Tyco Fire Product Star I-LD-2 User manual

Std Response - Std. Coverage
Upright and Pendent
Intermediate Level Sprinklers
Model I-LD-2
K=5.6 and 8.0
GENERAL DESCRIPTION
The Star Model I-LD-2, 5.6 and 8.0 K-Factor, Upright and
Pendent, Intermediate Level Sprinklers are standard re-
sponse - standard coverage, fusible solder type spray
sprinklers primarily designed for use in rack storage sprin-
kler systems. The Shields are intended to help prevent
water spray from higher elevation sprinklers, which could
operate earlier during a fire, from wetting the fusible ele-
ment of lower elevation sprinklers, e.g., sprinklers located
in rack storage or sprinklers located beneath open grid-
ded catwalks.
WARNINGS
The Model I-LD-2 Sprinklers described herein must be in-
stalled and maintained in compliance with this document,
as well as with the applicable standards of the National
Fire Protection Association, in addition to the standards
of any other authorities having jurisdiction. Failure to do
so may impair the integrity of these devices.
The owner is responsible for maintaining their fire protec-
tion system and devices in proper operating condition.
The installing contractor or sprinkler manufacturer should
be contacted relative to any questions.
OPERATION
A bronze tube sealed by two stainless steel balls holds a
fusible alloy. When the rated temperature is reached, the
alloy melts, the balls are forced toward each other releas-
ing the tension mechanism, which then allows the sprin-
kler to activate and flow water.
TECHNICAL DATA
Approvals
UL and ULC Listed. FM and NYC Approved.
(Refer to Table A. The approvals apply only to the service
conditions indicated in the Design Criteria section.)
Maximum Working Pressure
175 psi (12,1 bar)
Pipe Thread Connection
1/2 inch NPT for K=5.6
3/4 inch NPT for K=8.0
Discharge Coefficient
K=5.6GPM/psi
1/2 (80,7 LPM/bar1/2)
K=8.0GPM/psi
1/2 (115,2 LPM/bar1/2)
Temperature Ratings
135°F/57°C, 165°F/74°C, 212°F/100°C,
280°F/138°C, or 360°F/182°C
(Refer to Table A)
Finish
Sprinkler: Natural Brass
Physical Characteristics (Ref. Figure 1)
The Model I-LD-2 utilizes a dezincification resistant
(DZR) bronze frame with a brass deflector and shield.
The waterway is sealed with Teflon  gasketed brass but-
ton, and the fusible assembly is constructed of bronze
and stainless steel components.

DuPont Registered Trademark
SIN S1809
K=5.6 Upright
With I-LD-2
SIN S1801
K=5.6 Pendent
With Separately
Ordered I-LD-2
Shield & O-Rings
SIN S1822
K=8.0 Upright
With I-LD-2 Shield
SIN S1811
K=8.0 Pendent
With Separately
Ordered I-LD-2
Shield & O-Rings
Customer Service/Sales: Tel: [phone] • Fax: [phone]
Technical Services: Tel: [phone] • Fax: [phone]
1-4.2.20
TYCO FIRE PRODUCTS
OBSOLETE

DESIGN CRITERIA
The 5.6 and 8.0 K-Factor, Model I-LD-2 Upright and Pen-
dent, Intermediate Level Sprinklers are intended for fire
protection systems designed in accordance with the
standard installation rules recognized by the applicable
Listing or Approval agency (e.g., UL Listing is based on
NFPA 13 requirements).
STAR SPRINKLER
Page 2 1-4.2.20
FIGURE 1
5.6 K-FACTOR, MODEL I-LD-2
UPRIGHT AND PENDENT INTERMEDIATE LEVEL SPRINKLERS
NPT
1/2"
2-5/8"
(66.7 mm)
MAKE-IN
NOMINAL
(11.1 mm)
7/16"
(68.3 mm)
2-11/16"
PENDENTUPRIGHT
WRENCHING
AREA
3" (76.2 mm) DIA.
SHIELD
O-RINGS
(FIELD ASSEMBLED - SEE INSTALLATION SECTION)(FACTORY ASSEMBLED)
WRENCHING
FLANGES
MAKE-IN
NOMINAL
(11.1 mm)
7/16"
1/2"
NPT
FIGURE 2
8.0 K-FACTOR, MODEL I-LD-2
UPRIGHT AND PENDENT INTERMEDIATE LEVEL SPRINKLERS
NPT
3/4"
2-11/16"
(68.3 mm)
PENDENTUPRIGHT
WRENCHING
AREA
3" (76.2 mm) DIA.
SHIELD
O-RINGS
(FIELD ASSEMBLED - SEE INSTALLATION SECTION)(FACTORY ASSEMBLED)
WRENCHING
FLANGES
MAKE-IN
NOMINAL
3/4"
NPT
1/2"
(12.7 mm)
NOMINAL
MAKE-IN
(69.9 mm)
2-3/4"
1/2"
(12.7 mm)
OBSOLETE

INSTALLATION
The 5.6 and 8.0 K-Factor, Model I-LD-2 Sprinklers must
be installed in accordance with the following instructions:
NOTES
A leak tight 1/2 inch NPT sprinkler joint should be ob-
tained with a torque of 7 to 14 ft.lbs. (9,5 to 14,0 Nm). A
maximum of 21 ft.lbs. (28,5 Nm) of torque is to be used to
install sprinklers with 1/2 inch NPT connections. Higher
levels of torque may distort the sprinkler inlet with conse-
quent leakage or impairment of the sprinkler.
A leak tight 3/4 inch NPT sprinkler joint should be ob-
tainedwithatorqueof10to20ft.lbs.(13,4to26,8Nm).
A maximum of 30 ft.lbs. (40,2 Nm) of torque is to be used
to install sprinklers with 3/4 inch NPT connections. Higher
levels of torque may distort the sprinkler inlet with conse-
quent leakage or impairment of the sprinkler.
The O-ring seal for pendent sprinklers must be installed
to prevent possible dripping of spray onto the fusible link,
due to clearance between the shield mounting hole and
the threaded end of the sprinkler.
— Upright Sprinklers—
The Model I-LD-2 Intermediate Level Upright Sprinklers
must be installed in accordance with the following instruc-
tions.
1. With pipe thread sealant applied, hand tighten the sprinkler
into the sprinkler fitting.
2. Tighten the sprinkler into the sprinkler fitting using only the
W-Type 9 Sprinkler Wrench (Ref. Figure 3). The wrench
is to be applied to the sprinkler wrenching area shown in
Figure 1 or 2, as applicable.
— Pendent Sprinklers—
The Model I-LD-2 Intermediate Level Pendent Sprinklers
must be installed in accordance with the following instruc-
tions.
1. Roll one of the two required O-Rings over the sprinkler
threads until it seats against the sprinkler wrenching area
flange as shown in Figure 1 or 2, as applicable.
2. Install the Shield over the sprinkler threads, and then roll
the second O-Ring over the sprinkler threads until it is
seated firmly against the Shield.
3. With pipe thread sealant applied, hand tighten the sprinkler
into the sprinkler fitting.
4. Tighten the sprinkler into the sprinkler fitting using only the
W-Type 9 Sprinkler Wrench (Ref. Figure 3). The wrench
is to be applied to the sprinkler wrenching area shown in
Figure 1 or 2, as applicable.
When installed correctly, the O-Rings will be slightly
compressed and the Shield will be held firmly in place.
WRENCH
RECESS
#1849
FIGURE 3
W-TYPE 9 SPRINKLER WRENCH
STAR SPRINKLER
1-4.2.20 Page 3
SPRINKLER FINISH
Temperature
Rating
Frame
Color Code
Natural
Brass
Natural
Brass
135°F/57°C
165°F/74°C
Unpainted
Unpainted
K = 5.6 Upright (S1809)
K = 8.0 Upright (S1822)
Notes:
1. Listed by Underwriters Laboratories, Inc.
2. Listed by Underwriters’ Laboratories of Canada.
3. Approved by Factory Mutual Research Corporation as Rack Storage.
4. Approved by the City of New York under BSA 274-74-SA
TABLE A
LABORATORY LISTINGS AND APPROVALS
1, 2, 4
1, 2, 3, 4
K = 5.6 Pendent (S1801)
K = 8.0 Pendent (S1811)
1, 2, 4
1, 2, 3, 4
212°F/100°C White
280°F/138°C Blue
360°F/182°C Red 1, 2, 4 1, 2, 4
OBSOLETE

CARE AND MAINTENANCE
The 5.6 and 8.0 K-Factor, Model I-LD-2 Sprinklers must
be maintained and serviced in accordance with the follow-
ing instructions:
NOTE
Before closing a fire protection system main control valve
for maintenance work on the fire protection system which
it controls, permission to shut down the affected fire pro-
tection systems must be obtained from the proper authori-
ties and all personnel who may be affected by this action
must be notified.
Sprinklers which are found to be leaking or exhibiting vis-
ible signs of corrosion must be replaced.
Automatic sprinklers must never be shipped or stored
where their temperature will exceed 100°F/38°C and they
must never be painted, plated, coated, or otherwise al-
tered after leaving the factory. Modified or over-heated
sprinklers must be replaced.
Care must be exercised to avoid damage - before, dur-
ing, and after installation. Sprinklers damaged by drop-
ping, striking, wrench twist/slippage, or the like, must be
replaced.
The owner is responsible for the inspection, testing, and
maintenance of their fire protection system and devices in
compliance with this document, as well as with the appli-
cable standards of the National Fire Protection Associa-
tion (e.g., NFPA 25), in addition to the standards of any
other authorities having jurisdiction. The installing contrac-
tor or sprinkler manufacturer should be contacted relative
to any questions.
It is recommended that automatic sprinkler systems be in-
spected, tested, and maintained by a qualified Inspection
Service.
LIMITED WARRANTY
Products manufactured by Tyco Fire Products are war-
ranted solely to the original Buyer for ten (10) years
against defects in material and workmanship when paid
for and properly installed and maintained under normal
use and service. This warranty will expire ten (10) years
from date of shipment by Tyco Fire Products. No warranty
is given for products or components manufactured by
companies not affiliated by ownership with Tyco Fire Prod-
ucts or for products and components which have been
subject to misuse, improper installation, corrosion, or
which have not been installed, maintained, modified or re-
paired in accordance with applicable Standards of the Na-
tional Fire Protection Association, and/or the standards of
any other Authorities Having Jurisdiction. Materials found
by Tyco Fire Products to be defective shall be either re-
paired or replaced, at Tyco Fire Products’ sole option.
Tyco Fire Products neither assumes, nor authorizes any
person to assume for it, any other obligation in connec-
tion with the sale of products or parts of products. Tyco
Fire Products shall not be responsible for sprinkler sys-
tem design errors or inaccurate or incomplete information
supplied by Buyer or Buyer’s representatives.
IN NO EVENT SHALL TYCO FIRE PRODUCTS BE LI-
ABLE, IN CONTRACT, TORT, STRICT LIABILITY OR UN-
DER ANY OTHER LEGAL THEORY, FOR INCIDENTAL,
INDIRECT, SPECIAL OR CONSEQUENTIAL DAMAGES,
INCLUDING BUT NOT LIMITED TO LABOR CHARGES,
REGARDLESS OF WHETHER TYCO FIRE PRODUCTS
WAS INFORMED ABOUT THE POSSIBILITY OF SUCH
DAMAGES, AND IN NO EVENT SHALL TYCO FIRE
PRODUCTS’ LIABILITY EXCEED AN AMOUNT EQUAL
TO THE SALES PRICE.
THE FOREGOING WARRANTY IS MADE IN LIEU OF
ANY AND ALL OTHER WARRANTIES EXPRESS OR IM-
PLIED, INCLUDING WARRANTIES OF MERCHANT-
ABILITY AND FITNESS FOR A PARTICULAR PUR-
POSE.
ORDERING PROCEDURE
Please Specify:
5.6 K-Factor, Model I-LD-2
Upright Intermediate Level Sprinkler (#1809)
5.6 K-Factor, Model LD-2 Pendent Sprinkler (#1801) plus
one 1/2" NPT I-LD-2 Pendent Shield (#1568-02/05) and
two O-rings (#1426)
8.0 K-Factor, Model I-LD-2
Upright Intermediate Level Sprinkler (#1822)
8.0 K-Factor, Model LD-2 Pendent Sprinkler (#1811) plus
one 3/4" NPT I-LD-2 Pendent Shield (#1568-03/06) and
two O-rings (#1426)
W-Type 9 Sprinkler Wrench (#1849)
Refer to Price List for for complete listing of Part Num-
bers with respect to temperature ratings, sprinkler fin-
ishes, etc.
STAR SPRINKLER
Page 4 1-4.2.20
7071 S. 13th Street • Suite 103
Oak Creek, WI 53154
www.starsprinkler.com
PRINTED IN U.S.A. 3-01
OBSOLETE
