Sharp 32N-S500 User manual

As an ENERGY STAR
®
Partner, SHARP has determined that this product meets the ENERGY STAR
®
guidelines for energy efficiency.
ENERGY STAR
®
is a U.S. registered trademark.
model
32N-S500
PAGE
• Important Information ................................................................ 2
• Important Safeguards........................................................... 2 - 3
• Outstanding Features................................................................ 4
• Supplied Accessories ................................................................ 5
• Before Operating Your Television .............................................. 5
• Antenna Connections ................................................................ 6
• Quick Reference Control Operation ..................................... 7 - 9
• Menu Functions....................................................................... 10
• EZ SETUP during First Power On ............................................ 11
• Language ................................................................................. 11
• Sleep Timer ............................................................................. 12
• Closed Caption........................................................................ 12
• Video Adjust ............................................................................ 13
• Audio Adjust ..................................................................... 13 - 14
This operating manual includes basic operating instructions in
Spanish and French.
SPANISH is on page 8, 32.
FRENCH is on page 9.
PAGE
• Parent Control .................................................................. 15 - 19
• V-Chip ............................................................................ 15 - 19
• View Timer .............................................................................19
• Energy Save .............................................................................20
• Set Up .............................................................................. 20 - 23
• EZ Setup ....................................................................... 20 - 21
• Channel Setting ............................................................. 21 - 22
• Universal Plus Function.........................................................22
• Personal Preference ..............................................................23
• Blue Screen ...........................................................................23
• PIP (2 Tuner Picture In Picture)................................................24
• Using the Video and Audio Input Jacks ....................................25
• Using the Audio Output Jacks ..................................................26
• Operation of Remote Control ........................................... 27 - 30
• Before Calling for Service ........................................................31
• Calling for Service ....................................................................40
• Limited Warranty ......................................................................40
CONTENTS
7020 ME

2
WARNING - FCC Regulations state that any unauthorized changes or modifications to this equipment not expressly approved by the
manufacturer could void the user’s authority to operate this equipment.
Welcome to the SHARP Family. We are pleased that you are now the owner of a SHARP Color Television –built for outstanding quality, reliability
and performance.
Every SHARP Color Television set is properly tuned and adjusted for a proper color picture and sound, and has passed through the most stringent
quality control tests at the factory. We have prepared this OPERATION MANUAL so that you may adjust the picture and color to your personal
viewing preference.
We sincerely hope that you receive the utmost satisfaction and enjoyment from your new SHARP Color Television set for years to come.
Please read these instructions carefully, and keep them handy for your future reference.
The lightning flash with arrowhead within a triangle is intended to tell
the user that parts inside the product are a risk of electric shock to
persons.
The exclamation point within a triangle is intended to tell the user that
important operating and servicing instructions are in the papers with
the appliance.
Important Information
Model No.:
Serial No.:
There are two important reasons for prompt warranty registration of your new SHARP television set, using the REGISTRATION CARD packed
in with the set.
FIRST – WARRANTY
This is to assure that you will immediately receive the full consumer benefit of the parts, service and labor warranty applicable to your purchase.
SECOND – CONSUMER PRODUCT SAFETY ACT
To assure that you will promptly receive any safety notification on inspection, modification or recall that SHARP may be required to give under
the 1972 Consumer Product Safety Act. PLEASE READ CAREFULLY THE IMPORTANT “LIMITED WARRANTY”CLAUSE ON THE LAST
PAGE.
WHAT IS ENERGY STAR ®
TVs and VCRs use energy both when they are on and when they are off. Americans spend more than $1 billion a year on energy consumed
by TVs and VCRs when they are not in use. The new ENERGY STAR ®models will reduce that energy “leakage”by up to 75 percent. Ultimately,
this will mean more than $500 million a year in energy savings for consumers.
The energy savings will help reduce the burning of fossil fuels and the related carbon dioxide pollution that contributes to global warming. If
every American family replaced their TVs and VCRs with ENERGY STAR ®models, it would reduce carbon dioxide emissions by five million
tons every year —equivalent to eliminating the pollution from more than one million cars.
By using ENERGY STAR ®products, you will save money on your electric bills and use less energy. That makes good economic sense and it’s
good for our environment.
IMPORTANT:
To aid reporting in case of loss or theft, please record the TV’s model and serial numbers in the
space provided. The numbers are located at the rear of the TV.
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO
WET LOCATIONS.
WARNING:
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
“Note to CATV system installer: This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the National
Electrical Code that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the
grounding system of the building, as close to the point of cable entry as practical.”

3
CAUTION: Please read all of these instructions before you operate your television and save these intructions for later use.
Electrical energy can perform many useful functions. This unit has been engineered and manufactured to assure your personal safety. BUT
IMPROPER USE CAN RESULT IN POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARDS. In order not to defeat the safeguards incorporated
in this equipment, observe the following basic rules for its installation, use and servicing.
1. Unplug this television equipment from the wall outlet before cleaning.
2. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
3. Do not use attachments not recommended by the television equipment manufacturer as they may cause hazards.
4. Do not use this television equipment near water —for example, near a bathtub, washbowl, kitchen sink or laundry tub, in a wet basement,
or near a swimming pool, etc.
5. Do not place this equipment on an unstable cart, stand, or table. The television equipment may fall, causing serious injury to a child or an
adult, and serious damage to the equipment. Use only with a cart or stand recommended by the manufacturer or sold with the television
equipment.
6. Television equipment and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may
cause the equipment and cart combination to overturn.
7. Wall or shelf mounting should follow the manufacturer’s instructions, and should use a mounting kit approved by the manufacturer.
8. Slots and openings in the cabinet and the back or bottom are provided for ventilation. To insure reliable operation of the television equipment
and to protect it from overheating, these openings must not be blocked or covered. This television equipment should not be placed in a built-
in insulation such as a bookcase unless proper ventilation is provided.
9. The openings should never be covered with a cloth or other material, and the bottom openings should not be blocked by placing the television
equipment on a bed, sofa, rug, or other similar surface. This television equipment should never be placed near or over a radiator or heat
register.
10. This television equipment should be operated only from the type of power source indicated on the marking label. If you are not sure of the
type of power supplied to your home, consult your television dealer or local power company.
For television equipment designed to operate from battery power, refer to the operating instructions.
11. As a safety feature, television equipment is equipped with a 2-wire polarized plug (one plug blade bigger than the other). The 2-wire polarized
plug will fit only one way into the power outlet.
If the plug does not fit, ask your electrician to replace your obsolete outlet. Do not modify the plug and defeat this safety feature.
12. Do not allow anything to rest on the power cord. Do not locate this television equipment where the cord will be abused by persons walking
on it.
13. Follow all warnings and instructions marked on the television equipment.
15. For added protection for this television equipment during a lightning storm, or when it is left unattended and unused for long periods of time,
unplug it from the wall outlet and disconnect the antenna. This will prevent damage to the equipment due to lightning and power-line surges.
16. An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it
can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching
such power lines or circuits as contact with them might be fatal.
17. Do not overload wall outlets and extension cords as this can result in fire or electric shock.
EXAMPLE OF ANTENNA GROUNDING
ACCORDING TO NATIONAL ELECTRICAL CODE.
NEC - NATIONAL ELECTRICAL CODE
ANTENNA LEAD-IN WIRE
GROUND CLAMP
ANTENNA DISCHARGE UNIT
(NEC SECTION 810-20)
GROUND CLAMPS
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
ELECTRIC
SERVICE
EQUIPMENT
POWER SERVICE GROUNDING ELECTRODE SYSTEM
(NEC PART 250, PART H)
14. If an outside antenna is connected to the television equipment, be sure the antenna system is grounded so as to provide some protection
against voltage surges and built-up static charges. Section 810 of the National Electrical Code provides information with respect to proper
grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors,
location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.
Important Safeguards

4
Important Safeguards (Continued)
18. Never push objects of any kind into this television equipment through cabinet slots as they may touch dangerous voltage points or short out
parts that could result in a fire or electric shock. Never spill liquid of any kind on the television equipment.
19. Do not attempt to service this television equipment yourself as opening or removing covers may expose you to dangerous voltage or other
hazards. Refer all servicing to qualified service personnel.
20. Unplug this television equipment from the wall outlet and refer servicing to qualified service personnel under the following conditions:
A. When the power cord or plug is damaged or frayed.
B. If liquid has been spilled into the television equipment.
C. If the television equipment has been exposed to rain or water.
D. If the television equipment does not operate normally by following the operating instructions. Adjust only those controls that are covered
by the operating instructions as improper adjustment of other controls may result in damage and will often require extensive work by a
qualified technician to restore the television equipment to normal operation.
E. If the television equipment has been dropped or the cabinet has been damaged.
F. When the television equipment exhibits a distinct change in performance —this indicates a need for service.
21. Upon completion of any service or repairs to this television equipment, ask the service technician to perform routine safety checks to
determine that the television is in safe operating condition.
22. When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer that have
the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, or other hazards.
•V-CHIP FUNCTION
This function allows you to restrict TV programs and also allows you to control TV usage based on FCC data. This function is to prevent your children
from watching violence or sexual scenes that are harmful to youth.
•PICTURE IN PICTURE
The two built-in tuners enable you to watch two TV programs at the same time, one on the main picture and one on an inset while commercial
messages are on the screen..
•DARKER-TINTED PICTURE TUBE
The darker tint makes black look blacker for greater contrasts and richer colors. These features combine to provide you with a beautiful, easily viewed
picture.
•S-VIDEO INPUT TERMINALS
The S-Video input terminal allows connection to an S-VHS VCR or other video equipment with an S-Video output terminal for crisp, clear reproduction
of images.
•FRONT VIDEO/AUDIO INPUT JACKS
Additional Video/Audio input Jacks are located on the front of your set, so it is easier for you to connect camcorders, TV games and other video
equipment.
Outstanding Features
®
•UNIVERSAL REMOTE CONTROL
This infrared remote control operates your TV set, and can control a variety of VCRs and CATV converter boxes.
•UNIVERSAL PLUS FUNCTION
The unit will select the suitable input mode automatically when the VCR PLAY button on the UNIVERSAL REMOTE CONTROL is pressed.
•VARIABLE AUDIO OUTPUT (VAO)
The VAO offers TV remote control over separate audio equipment volume that can raise or lower the audio equipment volume.
•ENERGY SAVE
When this feature is turned on, it reduces the brightness of the TV to a level that consumes approximately 20 percent less energy than when the feature
is turned off.
•BUILT-IN MULTICHANNEL TV SOUND (MTS) CIRCUIT & (Sound Retrieval System)
This circuit allows reception of stereo or bilingual TV sound. The SRS feature adds a three dimensional quality to stereo so the audio is more like
a live performance (see page 13 for details).
•VIEWING TIMER
This function can be used to prevent your children from watching too much TV.
•TRILINGUAL MENU ON SCREEN DISPLAY
For your convenience you can easily select the MENU ON SCREEN DISPLAY in ENGLISH, SPANISH or FRENCH.
•CLOSED CAPTION DECODER
Allows you to view conversations, narration and sound effects from TV programs or pre-recorded video tape as subscript on your TV screen.
•SLEEP TIMER
For convenient viewing, the Sleep Timer automatically shuts off the set in preselected periods of up to 120 minutes. This Timer can be set at 30, 60,
90 or 120 minute intervals.

5
123
456
789
0
100
POWER
TV
VCR
MENU
CATV
PAUSE
PIP
TV
FLASHBACK
INPUT
TV •VCR •CATV
STOP REC
REW PLAY FF
VCR CH
SWAP FREEZE MOVE SELECT
CM SKIP DISPLAY MUTE
VOL
—
CH
CH
VOL
+
ENTER
ABCD
PERSONAL PREFERENCE
Infrared Remote Control
Part Number : RRMCG1494CESA Size AA
Dry Batteries (2pcs.)
Location
•For normal operation, your TV should be located in an area of the room where cool, adequate ventilation is provided. Do not place the back
of the television set in a place where free airflow will be restricted.
•Any magnetic force may disturb the color picture. Make sure that magnets, electric clocks, toys using magnets or any other magnetic
substance, such as iron are kept well away from this TV set.
Power
Your TV operates on 120 Volts, 60 Hertz (normal household current) and has a polarized plug. If you are unable to insert the plug fully into the
outlet, try reversing the plug. Should it fail to fit, contact an electrician. Do not defeat the safety feature of the polarized plug.
•If the set will not be used for a long period, such as during a vacation, unplug the set from the wall outlet to economize power. (If the TV set
is plugged in, slight current still flows, even with the POWER BUTTON in the OFF position.
•Lines and other noise may appear in TV broadcast images when an FM tuner or radio is located near the TV and both radio and TV
broadcasts are being received. Should such noise appear, turn off either the TV or the radio.
•If you are listening to the AM broadcasts, turn the TV off. AM broadcast signals may not be received due to the interference of the TV.
Before using the television, prepare the Remote Control.
To use the remote control, insert batteries first.
•With your thumbnail, pull up the slit as indicated by the arrow to
remove the back cover. Insert two batteries (size “AA”). Be sure
to match the battery e/dterminals with the e/dmarks inside
the compartment.
Before Operating Your Television
Supplied Accessories
Battery
Cover
Insert the batteries
Pull up
NOTE:

6
1. A 75 ohm system is generally a round cable with F-type connector that can easily be
attached to a terminal without tools. The F-type connector should be finger tightened
only.
2. A 300 ohm system is a flat “twin-lead” cable that can be attached to a 75 ohm terminal
through a 300-75 ohm ADAPTOR (not supplied).
Antennas
• The antenna requirements for good color television reception are more important than those for black & white television reception. For this
reason, a good quality outdoor antenna is strongly recommended.
The following is a brief explanation of the type of connections that are provided with the various antenna systems:
Antenna Connections
OUTDOOR ANTENNA CONNECTION
• Use one of the following two diagrams if you connect an outdoor antenna.
A: Using a VHF/UHF combination outdoor antenna.
B: Using separate VHF and/or UHF outdoor antenna.
• Connect an outdoor antenna cable lead-in to the COAXIAL CABLE CONNECTOR on the rear of the TV set.
A. Combination VHF/UHF Antennas B. Separate VHF/UHF Antenna
CABLE TV (CATV) CONNECTION
• A 75 ohm coaxial cable connector is built into the set for easy hookup. When connecting the 75 ohm coaxial cable to the set, screw the 75
ohm cable to the COAXIAL CABLE CONNECTOR.
• Some cable TV companies offer “premium pay channels”. Since the signals of these premium pay channels are scrambled, a cable TV
converter/descrambler is generally provided to the subscriber by the cable TV company. This converter/descrambler is necessary for
normal viewing of the scrambled channels. (Set your TV on channel 3 or 4. Typically one of these channels is used. If this is unknown,
consult your cable TV company.) For more specific instructions on installing cable TV, consult your cable TV company. One possible
method of utilizing the converter/descrambler provided by your cable TV company is explained below.
Please note: RF switch equipped with position A/B (not provided) is required.
“A” position on the RF switch (not supplied) : You can view all unscrambled channels using the TV’s channel keys.
“B” position on the RF switch (not supplied) : You can view the scrambled channels via the converter/descrambler using the converter’s
channel keys.
• Consult your SHARP Dealer or Service Center for the type of splitter, RF switch or combiner that might be required.
F-type connector
75-ohm coaxial cable (round)
300-ohm twin-lead cable (flat)
Cable TV converter/
descrambler
(not supplied)
Two-set
signal
splitter
(not
supplied)
Cable TV Line
RF switch (not supplied)
OUT IN
COMPONENT-IN
Y
P
B L
L
R
AUDIO
VIDEO
IN1 IN 3
R
P
R
(C B )
(C
R )
IN1 IN3
S-VIDEO
LINE
OUT
LINEIN
EithertheS-VIDEO or t he VIDEO terminal can be used,
buttheS-VIDEO overrides the VIDEO terminal.
VCRPus+,C3,AllSet, PlusCode and GUIDE Plus+ are trademarks
ofGemstarDevelopment Corporation. The VCR Plus+ and GUIDE
Plus+systemsare manufactured under license from Gemstar
DevelopmentCorporationand VCR Index Systems B.V.,respectively.
'1990GDC '1997 ISI 5,307,173and 5,335,079
ANT/
CABLE
75Ω
300-ohm
twin-lead
VHF/UHF ANTENNA
REAR OF TV
300/75-ohm
ADAPTOR
(not supplied)
or
ANT/
CABLE
75Ω
75-ohm
coaxial
cable
VHF/UHF
ANTENNA
COMPONENT-IN
Y
P
B L
L
R
AUDIO
VIDEO
IN1 IN 3
R
P
R
(C B )
(C
R )
IN1 IN3
S-VIDEO
LINE
OUT
LINEIN
EithertheS-VIDEO or t heVIDEO ter minal can be used,
buttheS-VIDEO overridesthe VIDEO terminal.
VCRPus+,C3, AllSet, PlusCode and GUIDE Plus+ are trademarks
ofGemstarDevelopmentCor poration.The VCR Plus+ and GUIDE
Plus+systemsare manufacturedunder license from Gemstar
DevelopmentCorporationandVCR Index Systems B.V., respectively.
©1990GDC ©1997 ISI 5,307,173and 5,335,079
ANT/
CABLE
75Ω
300-ohm
twin-lead
300-ohm
twin-lead
75-ohm coaxial
cable
IN OUT
VHF
ANTENNA
UHF
ANTENNA
COMBINER
(not supplied)
or
REAR OF TV
ANT/
CABLE
75Ω
OUT
A
IN
B
NOTE:

7
• The above shaded buttons on the Remote Control glow in the dark. To use the glow-in-the-dark display on the remote control, place it under
a fluorescent light or other lighting.
• The phosphorescent material contains no radioactive or toxic material, so it is safe to use.
• The degree of illumination will vary depending on the strength of lighting used.
• The degree of illumination will decrease with time and depending on the temperature.
• The time needed to charge the phosphorescent display will vary depending on the surrounding lighting.
• Sunlight and fluorescent lighting are the most effective when charging the display.
LLocation of Controls (ENGLISH)
Front Panel
CHANNEL UP/DOWN – MENU
(8) Selects next higher channel.
(9) Selects next lower channel.
• Press both at the same time to access the
MAIN MENU screen.
POWER
Press →On.
Press again →Off.
Basic Remote Control Functions
SENSOR AREA FOR REMOTE CONTROL
VOLUME UP/DOWN
(+) Increases sound.
(–) Decreases sound.
POWER
Press →On.
Press again →Off.
REMOTE KEYPAD
Accesses any channel from keypad.
FLASHBACK
Returns to previous channel.
PERSONAL PREFERENCE
With the Personal Preference buttons,
you can program your favorite programs by
using the four categories A, B, C and D. The
channels can be accessed quickly by using
these buttons. (See page 23.)
VOLUME UP/DOWN
(+) Increases sound.
(–) Decreases sound.
• In menu mode, changes or selects the TV
adjustments.
TV-CATV MODE SELECT SWITCH
In TV position, sends power and channel select
commands (Channel up/down and Random
Access buttons) to the TV.
In CATV position, sends power and channel
select commands to a cable TV converter.
VCR CONTROL
See page 27.
DISPLAY
Press →Display receiving channel for four
seconds.
Press again →Displays remaining time of
SLEEP TIMER and VIEW TIMER.
Press again →Temporarily displays receiving
channel when in Closed Caption mode.
Infrared Transmitter Window
INPUT
Press →Switch to external video INPUT 1
mode.
Press again →Switch to external video INPUT
2 mode.
Press again →Switch to external video INPUT
3 mode.
Press again →Switch back to the original TV
mode.
See page 25.
ENTER
Used in some instances where a VCR or Cable
Converter Box requires an “enter” command
after selecting channels, when using the
REMOTE KEYPAD button. (See page 27)
CHANNEL UP/DOWN
(8) Selects next higher channel.
(9) Selects next lower channel.
• See pages 21 - 22 for channel presetting.
• Moves the “ :” mark of the MENU screens.
MENU
Press →Accesses MAIN MENU.
Press again →Exits MAIN MENU.
MUTE
Press →Mutes sound.
Press again →Restores sound.
• CLOSED CAPTION appears when sound is
muted.
PIP FUNCTION
You can watch two pictures at the same time.
See page 24.
VIDEO/AUDIO TERMINALS
(VIDEO/AUDIO terminals are also provided on
the rear.)
IN 2
1 2 3
4 5 6
7 8 9
0 100
POWER
TV
VCR
MENU
CATV
PAUSE
PIP
TV
FLASHBACK
INPUT
TV •VCR •CATV
STOP REC
REW PLAY FF
VCR CH
SWAP FREEZE MOVE SELECT
CM SKIP DISPLAY MUTE
VOL
—
CH
CH
VOL
+
ENTER
A B C D
PERSONAL PREFERENCE
POWER CH –VOL + POWER VIEW TIMER
POWER CH –VOL + POWER VIEW TIMER
MENU
MENU
LED LED
NOTE:
Quick Reference Control Operation

8
LUbicación de los Controles (ESPAÑOL)
Front Delantero
Funciones Basicas Del Control Remoto
CANAL SUPERIOR/INFERIOR (CH) –MENU
(8)Selecciona el siguiente canal superior.
(9)Selecciona el siguiente canal inferior.
•Pulse ambos al mismo tiempo para acceder
a la pantalla de MENU PRINCIPAL.
TERMINALES DE ENTRADA
VIDEO/AUDIO
(Los terminales VIDEO/AUDIO también se
encuentran en la parte posterior)
ZONA DEL SENSOR DEL
MANDO A DISTANCIA
ALIMENTACION
(POWER)
Pulsando →Enciende (On).
Pulsando nuevamente →Apaga (Off).
ALIMENTACION (POWER)
Pulsando →Enciende (On).
Pulsando nuevamente →Apaga (Off).
TECLADO A DISTANCIA (REMOTE KEYPAD)
Para tener acceso a cualquier canal emplean-
do las teclas.
RETORNO AL CANAL ANTERIOR
(FLASHBACK)
Para volver al canal anterior.
PREFERENCIAS PERSONALES
(PERSONAL PREFERENCE)
Con los botones Personal Preference puede pro-
gramar sus programas favoritos utilizando las
cuatro categorías A, B, C y D.
Puede acceder a los canales rápidamente utili-
zando estos botones.
AUMENTO/DISMINUCION DEL VOLUMEN
(VOLUME UP/DOWN)
(+) Aumenta el sonido.
(–) Disminuye el sonido.
•En modo de MENU cambia o selecciona el
ajuste del televisor.
CONMUTADOR SELECTOR DE TELEVISOR/TV
POR CABLE (TV-CATV)
En la posición TV, el mando envia los coman-
dos de alimentación y selección de canales (bo-
tones de canal superior/inferior y de acceso
aleatorio) a un televisor.
En la posición CATV, envia los comandos de
alimentación y selección de canales a un con-
vertidor de TV por cable.
CONTROLES DEL VIDEO
VISUALIZACION (DISPLAY)
Pulsando →Aparece el canal de recepción
por cuatro segundos.
Pulsando nuevamente →Aparece el tiempo
restante del TEMPORIZADOR PARAAPAGAR
y del LIMITADOR.
•En el modo de “Closed Caption”se muestra
el canal de recepción por un corto tiempo.
•Los botones que arriba pueden verse sombreados en el Control Remoto lucen en la oscuridad. Para usar el visor del control remoto que
luce en la oscuridad, colocarlo bajo una luz fluorescente u otra fuente luminosa.
•El material fosforescente no contiene elementos radiactivos ni tóxicos, de modo que su uso no representa ningún peligro.
•El grado de iluminación variaráde acuerdo con la potencia de la luz utilizada.
•El grado de iluminación irádecayendo con el tiempo y dependiendo de la temperatura.
•El tiempo necesario para cargar el visor fosforescente variaráde acuerdo con la iluminación circundante.
•La luz del sol y la luz fluorescente son las más eficaces para la carga del visor.
Ventanilla del transmisor de infrarrojos
ENTRADA (INPUT)
Pulsando →Cambia al modo de entrada 1 del
vídeo externo.
Pulsando nuevamente →Cambia al modo de
entrada 2 del vídeo externo.
Pulsando nuevamente →Cambia al modo de
entrada 3 del vídeo externo.
Pulsando nuevamente →Vuelve al modo TV
original.
INTRODUCIR (ENTER)
Se utiliza en algunos casos en los cuales un
VCR o una Caja de Inversor de Cable requiere
una orden “enter”después de seleccionar los
canales, al usar el teclado a distancia.
CANAL SUPERIOR/INFERIOR
(CHANNEL UP/DOWN)
(8)Selecciona el siguiente canal superior.
(9)Selecciona el siguiente canal inferior.
•En el modo de MENU, mueve la marca “:”.
PREPARACION (MENU)
Pulsando →Accede al MENU PRINCIPAL.
Pulsando nuevamente →Sale del MENU
PRINCIPAL.
SILENCIAMIENTO (MUTE)
Pulsando →Silencia el sonido.
Pulsando nuevamente →Restaura el sonido.
•CLOSED CAPTION aparece automática-
mente cuando el sonido es silenciado.
Siempre y cuando la transmisión tenga esta
señal.
IMAGEN EN IMAGEN (FUNCTION PIP)
Se puede ver dos imágenes al mismo tiempo.
Front Delantero
Functiones Basicas Del Control Remoto
IN 2
POWER CH –VOL + POWER VIEW TIMER
POWER CH –VOL + POWER VIEW TIMER
MENU
MENU
1 2 3
4 5 6
7 8 9
0 100
POWER
TV
VCR
MENU
CATV
PAUSE
PIP
TV
FLASHBACK
INPUT
TV •VCR •CATV
STOP REC
REW PLAY FF
VCR CH
SWAP FREEZE MOVE SELECT
CM SKIP DISPLAY MUTE
VOL
—
CH
CH
VOL
+
ENTER
A B C D
PERSONAL PREFERENCE
DIODO EMISOR DE LUZ DIODO
EMISOR
DE LUZ
NOTE:
AUMENTO/DISMINUCION DEL VOLUMEN
(VOL)
(+) Aumenta el sonido.
(–) Disminuye el sonido.
Referencia rápida de los controles de operación

9
TOUCHES DES CANAUX
CROISSANT/DECROISSANT (CH) –MENU
(8)Sélectionne le canal supérieur suivant.
(9)Sélectionne le canal inférieur précédent.
•Appuyez simultanément sur ces deux
touches pour accéder àl’écran MENU
PRINCIPAL.
LEmplacement des touches (FRANÇAIS)
ALIMENTATION (POWER)
Appuyer pour mettre sous tension.
Appuyer de nouveau pour mettre hors tension.
ZONE DE DÉTECTION DU CAPTEUR
PRISES D’ENTRÉE VIDÉO/AUDIO
(Les prises VIDÉO/AUDIO sont également
reprises àl’arrière.)
AUGMENTATION/RÉDUCTION DU VOLUME
SONORE (VOL)
(+) Pour augmenter le volume du son.
(–) Pour diminuer le volume du son.
Fenêtre d’émission du signal infrarouge
ENTRÉE (INPUT)
Appuyer pour sélectionner le mode ENTRÉE
1 vidéo externe.
Appuyer de nouveau pour sélectionner le mode
ENTRÉE 2 vidéo externe.
Appuyer de nouveau pour sélectionner le
mode ENTRÉE 3 vidéo externe.
Appuyer de nouveau pour revenir au mode TV
initial.
ENTRER (ENTER)
Parfois utilisée lorsqu’un magnétoscope ou un
convertisseur nécessite l’introduction d’une
commande “enter”après la sélection de ca-
naux àl’aide du pavénumérique de comman-
de àdistance.
TOUCHES DES CANAUX CROISSANT/
DÉCROISSANT (CHANNEL UP/DOWN)
(8)Sélectionne le canal supérieur suivant.
(9)Sélectionne le canal inférieur précedént.
•Déplace le curseur “:”sur l’écran du MENU.
RÉGLAGE (MENU)
Appuyer →Accès au MENU PRINCIPAL.
Appuyer de nouveau →Sortie du MENU
PRINCIPAL.
SOURDINE (MUTE)
Appuyer →Mise en sourdine du son.
Appuyer de nouveau →Rétablissement du
son.
•CLOSED CAPTION apparaît lorsque le son
est mis en sourdine.
IMAGE DANS L’IMAGE (FUNCTION PIP)
Vous pouvez regarder deux images en même
temps.
ALIMENTATION (POWER)
Appuyer pour mettre sous tension.
Appuyer de nouveau pour mettre hors tension.
PAVÉNUMÉRIQUE DE COMMANDE A
DISTANCE (REMOTE KEYPAD)
Sélectionne directement le canal voulu sur le
pavénumérique.
RETOUR (FLASHBACK)
Rappelle demier le canal regardé.
PRÉFÉRENCES PERSONNELLES
(PERSONAL PREFERENCE)
Grâce aux touches de préférence personnelle,
vous pouvez programmer vos programmes
préférés àl’aide des 4 catégories:
A, B, C et D. Ces touches vous permettent
d’accéder rapidement àces canaux.
AUGMENTATION/RÉDUCTION DU
VOLUME SONORE (VOLUME UP/DOWN)
(+) Pour augmenter le volume du son.
(–) Pour diminuer le volume du son.
•Pour changer ou sélectionner les réglages
du téléviseur en mode menu.
SÉLECTEUR DE MODE TÉLÉVISION/
CÂBLOVISION (TV-CATV)
En position télévision (TV), permet de mettre
le téléviseur sous/hors tension et de
sélectionner ses canaux (touches de canaux
en ordre croissant/décroissant et d’accès
direct).
En position câblovision (CATV), permet de
mettre un convertisseur de téléviseur par câble
sous/hors tension et de sélectionner
ses canaux.
COMMANDE DU MAGNÉTOSCOPE
AFFICHAGE (DISPLAY)
Appuyer pour afficher le canal reçu pendant
quatre secondes.
Appuyer de nouveau →Affichage du temps
restant du MINUTEUR DE MISE HORS TENSION
ou du LIMITEUR.
•Pour afficher temporairement le canal
reçu en mode sous-titrage.
•Les boutons ombrés de la télécommande illustrés ci-dessus brillent dans l’obscuritélorsque la télécommande a étéplacée sous une
ampoule fluorescente ou toute autre source lumineuse.
•Le matériau phosphorescent n’est absolument pas toxique ou radioactif. Il peut donc être utiliséen toute sécurité.
•Le degréd’illumination variera en fonction de l’intensitéde la source d’éclairage.
•Le degréd’illumination diminuera avec le temps, en fonction de la température.
•Le temps requis pour charger les touches phosphorescentes dépendra de l’éclairage environnant.
•Les rayons directs du soleil et les luminaires fluorescents constituent les meilleures sources de chargement des touches phosphorescentes.
Fonctions de base de la télécommande
Panneau avant
1 2 3
4 5 6
7 8 9
0 100
POWER
TV
VCR
MENU
CATV
PAUSE
PIP
TV
FLASHBACK
INPUT
TV •VCR •CATV
STOP REC
REW PLAY FF
VCR CH
SWAP FREEZE MOVE SELECT
CM SKIP DISPLAY MUTE
VOL
—
CH
CH
VOL
+
ENTER
A B C D
PERSONAL PREFERENCE
POWER CH –VOL + POWER VIEW TIMER
POWER CH –VOL + POWER VIEW TIMER
MENU
MENU
IN 2
DEL DEL
REMARQUE:
Référence rapide sur les commandes

10
CH
CH
VOL
—VOL +
MENU
VOL
—
CH
CH
VOL
+
A B C D
PERSONAL PREFERENCE
LAccessing the MAIN MENU screen without Remote Control
• If you misplaced your Remote Control,
you can still access most settings via the
MAIN MENU screen when you press both
CH UP ( 8 )and DOWN ( 9 )on the TV set.
• Some features of your TV set will not be
accessible without the Remote Control. If
you lost your Remote Control, contact a
Sharp Service Center for a replacement.
CH
MENU
(On the Set)
CHANNEL
UP ( 8 )/DOWN ( 9 )
buttons
Menu Functions
LMaster these basic operations and the rest is simple.
9. SET UP
You can select each function of PERSONAL PREFERENCE,
UNIVERSAL PLUS, BLUE SCREEN, EZ SET UP, AIR/
CABLE, CH SEARCH and CH MEMORY. See pages 20 - 23.
10. PERSONAL PREFERENCE
By selecting the PERSONAL PREFERENCE channels in
advance you can select your favorite channels easily. See
page 23.
11. UNIVERSAL PLUS
VCR input mode will be selected automatically by pressing
VCR PLAY button on UNIVERSAL REMOTE CONTROL, and
CATV input mode by pressing TV-CATV switch. See page 22.
12. BLUE SCREEN
Automatically turns the screen blue if a broadcast signal is not
received. See page 23.
13. EZ SET UP
By operating the channel presetting functions, you can preset
your TV to the desired channels for viewing. See pages
20 - 21.
14. AIR/CABLE
You can select TV signal mode of AIR, CABLE STD, CABLE
HRC and CABLE IRC. See page 21.
15. CH SEARCH
You can save broadcast TV channels into memory. See
pages 21 - 22.
16. CH MEMORY
You can add weak or additional channels, or erase unwanted
channels from TV memory. See pages 21 - 22.
(SET UP mode)
VOLUME (+)/(–)
CHANNEL UP
(8)/DOWN (9)
MENU
LMENU SUMMARY
1. SLEEP TIMER
You can set the number of minutes for your TV to automati-
cally turn off. See page 12.
2. VIDEO ADJUST
You can adjust the settings of PICTURE, TINT, COLOR,
BRIGHTNESS, SHARPNESS, COLOR TEMP., FLESH
TONE and NOISE REDUCT. See page 13.
3. AUDIO ADJUST
You can adjust the AUDIO settings such as the BASS,
TREBLE and BALANCE, as well as MTS, EQUISOUND and
internal SPEAKER ON/OFF and SRS. See pages 13 - 14.
4. CLOSED CAPTION
Your TV is equipped with an internal Closed Caption decoder.
“Closed Caption” is a system which allows you to view
conversations, narration, and sound effects in TV programs
and home videos as subscript on your TV screen. See page 12.
5. PARENT CONTROL (V-CHIP)
This function allows you to restrict TV programs, to control TV
usage based on FCC data and to prevent your children from
watching violence or sexual scenes that may be harmful. See
pages 15 - 19.
6. PARENT CONTROL (VIEW TIMER)
This function allows you to restrict TV viewing time and also
allows you to control TV usage. This function is to prevent your
children from watching too much TV. See page 19.
7. LANGUAGE
Allows you to select between ENGLISH, ESPAÑOL and
FRANCAIS from the ON SCREEN DISPLAY. See page 11.
8. ENERGY SAVE
This function controls the BRIGHTNESS of CRT and reduces
power consumption about 20 percent. See page 20.
1Press MENU to access MAIN MENU screen.
2Press CH UP ( 8 )or DOWN ( 9 )to move the “ :”
mark to the desired function mode.
CH UP ( 8 )moves the “ :” mark up.
DOWN ( 9 )moves the “ :” mark down.
3Press VOL (+) or (–) to access the desired
function mode. (If you select RETURN, the cursor
moves to the MAIN MENU)
(MAIN MENU screen)
Calling Up the Functions. R/C buttons

11
AIR CABLE STD CABLE IRC CABLE HRC
POWER
POWER
TV
(EZ SETUP mode)
VOL
—VOL +
CH
CH
VOL
+
VOL
—VOL +
CH
CH
VOL
—VOL +
CH
CH
VOL
—VOL +
CH
CH
VOL
—VOL +
CH
CH
VOL
—VOL +
EZ SETUP during First Power On
(Remote
Control)
(On the Set)
LWhen you turn on the TV for the first time, it will automatically
memorize the broadcasting channels.
Please perform the following instructions before you press
the power button.
(1) Insert the batteries into the remote control. (See page 5)
(2) Connect the antenna cable to the TV set. (See page 6)
(3) Plug in the AC POWER cord to the wall outlet.
1Press the POWER button on the TV set or on the
Remote Control to turn on the TV. The SELECT
LANGUAGE mode will be displayed.
2 Press CH UP ( 8 )or DOWN ( 9 )to select
“ENGLISH”,“ESPAÑOL (SPANISH)”or “FRANÇAIS
(FRENCH)”and then press VOL (+) or (–) .
3Press CH UP ( 8 )or DOWN ( 9 )to select “NEXT”.
4Press VOL (+) or (–) to access SET AIR/CABLE mode.
5Press VOL (+) or (–) to set AIR/CABLE.
6Press CH UP ( 8 )or DOWN ( 9 )to select “NEXT”,
then press VOL (+) or (–) to access EZ SETUP mode.
7Press VOL (+) .
The tuner will automatically search for the broadcasting
and cable TV channels. (The CH No. will automatically
increase when it appears.)
If you want to stop the EZ SETUP process once it has
started, press VOL (–) and it will be canceled.
If you want to SETUP again, please refer to pages 20 -
23 on SETUP. Press VOL (–) to cancel EZ SETUP.
8Once EZ SETUP is completed, the lowest channel
number memorized will be displayed (Ex: 2 CH).
(SELECT LANGUAGE screen)
(SET AIR/CABLE mode)
Language
LThe language for the ON SCREEN DISPLAY can be set to
ENGLISH, SPANISH or FRENCH.
LSetting the ON SCREEN DISPLAY Language.
1Press MENU to access MAIN MENU screen.
2Press CH UP ( 8 )or DOWN ( 9 )to move the “:”
mark to “LANGUAGE”.
3Press VOL (+) or (–) to access LANGUAGE mode.
4Press CH UP ( 8 )or DOWN ( 9 )to move the “:”
mark to “ ESPAÑOL (SPANISH)”or “FRANÇAIS
(FRENCH )”.
5Press VOL(+) or (–) to select “ESPAÑOL
(SPANISH)”.
6Press MENU to exit.
•If EZ SETUP does not memorize all the channels
in your region, please refer to page 18 ~ 19 for more
information on manually memorizing the channels
using CHANNEL SETTING.
•It may be difficult to PRESET all channels in an
area when the broadcasting signals are weak, or
multiple stations are received on the same channel.
Please refer to pages 21 - 22 for more information
on manually memorizing additional channels using
CHANNEL MEMORY.
(MAIN MENU screen)
(LANGUAGE mode)
MENU
VOL
—
CH
CH
VOL
+
A B C D
PERSONAL PREFERENCE
VOLUME (+)/(–)
CHANNEL UP
(8)/DOWN (9)
MENU
NOTE:
VOL
—

12
LYou can set the number of minutes for your TV to
automatically turn off.
1Press MENU to access MAIN MENU screen.
2Press VOL (+) or (–) to access SLEEP TIMER mode.
3Press VOL (+) or (–) to set a sleep time of 30, 60, 90
or 120 minutes.
4Press MENU to exit.
• To turn off the Sleep Timer, repeat the above SLEEP TIMER
steps and select “– – – REMAIN” during step 3.
• While Sleep Timer is active, the time remaining will be briefly
displayed on-screen at regular intervals or when the remote's
Display key is pressed.
(SLEEP TIMER mode)
MENU
VOL
—
CH
CH
VOL
+
A B C D
PERSONAL PREFERENCE
VOLUME (+)/(–)
CHANNEL UP
(8)/DOWN (9)
MENU
Sleep Timer Closed Caption
VOL
—VOL +
CAPTION
TEXT
OFF
CH 1
CH 2
LHOW TO SET CLOSED CAPTION
•Your TV is equipped with an internal Closed Caption decoder.
“Closed Caption”is a system which allows you to view
conversations, narration, and sound effects in TV programs and
home videos as subscript on your TV screen as shown above.
•Not all the programs and videos will offer closed caption. Please
look for the “ ” symbol to ensure that captions will be shown.
•Closed Caption broadcast can be viewed in two modes:
CAPTION and TEXT. For each mode, two channels are available,
CH1 and CH2:
The [CAPTION] mode subscripts dialogues and commentaries
of TV dramas and news programs while allowing clear view of
the picture.
The [TEXT] mode displays over the picture other various
information (such as TV program schedule, weather forecast,
etc.) that is independent of the TV programs.
1Press MENU to access MAIN MENU screen.
2Press CH UP ( 8 )or DOWN ( 9 )to move the “:”
mark to “CLOSED CAPTION”.
3Press VOL (+) or (–) to access CLOSED CAPTION
setting mode.
4Press CH UP ( 8 )or DOWN ( 9 )to move the “:”
mark to either “MODE”or “DATA”.
5Press VOL (+) or (–) to change the CLOSED CAPTION
setting.
6Press MENU to exit.
•If a broadcast has CLOSED CAPTION and the MUTE button is
pressed, the set enters [CAPTION] mode automatically. Pressing
MUTE again will return the set to its previous condition.
•Closed Caption may malfunction (white blocks, strange
characters, etc.) if signal conditions are poor or if there are
problems at the broadcast source. This does not necessarily
indicate a problem with your set.
•If any button is pressed to call up the ON SCREEN DISPLAY
while viewing a CLOSED CAPTION broadcast, the closed
captions will disappear momentarily.
•When viewing in TEXT mode, if no TEXT broadcast is being
received, for some programs the screen may become dark and
blank. Should this occur, set the Closed Caption mode to “OFF”.
(CLOSED CAPTION setting mode)
MODE : DATA :
CH
CH
CH
CH
VOL
—VOL +
VOL
—VOL +
VOL
—VOL +
NOTE:
NOTE:

13
Video Adjust
Description of Adjustment Items
CH
CH
— +
1Press MENU to access MAIN MENU screen.
2Press CH UP ( 8 )or DOWN ( 9 )to move the “:”
mark to “VIDEO ADJUST”.
3Press VOL (+) or (–) to access VIDEO ADJUST
mode.
4Press CH UP ( 8 )or DOWN ( 9 )to move the “:”
mark to “the item (Ex. COLOR)”you wish to adjust.
5Press VOL (+) or (–) to access COLOR ADJUST
mode.
6Press VOL (+) or (–) to adjust “COLOR”.
7Repeat steps 4to 5to adjust other settings you wish
to adjust.
8Press MENU to exit.
(VIDEO ADJUST mode)
(COLOR ADJUST mode)
Selected item VOL UP (+) button VOL DOWN (–) button
PICTURE To increase contrast To decrease contrast
TINT To make skin tones greenish To make skin tones purplish
COLOR To increase color intensity To decrease color intensity
BRIGHT To increase brightness To decrease brightness
SHARP To increase sharpness To decrease sharpness
COLOR TEMP. To adjust color of the overall display:
“LOW”increases reddish color.
“HIGH”increases bluish color.
FLESH TONE When ON, adjusts skin tone to more natural colors.
NOISE REDUCTION When ON, reduces overall video noise.
RESET To return all adjustments to factory preset levels.
VOL
—VOL +
CH
CH
VOL
—VOL +
VOL
—VOL +
LOW M.L. (MID. LOW) M.H. (MID. HIGH) HIGH
( : VOL (+) / : VOL (–))
Audio Adjust
CH
CH
VOL
—VOL +
MTS EQUISOUND
STEREO
SAP
MONO STEREO
ON
OFF
SPEAKER
ON
OFF
SRS
OFF
3D MONO
LMTS (MULTICHANNEL TV SOUND)
This circuit allows reception of stereo or bilingual TV sound.
LEQUISOUND
This function keeps the volume level constant during
program changes and commercial breaks.
LINTERNAL SPEAKER SWITCH
This function turns the TV’s internal speakers “ON”or “OFF”
when listening to sound from external speakers by using
the AUDIO OUTPUT JACKS on page 26.
L(SOUND RETRIEVAL SYSTEM)
In “STEREO”mode, this function restores the Audio’s three
dimensional quality so that stereo sound is closer to a live
performance. The “3D MONO”mode adjusts mono sound
to simulate a more open, stereo-like quality.
1Press MENU to access MAIN MENU screen.
2Press CH UP ( 8 )or DOWN ( 9 )to move the “:”
mark to “AUDIO ADJUST”.
3Press VOL (+) or (–) to access AUDIO ADJUST
mode.
4Press CH UP ( 8 )or DOWN ( 9 )to move the “:”
mark to “MTS”, “EQUISOUND”, “SPEAKER”or
“SRS”.
5Press VOL (+) or (–) to select MTS mode “STEREO”,
“SAP”or “MONO”.
6Press MENU to exit.
(AUDIO ADJUST mode)
(MTS mode)
VOL
—VOL +
CH
CH
®

14
MENU
VOL
—
CH
CH
VOL
+
A B C D
PERSONAL PREFERENCE
VOLUME (+)/(–)
CHANNEL UP
(8)/DOWN (9)
MENU
—+
1Press MENU to access MAIN MENU screen.
2Press CH UP ( 8 )or DOWN ( 9 )to move the
“:”mark to “AUDIO ADJUST”.
3Press VOL (+) or (–) to access AUDIO ADJUST
mode.
4Press CH UP ( 8 )or DOWN ( 9 )to move the “:”
mark to “BASS”.
5Press VOL (+) or (–) to access BASS ADJUST
mode.
6Press VOL (+) or (–) to adjust “BASS”.
7Repeat steps 4and 5to adjust the other settings
you wish to adjust.
8Press MENU to exit.
Selected item VOL UP (+) button VOL DOWN (–) button
BASS To increase bass response. To decrease bass response.
TREBLE To increase treble response. To decrease treble response.
BALANCE To emphasize the right To emphasize the left
speaker’s volume. speaker’s volume.
RESET To return all adjustments to factory preset levels.
(BASS ADJUST mode)
(AUDIO ADJUST mode)
Ex.
Actual screen indicating ON AIR when receiving
STEREO broadcasts.
LYou can enjoy Hi-Fi stereo sound or SAP broadcasts where
available.
•Stereo broadcasts
Live television transmission of sports, shows, concerts, etc. can
be received in dynamic stereo sound.
•SAP broadcasts
Television broadcast can be received with either MAIN or SAP
sound.
MAIN sound: The normal program soundtrack. (Monaural or
stereo where available.)
SAP sound: Second language, supplementary commentaries,
etc. (SAP sound is monaural.)
LIf stereo sound is difficult to hear.
•You can obtain clearer sound by manually switching to fixed
monaural mode.
•Once MONO mode is selected, the TV sound remains monaural
even if the TV set receives a stereo broadcast. You must switch
the mode back to STEREO if you want to hear stereo sound
again.
•Selecting MTS while in the INPUT mode does not change the
type of sound; in this case, sound is determined by the video
source.
Actual channel number
“← ON AIR”will appear next to STEREO or SAP
when receiving STEREO or SAP broadcasts.
•SRS and the symbol are trademarks of SRS Labs, Inc. in
the United States and selected foreign countries. SRS technology
is incorporated under license from SRS Labs, Inc. and is
protected under United States Patent Nos. 4,748,669 and
4,841,572 with numerous additional issued and pending foreign
patents. Purchase of this product does not convey the right to
sell recordings made with the SRS technology.
VOL
—VOL +
VOL
—VOL +
CH
CH
CH
CH
VOL
—VOL +
Audio Adjust (Continued)
NOTE:
NOTE:

15
LV-CHIP
• This function allows you to restrict TV programs and also allows you to control TV usage based on FCC data. This function is to prevent your
children from watching violence or sexual scenes that may be harmful.
• Restriction of TV programs includes two characters that contain information about the program’s MPAArating and the TV Parental Guidelines.
MPAA is restricted by age. TV Parental Guidelines are restricted by age and contents.
• Since a TV program may use either the MPAA rating or the TV Guidelines you should adjust both for complete control.
[1] MPAA RATING
RATING
G GENERAL AUDIENCES. All ages admitted.
PG PARENTAL GUIDANCE SUGGESTED. Some material may not be suitable for children.
PG-13 PARENTS STRONGLY CAUTIONED. Some material may be inappropriate for children under 13.
R RESTRICTED. Under 17 requires accompanying parent or adult guardian.
NC-17 NO ONE 17 AND UNDER ADMITTED.
X X Rating is an older rating that is unified with NC-17 but may be encoded on older movie’s data.Note:
•MPAA RATING (Example)
Example 1.
“PG-13” in the age-based
RATING is blocked. This will
automatically block the high
ratings “R”, “NC-17”, “X” also.
• MPAA RATING is only age-based ratings.
[2] TV PARENTAL GUIDELINES
y content base x
FV V S L D
RATING (Fantasy (Violence) (Sexual (Adult (Sexually
Violence) Situation) Language) Suggestive
Dialog)
TV-Y (All children) XXXXX
TV-Y7 (Direct to Older Children) X XXX X
TV-G (General Audience) XXXX X
TV-PG (Parental Guidance Suggested) XXXX X
TV-14 (Parents Strongly Cautioned) XXXX X
TV-MA (Mature Audience Only) XXXXX
X: Content Rating can be set.
X: Content Rating can not be set (not normally broadcast by TV station).
•TV-PARENTAL GUIDELINES (Example)
Example 1.
If “TV-Y7” in age-based rating is “BLOCK” then this will
automatically block the higher ratings “TV-G”, “TV-PG”, “TV-14”
and “TV-MA”. Furthermore, the “D”, “L”, “S”, “V”,and “FV” in
“CONTENT” are automatically blocked for “TV-Y7” as well unless
you choose to unblock each one.
• Age-based ratings can be modified by the content-based ratings but only in the combinations indicated by an X in the table above.
• Choosing a lower age-based rating blocks the higher age-based ratings regardless of content ratings settings.
• An unblocked CONTENT RATING will override its respective AGE RATING, even when that AGE RATING is set to BLOCK. (For example,
if FCC data is “TV-PG” & “D”, then TV program is still viewable if CONTENT “D” is unblocked for “TV-PG” regardless if “TV-PG” AGE
RATING is also blocked.)
[3] ADDITIONAL MODE
Besides the above “MPAA RATINGS” and “TV PARENTAL GUIDELINES,” new ratings systems data can be downloaded when they
become available. (See page 17.)
E
age
base
D
age
base
Example 2.
“R” in the age-based RATING is
blocked. This will automatically
block the high ratings “NC-17” and
“X” also.
Example 2.
If all items in the age-based RATINGS are not blocked, “D” in content-
based ratings will be blocked as below. (2. Block table)
1. User setting 2. Block table
PG
age
base
not to
block
not to
block
Select
block
auto-
block
auto-
block
auto-
block
G G
PG
PG-13
R
NC-17
X
– – – – –
– – – – –
BLOCK
BLOCK
BLOCK
BLOCK
PG-13
R
NC-17
X
1. User setting 2. Block table
PG
age
base
not to
block
not to
block
not to
block
Select
block
auto-
block
auto-
block
G G
PG
PG-13
R
NC-17
X
–––––
–––––
–––––
BLOCK
BLOCK
BLOCK
PG-13
R
NC-17
X
TV-Y
FV V S L D
TV-G
TV-PG
TV-14
TV-MA
TV-Y
TV-Y7
TV-G
TV-PG
TV-14
TV-MA
BLOCK CONTENT (D L S V FV)
–––––
BLOCK
BLOCK
BLOCK
BLOCK
BLOCK
TV-Y7
TV-Y7 Select
block auto- block
age
base
content base
1. User setting 2. Block table
TV-Y
FV V S L D
TV-G
TV-PG
TV-14
TV-MA
TV-Y
TV-Y7
TV-G
TV-PG
TV-14
TV-MA
BLOCK CONTENT (D )
–––––
–––––
–––––
–––––
–––––
–––––
TV-Y7
TV-Y7
auto-
block
age
base
content base
1. User setting 2. Block table
NOTE:
NOTE:
Parent Control (V-CHIP operation)

16
[2] TV GUIDELINES
1Repeat steps 1to 4of [1] MPAA RATING to access V-
CHIP select move.
2Press CH UP ( 8 )or DOWN ( 9 )to move the “:”mark
to “TV GUIDELINES”.
3Press VOL (+) or (–) to access TV GUIDELINES mode.
4Press CH UP ( 8 )or DOWN ( 9 )to move the “:”mark to
“TV-Y7”, then press
VOL (+) or (–) to select BLOCK.
5Press MENU to exit.
•Higher ratings and their CONTENT are blocked when a
lower rating is set to BLOCK. Refer to example 1 in TV
PARENTAL GUIDELINES section of V-CHIP operation
on page 15.
1If you want to change CONTENT in above step 4, press
CH UP ( 8 )or DOWN ( 9 )to move the “:”mark to
CONTENT, then press
VOL (+) or (–) to access
CONTENT mode.
2You can select “BLOCK”or “– ––––” (VIEW) from
each CONTENT by pressing
CH UP ( 8 )or DOWN ( 9 )
and
VOL (+) or (–) if you want to control these ratings.
3Press MENU to exit.
•If FCC data of a TV program contains only theAGE rating
but not the CONTENT rating, then CONTENT settings
have no effect.
•Controlling only by the CONTENT rating works best if
each AGE rating is unblocked. Refer to example 2 in
TV PARENTAL GUIDELINES section of V-CHIP
operation on page 15.
Parent Control (V-CHIP operation Continued)
LHOW TO SET V-CHIP
[1] MPAA RATING
1Press MENU to access MAIN MENU screen.
2Press CH UP ( 8 )or DOWN ( 9 )to move the “:”mark
to “PARENT CONTROL”.
3Press VOL (+) or (–) to access PARENT CONTROL
mode. (The “:”mark move to “V-CHIP BLOCK”)
4Press VOL (+) or (–) to access V-CHIP select mode.
Press
VOL (+) or (–) to access MPAA rating mode.
6Press CH UP ( 8 )or DOWN ( 9 )to move the “:”mark
to “PG”, then press
VOL (+) or (–) to select BLOCK,
7Press MENU to exit.
•Higher ratings are blocked when a lower rating is set to
BLOCK. Refer to examples 1 and 2 in MPAA RATING
section of V-CHIP operation on page 15.
MENU
VOL
—
CH
CH
VOL
+
A B C D
PERSONAL PREFERENCE
VOLUME (+)/(–)
CHANNEL UP
(8)/DOWN (9)
MENU
(V-CHIP SELECT mode)
(TV GUIDELINES mode)
(CONTENT mode)
CH
CH
VOL
—VOL +
(MAIN MENU screen)
(PARENT CONTROL mode)
VOL
—VOL +
VOL
—VOL +
CH
CH
VOL
—VOL +
CH
CH
VOL
—VOL +
VOL
—VOL +
CH
CH
CH
CH
VOL
—VOL +
CH
CH
VOL
—VOL +
NOTE:
NOTE:
5
(V-CHIP SELECT mode)
(MPAA rating mode)
NOTE:

17
3Enter the 4-digit SECRET No. using the REMOTE
KEYPAD
, then V-CHIP BLOCK will temporarily be
canceled. If the wrong SECRET No. is chosen, “INPUT
SECRET No.”will be displayed again. Input the correct
SECRET No. again in this case.
4“V-CHIP TIMER mode”is displayed, then press VOL (+)
or (–) to set TIMER.
5Press MENU to exit.
LTo change the V-CHIP setting while V-CHIP BLOCK is set or
change the SECRET No. (When you forget the SECRET No.)
1Change to another unblocked channel. Repeat steps
1 to 4 of [1] MPAA RATING to access V-CHIP select
mode. The “INPUT SECRET No.”will be displayed
again.
2Press and hold both VOL (+) and CH DOWN ( 9 ) on
the TV set simultaneously until the message “INPUT
SECRET No.”disappears. The V-CHIP select mode
will be displayed and its settings or secret number can
be changed.
•As for the secret number, it will remain the same as shown
on the screen until you input another 4-digit pin number.
•If you turn the POWER OFF then ON again, the V-CHIP
function will be turned ON again.
[3]-A. Additional mode
There will be an additional new rating system. In that case,
please setup as follows. Subsequently the new rating system
will setup automatically.
1Repeat steps 1to 4of [1] MPAA RATING to access V-
CHIP select mode.
2Press CH UP ( 8 )or DOWN ( 9 )to move the “:” mark
to “OPTION”, then press VOL (+) or (–) .
Parent Control (V-CHIP operation Continued)
[3] TURN ON V-CHIP BLOCK
1Repeat steps 1 to 4 of (1) MPAA RATING to access V-
CHIP select mode.
2Press CH UP ( 8 )or DOWN ( 9 )to select “SECRET
No.”Enter the 4-digit secret no. (Ex. 1 2 3 4) using the
REMOTE KEYPAD.
3Press CH UP ( 8 )or DOWN ( 9 )to select “STATUS”.
Press
VOL (+) or (–) to turn “ON”the V-CHIP function.
(V-CHIP function is not operating if “STATUS”is
“OFF”.)
4Press MENU to exit.
LTo cancel the V-CHIP BLOCK screen while V-CHIP BLOCK
has been activated.
1“V-CHIP HAS BEEN ACTIVATED”will be displayed if
you watch the program with Program Rating data as
the same as you configured.
•“V-CHIP HAS BEEN ACTIVATED”will not be displayed
if STATUS is not configured to “ON”.
2Press MENU , then “INPUT SECRET No.”will be
displayed.
1 2 3
4 5 6
7 8 9
0 100
MENU
FLASHBACK
VOL
—
CH
CH
VOL
+
ENTER
A B C D
PERSONAL PREFERENCE
VOLUME (+)/(–)
CHANNEL UP
(8)/DOWN (9)
MENU
REMOTE
KEYPAD
(V-CHIP SELECT mode)
12
— — — —
12
CH
CH
1 2 3
4 5 6
7 8 9
0 100
ENTER
VOL
—VOL +
CH
CH
VOL
—VOL +
NOTE:
1 2 3
4 5 6
7 8 9
0 100
ENTER
VOL
—VOL +
CH
CH
NOTE:
(V-CHIP SELECT mode)
VOL (+) /
CHANNEL
DOWN
( 9 )
buttons
VOL +
MENU
CH

18
Parent Control (V-CHIP operation Continued)
4You can select “BLOCK”or “– ––––” (non BLOCK)
from each RATING by pressing
CH UP ( 8 )or DOWN
( 9 )and VOL (+) or (–) if your select “Cdn. FRENCH
RATINGS”in step 2.
LThe screen displays as follows when the picture is blocked
due to V-CHIP being activated.
A) PIP (Picture In Picture) is OFF
This is shown as page 17 [LTo cancel the V-CHIP BLOCK
screen while V-CHIP BLOCK has been activated].
B) PIP is ON
When the Main Picture is blocked, Main Picture will turn to blue
and “V-CHIP has been activated”will be displayed.
(Main and Sub Channel No. are displayed, but Sub Picture is
not displayed.)
This message will remain the same on the screen. Cancel the V-
CHIP BLOCK temporarily at the V-CHIP TIMER mode or change
to other channel in this case.
When the Sub Picture is blocked, Sub Picture will turn to blue
and “V-CHIP has been activated”will be displayed. This message
will remain the same on the screen. Cancel the V-CHIP BLOCK
temporarily at the V-CHIP TIMER mode or change to other
channel in this case.
V-CHIP TIMER mode during PIP ON
3Press CH UP ( 8 )or DOWN ( 9 )to select “DOWNLOAD” ,
press
VOL (+) or (–) to activate “ON”.
4Press MENU to exit.
LDOWNLOAD V-CHIP DATA
1If you watch the program with “New Rating System
Data”, DOWNLOAD screen will be displayed.
2DOWNLOAD screen will disappear, if DOWNLOAD is
finished.
•DOWNLOAD would not be started if you don’t watch
the program with New Rating System Data.
[3]-B. Additional mode (Example)
1Repeat steps 1to 4of [1] MPAA RATING to access V-
CHIP select mode.
2Press CH UP ( 8 )or DOWN ( 9 )to select “Cdn. ENGLISH
RATINGS”, then press
VOL (+) or (–) .
3You can select “BLOCK”or “– ––––” (non BLOCK)
from each RATING by pressing
CH UP ( 8 )or DOWN
( 9 )and VOL (+) or (–) .
(CANADIAN ENGLISH INDIVIDUAL BLOCK)
(CANADIAN FRENCH INDIVIDUAL BLOCK)
(DOWNLOAD screen)
(After download, the new rating data)
12
(Main Picture screen)
12
(Main and Sub Picture screen)
Sub
12
(V-CHIP TIMER mode)
Main
VOL
—VOL +
CH
CH
VOL
—VOL +
CH
CH
VOL
—VOL +
CH
CH
VOL
—VOL +
NOTE:
CH
CH

19
VOL +
MENU
CH
(On the Set)
VOL (+) /
CHANNEL
DOWN
( 9 )
buttons
VOL +
MENU
CH
(On the Set)
VOL (+) /
CHANNEL
DOWN
( 9 )
buttons
— — — —
1 2 3
4 5 6
7 8 9
0 100
ENTER
1 2 3
4 5 6
7 8 9
0 100
ENTER
* * * *
CH
CH
VOL
—VOL +
CH
CH
VOL
—VOL +
CH
CH
VOL
—VOL +
CH
CH
CH
CH
VOL
—VOL +
VOL
—VOL +
VOL
—VOL +
LNotice of Remaining VIEWING TIME
• For every 30 minute interval, the
“remaining time” will be displayed for
four seconds. For the last 5 minutes,
the “remaining time” will be displayed
every minute.
• “0H 00M REMAIN” will be displayed for
10 seconds just before the VIEWING
TIME is completed.
LTo cancel the VIEW TIMER setting or change the SECRET
No.(When you forget the SECRET No.)
1Repeat steps 1 to 3 of “How to set VIEW TIMER.”
During Step 3, Press VOL (+) or (–) , and the
message “VIEWING TIMER NOW SET” will be
displayed.
2Press and hold both VOL (+) and CH DOWN ( 9 )on
the TV set simultaneously until the message
“VIEWING TIMER NOW SET” disappears. The
VIEW TIMER is now off.
3Now repeat again Steps 1 to 3 of “How to set VIEW
TIMER." During Step 3, press the VOL (+) or (–) ,
and the message “INPUT SECRET No.” is
displayed.
4Enter the 4-digit SECRET No. using REMOTE
KEYPAD , and the VIEW TIMER mode will be
displayed. Repeat Steps 5- 7of “How to set VIEW
TIMER”.
5If in Step 4above you have forgotten your SECRET
No., press and hold both VOL (+) and CH DOWN
( 9 )on the TV set simultaneously until the message
“INPUT SECRET No.” disappears and the VIEW
TIMER mode will be displayed. Then repeat Steps
5- 7of “How to set VIEW TIMER”.
6Press MENU to exit.
• When you choose the correct SECRET No., VIEW TIMER mode
is displayed. If the wrong SECRET No. is chosen, the screen
message is not displayed. Input the SECRET No. again in this
case.
• While the TV set is OFF but the VIEW TIMER is set: Turn on TV;
the screen message “TIME OVER” will appear. If you do nothing,
the TV will turn off in approximately 30 seconds.
• To cancel VIEW TIMER while the TV set is OFF but the VIEW
TIMER is set: Turn on the TV; the screen message “TIME OVER”
will appear. Repeat “To cancel VIEW TIMER” Steps 2 - 6.
(VIEW TIMER mode)
LVIEW TIMER
This function allows you to restrict TV viewing time and also
allows you to control TV usage. This function is to prevent
your children from watching too much TV.
LHow to set VIEW TIMER.
1Press MENU to access MAIN screen.
2Press CH UP ( 8 )or DOWN ( 9 )to move the “ :”
mark to “PARENT CONTROL”.
3Press VOL (+) or (–) to access PARENT CONTROL
mode.
4Press CH UP ( 8 )or DOWN ( 9 )to move the “ :”
mark to “VIEW TIMER”.
5Press VOL (+) or (–) to access VIEW TIMER mode.
6Press CH UP ( 8 )or DOWN ( 9 )to select “VIEWING
TIME” and “OFF TIME”. For each selection, press
the VOL (+) or (–) to set the time duration.
7Press CH UP ( 8 )or DOWN ( 9 )to select “SECRET
No.” and then enter the 4-digit no. using the REMOTE
KEYPAD .
8Press CH UP ( 8 )or DOWN ( 9 )to select “STATUS”.
Press the VOL (+) or (–) to turn ON the “VIEWING
TIMER”. (If STATUS is OFF, VIEW TIMER is not
operated)
9Press MENU to exit.
Example
• To restrict anybody from watching the TV for 5 hours, after
watching the TV for 2 hours, your settings would look like the
settings in Step 8.
• They can choose to watch the 2 hours of TV however they wish.
For example, they could watch 1 hour of TV, turn TV off for 30
minutes, then turn TV on and watch the remaining 1 hour on the
VIEWING TIMER.
(PARENT CONTROL mode)
Parent Control (VIEW TIMER)
(VIEW TIMER mode; before setting)
(VIEW TIMER mode; after setting)
NOTE:
NOTE:

20
1 2 3
4 5 6
7 8 9
0 100
MENU
FLASHBACK
VOL
—
CH
CH
VOL
+
ENTER
A B C D
PERSONAL PREFERENCE
REMOTE
KEYPAD
VOLUME
(+)/(–)
CHANNEL UP
(8)/DOWN (9)
MENU
CH
CH
VOL
—VOL +
VOL
—VOL +
CH
CH
VOL
—VOL +
CH
CH
VOL
—VOL +
VOL
+
(MAIN MENU screen)
(SET UP mode)
Set Up
Energy Save
LThis feature lets you lower the power consumption of your
TV set which in turn saves you money and minimizes the
impact on the environment. When this feature is turned on,
it reduces the brightness of the TV to a level that consumes
approximately 20 percent less energy than when the feature
is turned off.
The reduction in brightness will be less noticeable under
low room lighting conditions.
1Press MENU to access MAIN MENU screen.
2Press CH UP ( 8 )or DOWN ( 9 )to move the “:”
mark to “ENERGY SAVE”.
3Press VOL (+) or (–) to access ENERGY SAVE
select mode.
4Press VOL (+) or (–) to select “ON”.
5Press MENU to exit.
(MAIN MENU screen)
(ENERGY SAVE select mode)
LEZ SETUP
By operating the channel presetting functions, you can
preset your TV to the desired channels for viewing.
1Press MENU to access MAIN MENU screen.
2Press CH UP ( 8 )or DOWN ( 9 )to move the “:”
mark to “SET UP”.
3Press VOL (+) or (–) to access SET UP mode.
4Press CH UP ( 8 )or DOWN ( 9 ) to move the “:”
mark to “EZ SET UP”.
5Press VOL (+) or (–) to access EZ SET UP.
6Press VOL (+) .
The tuner will automatically search for the
broadcasting and cable TV channels. (The CH No.
will automatically increase when it appears.)
If you want to stop the EZ SETUP process once it
has started, press VOL (–) . Search will be canceled.
To cancel EZ SETUP
Press VOL (–) .
VOL
—
