Sharper Image SL001 User manual

Sumo Robots
Two Robot Sumo Wrestlers
with Artificial Intelligence
SL001 Instructions
Read and save these instructions.

Table of Contents
Warnings ...................................................................................5
Important Battery Information....................................................6
Battery Installation .....................................................................7
Overview...................................................................................9
Playing the Game ......................................................................9
Remote Control Operation ......................................................10
Commands and Maneuvers .....................................................11
Keeping Score..........................................................................14
Charger Operation...................................................................15
The Dohyo ..............................................................................16
Game Modes...........................................................................17
Two Player Mode.....................................................................18
Artificial Intelligence vs. Artificial Intelligence (Demo. Mode)....19
Remote Control vs. Artificial Intelligence (One-Player Mode) ...20
Stunt Action Upgrade ..............................................................21
Barcode Reader.......................................................................22

Warnings
Troubleshooting .......................................................................25
Care and Maintenance ............................................................27
Specifications...........................................................................27
Statement of FCC Compliance .................................................28
FCC Label Compliance Statement............................................29
Table of Contents

•Do not expose units to water or moisture.
•Do not expose units to extreme temperatures from any source.
•Do not drop or subject the units to excessive force or shock.
Warnings
5

•Do not mix old and new batteries.
•Do not mix Alkaline, standard (Carbon Zinc) or rechargeable
(Nickel-Cadmium) batteries.
•Use only batteries of the same or equivalent type as
recommended.
•Due to small parts, an adult should install and replace batteries.
•Insert batteries, observing proper +/– polarities.
•Do not short-circuit the supply terminals.
•Do not recharge nonrechargeable batteries.
•Do not use rechargeable batteries.
•Do not dispose of batteries in fire. Batteries may explode or leak.
•Keep the packaging for future reference. It contains important
information.
•Always remove rechargeable batteries from remote controls and
charging station before charging.
Note: Robots’ rechargeable batteries are not replaceable.
Important Battery Information
6

Remote Control
1. Ensure the power switch is in the OFF position.
2. To open the battery compartment on the remote control,
remove the screw using a Phillips screwdriver (not included),
then lift off the cover.
3. Install 3 AAA batteries (purchase separately) into the battery
compartment, observing proper +/– polarities as indicated.
4. Replace the cover, then reinstall the screw using a Phillips
screwdriver (not included).
Battery Installation
7

Note: If remote control battery power is weak, the power LED
indicator flashes. Replace the batteries.
Charger
1. To open the battery compartment on the charger, remove the
screw using a Phillips screwdriver (not included), then lift off
the cover.
2. Install 3 AA batteries (purchase separately) into the battery
compartment, observing proper +/– polarities as indicated.
3. Replace the cover, then reinstall the screw using a Phillips
screwdriver (not included).
Battery Installation
8

Overview
Inspired by Sumo wrestling, the goal of the game is to push your
robot Sumo opponent out of the Dohyo ring. Players use the
infrared remote controls to execute various offensive or evasive
maneuvers against an opponent, or a robot’s artificial intelli-
gence. Advanced players may test their skill by creating exciting
new user-defined stunts for the robot Sumo wrestlers.
Playing the Game
One game consists of five matches; each match lasts approxi-
mately one minute. The winner is determined when:
•The opponent is pushed out of the Dohyo borderline.
•The opponent forfeits and leaves the Dohyo.
•The opponent is lifted up or knocked down in the Dohyo.
Notes:
•Before a match begins, ensure both robots are facing each other
in the shaded area of the Dohyo.
•To select a fighting posture, rotate the robots’ arms to the de-
sired pose.
9

Remote Control Operation
The remote controls drive two-player (two-player mode) and one
player vs. artificial intelligence (one-player mode).
Note: During A.I. (artificial intelligence) mode, all remote-control
functions are deactivated.
1. To use a remote control, after battery installation, the unit
must be calibrated.
2. To calibrate a remote control, move its joystick in a circular
motion around its outermost perimeter.
3. The remote controls have an operational range of approxi-
mately six feet. Do not block or cover the infrared sensor
located on the front of the remote units as malfunctions
may occur.
10
