GEA Hilge HYGIA K User manual

Hygienic Pumps
GEA Hilge HYGIA K
Operating instruction (Translation from the original language)
BA.H2A.KYY.001.GB_2

COPYRIGHT
All rights reserved.
Nothing contained in this documentation may be reproduced or distributed in any
form (print, photocopy, microfilm or another method) without the prior written
permission of
GEA Hilge
Niederlassung der GEA Tuchenhagen GmbH
hereinafter referred to as Manufacturer This restriction also applies to the
drawings and diagrams included in the documentation.
LEGAL NOTICE
These instructions are part of the technical documentation for the scope of
delivery. They contain important information to ensure safe and proper
transportation, mounting, commissioning, economic operation, maintenance, and
repair of the pump. Following these instructions will help you avoid risks, reduce
repair costs and downtime and increase the pump's reliability and service life.
These instructions are aimed at users of the pump and are intended in particular
for the operator and its operating and maintenance personnel.
It is mandatory for the operator and its operating and maintenance personnel to
read these instructions prior to transport, installation, commissioning, use,
maintenance, repair, disassembly and disposal of the pump. The obligation to
read these instructions applies also to persons responsible for carrying out
activities in the phases of the life of the pump.
The operator is required to complement these instructions with information based
on existing national regulations for occupational safety, health protection, and
environmental protection.
In addition to these instructions and the mandatory regulations for accident
prevention applicable in the country and place of use, the recognised technical
rules for safe and proper work must be observed.
These instructions are part of the pump. The entire documentation consists of
these instructions and any additional instructions provided. It must always be kept
within reach at the pump’s location of use. When moving the pump to a different
site and upon selling the pump, the entire documentation must be passed on as
well.
These instructions were written to the best of our conscience. However, the
manufacturer is not liable for any errors that may be contained in this document
or for any resulting consequences.
The manufacturer reserves the right to make technical changes by further
development of the pump described in these instructions.
Illustrations and drawings in these instructions are simplified representations.
Due to enhancements and changes, it is possible that the illustrations do not
exactly match the pump used by you. The technical data and dimensions are not
binding. Claims cannot be derived from them.
The manufacturer assumes no liability for damages
•arising within the warranty period due to
BA.H2A.KYY.001.GB_2
2 27.02.2018

–unintended operation and usage conditions,
–insufficient maintenance,
–improper operation,
–incorrect installation,
–incorrect or improper connection of electrical components.
•resulting or arising from unauthorised modifications or failure to follow the
instructions,
•caused by use of accessories / spare parts that have not been supplied or
recommended by the manufacturer.
BA.H2A.KYY.001.GB_2
27.02.2018 3

LAYOUT INFORMATION
Bullet points and numbered list characters
Bullet points are used to separate logical contents within a section:
•Bullet point 1
Types of bullet point 1.
•Bullet point 2
Types of bullet point 2.
Numbered list characters are used to separate enumerations within a
descriptive text:
Descriptive text with consecutive numbering:
–Numbered list point 1
–Numbered list point 2
Handling instructions
Handling instructions require you to do something. Several consecutive steps
result in a handling sequence that should be run in the specified order. The
handling sequence can be divided into separate steps.
Handling sequence
1. Handling sequence step 1
–step 1,
–step 2,
–step 3.
2. Handling sequence step 2
The subsequent handling sequence is the expected result:
®Result of the handling sequence.
Individual handling steps
Individual handling steps are marked thus:
–Individual work steps
BA.H2A.KYY.001.GB_2
4 27.02.2018

TABLE OF CONTENTS
1 General 7
1.1 Information about this document 7
1.2 Manufacturer address 7
1.3 Customer Service 7
1.4 EU Declaration of Conformity for Machines 8
2 Safety 9
2.1 Intended use 9
2.1.1 Pumped fluids 9
2.1.2 Minimum flow rate 9
Minimum flow rates in explosive atmospheres 9
2.1.3 Connections and piping 9
2.1.4 Switching frequency 9
2.1.5 Types 9
2.2 Safety precautions in these operating instructions 9
2.3 Explanation of the safety symbols used 11
2.4 Safety instructions for the company/operator 11
2.4.1 Dangers of non-compliance with safety information 12
2.4.2 Safety-conscious work behaviour 12
2.5 Unauthorised modification and ordering of spare parts 12
2.6 Staff qualifications and training 13
2.7 Safety equipment 13
2.8 Possible residual hazards 13
3 Description 15
3.1 Pump overview 15
3.2 Description 15
3.2.1 Standard version applications 15
3.2.2 Hygienic design applications 15
3.3 Pump name 16
3.4 Type plate 16
4 Transport and Storage 17
4.1 Special personnel qualification for transport and storage 17
4.2 Safety precautions for transport and storage 17
4.3 Dimensions / weights 18
4.4 Unpacking the pump 18
4.5 Disposal of packaging material 19
5 Technical data 20
5.1 Serial number 20
5.2 Performance data 20
5.3 Noise emissions 20
5.4 Maximum operating temperatures 21
5.5 Maximum operating pressure 21
5.6 Resistance of Sealing Materials 21
6 Assembly and installation 23
6.1 Safety precautions for setup, installation, and connection 23
6.1.1 Mechanical seal in quench arrangement 25
6.1.2 Vertically installed pumps 25
6.2 Special personnel qualification 25
6.3 Setup, installation, and connection 25
6.3.1 Checking smooth running of the impeller 25
6.3.2 Setting up and aligning the pump unit 26
6.3.3 Installation in the piping system 26
Space requirements 26
Noise and vibration damping 27
6.3.4 Using the mechanical seal 29
6.3.5 Flush connections for double mechanical seals (optional) 30
Flushing fluid (optional) 30
Quench version (optional) 31
6.3.6 Electrical connection 32
Star connection 32
Delta connection 32
BA.H2A.KYY.001.GB_2
27.02.2018 5

Frequency converter operation 32
Checking the direction of rotation after connecting 33
Earthing 33
7Commissioning 35
7.1 Special personnel qualification 35
7.2 Safety instructions for commissioning 35
7.3 Commissioning / initial startup 35
7.3.1 Checking conditions of use 35
7.3.2 Commissioning of the pump 35
7.3.3 Functional testing of the mechanical seal 36
7.3.4 Function test of the shaft sealing ring (quench) 36
8Cleaning 37
8.1 Special personnel qualification 37
8.2 Safety instructions 37
8.3 CIP 38
8.4 SIP 39
8.5 Manual exterior cleaning 39
9Maintenance / servicing 40
9.1 Safety instructions for maintenance and repair 40
9.2 Special personnel qualification 40
9.3 Pump maintenance 40
9.3.1 Inspections 40
Replacement of O-rings 40
9.3.2 Maintenance intervals 41
9.4 Maintenance of the motor 42
10 Malfunctions / repairs 43
10.1 Special personnel qualification 43
10.2 Safety instructions 43
10.3 Malfunctions and remedies 44
10.4 Repair 45
10.4.1 Repair order 45
10.4.2 GEA Hilge assembly tool kit 47
Contents and use 47
10.4.3 Parts overview 48
10.4.4 Parts overview for K motor stool 49
10.4.5 Parts overview of drive 50
10.4.6 Disassemble the pump 50
10.4.7 Installation instructions 51
Cleaning the components before assembly 51
10.4.8 Installing shaft protection sleeve 51
10.4.9 Installing the motor, motor stool and pump shaft 54
10.4.10 Determining gap size on HYGIA 59
10.4.11 Installing single conical spring mechanical seal 61
10.4.12 Installing the single mechanical seal - spring encapsulated (hygiene) 63
10.4.13 Installing impeller and housing 65
10.4.14 Installing the safety guards 71
10.4.15 Installing SUPER cover hood 71
11 Decommissioning 73
11.1 Special personnel qualification 73
11.2 Safety instructions 73
11.3 Temporary decommissioning 73
11.4 Disposal 73
12 Appendix 74
12.1 Certificate of non-objection 75
BA.H2A.KYY.001.GB_2
6 27.02.2018

1 General
1.1 Information about this document
Target group
These operating instructions are intended for:
–the operator/user of the pump,
–the maintenance and service personnel.
The instructions assume a general common technical understanding, which is
necessary for the commissioning, maintenance and servicing of pump units.
Sections that are aimed only at special authorised personnel are indicated by a
preceding note
Text highlights
The following symbols and text formatting facilitate the reading of this document:
–Bullets and lists points
–Instructions
Instructions that must be executed in a certain order are numbered according to
the sequence.
For the marking of safety instructions, please refer to Section 2.3, Page 11.
Technical changes
Versions, technical data and spare part numbers are subject to technical change.
We reserve the right to implement changes due to technical progress.
1.2 Manufacturer address
GEA Hilge
Niederlassung der GEA Tuchenhagen GmbH
Hilgestraße 37-47
55294 Bodenheim
Germany
Phone [phone]
Fax [phone]
[email protected]
gea.com
1.3 Customer Service
Phone [phone] (Sales support)
Phone [phone] (Service)
[email protected]
General
Information about this document
BA.H2A.KYY.001.GB_2
27.02.2018 7

1.4 EU Declaration of Conformity for Machines
in accordance with the EC Machinery Directive 2006/42/EC, Annex II 1. A
Manufacturer: GEA HILGE
Office of GEA Tuchenhagen GmbH
Hilgestrasse 37-47
D 55294 Bodenheim Germany
We declare under our sole responsibility that the machine
Designation: Centrifugal pump
Model: GEA Hilge HYGIA
Type: K, K-SUPER
conforms with all the relevant provisions of this directive and the following directives:
Relevant EC directives: 2006/42/EC EC Machinery Directive
Applicable harmonized
standards, in particular:
EN 809:1998/A1+AC(D)
EN ISO 12100:2010
Remarks: We also declare that the relevant technical documentation for
this machine has been prepared in accordance with Annex VII,
Part A, and agree to submit the documentation on justified
request of national authorities on a data carrier.
Person authorised for compilation and
handover of technical documentation:
GEA HILGE
Office of GEA Tuchenhagen GmbH
Hilgestrasse 37-47
55294 Bodenheim Germany
Bodenheim, 05/02/2018
Michael Wulle
Managing Director
p.p. Dr. Boris Kneip
Head, Development Dept. GEA Hilge
General
EU Declaration of Conformity for Machines
BA.H2A.KYY.001.GB_2
8 27.02.2018

2 Safety
2.1 Intended use
Warning!
Non-intended use!
► Pump only media that are specified in the order. The pump has been
specially designed for them.
► Operate the pump only on the electrical grid that was specified in the
purchase order.
2.1.1 Pumped fluids
Use only clean or lightly polluted liquids as pumped fluids as long as they do not
chemically or mechanically attack the pump materials or reduce their strength. If
you want to pump liquids with higher viscosity than that of water, check for
possible overload of the motor.
2.1.2 Minimum flow rate
The pump may not be operated below of a flow rate of Qmin = 10-15 % Qopt.
2.1.2.1 Minimum flow rates in explosive atmospheres
For pumps used in explosive atmospheres according to EU explosion protection
directive 2014/34/EU, the minimum flow rates of the ATEX additional instructions
in Annex B apply.
2.1.3 Connections and piping
The pipe nominal diameters of the system should be equal to or greater than the
pump nominal diameters DNE (suction side) or DNA (pressure side), and the
fittings to the pump should match exactly the type standard of the fixed mating
connection part on the pump. The suction line must be hermetically sealed and
routed such that no air pockets can form. Avoid tight bends and valves directly in
front of the pump. On the suction side, a straight settling section with a minimum
length of 5 times the pipe diameter should be provided. The suction head of the
system must not be larger than the suction head guaranteed by the pump.
2.1.4 Switching frequency
Do not exceed a switching frequency of 15 switching operations per hour.
2.1.5 Types
All information and descriptions in these operating instructions on the use and
handling of the pumps refer exclusively to the standard versions. Special designs
and customised deviations as well as random external influences in the use and
operation are not included in this provision.
2.2 Safety precautions in these operating instructions
Read the safety precautions!
Safety
Intended use
BA.H2A.KYY.001.GB_2
27.02.2018 9

These operating instructions contain basic precautions that must be observed
during installation, operation and maintenance. They must therefore be read by
the installer and relevant personnel or operator prior to installation and
commissioning. The operating instructions must always be available at machine/
system site.
In addition to the general safety precautions listed in this chapter on safety, be
sure to read also the other, special safety precautions included.
Safety
Safety precautions in these operating instructions
BA.H2A.KYY.001.GB_2
10 27.02.2018

2.3 Explanation of the safety symbols used
Danger
Stands for an immediate danger which leads to heavy physical injuries or to
the death.
► Description to avert the danger
Warning!
Stands for a possibly dangerous situation which leads to heavy physical
injuries or to the death.
► Description to avert the dangerous situation.
Caution!
Stands for a possibly dangerous situation which could lead to light physical
injuries or to damages to property.
► Description to avert the dangerous situation.
Notice!
Stands for an important tip whose attention is important for the designated
use and function of the product.
► Description of the necessary action for proper operation of the product.
2.4 Safety instructions for the company/operator
Follow the safety instructions contained in this operating manual, the relevant
national accident prevention regulations as well as any internal working,
operating, and safety provisions of the operating company.
Warning!
Hot or cold machine parts
Risk of burns.
► Secure hot or cold machine parts against contact!
Warning!
Rotating machine parts
Hazard of entrapment or entanglement.
► Do not remove contact protection for rotating machine parts (e.g.
coupling)!
► Replace defective safety devices promptly!
Safety
Explanation of the safety symbols used
BA.H2A.KYY.001.GB_2
27.02.2018 11

Warning!
Hazardous materials
Contact with dangerous substances, e.g. by inhalation.
► Discharge the leakage of dangerous goods such that no danger to
persons and the environment arises!
► Comply with legal provisions!
► Switch off the pump in the event of failure of the mechanical seal.
Replace the mechanical seal before next use!
Warning!
Tripping and falling hazard
Danger due to electrical cables.
► Route the electrical supply line such that there is no risk of tripping (only
for pumps on a chassis).
Danger
Live parts
Electric shock by touching live parts
► Use only technically flawless plugs and cables.
2.4.1 Dangers of non-compliance with safety information
Ignoring the safety instructions can result in bodily harm to persons as well as
environmental harm and machine damage.
Failure to follow the safety instructions will result in the loss of any claims for
damages.
Failure to follow the instructions may entail the following hazards, for example:
–Failure of important functions of the machine/system.
–Failure of prescribed methods for repair and maintenance
–Exposure of persons to electrical, mechanical, and chemical hazards.
–Environmental risks caused by leakage of hazardous substances.
2.4.2 Safety-conscious work behaviour
Follow the safety instructions contained in this operating manual, the relevant
national accident prevention regulations as well as any internal working,
operating, and safety provisions of the operating company.
2.5 Unauthorised modification and ordering of spare parts
Modification or alteration of the machine is only permitted with the written
permission of the manufacturer.
Exclusive use of original spare parts and accessories authorised by the
manufacturer ensures safety. The manufacturer will bear no liability for
consequences arising from the use of unauthorised parts.
Safety
Unauthorised modification and ordering of spare parts
BA.H2A.KYY.001.GB_2
12 27.02.2018

2.6 Staff qualifications and training
The staff for working on and with the pump must have the appropriate
qualifications. Responsibilities, competencies and supervision of staff must be
clearly defined by the operating company. If personnel do not have the necessary
knowledge, they are to be trained and instructed. If necessary, this can be done
by the product manufacturer/vendor on behalf of the operating company. The
operating company must also ensure that the contents of the operating
instructions are fully understood by the staff.
2.7 Safety equipment
Do not remove instructions from the pump.
Signs attached directly on the machine, such as an arrow to indicate the direction
of rotation, must absolutely be observed and kept in fully legible condition.
Damaged or illegible signs must be replaced.
2.8 Possible residual hazards
Hint!
Despite careful design of the machine and the implementation of all
safety-relevant regulations, further risks for persons and machine
during all life phases of the pump cannot be fully ruled out. The
additional safety instructions in the individual chapters of this manual
must therefore be carefully observed!
The residual risks that were ascertained during the risk assessment carried out
for the product according to safety standard EN ISO 14121 - Safety of Machines -
are:
–mechanical hazards due to sharp sheet metal edges and projecting parts
–electrical hazards as a result of inadvertently coming in contact with terminals
and cables
–thermal hazards as a result of inadvertently coming in contact with pump
housings and pipes
–exposure to noise
–hazards caused by vibration due to improper installation
–hazards due to working materials and other materials in case of allergies or
the like.
–neglect of ergonomic principles
–combinations of various hazards
–unexpected starting, unexpected rotation in case of wrong electrical
connections or defects
–shut down, emergency stop when defects are detected
–changes to the rotational speed
–power failure
–Hazard from insufficient / incorrect cleaning - Product contamination,
Safety
Staff qualifications and training
BA.H2A.KYY.001.GB_2
27.02.2018 13

–failure of the control circuit or control loop
–incorrect assembly
–fracture during operation
–operating media or objects getting thrown out
–loss of stability
–personnel slipping, tripping or falling
Safety
BA.H2A.KYY.001.GB_2
14 27.02.2018

3 Description
3.1 Pump overview
0801
0340
0103
0180
0156
0153
Fig.1: GEA Hilge HYGIA K
0103 Ring housing
0153 Suction nozzle
0156 Pressure nozzle
0180 Stainless steel foot
0340 Motor stool
0801 Motor
3.2 Description
The pump is a normal-priming, single-stage centrifugal pump in system block
design. All wetted parts are based on the “hygienic design” guidelines. The
material grade 1.4404 or 1.4435 Fe ≤ 1% and the respective execution standard
are carried out according to the order and, if required, certified in writing
3.2.1 Standard version applications
The standard version of the pumps is used in the following areas:
–Breweries (beer, wort, mash, yeast, etc.)
–Dairies (milk, milk mixes, cheese production, etc.)
–Soft drinks (fruit juice, lemonade, mineral water, etc.)
–Wine and sparkling wine production
–Distilleries (mash, distillates, etc.)
–Food production (marinades, pickle, cooking oil, etc.)
–Cleaning systems (CIP)
3.2.2 Hygienic design applications
Due to the consistent hygienic design and the use of pore and porosity-free
materials, the pump is ideally suited for use in the following areas:
–pharmaceutical industry
–medical technology
Description
Pump overview
BA.H2A.KYY.001.GB_2
27.02.2018 15

–in biotechnology process plants
Special applications arise in the area of ultrapure water delivery/WFI, as well as
in equipment for the production of parenterals and infusion solutions according to
FDA.
3.3 Pump name
GEA Hilge pump name
GEA Hilge
HYGIA I K 40/40 3 2
Pump name Size Design type Nominal width Output
[kW] Number of poles
3.4 Type plate
GEA Hilge
Niederlassung der GEA Tuchenhagen GmbH
Hilgestrasse - D - 55294 Bodenheim
Pump-Type:
Ser.-No.:
Q: H: n:
P:
TAG No.:
YOM: Made in Germany
Fig.2: Type plate GEA Hilge
Pump type: Pump name P: Motor rating
Serial No.: Serial number n: Speed
Q: Flow rate TAG No.:customer name
H: Delivery head YOM: Year of manufacture
Note: The type plate may differ from the presented layout.
Description
Pump name
BA.H2A.KYY.001.GB_2
16 27.02.2018

4 Transport and Storage
4.1 Special personnel qualification for transport and storage
Transports may only be carried out by qualified staff, who must observe the
safety instructions.
4.2 Safety precautions for transport and storage
Warning!
Falling loads
Danger from falling loads.
► To transport the pump, use suitable lifting gear with sufficient carrying
capacity.
► Make sure that there are no persons present under suspended loads.
► Make sure that the pump is horizontally aligned when lifting.
Warning!
Wrong attachment points!
► Attach the rope to suitable anchor points.
► Never fasten a rope to the pump housing or the suction/pressure port!
► For version with casing: Remove the stainless steel casing before
transport.
Fig.3: Anchor points (example)
Storage of the pump
Caution!
Frost
Risk due to external conditions.
► In case of frost risk, drain the pump completely.
If the pump is not used immediately, proper storage conditions are as important
for later operation as careful installation and proper maintenance.
Protect the pump from cold, moisture and dust, as well as against mechanical
influences.
Qualified personnel is required for proper installation and maintenance.
Transport and Storage
Special personnel qualification for transport and storage
BA.H2A.KYY.001.GB_2
27.02.2018 17

4.3 Dimensions / weights
The weights may differ from the ones shown here depending on the version and
accessories. Please contact the manufacturer for accurate information and quote
the pump / order number.
Weight [kg] - HYGIA I K
Motor
P2
[kW]
pole
Motor IEC Motor foot Cast iron foot Stainless steel foot Dome stand SUPER dome stand SUPER cast iron foot SUPER stainless steel foot SUPER tronic dome stand SUPER tronic cast foot SUPER tronic stainless steel foot
0.75 4 80 31.9 39.4 39.9 34.6 43.8 48.6 45.1 39.7 44.5 41
1.1 2 80 32.4 39.9 36.4 35.1 44.3 49.1 45.6 39.2 44 40.5
1.1 4 90S 37 44.5 41 39.7 48 52.8 49.3 41.8 46.6 43.1
1.5 2 90S 39 46.5 43 41.7 50 54.8 51.3 40.3 45.1 41.6
1.5 4 90L 54.5 62 58.5 57.2 51 55.8 52.3 62.3 67.1 63.6
2.2 2 90L 42 49.5 46 44.7 53 57.8 54.3 41.8 46.6 43.1
2.2 4 100L 58.8 65.8 62.3 61 64.3 69.1 65.6 66.1 70.9 67.4
3 2 100L 51.8 58.8 55.3 54 64.8 69.6 66.1 59.1 63.9 60.4
4 2 112M 62.3 69.3 65.8 64.5 73 77.9 74.4 69.6 74.4 70.9
5.5 2 132S 84.7 91.7 88.2 86.9 98.5 103.3 99.8 77 81.8 78.3
Weight [kg] - HYGIA II K
P2
[kW] pole
Motor IEC Motor foot Cast iron foot Stainless steel foot Dome stand SUPER dome stand SUPER cast iron foot SUPER stainless steel foot SUPER tronic dome stand SUPER tronic cast foot SUPER tronic stainless steel foot
2.2 4 100L 57 64 60.5 59.2 70.7 75.85 72 63.8 68.6 65.1
3 4 100L 65 72 68.5 67.2 78.7 83.85 80 67.3 72.1 68.6
3 2 100L 57 64 60.5 59.2 70.7 75.85 72 60.8 65.6 62.1
4 4 112M 70 77 73.5 72.2 82.2 87.13 83.5 79.8 84.6 81.1
4 2 112M 66 73 69.5 68.2 79.2 84.13 80.5 72.8 77.6 74.1
5.5 4 132S 95.5 102.5 99 97.7 109.7 114.13 111 92.8 97.6 94.1
5.5 2 132S 91.5 98.5 95 93.7 105.7 110.13 107 79.3 84.1 80.6
7.5 2 132S 99.5 106.5 103 101.7 113.7 118.13 115 88.8 93.6 90.1
11 2 160M 125 128.8 148
15 2 160M 131 134.8 154
18.5 2 160L 151 154.8 174
22.0 2 160L 187
4.4 Unpacking the pump
All of our pumps leave our warehouse properly packaged to avoid damage in
transit.
Should you nevertheless find any damage after cautious unpacking and exact
inspection of the shipment, immediately notify the carrier (railway, post, freight
forwarder, shipping company). Make claims for damages. The transport risk
passes to the customer once the shipment has left our warehouse.
Transport and Storage
Dimensions / weights
BA.H2A.KYY.001.GB_2
18 27.02.2018

4.5 Disposal of packaging material
The generation of waste should be avoided or minimized wherever possible.
Surpluses and packaging materials not suitable for recycling should be disposed
of through an approved waste disposal company. Packaging materials not
suitable for recycling must always be disposed of in accordance with the
requirements of environmental protection and waste disposal legislation as well
as the requirements of the local authorities.
Packaging materials suitable for recycling should be reused or reprocessed.
Transport and Storage
Disposal of packaging material
BA.H2A.KYY.001.GB_2
27.02.2018 19

5 Technical data
The operating safety of the delivered machine is only guaranteed if the machine
is used as intended according to the sections of the operating instructions and
the purchase order.
Warning!
Overload of the pump!
► Do not operate the pump above the maximum permissible operating
data.
► Avoid even short-term pressure overloads (e.g. by pressure surges).
5.1 Serial number
The pump can be uniquely identified by the serial number. When ordering spare
parts, always quote the serial number. The serial number is indicated on the type
plate.
5.2 Performance data
The performance data - delivery head and flow rate - are explained in accordance
with ISO 9906: 2012, Grade 3B and documented with the acceptance report.
5.3 Noise emissions
Measured values in accordance with DIN EN ISO 3746 for pump units,
measuring uncertainty 3 DB(A).
Noise emissions HYGIA I/II
Motor output [kW] Lpfa [dB(A)] 2-pole Lpfa [dB(A)] 4-pole
0.55 51
0.75 65 51
1.1 65 55
1.5 67 55
2.2 67 63
3.0 73 65
4.0 73 65
5.5 73 67
7.5 75 70
11.0 75
15.0 76
18.5 76
22.0 80
The noise emissions caused by a pump are influenced mainly by its application.
The values shown here should therefore be considered merely as a guide.
Technical data
Serial number
BA.H2A.KYY.001.GB_2
20 27.02.2018
