Shinco KFR-25GWZ/BM User manual

ShincoServiceManual
- 1 -
SERVICE MANUAL
Model:
KFR-25GWZ/BM
KFR-35GWZ/BM
KFR-50GWZ/BM
KFR-70GWZ/BM
Inverter Split system Air Conditioner
R410A

ShincoServiceManual
- 2 -
Table of contents
Part I
1. Introductions of Part Names and Functions
2. Outline Dimension of Indoor and Outdoor Units
3.Specification
4. Wiring Diagram
5. Refrigeration System Diagram
6. Refrigeration Piping Length and Height Difference Table
Additional Refrigerant Charge Table
7. Sensor Resistance Table
8. Parts List and exploding view
Part II
1 Service warning
2. Frequency table
3. Method of Testing the System at a Fixed Frequency
4. Running mode
5. Protection
6.Lampdisplay
Annex
1. PCB diagram
2. Schematic diagram

ShincoServiceManual
- 3 -
Part I
1. Introductions of Part Names and Functions
1.1 Remote controller

ShincoServiceManual
- 4 -
1.2 Indoor panel
1.3 Outdoor panel

ShincoServiceManual
- 5 -
2. Outline Dimension of Indoor and Outdoor Units
2.1. Outdoor unit
SIZE mm
MODEL A B C D E F G
KFR-25GWZ/BM 542 762 58 257 285 321 540
KFR-35GWZ/BM 542 762 58 257 285 321 540
KFR-50GWZ/BM 656 865 52 307 339.5 372 633
KFR-70GWZ/BM 840 950 60 352 388 425 582
