PR Lighting LSBAR 336 User manual

1/12
LSBAR 336
PR-6811
The user manual contains important information about the safe installation and use of a projector. Please read
and followtheseinstructionscarefullyandkeepthemanual in asafeplaceforfuture reference.
PR LIGHTING LTD.
http://www.pr-lighting.com

2/12
INDEX
NO.
CONTENTS
PAGE
1
SAFETYANDWARNINGS
3
2
INSTRUCTIONS
4
3
APPEARANCE
5
4
INSTALLATION
5
5
DMXPROTOCOL
6
6
TECHNICALDATA
7
7
CIRCUITDIAGRAMANDFIXTURECONNECTIONS
9
8
COMPONENTORDERCODES
11
ACCESSORIES
The followingitems aresupplied withthe projector and please check:
Name
Quantity
Unit
Remark
XLR connector
2
Set
Maleand female
User manual
1
Pc
Please note that as part of our ongoing commitment to continuous product development, specifications are subject tochange without notice.
Whilst every care is taken in the preparation of the manual we reserve the right to change specifications in the course of product
improvement.Thepublisherscannotbeheldresponsiblefortheaccuracyoftheinformationherein,oranyconsequencearisingfromthem.
Every unit is tested completely and packed properly by the manufacturer. Please make sure the packing and / or the unit are in good
conditionbeforeinstallationanduse.Shouldthere be any damagecaused bytransportation, consultyourdealeranddo not use the unit. Any
damagecausedbyimproperusewillnotbeassumedbythemanufacturerand/ordealer.
Any future technical change in the user manual won’t be with any further notice.
Note: Forthe productsmade by GuangzhouPRlighting Ltd,thewarranty forthe whole product is oneyear starting from the delivery date
butthelightsourceisnotwithinthewarranty.

3/12
1. SAFETYANDWARNINGS
.
NOTE
Before a projector’s installation, power-on,operationandmaintenance,pleasecarefullyread
thesafetyinformationhereinafter!
Thefollowingsafetysignsareusedintheusermanual.
Warning
User
Manual
Electrical
shock
Goggles
Protective
Gloves
Flames
High
Temperature
● When unpacking , check if there is transportation damage before using the projector. Should there be any
damagecausedbytransportation,consultyourdealerand donot use it.
●The manufacture is not responsible for loss caused by the user not following the manual or changing the
projectorashe/shelikes
●Please be noted that the damage caused by changing the projector at will isnotwarranted.
●Do not hesitate to contactthe dealer orthe manufacturer ifanyquestionsoradvice.
●The unit can be used both indoors and outdoors.ForitsIPclass,please refer totechnicaldatainthe user manual.
●The projector should be kept away from high temperature, fire, electrical surge, vibration and strong light while
beingoperated
●The projector is only intended for installation, operation and maintenance by qualified personnel. And the
operationmuststrictlyfollowtheproceduresinthe manual
●No repairable parts intheprojectoranddonotopencoversformaintenance by yourself.
●Don’t look straightly into the light sources especially for epileptics, otherwise eyes will be burned.
●Do not connect this device to any typeofdimmerpack
●lens and other optical parts shall be replaced immediately if they have deformed or been damaged, otherwise the
lightoutputwillbe compromised.
●Before operation, please confirm that all covers(housing) are on and screws tightened. It’s forbidden to use a
projectorwhilecovers(housing)areoff
●Keep the lamp clean and do not touch it with bare hands.
●While operating it, wear protective items.
●Any electrical connection must be carried out by a qualified person .
●Before installation, please confirm the voltagesupplied matcheswhatisrequiredfor theprojector
●Each projector must be properlyearthed and installedasper related electrical standards.
●Do not use power cord with its insulator damaged and connect the power cord with other cables.
●If the projector is not used or under cleaning,, please hold the plug and unplug it. Do not unplug it forcefullyor
bypullingthepower cable.
●All power cords must conform to related safety and regulations
●Do not switch on and off the projector constantly in very short intervals, otherwise the light source’s and other
electricalparts’ life willbeshortened .
●Before any installation, maintenance and cleaning work, please ensure the projector is disconnected from
powermains.
●Under normal temperature, the temperature of the housing will be 55℃; after being stable, the unit’s surface
temperaturewillbe70℃
●While operated, do not touch the metallic housing. It is very hot during operation.

4/12
●Do not mount the projector directly on inflammable surface.
●Do not project the beam straightly on combustible items and the minimum distance between the projector
and illuminateditemsis10m.
●A projector should be installed with good ventilation.
2. INSTRUCTIONS
●CLEANINGANDMAINTENANCE
For the units with optical lens, because of the accumulation of the smoke, oil and dust on lens, the light output will be
compromised. For the reliable use of the unit, it is very necessary to keep its surface clean. The unit is IP66 rating waterproof
device. Unless approval by some professional technician for necessary internal component replacement, it’s forbidden to
dismantle the unit.
Cleaning frequencyis to bedecidedby operations and its environment. Use soft cloth and normal detergent for glass for cleaning
work. It’s advised external optical system be cleaned every 20days. Keep lens clean and do not touch optical parts with bare
hands.
●Before anymaintenance and cleaning,pleaseensurethe projectisoffthepower
●Onlyqualified personisallowed todomaintenance
●Duringmaintenance and beforemaintenance, theprojectormustbe off power.
●To avoid internal damage, sun light or other light mustn’t penetrate into the projector via front lens whether
itrunsornot
●Do not use alcohol or other organic solvent to clean the housing to avoid damage.
●Do not use any solvent with chemical elements to clean color filters or hot mirror.
●TROUBLESHOOTING
PROBLEM
ACTION
The projector doesn’t switch on
Check thepowercordconnection
Power Switch fails or is not connected well, call a professional
technicianforrepairingand checking
Control board is not connected normally, call a professional technician
forrepairingandchecking ,
The projectcanbeturnedon,but theLEDlamps
can’t be on
LED lamp board is not connected well, call aprofessionaltechnician for
repairing and checking
The LEDlamps canbeon,butnot controlled
byDMX
CheckifDMXStartAddressisproperlyset
CheckifXLRcablefails ornot
Thebrightnessdecreasesobviously
Ambient temperature is too hot which makes the projector too hot,
pleasetakeappropriateventilationmeasures

5/12
3. APPEARANCE
4. INSTALLATION
●FIXINGFIXTURE(FOR REFERENCE)
Placea fixtureinthe placeto be illuminated anduse screws to tightenit.Pleasebesureit istightened.
●ADJUSTING A FIXTURE’S ANGLE:
Use inner hexagon spanner to loosen the adjusting bolt appropriately and rotate the fixture to the angle desired. Based on actual
operations,the angle canbebetween0 and 150degrees.
灯体
螺栓
支架
Body
Bolt
Support

6/12
●TRANSPORTATION
Beforetransportation,tightenscrewsafter thefixtureand the supportare overlapped.
●POWERCONNECTION
Connectthepower cordasfollows:
L(live)=brown
E(earth) =yellow/green
N(neutral)=blue
Before power connection, please ensure the power supplied must match what the nameplate says. It is recommended that each
projectorbeconnected withpowerseparatelyso thatthey maybeindividuallyswitchedonandoff.
●Theearth wire(yellow/green) must beconnectedto theground.Andelectricalconnectionmustbe in
accordancewiththe standardsconcerned.
●If any questionsaboutthe electrical installation, donotcontinue butconsult aqualifiedelectrician.
5. DMXPROTOCOL
GBA
Mode
HSIC
Mode
Function
DMX Value
Description
1
1
Effect
0
Stoprotation

7/12
1-128
Forwardrotationfromslowtofast
129-255
Reverse rotationfromslowtofast
2
Green(custom)
0-255
Linearadjusting（0-100%）
3
Blue(custom)
0-255
Linearadjusting（0-100%）
4
Amber(custom)
0-255
Linearadjusting（0-100%）
2
Hue
0-255
3
Saturation
0-255
4
Brightness
0-255
Linearadjusting（0-100%）
5
5
ColourTemperature
0
No
1-255
CT fromwarmto cold（2000K-5700K）
6
6
Dimmer
0-255
Lineardimmer （0-100%）
7
7
Strobe
0-5
No
6-255
Strobefromslowtofast
Note:CTchannelisoftoppriority. Ifitison, green,blue,amber,hueandsaturationchannelsare invalid.
6. TECHNICALDATA
ELECTRIC PARAMETERS
Inputvoltage100V~240VAC，50/60Hz
Ratedpower118W@230V
Maximum current 0.55A
PowerfactorPF>0.9
LIGHTSOURCESPECIFICATIONS
Lightsource 36pcsof3WLEDlamps(12G+12B+12A), LEDlamp colorsare custom
ManufacturersRated LampLife 50000hours
DIMMER
Linear Dimmer from0-100%
STROBE
ElectronicStrobe0-25FP.S.
FIELDANGLE(1/10peak) θ1/10
Angleoptions
25 x 80degrees (W x L)
30 x 65degrees (W x L)
35 x 80 degrees (W x L)
45 x 75 degrees (WxL)
45 degrees
CONTROL
Internationalstandard DMX512signal controlprotocolDMX512+RDM5-pininterface
2operationmodes(GBAmodeand HSICmode)
OTHERFUNCTIONS
Onlinefirmware upgrade

8/12
Overtemperatureprotection
HOUSING
Hightensile castAluminumalloy+extrudingaluminum,IP66
NETWEIGHT
6.2Kg
Grossweight7.2Kg
OPERATIONTEMPERATURE:
Maximum ambient temperature 40 ℃
SIZES:
999*90*145（withthesupport）
Theinstallationdiagramofthesupport

9/12
7. CIRCUITDIAGRAMANDFIXTURECONNECTIONS
●CIRCUITDIAGRAM

10/12
●DMXCONTROLSIGNALCONNECTIONANDSIGNALAMPLIFIERCONNECTION
Controlsignalconnection(Pleasetake noteofthewiringdirection)
Theconnectionof the signalamplifier(please note the wiring direction)
接控制器
DMX IN
DMX OUT
DMX OUT
DMX IN
第1台
第N-1台
第N台
第2台
DMX IN
DMX OUT
DMX OUT
DMX IN
第N+1台
第2N-1台
第2N台
第N+2台
DMX 信号放大器
接控制器
DMX IN
DMX OUT
DMX OUT
DMX IN
第1台
第N-1台
第N台
第2台
DMXCONTROLLER
The1st fixture
the2nd fixture
theN-1 fixture
theNfixture
DMXCONTROLLER
theN+1fixture
DMXsignalamplifier
theNfixture
theN-1fixture
the2nd fixture
The1st fixture
the2Nfixture
theN+2 fixture
the2N-1fixture

11/12
Remarks:
1. Based on the actual operation, select proper quantity of the fixtures; Signal amplifiers like the fixture and other stage
products are loads, therefore the total loads are not more than 32pcs in number counting from DMX out interface of
theDMX console.
2. Please calculate the proper number of the fixtures in a DMX chain based on its power, line voltage ,line load and the
specificationandlengthofthecable.
8. COMPONENTORDERCODES
NO.
NAME
CODENO.
QTY
REMARKS
1
TRANSPARENTBOARDOFPR-6811
6080000017
1
2
SEALOFPR68-11
6290000028
2
3
SWITCHINGPOWERSUPPLYOFPR-6811
6120110042
1
4
LAMPBOARD 1OFPR-6811
6230000135
1
5
LAMPBOARD 2OFPR-6811
6230000136
1
6
STEPPING MOTOR
030040073B
1

12/12
PR LIGHTING LTD.
1582 XingyeAvenue,NancunPanyu
Guangzhou,511442China
TEL:[phone]
PR lighting will try its best to offer accurate and overall information about a product’s technical data. Any changes won’t be notified ifnecessary. Patented Products.
CounterfeitingWillbeProsecuted! P/N: 6320000114
Version: 20190403
