Shenchen Precision Pump N6 Series User manual

Shenchen Precision Pump
Manual of N6 Series
DOMINIQUE DUTSCHER SAS

Warning
Tubing may have crack due to wear. It results in the overflow of
fluid from tubing. In that time human body and instruments may be hurt. Must
check usually and change tubing in time.
Please connect directly the power line to the wall socket, and avoid
using the extension electric line.
If power line or plug have wear and other damage, please unplug it.
If following situations happened, please turn off the pump, take off
the power plug.
1. Fluid splash on the pump.
2. You think the pump need to maintain or repair.
The user’s power socket must have ground wire, and have reliable
grounding.
Note: When connect foot pedal switch or external control, must turn off the
pump.
DOMINIQUE DUTSCHER SAS

Catalog
1. N6 Series Product Introduction....................................................................- 1 -
2. N6 Series Product Appearance.....................................................................- 1 -
3. N6 Series Keypad Instruction...................................................................... - 2 -
4. N6 Series Operation Interface......................................................................- 3 -
5. N6 Series Technical Specification..............................................................- 11 -
6. N6 Series Main Functions & Features....................................................... - 12 -
7. Product Dimension ....................................................................................- 13 -
8. External Control Instruction...................................................................... - 14 -
9. Maintenance................................................................................................-19-
10. Warranty and After Sales Service............................................................ - 20 -
DOMINIQUE DUTSCHER SAS

Shenchen Pump N6 Series
-1-
1. N6 Series Product Introduction
N6 series products with 303 stainless steel housing, 3.2 inch LCD screen
display; support variety of external control, RS232/RS485 communication,
standard MODBUS protocol (RTU mode), meet different requirements.
Suitable head: DZ25-3L, DZ25-6L, YZ35
2. N6 Series Product Appearance
A——Drive
B——Pump head
C——Power switch
D——Power socket
E——External control interface
F——Fuse
DOMINIQUE DUTSCHER SAS

Shenchen Pump N6 Series
-2-
3. N6 Series Keypad Instruction
Start/stop button: Press this button, the pump start running. Press this button
again, pump stop running.
Change direction button: Press this button to change the pump running
direction.
Full speed button: When the pump is stop or in transferring state, press this
button, pump will run with full speed. This function used for fast fill liquid into
tube or wash the tube. In dispensing function, this button is invalid.
Digital knob: Turn this knob to adjust the speed/flow rate. When the pump is in
stop status, press this knob to enter menu interface, turn and press the knob to
set the parameters.
ESC button: In menu interface, press this button back to previous menu. In
stop status, press this button more than 5 seconds, to check the pump SN code
and programme version.
DOMINIQUE DUTSCHER SAS

Shenchen Pump N6 Series
-3-
4. N6 Series Operation Interface
4.1 Main Interface
4.2 Menu Setting Interface
DOMINIQUE DUTSCHER SAS

Shenchen Pump N6 Series
-4-
Steps:
A. Press [digital knob] in the main interface to enter the menu setting interface,
press again to select the setting parameters.
B. Turn the [digital knob] to move up and down to select the parameter to be set.
C. Press [ digital knob] to enter the next setting parameters interface.
D. Press [ESC] to back to main interface.
4.2.1 Calibration Interface
Steps:
A. After entering this interface, the test time defaults to 60 seconds, and the actual
liquid volume defaults to the liquid volume displayed according to the current set
flow rate.
B. Press the [digital knob] key to select the test time. In the (1) state, turn the [knob],
move the cursor to the [volume] line, and then press the [Start] button to start the
pump for calibration. A countdown is displayed at the test time.
C. You can also switch to the (2) state by pressing the [ digital knob] in the (1) state,
then turn the [digital knob] in the (2) state to set the test time.
D. After the countdown is over, the cursor jumps directly to the actual liquid volume,
then turn the knob enters the actual liquid volume.
E. After enter the actual volume, press the [ digital knob] to confirm the entry. The
‘Calibration finished!’ dialog box will pop up. Press the knob again back to
calibration interface.
DOMINIQUE DUTSCHER SAS

Shenchen Pump N6 Series
-5-
F. Reset function: Select ‘Yes’ and press[ digital knob], the ‘Reset calibration
finished!’ dialog box will pop up, the calibrate factor been restored.
4.2.2 Select Pump Head & Tube Interface
Steps:
a. Select the pump head model by pressing the [ digital knob] in Head & Tube
interface. In the (1) state, turn the [digital knob] to move the cursor up and down to
select set pump head or tube size.
b. In the (1) state, press the [digital knob] to switch to the (2) state.
c. In the (2) state, turn the [digital knob] to select the pump head model.
e. In the (2) state, press the [digital knob] or [ESC] to return to the (1) state and
confirm the selected pump head or tube size.
4.2.3 Dispensing Interface
DOMINIQUE DUTSCHER SAS

Shenchen Pump N6 Series
-6-
Steps:
A. Press [digital knob] in the dispensing interface, the interface turn to (1) state.
Turn the knob to select setting On/Off, Time or Unit.
B. In (1) state, press the knob change the interface to (2) state.
C. In (1) state, press [ESC] back to menu interface.
D. In (2) state, turn knob to turn On/off dispensing function, or set the dispensing
time(0.1-9999s), or set the time unit ( second, minute, hour).
E. In (2) state, press knob or [ESC] back to (1) state and confirm the setting
parameters.
Note: 1. After turn on the dispensing function, the pump will stop automatically
when reach the setting time.
2. After turn on the dispensing function, external control speed is invalid.
4.2.4 External Control Speed Interface
Steps:
A. Press [ digital knob] on the external control speed interface to select the external
control speed. In the (1) state, turn the knob to move up and down to select the
external control speed, signal type or maximum speed.
B. In the (1) state, press knob to the (2) state.
C. In the (1) state, press the [ESC] back to menu interface.
D. In the (2) state, turn the [digital knob] to select the external control speed control
on/off or select the signal type: 0-5V/0-10V/4-20mA or select the maximum speed.
DOMINIQUE DUTSCHER SAS

Shenchen Pump N6 Series
-7-
E. In the (2) state, press the [digital knob] or [ESC] to return to the (1) state and
confirm the selected item.
F. In the (1) state, turn the [ digital knob] clockwise to enter the external control
speed customization interface, as shown below:
G. In the (1) state, turn the [digital knob] to select (4mA corresponding speed: 0) or
(20mA corresponding speed: 600).
H. In the (1) state, press the [digital knob] to the (2) state.
I. In the (1) state, press the [ESC] to return to the [Setup Menu Selection Screen]
J. In the (2) state, turn the [digital knob] to set the corresponding speed for each part.
K. In the (2) state, press the [digital knob] or the [ESC] to return to the (1) state and
confirm the selected item.
External control speed limit
Select external control signal according to external input signal, 0-5V, 0-10V,
4-20mA for option. External control speed can set the maximum speed, when the
maximum speed is 600rpm, the analog signal voltage range has a linear relationship
with the motor speed.
If the maximum speed is not 600 rpm, the motor speed will be limited by the analog
signal. When the motor speed and the analog signal amount reach the set maximum
speed according to the corresponding proportional relationship, then when the analog
signal amount is increased, the motor speed is set by The operation at a fixed
maximum speed does not follow the increase of analog signal quantity. For example:
DOMINIQUE DUTSCHER SAS

Shenchen Pump N6 Series
-8-
set 0V to 0 rpm, 5V to 600 rpm (2.5V should be 300 rpm), the maximum speed is set
to 300 rpm, if the external input analog signal is 2.5V, then the motor speed is 300
rpm, input signal The motor speed remains unchanged at 300 rpm after exceeding
2.5V.
4.2.5 External Control Interface
Operation steps：
A. In the (1) state, turn the [digital knob] to select the external control start/stop,
change direction or signal type.
B. In the (1) state, press the [digital knob] to the (2) state.
C. In the (1) state, press the [ESC] to return to the menu interface.
D. In the (2) state, turn the [digital knob] to select the external control start/stop
on/off or external control direction on/off or select the signal type: level/pulse ( in
level mode, the corresponding internal control buttons are invalid.)
E. In the (2) state, press the [ESC] or the [digital knob] to back to the (1) state and
confirm the selected item.
External control full-speed function is level mode. Connect to full speed, stop full
speed after disconnection;
External control start/stop, change direction signal is active signal and passive
signal.
External control start/stop, change direction signal: Level mode and pulse mode,
DOMINIQUE DUTSCHER SAS

Shenchen Pump N6 Series
-9-
detailed interface refer to external control interface instruction.
After turn on the dispensing function, external control start/stop only valid in pulse
mode, invalid in level mode.
External control have independent switch, only works when the corresponding
external control function is turned on
4.2.6 Communication Setting Interface
Operation steps:
Serial communication is always on and the On/Off option is not set.
A.In the (1) state, turn the [digital knob] to select setting local address,
communication port or Baud rate.
B. In the (1) state, press the [ digital knob] change to the (2) state.
C. In the (1) state, press the [ESC] to return to menu interface.
E. In the (2) state, turn the [digital knob] to select the local address (01-32) or the
interface to select RS232/RS485 or baud rate selection: 2400/4800/9600/19200.
F. In the (2) state, press the [ESC] or the [ digital knob] to return to the (1) state and
confirm the setting parameters.
Note: 1. N6 series pump support Modbus communication protocol-- RTH mode,
communication port RS232 or RS485, baud rate 9600.
2.After the setting is completed, the pump only receive communication signal
control in main interface; in other setting interface, the communication is
invalid.
DOMINIQUE DUTSCHER SAS

Shenchen Pump N6 Series
- 10 -
4.2.7 Back Suction Interface
Operation steps：
A. In the (1) state, turn the [ digital knob] to select setting on/off or suction angle.
B. In the (1) state, press the [ digital knob] change to the (2) state.
C. In the (1) state, press the [ESC] to return to menu interface.
D. In the (2) state, turn the [digital knob] to set the back suction function on/off or to
set the back suction angle (0-360).
E. In the (2) state, press the [ESC] or the [ digital knob] to return to the (1) state and
confirm the setting parameters.
Note: When the back suction is off, the main interface does not display the back
suction sign. Only when the back suction is turned on, the main interface will
display the back suction sign.
DOMINIQUE DUTSCHER SAS

Shenchen Pump N6 Series
- 11 -
5. N6 Series Technical Specification
Speed range
0.1-600rpm
Power
supply
AC220V±10%，
50Hz/60Hz (standard)
AC110V±10%，
50Hz/60Hz (option)
Power
consumption
N6-3L: <80W
N6-6L: <180W
N6-12L: <300W
Speed resolution
0. 1rpm
Communication
Interface
RS232 /RS485, Modbus
protocol (RTU mode)
Control
Mechanical keypad and
digital knob
Dimension
(L*W*H)
N6-3L:223*152*236mm
N6-6L:283*192*274mm
N6-12L:302*222*331mm
Display
3.2 inch LCD screen
Weight
N6-3L: 5.40Kg
N6-6L: 9.75Kg
N6-12L: 14Kg
Start/stop, change
direction signal
Passive switch signal, such
as: foot switch;
Active switch signal：
5V-24V
Relative
humidity
<80%
Condition
temperature
0-40℃
External speed
control
0-5V, 0-10V, 4-20mA
for optional
IP rate
IP31
DOMINIQUE DUTSCHER SAS

Shenchen Pump N6 Series
- 12 -
6. N6 Series Main Functions & Features
3.2 inch big screen LCD display working parameters in real time
Super silent drive setting, precise control, low vibration and low low
noise.
Mechanical keypad and digital knob control, convenient for users setting
the parameters.
Timing function, the time range is 0.1s-9999 hours, can be used for
simple dispensing function.
Various external control functions, support 0-5V, 0-10V, 4-20mA analog
signal control speed.
Power down memory function, store parameters in time, safe and
reliable.
Strong anti-jamming feature, wide voltage design, suitable for complex
power supply environment.
Fast fluid-filled function, not only can clean the tubing, but also fill
liquid into the tubing.
High torque and low power loss, it can load several pump heads or
multichannel pump head, meet different application requests.
DOMINIQUE DUTSCHER SAS

Shenchen Pump N6 Series
- 13 -
7. Product Dimension (Unit: mm)
N6-3L/DZ25-3L
N6-6L/DZ25-6L
DOMINIQUE DUTSCHER SAS

Shenchen Pump N6 Series
- 14 -
N6-12L/YZ35
8. External Control Instruction
DOMINIQUE DUTSCHER SAS

Shenchen Pump N6 Series
- 15 -
①Analog signal input port: Turn on external control speed function in
external control setting interface, control the pump speed from 0rpm to
maximum speed through analog signal.
0-10V: 0V to 10V voltage signal input terminal.
0-5V: 0V to 5V voltage signal input terminal.
4-20mA: 4mA to 20mA current signal input terminal.
I_/V_: Analog signal negative terminal.
Note: It is forbidden to connect 0-10V signal to 0-5V or 4-20mA input
terminal. Wrong connection may cause pump damage.
②Internal isolation 5VDC output
③External control start/stop, change direction, full speed signal input
terminal: Active signal input, 5V-24V.
GD2: External control signal input common terminal
NC: External control full speed signal input terminal
CW/CCW: External control direction signal input
R/S 2: External control start/stop signal input
Set the external control mode in the external control setting interface and
enable the corresponding external control function. The signal at the external
control signal input terminal is valid. (The external control full-speed signal
defaults to the level mode, short connect start, disconnect stop, no need to turn
on in the setting interface)
④R/S1external control start/stop signal input terminal: Passive signal input.
This terminal can connect with passive switch or foot pedal switch, in external
control setting interface to enable this terminal--Foot pedal switch.
DOMINIQUE DUTSCHER SAS

Shenchen Pump N6 Series
- 16 -
External control wiring connection as below:
A. In pulse mode: Disconnect K2 after short connect, the motor start running,
disconnect again after short connect, motor stop running. In level mode: Short
connect K2, motor start running; disconnect K2, motor stop running.
B.In pulse mode: Disconnect K1 after short connect once, the motor change
direction once. In level mode: Short connect K1, motor running clockwise;
disconnect K1, motor running anticlockwise.
C.In pulse mode: Disconnect K3 after short connect, motor start running;
disconnect again after short connect, motor stop running. In Level mode: short
connect K3, motor start running; disconnect K3, motor stop running.
D. Short connect K4, motor running with full speed; disconnect K4, motor back
DOMINIQUE DUTSCHER SAS

Shenchen Pump N6 Series
- 17 -
to the state before running at full speed. ( External control full speed default is
level mode. )
⑤The motor working status output terminal: Output motor working status as
below:
If connect with external relay, when motor is running, K1 is connect;
when motor is stop, K1 disconnect.
⑥RS232 communication terminal: Select RS232 in communication setting
interface, then this terminal is effective.
GND: Communication ground terminal
TXD: The external controller send, peristaltic pump receive signal terminal
RXD: Peristaltic pump send, external controller receive signal terminal.
Connect with computer RS232 communication interface connection
wiring diagram as below:
DOMINIQUE DUTSCHER SAS
