HDMI 8 Ports Splitter Amplifier by Cat5 x1
Dear Customer
Thank you for purchasing this product. For optimum performance and safety, please read these instructions
carefully before connecting, operating or adjusting this product. Please keep this manual for future reference.
1.0 INTRODUCTION
This HDMI Splitter is an HDMI splitter with eight RJ45 outputs. It distributes the input of the HDMI signal into the
eight identical outputs simultaneously. Eight HDMI Extender Receivers by Cat5 x1 receive the distributed signal
from the splitter and transmit to displays individually.
Each receiver works with the splitter as a full functional module. Only buy the most inexpensive UTP cable with
cross stand inside the full functional module to extend the HDTV display up to 165 feet for 1080p.
This HDMI Splitter offers solutions for HDTV retail and show site, HDTV, STB, DVD and Projector factory, noise,
space and security concerns, data center control, information distribution, conference room presentation, school
and corporate training environments
1.1 FEATURES
This HDMI Splitter has many features that enable it to perform in a superior manner. Among those features you
will find:
Easy to Use: Install in seconds.
One pair as a full functional module.
One piece of CAT-5e/6 cable can substitute HDMI cable to achieve long distance transmission.
Follow the standard of IEEE-568B.
Transmission distance can be up to 165 feet for 1080p using UTP cable with cross stand inside.
Supports HDMI1.2a.
Supports highest video resolution 1080p.
Supports 165MHz/1.65Gbps per channel (4.95Gbps all channel) bandwidth.
Supports 8bit per channel (24bit all channel) deep color.
Supports uncompressed audio such as LPCM.
ANI-0108HC
USERS GUIDE

HDMI 8 Ports Splitter Amplifier by Cat5 x1
2 of 4
2.0 SPECIFICATIONS
Signal Inputs/Output
Input DDC Signal
5 volts p-p (TTL)
Maximum Single Link Range
1920 x 1080p
Output Video HDMI 1.2a
Operating Frequency
Video Amplifier Bandwidth 1.65Gpbs/165MHz
Vertical Frequency Range 50/60Hz
Resolution(HDTV)
Interlaced(50&60Hz) 480i, 576i, 1080i
Progressive(50&60Hz) 480p, 576p, 720p, 1080p
Mechanical
Size of HDMI 8 Ports Splitter Amplifier (L-W-H)
17 x 8 x 1.7 in
Weight of HDMI 8 Ports Splitter Amplifier (Net) 4.9 lbs
Size of Receiver (L-W-H) 4 x 2.5 x 1 in
Weight of Receiver (Net) .85 lbs
Warranty
Limited Warranty
1 Year Parts and Labor
Environmental
Operating Temperature 32°F to +158°F
Operating Humidity 10% to 85 % RH (no condensation)
Storage Temperature
14°F to +175°F
Storage Humidity
5% to 90 % RH (no condensation)
Power Requirement
Power Supply for HDMI 8 Ports Splitter 5V DC@ 2A,10W
Power Supply for Receiver 5V DC@ 2A, 5W
Regulatory Approvals
Converter Unit FCC,CE,UL
Power Supply UL,CE,FCC
Accessories Adapter
AC Power Adapter US standard
User Manual
English Version
Note: Specifications are subject to change without notice.

HDMI 8 Ports Splitter Amplifier by Cat5 x1
3 of 4
3.0 PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and make sure the following items are contained
in the shipping carton:
Packaging of Main Unit
1) HDMI 8 Ports Splitter Amplifier
2) Users Manual
Packaging of Accessories
3) Eight Receivers
4) Nine pieces of 5V DC Power Supply
(one 5V@4A，eight 5V@2A)
4.0 PANEL DESCRIPTIONS
F
Output 4 Output 3 Output 2 Output 1
HDMI Input
Output 5Output 6Output 7Output 8
HDMI Splitter 1x8 by Cat5 x1
Receiver
DC5V
CAT5
Receiver
HDMI Extender by CAT5
X 1
HDMI Output

HDMI 8 Ports Splitter Amplifier by Cat5 x1
4 of 4
END OF DOCUMENT
11152011
5.0 CONNECTION AND OPERATION
1) Connect the single HDMI source (such as HD-DVD, PS3, STB) to the main HDMI input using a piece of
HDMI cable.
2) Connect each piece of CAT-5e/6 cable to both of the output of the HDMI 8Ports Splitter Amplifier and input
of the Receiver.
3) Connect outputs of Receivers to displays (such as HD-LCD, HD-DLP)
Plug the 5V@4A power supply into the HDMI 8Ports Splitter Amplifier and the 5V@2A power suppliers to
each Receiver individually
5.1 CONNECTION DIAGRAM
