the cord will be abused
by persons walking on it.
12. Follow all warnings and instructions marked on the
Projector.
13. To prevent damage to the projector due to lightning and
power-line surges, unplug the projector from the power
outlet, when not in use.
14. Do not overload wall outlets and extension cords with too
many products, because this can result in fire or electric
shock.
15. Never push objects of any kind into the Projector through
the cabinet slots as they may touch high-voltage points
or cause a short circuit. This could result in a fire or electric
shock.
16. Do not attempt to service the Projector yourself. Opening
or removing covers may expose you to dangerous voltage
or other hazards. Refer all servicing to qualified service
personnel.
Downloaded From projector-manual.com Sharp Manuals
-5
Important
Information
IMPORTANT SAFEGUARDS
Temperature Monitor Function
If the projector starts to overheat due to setup problems, “TEMP.”and “ ”
will blink in the lower-left corner of the picture. If the temperature continues to
rise, the lamp will turn off, the TEMPERATURE WARNING indicator on the
projector will blink, and after a 90-second cooling-off period the power will
shut off. Refer to “Lamp/Maintenance Indicators”on page 44 for details.
•The cooling fan regulates the internal temperature, and its performance is
automatically controlled. The sound of the fan may change during projector
operation due to changes in the fan speed.
Lamp Monitor Function
When the projector is turned on after the lamp has been used for 2,400 hours,
“LAMP”and “”will blink in the lower-left corner of the picture to advise you
to replace the lamp. See page 46 for lamp replacement. If the lamp has been
used for 2,500 hours, the projector power will automatically turn off and the
projector will enter standby mode. Refer to “Lamp/Maintenance Indicators”
on page 44 for details.
Using the Terminal Cover
When the projector is used on a desktop, high mounted or ceiling mounted,
attach the terminal cover (supplied) to hide the connecting cables.
Attaching the Terminal Cover
Align with the tabs on the projector and then press the terminal cover in
the direction of the arrow.
Tighten the two screws on the bottom of the projector.
Removing the Terminal Cover
Loosen the two screws on the bottom of the projector.
Raise the terminal cover and pull it out in the direction of the arrow.
Tighten the screws
Loosen the screws
Downloaded From projector-manual.com Sharp Manuals
-7
Important
Information
Outstanding Features
1. DMDª* 1(Digital Micromirror Device) Chip
The DMD Chip allows for a higher contrast image. It enables smoother expression of details of an image,
and high picture quality for an exciting theatre experience.
*1Digital Light Processing, DLP, Digital Micromirror Device and DMD are trademarks of Texas Instruments.
2. Five Speed Primary Colour Wheel
The colour wheel consists of only the three primary colours of the light and creates a higher contrast image
with high colour purity.
3. Advanced Video Circuitry
The video circuit setup is designed for obtaining optimal images from audiovisual equipment. The circuit
optimizes high optical performance that originates in the DMD chip and the five speed primary colour
wheel, to realise outstanding video images.
4. Low Noise Design
A new optical engine has been developed for this product to minimise fan noise for undisturbed viewing.
5. Lens Shift Function
The digital shift function optically adjusts the vertical position of images. The function allows for simple
adjustment when setting up the projector for the first time.
6. 2D Keystone Correction
The 2D keystone correction function electrically corrects the size of projected images. The function
enables diagonal projection and the wider range settings.
7. For use with DTV*2
Allows projection of DTV images and 16:9 wide-screen images when connected to a DTV decoder or
similar video systems.
*2DTV is the umbrella term used to describe the new digital television system in the United States.
8. Easy-to-use Graphical User Interface (GUI)
A multi-colour menu system, which allows for simple image adjustments.
9. Colour Temperature Adjustment
The function can be used to adjust the colour temperature to suit the type of image input to the projector.
10. Gamma Correction Function
The gamma value setting can be adjusted according to the input source for optimal image contrast.
11. Picture Setting Function
The values in various adjustment settings can be stored. The function can be used to select the values to
suit the type of image input to the projector by pressing the PICTURE SETTING button on the projector or
on the remote control.
12. Component Video Input
Utilises a component video input signal (Y, PB, PR). The video signal is input as separate components to
provide superior colour and image quality.
13. Direct Computer Compatibility
A multi-scan RGB input accepts signals from VGA (640 dots 2480 lines) and Macintosh (from 13" compatible
computers) without the need for any additional hardware.
Downloaded From projector-manual.com Sharp Manuals
-13
Setup & Connections




Projector
VCR, Laser disc player,
DVD player or DTV decoder
Connecting to Video Equipment
Connecting to a DVD Player and DTV Decoder


DVD player
or
DTV decoder


CAUTION
•
Projector
Connecting to a DVD player and DTV decoder with Component output (for INPUT 1)
Connecting to a DVD player and DTV decoder with component output (for INPUT 2)


“ ” “ ”
RGB/COMP.
CAUTION
•
Projector
DVD player
or
DTV decoder


Downloaded From projector-manual.com Sharp Manuals
-15
Setup & Connections
Operating the Remote Control
The remote control can be used to control the projec-
tor within the range shown on the left.
• The signal from the remote control can be reflected off a
screen for easy operation. However, the effective distance
of the signal may differ due to the screen material.
Remote Control
Remote Control
45˚
7 m
30˚
30˚
45˚
30˚
Using the remote control in a dark
room
The backlights of the operation buttons can be turned
on for five seconds and off by pressing LIGHT. If you
want to turn off the backlights while they are on, press
LIGHT again.
Connecting a computer with RGB output
1Connect one of the computer-RGB cable to the INPUT 2 COMPONENT/RGB port on the projector.
2Connect the other end to the Corresponding terminal on a computer.
•Make sure to turn both the projector and the video equipment off, before connecting.
Connect an RS-232C cable (null modem, cross type, commercially available) to the serial port on the computer.
CAUTION
•Do not connect or disconnect an RS-232C cable to or from the computer while it is on. This may damage your computer.
•Refer to “Computer Compatibility Chart”on page 54 for a list of computer signals compatible with the projector. Use with computer
signals other than those listed may cause some of the functions not to work.
•The RS-232C function may not operate if your computer port is not correctly set up. Please refer to the operation manual of the computer for
details.
•The arrows ( , ) in the configuration above indicate the direction of the signals.
•A Macintosh adaptor may be required for use with some Macintosh computers. Contact your nearest Sharp Authorised Projector Dealer or
Service Centre.
12
Connecting to a Computer
Computer-RGB cable
LIGHT button
Downloaded From projector-manual.com Sharp Manuals
-17
Setup & Connections
Using the Swivel Stand
Setting Up the Screen
You can adjust the angle and direction of the projected image by using
the Swivel Stand.
1Unlock the lever on the Swivel Stand.
2Adjust the angle and direction of the projected image as you want
by lifting up the projector and rotating the projector on the Swivel
Stand.
3Lock the lever on the Swivel Stand.
CAUTION
•Do not hold the lens when lifting, lowering or rotating the projector.
•When lowering the projector, be careful not to get your fingers caught in the
area between the Swivel Stand and the projector.
•When the height or direction of the projector is adjusted, the image may become
distorted (keystoned), depending on the relative positions of the projector
and the screen. See page 19 for details on the keystone correction.
1
2
3
Removing the Swivel Stand
Lift the projector (2) with pressing the removing-stand button on the
back of the projector (1).
Attaching the Swivel Stand
Align the tabs on the front bottom of the projector (1). While holding
down the button (2), place the projector onto the Swivel Stand (3) to
attach.
Press the projector down firmly to attach
it to the Swivel Stand to make sure it is
securely attached to the Swivel Stand.
1
2
13
2
Adjustable up to
±10°from the
standard position.
Adjustable up to
±25°from the
standard position.
Adjustable up to
±3°from the
standard position.
Removing-
stand button
Downloaded From projector-manual.com Sharp Manuals
-19
Setup & Connections
Keystone Correction
This function can be used to adjust the Keystone
settings.
•For details about using the menu screen, see page 26.
Description of 2D Keystone Correction
Selected item Description
Horizontal Keystone Correction
Vertical Keystone Correction
1Press KEYSTONE on the projector or on the
remote control.
2Press /to select “H Keystone”or “V
Keystone”.
3Press /to move the mark on the selected
adjustment item to the desired setting.
4To return to the normal screen, press KEYSTONE
again.
•Straight lines and the edges of the displayed image may
appear jagged, when adjusting the Keystone setting.
•When adjusting “H Keystone”and “V Keystone”at the same
time, the values of adjustable angles for each setting
become smaller.
•The “Digital Shift”and “Subtitle”cannot be adjusted when
Keystone correction is applied.
2 3
1 4
Downloaded From projector-manual.com Sharp Manuals
-21
Setup & Connections
Adjusting the Projection Distance
•Refer to pages 19 and 20 about the function of Keystone correction and placement of projector using the correction.
•Decide the placement of the projector referring to the figures on the table and the diagram below according to the size of
your screen and the input signal.
(a) Maximum projection distance
(b) Minimum projection distance
(c) Horizontal placement range when projection distance is maximum.
(d) Horizontal placement range when projection distance is minimum.
(e) Vertical placement range when projection distance is maximum.
(f) Vertical placement range when projection distance is minimum.
•The aspect ratio of the projected image shifts slightly when the
lens shift is at a position other than the top position.
•The aspect ratio of the projected image also shifts slightly
when the “H Keystone”and “V Keystone”functions are
adjusted simultaneously.
•Keystone correction cannot be applied to On Screen Display.
•When Keystone correction is applied, the resolution of image
can be deteriorated to some extent.
•There are errors of ±3% in the formulas below.
When using a
normal screen (4:3)
When using a wide
screen (16:9)
Screen size
(4:3)( )
Projection distance and Keystone correction
Maximum projection distance Minimum projection distance
Horizontal Placement range (d)
Diag.
508cm (200")
381cm (150")
254cm (100")
213cm (84")
183cm (72")
152cm (60")
102cm (40")
Horizontal Placement range (c)
Projection
distance (a)
–
5.6 m (18' 5")
3.7 m (12' 3")
3.1 m (10' 2")
2.7 m (8' 9")
2.2 m (7' 3")
1.5 m (4'11")
Composite, S-video
480 /P, 1080
–
1.7 m (5' 7")
1.1 m (3' 7")
0.9 m (2'11")
0.8 m (2' 7")
0.6 m (1'12")
0.4 m (1' 4")
720P
–
1.2 m (3'11")
0.8 m (2' 7")
0.6 m (1'12")
0.5 m (1' 8")
0.4 m (1' 4")
0.3 m (12")
RGB
–
0.9 m (2'11")
0.6 m (1'12")
0.5 m (1' 8")
0.4 m (1' 4")
0.3 m (12")
0.2 m ( 8")
Vertical
placement range
(e)
–
1.2 m (3'11")
0.8 m (2' 7")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.3 m (12")
Projection
distance (b)
6.2 m (20' 4")
4.6 m (15' 3")
3.1 m (10' 2")
2.6 m (8' 6")
2.2 m (7' 3")
1.8 m (6")
1.2 m (3'11")
Composite, S-video
480 /P, 1080
1.5 m (4'11")
1.1 m (3' 7")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.4 m (1' 4")
0.3 m (12")
720P
1.1 m (3' 7")
0.8m (2' 7")
0.5m (1' 8")
0.4 m (1' 4")
0.3m (12")
0.3 m (12")
0.2 m ( 8")
RGB
0.8 m (2' 7")
0.6 m (1'12")
0.4 m (1' 4")
0.3 m (12")
0.3 m (12")
0.2 m ( 8")
0.1 m ( 4")
Vertical
placement range
(f)
1.4 m (4' 7")
1.0 m (3' 3")
0.7 m (2' 4")
0.5 m (1' 8")
0.5 m (1' 8")
0.4 m (1' 4")
0.2 m ( 8")
Screen size
(16:9)( )
Projection distance and Keystone correction
Maximum projection distance Minimum projection distance
Diag.
508cm (200")
381cm (150")
338cm (133")
269cm (106")
254cm (100")
234cm (92")
213cm (84")
183cm (72")
152cm (60")
102cm (40")
Projection
distance (a)
8.2 m (26'11")
6.1 m (20' 1")
5.4 m (17'10")
4.3 m (14' 2")
4.1 m (13' 4")
3.7 m (12' 3")
3.4 m (11' 2")
2.9 m (9' 7")
2.4 m (7'11")
1.6 m (5' 3")
Composite, S-video
480 /P, 1080
2.5 m (8' 2")
1.8 m (5'11")
1.6 m (5' 3")
1.3 m (4' 3")
1.2 m (3'11")
1.1 m (3' 7")
1.0 m (3' 3")
0.8 m (2' 7")
0.7 m (2' 4")
0.4 m (1' 4")
720P
1.8 m (5'11")
1.3 m (4' 3")
1.1 m (3' 7")
0.9 m (2'11")
0.9 m (2'11")
0.8 m (2' 7")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.3 m (12")
RGB
1.4 m (4' 7")
1.0 m (3' 3")
0.9 m (2'11")
0.7 m (2' 4")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.4 m (1' 4")
0.4 m (1' 4")
0.2 m ( 8")
Vertical
placement range
(e)
1.8 m (5'11")
1.4 m (4' 7")
1.2 m (3'11")
0.9 m (2'11")
0.9 m (2'11")
0.8 m (2' 7")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.3 m (12")
Projection
distance (b)
6.8 m (22' 2")
5.1 m (16' 7")
4.5 m (14' 9")
3.6 m (11' 8")
3.4 m (11')
3.1 m (10' 2")
2.8 m (9' 3")
2.4 m (7'11")
2.0 m (6' 7")
1.3 m (4' 3")
Composite, S-video
480 /P, 1080
1.6 m (5' 3")
1.2 m (3'11")
1.1 m (3' 7")
0.8 m (2' 7")
0.8 m (2' 7")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.4 m (1' 4")
0.3 m (12")
720P
1.2 m (3'11")
0.9 m (2'11")
0.8 m (2' 7")
0.6 m (1'12")
0.6 m (1'12")
0.5 m (1' 8")
0.5 m (1' 8")
0.4 m (1' 4")
0.3 m (12")
0.2 m ( 8")
RGB
0.9 m (2'11")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.4 m (1' 4")
0.4 m (1' 4")
0.4 m (1' 4")
0.3 m (12")
0.2 m ( 8")
0.1 m ( 4")
Vertical
placement range
(f)
1.5 m (4'11")
1.1 m (3' 7")
1.0 m (3' 3")
0.8 m (2' 7")
0.7 m (2' 4")
0.7 m (2' 4")
0.6 m (1'12")
0.5 m (1' 8")
0.4 m (1' 4")
0.2 m ( 8")
Horizontal Placement range (c) Horizontal Placement range (d)
Downloaded From projector-manual.com Sharp Manuals
-23
Setup & Connections
Rear Projection
•Place a translucent screen between the projector and
the audience.
•Use the projector’s menu screen to reverse the
projected image. (See page 42 for use of this
function.)
•Optimal image quality can be achieved when the projector
is positioned perpendicular to the screen with all feet flat
and leveled.
Projection Using a Mirror
•When the distance between the projector and a
screen is not sufficient for normal rear projection, you
can use a mirror to reflect the image onto the screen.
•Place a mirror (normal flat type) in front of the lens.
•Project the normal image onto the mirror.
•The image reflected from the mirror is projected onto
the translucent screen.
CAUTION
•When using a mirror, be sure to carefully position both the
projector and the mirror so the light does not shine into the
eyes of the audience.
•It is recommended that you use the optional Sharp
ceiling-mount bracket for this installation.
•Before mounting the projector, remove the Swivel
Stand. (See page 17 for removing and attaching the
Swivel Stand.)
•Before mounting the projector, contact your nearest
Sharp Authorised Projector Dealer or Service Centre
to obtain the recommended ceiling-mount bracket
(sold separately). (AN-TK202 ceiling-mount bracket,
AN-TK201 extension tube, AN-60KT ceiling adaptors
for AN-TK202 or AN-TK201)
•When the projector is in the inverted position, use the
upper edge of the screen as the base line.
•Use the projector’s menu screen to select the
appropriate projection mode. (See page 42 for use
of this function.)
Ceiling-mount Projection
Image Projection
Downloaded From projector-manual.com Sharp Manuals
-25
Operation Buttons
Adjusting the Picture Aspect Ratio
Downloaded From projector-manual.com Sharp Manuals
