Nortel 1500 Series User manual

Getting Started with the
Contivity Extranet
Switch 1500 Series
Part No. 306009-B Rev 00
February 2000

306009-A Rev 00 ii
Accuracy Notice
The products and specifications, configurations, and other technical information regarding the products con-
tained in this document are subject to change without notice. All statements, technical information, and recom-
mendations contained in this document are believed to be accurate and reliable but are presented without
warranty of any kind, expressed or implied, and users take full responsibility for their application of any prod-
ucts specified in this document.
Copyright © 2000 Nortel Networks, Inc.
All rights reserved. Printed in the USA. February 2000.
The information in this document is subject to change without notice. The statements, configurations, technical
data, and recommendations in this document are believed to be accurate and reliable, but are presented with-
out express or implied warranty. Users must take full responsibility for their applications of any products spec-
ified in this document. The information in this document is proprietary to Nortel Networks, Inc.
The software described in this document is furnished under a license agreement and may only be used in ac-
cordance with the terms of that license. A summary of the Software License is in Appendix B.
Trademarks
Nortel Networks, Nortel Networks Extranet Switch 1500, Contivity, Extranet Ready, the Extranet Ready logo,
Personal Extranets, Infrastructure for Extranets, and the Nortel Networks logo are trademarks of Nortel Net-
works, Inc., Microsoft, Windows 95, Windows 98, and Windows NT are registered trademarks of Microsoft Cor-
poration.
The Microsoft Internet Explorer logo is a trademark or registered trademark of Microsoft Corporation in the
United States and/or other countries.
:
This product contains RSA Software.
This product incorporates MPPCTM compression from Hi/fnR.
All other trademarks and registered trademarks are the property of their respective owners.
Restricted Rights Legend
Use, duplication, or disclosure by the United States Government is subject to restrictions as set forth in sub-
paragraph (c)(1)(ii) of the Rights in Technical Data and Computer Software clause at DFARS 252.227-7013.
Notwithstanding any other license agreement that may pertain to, or accompany the delivery of, this computer
software, the rights of the United States Government regarding its use, reproduction, and disclosure are as set
forth in the Commercial Computer Software-Restricted Rights clause at FAR 52.227-19.

iii
Contents
Preface
Conventions .....................................................................................................................viii
Documentation ..........................................................................................................viii
Text ............................................................................................................................. ix
User Interface ............................................................................................................. ix
Related Publications ..........................................................................................................x
Nortel Networks Technical Publications ............................................................................ xi
Nortel Networks Customer Service ..................................................................................xii
Chapter 1
Introducing the Contivity Extranet Switch
The Switch ......................................................................................................................1-1
Components List ......................................................................................................1-4
Chapter 2
Preparing Your Site
Selecting a Site ...............................................................................................................2-1
Safety Guidelines .....................................................................................................2-2
Switch Power ON/OFF .............................................................................................2-2
Check the Voltage Switch .........................................................................................2-2
External Vent Cooling and Airflow ............................................................................2-3
Chapter 3
Cabling the Switch
Connecting the Cables ...................................................................................................3-2
Power Cord Requirements .......................................................................................3-3
Current Rating ..........................................................................................................3-3
Wall Outlet Connector ..............................................................................................3-3
Power Supply Connector ..........................................................................................3-3
Cord Length and Flexibility .......................................................................................3-3

iv
LAN Interface Connections .............................................................................................3-4
LAN Speed Selection ...............................................................................................3-4
Connector Pinouts ....................................................................................................3-4
Single V.35 WAN Interface (Optional) .............................................................................3-5
T1 CSU/DSU WAN Interface (Optional) .........................................................................3-7
Serial Interface Cable (Optional) ....................................................................................3-8
Understanding the LEDs ................................................................................................3-9
Chapter 4
Assigning a System Identity
Startup Configuration Requirements ..............................................................................4-2
Management IP Address ..........................................................................................4-2
Subnet Mask ............................................................................................................4-2
Default Gateway (Optional) ......................................................................................4-2
IP Address Configuration Utility ......................................................................................4-3
Requirements ...........................................................................................................4-3
Running the IP Configuration Utility .........................................................................4-3
Serial Interface Configuration .........................................................................................4-6
Prerequisites ............................................................................................................4-6
Procedure .................................................................................................................4-7
Chapter 5
Managing the Switch
Recommended Web Browsers .......................................................................................5-1
Platforms Supported ................................................................................................5-1
Browser Versions .....................................................................................................5-1
Display Setting .........................................................................................................5-1
Preparing for Configuration .............................................................................................5-2
Extranet Switch Welcome Display ..................................................................................5-3
Quick Start ...............................................................................................................5-5
Guided Configuration ...............................................................................................5-5
Manage Extranet Switch ..........................................................................................5-5
Registration ..............................................................................................................5-5
Notebook ..................................................................................................................5-5
Logging in and Supplying a Password ............................................................................5-6

v
Quick Start Configuration Prerequisites .........................................................................5-7
Required Environment .............................................................................................5-8
Prerequisites ............................................................................................................5-9
Post Configuration Testing .......................................................................................5-9
Configuration ................................................................................................................5-10
LAN/WAN Interfaces ..............................................................................................5-11
PPTP Users ...........................................................................................................5-12
Administrator ..........................................................................................................5-13
Date and Time ........................................................................................................5-14
Automatic Backup .........................................................................................................5-14
Chapter 6
Extranet Access Client Installation
Windows 95 ....................................................................................................................6-1
Windows 98 and Windows NT 4.0 ..................................................................................6-3
Appendix A
Specifications and Compliance
Physical ......................................................................................................................... A-1
Operating Environment .................................................................................................. A-1
Declaration of the Manufacturer or Importer .................................................................. A-1
Safety Compliance .................................................................................................. A-2
Electromagnetic Compatibility (EMC) ..................................................................... A-2
Harmonics ............................................................................................................... A-2
Appendix B
Special Notices

vii
Preface
This guide takes you through the necessary tasks to get your Nortel NetworksTM
Contivity Extranet Switch 1500TM Series up and running. Topics include:
• Introducing the Contivity Extranet Switch
• Preparing Your Site
• Assigning a System Identity
• Managing the Switch
• Installing the Extranet Access Client
• Rack Mounting
• Changing Hardware Configurations
Complete details for configuring and monitoring the Switch are in Managing the
Contivity Extranet Switch.

Getting Started with the Contivity Extranet Switch 1500 Series
viii
Conventions
This guide refers to the Contivity Extranet Switch as the CES or the Switch. It
assumes that you are familiar with Web browsers and their general operation.
Documentation
This document uses the following conventions to distinguish among notes of
varying importance:
TIP: Good idea. A Tip is something that might be considered a good idea,
whether for security reasons or because it will save you time or effort.
IMPORTANT: Take particular notice. Important references contain concepts or
information that has bearing on other fields or situations (i.e., what
you do here affects other fields or options elsewhere).
Note: Take notice. Notes contain helpful suggestions or references to
materials contained in this document.
CAUTION: Be careful. In this situation, you might do something that
could result in damage to the equipment or loss of data.
WARNING: Danger. You are in a situation that could cause bodily
injury. Before working on equipment, beware of the hazards
involved with electrical circuitry and standard practices for
preventing accidents, such as disconnecting equipment from
its power source.

Preface
ix
Text
This guide uses the following text conventions:
User Interface
Help Button
Click the Help button that is located in the upper right of displays to learn about
fields on a given page. Where appropriate, the information provides cause and
effect of an action; otherwise, it might offer troubleshooting steps.
italic text Indicates new terms and book titles.
screen text Indicates system output, for example, prompts and
system messages.
Example:
Set Nortel Networks Trap Monitor Filters
arrow ( →) Shows menu paths.
Example: Services →Available identifies the Switch
services that are available.

Getting Started with the Contivity Extranet Switch 1500 Series
x
Related Publications
The following table lists the associated documentation that you will need to
configure and manage your Switch and describes the document’s objectives.
Related Publications
Document Objective
Contivity Extranet Switch
Release Notes
Provides the latest information, including known
problems, workarounds, and special considerations.
Managing the
Contivity Extranet Switch
(included on the CD)
Provides complete details to configure, monitor, and
troubleshoot your Switch.

Preface
xi
Nortel Networks Technical Publications
You can print Nortel Networks technical manuals and release notes free, directly
from the Internet. Go to support.baynetworks.com/library/tpubs/. Find the Nortel
Networks product for which you need documentation. Then locate the specific
category and model or version for your hardware or software product. Using
Adobe Acrobat Reader, you can open the manuals and release notes, search for the
sections you need, and print them on most standard printers. You can download
Acrobat Reader free from the Adobe Systems Web site, www.adobe.com.
You can purchase Nortel Networks documentation sets, CDs, and selected
technical publications through the Nortel Networks Collateral Catalog. The
catalog is located at support.baynetworks.com/catalog.html:
• The “CD ROMs” section lists available CDs.
• The “Guides/Books” section lists books on technical topics.
• The “Technical Manuals” section lists available printed
documentation sets.
Make a note of the part numbers and prices of the items that you want to order.
Use the “Marketing Collateral Catalog description” link to place an order and to
print the order form.

Getting Started with the Contivity Extranet Switch 1500 Series
xii
Nortel Networks Customer Service
If you purchased a service contract for your Nortel Networks product from a
distributor or authorized reseller, contact the technical support staff for that
distributor or reseller for assistance.
If you purchased a Nortel Networks service program, contact one of the following
Nortel Networks Technical Solutions Centers:
Technical Solutions Center Telephone Number
United States and Canada 800-2LANWAN (800-252-6926);
enter Express Routing Code
(ERC): 176#
Valbonne, France 33-4-92-96-69-68
Sydney, Australia 61-2-9927-8800
Tokyo, Japan 81-3-5402-7041

1-1
Chapter 1
Introducing the Contivity Extranet Switch
The Switch
The Nortel Networks Contivity Extranet Switch 1500 Series provides scalable,
secure, manageable extranet access for up to 100 simultaneous users across the
Public Data Network (PDN). The Contivity Extranet Switch 1500 Series consists
of the 1500, 1510, 1520, and 1530 models.
The Switch includes the most popular tunneling protocols, IP Security (IPsec),
Point-to-Point Tunneling Protocol (PPTP), Layer 2 Forwarding Tunneling
Protocol (L2TP), and Layer 2 Forwarding (L2F). IPsec uses digital certificates,
password-based keys, and tokens for authentication; PPTP, L2TP, and L2F use
Challenge Handshake Authentication Protocol (CHAP) or Password
Authentication Protocol (PAP) for authentication. The PPTP implementation for
the Switch supports MS-CHAP authentication with 56- to 128-bit key encryption.
Figure 1-1 shows an intranet and an extranet.

Getting Started with the Contivity Extranet Switch 1500 Series
1-2
Figure 1-1. An Intranet and the Internet Make Up an Extranet
The Switch provides more security than traditional remote access schemes due to
the combination of authorization, authentication, privacy, and access control on a
per user basis. Additionally, the IPsec protocol and related Internet Security
Association & Key Management Protocol (ISAKMP) and the Oakley key
establishment protocol support further enhance the security offering.
For authentication and access control, the Switch supports an internal or external
Lightweight Directory Access Protocol (LDAP) server and external Remote
Authentication Dial-In User Service (RADIUS) servers.
Contivity
Extranet
Switch
Reseller
Cable or DSL
LAN
56K
Modem
ISDN
Internet
Intranet
Extranet
Partner
Remote
Employee
Authentication
Server
E-Mail
Server
NT
Server
Firewall Router
ISP POP
ISP POP
ISP POP
ISP POP

Introducing the Contivity Extranet Switch
1-3
To restrict access, the Switch uses packet filtering based on Protocol ID,
Direction, Source and Destination IP addresses, Source and Destination Ports,
and TCP connection establishment. Additionally, Nortel Networks provides
you with a set of predefined filters that you can use either directly or tailor to
your network needs.
The unique quality of service (QoS) mechanisms include call admission
and packet forwarding priorities, and support for Resource ReSerVation
Protocol (RSVP).
The HTML and Java Web management interface allows different Switch
administrators to have different access rights, including configuration, status, and
monitoring. The Switch offers RADIUS accounting support and extensive
logging, including events, system, configuration, and security logs.
Figure 1-2 shows a front view of the Switch.
Figure 1-2. The Switch, Front View
The Extranet Switch 1500 Series must be placed only in a horizontal position.

Getting Started with the Contivity Extranet Switch 1500 Series
1-4
Components List
The following table lists all of the components and accessories of the Switch.
Examine the product packaging to be sure that you have all the necessary
components.
Note that the Extranet Switch 1500 Series has no user-serviceable components.
If for any reason you have not received all of the materials listed above, contact
Nortel Networks Customer Service.
Description Quantity
Extranet Switch 1500
Series 1
Power Cord (ordered separately) 0
Molded Serial Cable DB9/DB25-to-DB9/DB25 1
WAN V.35 Cable (only with 1520) 1
Contivity Extranet Switch CD-ROM 1
Recovery Diskette 1
IP Address Configuration Utility Diskette 1
Getting Started Guide (this book) 1
Release Notes 1

2-1
Chapter 2
Preparing Your Site
This chapter provides information that you should read before you begin cabling
and configuring the Contivity Extranet Switch 1500 Series. This information
includes selecting an appropriate site, safety guidelines, information on the power
cord, voltage settings, and external vent cooling and airflow recommendations.
Selecting a Site
This Switch is designed to operate reliably in a typical office environment. You
should select a site that meets the following criteria:
• Has a desktop or surface that is off the floor.
• Has access to a grounded, three-pronged power outlet.
- Uses a NEMA 5-15R outlet for 100-120 VAC or a NEMA 6-15R
outlet for 200-240 VAC (US and Canada).
- Uses a three-pronged power outlet that is applicable for the region’s
electrical code (elsewhere).
• Remains dust free and clean.
• Is away from heat sources and is well ventilated.
• Allows adequate clearance for cooling and airflow -- about 10 centimeters
(3.93 inches) in back, 5 centimeters (1.96 inches) on each side, and 10
centimeters (3.93 inches) in front.

Getting Started with the Contivity Extranet Switch 1500 Series
2-2
Safety Guidelines
Hazardous Conditions Inside the Switch
Hazardous voltage, current, and energy levels are present inside the Switch. Do
not open the Switch; there are no user-serviceable parts inside. Contact Nortel
Networks Customer Support for service.
Switch Power ON/OFF
The On/Off power button on the front panel of the Switch does not completely
eliminate (turn off) the AC power from the Switch. To eliminate AC power from
the Switch completely, unplug the AC power cord from the power supply or wall
outlet.
Check the Voltage Switch
Before you connect the power cord to the back panel of the Switch, ensure that the
voltage selector switch is correctly set to the appropriate AC line source voltage.
For line voltages between:
• 100 and 127 VAC, set the power supply line voltage selector to
115V (115 VAC).
• 200 and 240 VAC, set the power supply line voltage selector to
230V (230 VAC).
Verify that the correct voltage (115V or 230V) is visible on the switch. See Figure
3-1 on page 3-2.
WARNING: Incorrectly setting the voltage will damage the
power supply. See Figure 3-1 on page 3-2.
CAUTION: Make sure that the power service connection is through an
outlet that is properly grounded.

Preparing Your Site
2-3
External Vent Cooling and Airflow
The Switch has external vents for cooling and air flow on:
• The chassis bezel
• The back panel
• On each of the side panels
Keep the side vents clear of obstruction to ensure proper cooling of the Switch.
