User Manual
H8922 3G/4G Router
www.hongdian.com

Doc. Version 1.1
i
H8922 3G/4G Router User Manual
We Hongdian provide full support to customers, contact us freely if any questions.
Shenzhen Hongdian Technologies Corporation
Address
F14-16,Headquarter Economic Center Building, Zhonghaixin
Science&Tech Park, Bulan Road, Longgang District, Shenzhen
Website
http://www.hongdian.com
Technical Support
[phone]/8238
Fax number
0755-83404677
Postalcode
518112
Copyright© Shenzhen Hongdian Technologies Corporation. 2017. All rights reserved.
All information in this user manual is protected by copyright law. Whereby, no organization or individual shall copy
or reproduce the whole or part of this user manual by any means without written authorization from Shenzhen
Hongdian Technologies Corporation.
Trademarks and Permissions
and DTU are the trademarks and logos of Shenzhen Hongdian Technologies Corporation. Other
trademarks and logos mentioned in this manual bel ong to other organizations related. Shenzhen Hongdian
Technologies Corporation does not own the rights of other trademarks and logos.
Caution
Due to product updates or functional upgrading, we may renew the content of this file, and this file only for
referenc e. All statement, information, suggestion.etc in this file do not compose any form of guarantee and we
Hongdian reserves the right of final explanation.

Doc. Version 1.1
ii
H8922 3G/4G Router User Manual
Foreword
Overview
H8922 3G/4G router is designed and manufactured by Hongdian, it based on 3G/4G
cellular network technology, industrial class quality. With its embedded cellular module, it
has been widely used in finance, transportation, telecom, electricity, security system and
other industries. This document introduced how to use H8922 and its function features.
Product Version
The following table lists t he product versions related to this document.
Model
Version
H8922
V30
Organization
Chapter
Description
1
Features of H8922 3G/4G router and target market.
2
SW & HW structure of H8922 3G/4G router.
3
How to installation of H8922 3G/4G router.
4
Prepare to config H8922 3G/4G router.
5
How to config H8922 3G/4G router.
6
Typical application of H8922 3G/4G router.
7
Frequently asked questions.

Doc. Version 1.1
iii
H8922 3G/4G Router User Manual
Conventions
Symbol Conventions
The symbols that may be found in this document are defined as follows.
Symbol
Description
Indicates a potentially hazardous situation, which if not avoided,
could result in equipment damage, data loss, performance
degradation, or unexpected results.
Indicates a tip that may help you address a problem or save your
time.
Provides additional information to emphasize or supplement
important points of the main text.
Command Conventions
Convention
Description
Boldface
The keywords of a command line are in boldface.
Italic
Command arguments are in italics.
[ ]
Items (keywords or arguments) in brackets [ ] are optional.
{ x | y | ... }
Optional items are grouped in braces and separated by vertical
ars. One item is selected.
[ x | y | ... ]
Optional items are grouped in brackets and separated by vertical
bars. One item is selected or no item is selected.
{ x | y | ... } *
Optional items are grouped in braces and separated by vertical
ars. A minimum of one item or a maximum of all items can be
selected.
[ x | y | ... ] *
Optional items are grouped in brackets and separated by vertical
ars. Several items or no item can be selected.
&<1-n>
The parameter before the & sign can be repeated 1 to n times.
#
A line starting with the # sign is comments.

Doc. Version 1.1
iv
H8922 3G/4G Router User Manual
GUI Conventions
Convention
Description
Boldface
Buttons, menus, parameters, tabs, window, and dialog titles are
in boldface. For example, click OK.
>
Multi-level menus are in boldface and separated by the ">" signs.
For example, choose File > Create > Folder.
Keyboard Operations
Format
Description
Key
Press the key. For example, press Enter and press Tab.
Key 1+Key 2
Press the keys concurrently. For example, pressing Ctrl+Alt+A
means the three keys should be pressed concurrently.
Key 1, Key 2
Press the keys in turn. For example, pressing Alt, A means the two
keys should be pressed in turn.
Mouse Operation
Action
Description
Click
Select and release the primary mouse button without moving the
pointer.
Double-click
Press the primary mouse button twice continuously and quickly
without moving the pointer.
Drag
Press and hold the primary mouse button and move the pointer
to a certain position.
Modifying Records
Modifying records accumulate the introduction of every document update. The document
of the newest version includes all updating contents of previous document versions.
Doc.
Version
Time of
Modifying
Modifying Introduction
V1.0
2014-07-11
The manual was firstly released aiming at the release
of H8922 Router.
V1.1
2017-10-10
Manual update to doc V1.1;

Doc. Version 1.1
v
H8922 3G/4G Router User Manual
Doc.
Version
Time of
Modifying
Modifying Introduction
H8951 hardware version update to V30 from V13.
Remove serial port function.

Doc. Version 1.1
vi
H8922 3G/4G Router User Manual
Contents
Foreword.......................................................................................................................................... ii
Overview ....................................................................................................................................................................................ii
Product Version ........................................................................................................................................................................ii
Organization ..............................................................................................................................................................................ii
Conventions..............................................................................................................................................................................iii
Modifying Records...................................................................................................................................................................iv
1 Product Introduction .................................................................................................................... 4
About this chapter....................................................................................................................................................................4
1.1 Overview .............................................................................................................................................................................4
1.2 Product positioning ...........................................................................................................................................................5
1.3 Function & Features ..........................................................................................................................................................5
1.4 Specification........................................................................................................................................................................6
2 Product structure.......................................................................................................................... 7
About this chapter....................................................................................................................................................................7
2.1 Hardware.............................................................................................................................................................................7
2.1.1 Appearance & Size ..................................................................................................................................................7
2.1.2 Accessories ...............................................................................................................................................................9
2.2 Structure..............................................................................................................................................................................9
3 Installation of H8922 3G/4G router ........................................................................................... 11
About this chapter................................................................................................................................................................. 11
3.1 Unpacking......................................................................................................................................................................... 11
3.2 How to install................................................................................................................................................................... 11
3.2.1 SIM/UIM card install............................................................................................................................................ 11
3.2.2 Ethernet cable connection.................................................................................................................................. 12
3.3 Power supply................................................................................................................................................................... 13
3.4 Review............................................................................................................................................................................... 13
4 Before config ............................................................................................................................... 15
About this chapter................................................................................................................................................................. 15
4.1 LED Status......................................................................................................................................................................... 15
4.2 Local config...................................................................................................................................................................... 16
4.3 Basic config ...................................................................................................................................................................... 22

Doc. Version 1.1
vii
H8922 3G/4G Router User Manual
4.3.1 Login WEB GUI ...................................................................................................................................................... 22
5 Router config............................................................................................................................... 23
About this chapter................................................................................................................................................................. 23
5.1 Overview .......................................................................................................................................................................... 23
5.2 Network configuration................................................................................................................................................... 23
5.2.1 LAN .......................................................................................................................................................................... 24
5.2.2 WAN........................................................................................................................................................................ 25
5.2.3 Modem ................................................................................................................................................................... 28
5.2.4 WLAN ...................................................................................................................................................................... 34
5.2.5 Parameter select (Recommend to Single module dual SIM version).......................................................... 38
5.2.6 Link Backup............................................................................................................................................................ 41
5.2.7 DHCP Service......................................................................................................................................................... 43
5.3 Application program configuration ............................................................................................................................. 46
5.3.1 ICMP check ............................................................................................................................................................ 46
5.3.2 DDNS configuration.............................................................................................................................................. 49
5.3.3 SNMP configuration............................................................................................................................................. 51
5.3.4 M2M configuration.............................................................................................................................................. 52
5.3.5 Timing configuration............................................................................................................................................ 54
5.3.6 Wake up configuration........................................................................................................................................ 57
5.3.7 GPS configuration (Optional) ............................................................................................................................. 59
5.4 Security............................................................................................................................................................................. 60
5.4.1 Overview ................................................................................................................................................................ 60
5.4.2 Configuration ........................................................................................................................................................ 60
5.5 Forward confi guration ................................................................................................................................................... 66
5.5.1 Overview ................................................................................................................................................................ 66
5.5.2 NAT.......................................................................................................................................................................... 67
5.5.3 Static Routing........................................................................................................................................................ 71
5.5.4 QoS (Optional) ...................................................................................................................................................... 74
5.5.5 Dynamic Routing (Optional) ............................................................................................................................... 76
5.6 VPN configuration........................................................................................................................................................... 81
5.6.1 Overview ................................................................................................................................................................ 81
5.6.2 VPDN configuration.............................................................................................................................................. 82
5.6.3 Tunnel configuration............................................................................................................................................ 84
5.6.4 IPSec configuration .............................................................................................................................................. 85
5.6.5 OpenVP N Configuration...................................................................................................................................... 91
5.7 Sys tem configuration ..................................................................................................................................................... 95
5.7.1 Overview ................................................................................................................................................................ 95
5.7.2 Local Log................................................................................................................................................................. 95
5.7.3 Remote Log............................................................................................................................................................ 96
5.7.4 Clock........................................................................................................................................................................ 97
5.7.5 Account .................................................................................................................................................................. 98

Doc. Version 1.1
viii
H8922 3G/4G Router User Manual
5.7.6 Network Test....................................................................................................................................................... 100
5.7.7 Files....................................................................................................................................................................... 101
5.8 Status .............................................................................................................................................................................. 107
5.8.1 Overview .............................................................................................................................................................. 107
5.8.2 Base Information................................................................................................................................................ 107
5.8.3 LAN ........................................................................................................................................................................ 108
5.8.4 WAN...................................................................................................................................................................... 109
5.8.5 Modem ................................................................................................................................................................. 110
5.8.6 Routing Table ...................................................................................................................................................... 112
5.9 RESET bu tton function ................................................................................................................................................. 113
6 Typical application .................................................................................................................... 113
About this chapter............................................................................................................................................................... 113
6.1 Overview ........................................................................................................................................................................ 114
6.2 Awake function ............................................................................................................................................................. 114
6.3 Parameter select........................................................................................................................................................... 115
6.4 VPN .................................................................................................................................................................................. 118
6.5 Timing Task.................................................................................................................................................................... 121
7 FAQ ............................................................................................................................................ 123
About this chapter............................................................................................................................................................... 123
7.1 Hardware Failure .......................................................................................................................................................... 123
7.1.1 All LED dark.......................................................................................................................................................... 123
7.1.2 SIM Slot ................................................................................................................................................................ 123
7.1.3 Ethernet Connection.......................................................................................................................................... 124
7.1.4 An tenna Connec ti on .......................................................................................................................................... 124
7.2 Dial Online Problem...................................................................................................................................................... 124
7.2.1 Dial discontinue.................................................................................................................................................. 124
7.2.2 No Signal .............................................................................................................................................................. 125
7.2.3 Cannot find SIM/UIM card................................................................................................................................ 125
7.2.4 Poor Signal........................................................................................................................................................... 125
7.2.5 Compr ess Protocol not match.......................................................................................................................... 126
7.3 VPN Problem.................................................................................................................................................................. 126
7.3.1 VPDN cannot connect........................................................................................................................................ 126
7.3.2 VPN cannot communicate ................................................................................................................................ 126
7.3.3 Router can communicate but subnet cannot................................................................................................ 127
7.4 WEB config problem..................................................................................................................................................... 127
7.4.1 Updating firmware failure ................................................................................................................................ 127
7.4.2 Backup setting problem .................................................................................................................................... 128
7.4.3 Updating patch failure....................................................................................................................................... 128
7.4.4 CFE Updating failure .......................................................................................................................................... 128
7.4.5 Update fail ure i n WEB GUI................................................................................................................................ 129
7.4.6 Forget Router Password.................................................................................................................................... 129

Doc. Version 1.1
ix
H8922 3G/4G Router User Manual
Table Contents
Table 2-1 H8922 3G/4G router size ......................................................................................................................................8
Table 2-2 H8922 3G/4G router accessories.........................................................................................................................9
Table 4-1 LED instruction..................................................................................................................................................... 15
Table 5-1 LAN Parameter instruction ................................................................................................................................ 24
Table 5-2 WAN connection type parameter instruction................................................................................................ 25
Table 5-3 “Modem” Parameter instruction...................................................................................................................... 29
Table 5-4 WLAN parameter instruction ............................................................................................................................ 35
Table 5-5 Parameter instruction......................................................................................................................................... 39
Table 5-6 Connection type Parameter instruction.......................................................................................................... 40
Table 5-7 Link Backup Parameter ....................................................................................................................................... 42
Table 5-8 DHCP Parameter .................................................................................................................................................. 44
Table 5-9 ICMP check rules Parameter instruction......................................................................................................... 47
Table 5-10 DDNS Parameter instruction........................................................................................................................... 49
Table 5-11 SNMP Parameter instruction .......................................................................................................................... 52
Table 5-12 M2M Parameter instruction............................................................................................................................ 53
Table 5-13 Timing task parameter instruction................................................................................................................. 55
Table 5-14 Wake up Parameter instruction ..................................................................................................................... 57
Table 5-15 GPS Parameter i nstruction .............................................................................................................................. 59
Table 5-16 IP filter parameter instruction ........................................................................................................................ 62
Table 5-17 Domain Filter parameter instruction............................................................................................................. 64
Table 5-18 MAC Filter explanation..................................................................................................................................... 65
Table 5-19 MAC Filter Parameter instruction .................................................................................................................. 66
Table 5-20 DNAT Parameter instruction........................................................................................................................... 68
Table 5-21 SNAT rule instruction........................................................................................................................................ 70
Table 5-22 MASQ rule Parameter instruction.................................................................................................................. 71
Table 5-23 Static Routing Parameter Instruction ............................................................................................................ 73
Table 5-24 QoS parameter instruction.............................................................................................................................. 75
Table 5-25 RIP Parameter Ins truction ............................................................................................................................... 77
Table 5-26 RIP parameter instruction................................................................................................................................ 78

Doc. Version 1.1
x
H8922 3G/4G Router User Manual
Table 5-27 OSPF parameter instruction............................................................................................................................ 79
Table 5-28 OSPF route parameter instruction................................................................................................................. 80
Table 5-29 VPDN rule parameter instruction................................................................................................................... 83
Table 5-30 Tunnel rule parameter instruction................................................................................................................. 85
Table 5-31 IPSec Phase 1 Parameter instruction............................................................................................................. 87
Table 5-32 IPSec Parameter instruction............................................................................................................................ 89
Table 5-33 IPSec Parameter instruction............................................................................................................................ 90
Table 5-34 OpenVPN parameter instruction.................................................................................................................... 92
Table 5-35 Remote log parameter instruction................................................................................................................. 96
Table 5-36 Clock Parameter instruction............................................................................................................................ 97
Table 5-37 Account parameter instruction....................................................................................................................... 99
Table 5-38 Network Test Parameter instruction........................................................................................................... 100
Table 5-39 Base i nformation Parameter instruction .................................................................................................... 108
Table 5-40 LAN Parameter instruction............................................................................................................................ 108
Table 5-41 WAN Parameter instruction.......................................................................................................................... 110
Table 5-42 Modem Parameter instructi on ..................................................................................................................... 111
Table 5-43 Routing table Parameter instruction ........................................................................................................... 112

Hongdian Corporation
1
H8922 3G/4G Router User Manual
Figure Contents
Figure 1-1 Network structure.................................................................................................................................................5
Figure 2-1 H8922 3G/4G router appearance.......................................................................................................................7
Figure 2-2 H8922 3G/4G router views ..................................................................................................................................8
Figure 2-3 H8922 3G/4G router drawing .............................................................................................................................9
Figure 2-4 Front pannel...........................................................................................................................................................9
Figure 2-5 Back pannel ......................................................................................................................................................... 10
Figure 3-1 Pop out SIM slot................................................................................................................................................. 12
Figure 3-2 SIM/UIM card install.......................................................................................................................................... 12
Figure 3-3 Single Equipment Direct Connection .............................................................................................................. 13
Figure 3-4 Multiple Equipments Connection.................................................................................................................... 13
Figure 4-1 Local Area Connection....................................................................................................................................... 16
Figure 4-2 Connection properties....................................................................................................................................... 17
Figure 4-3 Internet protocol (TCP/IP) ................................................................................................................................ 17
Figure 4-4 Advanced TCP/IP Settings ................................................................................................................................. 19
Figure 4-5 TCP/IP address.................................................................................................................................................... 20
Figure 4-6 Connectivity check ............................................................................................................................................. 21
Figure 4-7 User identity page.............................................................................................................................................. 22
Figure 5-1 LAN window ........................................................................................................................................................ 24
Figure 5-2 WAN window ...................................................................................................................................................... 25
Figure 5-3 Modem window ................................................................................................................................................. 28
Figure 5-4 Modem page ....................................................................................................................................................... 29
Figure 5-5 Single module single SIM/dual module dual SIM......................................................................................... 32
Figure 5-6 Single module dual SIM..................................................................................................................................... 32
Figure 5-7 Advanced setting................................................................................................................................................ 33
Figure 5-8 AP mode configure interface ........................................................................................................................... 34
Figure 5-9 Station mode configure interface ................................................................................................................... 35
Figure 5-10 Station scan signal interface.......................................................................................................................... 35
Figure 5-11 Parameter select .............................................................................................................................................. 38
Figure 5-12 Add rule ............................................................................................................................................................. 39

Hongdian Corporation
2
H8922 3G/4G Router User Manual
Figure 5-13 Connection type window................................................................................................................................ 40
Figure 5-14 Link Backup....................................................................................................................................................... 42
Figure 5-15 DHCP................................................................................................................................................................... 44
Figure 5-16 ICMP Check tab ................................................................................................................................................ 46
Figure 5-17 ICMP adding page............................................................................................................................................ 47
Figure 5-18 DDNS configuration......................................................................................................................................... 49
Figure 5-19 SNMP configuration ........................................................................................................................................ 51
Figure 5-20 M2M configuration.......................................................................................................................................... 53
Figure 5-21 Timing configuration....................................................................................................................................... 54
Figure 5-22 To add timing task............................................................................................................................................ 55
Figure 5-23 Wake up configuration.................................................................................................................................... 57
Figure 5-24 GPS configuration............................................................................................................................................ 59
Figure 5-25 IP Filter tab........................................................................................................................................................ 61
Figure 5-26 IP filter “Input” type ........................................................................................................................................ 61
Figure 5-27 IP Filter “Forward” type .................................................................................................................................. 62
Figure 5-28 Domain filter tab .............................................................................................................................................. 64
Figure 5-29 Domain filter tab .............................................................................................................................................. 64
Figure 5-30 MAC Filter tab................................................................................................................................................... 65
Figure 5-31 MAC Fil ter configuration ................................................................................................................................ 66
Figure 5-32 NAT tab .............................................................................................................................................................. 67
Figure 5-33 DNAT rule configuration................................................................................................................................. 68
Figure 5-34 SNAT rule configuration.................................................................................................................................. 69
Figure 5-35 MASQ configuration........................................................................................................................................ 71
Figure 5-36 Static Routing Interface .................................................................................................................................. 72
Figure 5-37 Static Routing Interface .................................................................................................................................. 72
Figure 5-38 Policy Routing Interface.................................................................................................................................. 73
Figure 5-39 QoS interface.................................................................................................................................................... 75
Figure 5-40 RIP interface...................................................................................................................................................... 77
Figure 5-41 RIP route configuration interface.................................................................................................................. 78
Figure 5-42 OSPF Interface.................................................................................................................................................. 79
Figure 5-43 OSPF route configuration interface.............................................................................................................. 80
Figure 5-44 VPDN configuration......................................................................................................................................... 82
Figure 5-45 VPDN rule configuration................................................................................................................................. 82
Figure 5-46 L2TP tunnel status............................................................................................................................................ 83
Figure 5-47 Tunnel configuration....................................................................................................................................... 84
Figure 5-48 IPSec tab ............................................................................................................................................................ 86
Figure 5-49 IPSec phase 1 configuration........................................................................................................................... 87

Hongdian Corporation
3
H8922 3G/4G Router User Manual
Figure 5-50 IPSec phase 2 configuration........................................................................................................................... 89
Figure 5-51 IPSec configuration tab................................................................................................................................... 90
Figure 5-52 OpenVPN configuration page ........................................................................................................................ 92
Figure 5-53 Local Log tab ..................................................................................................................................................... 95
Figure 5-54 Remote Log tab ................................................................................................................................................ 96
Figure 5-55 “NTP” Time Synch. ........................................................................................................................................... 97
Figure 5-56 Manual Time Synch. Type............................................................................................................................... 97
Figure 5-57 Account tab....................................................................................................................................................... 99
Figure 5-58 Network Test Tab........................................................................................................................................... 100
Figure 5-59 Files tab............................................................................................................................................................ 101
Figure 5-60 Add an IP address........................................................................................................................................... 102
Figure 5-61 CFE mode upgrading ..................................................................................................................................... 103
Figure 5-62 CFE upgrading page....................................................................................................................................... 103
Figure 5-63 Backup setting page ...................................................................................................................................... 104
Figure 5-64 Factory setting page ...................................................................................................................................... 105
Figure 5-65 Patch operation.............................................................................................................................................. 106
Figure 5-66 Reboot /Refr esh ............................................................................................................................................. 107
Figure 5-67 Base Information tab..................................................................................................................................... 107
Figure 5-68 “LAN” info........................................................................................................................................................ 108
Figure 5-69 Static IP WAN status...................................................................................................................................... 109
Figure 5-70 DHCP WAN status .......................................................................................................................................... 109
Figure 5-71 PPPoE WAN status ......................................................................................................................................... 110
Figure 5-72 Modem Status page ...................................................................................................................................... 111
Figure 5-73 Routing table page......................................................................................................................................... 112
Figure 6-1 Wake up/trigger setting example.................................................................................................................. 115
Figure 6-2 Rules setting...................................................................................................................................................... 116
Figure 6-3 Parameter select setting 1.............................................................................................................................. 117
Figure 6-4 Parameter select setting 2.............................................................................................................................. 118
Figure 6-5 Build IPSec ......................................................................................................................................................... 119
Figure 6-6 IPSec Phase 1 .................................................................................................................................................... 119
Figure 6-7 IPSec Phase 2 .................................................................................................................................................... 120
Figure 6-8 IPSec ................................................................................................................................................................... 120
Figure 6-9 IPSec status........................................................................................................................................................ 121
Figure 6-10 Timing............................................................................................................................................................... 121
Figure 6-11 Router online.................................................................................................................................................. 122
Figure 6-12 Router off line................................................................................................................................................. 122
Figure 6-13 Router reboot ................................................................................................................................................. 122

Hongdian Corporation
4
H8922 3G/4G Router User Manual
1 Product Introduction
About this chapter
Chapter
Content
1.1 Overview
Simple introduction of H8922 3G/4G router
1.2 Product
Positioning
Product Positioning of H8922 3G/4G router
1.3 Function &
features
Unique function & features
1.4 Specification
Detail specification of this router
1.1 Overview
H8922 3G/4G router based on 3G/4G technology, except tradition router function like
VPN, firewall, NAT, SNMP, DHCP. H8922 support 3G/4G as WAN interface, provide up to
100Mbps WAN bandwidth and up t o 150Mbps Wi-Fi bandwidth. Plus, H8922 3G/4G
router support three modes: single module single SIM, single module dual SIM, dual
module dual SIM mode. The unique feature of H8922 3G/4G router is network online &
backup among WAN, WLAN, 3G/4G network. This feature makes H8922 could maximum
the network availability, reduce the possibility of network failure, to avoid the loss caused
by network error. Also, definable route table makes customers could assign bandwidth by
business type, full use the bandwidth and lower the net delay.
H8922 3G/4G router support Hongdian M2M management platform. By the management
platform, you can check running info of H8922 3G/4G router and remote config or remote
updates.

Hongdian Corporation
5
H8922 3G/4G Router User Manual
1.2 Product positioning
H8922 3G/4G router widely used in Telecom, economic, advertisement, traffic, and
environment protection business area.
For example, in economic area, H8922 3G/4G router connect server by IPSec & GRE to
ensure data security, and dual module online or dual module switch online ensured
network availability. All these technology ensured safe and reliable data transmission, and
minimize the probability of network disconnection, and maximize the usability of
economic business like ATM, POS .etc.
Figure 1-1 Network structure
1.3 Function & Features
Function
Dual module/WAN/Wi-Fi multiple network mode backup
VPN support, GRE over IPSec, IPsec over PPTP/L2TP
WAN port support PPPoE, static IP, DHCP client
LCP/ICMP/flow/heartbeat check, ensure network usability
SNMP network management, NTP support
Local & remote firmware update
Local & remote log check
Supports DNS proxy and Dynamic DNS (DDNS)
Supports timing operation
Supports LED status indication

Hongdian Corporation
6
H8922 3G/4G Router User Manual
Available cellular network
LTE FDD: B1,B2,B4,B5,B7,B8,B12
LTE TDD: B38
LTE FDD: B1,B3,B7,B8,B20
LTE TDD: B40
LTE FDD: B1,B3,B7,B8,B20
LTE FDD: B2,B4,B5,B13,B17,B25
LTE TDD: B38,B39,B40
LTE FDD: B7
LTE FDD: B1/3/5/7/8/18/19/28
LTE TDD: B38/39/40/41
LTE FDD: B1/3/8/18/19/26
HSPA+/HSUPA/HSDPA/WCDMA/UMTS 2100/1900/900/850/800MHz
EDGE/GPRS/GSM 1900/1800/900/850MHz
CDMA 2000/EVDO Rev.A 800/1900MHz
1.4 Specification
Interface
4×10/100Mb LAN interface
1×10/100Mb WAN interface
2× SMA-K antenna interface
2× SMA-K antenna interface (Wi -Fi, optional)
2× Standard SIM/R-UIM interface
1× Standard DC power interface
Power supply
Voltage: +5V ～+36VDC
Dual module Idle: 204mA@12V DC
Dual module communication: 330mA@12V DC
Others
Dimension: 194mm x 105mm x 25mm (not including antenna)
Weight: 540g
Operation temperature: -30~+70℃
Store temperature: -40~+85℃
Related humidity: <95% (non-condensing)
Guarantee: one year

Hongdian Corporation
7
H8922 3G/4G Router User Manual
2 Product structure
About this chapter
Chapter
Content
2.1 Hardware
H8922 3G/4G router hardware.
2.2 Structure
Structure of H8922 3G/4G router.
2.1 Hardware
2.1.1 Appearance & Size
Appearance
Figure 2-1 H8922 3G/4G router appearance

Hongdian Corporation
8
H8922 3G/4G Router User Manual
Size
Table 2-1 H8922 3G/4G router size
Model
Dimension (mm)
Interface
H8922
3G/4G
router
176×105×25
4×10/100Mb LAN interface
1×10/100Mb WAN interface
4× SMA-K 3G/4G antenna interface
2× SMA-K Wi-Fi antenna interface
2× Standard SIM/R-UIM interface
1× Standard DC power interfac
H8922 3G/4G router appearance as Figure 2-2, Figure 2-3 shows
Figure 2-2 H8922 3G/4G router views

Hongdian Corporation
9
H8922 3G/4G Router User Manual
Figure 2-3 H8922 3G/4G router drawing
2.1.2 Accessories
Table 2-2 H8922 3G/4G router accessories
Accessories name
Number
Note
H8922 3G/4G router
1 pcs
CD-ROM
1 pcs
Optional
3G/4G antenna
1 or 2 pcs
According to module number inside
Wi-Fi antenna
1 pcs
Optional
GPS antenna
1 pcs
Optional
RJ45 cable
1 pcs
Mounting
1 pair
Optional
Certificate and warranty
card
1 pcs
+12V power adapter
1 pcs
2.2 Structure
Figure 2-4 Front pannel
