Shenzhen Mindray Bio-Medical Electronics DC-80S User manual

DC-80/DC-80S/DC-80 PRO/DC-80
EXP/DC-85
Diagnostic Ultrasound System
Operator’s Manual
[Basic Volume]

i
Contents
Contents............................................................................................................................... i
Intellectual Property Statement...................................................................................................... I
Responsibility on the Manufacturer Party....................................................................................... I
Warranty...................................................................................................................................... II
Exemptions............................................................................................................................. II
Customer Service Department ............................................................................................... III
Important Information..................................................................................................................IV
About This Manual.......................................................................................................................V
Notation Conventions...................................................................................................................V
Operator’s Manuals......................................................................................................................V
Hardcopy Manuals.......................................................................................................................V
Software Interfaces in This Manual..............................................................................................VI
Conventions................................................................................................................................VI
1Safety Precautions....................................................................................................1-1
1.1 Safety Classification........................................................................................................ 1-1
1.2 Meaning of Signal Words................................................................................................. 1-2
1.3 Meaning of Safety Symbols............................................................................................. 1-2
1.4 Safety Precautions.......................................................................................................... 1-3
1.5 Latex Alert..................................................................................................................... 1-10
1.6 Warning Labels ..............................................................................................................1-11
2System Overview......................................................................................................2-1
2.1 Intended Use................................................................................................................... 2-1
2.2 Contraindication.............................................................................................................. 2-1
2.3 Product and Model Code................................................................................................. 2-1
2.4 Product Specifications..................................................................................................... 2-2
2.5 System Configuration...................................................................................................... 2-3
2.6 Introduction of Each Unit ................................................................................................. 2-9
2.7 I/O Panel........................................................................................................................2-11
2.8 Power Supply Panel...................................................................................................... 2-12
2.9 Physio Panel (ECG)...................................................................................................... 2-14
2.10 Operation Panel............................................................................................................ 2-15
2.11 Symbols........................................................................................................................ 2-23
3System Preparation ..................................................................................................3-1
3.1 Move / Position the System ............................................................................................. 3-1
3.2 Connecting Power Cord & Protective Grounding.............................................................. 3-2
3.3 Monitor Adjustment.......................................................................................................... 3-5
3.4 Control Panel PositionAdjustment................................................................................... 3-8
3.5 Connecting a Probe......................................................................................................... 3-9
3.6 Connecting Peripheral Devices...................................................................................... 3-10
3.7 Basic Screen & Operation ............................................................................................. 3-15
4Exam Preparation .....................................................................................................4-1
4.1 Patient Information.......................................................................................................... 4-1
4.2 Select Exam Mode and Probe......................................................................................... 4-9
4.3 Select the Imaging Mode............................................................................................... 4-10
4.4 Activate& Continue an Exam......................................................................................... 4-10
4.5 Pause & End an Exam .................................................................................................. 4-10

ii
5Image Optimization...................................................................................................5-1
5.1 Imaging Mode................................................................................................................. 5-1
5.2 B Mode Image Optimization ............................................................................................ 5-4
5.3 M Mode Image Optimization...........................................................................................5-10
5.4 Color Mode Image Optimization .....................................................................................5-13
5.5 Power Mode Image Optimization....................................................................................5-18
5.6 PW/CW Doppler Mode...................................................................................................5-20
5.7 Color M Mode ................................................................................................................5-26
5.8 Anatomical M Mode........................................................................................................5-27
5.9 TDI.................................................................................................................................5-30
5.10 3D/4D ............................................................................................................................5-34
5.11 iScape View (Real-time Panoramic Imaging)..................................................................5-75
5.12 Contrast Imaging............................................................................................................5-79
5.13 Elastography..................................................................................................................5-86
5.14 Stress Echo....................................................................................................................5-95
5.15 Tissue Tracking Quantitative Analysis (QA)...................................................................5-103
6Display & Cine Review..............................................................................................6-1
6.1 Splitting Display............................................................................................................... 6-1
6.2 Image Magnification........................................................................................................ 6-1
6.3 Freeze / Unfreeze the Image........................................................................................... 6-2
6.4 Cine Review.................................................................................................................... 6-3
6.5 Image Compare .............................................................................................................. 6-6
6.6 Cine Saving..................................................................................................................... 6-7
6.7 Setting Cine Length......................................................................................................... 6-8
7Physiological Signal .................................................................................................7-1
7.1 ECG................................................................................................................................ 7-2
7.2 PCG................................................................................................................................ 7-4
7.3 Respiratory Wave............................................................................................................ 7-6
8Measurement.............................................................................................................8-1
8.1 Basic Operations............................................................................................................. 8-1
8.2 General Measurements................................................................................................... 8-2
8.3 Application Measurement................................................................................................ 8-4
8.4 Measurement Accuracy................................................................................................... 8-5
9Comments and Body Marks .....................................................................................9-1
9.1 Comments....................................................................................................................... 9-1
9.2 Voice Comment............................................................................................................... 9-6
9.3 Body Mark....................................................................................................................... 9-7
10 Patient Data Management.......................................................................................10-1
10.1 Patient Information Management....................................................................................10-1
10.2 Image File Management.................................................................................................10-1
10.3 Report Management.......................................................................................................10-7
10.4 iStation - Patient Data Management................................................................................10-9
10.5 iStorage........................................................................................................................10-11
10.6 Print.............................................................................................................................10-11
10.7 Backup Files through DVD Drive..................................................................................10-12
10.8 Patient Task Management............................................................................................10-13
10.9 Administration..............................................................................................................10-14
11 DICOM/HL7 ..............................................................................................................11-1

iii
11.1 DICOM Preset................................................................................................................11-1
11.2 Verify Connectivity........................................................................................................11-10
11.3 DICOM Services...........................................................................................................11-10
11.4 DICOM Media Storage .................................................................................................11-13
11.5 Structured Report.........................................................................................................11-14
11.6 DICOM Task Management............................................................................................11-15
12 Setup........................................................................................................................12-1
12.1 System Preset............................................................................................................... 12-1
12.2 ExamMode Preset......................................................................................................... 12-7
12.3 Measure Preset............................................................................................................. 12-7
12.4 Comment Preset ........................................................................................................... 12-8
12.5 iWorks Preset................................................................................................................ 12-8
12.6 Stress Echo................................................................................................................... 12-9
12.7 DICOM/HL7 .................................................................................................................. 12-9
12.8 Print Preset................................................................................................................... 12-9
12.9 Network Preset............................................................................................................ 12-10
12.10 Maintenance ................................................................................................................12-11
12.11 System Information ..................................................................................................... 12-12
13 Probes and Biopsy .................................................................................................13-1
13.1 Probes .......................................................................................................................... 13-1
13.2 Biopsy Guide............................................................................................................... 13-17
13.3 Middle Line.................................................................................................................. 13-46
14 DVR Recording .......................................................................................................14-1
14.1 DVR Recording............................................................................................................. 14-1
14.2 Send Image................................................................................................................... 14-1
14.3 DVR Video Replay ........................................................................................................ 14-2
15 Acoustic Output......................................................................................................15-1
15.1 Concerns with Bioeffects............................................................................................... 15-1
15.2 Prudent Use Statement.................................................................................................. 15-1
15.3 ALARA Principle (As LowAs Reasonably Achievable) ................................................... 15-1
15.4 MI/TI Explanation .......................................................................................................... 15-2
15.5 Acoustic Power Setting.................................................................................................. 15-3
15.6 Acoustic Power Control................................................................................................. 15-4
15.7 Acoustic Output............................................................................................................. 15-4
15.8 Measurement Uncertainty.............................................................................................. 15-6
15.9 References for Acoustic Power and Safety .................................................................... 15-6
16 EMC Guidance and Manufacturer's Declaration...................................................16-1
17 System Maintenance ..............................................................................................17-1
17.1 Daily Maintenance......................................................................................................... 17-1
17.2 Troubleshooting............................................................................................................. 17-6
Appendix A Wireless LAN ........................................................................................A-1
Appendix B Ultrasound Gel Warmer........................................................................B-1
Appendix C Battery...................................................................................................C-1
Appendix D iWorks (Auto Workflow Protocol)........................................................D-1
Appendix E Barcode Reader....................................................................................E-1
Appendix F Electrical Safety Inspection .................................................................F-1

I
© 2018 Shenzhen Mindray Bio-Medical Electronics Co., Ltd. All rights Reserved.
For this Operator’s Manual, the issue date is 2018-11.
Intellectual Property Statement
SHENZHEN MINDRAY BIO-MEDICAL ELECTRONICS CO., LTD. (hereinafter called Mindray)
owns the intellectual property rights to this Mindray product and this manual. This manual may
refer to information protected by copyright or patents and does not convey any license under the
patent rights or copyright of Mindray, or of others.
Mindray intends to maintain the contents of this manual as confidential information. Disclosure of
the information in this manual in any manner whatsoever without the written permission of Mindray
is strictly forbidden.
Release, amendment, reproduction, distribution, rental, adaptation, translation or any other
derivative work of this manual in any manner whatsoever without the written permission of Mindray
is strictly forbidden.
, and are the trademarks, registered or otherwise, of Mindray
in China and other countries. All other trademarks that appear in this manual are used only for
informational or editorial purposes. They are the property of their respective owners.
This posting serves as notice under 35 U.S.C. §287(a) for Mindray patents:
http://www.mindrayna.com/patents.
Responsibility on the Manufacturer Party
Contents of this manual are subject to change without prior notice.
All information contained in this manual is believed to be correct. Mindray shall not be liable for
errors contained herein or for incidental or consequential damages in connection with the
furnishing, performance, or use of this manual.
Mindray is responsible for the effects on safety, reliability and performance of this product, only if:
all installation operations, expansions, changes, modifications and repairs of this product
are conducted by Mindray authorized personnel;
the electrical installation of the relevant room complies with the applicable national and
local requirements; and
the product is used in accordance with the instructions for use.
Note
This equipment must be operated by skilled/trained clinical professionals.
Warning
It is important for the hospital or organization that employs this equipment to carry out a
reasonable service/maintenance plan. Neglect of this may result in machine breakdown or
personal injury.

II
Warranty
THIS WARRANTY IS EXCLUSIVE AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED
OR IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY OR FITNESS FOR ANY
PARTICULAR PURPOSE.
Exemptions
Mindray's obligation or liability under this warranty does not include any transportation or other
charges or liability for direct, indirect or consequential damages or delay resulting from the
improper use or application of the product or the use of parts or accessories not approved by
Mindray or repairs by people other than Mindray authorized personnel.
This warranty shall not extend to:
Malfunction or damage caused by improper use or man-made failure.
Malfunction or damage caused by unstable or out-of-range power input.
Malfunction or damage caused by force majeure such as fire and earthquake.
Malfunction or damage caused by improper operation or repair by unqualified or
unauthorized service people.
Malfunction of the instrument or part whose serial number is not legible enough.
Others not caused by instrument or part itself.

III
Customer Service Department
Manufacturer:
Shenzhen Mindray Bio-Medical Electronics Co., Ltd.
Address:
Mindray Building, Keji 12th Road South, High-tech industrial park,
Nanshan, Shenzhen 518057,P.R.China
Website:
www.mindray.com
E-mail Address:
[e-mail]
Tel:
[phone]
Fax:
[phone]
Manufacturer:
Mindray DS USA, Inc.
Address:
800 MacArthur Blvd.
Mahwah, NJ 07430-0619 USA
Tel:
[phone]
Toll Free:
[phone]
Fax:
[phone]

IV
Important Information
1. It is the customer’s responsibility to maintain and manage the system after delivery.
2. The warranty does not cover the following items, even during the warranty period:
(1) Damage or loss due to misuse or abuse.
(2) Damage or loss caused by Acts of God such as fires, earthquakes, floods, lightning, etc.
(3) Damage or loss caused by failure to meet the specified conditions for this system, such as
inadequate power supply, improper installation or environmental conditions.
(4) Damage or loss due to use of the system outside the region where the system was
originally sold.
(5) Damage or loss involving the system purchased from a source other than Mindray or its
authorized agents.
3. This system shall not be used by persons other than fully qualified and certified medical
personnel.
4. DO NOT make changes or modifications to the software or hardware of this system.
5. In no event shall Mindray be liable for problems, damage, or loss caused by relocation,
modification, or repair performed by personnel other than those designated by Mindray.
6. The purpose of this system is to provide physicians with data for clinical diagnosis. It is the
physician’s responsibility for diagnostic procedures. Mindray shall not be liable for the results
of diagnostic procedures.
7. Important data must be backed up on external memory media.
8. Mindray shall not be liable for loss of data stored in the memory of this system caused by
operator error or accidents.
9. This manual contains warnings regarding foreseeable potential dangers, but you shall always
be alert to dangers other than those indicated as well. Mindray shall not be liable for damage
or loss that results from negligence or from ignoring the precautions and operating instructions
described in this operator’s manual.
10. If the manager for this system is changed, be sure to hand over this operator’s manual to the
new manager.

V
About This Manual
This operator’s manual describes the operating procedures for this diagnostic ultrasound system
and the compatible probes. To ensure safe and correct operations, carefully read and understand
the manual before operating the system.
Notation Conventions
In this operator’s manual, the following words are used besides the safety precautions (refer to
“Safety Precautions”). Please read this operator’s manual before using the system.
NOTE:
Indicates information of interest to users of this system as to exceptional conditions or
operating procedures.
CAUTION:
The diagnostic ultrasound system is not intended for ophthalmic use. Its
use in this clinical specialty is contraindicated.
U.S.A. Federal Law restricts this device to sale by or on the order of a
physician.
Operator’s Manuals
You may receive multi-language manuals in compact disc or paper. Please refer to English manual
for latest information and register information.
The content of the operator manual, such as screens, menus or descriptions, may be different from
what you see in your system. The content varies depending upon the software version, options
and configuration of the system.
Hardcopy Manuals
Operator’s Manual [Basic Volume]
Describes the basic functions and operations of the system, safety precautions, exam
modes, imaging modes, preset, maintenance and acoustic output, etc.
Operator’s Manual [Advanced Volume]
Operator’s Manual [Acoustic Power Data and Surface Temperature Data]
Contains data tables of acoustic output for transducers.
Operation Note
Contains quick guide for basic operations of the system.
NOTE:
Manuals on CD are the manuals translated into languages other than English
according to the English manuals.
If you find that the contents of the manuals on CD are NOT consistent with the system
or English manuals, refer ONLY to the corresponding English manuals.
The accompanying manuals may vary depending upon the specific system you
purchased. Please refer to the packing list.

VI
Software Interfaces in This Manual
Depending on the software version, preset settings and optional configuration, the actual
interfaces may be different from those in this manual.
Conventions
In this manual, these conventions are used to describe the buttons on the control panel, the items
in menu, buttons in dialog box and some basic operations:
<Buttons>: the angular bracket indicates buttons, knobs and other controls on control
panel or on the keyboard.
[Items in menu or buttons in dialog box]: the square bracket indicates items in menu, on
the touch screen or buttons in dialog box.
Click [Items or Buttons]: move the cursor to the item or button and press <Set>.
Touch [Items or Buttons]: touch the item on the touch screen.
[Items in Menu] →[Items in Submenu]: select a submenu item following the path.

Safety Precautions 1-1
1 Safety Precautions
1.1 Safety Classification
According to the type of protection against electric shock:
CLASS I EQUIPMENT
According to the degree of protection against electric shock:
Type-BF applied part
According to the disinfection and sterilization method(s) recommended by manufacturer:
The devices recommended by the manufacturer.
The device equipped with the applied part of defibrillation protection:
The device is not equipped with the applied part of defibrillation protection.
Persistent installation or non-persistent installation:
Non-persistent installation
According to the degree of protection against harmful ingress of water:
The main unit and ECG belong to IPX0
Probes belong to IPX7
Footswitch belongs to IP68
According to the degree of safety of application in the presence of a FLAMMABLE
ANESTHETIC MIXTURE WITH AIR or WITH OXYGEN OR NITROUS OXIDE
EQUIPMENT not suitable for use in the presence of a FLAMMABLEANESTHETIC MIXTURE
WITH AIR or WITH OXYGEN OR NITROUS OXIDE
According to the mode of operation:
CONTINUOUS OPERATION

1-2 Safety Precautions
1.2 Meaning of Signal Words
In this manual, the signal words DANGER, WARNING, CAUTION, NOTE
and Tip are used regarding safety and other important instructions. The signal words and their
meanings are defined as follows. Please understand their meanings clearly before reading this
manual.
Signal word
Meaning
DANGER
Indicates an imminently hazardous situation that, if not avoided, will
result in death or serious injury.
WARNING
Indicates a potentially hazardous situation that, if not avoided, could
result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation that, if not avoided, may
result in minor or moderate injury.
NOTE
Indicates a potentially hazardous situation that, if not avoided, may result in
property damage.
Description
Important information that helps you use the system more effectively.
1.3 Meaning of Safety Symbols
Symbol
Description
Type-BF applied part
The ultrasound probes connected to this system are type-BF applied parts.
The ECG leads applied on this system are type-BF applied parts.
Caution!
General warning sign.
Patient/user infection due to contaminated equipment. Be careful when
performing the cleaning, disinfection and sterilization.
Patient injury or tissue damage from ultrasound radiation. It is required to
practiceALARA when operating ultrasound system.

Safety Precautions 1-3
1.4 Safety Precautions
Please observe the following precautions to ensure patient and operator’s safety when using this
system.
DANGER:
Do not operate this system and probes in an atmosphere containing
flammable gasses or liquids such as anesthetic gasses, hydrogen,
and ethanol, because there is danger of explosion.
WARNING:
1.
Do connect the power plug of this system to wall receptacles that
meet the ratings indicated on the rating nameplate. If adapters or
multifunctional receptacles are used, it may cause the leakage
current to exceed the safety requirement.
2.
In the environment that patient is 1.5 meters around, connect
peripherals to the auxiliary power outlet which is capable of
isolation protection, or power the peripherals by auxiliary output
cable or isolation transformer complied with IEC 60601-1-1:2005 or
the power input of the same safety level.
3.
DO NOT use power supply of different phases to power
peripherals, like power supply of air-conditioning.
4.
When using peripherals not powered by the auxiliary output of
the ultrasound system, or using peripherals other than permitted
by Mindray, make sure the overall leakage current of peripherals
and the ultrasound system meets the requirement of the local
medical device electrical regulation (like enclosure leakage
current should be no more than 500uAof IEC 60601-1-1:2005),
and the responsibility is held by the user.
5.
Connect the grounding conductor before turning ON the system.
Disconnect the grounding cable after turningOFF the system.
Otherwise, electric shock may result.
6.
For the connection of power and grounding, follow the appropriate
procedures described in this operator’s manual. Otherwise, there is
risk of electric shock. Do not connect the grounding cable toa gas
pipe or water pipe; otherwise, improper grounding may result or a
gas explosion may occur.
7.
Before cleaning the system, disconnect the power cord from the
outlet. Otherwise, system failure and electric shock may result.
8.
This system is not water-proof. Do not use this system in any place
where water leakage may occur. If any water is sprayed on or into
the system, electric shock may result. If water is accidentally
sprayed on or into the system, contact Mindray Customer Service
Department or sales representative.
9.
DO NOT use a probe that has a damaged, scratched surface, or
exposed wiring of any kind. Immediately stop using the probe and
contact Mindray Customer Service Department or sales
representative. There is risk of electric shock if using a damaged or
scratched probe.

1-4 Safety Precautions
10.
Do not allow the patient to contact the live parts of the ultrasound
system or other devices, e.g. signal I / O ports. Electric shock may
occur.
11.
Do not use an aftermarket probe other than those specified by
Mindray. The probes may damage the system causing a profound
failure, e.g. a fire in the worst case.
12.
Do not subject the probes to knocks or drops. Use of a defective
probe may cause an electric shock.
13.
Do not open the covers and front panel of the system. Short circuit
or electric shock may result when the system hardware is exposed
and powered on.
14.
Do not use this system when any digital device such as a high-
frequency electrotome, high-frequency therapeutic device or
defibrillator is applied already. Otherwise, there is a risk of electric
shock to the patient.
15.
Only use the ECG leads provided with the physiology module;
otherwise, electric shock may be resulted.
16.
When moving the system, you should hold the handle; otherwise,
damage may be resulted by abnormal force. Donot push the
system from the left/right side; otherwise, it may be toppled over.
17.
The auxiliary power output outlet in the system is used to supply
power for the recommended peripheral devices. Do not connect
other devices to the outlet, otherwise, the rated output power
limitation may be exceeded and failure may be resulted. Maximum
output power of the outlet is 240VA.
18.
Accessory equipment (analog or digital) connected to the
ultrasound system must comply with the relevant IEC standards
(e.g., IEC 60950 information technology equipment safety standard
and IEC 60601-1 medical equipment standard).Furthermore, all
configurations must comply with the standard IEC 60601-1-1:2005. It
is the responsibility of the person, who connects additional
equipment to the signal input or output ports and configures a
medical system, to verify that the system complies with the
requirements of IEC 60601-1-1:2005. If you have any questions
regarding these requirements, please consult your sales
representative.
19.
Prolongedand repeated use of keyboards may result in hand or arm
nerve disorders for some individuals. Observe the local safety or
health regulations concerning the use of keyboards.
20.
When using intra-cavity probes, do not activate the probe outside
the patient’s body.
21.
DO NOT touch the Signal I/O ports if in contact with the patient;
otherwise patient injury may result.

Safety Precautions 1-5
CAUTION:
1.
Precautions concerning clinical examination techniques:
This system must be used only by qualified medical professionals.
This operator’s manual does not describe clinical examination
techniques. The clinician should select the proper examination
techniques based on specialized training and clinical experience.
2.
Malfunctions due to radio wave:
If a radio wave emitting device is used in the proximity of this
system, it may interfere with operations. Do not use or take any
devices transmitting RF signals (such as cellular phones,
transceivers and radio controlled products) in the room placing the
system.
If a person brings a device that generates radio waves near the
system, ask him / her to immediately turn OFF the device.
3.
Precautions concerning movement of the system:
Please install the system on a flat plane with casters locked.
Otherwise, damage may be resulted by accidental moving.
Do not move the system laterally, which may result in damage in
case of toppling.
Move the system slowly on the slope by two people, otherwise,
damage may result in case of unexpected sliding.
Do not sit on the system, which may result individual falling in case
of system moving.
Object placed on the monitor may fall and injure an individual.
Fasten and fully secure any peripheral device before moving the
system. A loose peripheral device may fall and injure an individual.
When moving the system on the steps, please make sure to prevent
the system from toppling.
4.
If the circuit protector is tripped, it indicates that the system or a
peripheral device was improperly shut down and the system is
unstable. You cannot repair the system under this circumstance and
must call the Mindray Customer Service Department or sales
representative.
5.
There is no risk of high-temperature burns during normal ultrasound
examinations. It is possible for the surface temperature of the probe
to exceed the body temperature of a patient due to environmental
temperature and exam type combinations. Do not apply the probe to
the same region on the patient for a long time. Apply the probe only
for a period of time required for the purpose of diagnosis.
6.
Do not use the system to examine a fetus for a long period of time.
7.
The system and its accessories are not disinfected or sterilized prior
to delivery. The operator is responsible for the cleaning and
disinfection of probes and sterilization of biopsy brackets according
to the manuals, prior to the use. All items must be thoroughly
processed to completely remove harmful residual chemicals, which
will not only be harmful to the human body, but also damage the
accessory.

1-6 Safety Precautions
8.
It is necessary to press <End Exam> to end the current scan that is
in progress and clear the current Patient Information field.
Otherwise, new patient data may be combined with the previous
patient data.
9.
Do not connect or disconnect the system’s power cord or its
accessories (e.g., a printer or a recorder) without turning OFF the
system power first. This may damage the system and its accessories
or cause electric shock.
10.
If the system is powered off improperly during operation, it may
result in data damage of the system hard disk or system failure.
11.
Do not use a USB memory device (e.g., a USB flash drive, a
removable hard disk) which has unsafe data. Otherwise, system
damage may result.
12.
It is recommended to only use the video devices specified in this
manual.
13.
Do not use gel, disinfectant, probes, probe sheath or needle-guided
brackets that are not compatible with the system.
14.
The applied contrast agents should be compliant with the relevant
local regulations.
15.
Read the Acoustic Output Principle in the operation manual carefully
before operating this system on clinical examination.
16.
The cover contains natural rubber that can cause allergic reactions
in some individuals.
17.
Please use the ultrasound gel compliant with the relevant local
regulations.
18.
Normal operation may be affected by unstable mains power supply;
it is recommended that our product be powered from an
uninterruptible power supply.
19.
DO NOT expose the system to excessive vibration through
transportation. Mechanical damage may result.
20.
Always keep the system dry. Avoid transporting this system quickly
from a cold place to a warm place; otherwise condensation or water
droplets may form allowing a short circuit and possible electric
shock.
NOTE:
1. DO NOT use the system in the vicinity of strong electromagnetic field (such as a
transformer), which may affect the performance of the system.
2. Do not use the system in the vicinity of high-frequency radiation source (e.g. cellular
phones), which may affect the performance of the system or even lead to failure.
3. When using or placing the system, keep the system horizontal to avoid imbalance.
4. To avoid damaging the system, do not use it in following environment:
Locations exposed to direct sunlight;
Locations subject to sudden changes in environmental temperature;
Dusty locations;
Locations subject to vibration;
Locations near heat generators;
Locations with high humidity.

Safety Precautions 1-7
5. Turn ON thesystem only after thepower has been turnedOFFfor awhile. If thesystem
is turned ON immediately after being turned OFF, the system may not be rebooted
properly and could malfunction.
6. Press the <Freeze> key to freeze an image or turn off the power of the system
before connecting or disconnecting a probe. Otherwise, the system and/or probe
can be damaged.
7. Remove the ultrasound gel from the face of the probe when the examination is
completed. Water in the gel may enter the acoustic lens and adversely affect the
performance and safety of the probe.
8. You should properly back up the system to a secure external storage media,
including system configuration, settings and patient data. Data stored to the
system’s hard drive may be lost due to system failure, improper operation or
accident.
9. Do not apply external force to the control panel. Otherwise, the system may be
damaged.
10. If the system is used in a small room, the room temperature may rise. Please
provide proper ventilation and free air exchange.
11. To dispose of the system or any part, contact Mindray Customer Service
Department or sales representative. Mindray is not responsible for any system
content or accessories that have been discarded improperly. Mindray is not
responsible for any system content or accessories that have been discarded
improperly.
12. Electrical and mechanical performance may be degraded due to long usage (such
as current leakage or distortion and abrasion); the image sensitivity and precision
may become worse too. To ensure optimal system operations, it is recommended
that you maintain the system under a Mindray service agreement.
13. The replaceable fuse is inside the chassis. Refer replacing job to Mindray service
engineers or engineers authorized by Mindray only.
14. Do not turn OFF the power supply of the system during printing, file storage or
invoking other system operations. An interrupted process may not be completed,
and can become lost or corrupted.
15. The iScape feature constructs a single extended image from a series of individual
image frames. The quality of the final image is user-dependent and requires skill to
efficiently apply the feature and technique. Exercise caution when measurements
are performed from an iScape image.
16. Ensure that the current exam date and time are the same as the system date and
time.
17. Use the pluggable power supply as the net power supply breaking facility.
Please read the following precautions carefully to ensure the safety of the patient and the operator
when using the probes.
WARNING:
1. The probe is only for use with the specified ultrasonic diagnostic
system. Please refer to the “2.5.2 Probes and Needle-guided Brackets
Available ” to select the proper probe.
2. The ultrasonic probe must be used only by qualified professionals.
3. Confirm that the transducer and probe cable are normal before and
after each examination. A defective probe may cause electric shock
to the patient.

1-8 Safety Precautions
4. Do not subject the probe to shock. A defective probe may cause
electric shock to the patient.
5. Do not disassemble the probe to avoid the possibility of electric
shock.
6. Never immerse the probe connector into liquids such as water or
disinfectant because the connector is not waterproof. Immersion
may cause electric shock or malfunction.
7. A probe sheath must be installed over the probe before performing
intra-cavity or intra-operative examination.
CAUTION:
1. When using the probe, wearing sterile gloves can help to prevent
infection.
2. Be sure to use sterile ultrasound gel. Please use the ultrasound gel
compliant with the relevant local regulations. And manage the
ultrasound gel properly to ensure that it does not become a source of
infection.
3. In normal diagnostic ultrasound mode, there is no danger of a
normal-temperature burn; however, keeping the probe on the same
region of the patient for a long time may cause such a burn.
4. Do not use the carrying case for storing the probe. If the carrying
case is used for storage, it may become a source of infection.
5. It is required to practice ALARA when operating ultrasound system.
Minimize the acoustic power without compromising the quality of
images.
6. The probe and accessories supplied with it are not delivered
disinfected or sterilized. Sterilization (or high-level disinfect) before
use is required.
7. Disposable components should be packaged sterile and for single-
use only. Do not use if integrity of packaging violated or if expiration
date has passed. Please use the disposable components compliant
with the relevant local regulations.
8. Please use the disinfection or sterilization solution recommended in
this operator’s manual; otherwise Mindray will not be liable for
damage caused by other solutions. If you have any questions, please
contact Mindray Customer Service Department or sales
representative.
9. Do not use pre-lubricated condoms as a sheath. Lubricant may not be
compatible with the probe material and damage may result.
10. The damage of the probe may be caused by the contact of improper
gel or cleaner:
DO NOT soak or saturate probes in the strong polar solution of
ethanol, chloride of lime, ammonium chloride, acetone or
formaldehyde.
DO NOT contact the probe with solutions or ultrasound gels
containing oily medium such as mineral oil or lanoline.
