Sharper Image SOUND SOOTHER SI735 User manual

THE
SHARPER
®
SOUND SOOTHER®
CD/RADIO/ALARM CLOCK
SI735 Instructions
SI735 IM V6 5/2/74 6:52 PM Page 1

Dear Customer,
Thank you for your purchase of a Sharper Image Design
TM
product. You have received a
quality product, acked y a one-year warranty. Your satisfaction as a Sharper Image
customer means everything to us. We look forward to serving you now and in the future.
Over 500 other afforda le, fun, and useful products are availa le through The Sharper
®
Catalog and retail stores. To receive a copy of our catalog or for the address of
the store nearest you, please call our toll-free num er 1-800-344-4444.
Enjoy your purchase!
Richard Thalheimer
Founder and Chairman
Shop our complete Internet catalog.
Online ordering is protected y Secure Sockets Layer technology.
SI735 IM V6 5/2/74 6:52 PM Page 2

DISPLAY AND CONTROLS
AUDIO CONTROLS
BATTERY INFORMATION
SETTING THE CLOCK
SETTING THE CALENDAR
SETTING THE ALARM
RADIO PRESETS
SOUND SOOTHER®
CD PLAYER FEATURES
INTERNATIONAL &SLEEP
DESCRIPTION AND TABLE OF CONTENTS
Page 1
Page 2
Page 3
Page 5
Page 6
Page 8
Page 9
Page 10
Page 12
Page 13
The portable CD Alarm Clock/Radio with Sound
Soother®offers the most popular audio features
in one compact unit. Perfect for travel, convenient
for bedside, and small enough to sit on a desktop.
Additional features include: a display for month
and date, temperature display, and a jack to use
with the included “bud” style headphones.
It includes a telescoping antenna for FM reception,
and an internal antenna for AM radio broadcasts.
NOTE: The quality of AM reception can be
adjusted by changing the position of the
unit itself. Re-position the telescoping
antenna to alter FM reception.
SI735 IM V6 5/2/74 6:52 PM Page 3

Turn selected
alarms on or off.
DISPLAY AND CONTROLS
1
Select alarm
sound options.
Set radio presets.
(Also can sample
alarm buzzer.)
Displays the active
audio choice.
Low battery
indicator.
Displays date
or radio preset.
Scroll through
setting modes.
Delay alarm.
Also activate the display
light (batteries only).
Advance setting or
radio preset.
Displays the
temperature.
Displays time
or radio tuning.
Indicates the active
alarm choice.
Backlight toggles
on and off when
the AC adapter
is used and the
LIGHT button is
pressed.
SI735 IM V6 5/2/74 6:52 PM Page 4

AUDIO CONTROLS 2
Turn and hold to fast scan radio tuning.
Turn and release to fine-tune radio.
Activate SLEEP mode for radio, CD or Sound Soother.
Turn audio POWER on and off.
Display for current CD track
and time information.
Skip CD back or forward.
Stop playing CD.
Play or pause CD.
Select CD program,
repeat or random
play mode.
Select SOUND
Soother®mode.
Select RADIO mode.
Select AM or
FM radio band.
SIDE VIEW
Select Sound Soother®sounds.
Control bass response.
VOLUME control. Audio/headphone jack.
DC power jack.
SI735 IM V6 5/2/74 6:52 PM Page 5

BATTERY INFORMATION
3
An optional AC adapter may be plugged into the jack located on the side of the unit. This adapter
can be used to power the alarm, CD player, Sound Soother, and radio only. The SNOOZE/LIGHT
button toggles the display backlight on and off when powering the unit with the adapter.
One CR2032 button battery is required for the clock and display to function properly. The clock
battery should only be removed when being replaced with a new battery.
Icon indicates low/weak battery.
SI735 IM V6 5/2/74 6:52 PM Page 6

BATTERY INFORMATION
CLOCK/BACKUP BATTERY AND RESET BUTTON
This unit is shipped with one CR2032 battery in place. Activate the battery for the first time, by
removing the shipping tab, pulling it away from and out of the battery compartment. This compart-
ment also houses a reset button. Use a small object, such as an unbent paper clip, to press the
reset button if the unit or display malfunctions.
4
CD/RADIO/ALARM AND SOUND SOOTHER BATTERIES
Requires four AA alkaline batteries, or optional AC adapter. Replace old batteries with new
ones when the WEAK BATTERY icon flashes on the LCD screen. Controls will not function without
these batteries or the AC adapter in place. The AA batteries should be removed when the unit
is to be powered mainly by the AC adapter.
This product has
two battery compartments.
To access the battery compartments,
slide the covers as indicated.
SI735 IM V6 5/2/74 6:52 PM Page 7

Press the MODE button
SETTING THE CLOCK
Press UP or Down
Press the MODE button
Press UP or Down
Until the hour setting flashes.
To change the hour setting.
Until the minute setting flashes.
To change the minute setting.
Press and hold buttons to quickly advance the settings.
If the setting is advanced past midnight, the time will be displayed in 24 hour (military) format.
Continue advancing to switch back to 12 hour (US standard) time display.
5
SI735 IM V6 5/2/74 6:52 PM Page 8

Press the MODE button
SETTING THE CALENDAR
Press UP or DOWN
Press the MODE button
Press UP or DOWN
Press the MODE button
Until the year display is flashes.
To change the year.
Until the month flashes.
To change the month.
Until the date flashes.
Press and hold buttons to quickly cycle through the display.
Press UP or DOWN
To change the date.
6
2002
2002
SI735 IM V6 5/2/74 6:52 PM Page 9

SETTING THE ALARM
If no button is pressed, new setting is saved and the display returns to normal operation.
Press UP or DOWN
Press the MODE button
Press the MODE button
Press UP or DOWN
Press ALARM SOUND
To change alarm time hour.
Until alarm hour flashes.
Until alarm minutes flashes.
To change alarm time minutes.
To select alarm sound.
7
Selecting RADIO alarm will default
the alarm to the last selected radio
station.
When this alarm icon is on the screen, it
tells you that the alarm will go off at the
time you selected.
SI735 IM V6 5/2/74 6:52 PM Page 10

ADDITIONAL ALARM FEATURES
SNOOZE
Press the SNOOZE button when the alarm sounds to delay the alarm for up to thirty minutes.
Each press adds 10 minutes to the delay time. (Press 1X for 10 minute snooze, 2X for 20 minutes
and 3X for the maximum 30 minutes snooze delay.) If the ALARM ON/OFF button is not pressed, the
snooze feature will repeat three times, and then the alarm will reset itself for the next day.
8
AUTO-SNOOZE (Buzzer Only)
If no buttons are pressed the alarm will continue for one minute, after which time the snooze feature
will be automatically activated. The alarm will sound again after nine minutes. This will repeat three
times before the alarm will turn off and reset itself for the next day.
AUTO-RESET
If the ALARM ON/OFF button is used to turn the alarm off, the alarm is automatically reset for the
next day. If no button is pressed within the first minute of the radio, or CD alarm activating, the
unit will power off automatically after 30 minutes, and the alarm will reset for the next day. To
completely de-activate the alarm, press the ALARM ON/OFF button a second time.
SI735 IM V6 5/2/74 6:52 PM Page 11

SETTING THE RADIO PRESETS
9
Pressing UP or DOWN when the radio is playing, will scan up and down instantly to preset stations.
Tune to desired station.
Press RADIO
Press MEM/DEMO
Press UP or DOWN
Press MEM/DEMO
(Use tuning knob.)
(Power must be on.)
Active preset number flashes.
To change active preset number.
To lock selection to memory.
Up to 10 preset stations can be
programmed for AM and FM.
MEM
1
SI735 IM V6 5/2/74 6:52 PM Page 12

Press SOOTHER
To select Sound Soother mode.
Use the soother switch
To select Sound Soother sound.
SOUND SOOTHER
®10
The Sound Soother provides a relaxing atmosphere of soothing background sounds of
nature. It can be used to effectively mask out surrounding noises, such as traffic, loud
neighbors and even snoring.
It has been generally found that the Sound Soother volume does not need to be very
loud to be effective. Most people find that even with the Sound Soother positioned at a
low volume, they will be able to ignore distracting noises, and improve their relaxation.
The Sound Soother®will turn off when the alarm sounds, but it cannot be used as an alarm.
SI735 IM V6 5/2/74 6:52 PM Page 13

CD PLAYER CONTROLS
WHEN CD IS NOT PLAYING:
Press to forward or reverse
track selection by 1 .
WHEN CD IS PLAYING:
Press and release to forward
or reverse track selection by 1.
Press and hold to scan forward
or backward within the track
that is playing.
Press to stop playing the CD
and to indicate completion
when programming .
WHEN CD IS NOT PLAYING:
Press to begin playing CD or
CD program.
WHEN CD IS PLAYING:
Press to toggle between pause
and play.
WHEN CD IS PLAYING:
Press to select either single track repeat,
or entire CD replay.
WHEN CD IS NOT PLAYING:
Press to toggle between random
and regular play order .
11
SI735 IM V6 5/2/74 6:52 PM Page 14

CD PLAYER ADVANCED FEATURES
The CD player can be accessed by pressing on the side and lifting it open. This cover
must be closed to operate the CD player.
REPEAT/AUTO-REPLAY:
Press MODE, while the unit is playing, to toggle through the repeat
feature. A “1” on the display indicates a single track replay. An
“ALL” on the display indicates continuous replay for the entire
CD. Pressing one more time cancels the repeat/replay program.
12
RANDOM PLAY:
Press MODE, while the unit is stopped, until the display indicates
“RND”. Press play to begin. The CD will now play in random order.
PROGRAMMED PLAYBACK:
Press MODE, while the unit is stopped, until the display indicates
“PROGRAM”. Select a track to play by using the FORWARD or REVERSE
buttons. Program the selected track by pressing MODE. Continue
until all desired tracks have been selected and programmed. Press
stop when selections are complete and to end programming.
SI735 IM V6 5/2/74 6:52 PM Page 15

Press the MODE button
Press UP or DOWN
Until the temperature flashes.
Selects Fahrenheit or Celsius.
Use the sleep timer to fall asleep to the Sound Soother,
radio or CD. The selected audio will automatically shut
off after the programmed time.
To operate the timer: Press the sleep button to activate
the timer for 15 minutes, each additional press will add
a fixed number of minutes to the timer. The timer can
not be set for more than 60 minutes.
INTERNATIONAL AND SLEEP TIMER FEATURES
13
Change the AM scanning rate from 10kHz (US) to 9kHz (European) by pressing MODE
until the main display flashes the current setting (either 9 or 10). Press UP or DOWN to
change the selection.
SI735 IM V6 5/2/74 6:52 PM Page 16

MODEL:SI735
WARNING:
Changes or modifications to this unit not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
NOTE:
This product complies with DHHS Rule 21 subchapter J at date of manufacture. This equip-
ment has been tested and found to comply with the limits for a Class B digital device, pur-
suant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation
If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio TV technician
for assistance.
SI735 IM V6 5/2/74 6:52 PM Page 18

WARRANTY
We warrant to the original user that this product shall be free from all defects in material or workmanship
for one year from the date of purchase. This warranty does not apply to any product which has been
subject to abuse, misuse, negligence or accident, nor does it apply to any batteries which may be
supplied with the product. Defects caused by tampering, unauthorized alterations or repairs are not
covered by this warranty. We may elect to replace the entire unit, at no extra cost to you, with the
same model or a similar model rather than repair it.
If a defect covered by this warranty should occur, return the product along with proof of purchase, a check
or money order for $5.00 to cover shipping and handling, and a brief explanation of the problem to:
TSI - Returns Department
2901-A West 60th Street
Little Rock, AR 72209
We have found through experience that if a product uses batteries, many of the problems thought
to be product defects are simply caused by weak batteries. To save any unnecessary inconve-
nience, we encourage you to try replacement batteries before you return the product. Please feel free
to call our customer service representatives at 1-800-344-5555 with any questions.
This warranty gives you specific legal rights, and you may have other legal rights that vary from state
to state.
Copyright 2002
Sharper Image Corporation
San Francisco
PRINTED IN HONG KONG
V6
SI735 IM V6 5/2/74 6:52 PM Page 20
