Sharp 21K-FD5RU User manual

FEATURES
■Aperture Control Circuit
■Auto Fine Tuning
■Colour Comb Filter (PAL & NTSC)
■High Contrast Picture
■Hotel Mode
■English/ Russia
2 Languages OSD
■White Temperature Select
■Component In
SERVICE MANUAL
TopPage
21K-FD5RU
No. S360921KFD5RU
COLOUR TELEVISION
Chassis No.GA-5
MODEL 21K-FD5RU
In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its original condition and
only parts identical to those specified should be used.
■Multi 21 Systems
■Full Auto Channel Preset and Auto
Channel Skip
■100-CH Program Memory
■CATV (Hyper Band) Ready
<Used Frequency Synthesizer Tuner>
■Black Stretch Circuit
■On Timer/Sleep Timer/Reminder Timer
■Blue Back Noise Mute
■Front AV IN & Rear AV IN/OUT Terminals
■Surround Sound Effect (with Bass/
Treble/Balance)
■AV Stereo
■Blue Stretch Function
■AV Mode (Dynamic/Standard/Soft)
■Auto Picture Noise Reduction
■Pixel Generator
■Nicam & A2 Stereo decoder
■Tuner Booster
■Multi Language FastText
The chassis in this receiver is partially hot. Use an isolation transformer between the line cord plug and power receptacle, when servicing
this chassis. To prevent electric shock, do not remove cover. No user-serviceable parts inside. Refer servicing to qualified service personnel.
WARNING
CHAPTER 1. SPECIFICATIONS
[1] SPECIFICATIONS ..................................................1-1
CHAPTER 2. IMPORTANT SERVICE NOTES
[1] IMPORTANT SERVICE NOTES .............................2-1
CHAPTER 3. ADJUSTMENT PRECAUTIONS
[1] ADJUSTMENT PRECAUTIONS .............................3-1
[2] ADJUSTMENT ......................................................3-17
CHAPTER 4. MEMORY MAP
[1] MEMORY MAP .......................................................4-1
CHAPTER 5. TROUBLE SHOOTING
[1] TROUBLE SHOOTING ...........................................5-1
CHAPTER 6. SOLID STATE DEVICE BASE DIAGRAM
[1] SOLID STATE DEVICE BASE DIAGRAM...............6-1
CHAPTER 7. CHASSIS LAYOUT
[1] CHASSIS LAYOUT .................................................7-1
CHAPTER 8. BLOCK DIAGRAM
[1] BLOCK DIAGRAM: MAIN UNIT..............................8-1
[2] BLOCK DIAGRAM: CRT UNIT ...............................8-3
[3] BLOCK DIAGRAM: HEADPHONE UNIT ................8-3
[4] BLOCK DIAGRAM: NICAM UNIT ...........................8-4
CHAPTER 9. DESCRIPTION OF SCHEMATIC DIAGRAM
[1] DESCRIPTION OF SCHEMATIC DIAGRAM..........9-1
CHAPTER 10. WAVEFORM
[1] WAVEFORMS.......................................................10-1
CHAPTER 11. SCHEMATIC DIAGRAM
[1] SCHEMATIC DIAGRAM: CRT UNIT.....................11-1
[2] SCHEMATIC DIAGRAM: HEADPHONE UNIT........11-1
[3] SCHEMATIC DIAGRAM: NICAM UNIT ................11-2
[4] SCHEMATIC DIAGRAM: MAIN UNIT ...................11-3
CHAPTER 12. PRINTED WIRING BOARD ASSEMBLIES
[1] PWB-A: MAIN UNIT..............................................12-1
[2] PWB-B: CRT UNIT................................................12-5
[3] PWB-C: HEADPHONE UNIT ................................12-5
[4] PWB-D: NICAM UNIT ...........................................12-6
Parts Guide
CONTENTS

21K-FD5RU
1 – 1
CHAPTER 1. SPECIFICATIONS
[1] SPECIFICATIONS
Convergence ................................................................................................................ Self Convergence System
Focus
............................................................................................................................ UNI-BI Focusing
Sweep Deflection ..................................................................................................................................... Magnetic
Intermediate Frequencies
Picture IF Carrier ................................................................................................................................. 38.9MHz
Sound IF Carrier Frequency
4.5MHz ............................................................................................................................................. 34.4MHz
5.5MHz ............................................................................................................................................. 33.4MHz
6.0MHz ............................................................................................................................................. 32.9MHz
6.5MHz ............................................................................................................................................. 32.4MHz
Colour Sub-Carrier Frequency........................................................................................................... 34.47MHz
Cabinet materrial..................................................................................................................................... All Plastics
Specifications are subject to change without prior notice
Aerial Input Impedance
VHF/UHF .......................................................................................................................... 75 ohms Unbalanced
Receiving System ...................................................................... PAL I, B/G, D/K SECAM B/G, D/K, K1, NTSC-M
Receiving Channel
VHF-Channels ......................................................................................... E2(48.25MHz) thru E12(224.25MHz)
C1(49.75MHz) thru C12(216.25MHz)
S1(105.25MHz) thru S41(463.25MHz)
UHF-Channels ..................................................................................... E21(471.25MHz) thru E69(855.25MHz)
C13(471.25MHz) thru C57(863.25MHz)
Power Input .......................................................................................................................... 220 ~ 240V AC 50 Hz
Power Consumption.................................................................................................................................
.....
115W
Audio Power Output Rating ....................................................................................................... 7.5W(rms) x 2pcs
Voice Coil Impedance .............................................................................................................16 ohms at 400 Hz
.........................................................................................................................................
Speaker
12 x 6 cm (2pcs)
Size
Dimensions ..................................................................................................................................... Width: 605mm
Height: 468mm
Depth: 487.5mm
Weight(approx): 22.5kg

21K-FD5RU
2 – 1
TV21K-FD5RUService Manual21K-FD5RUMarketE
CHAPTER 2. IMPORTANT SERVICE NOTES
[1] IMPORTANT SERVICE NOTES
Maintenance and repair of this receiver should be done by qualified service personnel only.
1. SERVICE OF HIGH VOLTAGE SYSTEM AND PICTURE TUBE
When servicing the high voltage system, remove static charge from it by connecting a 10K ohm resistor in series with an insulated wire ( such as a
test probe ) between picture tube dag and 2nd anode lead. ( AC line cord should be disconnected from AC outlet. )
1) Picture tube in this receiver employs integral implosion protection.
2) Replace with the same type number of picture tube for continued safety.
3) Do not lift picture tube by the neck.
4) Handle the picture tube only when wearing shatterproof goggles and after discharging the high voltage completrly.
2. X-RAY
This receiver is designed so that any X-Ray radiation is kept to an absolute minimum. Since certainmalfunctions or servicing may produce potentially
hazardous radiation with prolonged exposure at close range, the following precautions should be observed :
1) When repairing the circuit, please make sure do not increase the high voltage of the set to more that 30.0kV ( at beam 0µA ).
2) To keep the set in a normal operation, please make sure it’s function at 26.2kV±1.0kV ( at beam 1150µA ). The set has been factory - adjusted to
the above -mentioned high voltage.
* If there is a possibility that the hig voltage fluctuates as a result of the repairs,never forget to checkfor such high voltage after the work.
3) Do not substitute a picture tube with unauthorized types and/or brands which may cause excessive X-ray radiation.
3. BEFORE RETURNING THE RECEIVER
Before returning the receiver to the user , perform the following safety checks.
1) Inspect all lead dress to make certain that leads are not pinched or that hardware is not lodged between the chassis and other metal parts in the
receiver.
2) Inspect all protective devices such as non-mental control knobs, insulating materials,cabinet backs,adjustment and compartment cover or
shields,isolation resistor-capacity networks,mechanical insulators etc.

21K-FD5RU
3 – 1
TV21K-FD5RUService Manual21K-FD5RUMarketE
CHAPTER 3. ADJUSTMENT PRECAUTIONS
[1] ADJUSTMENT PRECAUTIONS
This model's setting are adjusted in two different ways: through the I2C bus control and in the conventional analog manner. The
adjustments via the I2C bus control include preset-only items and variable data.
CAUTION: MAKE SURE TV SET IN "NORMAL CONDITION" BEFORE SWITCH TO SERVICE MODE FOR ADJUSTMENT.
1. Setting the service mode by the microprocessor.
1) Press SERVICE key on the remote controller to set the TV set to SERVICE mode position, and the microprocessor is in
input mode. (Adjustment through the I2C bus control).
2) Press the MENU key on the remote controller to get ready to select the mode. (Adjustment mode, Setting mode, Check
mode and Option mode) one by one.
3) Press the CH DOWN / UP key on the remote controller to select the item in Adjustment mode, Setting mode or Option
mode.
4) Using the VOLUME UP / DOWN key on the remote controller, the data can be modified. Please wait approximately 200
msec for data storage in EEPROM before select to another mode.
5) In Check mode the data cannot be changed.
6) Press the SERVICE key again, it will switch to the NORMAL mode position, and the microprocessor is out of the SERVICE
mode.
2. Factory Presetting.
1) Power ON the TV set, press the SERVICE key on the remote controller, then press both the CH UP and VOL UP button on
the set simultaniously for 5 secs.
Initial values are automatically preset, only when a new EEPROM is used.
2) The initial data are preset as listed in page 3.7 ~ 3.16.
3) Make sure the data need modification or not (Initial data).
Precaution: If haven’t done this initialization, it may possibly generate excessive Beam current.
3. For reference please check with memory map RH-IXB584WJXX (See attachment).

21K-FD5RU
3 – 2
1. ADJUSTMENT ITEM
***Below are the adjustment items that should be done, PLS FOLLOW THE PROCEDURE.
Otherwise some adjustment items will not be accurate.
NO *** ADJUSTMENT ITEM EFFECTIVE MODEL REVISION
1 BUS SET UP
2 OPTION SET UP
3H-VCO
4VIF-VCO
5 S-TRAP fo
6RF-AGC
7 PURITY ADJ
8 CONVERGENCE ADJ
9 FOCUS ADJ
10 V-SHIFT (50 Hz) ALL MODEL
11 H-SHIFT (50 Hz)
12 V-SIZE (50 Hz)
13 SCREEN
14 SECAM-OFFSET
15 SUB-COLOR
16 SUB-TINT
17 WHITE BALANCE
18 SUB-BRIGHTNESS
19 SUB-CONTRAST
20 SIF VCO ADJ Only for Nicam model
21 BEAM CURRENT CHECK
22 BEAM PROTECTOR CHECK
23 HV PROTECTOR CHECK
24 OTHER PROTECTOR CHECK
25 AV OUT CHECK
26 AV IN CHECK
27 COMPONENT IN CHECK
28 CONTRAST CONTROL CHECK
29 COLOR CONTROL CHECK
30 BRIGHTNESS CONTROL CHECK
31 TINT CONTROL CHECK
32 SHARPNESS CONTROL CHECK
33 CH DISPLAY COLOR CHECK ALL MODEL
34 NORMAL DISPLAY CHECK
35 WHITE TEMP CONTROL CHECK
36 COLOR SYSTEM CHECK
37 SURROUND CHECK
38 TREBLE CHECK
39 BASS CHECK
40 BALANCE CHECK
41 SOUND SYSTEM CHECK
42 NOISE MUTE CHECK
43 OSD LANGUAGE QUANTITY CHECK
44 HEAD PHONE CHECK
45 SHOCK TEST CHECK

21K-FD5RU
3 – 3
2. USER DATA IN SERVICE MODE
1). While SERVICE mode ON, EEPROM DATA will switch to the service data. Also, once SERVICE mode OFF, EEPROM will switch back
to previous USER DATA.
2). In the service mode, the user data establish as below.
USER DATA
CONTRAST MAX 60
COLOUR CENT 0
BRIGHTNESS CENT 0
TINT CENT 0
SHARPNESS CENT 0
WHITE TEMP STANDARD
S-VOLUME MIN
SURROUND OFF
TREBLE CENT 0
BASS CENT 0
BALANCE CENT 0
BLUE BACK OFF
C SYSTEM AUTO
S SYSTEM *1
*1: For each CH, data is same as before switch to Service mode.
The flow of Mode list as following,
* Direct Key-in Mode for Service Items in Service Mode
RC CODE (HEX) R/C KEY NAME SERVICE-ITEM
01 POS 1 R-C UP (IN SERVICE MODE V00)
02 POS 2 G-C UP (IN SERVICE MODE V00)
03 POS 3 B-C UP (IN SERVICE MODE V00)
04 POS 4 R-C DOWN (IN SERVICE MODE V00)
05 POS 5 G-C DOWN (IN SERVICE MODE V00)
06 POS 6 B-C DOWN (IN SERVICE MODE V00)
07 POS 7 R-D UP (IN SERVICE MODE V00)
08 POS 8 B-D UP (IN SERVICE MODE V00)
0A POS 0 B-D DOWN (IN SERVICE MODE V00)
09 FLASHBACK R-D DOWN (IN SERVICE MODE V00)
27 FLASHBACK Y-MUTE (BESIDES OF SERVICE MODE V00)
AE WHITE TEMP UP RF-AGC (V01)
AF WHITE TEMP DOWN VIF-VC0 (V02)
43 TUNE DOWN H-VCO (V03)
B1 SHARPNESS DOWN SUB-CON (V04)
6B BALANCE LEFT SUB-COL (V05)
B0 SHARPNESS UP SUB-BRIGHT (V06)
6C BALANCE RIGHT SUB-TINT (V07)
62 TREBLE UP SUB-SHP (V08)
63 TREBLE DOWN SUB-COL-YUV (V09)
64 BASS UP SUB-TINT-YUV (V10)
24 COLOUR UP V-SIZE (V11), V-SIZE60 (V17)
2A BRIGHTNESS DOWN V-SHIFT (V12), V-SHIFT60 (V18)
2E TINT DOWN H-SHIFT (V13), H-SHIFT60 (V19)
66 SURROUND UP SCM-BR (V14)
67 SURROUND DOWN SCM-BB (V15)
23 CONTRAST DOWN SUB-VOL (V16)
32 PICTURE S-TRAP-BG (V20)
33 HOLD S-TRAP-I (V21)
34 TEXT S-TRAP-DK (V22)
35 CANCEL S-TRAP-M (V23)
37 SIZE S-TRAP-574 (V24)
01 POS 1 R-C UP YUV (IN SERVICE MODE V25)
02 POS 2 G-C UP YUV (IN SERVICE MODE V25)
03 POS 3 B-C UP YUV (IN SERVICE MODE V25)
04 POS 4 R-C DOWN YUV (IN SERVICE MODE V25)
05 POS 5 G-C DOWN YUV (IN SERVICE MODE V25)
06 POS 6 B-C DOWN YUV (IN SERVICE MODE V25)

21K-FD5RU
3 – 4
RC CODE (HEX) R/C KEY NAME SERVICE-ITEM
07 POS 7 R-D UP YUV (IN SERVICE MODE V25)
08 POS 8 B-D UP YUV (IN SERVICE MODE V25)
0A POS 0 B-D DOWN YUV (IN SERVICE MODE V25)
09 FLASHBACK R-D DOWN YUV (IN SERVICE MODE V25)
83 AUTO ADJ FOR V01, V02, V03, V20, V21, V22, V23, V24
53 T-SET
81 SERVICE MODE
1.) Please set the MCL according to the specific models.
MCL1 : 21K-FD5RU
MCL2 :
MCL3 :
MCL4 :
2.) After set the MCL, please set the INITIAL SETTING for each models.
INITIAL 1 : For China ( All Channel Sound System are set to D/K )
INITIAL 2 : For Hong Kong ( All Channel Sound System are set to I )
INITIAL 3 : For Singapore, Africa and Australia ( All Channel Sound System are set to B/G )
INITIAL 4 : For Middle-East ( All Channel Sound System are set to B/G )
INITIAL 5: For Russia (All Channel Sound System are set to D/K)
MCL1 (HEX AE) MCL2 (HEX 95) MCL3 (HEX 55) MCL4 (HEX D5)
CH-No Fv (MHz) Sound Sys CH-No Fv (MHz) Sound Sys CH-No Fv (MHz) Sound Sys CH-No Fv (MHz) Sound Sys
0 0 590.25 B/G 0 0
1 48.25 B/G 1 46.25 B/G 1 48.25 B/G 1 55.25 B/G
2 62.25 B/G 2 64.25 B/G 2 59.25 D/K 2 175.25 B/G
3 77.25 D/K 3 86.25 B/G 3 65.75 D/K 3 189.25 B/G
4 175.25 B/G 4 95.25 B/G 4 77.25 D/K 4 203.25 B/G
5 182.25 B/G 5 138.25 B/G 5 85.25 D/K 5 217.25 B/G
6 183.25 D/K 6 175.25 B/G 6 93.25 D/K 6 535.25 B/G
7 191.25 D/K 7 182.25 B/G 7 175.25 B/G 7
8 196.25 B/G 8 189.25 B/G 8 184.25 D/K 8
9 199.25 M 9 196.25 B/G 9 199.25 D/K 9
10 210.25 B/G 10 209.25 B/G 10 210.25 B/G 10
11 224.25 B/G 11 216.25 B/G 11 224.25 B/G 11 48.25 B/G
12 471.25 B/G 12 12 487.25 I 12 62.25 B/G
13 487.25 I 13 13 503.25 I 13 196.25 B/G
14 503.25 B/G 14 14 575.25 B/G 14 210.25 B/G
15 575.25 B/G 15 15 639.25 D/K 15 224.25 B/G
16 583.25 B/G 16 16 767.25 D/K 16 471.25 B/G
17 599.25 B/G 17 17 831.25 D/K 17 855.25 B/G
18 621.25 M 18 18 855.25 I 18
19 639.25 D/K 19 19 97.25 M 19
20 703.25 B/G 20 20 183.25 M 20
21 735.25 I 21 21 193.25 M 21 223.95 B/G
22 767.25 B/G 22 22 211.25 M 22 224.55 B/G
23 815.25 B/G 23 23 217.25 M 23 223.85 B/G
24 855.25 I 24 24 477.25 M 24 224.65 B/G
25 855.25 B/G 25 25 693.25 M 25 223.75 B/G
26 55.25 M 26 26 62.25 B/G 26 224.75 B/G
27 83.25 M 27 27 503.25 B/G 27
28 183.25 M 28 527.25 B/G 28 527.25 B/G 28
29 193.25 M 29 29 599.25 B/G 29
30 217.25 M 30 30 621.25 M 30
31 471.25 M 31 31 815.25 B/G 31 91.25 M
32 477.25 M 32 32 112.25 B/G 32 103.25 M
33 693.25 M 33 33 168.25 B/G 33 171.25 M
34 885.25 M 34 34 91.25 M 34 183.25 M
35 112.25 B/G 35 35 294.25 B/G 35 193.25 M
36 168.25 B/G 36 36 463.25 B/G 36 205.25 M
37 37 590.25 B/G 37 174.95 B/G 37 217.25 M
38 294.25 B/G 38 38 174.55 B/G 38 621.25 M
39 463.25 B/G 39 39 39
40 40 40 40

21K-FD5RU
3 – 5
MCL1 (HEX AE) MCL2 (HEX 95) MCL3 (HEX 55) MCL4 (HEX D5)
CH-No Fv (MHz) Sound Sys CH-No Fv (MHz) Sound Sys CH-No Fv (MHz) Sound Sys CH-No Fv (MHz) Sound Sys
41 647.25 B/G 41 48.25 B/G 41 41
42 663.25 B/G 42 62.25 B/G 42 42
43 679.25 B/G 43 77.25 D/K 43 43
44 174.95 B/G 44 175.25 B/G 44 44
45 175.55 B/G 45 183.25 D/K 45 45
46 46 191.25 D/K 46 46
47 47 210.25 B/G 47 47
48 48 224.25 B/G 48 48
49 49 487.25 I 49 49
50 50 503.25 B/G 50 50
51 51 575.25 B/G 51 51
52 52 599.25 B/G 52 52
53 53 621.25 M 53 53
54 54 639.25 D/K 54 54
55 55 735.25 I 55 55
56 56 767.25 B/G 56 56
57 57 815.25 B/G 57 57
58 58 855.25 I 58 58
59 59 91.25 M 59 59
60 60 183.25 M 60 60
61 61 193.25 M 61 61
62 62 217.25 M 62 62
63 63 471.25 M 63 63
64 64 693.25 M 64 64
65 65 112.25 B/G 65 65
66 66 168.25 B/G 66 66
67 67 294.25 B/G 67 67
68 68 463.25 B/G 68 68
69 69 174.25 B/G 69 69
70 70 175.25 B/G 70 70

21K-FD5RU
3 – 6
3. SHIPPING SETTING & CHECKING
(1) The following default data has been factory-set for the E2PROM follow by INITIAL DATA selected.
ITEMS DATA SETTING
LAST POWER ON
LAST TV/AV MODE TV MODE
LAST POSITION CH 1
FLASHBACK CHANNEL CH 1
1/2 DIGIT ENTRY 2 DIGIT ENTRY
VOLUME 0 (Min)
BLUE BACK OFF
OFF TIMER --:--
ON TIMER --:--
ON TIMER POSITION --
ON TIMER VOLUME --
REMINDER --:--
AFT ALL CH ON
COLOR SYSTEM ALL CH AUTO
SKIP ALL CH OFF
NICAM ON/OFF ALL CH ON
NICAM STEREO MODE ALL CH STEREO
NICAM BILINGUAL MODE ALL CH MAIN
NICAM MONO MODE ALL CH MONO
A2 ON/OFF ALL CH ON
A2 STEREO MODE ALL CH STEREO
A2 BILINGUAL MODE ALL CH MAIN
CONTRAST 60
COLOR 0
BRIGHTNESS 0
TINT 0
SHARPNESS 0
WHITE TEMP 0
SURROUND OFF
TREBLE 0
BASS 0
BALANCE 0 (CENTER)
INITIAL LANGUAGE SOUND SYSTEM
1 (HEX 14) CHINESE D/K
2 (HEX 15) CHINESE I
3 (HEX 17) ENGLISH B/G
4 (HEX 97) ARABIC B/G
5 (HEX 57) RUSSIAN D/K
6 (HEX D7) MALAY B/G
7 (HEX 37) FRENCH D/K
FACTORY SETTING BY MODEL
(Reference: Geomagnetism Adjustment)
MODEL MAGNETIC FIELD(V, H) nT BACKGROUND LANG. S-SYS LANG QTY
CHINA 30000 20000 12300K CHINESE D/K 5
HONG KONG 20000 40000 12300K CHINESE I 5
SINGAPORE -10000 40000 12300K ENGLISH B/G 5
AFRICA -10000 40000 12300K ENGLISH B/G 5
MID-EAST 30000 20000 18000K ARABIC B/G 6
RUSSIA 45000 20000 7500K RUSSIAN D/K 2
AUSTRALIA -50000 20000 12300K ENGLISH B/G 5
*NOTE FOR OSD TYPE:
2: ENGLISH/RUSSIA
5: ENGLISH/CHINESE/FRENCH/ARABIC/MALAY
6: ENGLISH/CHINESE/FRENCH/ARABIC/MALAY/RUSSIAN

21K-FD5RU
3 – 7
**AFTER INITIALIZED THE EEPROM (REFER TO FACTORY PRESETTING), READ DATA FROM
EEPROM ADDRESS 00H ~ 03H,AND COMPARE TO THE LIST BELOW, IF DIFFERENT,
INITIALIZE THE EEPROM.
ADDRESS DATA ADDRESS DATA
00H: 7BH 02H: 78H
01H: 75H 03H: 74H
*** There are five stages of service mode data. First stage data from V00~V31 (Adjustment Mode).
To go into second stage of service mode data, press MENU key.Second stage data from F01~F298 (Setting Mode).
To go into third stage of service mode data, press MENU key. Third stage data is Pixel mode setting.
To go into fourth stage of service mode data, press MENU key.Fourth stage data is Check Mode.
To go into fifth stage of service mode data, press MENU key.Fifth stage data from O01~O29 (Option Mode).
ADJUSTMENT MODE (FIRST STAGE)
EEPROM ITEMS OSD DATA LENGTH INITIAL DATA FIX/ADJ/AUTO REMARK
R-DRIVE V00 0...127 31 FIX PLS REFER TO
B-DRIVE V00 0...127 31 FIX ADJ ITEM FOR
R-CUT V00 0...511 95 FIX SCREEN AND
G-CUT V00 0...511 95 FIX WHITE BALANCE
B-CUT V00 0...511 95 FIX
RF-AGC V01 0...127 50 ADJ
VIF-VCO V02 0...127 63 ADJ
H-VCO V03 0...15 7 ADJ
SUB-CONTRAST V04 0...127 65 ADJ
SUB-COLOR V05 0...127 63 ADJ
SUB-BRIGHT V06 0..255 75 ADJ
SUB-TINT V07 0...127 63 ADJ
SUB-SHARPNESS V08 0...63 44 FIX
SUB-COLOR -YUV V09 0...127 55 *FIX BUS SET UP
SUB-TINT-YUV V10 0...127 63 *FIX BUS SET UP
V-SIZE 50 Hz V11 0...63 38 ADJ
V-SHIFT 50 Hz V12 0...15 7 ADJ
H-SHIFT 50 Hz V13 0...127 63 ADJ
SECAM-BR V14 0...255 127 ADJ
SECAM-BB V15 0...255 127 ADJ
SUB-VOL V16 0...60 60 FIX
V-SIZE 60 Hz V17 -31...0...+31 + 3 FIX IF NECESSARY, ADJ
V-SHIFT 60 Hz V18 -7...0...+7 - 3 FIX IF NECESSARY, ADJ
H-SHIFT 60 Hz V19 -15...0...+15 - 4 *FIX BUS SET UP
S-TRAP (BG) V20 0...31 15 ADJ
S-TRAP (I) V21 0...31 15 ADJ
S-TRAP (DK) V22 0...31 15 ADJ
S-TRAP (M) V23 0...31 15 ADJ
S-TRAP (5.74) V24 0...31 15 ADJ
CUTOFF/BKGD YUV V25 FIX
R-DRI YUV V25 0...127 31 FIX
B-DRI YUV V25 0...127 31 FIX
R-CUT YUV V25 0...511 95 FIX
G-CUT YUV V25 0...511 95 FIX
B-CUT YUV V25 0...511 95 FIX
SUB-CON YUV V26 0...127 65 FIX
SUB-BRGHT YUV V27 0...255 75 FIX
VS-CORRECT V28 0...63 31 FIX
VC-CORRECT OFFSET V29 -13...+13 + 2 FIX
V LINEARITY V30 0...63 31 *FIX BUS SET UP
V LINEARITY OFFSET V31 -13...+13 + 2 FIX

21K-FD5RU
3 – 8
SETTING MODE (SECOND STAGE)
EEPROM ITEMS FUNCTION OSD IC DATA LENGTH INITIAL
DATA
FIX/ADJ/
AUTO
REMARK
SIF-PAL F01 iDREAMA 0/1 0 FIX
SBPF WIDE F02 iDREAMA 0..3 0 FIX
STRAP OFF F03 iDREAMA 0/1 0 FIX
OM-DET F04 iDREAMA 0/1 0 FIX
SIF M GAIN F05 iDREAMA 0/1 0 FIX
TV Audio ATT [S-OUT-LVL] F06 iDREAMA 0..127 95 FIX
VIF-G F07 iDREAMA 0..7 4 FIX
AMF ON F08 iDREAMA 0/1 0 FIX
AMF VTH F09 iDREAMA 0/1 0 FIX
2DYCS BPF F10 iDREAMA 0..3 0 FIX
YDL Y SIGNAL DELAY F11 iDREAMA 0..15 7 FIX
YDL-P Y SIGNAL DELAY PAL F12 iDREAMA 0..15 3 FIX
YDL-S Y SIGNAL DELAY
SECAM F13 iDREAMA 0..15 7 FIX
YDL-N4 Y SIGNAL DELAY N443 F14 iDREAMA 0..15 6 FIX
YDL-N3 Y SIGNAL DELAY N358 F15 iDREAMA 0..15 4 *FIX BUS SET UP
YDL-AV Y SIGNAL DELAY AV F16 iDREAMA 0..15 7 FIX
YDL-AV-P Y SIGNAL DELAY PAL
(AV) F17 iDREAMA 0..15 3 FIX
YDL-AV-S Y SIGNAL DELAY
SECAM (AV) F18 iDREAMA 0..15 5 FIX
YDL-AV-N4 Y SIGNAL DELAY N443
(AV) F19 iDREAMA 0..15 5 FIX
YDL-AV-N3 Y SIGNAL DELAY N358
(AV) F20 iDREAMA 0..15 5 *FIX BUS SET UP
YDL-YUV Y SIGNAL DELAY YUV F21 iDREAMA 0..15 7 FIX
AP FREQ F22 iDREAMA 0..3 0 FIX
CORH LH F23 iDREAMA 0..15 8 FIX
SHP OV-P F24 iDREAMA -31..0..+31 0 FIX
SHP OV-S F25 iDREAMA -31..0..+31 -5 FIX
SHP OV-N4 F26 iDREAMA -31..0..+31 0 FIX
SHP OV-N3 F27 iDREAMA -31..0..+31 0 FIX
SHP OV-AV F28 iDREAMA -31..0..+31 +5 FIX
SHP OV-YUV F29 iDREAMA -31..0..+31 +5 FIX
SHP PRE-P F30 iDREAMA -31..0..+31 -10 FIX
SHP PRE-S F31 iDREAMA -31..0..+31 -15 FIX
SHP PRE-N4 F32 iDREAMA -31..0..+31 -10 FIX
SHP PRE-N3 F33 iDREAMA -31..0..+31 -10 FIX
SHP PRE-AV F34 iDREAMA -31..0..+31 +5 FIX
SHP PRE-YUV F35 iDREAMA -31..0..+31 -5 FIX
SHP ANT-ONII OFFSET F36 iDREAMA -31..0..+31 0 *FIX BUS SET UP
BS SW [BS] F37 iDREAMA 0/1 1 FIX
BS ST PNT F38 iDREAMA 0..3 3 FIX
BS D F39 iDREAMA 0..7 0 FIX
BS ATK T F40 iDREAMA 0..15 7 FIX
BS RCV T F41 iDREAMA 0..15 7 FIX
ACC AMP ON F42 iDREAMA 0/1 0 FIX
Take-Off-TV F43 iDREAMA 0 (BPF)/ 1(TOF) 1 FIX
Take-Off-AV F44 iDREAMA 0 (BPF)/ 1(TOF) 0 FIX
Take-Off-YUV F45 iDREAMA 0 (BPF)/ 1(TOF) 0 FIX
BGP SEL F46 iDREAMA 0/1 0 FIX
P/N BGP SHIFT F47 iDREAMA 0..3 0 FIX
SCM BGP SHIFT F48 iDREAMA 0..3 0 *FIX BUS SET UP
BGP WIDTH F49 iDREAMA 0..31 22 FIX
BGP FRT POS F50 iDREAMA 0..31 14 FIX
AUTO-SCM-KIL-TV F51 iDREAMA 0..3 1 FIX
AUTO-SCM-KIL-AV-YUV F52 iDREAMA 0..3 1 FIX
Forced-SCM-KIL-TV F53 iDREAMA 0..3 2 FIX
Forced-SCM-KIL-AV-YUV F54 iDREAMA 0..3 2 FIX
SCM FO COL F55 iDREAMA 0/1 0 FIX
PAL ID F56 iDREAMA 0..127 15 FIX
NTSC ID F57 iDREAMA 0..127 15 *FIX BUS SET UP

21K-FD5RU
3 – 9
ID ATK TIME F58 iDREAMA 0..3 0 FIX
ID RCV TIME F59 iDREAMA 0..3 3 FIX
KILLER LEVEL F60 iDREAMA 0..127 28 *FIX BUS SET UP
KILLER ATK TIME F61 iDREAMA 0..3 2 *FIX BUS SET UP
KILLER RCV TIME F62 iDREAMA 0..3 1 FIX
443 50 NT F63 iDREAMA 0/1 0 FIX
COL-AV F64 iDREAMA -31..0..+31 +20 *FIX BUS SET UP
COL-P F65 iDREAMA -31..0..+31 0 FIX
COL-S F66 iDREAMA -31..0..+31 - 25 FIX
COL-N4 F67 iDREAMA -31..0..+31 -7 *FIX BUS SET UP
COL-N3 F68 iDREAMA -31..0..+31 -7 *FIX BUS SET UP
COL-ADJ F69 iDREAMA -31..0..+31 + 15 FIX
TINT-AV F70 iDREAMA -63..0..+63 0 *FIX BUS SET UP
TINT-ADJ F71 iDREAMA -63..0..+63 + 12 *FIX BUS SET UP
TINT-YUV-ADJ F72 iDREAMA -63..0..+63 0 FIX
CTI F73 iDREAMA 0/1 1 FIX
R-Y PHASE OFFSET F74 iDREAMA 0..63 21 *FIX BUS SET UP
U OFFSET
[Black <FmSdata>[amp ]
White signal or YUV]
F75 iDREAMA 0..255 127 FIX
V OFFSET
[Black <FmSdata>[amp ]
White signal or YUV]
F76 iDREAMA 0..255 127 FIX
G-DRI F77 iDREAMA 0..127 31 *FIX BUS SET UP
G-Y GAIN F78 iDREAMA 0..3 3 *FIX BUS SET UP
GAMMA F79 iDREAMA 0..3 2 *FIX BUS SET UP
BLUE ST F80 iDREAMA 0..3 1 FIX
OSD BRT LIMIT F81 iDREAMA 0..3 0 FIX
OSD CONT LIMIT F82 iDREAMA 0..3 2 FIX
ABL TH F83 iDREAMA 0..7 0 FIX
ABL GAIN F84 iDREAMA 0..7 0 FIX
DC TRAN SEL F85 iDREAMA 0/1 0 FIX
DC TRAN GAIN F86 iDREAMA 0..15 0 FIX
DC TRAN TH F87 iDREAMA 0..127 0 FIX
AUTO SLICE LVL-TV F88 iDREAMA 0..15 3 FIX
AUTO SLICE LVL-AV F89 iDREAMA 0..15 3 FIX
AUTO SLICE LVL-YUV F90 iDREAMA 0..15 3 FIX
AS GAIN-TV F91 iDREAMA 0..3 0 FIX
AS GAIN-AV F92 iDREAMA 0..3 0 FIX
AS GAIN-YUV F93 iDREAMA 0..3 0 FIX
V SYNC DET-TV F94 iDREAMA 0..7 0 *FIX BUS SET UP
V SYNC DET-AV F95 iDREAMA 0..7 0 FIX
V SYNC DET-YUV F96 iDREAMA 0..7 0 FIX
S DET ON-TV F97 iDREAMA 0/1 1 FIX
S DET ON-AV F98 iDREAMA 0/1 1 FIX
S DET ON-YUV F99 iDREAMA 0/1 1 FIX
V STD DET-TV F100 iDREAMA 0/1 0 FIX
V STD DET-AV F101 iDREAMA 0/1 0 FIX
V STD DET-YUV F102 iDREAMA 0/1 0 FIX
C SYNC LPF F103 iDREAMA 0..3 0 FIX
V SYNC LPF1 F104 iDREAMA 0..3 0 FIX
V SYNC LPF2 F105 iDREAMA 0..3 3 FIX
AFC1 GAIN-TV F106 iDREAMA 0..7 4 *FIX BUS SET UP
AFC1 GAIN-AV F107 iDREAMA 0..7 4 FIX
AFC1 GAIN-YUV F108 iDREAMA 0..7 4 FIX
AFC2 GAIN UP-TV F109 iDREAMA 0..3 0 FIX
AFC2 GAIN UP-AV F110 iDREAMA 0..3 0 FIX
AFC2 GAIN UP-YUV F111 iDREAMA 0..3 0 FIX
V PULLIN WIDE F112 iDREAMA 0/1 0 FIX
H PULLIN UP F113 iDREAMA 0/1 0 FIX
DBL COIN F114 iDREAMA 0/1 0 FIX
V-FREE(NO SYNC) F115 iDREAMA 1 (off)/ 1(free-run) 1 FIX
V-FREE2(H-FREE) F116 iDREAMA 1 (off)/ 1(free-run) 1 FIX
SETTING MODE (SECOND STAGE)
EEPROM ITEMS FUNCTION OSD IC DATA LENGTH INITIAL
DATA
FIX/ADJ/
AUTO
REMARK

21K-FD5RU
3 – 10
RDRV-R F117 iDREAMA -63..0..+63 +8 *FIX BUS SET UP
BDRV-R F118 iDREAMA -63..0..+63 -10 *FIX BUS SET UP
RDRV-B F119 iDREAMA -63..0..+63 -3 *FIX BUS SET UP
BDRV-B F120 iDREAMA -63..0..+63 +13 *FIX BUS SET UP
R-DRI YUV OFFSET F121 iDREAMA -63..0..+63 0 FIX
VRAMP LPF ADJ F122 iDREAMA 0..7 0 FIX
B-DRI YUV OFFSET F123 iDREAMA -63..0..+63 0 FIX
R-CUT YUV OFFSET F124 iDREAMA -63..0..+63 0 FIX
G-CUT YUV OFFSET F125 iDREAMA -63..0..+63 + 17 *FIX BUS SET UP
B-CUT YUV OFFSET F126 iDREAMA -63..0..+63 + 5 *FIX BUS SET UP
CON YUV OFFSET F127 iDREAMA -63..0..+63 + 1 FIX
BRT YUV OFFSET F128 iDREAMA -63..0..+63 - 5 FIX
Contrast OFFSET F129 iDREAMA -63..0..+63 0 FIX
Bright OFFSET F130 iDREAMA -63..0..+63 0 *FIX BUS SET UP
AV2 Brigtness OFFSET F131 iDREAMA -15..0..+15 0 FIX
V-Demute-Delay F132 iDREAMA 0..255 0 FIX
S-Demute-Delay F133 iDREAMA 0..255 0 FIX
Pow-Storage F134 iDREAMA 0 (disable)/
1(enable) 1FIX
OSD-POS F135 iDREAMA 0Ö127 0 FIX
CP F136 iDREAMA 0/1 1 FIX
SMALL-SURR F137 iDREAMA 0/1 0 FIX
SUB-BASS
SUB BASS CONTROL
F138 iDREAMA
0(0dB), 1(-1dB),
2(-2dB), 3(-3dB),
4(0dB), 5(+1dB),
6(+2dB), 7(+3dB)
6 *FIX BUS SET UP
SUB-TREB
SUB TREBLE CONTROL
F139 iDREAMA
0(0dB), 1(-1dB),
2(-2dB), 3(-3dB),
4(0dB), 5(+1dB),
6(+2dB), 7(+3dB)
3 *FIX BUS SET UP
AGC-ADJ
AGC LEVEL ADJUST
F140 iDREAMA
0(AGC Off),
1(300mVrms),
2(400mVrms),
3(500Vrms),
4(600mVrms)
3 *FIX BUS SET UP
AGC-Sw-Off NICAM AGC SWITCH
OFF F141 iDREAMA 0(Disable, fix gain),
1(Enable AGC) 1FIX
AGC-Gain-Adjust F142 iDREAMA 0...31 16 FIX
FM-Level-Adjust F143 iDREAMA -15..0..+15 (please
refer to Appendix A) 0FIX
IGR-Level-Adjust F144 iDREAMA -15..0..+15 (please
refer to Appendix A) +1 FIX
NICAM-BG-Level-Adjust F145 iDREAMA -15..0..+15 (please
refer to Appendix A) -2 FIX
NICAM-I-Level-Adjust F146 iDREAMA -15..0..+15 (please
refer to Appendix A) +3 FIX
NICAM-DK-Level-Adjust F147 iDREAMA -15..0..+15 (please
refer to Appendix A) -1 FIX
NICAM-Lower-Error-Limit F148 iDREAMA 0..55 35 FIX
NICAM-Upper-Error-Limit F149 iDREAMA 0..255 70 FIX
IGR-Gain-Adjust F150 iDREAMA -6..0..+7 (please
refer to Appendix B) 0FIX
A2-ID-Response F151 iDREAMA 0 (normal)/ 1(fast) 1 FIX
FM-ID-Speed F152 iDREAMA 0..3 1 FIX
NICAM-Auto-Mute F153 iDREAMA 0/1 0 FIX
MER
S-BOOSTER FREQ.
CHARACTERISTIC CON-
TROL
F154 iDREAMA 0..255 70 FIX
MEL1 S-BOOSTER LEVEL1 F155 iDREAMA 0..255 150 FIX
MEL2 S-BOOSTER LEVEL2 F156 iDREAMA 0..255 156 FIX
MEL3 S-BOOSTER LEVEL3 F157 iDREAMA 0..255 163 FIX
MEL4 S-BOOSTER LEVEL4 F158 iDREAMA 0..255 165 FIX
MEL5 S-BOOSTER LEVEL5 F159 iDREAMA 0..255 170 FIX
MEL6 S-BOOSTER LEVEL6 F160 iDREAMA 0..255 180 FIX
SETTING MODE (SECOND STAGE)
EEPROM ITEMS FUNCTION OSD IC DATA LENGTH INITIAL
DATA
FIX/ADJ/
AUTO
REMARK

21K-FD5RU
3 – 11
S-St-Point S-BOOSTER START
POINT F161 iDREAMA 0..60 21 FIX
S-Sp-Point S-BOOSTER STOP
POINT F162 iDREAMA 0..60 60 FIX
S-Step S-BOOSTER STEP F163 iDREAMA 0..60 7 FIX
S-B-BASS
S-BOOSTER BASS LIM-
ITER (WHEN S-
BOOSTER ON)
F164 iDREAMA -30..0..+30 +15 FIX
S-B-TREB
S-BOOSTER TREBLE
LIMITER (WHEN S-
BOOSTER ON)
F165 iDREAMA -30..0..+30 +15 FIX
S-BASS
S-BOOSTER BASS LIM-
ITER (WHEN S-
BOOSTER OFF)
F166 iDREAMA -30..0..+30 +30 FIX
S-TREB
S-BOOSTER TREBLE
LIMITER (WHEN S-
BOOSTER OFF)
F167 iDREAMA -30..0..+30 +30 FIX
COREL YNR1 F168 iDREAMA 0..15 5 *FIX BUS SET UP
COREL YNR2 F169 iDREAMA 0..15 12 FIX
COREL YNR3 F170 iDREAMA 0..15 15 FIX
H COEF1 TV F171 iDREAMA 0..7 3 FIX
H COEF2 TV F172 iDREAMA 0..7 2 FIX
H COEF3 TV F173 iDREAMA 0..7 1 FIX
SF COEF1 TV F174 iDREAMA 0..7 6 *FIX BUS SET UP
SF COEF2 TV F175 iDREAMA 0..7 4 *FIX BUS SET UP
SF COEF3 TV F176 iDREAMA 0..7 3 *FIX BUS SET UP
SG COEF1 TV F177 iDREAMA 0..7 1 FIX
SG COEF2 TV F178 iDREAMA 0..7 3 FIX
SG COEF3 TV F179 iDREAMA 0..7 4 FIX
VC COEF1 TV F180 iDREAMA 0..7 2 *FIX BUS SET UP
VC COEF2 TV F181 iDREAMA 0..7 2 *FIX BUS SET UP
VC COEF3 TV F182 iDREAMA 0..7 2 *FIX BUS SET UP
VD COEF1 TV F183 iDREAMA 0..7 5 *FIX BUS SET UP
VD COEF2 TV F184 iDREAMA 0..7 5 *FIX BUS SET UP
VD COEF3 TV F185 iDREAMA 0..7 5 *FIX BUS SET UP
H COEF1 AV F186 iDREAMA 0..7 6 FIX
H COEF2 AV F187 iDREAMA 0..7 4 FIX
H COEF3 AV F188 iDREAMA 0..7 2 FIX
SF COEF1 AV F189 iDREAMA 0..7 6 FIX
SF COEF2 AV F190 iDREAMA 0..7 4 FIX
SF COEF3 AV F191 iDREAMA 0..7 3 FIX
SG COEF1 AV F192 iDREAMA 0..7 1 FIX
SG COEF2 AV F193 iDREAMA 0..7 3 FIX
SG COEF3 AV F194 iDREAMA 0..7 4 FIX
VC COEF1 AV F195 iDREAMA 0..7 3 FIX
VC COEF2 AV F196 iDREAMA 0..7 3 FIX
VC COEF3 AV F197 iDREAMA 0..7 3 FIX
VD COEF1 AV F198 iDREAMA 0..7 4 FIX
VD COEF2 AV F199 iDREAMA 0..7 4 FIX
VD COEF3 AV F200 iDREAMA 0..7 4 FIX
H COEF1 YUV F201 iDREAMA 0..7 6 FIX
H COEF2 YUV F202 iDREAMA 0..7 4 FIX
H COEF3 YUV F203 iDREAMA 0..7 2 FIX
SF COEF1 YUV F204 iDREAMA 0..7 6 *FIX BUS SET UP
SF COEF2 YUV F205 iDREAMA 0..7 4 *FIX BUS SET UP
SF COEF3 YUV F206 iDREAMA 0..7 3 *FIX BUS SET UP
SG COEF1 YUV F207 iDREAMA 0..7 1 FIX
SG COEF2 YUV F208 iDREAMA 0..7 3 FIX
SG COEF3 YUV F209 iDREAMA 0..7 4 FIX
VC COEF1 YUV F210 iDREAMA 0..7 3 *FIX BUS SET UP
VC COEF2 YUV F211 iDREAMA 0..7 4 *FIX BUS SET UP
VC COEF3 YUV F212 iDREAMA 0..7 3 *FIX BUS SET UP
VD COEF1 YUV F213 iDREAMA 0..7 4 FIX
SETTING MODE (SECOND STAGE)
EEPROM ITEMS FUNCTION OSD IC DATA LENGTH INITIAL
DATA
FIX/ADJ/
AUTO
REMARK

21K-FD5RU
3 – 12
VD COEF2 YUV F214 iDREAMA 0..7 3 *FIX BUS SET UP
VD COEF3 YUV F215 iDREAMA 0..7 4 FIX
NOISE BPF SEL F216 iDREAMA 0..3 1 FIX
NOISE DET SENSE F217 iDREAMA 0..3 0 FIX
NOISE DET LINE F218 iDREAMA 0..3 0 FIX
SIG BPF SEL F219 iDREAMA 0..3 0 FIX
SIG DET SENSE F220 iDREAMA 0..3 0 FIX
CONT SOFT F221 iDREAMA 0..60 30 *FIX BUS SET UP
CONT STD F222 iDREAMA 0..60 50 FIX
CONT DYM F223 iDREAMA 0..60 60 FIX
BRIGHT SOFT F224 iDREAMA -30..0..+30 0 FIX
BRIGHT STD F225 iDREAMA -30..0..+30 0 FIX
BRIGHT DYM F226 iDREAMA -30..0..+30 0 FIX
COL SOFT F227 iDREAMA -30..0..+30 0 FIX
COL STD F228 iDREAMA -30..0..+30 0 FIX
COL DYM F229 iDREAMA -30..0..+30 +10 *FIX BUS SET UP
SHARP SOFT F230 iDREAMA -30..0..+30 -10 FIX
SHARP STD F231 iDREAMA -30..0..+30 0 FIX
SHARP DYM F232 iDREAMA -30..0..+30 +5 FIX
SURR SOFT F233 iDREAMA 0(OFF) / 1(ONI) 0FIX
/ 2(ONII)
SURR STD F234 iDREAMA 0(OFF) / 1(ONI) 0FIX
/ 2(ONII)
SURR DYM F235 iDREAMA 0(OFF) / 1(ONI) 0FIX
/ 2(ONII)
TREBLE SOFT F236 iDREAMA -30..0..+30 -10 FIX
TREBLE STD F237 iDREAMA -30..0..+30 0 FIX
TREBLE DYM F238 iDREAMA -30..0..+30 +5 FIX
BASS SOFT F239 iDREAMA -30..0..+30 -5 FIX
BASS STD F240 iDREAMA -30..0..+30 0 FIX
BASS DYM F241 iDREAMA -30..0..+30 +10 *FIX BUS SET UP
S-BOOST SOFT F242 iDREAMA 0(OFF) / 1(ON) 0 FIX
S-BOOST STD F243 iDREAMA 0(OFF) / 1(ON) 1 FIX
S-BOOST DYM F244 iDREAMA 0(OFF) / 1(ON) 1 FIX
AC-Fail-WO-Bright F245 iDREAMA 0..255 255 FIX
WO-Bright-after-WO-TIME F246 iDREAMA 0..255 255 FIX
WO-Contrast-after-WO-TIME F247 iDREAMA 0..127 127 FIX
WO-Bright-before-WO-TIME F248 iDREAMA 0..255 255 FIX
WO-Contrast-before-WO-TIME F249 iDREAMA 0..127 127 FIX
WO-TIME F250 iDREAMA 0..31 0 FIX
BASS OFFSET F251 iDREAMA -30..0..+30 0 FIX
TREBLE OFFSET F252 iDREAMA -30..0..+30 0 FIX
PM500 F253 iDREAMA 0 (250) / 1 (500) 0 FIX
OSDCLK_NCEN F254 iDREAMA 0 (OFF) / 1 (ON) 0 FIX
PXG_HDDLY F255 iDREAMA 0..15 0 *FIX BUS SET UP
FPB_FIX F256 iDREAMA 0 (OFF) / 1 (ON) 0 FIX
FH_JUDGE F257 iDREAMA 0..3 0 FIX
RC_DLY_SEL F258 iDREAMA 0..3 0 FIX
RC_RESET_SEL F259 iDREAMA 0..3 0 FIX
RC_REST0 F260 iDREAMA 0/1 0 FIX
LBVLATCH F261 iDREAMA 0/1 1 FIX
S BPF WIDE (574 MHZ) F262 iDREAMA 0..3 0 FIX
U OFFSET-PAL F263 iDREAMA 0..255 127 *FIX BUS SET UP
V OFFSET-PAL F264 iDREAMA 0..255 127 *FIX BUS SET UP
U OFFSET-N358 F265 iDREAMA 0..255 127 *FIX BUS SET UP
V OFFSET-N358 F266 iDREAMA 0..255 127 *FIX BUS SET UP
U OFFSET-N443 F267 iDREAMA 0..255 127 *FIX BUS SET UP
V OFFSET-N443 F268 iDREAMA 0..255 127 FIX
U OFFSET-SECAM F269 iDREAMA 0..255 127 *FIX BUS SET UP
V OFFSET-SECAM F270 iDREAMA 0..255 127 *FIX BUS SET UP
YCDETVTH F271 iDREAMA 0/1 1 FIX
AS SPEED UP F272 iDREAMA 0/1 1 FIX
SECAM FSC FREE F273 iDREAMA 0/1 1 FIX
SETTING MODE (SECOND STAGE)
EEPROM ITEMS FUNCTION OSD IC DATA LENGTH INITIAL
DATA
FIX/ADJ/
AUTO
REMARK

21K-FD5RU
3 – 13
AFC1 GAIN-NOSYNC F274 iDREAMA 00..07 0 FIX
RF-AGC WAIT TIME F275 iDREAMA 00..127 0 FIX
PAL/SECAM TINT F276 iDREAMA 00..127 63 *FIX BUS SET UP
TELETEXT LEVEL F277 iDREAMA 0..255 8 *FIX BUS SET UP
CLK LINE AUTO ADJ F278 iDREAMA 0..255 1 FIX
CLK LINE KILLER LEVEL F279 iDREAMA 0..255 0 FIX
CSYNC SLICE LEVEL F280 iDREAMA 0..255 112 FIX
AFC COMPRESSION LIMIT F281 iDREAMA 0..255 19 FIX
F SPECIAL ADJ F282 iDREAMA 0..255 164 FIX
AD OFFSET (EPG) F283 iDREAMA 0..255 212 FIX
AD GAIN (EPG) F284 iDREAMA 0..255 193 FIX
CLK GATE, LOW POWER
RESET, CLK LINE LIMIT, VPS
COMPARE MASK, WSS COM-
PARE MASK
F285 iDREAMA 0..127 59 FIX
REG. SETTING VALUE F286 iDREAMA 0..255 132 FIX
REG. SETTING VALUE F287 iDREAMA 0..255 132 FIX
FRAMING GATE START POS F288 iDREAMA 0..255 116 FIX
FRAMING GATE END POS F289 iDREAMA 0..255 170 FIX
CLK GATE START POS F290 iDREAMA 0..255 108 FIX
CLK GATE END POS F291 iDREAMA 0..255 128 FIX
AD OFFSET (TELETEXT) F292 iDREAMA 0..255 207 FIX
AD GAIN (TELETEXT) F293 iDREAMA 0..255 140 FIX
CCD (N) DATA REG. 1 F294 iDREAMA 0..255 148 FIX
VPS DATA REG. 1 F295 iDREAMA 0..255 3 FIX
OSD_HS F296 iDREAMA 0..1 0 *FIX BUS SET UP
TEXT_MD F297 iDREAMA 0..1 0 FIX
V-BLK TOP SHIFT F298 iDREAMA 0..15 3 FIX
OPTION MODE (FIFTH STAGE)
EEPROM ITEMS OSD DATA LENGTH INITIAL DATA REMARK
HTL O01 0/1 0 OPTION SET UP
HTL-POS O02 0...99,-- -- OPTION SET UP
HTL-VOL O03 0...60,-- -- OPTION SET UP
SECAM O04 0/1 1 OPTION SET UP
N443(RF) O05 0/1 1 OPTION SET UP
N358(RF) O06 0/1 1 OPTION SET UP
Force-Col O07 0/1 0 OPTION SET UP
S-SYS O08 1...15 15 OPTION SET UP
AV O09 0/1 1 OPTION SET UP
AV2 O10 0/1 1 OPTION SET UP
YUV O11 0/1 1 OPTION SET UP
S-CTRL O12 0/1 1 OPTION SET UP
NICAM O13 0/1 0 OPTION SET UP
A2 O14 0/1 0 OPTION SET UP
TEXT O15 0/1 0 OPTION SET UP
BIL O16 0/1 0 OPTION SET UP
LANG O17 1...65 63 OPTION SET UP
SERCH-SP O18 1...5 3 OPTION SET UP
LED-CONT O19 0/1 0 OPTION SET UP
S-BOOSTER O20 0/1 0 OPTION SET UP
SHARP-LOGO O21 0/1 0 OPTION SET UP
YUV BKGD ADJ O22 0/1 0 OPTION SET UP
WHITE BACK O23 0/1 0 OPTION SET UP
BOOSTER O24 0/1 1 OPTION SET UP
MESSAGE O25 0/1 0 OPTION SET UP
LNA TUNER O26 0...2 0 OPTION SET UP
GAME O27 0/1 0 OPTION SET UP
CHILD LOCK O28 0/1 1 OPTION SET UP
Idreama IC O29 0/1 0 OPTION SET UP
SETTING MODE (SECOND STAGE)
EEPROM ITEMS FUNCTION OSD IC DATA LENGTH INITIAL
DATA
FIX/ADJ/
AUTO
REMARK

21K-FD5RU
3 – 14
Setting below only applicable to Thai Model
LANG O17 1...65 65 OPTION SET UP
Remark for O08 (S-SYS)
When O08=1 (B/G only), SOUND item in CH-SETTING OSD MENU will not be appeared, and
there is no showing of sound system B/G in AUTO PRESET and MANUAL PRESET OSD Menu
*** HOTEL MODE
OPERATION OF HOTEL MODE:
WHEN CHANGE SERVICE DATA O01 TO 1, HOTEL MODE IS ON
WHEN HOTEL MODE IS ON,
1. Max volume data is determined by option setting HTL-VOL (O03)
2. Channel position after POWER ON is determined by option setting HOTEL-POS (O02) (if option setting
HOTEL-POS is not set, processing is according to last position data).
3. User data updates of EEPROM regarding the video and audio control is not allowed.
4. Preset mode is disable.
5. CH SETTING menu is not available.

21K-FD5RU
3 – 15
PXG-2 Demo Mode
㩷㩷㩷㩷㩷㩷㩷㩷㩷㩷㩷㩷㩷㩷㩷
PXG-2 DEMO MODE
Generate imaginary data from 3 line real
input signal data.
Double digital sampling increase the vertical
pixel resolution.
PXG-2 Technolo
gy
Input signal
pixels/resolution
Output signal
pixels/resolution
With PXG-2 technology, it helps to improve
picture resolution thus increase picture
sharpness and achieve a truly lifelike TV image.
PXG-2 Output Effect
㪧㪯㪞㩷㪦㪝㪝
㪧㪯㪞㩷㪦㪥
Pixel Generator (PXG-2)
SHARP 21K-FD series TV that adopt high features is a step up model that first implement Pixel Generator (PXG-2) technology. SHARP has made
a step ahead by producing high resolution picture in 21K-FD series and this make 21K-FD series model stands out among SHARP and other
competitors 21" flat TV. With this attractive PXG-2 feature, it is believe that it will helps to increase SHARP 21" flat TV market share .
PXG-2 DEMO mode is integrated into 21K-FD series to let customer to understand PXG-2 more easily and the differences within PXG OFF and ON
will give customer more clear image about PXG-2. PXG-2 DEMO mode will also ease the sales person in explaining PXG-2 as the selling point to
the customer.
Conce
pt
1)To enter PXG DEMO mode, press /
(on TV set) at the same time for more than 3
seconds during TV broadcast or AV input program.
2)Once enter to PXG DEMO mode, the AUTO DEMO
mode will run automatically in 4 type of display
screen (each at 5 seconds interval time).
3)At any DEMO mode,
Press FULL SCREEN DEMO
HALF SCREEN DEMO
AUTO DEMO
4)From any mode, press (on TV set) or
(on remote control) to change to the
respectively PAUSE mode. To release it, press
or again.
5)During PAUSE mode, press or
to change to other display screen.
6)During any mode or PAUSE mode, press
/ (on TV set) at the same time for
more than 3 seconds to cancel the PXG DEMO
mode.
Procedu
r
a) AUTO DEMO
PXG OFF
PXG ON
PXG ON
PXG ON
PXG OFF
PXG OFF
5s 5s
5s
5s
PXG OFF PXG ON
5s
b) FULL SCREEN DEMO
PXG ON
PXG ONPXG OFF
PXG OFF
5s
c) HALF SCREEN DEMO

21K-FD5RU
3 – 16
4. ADJ ITEM: BUS SET UP (1ST & 2ND STAGE SERVICE DATA)
SERVICE ITEMS 21K-FD5RU
V09 SUB-COLOR -YUV 70
V10 SUB-TINT-YUV 55
V19 H-SHIFT 60 Hz -5
V30 V LINEARITY 33
F15 YDL-N3 5
F20 YDL-AV-N3 9
F36 SHP ANT-ONII OFFSET -15
F48 SCM BGP SHIFT 1
F57 NTSC ID 33
F60 KILLER LEVEL 20
F61 KILLER ATK TIME 1
F64 COL-AV +10
F67 COL-N4 +3
F68 COL-N3 +3
F70 TINT-AV -3
F71 TINT-ADJ +14
F74 R-Y PHASE OFFSET 21
F77 G-DRI 63
F78 G-Y GAIN 3
F79 GAMMA 3
F94 V SYNC DET-TV 3
F106 AFC1 GAIN-TV 0
F117 RDRV-R +8
F118 BDRV-R -10
F119 RDRV-B -6
F120 BDRV-B +30
F125 G-CUT YUV OFFSET -3
F126 B-CUT YUV OFFSET 0
F130 Bright OFFSET 0
F138 SUB-BASS 0
F139 SUB-TREB 3
F140 AGC LEVEL ADJUST 4
F168 COREL YNR1 5
F174 SF COEF1 TV 7
F175 SF COEF2 TV 5
F176 SF COEF3 TV 4
F180 VC COEF1 TV 1
F181 VC COEF2 TV 1
F182 VC COEF3 TV 1
F183 VD COEF1 TV 7
F184 VD COEF2 TV 7
F185 VD COEF3 TV 7
F204 SF COEF1 YUV 7
F205 SF COEF2 YUV 5
F206 SF COEF3 YUV 4
F210 VC COEF1 YUV 2
F211 VC COEF2 YUV 2
F212 VC COEF3 YUV 2
F214 VD COEF2 YUV 4
F221 CONT SOFT 40
F229 COL DYM +5
F241 BASS DYM +5
F255 PXG_HDDLY +10
F263 U OFFSET-PAL 130
F264 V OFFSET-PAL 130
F265 U OFFSET-N358 133
F266 V OFFSET-N358 131
F267 U OFFSET-N443 131
F269 U OFFSET-SECAM 129
F270 V OFFSET-SECAM 129
F276 PAL/SECAM TINT 73
F277 TELETEXT LEVEL 11
F296 OSD_HS 1

21K-FD5RU
3 – 17
5. ADJ ITEM: OPTION SET UP (5TH STAGE SERVICE DATA)
SERVICE ITEMS 21K-FD5RU
O01 HTL 0
O02 HTL-POS --
O03 HTL-VOL --
O04 SECAM 1
O05 N443(RF) 1
O06 N358(RF) 1
O07 Force-Col 0
O08 S-SYS 15
O09 AV 1
O10 AV2 1
O11 YUV 1
O12 S-CTRL 1
O13 NICAM 1
O14 A2 1
O15 TEXT 1
O16 BIL 0
O17 LANG 9
O18 SERCH-SP 3
O19 LED-CONT 0
O20 S-BOOSTER 0
O21 SHARP-LOGO 0
O22 YUV BKGD ADJ 0
O23 WHITE BACK 0
O24 BOOSTER 1
O25 MESSAGE 0
O26 LNA TUNER 0
O27 GAME 0
O28 CHILD LOCK 1
O29 Idreama IC 0
