Sharp HT-CN300H User manual

– 1 –
HT-CN300H
HOME CINEMA COMMAND
TINSE0015BGZZ
02F Y HK 1
This Quick Guide will help you to correctly install
and operate your system.
1
Accessories
Remote control × 1
AM loop aerial × 1
FM aerial × 1
Remote control sensor × 1Double-sided tape for
remote control sensor × 1
SCART adaptor × 2
(IN/OUT)
AC adaptor for
remote control × 1Labels for
remote control × 1
Video cable × 1
Speaker cushion × 20 Speaker connection lead × 5
White
Front (left): 5 m (15') Green Centre: 5 m (15') Red Front (right): 5 m (15')
Blue
Surround (left): 15 m (45') Grey Surround (right): 15 m (45')
IN
OUT
If you require any advice or assistance regarding
your Sharp product, please visit our web-site
www.sharp.co.uk/support.
Customers without Internet access may telephone
08705 274277 during office hours (or [phone]
if telephoning from Ireland).
0101

–2 –
2
Speaker connections
Connect the cables to the sockets of matching colours.
Front speaker (right) Centre speaker Front speaker (left)
Black Red
Red
Black Red
Green
Black Red
White
Black Red
Blue
Black Red
Grey
Red
Green
White
Blue
Grey
Main unit
(with subwoofer)
Black Red
Surround speaker (right) Surround speaker (left)

–3 –
4
Aerial and Remote control sensor connection
Supplied FM aerial:
Connect the FM aerial wire to the FM 75 OHMS
socket and position the FM aerial wire in the direc-
tion where the strongest signal can be received.
Supplied AM loop aerial:
Connect the AM loop aerial to the AM LOOP socket.
Position the AM loop aerial for optimum reception.
Place the AM loop aerial on a shelf, etc., or attach it
to a stand or a wall with screws (not supplied).
Connect the plug of the remote control sensor
and push the plug cover until it clicks.
Remote control sensor
3
Speaker layout
The best surround effect will be
achieved by placing each speaker at
the same distance from the listening
position.
Notes:
●Place the TV halfway between the front speakers.
●It is recommended that the centre speaker be placed near the television.
●Keep the free space of at least 10 cm (4") along the side of the unit (subwoofer).
●Place the surround speakers at a position just above the height of your ears.
Front
speaker (left)
Centre speaker Front speaker
(right)
Main unit
(subwoofer)
Surround
speaker (left)
Surround
speaker (right)
Same distance
Centre speaker
Same distance
Front speaker
(right)
Front speaker
(left)
10 cm (4") 10 cm (4")
Main unit (subwoofer)

–4 –
5
Connecting other equipment
Video cable (supplied) To video input socket TV
S-video cable To S-video input socket
Connecting the TV
Connecting the DVD player
To connect to the video socket with the video cable:
Coaxial digital audio cable
Optical digital audio cable
Video cable To video output socket
DVD player
To connect to the S-video socket with the S-video cable:
Coaxial digital audio cable
Optical digital audio cable
S-video cable To S-video output socket
DVD player
Connecting the VCR (VIDEO 1)
Video cable:
Audio cable:
Yellow
White (Left)
Red (Right)
Yellow
White (Left)
Red (Right)
LAUDIO VIDEOR
IN
TV
Video cable (supplied)
To video input socket
SCART adaptor (IN)
To SCART
socket
Video cable
Audio cable
Video cable
Audio cable
VCR
To audio
output sockets
To video
output socket
To audio
input sockets
To video
input socket
Connecting the TV with SCART socket:
Use a supplied SCART adaptor (IN).
One video cable and two SCART adaptors are supplied.

–5 –
LAUDIO VIDEOR
OUT
LAUDIO VIDEOR
IN
6
Plugging in the main unit and the remote control
To 3.6 V DC
Input socket
Wall socket
(AC 230 V, 50 Hz)
7
Turning on your system
The first time the unit is plugged in, the
unit will enter the demonstration mode.
You will see words scroll.
1Press the X-BASS button to cancel
the demonstration mode.
2Press the ON/STAND-BY button on
the main unit or the ON/]]
]]
](STAND-BY)
button on the remote control to turn
the power on.
Power indicator
Wall socket
(AC 230 V, 50 Hz)
Connection example using a SCART adaptor:
To SCART socket
SCART
adaptor
(OUT)
To audio output
sockets To video
output
socket
Audio cable
Video cable
To SCART socket
SCART
adaptor
(IN)
To audio input
sockets To video
input
socket
Audio cable
Video cable

–6 –
Operation buttons on the remote control
This remote control allows you to operate the main unit and other Sharp equipment.
By memorising remote control operations (learn function), you can operate various equipment.
Operation buttons for other equipment
Operation buttons for the main unit
Memory 1/2 buttons for other equipment
MEMORY 1
MEMORY 2
Memory 1 buttons:
The remote control is set at the factory to operate the Sharp’s DVD, TV and VCR.
Memory 2 buttons:
No functions are stored at the factory setting.
Memorise the remote control signals (learn function) of your equipment before use.
Listening to the radio
1Press the TUNER/BAND button repeatedly to select the
desired frequency band (FM ST, FM or AM).
2Press the or button to tune in to the desired station.
When the or button is pressed for more than 0.5 sec-
onds, scanning will start automatically and the tuner will stop
at the first receivable broadcast station.
To receive an FM stereo transmission:
Press the TUNER/BAND button to display the "ST" indicator.
" " will appear when an FM broadcast is in stereo.
ST

–7 –
Memorising operations in the Memory 2 buttons
for other equipment
You can assign only one function to each button. If you assign two functions to the button, the newer
one will be memorised (learn function).
1Set the MEMORY 1/2 selector switch to MEMORY 2.
2Move the LEARN/TRANSMIT selector switch to LEARN.
The red learn indicator will light up. Though the red and green
learn indicators light up alternately after approx. 15 seconds,
you can go on to the next step.
3Press down the desired button on the remote control for 2
seconds or more.
The green learn indicator will flash (the red indicator remains lit).
4Within 10 seconds, press down for more than 2 seconds
the desired button on the remote control supplied with
other equipment to send the signal to the marking.
When the signal is sent to the remote control of the unit, the
green indicator will go off. When memorisation is completed,
it will light up.
If the signal is not memorised correctly, the red learn in-
dicator will flash.
Perform the operations from step 3 again.
5Repeat steps 3 and 4 to memorise other buttons.
6After memorisation is completed, move the LEARN/TRANSMIT selector switch to TRANSMIT.
You can use the remote control.
Lights up Alternately light up
Lit Flashes
10˚
Angle and distance
5 cm - 10 cm (2" - 4")
mark
Goes offLit Lit Lights up
Flashes

–8 –
If trouble occurs
When this product is subjected to strong external interference (mechanical shock, excessive static electricity, abnormal
supply voltage due to lightning, etc.) or if it is operated incorrectly, it may malfunction.
If such a problem occurs, do the following:
Clearing all the memory (reset): Main unit
1 Unplug the unit.
2 Whilst holding down the ON/STAND-BY button, plug in the AC power lead.
Release the ON/STAND-BY button when the “CLEAR AL”is displayed.
3 Press the ON/STAND-BY button again to turn the power on.
Caution:
This operation will erase all data stored in memory and restore various settings to the
initial status (default).
Clearing all the memory (initialisation): Remote control
1 Move the LEARN/TRANSMIT selector switch to LEARN.
The red learn indicator will light up. Though the red and green learn indicators light up alternately after approx. 15
seconds, you can go on to the next step.
2 Press the ON/](STAND-BY) and CLEAR buttons simultaneously for more than 3 seconds.
Initialisation is completed when the red and green learn indicators light up alternately and then the red learn indicator
lights up.
3 Move the LEARN/TRANSMIT selector switch to TRANSMIT.
Caution:
This operation will reset all data stored in memory to the initial status (default).
Memorising operations in the Memory 1 buttons for other equipment:
Set the MEMORY 1/2 selector switch to MEMORY 1 and perform steps 2 - 6 in "Memorising operations in the
Memory 2 buttons for other equipment".
Memorising operations in the operation buttons for other equipment:
1Move the LEARN/TRANSMIT selector switch to LEARN.
2Press down the desired button on the remote control for
2 seconds or more.
3Perform steps 4 - 6 in "Memorising operations in the
Memory 2 buttons for other equipment".
6Using the supplied labels:
Main features are already printed on the labels.
Write in other operations as you prefer.
Registrable buttons
