SmartLine Medical SmartPack User manual

MAN-1001 SMARTPACK TABLE
RELEASE DATE 07/07/2022 VERSION: 2
1
SmartPack
HEIGHT ADJUSTABLE TABLE
USER MANUAL
2.0

MAN-1001 SMARTPACK TABLE
RELEASE DATE 07/07/2022 VERSION: 2
2
CONTENTS
CONTENTS...........................................................................................................................................................................2
NOTICE................................................................................................................................................................................3
ABOUT THIS MANUAL.........................................................................................................................................................3
PREFACE..............................................................................................................................................................................4
SAFETY ................................................................................................................................................................................ 4
PRODUCT OVERVIEW..........................................................................................................................................................5
INSTALLATION INSTRUCTIONS............................................................................................................................................ 5
Unpacking ....................................................................................................................................................................... 5
Unassembled parts .........................................................................................................................................................5
Assembly.........................................................................................................................................................................6
OPERATING INSTRUCTIONS................................................................................................................................................7
CLEANING AND MAINTENANCE..........................................................................................................................................7
TROUBLESHOOTING ...........................................................................................................................................................8
TECHNICAL SUPPORT.......................................................................................................................................................... 8
AUSTRALIA ......................................................................................................................................................................8
WARRANTY ......................................................................................................................................................................... 8
APPENDICES......................................................................................................................................................................10
Conformances............................................................................................................................................................... 10
Spare parts....................................................................................................................................................................10
Specifications................................................................................................................................................................11

MAN-1001 SMARTPACK TABLE
RELEASE DATE 07/07/2022 VERSION: 2
3
NOTICE
This manual and any examples or images contained herein are provided “as is” and are subject to change without
notice. Smartline Medical makes no warranty of any kind with regard to this manual, including, but not limited to, the
implied warranties of merchantability, non-infringement and fitness for a particular purpose.
Smartline Medical shall not be liable for any errors or for consequential damages in connection with the furnishing,
performance, or use of this manual or the examples contained herein.
© 2022, Smartline Medical
Product designed and manufactured by Smartline Medical Pty. Ltd.
PO Box 532, Buderim, Qld 4556
Australia
ABOUT THIS MANUAL
WARNING: Warnings must be followed to avoid injury.
CAUTION: Cautions must be observed to avoid damage to the product.
Must be observed to avoid bodily injury and damage to the product.
NOTE: Notes contain important information and hints for using the product.
REFERENCE: Indicates a page where additional information can be found.

MAN-1001 SMARTPACK TABLE
RELEASE DATE 07/07/2022 VERSION: 2
4
PREFACE
We are delighted that you have chosen a product from Smartline Medical Pty Ltd. Smartline’s products are designed
to meet specific needs in the healthcare industry and manufactured in Australia under ISO 9001 quality system
standards. We are also constantly improving our products to meet changing customer requirements.
This User Manual covers the installation, use, and maintenance of your Smart Pack Table.
We are confident that this product will give you many years of problem-free operation. Before our products leave the
factory they undergo quality assurance testing to ensure that they meet our quality standards. Should you experience
problems with this product, you are always welcome to contact us for support or repairs.
Our products are supported by local distributors who are always ready to help you. If the local distributor is unable to
solve your problems, they will forward your support requests to us.
SAFETY
•Use only certified 240V power sources.
•Ensure area under table top is free from clutter and top will not be impeded if fully lowered.
•Be sure table is free from obstruction and possible pinch points are clear.
•Be sure that operation of table is done in safe environments and precautions are made for when in use in wet
areas
•The SmartPack table and multipack power board are earthed 240V systems
•Overloading can lead to damage to the table and/or risk of injury to the user
•Human obstruction should be mitigated during use –do not have any body parts under the table when
lowering the table
•When moving the table be sure that the castor brakes are disengaged and reengaged before operation once
table position is suitable.
•The assembly of the table is at times a two person job and should not be attempted alone.
•LINAK legs use PIEZO safety technology which prevents damage being done to anything that obstructs the
table when being raised or lowered. More detail on this technology can be found at the Linak website:
http://www.linak.com.au/about/?id3=2647
•PIEZO is a hardware based anti-collision solution from LINAK. The solution is based on a PIEZO sensor that has
been completely integrated in the lifting column –without visually altering the desk design. The built-in
PIEZO sensor reacts to any obstruction when raising or lowering the desk, then halts and reverses to avoid
collision.

MAN-1001 SMARTPACK TABLE
RELEASE DATE 07/07/2022 VERSION: 2
5
PRODUCT OVERVIEW
The Smartline SmartPack Tables are designed to be compliant with standards and are made using quality grade
stainless steel.
SmartPack Tables come in 3 sizes:
▪1400mmL x 800mmW
▪1700mmL x 800mmW
▪2000mmL x 800mmW
With the height adjustment from 747-1407mm for use in standing or sitting positions. The standard table comes as a
basic table that is prepared for the addition of a range of accessories.
INSTALLATION INSTRUCTIONS
UNPACKING
Before unpacking the table be sure to have a large uninterrupted space to work in.
All of the tools required to assemble the table are provided in the table package, however, the following tools may be
of use to the user/technician:
•Stanley Knife or similar –for cutting straps and plastic packaging.
•7mm Spanner –for tightening dome nuts on top of light shroud
•Rubber mallet –for encouraging scout rack brackets onto posts, assembling shelf unit
Supplied tools are:
•5mm Allen Key –for M6 cap screws(common fixing)
•7/32 Allen Key –for attaching Scout Rack Posts
•4mm Allen Key –for countersunk cap screws on Leg Attaching Plate
•10mm L-wrench –for M6 Nylock nuts (Leg to Table)
•Full set of assembly drawings and instructions
UNASSEMBLED PARTS
In your table package you should have the following:
•One table package consisting of:
o1 x Table Top and Under Top Frame
o2 x Base Shelf Bar
o2 x Leg Attaching Plate
oFixings
oTools
oAssembly Instructions

MAN-1001 SMARTPACK TABLE
RELEASE DATE 07/07/2022 VERSION: 2
6
•One leg package consisting of:
o2 x Castor Bars (with castors)
•One Linak leg box consisting of:
o2 x Linak legs
In the optional Scout Rack package you should have the following:
•One package consisting of:
o1 x Scout Rack Top and Brackets
o2 x Scout Rack Brace Bars
o2 x Scout Rack Posts
o2x Over Head Light Posts
o1 x Overhead Light and Shroud
oFixings
oTools
oAssembly Instructions
In the optional Under Shelf package you should have the following:
•One shelf package consisting of:
o2 x Under Shelves
o8 x Two part plastic clips
•One leg package consisting of:
o4 x Under Shelf Posts
o8 x Two part plastic clips
In the optional Wrap rack package you should have the following:
•One package consisting of:
o1 x Wrap Rack
o2 x Wrap Rack attaching bars
o4 x M6 Cap Screws
o1 x 5mm Allen Key
In the optional Tape Dispenser package you should have the following:
•One package consisting of:
o1 x Tape Dispenser
o2 x Tape Dispenser attaching bars
o4 x M6 Cap Screws
o1 x 5mm Allen Key
ASSEMBLY
The assembly of the SmartPack table will take approximately 30 minutes and at times requires two people to carry
out.
Please follow the set of drawings and Instructions provided in the table or accessory packages.

MAN-1001 SMARTPACK TABLE
RELEASE DATE 07/07/2022 VERSION: 2
7
OPERATING INSTRUCTIONS
Before start-up:
•Make sure that the system has been installed as instructed in this User Manual.
•Make sure that the voltage at the control box is correct before the system is connected to the mains.
•System connection. The individual parts must be connected before the control box is connected to the mains.
See the User Manual for LINAK DL12 actuators, if necessary.
•Ensure Castors are brakes are activators prior to using the SmartPack Table.
•The SmartPack Table “control switch” is used to raise and lower the table; the up arrow is for raising the table
and the down arrow is for lowering the table.
•The SmartPack Table “control panel” has an on button (on) (low voltage battery option only), this must be
pressed prior to raising or lowering the table (please note: if the table has not been raised or lowered within
90 seconds it will automatically turn off to conserve power –press the on button to resume raising or
lowering the table).
•The low voltage battery kit SmartPack Table can be re-charged at any time via a standard 240volt outlet.
•The electric cords MUST BE out of the ‘pinch zone” area when raising or lowering the table.
•The SmartPack Table MUST NOT be lowered if there are large items placed on the shelf below that could
come in contact with the table top.
•The castors brakes MUST BE activated prior to using the table.
•The SmartPack Table MUST BE in the lowest position and the mains power lead removed from the wall socket
prior to moving from one location to another.
•The SmartPack Table MUST NOT be used as a lifting and/or loading device ie: forklift. It is designed as a
height adjustable table only.
•The SmartPack Table MUST NOT be loaded beyond the SWL capacity of the equipment.
•The attachments on the SmartPack Table are designed for specific items, DO NOT use the attachments for
any other purpose than they were designed for.
•DO NOT place hands/arms under the table top while it is being lowered.
•DO NOT raise the table under over-hanging ledges/shelves, electrical equipment etc.
•All maintenance MUST BE carried out by an authorised service technician.
•All associated Workplace Health and Safety requirements MUST BE adhered to when using this equipment.
•For further information please refer to the Instruction Manual supplied with the equipment.
CLEANING AND MAINTENANCE
Cleaning must be done in accordance to department regulations. The unit should be inspected regularly for any
damage and general wear and tear.

MAN-1001 SMARTPACK TABLE
RELEASE DATE 07/07/2022 VERSION: 2
8
TROUBLESHOOTING
ISSUE
SOLUTION
Table will not raise or lower
•Switch off the power supply then switch back
on
•With the table turned on press and hold both
the up and down arrows on the control panel
for 10 seconds. Release the up arrow and hold
the down arrow to lower the table to lowest
position. This will reset the leg and the legs
should now work.
•If the above step doesn’t work then switch off
the power source leave for 30 seconds, turn
back on then try the reset function again.
•If you still have issues please check that ALL
electrical ports are still connected on the Linak
power pack and legs.
Scout Rack dropping down
Use a spanner/socket wrench and a 5mm Allen key to
tighten the Scout Rack Bracket
TECHNICAL SUPPORT
AUSTRALIA
Smartline Medical Pty Ltd
Phone: [phone]
Fax: [phone]
e-mail: [email protected]m
Web: www.smartlinemedical.com
WARRANTY
1. Interpretation
In these terms:
“Smartline” means Smartline Medical Pty Ltd (ABN: 34 119 206 611)
“Customer” means the organisation that purchases any product / services from Smartline
“Product”means any product / services provided by Smartline for fee or price
2. Warranty
2.1. Subject to Clause 2.7 Smartline warrants the Products it supplies to the Customer against defective
materials and workmanship for the period of 12 months from the date of invoice.
2.2. The warranty does not apply in circumstances where:
a. the Products were used for a purpose other than for which they were intended;
b. the Products were repaired, modified or altered by a party other than Smartline without prior
written consent by Smartline
c. the defect has arisen due to misuse, neglect or accidental damage;

MAN-1001 SMARTPACK TABLE
RELEASE DATE 07/07/2022 VERSION: 2
9
d. the defect has arisen due to the incorrect installation of the Products by a party other than a
Smartline employee or contractor appointed by Smartline;
e. the Products have not been stored or maintained as recommended by Smartline
f. the defect has arisen due to normal wear and tear on the Products;
g. the identification labels are removed or altered;
h. the damage was caused due to acts of God & force majeure;
i. the Customer is in breach of the Supply Conditions; or
j. the Products are found to not be defective;
2.3. Any repairs not covered by Warranty provided by Smartline at the Customer’s request shall be invoiced to
Customer at Smartline’ then-current rates for parts, labour, and travel.
2.4. In order to make a claim under this warranty, the Customer must:
a. give Smartline written details of any defect in the products (with photographic evidence) together
with proof of purchase of the products within 5 days of identifying the defect;
b. allow Smartline or its employees or agents to inspect the products;
c. return the defective products to Smartline at Smartline’s expense if required;
d. Provide all information requested by Smartline in relation to the products or installation of the
products.
2.5. All claims for damage during delivery, short supply, non –receipt of Products or incorrect delivery
documents must be made to Smartline within 5 days of receipt of Products.
2.6. Any Products which are damaged or defective, or which are not otherwise in accordance with the
Customer’s order, may be returned to Smartline, at no cost to the Customer;
a. Except for specially ordered products, custom-built products or products specifically tailored for the
Customer’s requirements, which may not be returned.
b. Provided that it does so within 5 days of delivery and a return authorisation is obtained from
Smartline. The Customer may otherwise return Products to Smartline and obtain a credit;
i. Provided that the Products are in their original packaging, and in an as-new and saleable
condition.
ii. At the Customer’s own expense, or to the Customer’s account; and
iii. On the basis that risk in the Products remains with the Customer until the Products are received
by Smartline, and that a restocking fee (20% of Product invoice value) or return fee may be
charged.
2.7. Where Smartline supplies Products manufactured by a third party, the original manufacturer’s warranty is
the only warranty provided to the Customer.
2.8. In the repair or maintenance of the Product, Smartline may use new, remanufactured, or refurbished
parts, assemblies, or products. All defective parts, assemblies, and products become the property of
Smartline.
2.9. Replacement or repair of the Product or a part under the Standard Warranty does not extend or restart
the Standard Warranty period.
2.10. The Standard Warranties are not transferrable to a third party.
2.11. Correspondence should be sent to [email protected] or by mail to P.O. BOX 532, Buderim,
QLD, 4556.
3. Liability
3.1. Except as specifically set out in these conditions, any term, condition or warranty in respect of the quality,
merchantability, fitness for purpose, condition, description, assembly, manufacture, design or
performance of the Products or services, whether implied by statute, common law, trade usage, custom
or otherwise is expressly excluded.
3.2. Replacement or repair of the Products is the absolute limit of Smartline’s liability arising under or in
connection with the description, quality, condition, performance, assembly, manufacture, design,
merchantability or fitness for purpose of the Products or services or alternatively the sale, use of, storage
or any other dealings with the Products or service by the Customer or any third party.

MAN-1001 SMARTPACK TABLE
RELEASE DATE 07/07/2022 VERSION: 2
10
3.3. Smartline is not liable for any indirect or consequential losses or expenses suffered by the Customer or
any third party, howsoever caused, including but not limited to loss of turnover, profits, business or
goodwill or any liability to any other party.
3.4. Smartline will not be liable for any loss or damage suffered by the Customer where Smartline has failed to
meet any delivery date of cancels or suspends the supply of Products or services.
3.5. Nothing in these Conditions is to be interpreted as excluding, restricting or modifying or having the effect
of excluding, restricting or modifying the application of any State of Federal legislation applicable to the
sale of Products or the provision of services which cannot be excluded, restricted or modified.
3.6. The Customer undertakes in relation to Products it acquires from Smartline.
a. not to attach Smartline’s name, brand or mark to the Products, unless already attached when
Smartline supplies the Products to the Customer;
b. Do not use Smartline’s Products for any purpose for which they are not suitable, and that it will
(wherever appropriate) correctly train its employees in the use of Smartline’s Products.
c. Immediately notify Smartline in writing of any claim they may make in respect of the Products
and/or services giving full details of the claim concerned.
3.7. The Customer indemnifies Smartline against all liabilities and costs (including all legal costs on an
indemnity basis) expenses, losses, damages or claims arising in any way as a result of the Customer’s
failure to comply with any part of these Conditions.
APPENDICES
SmartPack Installation Drawings and Instructions
CONFORMANCES
SmartPack Tables meet AS4187
Electrically Certified
SPARE PARTS
While under warranty please contact your local sales representative or distributor if you require any replacement
parts. If you are outside the warranty period and require spare parts please also contact your local sales
representative or distributor to see how we can assist you in purchasing spare parts.

MAN-1001 SMARTPACK TABLE
RELEASE DATE 07/07/2022 VERSION: 2
11
SPECIFICATIONS
Installed Dimensions and Weight
1. 1400mm Table
a. Lifts 93 kg
b. Length = 1400mm
c. Width = 800mm
d. Height = 747-1407mm
e. Weight = 68KG
f. An additional 50mm Wide and 850mm High if Scout Rack and Light is installed
g. An Additional 365mm Wide if a Wrap Rack is installed
h. An Additional 95mm Wide if a Tape Dispenser is installed
2. 1700mm Table
a. Lifts 79 kg
b. Length = 1700mm
c. Width = 800mm
d. Height = 747-1407mm
e. Weight = 82KG
f. An additional 50mm Wide and 850mm High if Scout Rack and Light is installed
g. An Additional 365mm Wide if a Wrap Rack is installed
h. An Additional 95mm Wide if a Tape Dispenser is installed
3. 2000mm Table
a. Lifts 70 kg
b. Length = 2000mm
c. Width = 800mm
d. Height = 747-1407mm
e. Weight = 98KG
f. An additional 50mm Wide and 850mm High if Scout Rack and Light is installed
g. An Additional 365mm Wide if a Wrap Rack is installed
h. An Additional 95mm Wide if a Tape Dispenser is installed
4. Accessories
a. Scout Rack and Light - an additional 50mm Wide, 850mm High - 15Kg
b. Wrap Rack - an additional 365mm Wide - 9Kg
c. Tape Dispenser - an additional 95mm Wide –1.5Kg
d. Under Shelf Kit - an additional 10Kg
e. Extra Scout Rack Shelf –an additional 8kg
f. Steripeel Roll Holder –an additional 3kg
