Shelly Button User manual
Wiring guide
With
Max Voltage 260V AC
Max load 11A
Working temp -20 up to 40Co
Protection IP47
L N N L
Connect the wires, as shown on the picture above.
Step 1
Place the button extension lead, as shown on the pic-
ture above.
Step 2
Power
IN
Power
OUT
L N N L
Connect the power (input and output) cables, as
shown on the picture above.
Step 3
Power
IN
Power
OUT
Inside the case of Shelly Button there are guiding ar-
rows, which show how to organise the power cables.
After placing the cables, they should look as shown
on the picture above.
Step 4
Put the screws in the holes, shown on the picture
above and tighten the top and botton parts of Shelly
Button.
Step 5
With
Wiring guide
Max Voltage 260V AC
Max load 11A
Working temp -20 up to 40Co
Protection IP47
L N N L
Connect the wires, as shown on the picture above.
Step 1
Place the button extension lead, as shown on the pic-
ture above.
Step 2
L N N L
Power
IN
Power
OUT
Connect the power (input and output) cables, as
shown on the picture above.
Step 3
Power
IN
Power
OUT
Inside the case of Shelly Button there are guiding ar-
rows, which show how to organise the power cables.
After placing the cables, they should look as shown
on the picture above.
Step 4
Put the screws in the holes, shown on the picture
above and tighten the top and botton parts of Shelly
Button.
Step 5
