Shield SD1010 User manual

6
www.shieldglobal.com
MODEL: SD1010, SD1015, SD1030, SD1032
DESCRIPTION
The SHIELD Sprinklers, SD1010, SD1015, SD1030, SD1032
(Glass Bulb Type), Standard Orice, Upright, Pendent and
Recessed Pendent type, design incorporates state-of-the-art,
heat responsive, frangible glass bulb design (standard or quick
response)forprompt,preciseoperation.
The die cast frame is more streamlined and attractive than
traditionalsandcastframes.Itiscastwithahex-shapedwrench
boss to allow easy tightening from many angles, reducing assembly
effort. This sprinkler is available in various temperature ratings
and nishes to meet many design requirements. The recessed
pendent should be utilized with a recessed escutcheon which
provides up

” of adjustments. All Sprinklers aremanufactured
usingthetimeprovenBellevillesealusedexclusivelybyallmajor
manufacturestoensurelonglifeandsafeoperation.
SPRINKLER OPERATION
Theoperatingmechanismisafrangibleglassbulbwhichcontains
a heat responsive liquid. During a re, the ambient temperature
risescausingtheliquidinthebulbtoexpand.Whentheambient
temperature reaches the rated temperature of the sprinkler, the
bulbshatters. Asa result, the waterway is clearedofall sealing
partsandwaterisdischargedtowardsthedeector.Thedeector
is designed to distribute the water in a pattern that is most
effectiveincontrollingthere.
MAXIMUM COVERAGE
Standard spray coverage is up to: Light Hazard = 225 square
feet(20.9sq.m);OrdinaryHazard=130squarefeet(12.1sq.m)per
NFPA13.
TECHNICAL SPECIFICATION
RATINGS
SPRINKLER HEAD
Upright, Pendent & Recessed Pendent Sprinklers
SprinklerIdentication
Number
Standard SD1015, SD1010
(bulb5mm),QuickResponse
SD1030,SD1032(bulb3mm)
Style Upright Sprinkler SD1015,
SD1032, Pendent &
Recessed Pendent
SD1010, SD1030
K Factor 5.6gpm/psi½.(80lpm/bar½)
ResponseTimeIndex
(RTI)
Standard 50
Quick Response 30
NominalThreadSize
½”NPT(15mm)
OrceSize 13mm
Max.WorkingPressure 175PSI(1200kPa)
FactoryHydrostaticTest 100%@500PSI(3450kPa)
Min.OperationPressure 7PSI(48kPa)
SprinklerTemperature
Classication
Norminal Sprinkler
TemperatureRating
N.F.P.AMaximumAmbient
(Ceiling)Temp.(Allowed) Glass Bulb Color
Ordinary** 155ºF/57ºC 100ºF/38ºC Orange
Ordinary 155ºF/68ºC 100ºF/38ºC Red
Intermediate 175ºF/79ºC 150ºF/65ºC Yellow
Intermediate 200ºF/93ºC 150ºF/65ºC Green
High* 286ºF/141ºC 225ºF/107ºC Blue
ExtraHigh* 360ºF/182ºC 300ºF/149ºC Mauve
Open* Open - No Bulb
*Non-Approved
**ULListedonly.

7
www.shieldglobal.com
PART LIST
DISCHARGE CURVE
SD1015 SD1010 SD1030 SD1032
1.Frame2.Deector3.Cap4.CapSeat5.LoadScrew6.Seal7.Bulb

8
www.shieldglobal.com
WARNINGS
TheSHIELDsprinklersmustbeinstalledandmaintained
incompliancewiththisdocument.Depressurizeanddrain
the piping system before attempting to install, remove,
oradjustanySprinklers.Failuretodosomayimpairthe
performanceofthesesprinklers.Theownerisresponsible
formaintainingthereprotectionsystemanddevicesin
operation.
WRENCH DESCRIPTION
The Sprinkler Wrench is a tool specically designed for
installingSHIELDSprinklers.Thesespecialwrenchesmust
be used to provide the proper leverage when tightening
thesprinklerandtominimizeslippageduringinstallation.
Anyotherwrenchmaydamagethesprinkler.
INSTALLATION
All SHIELD Sprinklers must be installed according to
NFPA13 Standards.Deviationsfromthese requirements
and standards or any alteration to the sprinkler itself will
void any warranty made by manufacturer. In addition,
installation must also meet local government provisions,
codesandstandardsasapplicable.
The system piping must be properly sized to insure the
minimumrequiredowrateatthesprinkler.Checkforthe
proper model, style, orice size and temperature rating
priortoinstallation.Installsprinklersafterthepipingisin
place to avoid mechanical damage, replace any damaged
units.Wetpipesystemsmustbeprotectedfromfreezing.
Upon completion of the installation, the system must be
testedperrecognizedstandards.Intheeventofathread
task, remove the unit, apply new pipe joint compound or
tape,andreinstall.
ADDITIONAL
Recessed Sprinkler - To install the escutcheon plate,
align with it and push or thread over the sprinkler body
into the upper support piece, until the outer edge of the
escutcheonmeetsthemountingsurface.
INSTALLATION SEQUENCE
Step1-Theunitmustbeinstalledintheuprightpositionfor
the Upright Sprinklers, and in the Pendent position for the
PendentSprinkler,PendentRecessedSprinkler.
Step 2 - Use only a non-hardening pipe joint compound or
tapeseal.Applyonlytothemalethreads.
Step3-Handtightenthesprinklerintotting.
Step 4 - For Upright and Pendent Sprinklers, use a
standardwrench.Tightentheunitintothetting.Alead-tight
jointrequiresonly7to14ft.lbs(9.5to19.0Nm)oftorque.A
tangentialforceof14to28ft.lbs(62.3to124.5N)delivered
througha 6”(150mm) handle will deliver adequate torque.
Once torque level reach over 21ft.lbs (28.6Nm) it may
distort the orice seal, resulting in leakage. For exposed
piping systems, the sprinkler should be oriented so the
framearmsareparallelwiththebranchlinepipe.
CAUTION
Do not over-tighten or under-tighten the sprinkler to
compensateforinaccurateescutcheonplateadjustment.
Protection clips are used to protect its bulb. Please have
cliponatalltimesduringtransportation.
MAINTENANCE
Sprinklers must never be altered after manufacture. Any
alteration such as painting and coating will directly harm
thesprinklerandcausemalfunctions.
Sprinkler in contact with corrosive products should be
replacediftheycannotbecleanedcompletely.
Visual inspections are recommended after installation.
After installation, a close-up inspection annually will
sufce.
Inspection and maintenance of re protection system is
the responsibility of the owner. It is recommended that
automatic sprinkler system be inspected and tested
accordingtolocaland/ornationalregulations.
Sprinkler Wrench

9
www.shieldglobal.com
DISTRIBUTION PATTERNS
K5.6PENDENTSPRINKLER
DISTRIBUTIONPATTERNS-TRAJECTORY
K5.6UPRIGHTSPRINKLER
DISTRIBUTIONPATTERNS-TRAJECTORY

10
www.shieldglobal.com
DIMENSIONS
UPRIGHTSPRINKLER PENDENTSPRINKLER
RECESSEDPENDENTSPRINKLER
MaximumExtension MaximumRecess

11
www.shieldglobal.com
MODEL: SD1133, SD1121
DESCRIPTION
The SD1133, SD1121,
½
” orice, standard horizontal sidewall
sprinkler is designed for standard or recessed installation. The
design provides a crescent-shaped water discharge pattern for
installation along a wall or under a beam or ceiling. The design
incorporates state-of-the-art, heat responsive, frangible glass
bulb design (standard or quick response) for prompt, precise
operation. Thedie cast frameis morestreamlinedand attractive
thantraditionalsandcastframes.
Itiscastwithahex-shapedwrenchbosstoalloweasytightening
from many angles, reducing assembly effort. This sprinkler is
available in various temperature ratings and nishes to meet
many design requirements. The recessed pendent should be
utilized with a recessed escutcheon which provides up  ” of
adjustments.
SPRINKLER OPERATION
Theoperatingmechanismisafrangibleglassbulbwhichcontains
a heat responsive liquid. During a re, the ambient temperature
risescausingtheliquidinthebulbtoexpand.
When the ambient temperature reaches the rated temperature of
thesprinkler,thebulbshatters.Asaresult,thewaterwayiscleared
ofallsealingpartsandwaterisdischargedtowardsthedeector.
Thedeectorisdesignedtodistributethewaterinapatternthatis
mosteffectiveincontrollingthere.
MAXIMUM COVERAGE
Standard spray coverage is up to: Light Hazard = 196 square
feet(18,2 sq.m);Ordinary Hazard = 100 square feet(9,3 sq.m)per
NFPA13.
TECHNICAL SPECIFICATION
SPRINKLER HEAD
Horizontal Sidewall Sprinkler
SprinklerIdentication
Number
Standard SD1133 (bulb
5mm),QuickResponse
SD1121(bulb3mm)
Style HorizontalSidewall
K Factor 5.6gpm/psi½.(80lpm/bar½)
ResponseTimeIndex
(RTI)
Standard 50
Quick Response 30
NominalThreadSize
½”NPT(15mm)
OrceSize 13mm
Max.WorkingPressure 175PSI(1200kPa)
FactoryHydrostaticTest 100%@500PSI(3450kPa)
Min.OperationPressure 7PSI(48kPa)
RATINGS
SprinklerTemperature
Classication
Norminal Sprinkler
TemperatureRating
N.F.P.AMaximumAmbient
(Ceiling)Temp.(Allowed) Glass Bulb Color
Ordinary 155ºF/57ºC 100ºF/38ºC Orange
Ordinary 155ºF/68ºC 100ºF/38ºC Red
Intermediate** 175ºF/79ºC 150ºF/65ºC Yellow
Intermediate** 200ºF/93ºC 150ºF/65ºC Green
High* 286ºF/141ºC 225ºF/107ºC Blue
ExtraHigh* 360ºF/182ºC 300ºF/149ºC Mauve
Open* Open - No Bulb
*Non-Approved **FMApprovedonly

12
www.shieldglobal.com
PART LIST
SD1133 SD1121
1.Frame2.Deector3.Cap4.CapSeat5.LoadScrew6.Seal7.Bulb
DISCHARGE CURVE

13
www.shieldglobal.com
WARNINGS
The SHIELD sprinklers mustbe installed andmaintained
incompliancewiththisdocument.Depressurizeanddrain
the piping system before attempting to install, remove,
or adjust any Sprinklers. Failure to do so mayimpair the
performanceofthesesprinklers.Theownerisresponsible
for maintaining the re protection system and devices in
operation.
WRENCH DESCRIPTION
The Sprinkler Wrench is a tool specically designed for
installingSHIELDSprinklers.Thesespecialwrenchesmust
be used to provide the proper leverage when tightening the
sprinklerandtominimizeslippageduringinstallation.Any
otherwrenchmaydamagethesprinkler.
INSTALLATION
All SHIELD Sprinklers must be installed according to
NFPA 13 Standards. Deviations from these requirements
and standards or any alteration to the sprinkler itself will
void any warranty made by manufacturer. In addition,
installation must also meet local government provisions,
codesandstandardsasapplicable.
The system piping must be properly sized to insure the
minimumrequiredowrateatthesprinkler.Checkforthe
proper model, style, orice size and temperature rating
prior to installation. Install sprinklers afterthe piping isin
place to avoid mechanical damage, replace any damaged
units.Wetpipesystemsmustbeprotectedfromfreezing.
Upon completion of the installation, the system must be
testedperrecognizedstandards.Intheeventofathread
task, remove the unit, apply new pipe joint compound or
tape,andreinstall.
ADDITIONAL
Recessed Sprinkler - To install the escutcheon plate,
align with it and push or thread over the sprinkler body
into the upper support piece, until the outer edge of the
escutcheonmeetsthemountingsurface.
INSTALLATION SEQUENCE
Step1.Theunitmustbeinstalledinthehorizontalsidewall
positionfortheHorizontalSidewallSprinklers.
Step2.Useonlyanon-hardeningpipejointcompoundor
tapeseal.Applyonlytothemalethreads.
Step3.Handtightenthesprinklerintotting.
Step 4. For Horizontal Sidewall Sprinklers, use a
standard wrench. Tighten the unit intothe tting.Alead-
tight joint requires only 7 to 14ft.-lbs(9.5 to19.0Nm) of
torque.Atangentialforceof14to28ft.-lbs(62.3to124.5N)
deliveredthrougha6”(150mm)handlewilldeliveradequate
torque. Once torque level reach over 21ft.-lbs(28.6Nm)
it may distort the orice seal, resulting in leakage. For
exposedpipingsystems,thesprinklershouldbeoriented
sotheframearmsareparallelwiththebranchlinepipe.
CAUTION
Do not over-tighten or under-tighten the sprinkler to
compensateforinaccurateescutcheonplateadjustment.
Protectionclipsareusedtoprotectitsbulb.Pleasehave
cliponatalltimesduringtransportation.
MAINTENANCE
Sprinklers must never be altered after manufacture. Any
alteration such as painting and coating will directly harm
thesprinklerandcausemalfunctions.Sprinklerincontact
with corrosive products should be replaced if they cannot
becleanedcompletely.
Visual inspections are recommended after installation.
After installation, a close-up inspection annually will
sufce.
Inspection and maintenance of re protection system is
the responsibility of the owner. It is recommended that
automatic sprinkler system be inspected and tested
accordingtolocaland/ornationalregulations.
Sprinkler Wrench

14
www.shieldglobal.com
DISTRIBUTION PATTERNS
K5.6STANDARDHORIZONTALSIDEWALLANDRECESSEDHORIZONTALSIDEWALL
DISTRIBUTIONPATTERNS-TRAJECTORY
K5.6STANDARDHORIZONTALSIDEWALL
DISTRIBUTIONPATTERNS–PLANVIEW

15
www.shieldglobal.com
DIMENSIONS
RECESSEDPENDENTSPRINKLER
MaximumExtension MaximumRecess

16
www.shieldglobal.com
MODEL: SD2133, SD2121
DESCRIPTION
The SD2133, SD2121,
½
” orice, standard vertical sidewall
sprinkler is designed for standard installation. The design
provides a crescent-shaped water discharge pattern for
installation along a wall or under abeam or ceiling. The design
incorporates state-of-the-art, heat responsive, frangible glass
bulb design (standard or quick response) for prompt, precise
operation.Thediecastframeismorestreamlinedandattractive
thantraditionalsandcastframes.
Itiscastwithahex-shapedwrenchbosstoalloweasytightening
from many angles, reducing assembly effort. This sprinkler is
available in various temperature ratings and nishes to meet
many design requirements. The recessed pendent should be
utilized with a recessed escutcheon which provides up  ” of
adjustments. All sprinklers are manufactured using the time
provenBellevillesealusedexclusivelybyallmajormanufactures
toensurelonglifeandsafeoperation.
SPRINKLER OPERATION
Theoperatingmechanismisafrangibleglassbulbwhichcontains
a heat responsive liquid. During a re, the ambient temperature
risescausingtheliquidinthebulbtoexpand.
When the ambient temperature reaches the rated temperature
of the sprinkler, the bulb shatters. As a result, the waterway is
cleared of all sealing parts and water is discharged towards the
deector. Thedeector is designed to distribute the water in a
patternthatismosteffectiveincontrollingthere.
MAXIMUM COVERAGE
Standardspraycoverageisupto:LightHazard=196
squarefeet(18,2sq.m);OrdinaryHazard=100square
feet(9,3sq.m)perNFPA13.
TECHNICAL SPECIFICATION
RATINGS
SPRINKLER HEAD
Vertical Sidewall Sprinkler
SprinklerIdentication
Number
Standard SD2133 (bulb
5mm),QuickResponse
SD2121(bulb3mm)
Style Vertical Sidewall
K Factor 5.6gpm/psi½.(80lpm/bar½)
ResponseTimeIndex
(RTI)
Standard 50
Quick Response 30
NominalThreadSize
½”NPT(15mm)
OrceSize 13mm
Max.WorkingPressure 175PSI(1200kPa)
FactoryHydrostaticTest 100%@500PSI(3450kPa)
Min.OperationPressure 7PSI(48kPa)
SprinklerTemperature
Classication
Norminal Sprinkler
TemperatureRating
N.F.P.AMaximumAmbient
(Ceiling)Temp.(Allowed) Glass Bulb Color
Ordinary 135ºF/57ºC 100ºF/38ºC Orange
Ordinary 155ºF/68ºC 100ºF/38ºC Red
Intermediate 175ºF/79ºC 150ºF/65ºC Yellow
Intermediate 200ºF/93ºC 150ºF/65ºC Green

17
www.shieldglobal.com
PART LIST
SD2133 SD2121
1.Frame2.Deector3.Cap4.CapSeat5.LoadScrew6.Seal7.Bulb
DISCHARGE CURVE

18
www.shieldglobal.com
WARNINGS
The SHIELD must be installed and maintained in
compliancewiththisdocument.Depressurizeanddrainthe
piping system before attempting to install, remove, or adjust
anySprinklers.Failuretodosomayimpairtheperformance
ofthesesprinklers.Theownerisresponsibleformaintaining
the re protection system and devices in operation.
WRENCH DESCRIPTION
The Sprinkler Wrench is a tool specically designed for
installingSHIELDSprinklers.Thesespecialwrenchesmust
be used to provide the proper leverage when tightening the
sprinklerandtominimizeslippageduringinstallation.Any
otherwrenchmaydamagethesprinkler.
INSTALLATION
All SHIELD Sprinklers must be installed according to
NFPA 13 Standards. Deviations from these requirements
and standards or any alteration to the sprinkler itself will
void any warranty made by manufacturer. In addition,
installation must also meet local government provisions,
codesandstandardsasapplicable.
The system piping must be properly sized to insure the
minimumrequiredowrateatthesprinkler.Checkforthe
proper model, style, orice size and temperature rating
prior to installation.Install sprinklers after the piping isin
place to avoid mechanical damage, replace any damaged
units.Wetpipesystemsmustbeprotectedfromfreezing.
Upon completion of the installation, the system must be
testedperrecognizedstandards.Intheeventofathread
task, remove the unit, apply new pipe joint compound or
tape,andreinstall.
ADDITIONAL
RecessedSprinkler-Toinstalltheescutcheonplate,align
with it and push or thread over the sprinkler body into the
upper support piece, until the outer edge of the escutcheon
meetsthemountingsurface.
INSTALLATION SEQUENCE
Step1.Theunitmustbeinstalledinthehorizontalsidewall
positionfortheHorizontalSidewallSprinklers.
Step2.Useonlyanon-hardeningpipejointcompoundor
tapeseal.Applyonlytothemalethreads.
Step3.Handtightenthesprinklerintotting.
Step 4. For Horizontal Sidewall Sprinklers, use a
standard wrench. Tighten the unit into the tting. A
lead-tightjointrequiresonly7to14ft.-lbs(9.5to19.0Nm)of
torque.Atangentialforceof14to28ft.-lbs(62.3to124.5N)
deliveredthrougha6”(150mm)handlewilldeliveradequate
torque. Once torque level reach over 21ft.-lbs(28.6Nm)
it may distort the orice seal, resulting in leakage. For
exposedpipingsystems,thesprinklershouldbeoriented
sotheframearmsareparallelwiththebranchlinepipe.
CAUTION
Do not over-tighten or under-tighten the sprinkler to
compensate for inaccurateescutcheon plate adjustment.
Protectionclipsareusedtoprotectitsbulb.Pleasehave
cliponatalltimesduringtransportation.
MAINTENANCE
Sprinklers must never be altered after manufacture. Any
alteration such as painting and coating will directly harm
thesprinklerandcausemalfunctions.Sprinklerincontact
with corrosive products should be replaced if they cannot
becleanedcompletely.
Visual inspections are recommended after installation.
After installation, a close-up inspection annually will
sufce.
Inspection and maintenance of re protection system is
the responsibility of the owner. It is recommended that
automatic sprinkler system be inspected and tested
accordingtolocaland/ornationalregulations.
Sprinkler Wrench

19
www.shieldglobal.com
DISTRIBUTION PATTERNS
K5.6STANDARDVERTICALSIDEWALL
DISTRIBUTIONPATTERNS-TRAJECTORY
K5.6STANDARDVERTICALSIDEWALL
DISTRIBUTIONPATTERNS–PLANVIEW

20
www.shieldglobal.com
DIMENSIONS

21
www.shieldglobal.com
MODEL: SD1050, SD1055
DESCRIPTION
The SHIELD Sprinklers, SD1050, SD1055 (Glass Bulb Type)
Standard and Quick Response Concealed Sprinkler, design
incorporates state-of-the-art, heat responsive, frangible glass
bulbdesignforprompt,preciseoperation.Thediecastframeis
morestreamlinedandattractivethantraditionalsandcastframes.
Itiscastwithahex-shapedwrenchbosstoalloweasytightening
from many angles, reducing assembly effort. This sprinkler is
available in various temperature ratings  and nishes to meet
many design requirements. The recessed pendent should be
utilized with a recessed escutcheon which provides up
½
” of
adjustments. All sprinklers are manufactured using the time
provenBellevillesealusedexclusivelybyallmajormanufactures
toensurelonglifeandsafeoperation.
SPRINKLER OPERATION
Theoperatingmechanismisafrangibleglassbulbwhichcontains
a heat responsive liquid. During a re, the ambient temperature
risescausingtheliquidinthebulbtoexpand.Whentheambient
temperature reaches the rated temperature of the sprinkler, the
bulbshatters.
As a result, the waterway is cleared of all sealing parts and water
isdischargedtowardsthedeector.Thedeectorisdesignedto
distribute the water in a pattern that is most effective in controlling
there.
MAXIMUM COVERAGE
Standard spray coverage is up to: Light Hazard = 225 square
feet(20.9sq.m);OrdinaryHazard=130squarefeet(12.1sq.m)per
NFPA13.
TECHNICAL SPECIFICATION
RATINGS
SPRINKLER HEAD
Concealed Sprinkler
SprinklerIdentication
Number
Standard SD1050 (bulb
5mm),QuickResponse
SD1055(bulb3mm)
Style Concealed Sprinkler
K Factor 5.6gpm/psi½.(80lpm/bar½)
ResponseTimeIndex
(RTI)
Standard 50
Quick Response 30
NominalThreadSize
½”NPT(15mm)
OriceSize 13mm
Max.WorkingPressure 175PSI(1200kPa)
FactoryHydrostaticTest 100%@500PSI(3450kPa)
Min.OperationPressure 7PSI(48kPa)
SprinklerTemperature
Classication
Norminal Sprinkler
TemperatureRating
N.F.P.AMaximumAmbient
(Ceiling)Temp.(Allowed) Glass Bulb Color
Ordinary 155ºF/68ºC 100ºF/38ºC Red
Intermediate 175ºF/79ºC 150ºF/65ºC Yellow
Intermediate 200ºF/93ºC 150ºF/65ºC Green
Note:
Shield SD1055 (3-mm bulb) is FM Approved
as standard response only. Factory Mutual do not
approve any concealed sprinklers for quick response

22
www.shieldglobal.com
PART LIST
SD1050 SD1055
1.Frame2.Deector3.Cap4.CapSeat5.LoadScrew6.Seal7.Bulb
DISCHARGE CURVE

23
www.shieldglobal.com
WARNINGS
TheSHIELD Sprinklers mustbe installed andmaintained
incompliancewiththisdocument.Depressurizeanddrain
the piping system before attempting to install, remove,
oradjustanySprinklers.Failuretodosomayimpairthe
performanceofthesesprinklers.Theownerisresponsible
for maintaining the re protection system and devices in
operation.
WRENCH DESCRIPTION
The Sprinkler Wrench is a tool specically designed for
installingSHIELDSprinklers.Thesespecialwrenchesmust
be used to provide the proper leverage when tightening the
sprinklerandtominimizeslippageduringinstallation.Any
otherwrenchmaydamagethesprinkler.
INSTALLATION
All SHIELD Sprinklers must be installed according to
NFPA 13 Standards. Deviations from these requirements
and standards or any alteration to the sprinkler itself will
void any warranty made by manufacturer. In addition,
installation must also meet local government provisions,
codesandstandardsasapplicable.
The system piping must be properly sized to insure the
minimumrequiredowrateatthesprinkler.Checkforthe
proper model, style, orice size and temperature rating
prior to installation. Install sprinklers afterthe piping isin
place to avoid mechanical damage, replace any damaged
units.Wetpipesystemsmustbeprotectedfromfreezing.
Upon completion of the installation, the system must be
testedperrecognizedstandards.Intheeventofathread
task, remove the unit, apply new pipe joint compound or
tape,andreinstall.
ADDITIONAL
Cover Plate - To install the conceal cover plate, align it
with the sprinkler and slowly turn clockwise for the cover
platesandsprinklertolockin.Makesurethecoverplateis
securely locked in, fail to do so may cause the sprinkler to
malfunction.
INSTALLATION SEQUENCE
Step1.TheunitmustbeinstalledinthePendentposition
fortheConcealedSprinkler.
Step2.Useonlyanon-hardeningpipejointcompoundor
tapeseal.Applyonlytothemale
threads.
Step3.Handtightenthesprinklerintotting.
Step4.ForConcealedSprinklers,useastandardwrench.
Tightentheunit intothetting.Alead-tightjointrequires
only 7to 14ft.-lbs(9.5 to19.0Nm) oftorque. A tangential
force of 14 to 28ft.-lbs(62.3 to124.5N) delivered through
a 6”(150mm) handle will deliver adequate torque. Once
torque level reach over 21ft.-lbs(28.6Nm) it may distort
the orice seal, resulting in leakage. For exposed piping
systems, the sprinkler should be oriented so the frame
armsareparallelwiththebranchlinepipe.
CAUTION
Do not over-tighten or under-tighten the sprinkler to
compensateforinaccurateescutcheonplateadjustment.
Protectioncapsareusedtoprotectitsbulbanddeector.
Please have cap on at all times during transportation and
interiordecorating.
MAINTENANCE
Sprinklers must never be altered after manufacture. Any
alteration such as painting and coating will directly harm
thesprinklerandcausemalfunctions.Sprinklerincontact
with corrosive products should be replaced if they cannot
becleanedcompletely.
Visual inspections are recommended after installation.
After installation, a close-up inspection annually will
sufce.
Inspection and maintenance of re protection system is
the responsibility of the owner. It is recommended that
automatic sprinkler system be inspected and tested
accordingtolocaland/ornationalregulations.
Concealed
Sprinkler Wrench

24
www.shieldglobal.com
DISTRIBUTION PATTERNS
K5.6PENDENTSPRINKLER
DISTRIBUTIONPATTERNS-TRAJECTORY
DIMENSIONS

25
www.shieldglobal.com
MODEL: SD1020, SD1021
DESCRIPTION
The SHIELD Sprinkler, SD1020, SD1021 (Glass Bulb Type) 3/8”
StandardOrice,Upright,PendentandRecessedPendent,Quick
Response, design incorporates state-of-the-art, heat responsive,
frangibleglassbulbdesignforprompt,preciseoperation.Thedie
cast frame is more streamlined and attractive than traditional sand
castframes.
Itiscastwithahex-shapedwrenchbosstoalloweasytightening
from many angles, reducing assembly effort. This sprinkler is
availableinvarioustemperatureratingsandnishestomeetmany
design requirements. The recessed pendent should be utilized
with a recessed escutcheon which provides up
”
ofadjustments.
All sprinklers are manufactured using the time proven Belleville
sealusedexclusivelybyallmajormanufacturestoensurelonglife
andsafeoperation.
SPRINKLER OPERATION
Theoperatingmechanismisafrangibleglassbulbwhichcontains
a heat responsive liquid. During a re, the ambient temperature
risescausingtheliquidinthebulbtoexpand.
When the ambient temperature reaches the rated temperature
of the sprinkler, the bulb shatters. As a result, the waterway is
cleared of all sealing parts and water is discharged towards the
deector. The deector is designed to distribute the water in a
patternthatismosteffectiveincontrollingthere.
MAXIMUM COVERAGE
Standardspraycoverageisupto:LightHazard=225
squarefeet(20.9sq.m);OrdinaryHazard=130square
feet(12.1sq.m)perNFPA13.
TECHNICAL SPECIFICATION
RATINGS
SPRINKLER HEAD
Quick Response Upright & Pendent Sprinklers
SprinklerIdentication
Number
Quick Response SD1020,
SD1021(bulb3mm)
Style Pendent Sprinkler SD1020,
Upright Sprinkler SD1021
K Factor 4.2gpm/psi½.(60lpm/bar½)
ResponseTimeIndex
(RTI)
Quick Response 30
NominalThreadSize
⅜”NPTor⅜”PT
Max.WorkingPressure 175PSI(1200kPa)
FactoryHydrostaticTest 100%@500PSI(3450kPa)
Min.OperationPressure 7PSI(48kPa)
SprinklerTemperature
Classication
Norminal Sprinkler
TemperatureRating
N.F.P.AMaximumAmbient
(Ceiling)Temp.(Allowed) Glass Bulb Color
Ordinary 135ºF/57ºC 100ºF/38ºC Orange
Ordinary 155ºF/68ºC 100ºF/38ºC Red
Intermediate 175ºF/79ºC 150ºF/65ºC Yellow
Intermediate 200ºF/93ºC 150ºF/65ºC Green
