Sharp EQ Series User manual

Operating Instructions
Android TV Operation Manual
EQ Series
Image for illustration purposes only. Actual product may vary.
SHA/MAN/0535

2
IMPORTANT GUARANTEE INFORMATION
Thank you for purchasing this television. We hope you have many years of trouble free
enjoyment from your purchase.
Your product is covered under the manufacturers’ guarantee for 12 months from the date
of purchase.
If you experience any difficulties with your TV, please refer to the ‘Frequently Asked Questions’ section
at the rear of these Operating Instructions.
If you are still unable to remedy the issue, try resetting the TV to factory settings - details can be found in the
‘Settings’ menu section of these Operating Instructions - alternatively, please contact the helpline.
In the event that a fault is diagnosed, the helpline will arrange to collect the TV from your home
or work address, return it to our service centre, repair the item and then return it to you.
If we believe we cannot offer a permanent repair, we will replace the item.
Technical Support Information
Telephone
UK 0330 024 0803 ROI 01443 3323
Web support: www.umc-uk.co.uk
Email: [email protected]
Calls to 0330 numbers are charged at standard call rates and are included
as part of any bundled minutes with your phone provider.
The telephone opening hours are Monday to Friday 8.30am to 6pm, Saturday 9am – 5pm.
Please note these hours are subject to change periodically.
UK: Calls are charged at your normal telephone call rate.
ROI: Calls are charged at a local rate.
Please retain all packaging materials, in addition to your proof of purchase/receipt,
as you will need these in the event of warranty/service support.
This guarantee is in addition to and does not affect your statutory rights.
If you need to call the helpline, you will need the following information.
Model No: (You can find this on the rear of the TV)
Serial Number: (You can find this on the rear of the TV)
Date of purchase: (You can find this on your sales receipt)
EXAMPLE OF LABEL ON REAR OF TV
This TV set is for domestic use only
Manufacturers Guarantee
Model No
Serial No

3
3
Important Safety Instructions
Please read these instructions. All of the safety and
operating instructions should be read before the
appliance is operated.
Warnings
• Television sets with 40” screens or larger must be lifted and
carried by at least 2 people.
• This television does not contain any parts that are
serviceable by the user. In the event of a fault, contact the
manufacturer or authorised service department.
• Exposing the internal parts of the TV may endanger your
life. The manufacturers guarantee does not extend to faults
caused by repairs carried out by unauthorised third parties.
• Do not use the TV set immediately after unpacking.
Wait until the TV warms up to room temperature before using
it.
• To reduce the risk of fire, electric shock or damage to the
TV, do not expose it to dust, rain or moisture. Never expose the
TV to dripping or splashing and do not place objects filled with
liquids on or near the TV.
• Do not connect any external devices (DVD player, games
console etc.) when the TV is switched on. Disconnect both the
TV and device from the mains before connecting. Only switch
appliances on when the connection process is complete.
• Do not place the television in a confined space and do not
obstruct the ventilation openings at the rear of the television.
• When installing on a wall, ensure the TV is at
least 5cm from the wall for ventilation.
• Always ensure that the TV’s ventilation openings
are not covered with items such as newspapers, table-cloths,
curtains, etc.
• Dispose of this television and any components including
batteries in an environmentally friendly manner. If in doubt,
please contact your local authority for details of recycling.
• Ensure this TV is used in moderate climates only.
• In cases of electrostatic discharge (ESD) the TV may operate
incorrectly. If this happens, turn the set offat the mains and
then turn back on again after 30 seconds. The set should now
work normally.
• TV operating Conditions:
- Temperature from +10°C to + 35°C
- Humidity no more than 80% (at a temperature of 25°C)
WARNING: Never place a television set on an unstable
surface. The TV set may fall causing serious personal injury or
death. Many injuries, particularly to children, can be avoided
by taking simple precautions such as:
• Use cabinets or stands recommended by the manufacturer
of the television set.
• Only use furniture that can safely support the television set.
• Ensure the television set is not overhanging the edge of the
supporting furniture.
• Do not place the television set on tall furniture
(for example, cupboards or bookcases) without anchoring both
the furniture and the television
set to a suitable support.
• Do not place the television set on cloth or other materials
that may be located between the television set and supporting
furniture.
• For maximum safety while using your set, it is
recommended to fit anti-tip straps. These are designed to
be attached between the wall/secure surface and the VESA
mounts on the television. These are available from major
retailers and websites and are an easy and inexpensive way of
ensuring that your set stays safely upright.
• Please educate children about the dangers of climbing on
furniture to reach the television set or its controls.
• If your existing television set is being retained and
relocated, the same considerations as above should be applied.
Safety
• For your safety, this appliance is fitted with a fused 3 pin
mains plug. Should the fuse need to be replaced, ensure that
any replacement is of the same amperage and approved with
the BSI mark.
• Never try and replace the mains plug unless you have
adequate qualifications and are legally authorised to do so. In
the event that a replacement mains cable is required, contact
the manufacturer for a suitable replacement.
• Never use the television if it is damaged in any way.
• Always place the television on a flat level surface avoiding
anywhere which may be subject to
strong vibration.
• The ideal distance to watch the television is from
approximately 2.5-3 times the length of the diagonal
measurements of the TV screen away.
• Ensure the television is not placed on top of the power
cable as the weight of the television may damage the cable and
cause a safety hazard.
• Never place mobile phones, speakers or any other device
which may cause magnetic or radio interference, near the
television. If interference is apparent, move the device causing
the interference away from the television.
• To disconnect the set from the mains, remove the mains
plug from the socket.
• Ensure that the mains plug is always easily accessible.
• When handling the set do not grip the LCD screen/glass.
• Do not pull the set when mounted on a bracket. If using a
moveable bracket, adjust via the bracket and not the TV set.
• Do not place this set above a heat source.
WARNING: Excessive volume when using earphones
and headphones can cause damage to hearing.
To prevent spread of fire, keep
candles or other open flames away
from this product at all times
~ - Alternating current
- This equipment is a Class II or double
insulated electrical appliance. It has been designed
in such a way that it does not require a safety
connection to electrical earth.

4
Important Safety Instructions
Maintenance
• To clean your TV, wipe with a soft, dry cloth. If the surfaces
are extremely dirty, use a soft cloth dampened with a weak
detergent solution.
• Never use alcohol, paint thinner or benzene to clean this
unit.
• Before using a chemically treated cloth, read the
instructions that came with the cloth carefully.
CAUTION: If water or other liquid enters the
television through the display panel surface,
a malfunction may occur.
Packaging
• The safest way to transport your item is in the original box/
packaging - please save your packaging for this.
• You will need the original box/packaging in the event of
warranty/service repair or support. We are unable to carry
out warranty/service if you are unable to package the item
correctly.
Important information regarding use of video
games, computers, captions or other fixed image
displays
The extended use of fixed image program material can cause a
permanent “shadow image” on the LCD/LED panel, also known
as “screen burn”.
This “shadow image” can appear in the background during
normal viewing. This type of irreversible LCD/LED panel
deterioration can be limited by observing the following steps:
1. Reduce the brightness/contrast setting to a minimum
suitable viewing level.
2. Do not display the fixed image for extended periods
of time.
3. Turn the power offwhen not in use.
Examples of images that are more likely to cause “screen burn”
are as follows (this is not an exhaustive list):
• TV channel logos: e.g. shopping channel logos and pricing
displays - especially if they are bright and stationary. Moving
or low-contrast graphics are less likely to cause ageing of the
screen.
• Time displays.
• Teletext: Do not view a static page for a long period of time
• TV/DVD menus: e.g. listings of DVD disc content.
• Pause mode: Do not leave the TV in pause mode
for long periods of time, e.g. when watching DVDs
or videos.
Important: Once ‘shadow image/screen burn’
occurs, it will never disappear and is not
repairable under warranty.
How do I dispose of this product?
UK: Waste electrical products should not be disposed of with
household waste. Please dispose of the product at a
designated collection point for recycling
of WEEE. For your nearest facilities, please see www.recycle-
more.co.uk or ask store
for details.
ROI: Waste electrical products should not be
disposed of with household waste. Separate
disposal facilities exist. Check with your local
authority or retailer for recycling advice.
Batteries
• CAUTION: Risk of explosion if the battery
is replaced with an incorrect type.
• Do not expose batteries to high
temperatures, excessive heat, prolonged
sunshine or fire as this may cause leakage,
explosion or ignition.
• Observe the correct polarity when inserting
batteries.
• Do not use different types of batteries together or
mix old and new batteries.
• Dispose of batteries in an environmentally
friendly way.
• Certain regions may regulate the disposal of batteries.
Please consult your local authority.
CE Statement:
Hereby, Sharp Consumer Electronics Poland sp.
z o.o. declares that this LED TV is in compliance
with the essential requirements and other relevant
provisions of RED Directive 2014/53/EU.
The full text of the EU declaration of conformity is
available by following the link:
www.sharpconsumer.eu
and then entering download section of your model
and choosing’CE Statements’’.
This equipment may be operated in all EU
countries.
The 5 GHzWLAN(Wi-Fi) function of this equipment
may only be operated indoors.
Wi-Fi max transmitter power:
100 mW at 2.412 GHz - 2.472 GHz;
100 mW at 5.150 GHz - 5.350 GHz;
100 mW at 5.470 GHz- 5.725 GHz
Bluetooth max transmitter power: 10 mW at 2.402
GHz - 2.480 GHz
Cd

Microsoft PlayReady™
5
5
For DTS patents, see http://patents.dts.com. Manu-
factured under license from DTS, Inc. (for companies
headquartered in the U.S./Japan/Taiwan) or under
license from DTS Licensing Limited (for all other
companies). DTS, DTS:X, Virtual:X, and the DTS:X logo
are registered trademarks or trademarks of DTS, Inc.
in the United States and other countries. © 2021 DTS,
Inc. ALL RIGHTS RESERVED.
The DVB logo is the registered trademark of the
Digital Video Broadcasting (DVB) project.
The FREEVIEW text and logos are trademarks of DTV
Services LTD. © DTV Services Ltd
SAORVIEW is a registered trademark owned by RTÉ.
The “CI plus” Logo is a trademark of CI Plus LLP.
YouTube and the YouTube logo are trademarks of
Google Inc.
The Wi-Fi CERTIFIED Logo and Miracast® are
registered trademarks of Wi-Fi Alliance. Wi-Fi
CERTIFIED Miracast™ is a trademark of Wi-Fi Alliance.
The Bluetooth® word mark and logos are registered
trademarks owned by bluetooth SIG,. Inc.
This product contains technology subject to certain
intellectual property rights of Microsoft. Use or
distribution of this technology outside of this product
is prohibited without the appropriate license(s) from
Microsoft.
Content owners use Microsoft PlayReady™ content
access technology to protect their intellectual
property, including copyrighted content. This device
uses PlayReady technology to access PlayReady-
protected content and/or WMDRM-protected
content. If the device fails to properly enforce
restrictions on content usage, content owners may
require Microsoft to revoke the device’s ability to
consume PlayReady-protected content. Revocation
should not affect unprotected content or content
protected by other content access technologies.
Content owners may require you to upgrade
PlayReady to access their content. If you decline an
upgrade, you will not be able to access content that
requires the upgrade.
Dolby, Dolby Vision, Dolby Atmos, Dolby Audio,
and the double-D symbol are trademarks of Dolby
Laboratories Licensing Corporation. Manufactured
under license from Dolby Laboratories. Confidential
unpublished works. Copyright © 1992–2021 Dolby
Laboratories. All rights reserved.
The terms HDMI, HDMI High-Definition Multimedia
Interface, and the HDMI Logo are trademarks or
registered trademarks of HDMI Licensing Administra-
tor, Inc.
Google, Google Play, YouTube, Android TV and other
marks are trademarks of Google LLC.
TRADEMARKS

6
CONTENTS
Guarentee Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-5
Trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Securing to a wall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
GETTING STARTED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-24
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Set Functionality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Connecting External Device - Wired & non wired . . . . . .9-15
Connecting Headphones - Wired & non wired. . . . . . . . .15
Playing Content stored on a USB Device . . . . . . . . . . . . . .16
Inputting Text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Remote Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
First Time Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19-23
ANDROID FUNCTIONALITY . . . . . . . . . . . . . . . . . . . . . . 24-34
Viewing Internet Media . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Safe Apps and Video Streaming . . . . . . . . . . . . . . . . . . . . .24
The Google Assistant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25-26
Home Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27-29
Installing Apps. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Memory Device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Play Next . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Channels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Discover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
USING THE TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35-60
Television Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Source. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Picture Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36-40
Sound Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40-42
Power Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
CI Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Advanced Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44-60
Network & Internet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Connecting to a Network. . . . . . . . . . . . . . . . . . . . . . . .45
Channel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Tuning in your TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Parental Controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
Accounts & Sign-in. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
Sign in via Android Phone. . . . . . . . . . . . . . . . . . . . . . .48
Sign in Manually . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
Manage your account. . . . . . . . . . . . . . . . . . . . . . . . . . .48
Apps. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
Device Preferences . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49-50
About TV. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
Date & Time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
Keyboard. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
Power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
Home Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
Store Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
Google Assistant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
Chromecast Built in. . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
Screensaver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
Energy Saver. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
Usage & Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . .58
Accessibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
Remotes & Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . .60
DIGITAL TV & FREEVIEW PLAY. . . . . . . . . . . . . . . . . . . 61-68
Tuning in Digital Channels . . . . . . . . . . . . . . . . . . . . . . . . . .61
Terrestrial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61
Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61
Satellite . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61
Using Freeview Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
Channel Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
Back EPG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
Quick Buttons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63-64
Freeview Play Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65
Freeview Play App. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Channel List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67
Information Bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68
UPDATING SOFTWARE . . . . . . . . . . . . . . . . . . . . . . . . . . 68
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69-74
Video Formats. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69-70
Audio Formats. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .71-73
Image Formats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74
TROUBLESHOOTING GUIDE . . . . . . . . . . . . . . . . . . . . . . 75-79

Viewing Angle Viewing Angle
A B
7
7
SECURING THE TV TO A WALL
For maximum safety in the home, when using a TV with its stand, anti-tip straps should be fitted. These are
available from major retailers & websites and are an easy, inexpensive and effective way of ensuring your TV
stays safely upright. Straps are designed to be attached to the rear of the TV and then tethered to the wall or
furniture the TV is stood on, these are fitted as follows.
Using one or both of the top wall-mounting
holes and screws fasten one end of the fastening
cord/s to the TV. (the screws are already supplied in
the wall mounting holes)
Secure the other end of the fastening cord/s to
your wall. (you will need screws/fixings suitable for
your wall type - available separately from most DIY
stores).
Note: Please ensure that children do not climb on the TV set.
Note: When handling the set do not grip the LCD Panel.
Note: Do not pull the set when mounted on a bracket. If using a moveable bracket, adjust via the
bracket and not the set.
The Royal Society for the Prevention of Accidents is urging people to take care with flat-screen televisions.
RoSPA stated in 2010 that “Toddlers are particularly at risk of pulling flat-screen televisions on to themselves.
They are unsteady on their feet and are attracted by colourful television images.”
The risk is increased as televisions become lighter.
IMPORTANT - Before drilling any holes in the wall ensure you are not drilling where there could be any electrical
wires, water or gas pipes.
1. Remove the four screws located at the back of the TV set.
2. The wall mount can now be easily attached to the mounting holes,
located on the back of the TV, using the same four screws removed.
Important: If wall mounting this TV, only use the screws already provided in the wall mounting holes.
Using other screws which are longer could cause irreparable damage to the internal parts. When using a
wall bracket, please ensure the screws in the back of the TV set are not over tightened.
Note: This diagram to the left is an example of screw positions. Due to
model variations, please ensure you check your TV for the exact location of
the wall mounting screw positions.
Securing the TV to a wall with anti-tip straps
Wall mounting & Viewing Angle
Securing to a wall
A
B

8
Getting Started
Your new Android television set is able to run applications, stream video, connect to various sources and allows
you to watch Freeview and benefit from various catch up services. It features all of the usual applications you are
used to such as Netflix, Amazon Prime and YouTube in addition to many more apps available in the Google Play
Store.
When the set is first powered on, you will be presented with the First Time Installation screens. Follow the on
screen instructions for guidance. You can also use the Quick Start Guide supplied for additional guidance. Once
completed the set is ready to be used. It is important that the correct language and country is selected during
this stage of the set-up process as this will determine the basic functionality of the set.
To make full use of your Android set, you will require an aerial and internet connection.
Use these Operating Instructions for guidance on how to use your Sharp Android television.
Unless otherwise stated, the remote control is used to operate the set, i.e., it will be noted when to use the
buttons or control stick on the set itself.
Your set can be used in several ways. If you wish to use the Android functionality, this can be done via the Home
Page. Should you want to watch television, or access the various source inputs, then use the television mode.
SET FUNCTIONALITY
Note: The functionality and appearance of the screens and advice shown in the following pages may vary
depending upon the version of software installed in your set. It is recommended that your set is kept up
to date with the latest version of software applicable to your set to ensure smooth running and continued
enjoyment of your Android based product.
When navigating though the menus, selection will be accompanied by a soft tone coming though the sets
speakers, or headphones/sound device if connected.
INTRODUCTION

HDMIHDMI
B
A
A
B
9
9
Getting Started
Before turning your set on, it is recommended that your external devices are connected before continuing with
the first-time installation process. Depending on the source connectivity on your television, follow the guidance
below when connecting external devices.
For optimum picture quality, we recommend connecting your device to the television using an HDMI cable.
*Be sure to use an authorised HIGH-SPEED HDMI cable bearing the HDMI logo.
If an HDMI CEC-compatible device (e.g., Blu-ray player, AV receiver) is connected with an HDMI cable, you can
operate the device with the televisions remote control. We recommend using the HDMI (ARC) connection when
used with an AV receiver – please refer to the ARC section of this Operation Manual.
1. Turn on the connected device.
2. To enable HDMI control, press the [HOME] button, then select Settings >Device Preferences >
Inputs.
3. Activate HDMI control on the connected device.
HDMI control Allow the TV to control HDMI devices.
Device auto power offIf disabled, the connected device does not turn offautomatically when
the television is turned off.
Television auto power
on
If disabled, the television does not turn on automatically when the
connected device is turned on.
CEC Device list Displays the HDMI CEC device list.
Available options
External Device
HDMI cable (not supplied)*
HDMI Connection
HDMI CEC-Compatible Devices
Adjusting HDMI CEC Settings
CONNECTING EXTERNAL DEVICES -WIRED

10
Features Available to Compatible CEC Devices
• Automatically turns the television on and switches the input to the connected Blu-ray/DVD player when
the Blu-ray/DVD player starts to play.
• Automatically turns the connected Blu-ray/DVD player offwhen you turn the television off.
• Controls menu operation [ARROW] buttons, playback and track selection of the connected Blu-ray/DVD
player through the TV’s remote control.
• Automatically turns the connected AV receiver on and switches the sound output from the TV speaker
to the audio system when you turn the TV on. This function is only available if you have previously used
the AV receiver to output the TV’s sound.
• Automatically switches the sound output to the AV receiver by turning the AV receiver on when the
TV is turned on.
• Automatically turns the connected AV receiver offwhen you turn the TV off.
• Adjust the volume and mute functions via the [VOL+/–] and [MUTE] buttons on your television remote
control.
• Automatically turns the TV on and switches the input to the connected video camera when the camera
is turned on.
• Automatically turns the connected video camera offwhen you turn the TV off.
• Controls menu operation [ARROW] buttons, playback, e.g. [PLAY] button of the connected video
camera through the TV’s remote control.
Note: Not all devices with HDMI input/output are HDMI CEC compatible. For information about CEC
compatibility, refer to the instruction manual of the device.
Refer to “HDMI connection (ARC supported)” section of this manual for information relating to connecting
an HDMI (ARC) enabled device.
Blu-ray/DVD player
AV Receiver
Video Camera
Getting Started

AV in
A
BC
C
A
B
11
11
Component video Connection
If your external device has component video jacks/sockets, connect them to the television using a mini
component video cable and an audio cable.
Mini AV Source
External Device
Composite video/audio adapter cable (not supplied)
Composite video/audio cable (not supplied)
R
L
Video CVBS
You can connect wired USB devices such a mouse and keyboard via the USB sockets on the rear of the set.
Getting Started
Note: We are unable to guarantee connection of a wired USB device. Use of USB hubs is not
recommended.
USB Devices (wired)

A
B
A
B
12
Connecting an External Audio Device
You can connect audio systems such as AV receivers or sound bars to the television. Select a connection method
below according to the specifications of the audio system you want to connect.
• Connecting with an HDMI cable. for Details, carefully read
HDMI Connection (ARC supported) .
• Connecting with a digital optical cable.
• Connecting with an audio cable.
HDMI Connection (ARC Supported)
Connecting the television and audio system with an HDMI cable. This is the recommended method of
connecting an external audio device.
Connect to the television’s HDMI input terminal bearing the text “ARC”.
HDMI (ARC) HDMI (ARC)
AV Receiver or Soundbar
HDMI cable (not supplied)*
Ensure that the connected audio device is HDMI ARC compatible.
The ARC output on your television may vary depending on the model.
HDMI CEC must be enabled on your set for this connection to work. To do this press the [HOME] button, then
select Settings >Device Preferences >Inputs and then enable the HDMI control option.
Control of volume can be achieved via the television remote control (CEC must be turned on).
When ARC is working, the sound from the television speakers will be muted.
You need to configure the Digital Output settings according to your audio system. Press the [HOME] button,
then select Settings >Device Preferences >Sound >Digital Output.
If the audio system is not compatible with Dolby Digital or DTS, set Settings >Device Preferences >Sound >
Digital Output to PCM.
Note: We recommend authorised Premium High-Speed HDMI Cable(s) bearing the HDMI logo.
Getting Started
Note: Refer to the instruction manual of the device to be connected.

A
B
A
A
B
A
B
B
13
13
Digital Audio (Optical)
Connecting your television and audio system with a digital optical cable.
Connect to the audio system digital optical input terminal.
Digital Audio Out
Optical
Digital Audio In
Optical
AV Receiver or Soundbar
Audio Optical cable (not supplied)
If there is no output on the digital optical output, ensure that the digital output is set to PCM.
To set, go to: Settings >Device Preferences >Sound >Digital Output to PCM.
The digital optical output is always present whatever source is selected.
RCA Analogue Audio Cable
Connect to the audio system’s audio input terminal.
Audio L/R
Earphone
AV Receiver or Soundbar
Audio cable (not supplied)*
Note: The output audio level is dependent upon the headphone level. The volume level on the connected audio
system must be turned up.
Getting Started
L
R

14
It is possible to connect external non-wired devices such as Bluetooth headphones, keyboard, mouse, etc.
CONNECTING EXTERNAL DEVICES -
NON WIRED
Chromecast built-in
Chromecast built-in allows you to wirelessly cast content from your favourite websites and apps to your
television, directly from your computer or mobile device.
1. Connect a mobile device such as a smartphone or table to the same home network that the television is
connected to
2. Launch a Chromecast supoorted app on the mobile device.
3. Select the (cast) icon in the app
The screen of the mobile device is displayed on the television.
Bluetooth Devices
The Bluetooth function can be used to pair the television with various devices. You can pair audio output devices
such as Bluetooth soundbars, speakers or headphones. Supported input devices are Bluetooth remote controls,
gamepads, computer mouse etc.
To pair the television with a Bluetooth device, follow the instructions below:
1. Turn the Bluetooth device on and put it in pairing mode.
2. To put your Bluetooth device in pairing mode, refer to the instruction manual of the device.
3. Press the [HOME] button, then select Settings >Remotes & Accessories >Add Accessory to put the
television in pairing mode
4. A list of available Bluetooth devices will be displayed.
5. Select the desired device from the list, then follow the on-screen instructions.
6. If you are prompted to enter a passcode, refer to the instruction manual of the device.
7. After pairing is completed, your device will be connected to the television.
Note: An Internet connection is required to use Chromecast built-in. Both your television and device
need to be connected to the same network for the casting function to operate.
There are many Chromecast apps available for mobile and other devices.
Getting Started

15
15
Connecting Headphones
You can connect wired or Bluetooth headphones to this set.
Earphone
When
wired headphones are connected to the 3.5mm jack socket on the rear of the set, the internal speakers
will cut out. The volume of the sound which comes from the headphones is controlled via the remote control
using the [VOL+] and [VOL-] buttons.
When a
Bluetooth device is paired with the set, the internal speakers will cut out. The volume of the sound that
which comes from the Bluetooth device is adjusted via the remote control using the [VOL+] and [VOL-] buttons.
If headphones are connected to the 3.5mm jack on the rear of the set, the Bluetooth device takes over the sound
output, i.e. if both wired and Bluetooth headphones are connected, there will only be sound from the Bluetooth
headphones.
Volume bar display
When the volume is changed on your television set, the volume bar will come up at the bottom of the screen. If
Bluetooth is being used, the bluetooth icon will be displayed.
When the audio is muted, the volume bar will display the last set volume and also the mute icon.
Note: When using headphones, a warning will appear advising not to use excessive volume for long
periods of time as this may damage your hearing.
Turning up the headphone volume too high may result in distortion.
To unpair your remote control, follow the instructions below:
1. Go to Settings >Remotes & Accessories.
2. Select the remote control to be unpaired and press [OK].
3. Now select “Unpair” and press [OK].
4. Select “OK” and press [OK] on the remote control.
5. Your remote control will now unpair from the set.
Getting Started

16
PLAYING CONTENT STORED ON A USB
DEVICE
USB
Connect a USB storage device to the USB port of the television to enjoy photo, music, and video files stored on
the device.
Connect the USB device to your television and turn it on.
1. Press the [HOME] button, select “Apps” from the Home Page, and select the DigitalMediaPlayer from the
app list.
2. If the supplied remote control has an [APPS] button, you can press the APPS button to display the app list.
3. Browse the list of folders and files and select the desired file.
4. Press [OK] and playback will start.
Note: Depending on the image dimension, file size, and number of files in a folder, some photo images
or folders take time to display.
Displaying the contents of the USB device may take some time depending on the content.
While accessing the USB device, do not disconnect power from the television or USB device as the data
may be corrupted.
Depending on the file, playback may not be possible, refer to
USB Specifications.
Some photos and movies may be magnified, resulting in low picture quality. Depending on the size and
aspect ratio, images may not be displayed in full screen.
It may take a long time to display a photo, depending on the file or settings.
If DigitalMediaPlayer cannot be found in the favourite’s apps, you can add it from the apps listing.
The USB ports on the television support FAT32 and NTFS file systems.
If your digital still camera does not work with your television, try the following:
• Set the USB connection settings on your camera to Mass Storage.
• Copy the files from the camera to a USB flash drive, then connect the drive to the television.
Getting Started

17
17
INPUTTING TEXT
On -Screen Keyboard
There is a preinstalled on-screen keyboard app in your set which will appear whenever text is expected to be
entered by the user, e.g. Wi-Fi password or website address in the web browser. To navigate the on-screen
keyboard, use the [ARROW] buttons on the remote control, enter the character selected by pressing [OK]. The
character you select will be highlighted like the “Q” in the image below.
If you press and hold the [OK] button for 2 seconds while on a selected symbol, this will display the associated
national character(s) with accents or diacritical marks.
Using the Remote Control
You can operate many of the televisions features by using the [UP], [DOWN], [LEFT], [RIGHT] and [OK] buttons
on the remote control.
The following remote control buttons are used to navigate the menus:
• [EXIT]: Exits from the menu and returns to the source or Home Page.
• [BACK]: Takes you one step back in the menu.
• [ARROW BUTTONS]: Navigate around the options on the screen.
• [OK]: Selects the option highlighted or selected.
Your set can also be voice controlled using the Google Assistant.
Note: When entering the Wi-Fi password this keyboard is extended to show all characters at once.
Getting Started

18
2
3
45
7
9
11
12
13 14
15 16
17 18
19 22
20 21
23 26
24 25
27
9
15 16
17 18
13 14
6
28
2
14
10
11
12
68
10
1
1. STANDBY - Switch on the TV when in standby or vice versa.
2. SOURCE - To display the input/source menu.
3. NUMBER BUTTONS - 0-9 to select a TV channel directly.
4. MUTE - Mute the sound or vice versa.
5. GUIDE - Opens the 7 day TV guide (Digital TV mode).
6. MENU - Displays LIVE TV menu.
7. APPS - Opens the menu with installed apps.
8. INFO - Press once for programme information.
Press again to view detailed information
9. - Allows you to navigate the on-screen menus
and adjust settings to your preference.
10. BACK - Step back in the menu.
11. HOME - Displays the TVs Home Menu.
12. EXIT - Exits all menus.
13. VOL (+/-) - Tilt to increase/decrease the sound level.
14. CH (+/-) - Tilt to switch to the next/previous channel in the
sequence.
15. NETFLIX - Access the YouTube App.
16. PRIME VIDEO - Access the Prime Video App.
17. YOUTUBE - Access the YouTube App.
18. FREEVIEW PLAY - Access the Freeview Play service. Only
availble in the UK.
19. AUDIO - Opens the audio track menu.
20. SUB - Turns on/off subtitles at the bottom of the screen.
21. TEXT - turns teletext on/off.
22. TV - Switches the TV to the last watched input.
23. - Play/Pause media.
24. - Play in fast rewind mode.
25. - Play in fast forward mode.
26. - Stop playback.
27. COLOUR BUTTONS - Execute corresponding function at
that time.
28. Google Assistant - Use your voice to access entertain-
ment, control smart devices, obtain answers on screen,
and more.
Getting Started
REMOTE CONTROL

19
19
FIRST TIME INSTALLATION
When the set starts up for the first time, it will do so in the first-time installation mode. This enables you to set
up various Android functions, log into your Google account (you will be able to set up a Google account if you
do not have one) and for the set to be tuned into digital television if required.
To navigate through the options when in the first-time installation mode, use the buttons on your remote
control as shown here:
Using the Remote Control
During the set-up process you will be prompted to sign into your Google account via the pre-installed Google
app. This set up process will depend upon the model of television being configured. Please ensure that you have
your account details to hand. If not, you will be prompted to set up an account. If you do not wish to set up an
account, this can be done later.
Note: The basic installation steps may vary slightly depending on your model and/or country of use.
Due to Android software updates, the look and feel of the television start up procedure and
subsequent menus may be subject to change.
TV Control Stick
The TV control stick is located on the back of the TV, on the left hand side when looking at the TV. The control
stick can be used to control a variety of TV functions. The shape of the TV’s control stick may vary by model.
While the TV is in standby mode:
1. Pressing the centre of the control stick once powers on the TV set.
While watching TV:
1. RIGHT/LEFT – volume up/volume down.
2. UP/DOWN – changes channel up/down.
3. Press the centre of the control stick once – displays the menu.
4. Press and hold the centre of the control stick – Standby/Power Off.
While in menu:
1. RIGHT/LEFT/UP/DOWN – navigation of cursor in on-screen menus.
2. Press the centre of the control stick once – OK/Confirm selected item.
3. Press and hold the centre of the control stick – back to previous menu.
TV Control Stick
Getting Started
Press to navigate up
Press to confirm a selection
Press to navigate right
Press to navigate left
Press to navigate down

20
Full First Time Installation
When the set is turned on for the first time it will enter the installation mode as shown here. It is recommended
that all steps are completed as shown in the process to ensure correct operation. Use the back button on your
remote control to return to the previous screen.
1. When the set first turns on, you will be
requested to select your preferred on-
screen display language. This will set the
language in which the menus and associated
information is displayed in. Should you wish
to do so, this can be changed later in the
Device Preferences menu.
2. Next you will be requested to set up your set
with an Android phone. If you do not have
an Android phone, proceed to the next step.
If chosen, the set will request you to log into
your Android phone and connect the set to
your network automatically.
3. If your set is not connected via an Ethernet
cable, it will request that a Wi-Fi network
is selected and logged into. Choose your
network and then follow the on-screen
display to enter your password. When
correctly entered, the set will log into your
network and connect to the internet if this is
available.
4. Now you can sign in using your Google
account. If you do not have a Google
account, this can be set up at this stage if
required. Should you not want to sign in or
create a Google account, then this stage can
be skipped.
5. If signing in, there are two options. You can
either sign in using a device by choosing “Use
your phone or computer”, this will bring up
further options to follow. If using the remote
control to sign in, you will be asked for your
Google account name and password; follow
the prompts to sign in.
Getting Started
